INSTALLATION GUIDE
PBF Pre-construction Board Installation guide
PBF (
FLUSH
) PRE-CONSTRUCTION BOARD INSTALLATION GUIDE
Before installing the PBF pre-construction board,
we recommend securing two horizontal studs, at
PBF board height, between the vertical studs of
the chosen installation location to add additional
support.
1
2
Measure the PBF board and make an outline of the
board on a new panel of sheet rock.
4
3
After this has been done, ensure that the
board is level before fully securing it to the
wall studs.
Lay the frame panel of sheet rock over the PBF
board and fasten the frame to studs of the wall.
6
5
Cut along the traced path to make a frame for
the pre-construction board.
Once the board has been properly leveled, fasten
the PBF board to the vertical and horizontal studs.
James Loudspeaker | 535 Airpark Road, Napa, CA 94558 | 707.265.6343 | www.JamesLoudspeaker.com
®
20171027
PBF PRECONSTRUCTION BOARD INSTALLATION GUIDE
8
After the speaker installation is completed, the
grille will be flush with the wall.
Mount the speaker bracket to the wall, and begin
the speaker installation process.
7
8
After you finish the mudding process,the inner
plug can now be removed and sanding can be
performed to remove any unwanted surface
features.
Now, cover the seams around the board with
mesh tape, and begin the mudding process.
Make sure to apply mud up to the lip of the PBF
board.
7
10
9
