User Manual
TK-866C
PORTABLE BATTERY SPEAKER
1
2
Control Panel Function
1.Long press to power on/off, short press to access the menu (volume,
treble, bass, microphone volume, Echo)
2.Press and hold to adjust volume -, short press to switch previous
song tracks (FM stations)
3.Press and hold TWS for a long press, short press to pause playback
(FM search)
4.LED display
5.Press and hold to adjust volume+, short press to switch
tracks (FM stations)
6.Short press to input selection (BT/USB/FM/AUX),Press and hold the LED
7.
9.
10.TF
11.AUX input
12.MIC1: Microphone input
13.MIC2: Microphone input
next song
AC power input
8.Charging lndicator
RED = Charging Light off = Fully Charged
USB Jack
card input
PORTABLE BATTERY SPEAKER
MODEL: MPD866XB
POWER CONSUMPTION: 6 0W
DRIVER UN IT: 2*8"+3*1"
POWER SUPPLY: AC 110 -240V/60 -50Hz
FCC ID:
MADE IN CHINA
1 2 3 4 5 6
7 8 9 10 11 12 13
Operating instructions
1.playing
Turn on the power switch, Press and hold the volume up or down button to adjust
the volume to the desired level.
Switch on, and EQ adjustment in accordance with your preferences.
You then are able to enjoy the wonderful & professional glamour brought by
the product.
2.Karaoke performance
Plug in the microphone, and then turn the knobs to adjust microphone
volume for optimizing the performance, press power switch.
Note:
after using, please turn down the volume first.
Then switch off the
power and pull out the power plug.
FM Operation
Press INPUT
button to switch to FM mode, short press PLAY/PAUSE button to
automatically scan radio station, by pressing PREVIOUS or NEXT
you can select
a previous or next radio station.
Bluetooth:
Press the INPUT
button on the panel control to select Bluetooth mode.
Simultaneously open the Bluetooth setting on your phone, tablet or any other
Bluetooth enabled audio device and select "Tk-866C".
SPECIFICATIONS
Power Output: 60W
Frequency Response
for main speaker: 30Hz-20KHz
Power Supply:
AC110-240V,50~60Hz
Battery: 7.4V 4000mAh
FCC Warnning:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable
protection againstharmful interference in a residential installation. This equipment generates,
uses and can radiateradio
frequency
energy
and,
if
not
installed
and
used
in
accordance
with
the
instructions,
maycause
harmful
interference
to
radio
communications.
However,
there
is
no
guarantee
thatinterference
will
not
occur
in
a
particular
installation.
If
this
equipment
does
cause
harmfulinterference to radio or television reception, which can be
determined by turning the equipmentoff
and
on,
the
user
is
encouraged
to
try
to
correct
the
interference
by
one
or
more
of
thefollowing measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution:
Any
changes
or
modifications
to
this
device
not
explicitly
approved
by
manufacturer
could void your authority to operate this equipment.
This
device
complies
with
part
15
of
the
FCC
Rules.
Operation
is
subject
to
the
following
two
conditions:
(1)This
device
may
not
cause
harmful
interference,
and
(2)
this
device
must
accept
any
interference received, including interference that may cause undesired operation.
This
equipment
complies
with
FCC
radiation
exposure
limits
set
forth
for
an
uncontrolled
environment.
This
equipment
should
be
installed
and
operated
with
minimum
distance
20cm
between the radiator and your body.
