Worktable Caster with Expanding Rubber Stem
Installation Instructions for Models 28-129S, 28-125S, 28-118S, & 28-124S
Step 1. Hold the swivel bearing (E) with one hand and turn the
grip nut (B) clockwise with the other hand to expand the
rubber sleeve (C).
Step 2. Expand the rubber sleeve (C) until it fits snugly into the
tubing. Insert all the way into the leg.
Step 3. Turn the swivel bearing (E) counter-clockwise to further
expand the rubber sleeve (C) and tighten into the leg.
Krowne Metal Corporation
100 Haul Rd. Wayne, NJ 07470 • Toll Free: (800) 631-0442 • Fax: (973) 872-1129
[email protected] • www.krowne.com • www.facebook.com/KrowneMetal • www.twitter.com/KrowneMetal
(B) Grip Nut
(C) Rubber Sleeve
(D) Plastic Spacer
(E) Swivel Bearing
(A) Complete
Stem Assembly
