MODEL VT-8165
SKU 24358
INPUT VOLTAGE AC: 220-240V, 50/60 Hz
RATED CURRENT 6A
RATED LOAD
Max. 1200W
600W +LED
WOOD/GLASS
POWER CONSUMPTION
THICKNESS
≤ 40mm
<05W
WORKING
TEMPERATURE
-20°C to +50°C
IP RATING IP20
DIMENSION
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
INSTRUCTION MANUAL
TOUCH SENSOR
TECHNICAL DATA
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product.
V-TAC LED
RANGE (UPTO 600W)
COMPATIBLE WITH
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: [email protected]
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
WIRING DIAGRAM
TEST
INSTALLATION INSTRUCTIONS
Figure 1 Figure 2
WARNING
1. Switch o the power supply.
2. Install the product’s sensing component on the wooden or glass door (thickness ≤
40 mm) using double-coated adhesive tape. Install the product’s power unit on the
wall using the two supplied expansion screws, as shown in Figure 1.
3. Connect the power supply and load to the sensor according to the wiring diagram.
4. Switch on the power supply and test the operation as shown in Figure 2.
1. Switch on the power supply.
2. When your hand touches the back side of the object where the sensor is installed,
the sensor detects the action and turns the light on immediately. The light will switch
o when the IR sensor detects another touch by hand.
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. For indoor use only.
