Bagless Vacuum Cleaner
User's manual
EN
EN-1
SVC 1030 (Cat & Dog)
Before first use, please read all instructions contained in this user's manual carefully, even if you are already
familiar with using similar products. Only use this product in accordance with the instructions described in the
user's manual. Keep the user's manual in a safe place where it can be easily retrieved for future use.
Save the original packaging, including the internal packing material, warranty card and proof of purchase receipt,
at least for the duration of the warranty. If you need to ship this product, pack it in the original cardboard box
to ensure maximum protection during shipping or transport (e.g. when moving or when you need to send this
product for repair).
2019 09/2019
Translation of the original manual
EN-2
EN
Bagless Vacuum Cleaner
SVC 1030 (Cat & Dog)
2019 09/2019
CONTENTS
IMPORTANT SAFETY NOTICE .............................................................. 3
DESCRIPTION ......................................................................... 5
ASSEMBLY ........................................................................... 6
USING YOUR VACUUM CLEANER .......................................................... 6
USING YOUR ACCESSORIES .............................................................. 7
STORAGE OF VACUUM CLEANER .......................................................... 8
CLEANING AND MAINTENANCE ........................................................... 8
TROUBLESHOOTING ................................................................... 11
TECHNICAL SPECIFICATIONS ............................................................. 12
PRODUCT INFORMATION SHEET .......................................................... 12
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS ....... 12
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES ................................. 12
Bagless Vacuum Cleaner
SVC 1030 (Cat & Dog)
EN
EN-3
2019 09/2019
IMPORTANT SAFETY NOTICE
READ CAREFULLY AND STORE FOR FUTURE USE.
■ This vacuum cleaner may be used by children 8 years of age
and older and by persons with physical or mental impairments
or by inexperienced persons, if they are properly supervised
or have been informed about how to use this vacuum cleaner
in asafe manner and understand the potential dangers.
Children must not play with the vacuum cleaner. Cleaning and
maintenance performed by the user must not be performed
by unsupervised children. Keep the vacuum cleaner and its
accessories out of reach of children that are younger than
8 years of age.
■ This vacuum cleaner is designed for use in households, offices
and similar types of areas. Do not use in industrial surroundings.
■
Do not expose the vacuum cleaner to direct sunlight and do not
place it near an open fire or appliances that are asource of heat.
■
Before connecting the power cord to apower socket, check that
the technical details on the vacuum cleaner’srating label match
the electrical voltage in the socket.
■
Make sure the power cord is not touching ahot surface or sharp
objects.
■
Do not submerge the vacuum cleaner under water or any other
liquid and do not rinse it under running water.
■
Before turning on the vacuum cleaner, make sure that the motor
filter, micro-filter and the outflow EPA filter are installed in their
place.
■
When the vacuum cleaner is running, ensure that the air outlets
and the suction opening are not blocked.
EN-4
EN
Bagless Vacuum Cleaner
SVC 1030 (Cat & Dog)
2019 09/2019
■ Do not use the vacuum cleaner to vacuum the following items:
– smouldering cigarettes, burning items, matches or embers;
– water and other liquids;
– flammable or volatile materials;
– sharp items, e.g. broken glass, needles, pins, etc.;
– flour, wall plaster, cement and other building materials;
– larger pieces of paper or plastic bags, which can easily block
the suction opening.
■ Vacuuming of some types of floors or floor surfaces can create
aelectrostatic discharge, which presents no danger to the user.
■
Do not place the suction nozzle or tube against any parts of the
face.
■ Always turn off the vacuum cleaner and disconnect it from the
power socket when leaving it without supervision, after finishing
using it and before cleaning it.
■
Disconnect the power cord from the power socket by pulling
on the plug, never pulling on the cord. Otherwise, this could
damage the power cord or the socket. Hold the power cord in
your hand when winding it up.
■
In the event that the power cord is damaged, it must be replaced
by an authorised service centre or by a similarly qualified person,
this will prevent the creation of a dangerous situation. It is
forbidden to use the vacuum cleaner if it has adamaged power
cord.
■ Do not use the vacuum cleaner if it is not working correctly, if
it has been damaged or has been submerged in water. Do not
repair the vacuum cleaner yourself or make any adjustments to
it. Have all repairs performed at an authorised service centre. By
tampering with the appliance, you risk voiding your legal rights
arising from unsatisfactory performance or quality warranty.
Bagless Vacuum Cleaner
SVC 1030 (Cat & Dog)
EN
EN-5
2019 09/2019
DESCRIPTION
A
1 START/STOP button
2 Dust container button
3 Dust container handle
4 Vacuum hose connection
socket
5 Vacuum cleaner handle
6 Motor power output control
7 Outflow micro-filter cover
8 Cord winding button
9 Rubber wheel
0 Dust container
qa Handle
qs Sliding air suction knob
qd Telescopic tube
qf Telescopic tube position lock
qg Floor inlet nozzle
qf Flap position for vacuuming
hard (smooth) floors
qj Flap position for vacuuming
carpets
qk Hose
ql Accessory holder
w; Stopper for the vertical parking
position
wa Stopper for the horizontal
parking position
ws Clip
wd Hose end
B
1 Full dust container indicator
2 Horizontal parking position
3 Power cord
EN-6
EN
Bagless Vacuum Cleaner
SVC 1030 (Cat & Dog)
2019 09/2019
C
1 Handle
2 Vertical parking position
3 Front wheel mechanism
ASSEMBLY
Inserting the hose into the air suction socket on the vacuum cleaner:
Press the safety button on the hose end and insert the hose end into the air suction socket on the vacuum cleaner
until you hear "click". The hose is now secured in the correct position.
Attach the holder to the telescopic tube:
Make sure to place the holder with the hose on the wider part of the telescopic tube.
Attach the floor inlet nozzle to the telescopic tube:
Make sure the floor nozzle is attached the narrower part of the telescopic tube.
Adjust the length of the telescopic tube:
Adjust the length of the telescopic tube as follows: Move and hold the button on the tube forward as shown the
by arrows and adjust the length of the tube as required. Release the button and move the tube slightly forward
until you hear a "click". The telescopic tube is now securely fixed in position.
USING YOUR VACUUM CLEANER
Connecting your vacuum cleaner to the electrical power grid
Pull the plug attached to the power cord out from the vacuum cleaner until the desired length of the cord is out
of the product. Insert the plug into a power socket.
Caution:
Yellow marking on the power cord warns that the power cord is close to its end. Do not pull the
cord further than the red marking.
Adjusting the floor inlet nozzle according to the floor surface.
You may set the inlet nozzle according to the floor surface by adjusting the inlet flap:
• If you want to vacuum carpets, close the bristles of the inlet inside the inlet nozzle, by turning the flap
accordingly.
• If you want to vacuum hard and smooth surfaces, move the bristles out of the nozzle, by turning the flap
accordingly.
Bagless Vacuum Cleaner
SVC 1030 (Cat & Dog)
EN
EN-7
2019 09/2019
Turning your vacuum cleaner on and off
To switch your machine on or off, press the START / STOP button on the vacuum cleaner body.
Adjusting the suction strength
The suction strength may be adjusted by moving the rider on the vacuum cleaner body ( small range) or by the
moveable rider on the hose handler.
Tips
• Use the maximum suction strength when vacuuming carpets or floors with a hard surface. Use the
reduced strength when vacuuming upholstery, window curtains, etc.
• If the hose holder becomes blocked when vacuuming, disconnect it from the telescopic tube and also
disconnect the hose from the vacuum cleaner body. Then place the holder inside the suction socket
on the vacuum cleaner body and vacuum the stuck dirt out.
Temporary interruption of the vacuuming process
If you want to stop vacuuming for a short time, you may use one of the parking positions:
• for the horizontal parking position use the stopper at the end of the floor nozzle,
• for the vertical parking position use the stopper on the telescopic tube.
Attention:
Do not move the vacuum cleaner from place to place if the hose is in the parked position! It may break off
or the stoppers for the floor nozzle or telescopic tube may break off.
USING YOUR ACCESSORIES
D
1 Slot nozzle for vacuuming in hard to reach places (e.g. windows, corners, book shelves, areas between
mattresses, upholstery, etc.)
2 Upholstery nozzle
3 Brush nozzle (by turning the brush part it is possible to use it for vacuuming hard to reach places)
4 The mini turbo-brush for upholstery can be used for vacuuming animal hair from upholstery. Air
vacuum rotates the brushes making the removal and vacuuming of animal hair from couches and sofas
very easy. The size of the turbo brushes makes work possible in hard to reach places, where a standard
turbo nozzle could not reach.
Tip:
If during vacuuming you use an accessory very often, you may attach it to the special holder on the
telescopic tube.
EN-8
EN
Bagless Vacuum Cleaner
SVC 1030 (Cat & Dog)
2019 09/2019
Ending the vacuuming process
When you finish vacuuming, switch the vacuum cleaner off by pressing the START / STOP button and then
disconnect the power plug from the socket.
To wind the power cord back to the vacuum cleaner, press and hold the winding button with one hand. Hold the
cord with your other hand to protect the vacuum cleaner input area from damage
Tip:
If the winding process stops and part of the power cord is still outside, release the winding button and pull
the cable out again by about 50 cm and press the winding button again and repeat the winding process.
Carrying your vacuum cleaner
It is possible to hold and carry the vacuum cleaner using the fold-out handle (pic. A5) or the handle at the front
of the vacuum cleaner (pic. C1).
Caution:
Never try to carry your vacuum cleaner by holding the dust container handle!
STORAGE OF VACUUM CLEANER
Before storage you can disassemble your product to the individual parts or you can store it assembled with the
telescopic tube stored in one of the parking positions.
CLEANING AND MAINTENANCE
Caution:
Before cleaning disconnect this product from the power source.
Emptying the dust container
Empty the dust container as soon as the full dust container warning light comes on; otherwise the air flow and
the suction strength will be reduced.
E
1 Safety lock of the bottom
hatch
2 Plastic conical filter
3 Bottom hatch
4 Plastic conical filter
Bagless Vacuum Cleaner
SVC 1030 (Cat & Dog)
EN
EN-9
2019 09/2019
1) Press the safety lock and pull the dust container handle up at the same time to remove the dust container
from the vacuum cleaner.
2) Place the dust container over a waste bin.
3) Press the safety clip of the bottom hatch on the dust container and the bottom hatch will open.
4) By turning in the anti-clockwise direction remove the plastic conical filter from the dust container, tip out the
dust and if necessary wash under running lukewarm water.
5) In the same way tip out the dust and dirt from the dust container into ordinary household waste. If the
container is heavily soiled you may wash the entire container under lukewarm running water. However,
before doing so, it is necessary to remove the H.E.P.A filter and its foam pre-filter from the container!
6)
Then insert the plastic conical filter back into the dust container and lock in position by turning in the clockwise
direction.
7) Close the bottom hatch of the dust container. Make sure the safety clip clicks in.
8) Place the dust container back into the vacuum cleaner.
Caution:
Before replacing the dust container and the plastic conical filter back into the vacuum cleaner,
make sure that all parts are completely dry.
Replacing and cleaning the H.E.P.A. filter and the foam pre-filter
F
1 H.E.P.A. filter
2 Safety clip for the H.E.P.A. filter
G
1 Safety clip
2 Hinge for the H.E.P.A filter
frame
3 Hinge for the H.E.P.A filter
frame
4 Foam pre-filter
5 H.E.P.A. filter
EN-10
EN
Bagless Vacuum Cleaner
SVC 1030 (Cat & Dog)
2019 09/2019
1) Press the safety clip and pull the dust container handle up at the same time to remove the dust container
from the vacuum cleaner.
2) Fold out both safety clips of the H.E.P.A. filter frame, take it off the dust container and from behind it also
remove the foam pre-filter.
3) Wash both filters under running lukewarm water and if necessary replace with new ones.
4) Then first reinsert the foam pre-filter and then the H.E.P.A. filter until you hear both clips click in.
5) Place the dust container back into the vacuum cleaner.
Attention:
Never insert the filters back into the vacuum cleaner if they are wet or damp! Always wait until
they are thoroughly dry. The dust container is equipped with a safety clip (see. pic. G 1), which
in the absence of the H.E.P.A. filter will not make it possible to insert the dust container into the
vacuum cleaner.
Changing the outflow filter
H
1 Outflow micro-filter
2 Outflow micro-filter cover
3 Cover clip
4 Cover clip
I
1 Outflow micro-filter cover
2 Foam pre-filter
3 Outflow micro-filter
Bagless Vacuum Cleaner
SVC 1030 (Cat & Dog)
EN
EN-11
2019 09/2019
1) First remove the grill of the outflow filter by pulling upwards in the place of both safety clips.
2) Then remove the outflow filter and the foam pre-filter and replace them with new ones.
3) After reinserting both filters attach the cover and click in both clips.
Caution:
Make sure you put the outflow filter in the vacuum cleaner with the plastic grill facing outwards!
Cleaning your vacuum cleaner.
To clean the outside parts of the product use a fine cloth dipped in lukewarm water. Do not use aggressive
cleaning agents, paint thinners or solvents. Using these solutions could damage the surface of the product.
TROUBLESHOOTING
Before you decide to contact an authorized service centre, please read these following tips in the
troubleshooting chart:
Problem Possible cause Recommended action
The engine will not start - The power cord is not firmly
inserted in the socket
- The wall power outlet is
damaged
- The vacuum cleaner is not
switched on
- Insert the plug firmly into the
power outlet
- Inspect the power outlet
- Turn the product on.
The suction output is insufficient - The product is clogged
- The dust filter needs cleaning.
- The dust container is inserted
in the wrong position
- The filter is clogged
- Remove the blockage or foreign
object
- Clean the dust filter
- Close the dust container
- Clean the filter
The power cord is not wound in
completely
The power cord may have slipped
down from the winding pulley
during winding.
Hold the power cord during the
winding. Apply slight tension (by
pulling the power cord back) to
the power cord during the winding
process
The power cord cannot be pulled
out
The power cord is wound up
incorrectly
Press the winding button and try to
rewind the power cord again
The speed control is not working. The product is out of order Have the product repaired by a
technician.
(only by a qualified technician).
The power cord starts to wind in
when you do not required.
The winding mechanism is out
of order
Have the product repaired by a
technician.
(only by a qualified technician).
The dust container cannot be closed The dust filter is inserted
incorrectly or in an incorrect
position
Reinstall and secure the filter in
position and try again
EN-12
EN
Bagless Vacuum Cleaner
SVC 1030 (Cat & Dog)
2019 09/2019
TECHNICAL SPECIFICATIONS
Nominal voltage ........................................................................................................................220 – 240 V AC
Nominal frequency ....................................................................................................................................50 Hz
Rated power input ................................................................................................................................... 700 W
Safety class (with regard to electric shock protection) ........................................................................................ II
Noise level ........................................................................................................................................... 73 dB(A)
Length of the power cord ............................................................................................................................ 8 m
Operating range ........................................................................................................................................ 11 m
Dust container capacity .............................................................................................................................. 2.3 l
Dimensions (length x width x height) ................................................................................ 397 x 303 x 228 mm
Weight .................................................................................................................................................... 4.9 kg
The declared noise emission level of the appliance is 73 dB(A), which represents a level A of acoustic power with
respect to a reference acoustic power of 1 pW.
Amendments to text and technical parameters are reserved.
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING MATERIALS
Dispose of packaging material at a public waste disposal site.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES
The meaning of the symbol on the product, its accessory or packaging indicates that this prod-
uct shall not be treated as household waste. Please, dispose of this product at your applicable
collection point for the recycling of electrical & electronic equipment waste. Alternatively in
some states of the European Union or other European states you may return your products to
your local retailer when buying an equivalent new product. The correct disposal of this product
will help save valuable natural resources and help in preventing the potential negative impact
on the environment and human health, which could be caused as a result of improper liquida-
tion of waste. Please ask your local authorities or the nearest waste collection centre for further
details. The improper disposal of this type of waste may fall subject to national regulations for
fines.
For business entities in the European Union
If you wish to dispose of an electrical or electronic device, request the necessary information
from your seller or supplier.
Disposal in other countries outside the European Union
If you wish to dispose of this product, request the necessary information about the correct
disposal method from local government departments or from your seller.
This product meets all the basic EU regulation requirements that relate to it.
Changes to the text, design and technical specifications may occur without prior notice and we reserve the
right to make these changes.
