13A ELECTRIC PRESSURE WASHER
2000 PSI MAX PRESSURE AT INITIAL DISCHARGE PER ITS INTERNAL PRESSURE TESTING
1.7 GPM MAX FLOW WITH NOZZLE OPEN AT MINIMUM PRESSURE
EN
Model SPX200-GO
R
OPERATOR’S MANUAL
2
SAVE THESE INSTRUCTIONS
Form No. ASP-SPX200-GO-880E-MR1 (JC)
R
13A ELECTRIC PRESSURE WASHER
2000 PSI MAX PRESSURE AT INITIAL DISCHARGE PER ITS INTERNAL PRESSURE TESTING
1.7 GPM MAX FLOW WITH NOZZLE OPEN AT MINIMUM PRESSURE
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
mWARNING! This indicates a hazardous situation, which,
if not avoided, could result in death or serious injury.
mCAUTION! This indicates a hazardous situation, which,
if not avoided, could result in minor or moderate injury.
mDANGER! This indicates a hazardous situation, which,
if not followed, will result in death or serious injury.
General Safety
mWARNING! This appliance is not intended for use
by children or by unassisted, unsupervised persons whose
physical, sensory or mental capabilities prevent them from using
it safely. Children should be supervised to ensure that they do
not play with the appliance.
Before starting up your machine, please check it carefully
for any defects. If you find any, do not start up your machine.
Contact your authorized Snow Joe
®
+ Sun Joe
®
dealer or call
the All Season Power customer service center at
1-866-225-9723.
mWARNING! When using the pressure washer, basic safety
precautions should always be followed to reduce the risk of fire,
electric shock, and personal injury. These include:
• Know your product – Know how to stop the machine and
bleed pressure quickly. Thoroughly familiarize yourself with
the controls.
• Keep bystanders away – All visitors and pets should be kept
a safe distance away from the work area.
• Use the right product – Do not use this machine for any job
except that for which it is intended.
• Dress properly – Do not wear loose clothing or jewelry. They
can get caught in moving parts. Protective rubber gloves and
non-slip footwear are recommended when working outdoors.
• mCAUTION! – Exercise caution to avoid slipping or falling.
Wear protective footwear that will protect your feet and
improve your footing on slippery surfaces.
• Stay alert – Watch what you are doing. Use common sense.
Do not operate the pressure washer when you are tired, or
under the influence of alcohol or drugs.
• WARNING! Risk of Injection or Injury – Do not direct
discharge stream at persons.
• Do not overreach – Keep proper footing and balance at
all times.
• Avoid unintentional starting – Do not carry a plugged-in
machine with your finger on the trigger. Make sure the switch
is off before plugging in the machine.
• Do not abuse the cord – Never carry the machine by the
cord or yank the cord to disconnect it from the receptacle.
Keep the cord away from heat, oil, and sharp edges.
• Use safety glasses – Also use safety footwear, snug-fitting
clothing, protective gloves, hearing and head protection.
• Check the water temperature – This pressure washer is not
meant to pump hot water. NEVER connect it to a hot water
supply as it will significantly reduce the life of the pump.
• Store indoors – NEVER store the pressure washer outdoors
or where it could freeze. The pump could be seriously
damaged.
• Inspect electrical cables – The insulation of the power cord
should be perfectly intact. If the power cord is damaged or
shows any signs of wear or tear, do not use the pressure
washer. Contact your authorized Snow Joe
®
+ Sun Joe
®
dealer or call the All Season Power customer service center
at 1-866-225-9723.
mWARNING! Do not use this appliance without reading this
instruction manual.
mWARNING! This appliance has been designed for use
with cleaning agents that are recommended by the manufacturer.
The use of other cleaning agents or chemicals may adversely
affect the safety of the appliance.
mWARNING! Do not use the appliance within range of
persons unless they are wearing protective clothing.
mWARNING! High-pressure jets can be dangerous if
subject to misuse. The jet must not be directed at persons, pets,
live electrical equipment, or the appliance itself.
• Do not direct the jet at yourself or others in order to clean
clothes or footwear.
• Risk of explosion – Do not spray flammable liquids.
• Disconnect the tool – Disconnect from the electrical
power supply before performing any maintenance task.
3
• Keep children away – This high-pressure electric
power washer must not be used by children or
untrained personnel.
• To ensure appliance safety, use only original replacement
parts from the manufacturer or those approved by
the manufacturer.
mCAUTION! To prevent damage to the appliance, do not
allow it to operate dry. Before starting the appliance, make sure
that it has a proper and stable supply of water.
mWARNING! Water that has flowed through backflow
preventers is considered to be non-potable.
mWARNING! During cleaning, maintenance or when
replacing parts, the machine must be disconnected from its
power source by removing the plug from the socket outlet.
mWARNING! High-pressure hoses, fittings, and couplings
are important for the safe operation of the appliance. Use only
hoses, fittings, and couplings recommended by
the manufacturer.
• Check for damaged parts – Do not use the appliance if the
supply cord or other important parts of the appliance are
damaged (e.g. safety devices, high-pressure hoses, trigger
gun).
mWARNING! If an extension cord is used, the plug and
socket must be of watertight construction.
mWARNING! Inadequate extension cords can be
dangerous.
• This high-pressure electric power washer must not be used
at temperatures below 32°F (0°C).
mWARNING! Power cords on drums should always be
completely unwound to prevent the cord from overheating.
• Power cord connections should be kept dry and off
the ground.
• If the power cord is damaged, do not use the appliance.
Contact your authorized Snow Joe
®
+ Sun Joe
®
dealer or call
the All Season Power customer service center at
1-866-225-9723.
• Keep the machine on a stable, flat surface during operation,
handling, transportation, and storage. Sudden overturn of the
machine can cause bodily injury.
• In the event of an accident or breakdown, switch off the
machine immediately. (If contact with detergent occurs, rinse
with an abundance of clean water.)
Electrical Safety
ATTENTION: If there are problems with the electrical MAINS,
short voltage drops may appear when starting the equipment.
This can, in turn, influence other equipment (e.g. cause a lamp
to blink). If the MAINS-IMPEDANCE Zmax < 0.335 OHM, such
disturbances are not expected. (If you require assistance,
contact your local supply authority for further information.)
mWARNING! Electrical Shock Hazard – Before starting
up your machine, please check it carefully for any defects.
If you find any, do not start up your machine and contact your
distributor.
The following should be observed when connecting the
high-pressure electric power washer to the electric supply:
• The electric supply connection should be performed by a
qualified person.
• The electric supply to this appliance should include either
a residual current device that will interrupt the supply if the
leakage current to the earth exceeds 30 mA for 30 ms or a
device that will interrupt the earth circuit (GFCI).
IMPORTANT: Only use water without any impurities. If there
is a risk of running sand into the inlet water (i.e. from your own
well), an additional filter should be installed.
Safety Devices
The unloader valve can reduce pressure if it exceeds preset
values. The spray gun features a locking device. When the lock
is activated, the spray gun cannot be operated.
1. Thermal sensor – A thermal sensor protects the motor
against overloading. The machine will restart after a few
minutes when the thermal sensor has cooled.
2. Double insulation – In a double-insulated appliance, two
systems of insulation are provided instead of grounding.
No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added
to the appliance. Servicing a double-insulated appliance
requires extreme care and knowledge of the system, and
should be performed only by qualified service personnel at
an authorized Snow Joe
®
+ Sun Joe
®
dealer. Replacement
parts for a double-insulated appliance must be identical
to the parts they replace. A double-insulated appliance
is marked with the words “Double Insulation” or “Double
Insulated.” The symbol (square within a square) may
also be marked on the appliance.
3. Ground fault circuit interrupter (GFCI) protection – this
product is provided with a Ground Fault Circuit Interrupter
built into the power cord plug. This device provides
additional protection from the risk of electric shock.
If replacement of the plug or cord is needed, use only
identical replacement parts that include GFCI protection.
4
4. It is not recommended to use an extension cord with this
pressure washer. The unit comes standard with a 35 ft GFCI
power cable. Using an extension cord may cause a drop in
line voltage resulting in loss of power and overheating.
Use only extension cords that are intended for outdoor
use. These extension cords are identified by marking
"Acceptable for use with outdoor appliance; store indoors
while not in use". Use only extension cords having an
electrical rating not less than the rating of the product.
Do not use damaged extension cords. Examine extension
cord before using and replace if damaged. Do not abuse
extension cord and do not yank on any cord to disconnect.
Keep cord away from heat and sharp edges. Always
disconnect extension cord from the receptacle before
disconnecting the product from the extension cord.
5. To reduce the risk of electric shock, this appliance has a
polarized plug (i.e. one blade is wider than the other). The
appliance plug will fit into a polarized outlet only one way.
If the appliance plug does not fit fully into the outlet, reverse
the plug. If the plug still does not fit, make sure that you are
using the correct polarized wall outlet. If the plug still does
not fit, contact a qualified electrician to install the proper
wall outlet. Do not modify the appliance plug, power cord
receptacle, or power cord plug in any way.
6. To prevent the appliance cord from disconnecting from the
extension cord during operation, make a knot with the two
cords as shown in Table 1.
7. Do not abuse the cord. Never pull the pressure washer
by the cord or yank the cord to disconnect it from the
receptacle. Keep the cord away from heat, oil, and
sharp edges.
Risk of Electrocution
• Inspect cord before using.
• Do not use if cord is damaged.
• Keep all connections dry and off the ground.
• Do not touch plug with wet hands.
• Keep cord away from heat and sharp edges.
• Do not spray electrical apparatus and wiring.
Risk of Explosion
• Do not spray flammable liquids.
• Do not use acids, bases, solvents, or any flammable material
in this product. These substances can cause physical injuries
to the operator and irreversible damage to the machine.
Additional Safety Instructions
• High-pressure: keep clear of nozzle.
• Injection hazard: equipment can cause serious injury if the
spray penetrates the skin.
• Do not point the gun at anyone or at any part of the body.
• In case of skin penetration, seek medical aid immediately.
• Before servicing, cleaning, or removing any parts, shut off the
power and relieve pressure.
• This machine is not suitable for connection to the potable
water mains.
m WARNING m
Electric shock may cause SEVERE INJURY or DEATH.
Heed these warnings:
• Do not allow any part of the electric pressure washer
to make contact with water while it is in operation. If
the appliance becomes wet while turned off, wipe dry
before starting.
• Do not use an extension cord over 25 ft. The pressure
washer comes equipped with a 35 ft power cable.
Combined cord length must not exceed 60 ft. Any
extension cord must be 14-gauge (or heavier) to safely
power the pressure washer.
• Do not touch the appliance or its plug with wet hands
or while standing in water. Wearing rubber boots offers
some protection.
EXTENSION CORD CHART
Cord Length:
Min. Wire Gauge (A.W.G.):
25 ft (7.6 m)
14
(B) Connect plug and receptacle
Cord set Appliance cord
(A) Tie cord as shown
Table 1. Method of Securing Extension Cord
5
Product Description
Purpose
• This high-pressure electric power washer is intended for
residential use to clean vehicles, equipment, buildings, and
similar surfaces.
Areas of Application
• Never use the machine in potentially explosive areas under
any circumstances!
• The operating temperature must be between 32°F (0°C) and
104°F (40°C).
• The machine consists of an assembly with a pump, which is
encased in a shock-absorbing housing. To provide the operator
with an optimal working position, the machine is equipped with
a stainless steel lance and a non-slip handle grip, whose shape
and configuration comply with applicable regulations.
• Do not cover or modify the stainless steel lance or the spray
nozzles in any way.
• The high-pressure electric power washer is designed to be
used with cold or lukewarm water; higher temperatures can
damage the pump.
• Do not use water that is dirty, gritty, or contains any chemical
products, as these could impair operation and shorten the life
of the machine.
6
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
To reduce the risk of injury, user
must keep all bystanders at least
49 ft (15 m) away.
Sound power level is 96 dB(A).
Always keep the power cable away
from heat sources, oils, or sharp
edges. Immediately remove plug from
the mains if the cable is damaged,
frayed, or entangled.
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting to
assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
WEAR EYE AND HEARING
PROTECTION – For protection
against injury, wear ear defenders
and safety goggles.
Double Insulation – When servicing,
use only identical replacement parts.
WARNING! Do not expose the unit
to rain or wet conditions. Keep dry.
Machine not suitable for connection
to the potable water mains.
WARNING! Electrical shock hazard.
WARNING! Turn the machine OFF
and disconnect it from the power
supply before inspecting, cleaning,
changing accessories, or conducting
any other maintenance task.
Symbols SymbolsDescriptions Descriptions
Wear non-slip footwear that will
protect your feet and improve your
footing on slippery surfaces.
Wear safety gloves during
use to protect hands.
Store indoors. Never store the
pressure washer outdoors.
If the pump freezes, permanent
damage may result.
7
Know Your Electric Pressure Washer
Read the owner’s manual and safety instructions carefully before operating the electric pressure washer. Compare the illustration
below to the electric pressure washer in order to familiarize yourself with the location of the various controls and adjustments. Save
this manual for future reference.
1. Safety Lock
2. Trigger
3. High-Pressure Hose Connection
4. Trigger Gun
5. Stainless Steel Lance
6. Transport Handle
7. Hose Holder
8. Gun Holder
9. Cord Holder
10. On/Off Switch
11. Power Cord with GFCI
12. High-Pressure Washer
13. Water Outlet
(High-Pressure Connection)
14. Wheel (2)
15. Detergent Bottle
16. Needle Clean-Out Tool
17. 0°/15°/ 25°/ 40°
Quick Connect Nozzles
18. High-Pressure Hose
111
1
6
7
15
16
17
18
8
9
10
11
12
13
14
2
3
4
5
8
Technical Data
Rated Voltage ................................................................ 120V ∼ 60 Hz
Motor ........................................................................................ 13 - amp
Max Water Inlet Temperature ........................................ 104°F/40°C
Max Water Inlet Pressure ...................................................... 0.7 MPa
Max Pressure at initial discharge per ................................2000 PSI
ITS internal pressure testing
Rated Pressure under typical load ................................... 1500 PSI
Max Flow with nozzle open ..............................1.7 GPM (6.8L/MIN)
at minimum pressure
Rated Flow under typical load ......................... 1.2 GPM (4.5L/MIN)
Hose Length ........................................................................ 20 ft (6 m)
Detergent Bottle Capacity ................................. 13.53 fl oz (400 ml)
Power Cord Length ....................................... 35 ft (GFCI Protected)
Net Weight .................................................................... 17.6 lbs (8 kg)
Gross Weight ............................................................ 19.6 lbs (8.9 kg)
Unpacking
Carton Contents
• Electric pressure washer
• Transport handle
• Trigger gun
• Stainless steel lance
• Four (4) Quick-Connect nozzles (0°, 15°, 25°, and 40°)
• Detergent bottle
• Trigger gun holder
•Screws (x 4)
• Cord holder
• Needle clean-out tool
• High-pressure hoses
• Manual
1. Carefully remove the pressure washer and check to see that
all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you find damaged or
missing parts, DO NOT return the unit to the store. Please
call the All Season Power customer service center at
1-866-225-9723.
NOTE: Do not discard the shipping carton and packaging
materials until you are ready to use your new electric
pressure washer. The packaging is made of recyclable
materials. Properly dispose of these materials in
accordance with local regulations.
IMPORTANT! The equipment and packaging materials are
not toys. Do not let children play with plastic bags, foils, or small
parts. These items can be swallowed and pose a suffocation
risk!
mWARNING! Do not connect to power supply until
assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
Assembly
1. Position the washer as CLOSE as possible to the
water supply.
2. The washer must be used on a secure and stable surface in
a standing, upright position (Fig. 1).
3. Slide the trigger gun holder, hose holder and cord holder
into position (Fig. 2).
Fig. 1
9
4. Slide the handle into position (Fig. 3).
5. Store the hose in place (Fig. 4). This allows the hose to be
securely stored when nozzle not in use.
6. Attach the detergent bottle to the hook on the back of the
hose holder, and press it down firmly to ensure it is securely
stored (Fig. 5).
7. Put the nozzle in the storage part (Fig. 6).
8. Insert the trigger gun into the trigger gun holder (Fig. 7).
1
1
10
9. Fit the stainless steel lance into the trigger gun and make
sure the two parts are completely locked (Fig. 8).
10. Connect the high-pressure hose to the trigger gun
(Fig. 9).
11. Connect the high-pressure hose to the outlet on the washer
(Fig. 10).
mWARNING! Keep hose away from sharp objects. Bursting
hoses may cause injury. Examine hoses regularly and replace if
damaged. Do not attempt to mend a damaged hose.
12. Connect the garden hose adapter (female coupler) to
the water inlet of the pressure washer, then thread your
garden hose (male end) into the garden hose adapter
(Fig. 11). The garden hose must have an internal diameter
of at least 13 mm (1/2 in.) and must be reinforced. The
water supply must be at least equal to the washer delivery
capacity.
mWARNING! The machine is not suitable for connection to
the potable water main.
13. Attach garden hose to water supply (Fig. 12).
mWARNING! The intake water temperature must not
exceed 104ºF/40ºC. The water supply must not exceed
0.7 MPa.
mCAUTION! The washer must only be used with clean
water; use of unfiltered water containing corrosive chemicals will
damage the washer.
14. Make sure the On/Off switch is set to the OFF position
before plugging the unit into the power outlet (Fig. 13).
Stainless Steel Lance
Trigger Gun
1
High-Pressure Hose
Trigger Gun
Quick Connector Lock
High-Pressure
Water Outlet
Quick Connector
Garden
Hose
Adapter
Nozzle storage
Garden
Hose
Connect to water supply
Garden hose
11
15. Check that the electrical supply voltage and frequency
(Volt/Hz) correspond to those specified on the pressure
washer rating plate. If the power supply is correct, you may
now plug the pressure washer into the power outlet
(Fig. 14).
NOTE: The GFCI may need to be reset when first plugged
into the electric outlet. Press the "Reset" button until the
power light indicator on the GFCI illuminates.
Operation
mIMPORTANT! This pressure washer is equipped with
a micro-switch sensitive to water flow. This Total Stop System
(TSS) senses water flow in the pump. When the trigger is
released, water stops flowing through the pump. The TSS then
automatically turns the motor off to protect the pump from
overheating, thus saving energy and prolonging pump life.
1. Turn the water supply tap on completely.
2. Make sure the safety lock is down and in its original
position (Fig. 15), then press the trigger for a few seconds
until water flow is steady. This will allow air to escape and
discharge any residual pressure in the hose.
3. Turn the switch to the ON position to start the pressure
washer (Fig. 16).
Using the Nozzles
Before beginning any cleaning task, determine the best nozzle
for the job. Each of the nozzles has a different spray pattern.
The nozzle patterns are 40° (for gentle cleaning), 25° (for all-
purpose cleaning), 15° (for tough jobs), and the 0° (for spot
cleaning or hard-to-reach areas).
mCAUTION! NEVER change nozzles without locking the
safety lock on the trigger handle.
mWARNING! High-pressure jets can be dangerous if
subject to misuse. The jet must not be directed at persons, pets,
live electrical equipment, or the appliance itself.
This electric pressure washer is equipped with four (4) Quick-
Connect nozzles that easily snap onto the Quick-Connect collar
of the stainless steel lance.
To connect a nozzle to the stainless steel lance:
1. Turn off the pressure washer and shut off the water supply.
Pull the trigger to release water pressure.
1
Reset
Test
Power light
indicator
1
12
2. Press the trigger and then turn the safety lock to make sure
it is locked (Fig. 17).
3. Snap the desired nozzle onto the Quick-Connect collar until
it clicks into place (Fig. 18).
To disconnect a nozzle from the stainless steel lance once the
cleaning job is complete:
4. Turn off the pressure washer and shut off the water supply.
Pull the trigger to release water pressure.
5. Engage the safety lock on the trigger handle by pushing up
on the safety lock until it clicks into the slot (Fig. 17).
6. Remove the nozzle by placing your hand over the nozzle
while pulling back on the Quick-Connect collar.
mWARNING! Do not make changes to the nozzle while
the trigger is engaged. Doing so could result in damage to the
pressure washer or injury to the user.
Working with Detergents
When cleaning with the pressure washer, some cleaning tasks
can be solved with water alone, but for most tasks cleaning with
detergent allows for more effective dirt removal.
For additional cleaning power, the unit comes equipped with a
detergent spray bottle.
mWARNING! Use only detergents specifically designed for
use with pressure washers, such as Sun Joe
®
HOUSE + DECK
WASH (SPX-HDC1G), Sun Joe
®
SNOW FOAM AUTO WASH
(SPX-FCS1G), or Sun Joe
®
HEAVY DUTY CLEANER (SPX-
APC1G). DO NOT USE household detergents, acids, alkaline
solutions, bleaches, solvents, flammable material, or industrial
grade solutions. These could damage the pressure washer.
Many detergents may require mixing prior to use. Prepare the
cleaning solution as instructed on the solution bottle.
1. Remove the detergent bottle with foam cannon from the
nozzle storage board. Remove the foam cannon cap with
detergent suction tube from the detergent bottle.
2. Fill the detergent tank with detergent designed specifically
for use with pressure washers (Fig. 19).
3. Recap the detergent bottle, and attach it to the stainless
steel lance by snapping it onto the Quick-Connect collar
until it clicks into place (Fig. 20).
4. Twist to open the soap bottle, add the recommended
detergent, tighten the soap bottle after completing the
installation as shown in the figure above, then you can start
using it (Fig. 21).
Fig. 19
Detergent tank
Pressure washer
detergent
Safety lock
Click
Stainless steel lance
Quick-Connect collar
Quick Connect
Nozzle
1
13
5. Apply detergent from the bottom to the top of the dry
surface to be cleaned. Applying detergent in this manner
will dissolve dirt most effectively.
NOTE: Wetting the surface first is not recommended as it
dilutes the detergent and reduces its cleaning ability.
mCAUTION! Always test the detergent in an inconspicuous
area before use.
6. Allow the detergent to remain on the surface for a short
time before rinsing with the pressure washer. Do not allow
the detergent to dry on the surface.
mCAUTION! Damage may occur to painted surfaces if the
detergent is allowed to dry on them. Wash and rinse a small
section at a time. Avoid working on hot surfaces or in direct
sunlight.
Rinsing with the Pressure Washer
1. Turn off the pressure washer and shut off the water supply.
2. Pull the trigger to release water pressure.
3. Engage the safety lock on the trigger handle by pushing up
on the safety lock until it clicks into the position.
4. Remove the detergent bottle with foam cannon by holding
the bottle while pulling back on the Quick-Connect collar.
5. Select the right nozzle for the job (Fig. 22):
i) The 0º intense-jet nozzle (red) is an extremely powerful
nozzle that delivers a high-pressure, pencil-point jet
stream. It is used to cut heavy dirt deposits in a small,
concentrated area. It is ideal for dissolving stubborn
substances, like tar and grease spots on concrete, or for
removing caked mud from equipment. Use this nozzle
to clean hard-to-reach areas including the facades of
2-story buildings or the undersides of lawn mowers and
tractors.
NOTE: Care should be used when choosing the right
nozzle to avoid permanently gouging wood or damaging
fragile surfaces.
ii) Use the 15° fan-tip nozzle (yellow) for intense cleaning
jobs on hard surfaces. Applications include stripping
paint, removing oil stains, grease, heavy mildew stains,
and rust from steel. This nozzle should only be used
in areas that can withstand the high-pressure from this
nozzle.
iii) Use the 25° fan-tip nozzle (green) to clean home siding,
brick patios, wood decks, driveways, or sidewalks. When
using this nozzle, test a small area first to avoid surface
damage.
iv) Use the 40° wide-spray tip nozzle (gray) to clean items
such as cars, trucks, boats, patio furniture, or lawn
equipment.
6. Start at the top of the area to be rinsed and work your way
down, making sure to overlap your strokes.
14
mIMPORTANT! NEVER USE:
• Bleach, chlorine products, and other corrosive chemicals
• Liquids containing solvents
(e.g. paint thinners, gasoline, oils)
• Tri-sodium phosphate products
• Ammonia products
• Acid-based products
These chemicals will harm the unit and will damage the cleaning
surface.
Shutting Down
1. Turn the switch to the OFF position and unplug the power
cord from the outlet.
2. Turn off the water source.
3. Hold the trigger to release water pressure.
4. Disconnect the garden hose from the water inlet on
the unit.
5. Disconnect the high-pressure hose connection on the
trigger gun handle.
6. Release the trigger and engage the gun safety lock.
mWARNING! Turn off the water supply and squeeze the
trigger to depressurize the unit. Failure to do so could result in
personal injury due to discharge of high-pressure water.
Taking a Break
If you are taking a break of five minutes or more between
cleaning tasks:
1. Engage the gun safety lock (Fig. 17).
2. Turn the switch to the OFF position.
3. Unplug the power cord from the outlet.
Storage
mCAUTION! Always store your pressure washer in a
location where the temperature will not fall below 32ºF (0ºC).
The pump in this machine is susceptible to permanent damage
if it freezes. FREEZE DAMAGE IS NOT COVERED BY THE
WARRANTY.
• Store the pressure washer indoors in a dry, covered area
where it is not subject to adverse weather conditions.
• It is important to store this product in a frost-free area.
• Always empty water from all hoses, the pump, and the
detergent bottle before storing.
mCAUTION! The use of a pump protector is recommended
to prevent cold weather damage during storage over the winter
months.
Winterizing + Long-Term Storage
If you must store your pressure washer in a location where the
temperature falls below 32ºF (0ºC), you can minimize the chance
of damage to your machine by utilizing the following procedure:
• Disconnect all water connections.
• Turn on the machine for a few seconds until the remaining
water in the pump exits. Turn off immediately.
• Do not allow the high-pressure hose to become kinked.
• Store the machine and accessories in a room that does not
reach freezing temperatures.
• Do not store near a furnace or other sources of heat that
may dry out the pump seals.
• Operate the pressure washer with non-corrosive/non-toxic
anti-freeze, a pump saver, or a pump protector before
storing for the winter.
mWARNING! Before reusing, completely flush the unit
out with clear water. Anti-freeze products can damage paintwork,
so you must ensure there is no anti-freeze left in the system
before using it again.
Maintenance
mCAUTION! Before working on the pressure washer,
disconnect the plug from the power supply socket.
1. To ensure good performance, check and clean the water
inlet filter (Fig. 23). Remove the water inlet filter and rinse it
with warm water to prevent any foreign matter from clogging
the pump (Figs. 24 – 25).
Garden
Hose
Adapter
Garden Hose
Water Inlet Filter
15
2. Clean the nozzle with the needle clean-out tool provided
(Fig. 25). Remove the stainless steel lance from the gun;
remove any dirt from the nozzle hole and rinse.
3. Remove additional debris by back flushing water through
the nozzle and stainless steel lance. To do this, place the
end of your garden hose (with water running) to the tip
of the nozzle, pushing water and debris out of the back
opening of the nozzle and stainless steel lance.
Disposal
Recycling the Washer
• Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities.
• Contact your local government agency for information
regarding the collection systems available.
• If electrical appliances are disposed of in landfills
or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your
health and well-being.
• When replacing old appliances with new ones, the retailer
is legally obligated to take back your old appliance for
disposal at least free of charge.
Service + Support
If your Sun Joe
®
SPX200-GO electric pressure washer requires
service or maintenance, please call the All Season Power
customer service center at 1-866-225-9723.
Model + Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into the
space provided below.
Record the following numbers from the housing or handle of your
new product:
S P X 2 0 0 - G
O
Model #:
Serial #:
Fig. 21
1
16
Troubleshooting
• Disconnect the unit from the electrical power supply before carrying out maintenance on the machine or when checking that its
parts are in proper working order.
• The hose must be connected and the water turned on before operating your unit. Failure to do so will damage the pump motor
and void your warranty.
• Total Stop System (TSS) – The motor will shut OFF and remain in standby mode during periods of inactivity, or as soon as the unit
is pressurized. THIS IS NORMAL. Simply squeeze the trigger to restart the pump motor.
• To avoid unnecessary hassles, consult the following table before contacting customer service with any mechanical issues.
Problems Possible Cause Possible Solution
Machine refuses
to start
• Power failure/machine not plugged
into a working receptacle.
• Defective socket.
• Fuse has blown.
• Defective extension cord.
• Check to make sure machine is plugged into
a working outlet.
• Check the power cord and reset the GFCI.
Try a different outlet.
• Replace fuse. Switch off any other machines
that are using the same circuit.
• Try the unit without an extension cord.
• Check the hoses and connections are airtight.
• Clean or replace valves/seals.
• Please call the All Season Power customer
service center at 1-866-225-9723 for assistance.
• Replace fuse. Switch off other machines using
the same circuit.
• Check that the mains voltage corresponds to
specification on the model tag.
• Leave the washer for 5 minutes to cool down.
• Clean the nozzle.
• Install a fuse with a higher amp rating than the amp
consumption of the machine. Try the unit without an
extension cord.
• Allow machine to run by holding the trigger until
regular working pressure resumes.
• Check that the water supply corresponds to the
specifications required.
• WARNING! Avoid using long, thin hoses
(minimum 1/2 in. diameter).
• Clean the nozzle.
• Clean the water inlet filter.
• Straighten out the hose to remove any kinks/blockages.
• Please call All Season Power customer service center at
1-866-225-9723 for assistance.
• Wait for pump/hoses or accessories to thaw.
• Connect inlet water.
• Clean the water inlet filter.
• Clean the nozzle.
• Pump sucking air.
• Valves dirty, worn out, or stuck.
• Pump seals worn out.
• Fuse has blown.
• Incorrect mains voltage.
• Thermal sensor activated.
• Nozzle partially blocked.
• Fuse too small.
• Air in inlet hose.
• Inadequate supply of mains water.
• Nozzle partially blocked.
• Water filter blocked.
• Hose kinked.
• Pump/spray gun is leaking.
• Trigger mechanism is broken.
• Pump/hoses or accessories frozen.
• No water supply.
• Water inlet filter blocked.
• Nozzle blocked.
Fluctuating pressure
Machine stops
Fuse blows
Machine pulsating
Machine often starts
and stops by itself
Machine starts, but no
water comes out
17
Optional Accessories
mWARNING! ALWAYS use only authorized Snow Joe
®
+ Sun Joe
®
replacement parts and accessories. NEVER use replacement
parts or accessories that are not intended for use with this electric pressure washer. Contact All Season Power if you are unsure
whether it is safe to use a particular replacement part or accessory with your pressure washer. The use of any other attachment or
accessory can be dangerous and could cause injury or mechanical damage.
ModelAccessories Description
1
2
SPX-HDC1G
SPX-FCS1G
SPX-APC1G
Concentrated house and deck cleaner for Sun
Joe
®
pressure washers
Premium car wash soap and foaming detergent
for Sun Joe
®
pressure washers
High-performance multipurpose cleaner and
degreaser for Sun Joe
®
pressure washers
3-Pack Pressure Washer Concentrate
SPX-ASST3Q
NOTE: Accessories are subject to change without any obligation on the part of All Season Power to provide notice of such changes.
Accessories can be ordered online at shopjoe.com or via phone by contacting the All Season Power customer service center at
1-866-225-9723.
Sun Joe’s complete line of premium pressure washer accessories and attachments
make it easy to get your dirty work done, and also help you get the most out of your model!
SHOP ONLINE now at shopjoe.com
18
R7_06022025
OUR CUSTOMER PROMISE + LIMITED WARRANTY
OUR WARRANTY:
All Season Power warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when
used for ordinary household use for a period of two years from the date of purchase or delivery by the original, end-user purchaser when
purchased from All Season Power or from one of All Season Power’s authorized sellers with proof of purchase. Because All Season Power
is unable to control the quality of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not
cover Products purchased from unauthorized sellers. If you have any questions about how to buy from an authorized seller, chat with us at
shopjoe.com/support or call us at 1-866-225-9723. If your Product does not work or there’s an issue with a specific part that is covered
by the terms of this Warranty, All Season Power will elect to either (1) send you a free replacement part, (2) replace the Product with a new
or comparable product (which may include a refurbished, like-new product) at no charge, or (3) repair the Product. How cool is that!
PRODUCT REGISTRATION:
All Season Power strongly encourages you to register your Product. You can register online at shopjoe.com/register, by chatting with us at
shopjoe.com/support
or calling our Customer Service Department at 1-866-225-9723. Failure to register your Product will not diminish your
warranty rights. However, registering your Product will allow All Season Power to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by All Season Power to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not affect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased at
shopjoe.com or by calling 1-866-225-9723.
We encourage you to use CERTIFIED AUTHENTIC Snow Joe
®
, Sun Joe
®
, Aqua Joe
®
+ Auto Joe
®
replacement parts + accessories. Damage
caused by the use of any other parts + accessories on your Product will not be covered under the warranty. Genuine parts + accessories
can be found and purchased here by entering the model number of your product.
ABOVE ALL ELSE, All Season Power, LLC (“All Season Power”) is dedicated to you, our customer. We strive to make your experience as
pleasant as possible. Unfortunately, there are times when a Snow Joe
®
, Sun Joe
®
, Aqua Joe
®
or Auto Joe
®
product (“Product”) does not
work or breaks under normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have
a Limited Warranty (“Warranty”) for our Products.
When you register your powered or non-powered Product with All Season Power at shopjoe.com/register, you will receive an additional
90 days of warranty coverage. In addition, you will have the option of purchasing extended warranty coverage beyond the standard 2-year
manufacturer’s warranty. Choose from one, two, or three years of extended coverage through Extend, Inc. Additional charges apply. When
you Go With Joe
®
, you’re not just buying an extended warranty; you’re buying total peace of mind to know that you can rely on our top-notch
tools, top-tier customer support, complete product coverage + no hassle return policy. Chat with us at shopjoe.com/support or call us at
1-866-225-9723 7 days a week 10AM-6PM EST. We’ve got you covered!
There are no warranties which extend beyond those stated herein. ANY IMPLIED WARRANTIES THAT MAY BE APPLICABLE TO
PRODUCTS, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
IN DURATION TO THE DURATION OF THIS WARRANTY. Some States do not allow limitations on how long an implied warranty lasts, so
the above limitation may not apply to you.
UNDER NO CIRCUMSTANCES SHALL WE BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES BASED UPON
BREACH OF THIS LIMITED WARRANTY, BREACH OF CONTRACT OR STRICT LIABILITY. Some States do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights which vary from State to State. This warranty supersedes those printed in product manuals.
EN
R
19
R
shopjoe.com
R
