en Table of contents
You can find additional information and explanations online.
Scan the QR code on the title page.
Table of contentsTable of contents
INFORMATION FOR USE
1 Safety ........................................................................ 2
2 Preventing material damage .................................. 3
3 Environmental protection and saving energy ...... 4
4 Familiarising yourself with your appliance .......... 4
5 Before using for the first time ................................ 5
6 Cookware ................................................................. 5
7 Basic operation ....................................................... 6
8 Pre-heating cookware ............................................. 6
9 Preheat cups ............................................................ 7
10 Keep food warm .................................................... 7
11 Making yeast dough or yoghurt ........................... 7
12 Low-temperature cooking .................................... 8
13 Additional applications ........................................ 8
14 Defrosting .............................................................. 9
15 How it works .......................................................... 9
16 HomeConnect .................................................... 11
17 Cleaning and servicing ...................................... 12
18 Troubleshooting ................................................. 13
19 Disposal ............................................................... 15
20 Customer Service ............................................... 15
21 Information regarding Free and Open Source
Software ............................................................... 15
22 Declaration of Conformity .................................. 16
23 INSTALLATION INSTRUCTIONS ....................... 16
23.5 Safe installation ............................................... 18
Safety 1 Safety
Observe the following safety instructions.
1.1 Definition of the signal words
This is where you can find explanations for the
safety signal words used in this manual.
WARNING
This indicates that death or serious injuries
may occur as a result of non-observance of
this warning.
ATTENTION
This indicates that damage to the appliance or
other material damage may occur as a result
of non-compliance with this warning.
Note: This alerts you to important information.
1.2 General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the product
information safe for future reference or for
the next owner.
¡ Do not connect the appliance if it has been
damaged in transit.
1.3 Intended use
Only use this appliance:
¡ To keep food warm and to warm cookware.
¡ To prepare meals and drinks.
¡ in private households and in enclosed
spaces in a domestic environment.
¡ Up to an altitude of 4000m above sea level.
Do not use the appliance:
¡ On boats or in vehicles.
1.4 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
2
Preventing material damage en
1.5 Safe use
WARNING‒Risk of fire!
The inside of the appliance gets very hot and
may cause flammable materials to ignite.
Never place flammable objects or plastic
containers in the appliance.
WARNING‒Risk of burns!
The accessories and cookware become very
hot during operation.
Always use oven gloves when removing hot
accessories or cookware from the appliance.
The inside of the appliance becomes very hot
during operation.
Never touch the inside of the appliance while
it is hot.
Keep children away from the appliance.
The rear of the front panel becomes very hot
during operation.
To open the appliance, only touch the front
panel on the side or the underside.
The appliance becomes hot during operation.
Allow the appliance to cool down before
cleaning.
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be car-
ried out by trained specialist staff.
Only use genuine spare parts when repairing
the appliance.
If the power cord or the appliance power
cable of this appliance is damaged, it must
be replaced with a special power cord or
special appliance power cable, which is
available from the manufacturer or its Cus-
tomer Service.
If the power cord of this appliance is dam-
aged, it must be replaced by trained special-
ist staff.
If the insulation of the power cord is damaged,
this is dangerous.
Never let the power cord come into contact
with hot appliance parts or heat sources.
Never let the power cord come into contact
with sharp points or edges.
Never kink, crush or modify the power cord.
An ingress of moisture can cause an electric
shock.
Do not use steam- or high-pressure cleaners
to clean the appliance.
If the appliance or the power cord is damaged,
this is dangerous.
Never operate a damaged appliance.
Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
If the appliance or the power cord is dam-
aged, immediately unplug the power cord or
switch off the fuse in the fuse box.
Call customer service.
Page15
WARNING‒Risk of suffocation!
Children may put packaging material over their
heads or wrap themselves up in it and suffoc-
ate.
Keep packaging material away from chil-
dren.
Do not allow children to play with packaging
material.
Children may breathe in or swallow small
parts, causing them to suffocate.
Keep small parts away from children.
Do not let children play with small parts.
Preventing material damage2 Preventing material damage
ATTENTION
Excessive weight may damage the appliance.
The appliance has a maximum load capacity of
25kg.
Moisture may damage the appliance.
Do not use the appliance to store food and drinks.
The humidity of the food may cause corrosion dam-
age.
Tightening the screws too tight causes the side panel to
become misshapen. The appliance will then no longer
be flush with the other appliances.
Do not use excessive force when tightening.
3
en Environmental protection and saving energy
Environmental protection and saving energy3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compatible
and can be recycled.
Sort the individual components by type and dispose
of them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use
less power.
To preheat cookware efficiently, distribute the cookware
evenly throughout the appliance.
It is more energy-efficient to prepare food, e.g. low-tem-
perature cooking, in the warming drawer rather than in
the oven.
Familiarising yourself with your appliance4 Familiarising yourself with your appliance
4.1 Control panel
You can use the control panel to configure all functions of your appliance and to obtain information about the operat-
ing status.
Touch fields
Touch fields are touch-sensitive surfaces. To select a
function, press the relevant field.
Touch field Function
Switch the appliance on or
off
Adding favourites
1
Preheating cups
Preheating cookware
Keeping food warm
Low-temperature cooking
Setting the temperature
30° - 80° Selecting a temperature
2
Starting HomeConnect
pairing
Notes
If you touch the touch field, the appliance performs
the corresponding function.
Touch fields that cannot currently be selected do not
light up.
The settings that are currently selected light up in col-
our.
Always keep the controls dry. Moisture reduces its ef-
fectiveness.
Displays
The displays on the control panel show the operating
status of the appliance.
Display Function
lights up white HomeConnect is available.
flashes white Appliance connects to
HomeConnect.
lights up in colour Appliance is connected to
HomeConnect.
flashes in colour Connection to HomeCon-
nect is faulty.
The operation indicator is located on the appliance's
front panel.
Operation indicator Function
Off Appliance OFF
Lights up Appliance ON
Flashes Heating-up display
Flashes quickly Fault
1
Only available if the appliance is connected to HomeConnect.
2
Depending on the selected operating mode.
4
Before using for the first time en
Default temperature and temperature range
The appliance displays the possible temperature range depending on the operating mode selected. The selected op-
erating mode and the corresponding default temperature light up in colour.
When the appliance is switched on, the operating mode and temperature that were last set light up in colour.
Operating mode Default temperature in °C Adjustable temperature range in °C
Preheat cups 50 40-60
Preheat cookware 60 50-70
Keep food warm 70 60-80
Low-temperature cooking 80 70-80
Temperature range 50 30-80
4.2 Keeping warm over an extended period
Your appliance maintains the temperature of your food
between 30 and 80°C over a longer period of time.
You can keep food warm for up to 74hours without hav-
ing to switch the appliance on or off. Bear in mind that
food which spoils easily should not be left in the appli-
ance for too long.
If you open the appliance during this period, the appli-
ance continues to heat up and the fan runs.
4.3 Safety shut-off
For your safety, the appliance has a safety shut-off func-
tion. Any kind of heating will be switched off after
24hours if the appliance controls are not used during
this time. All displays are off. When the appliance
switches off, an audible signal sounds. The appliance
will also remain off after a power failure.
If the "Keep warm" function is set over an extended
period, the safety shut-off is deactivated.
Before using for the first time5 Before using for the first time
Prepare the appliance for use.
5.1 Cleaning and heating up the appliance
before using it for the first time
Note: When the appliance is switched on for the first
time, it takes approx.60seconds until the appliance is
ready to use. A signal tone sounds. The touch fields
light up in ascending order from left to right.
Requirement: There are no objects in the appliance.
1.
Press on the appliance's front panel.
The appliance opens and can be pulled out as far as
it will go by the sides or underside of the front panel.
2.
Clean the appliance with a damp cloth and a neutral
cleaning agent, such as washing-up liquid and water.
3.
Press .
A signal tone sounds.
4.
Press .
5.
Press 80°C and close the appliance.
The operation indicator flashes while the appliance is
preheating.
6.
Heat up the appliance at 80°C for one hour.
Smoke development and odour development are nor-
mal.
Ventilate the installation room well.
Cookware6 Cookware
Observe the instructions for filling the appliance. The ap-
pliance has a maximum load capacity of 25kg. You can
heat a different quantity of cookware depending on the
appliance height.
6.1 Cookware for appliances with a height of
29cm
You can use an appliance with a height of 29cm to pre-
heat the place settings for 12people, for example.
Cookware Dimensions
12dinner plates 27cm diameter
12soup bowls 13cm diameter
1bowl 24cm diameter
1bowl 21cm diameter
1bowl 17cm diameter
Cookware Dimensions
2meat platters 32x20cm
6.2 Cookware for appliances with a height of
14cm
You can use an appliance with a height of 14cm to pre-
heat the place settings for 6people, for example.
Tableware Dimensions
6dinner plates 27cm diameter
6soup bowls 13cm diameter
1bowl 20cm diameter
1bowl 18cm diameter
1bowl 14cm diameter
1meat platter 32x20cm
5
en Basic operation
Basic operation7 Basic operation
7.1 Opening the appliance
WARNING‒Risk of burns!
The rear of the front panel becomes very hot during op-
eration.
To open the appliance, only touch the front panel on
the side or the underside.
Press on the appliance's front panel.
The appliance opens and can be pulled out as far as
it will go by the sides or underside of the front panel.
7.2 Closing the appliance
Slide the appliance in until it engages.
7.3 Switching on the appliance
1.
Press .
A signal tone sounds.
2.
Select an operating mode.
The default temperature lights up in colour.
The available temperatures light up.
3.
If required, select another temperature.
The selected temperature lights up in colour.
4.
Close the appliance.
The operation indicator flashes while the appliance is
preheating.
The operation indicator lights up, the appliance heats
up and the fan runs.
7.4 Switching off the appliance
Press .
A signal tone sounds.
7.5 Set temperature
1.
Press .
The default temperature lights up in colour.
The temperatures that can be set light up white.
2.
Select a temperature.
The selected temperature lights up in colour.
7.6 Adjusting the default temperature
1.
Select the operating mode.
2.
Press and hold the symbol for the required default
temperature until the signal tone sounds.
The default temperature has changed.
7.7 Setting the "Keep warm" function over
an extended period
1.
Press .
A signal tone sounds.
2.
Press .
The default temperature lights up in colour.
3.
Set the desired temperature between 30°C and
80°C.
4.
Press and at the same time.
lights up in colour. 30° lights up white.
5.
Press 30°.
30° lights up in colour.
6.
Press and hold until a signal sounds.
lights up white.
and the set temperature light up in colour. The
brightness of the display is dimmed.
7.
Close the appliance.
The operation indicator lights up, the appliance heats
up and the fan runs.
If you open the appliance during this period, the ap-
pliance continues to heat up and the fan runs.
7.8 Ending the "Keep warm" function over
an extended period
1.
Press .
The appliance stops heating.
2.
Press to switch off the appliance again.
A signal tone will sound.
Tip: If you have connected the appliance to HomeCon-
nect, you can programme a switch-off timer in the
HomeConnect app.
Pre-heating cookware8 Pre-heating cookware
Food remains warm for longer in preheated cookware.
8.1 Starting the "Preheat cookware" function
1.
Place the cookware in the appliance.
To guarantee that hot air can circulate efficiently,
ensure that no tall items of cookware or stacks of
plates are blocking the ventilation slots on the rear
panel of the appliance.
Distribute the cookware across the entire bottom of
the appliance to reduce the preheating time.
The preheating time depends on the material, thick-
ness, quantity and distribution of the cookware. For
place settings for 6people, the preheating time is ap-
prox.30-40minutes.
2.
Press .
The default temperature lights up in colour.
The available temperatures light up.
3.
If required, select another temperature.
4.
Close the appliance.
The operation indicator flashes while the appliance is
preheating.
The operation indicator lights up, the appliance heats
up and the fan runs.
6
Preheat cups en
8.2 Ending the "Preheat cookware" function
WARNING‒Risk of burns!
The accessories and cookware become very hot during
operation.
Always use oven gloves when removing hot ac-
cessories or cookware from the appliance.
1.
Open the appliance.
2.
Switch off the appliance.
3.
Remove the cookware.
Preheat cups9 Preheat cups
Drinks remain warm for longer in preheated cups.
9.1 Starting the "Preheat cups" function
WARNING‒Risk of burns!
There is a risk of burns if the temperatures are too high.
Always set temperatures below 60°C for cups.
1.
Place the cups in the appliance.
Distribute the cups across the entire bottom of the
appliance to reduce the preheating time.
The preheating time depends on the material, thick-
ness, quantity and distribution of the cups.
2.
Press .
The default temperature lights up in colour.
The available temperatures light up.
3.
If required, select another temperature.
4.
Close the appliance.
The operation indicator flashes while the appliance is
preheating.
The operation indicator lights up, the appliance heats
up and the fan runs.
9.2 Ending the "Preheat cups" function
WARNING‒Risk of burns!
The accessories and cookware become very hot during
operation.
Always use oven gloves when removing hot ac-
cessories or cookware from the appliance.
1.
Open the appliance.
2.
Switch off the appliance.
3.
Remove the cups.
Keep food warm10 Keep food warm
You can use the appliance to keep food warm for a cer-
tain period of time.
Note the recommended settings.
"Recommended settings for keeping food warm",
Page9
10.1 Starting the "Keep food warm" function
1.
To prevent spillage, do not completely fill the cook-
ware.
2.
Cover the food with heat-resistant cling film, alu-
minium foil or a heat-resistant cover.
3.
Place the cookware in the appliance.
4.
Press .
The default temperature lights up in colour.
The available temperatures light up.
5.
If required, select another temperature.
6.
Close the warming drawer.
The operation indicator flashes while the appliance is
preheating.
The operation indicator lights up, the appliance heats
up and the fan runs.
10.2 Ending the "Keep food warm" function
WARNING‒Risk of burns!
The accessories and cookware become very hot during
operation.
Always use oven gloves when removing hot ac-
cessories or cookware from the appliance.
1.
Open the appliance.
2.
Switch off the appliance.
3.
Remove the cookware.
Making yeast dough or yoghurt11 Making yeast dough or yoghurt
You can use your appliance to make yeast dough or
yoghurt.
Note the recommended settings.
"Recommended settings for making yeast dough or
yoghurt", Page9
11.1 Making yeast dough
1.
Make the yeast dough.
2.
Put the yeast dough into a suitable container.
3.
Place the container in the appliance.
4.
Cover the container with a damp tea towel.
5.
Heat the appliance in accordance with the corres-
ponding temperature indicator and time.
7
en Low-temperature cooking
11.2 Making yoghurt
1.
To make thick yoghurt, add skimmed milk powder to
the milk before heating it.
Use one to two tablespoons of skimmed milk powder
per litre of milk.
2.
Heat pasteurised milk to 90°C on the hob to prevent
a disturbance of the yoghurt cultures.
For ultra-high temperature (UHT) milk, heating is not
required.
Cold milk extends the incubation time.
3.
Allow the milk in the water bath to cool to 40°C so
that the yoghurt cultures are not destroyed.
4.
Stir natural yogurt with designated yogurt cultures into
the milk.
Use one to two teaspoons of yoghurt per 100ml milk.
5.
When using yoghurt starter, follow the instructions on
the packet.
6.
Use yoghurt jars with screw tops.
7.
If available, disinfect the washed yoghurt jars in your
steam oven at 100°C and 100% humidity for
20-25minutes.
8.
Pour the yoghurt mixture into the disinfected yoghurt
jars.
9.
Close the yoghurt jars using a screw lid.
10.
Place the yoghurt jars in the appliance.
11.
Place the finished yoghurt into the refrigerator.
Low-temperature cooking12 Low-temperature cooking
Low-temperature cooking is the ideal cooking method
for cooking all tender pieces of meat which are to be
cooked medium rare or "à point". The meat remains
very juicy and turns out as soft as butter. Since the
times for low-temperature cooking are considerably
longer, you have plenty of leeway for menu planning.
Meat that is cooked at a low temperature is easy to
keep warm.
Note the recommended settings.
"Recommended settings for low-temperature cook-
ing", Page9
12.1 Tips for low-temperature cooking
This is where you will find tips for achieving good results
when cooking at a low temperature.
Only use fresh, good-quality meat. Carefully remove
sinews and fat from around the edge. Fat develops a
strong, distinct taste during low-temperature cooking.
Even larger pieces of meat do not need to be turned.
You can cut the meat immediately after low-temperat-
ure cooking. No standing time is required.
Due to the special cooking method, the meat always
looks pink on the inside. This does not mean, how-
ever, that the meat is raw or not well done enough.
Meat that is cooked at a low temperature is not as
hot as conventionally roasted meat. Ensure that the
sauces are very hot when you serve them. Place the
plates in the appliance in the last 20-30minutes.
If you want to keep meat that is cooked at a low tem-
perature warm, select 60°C. Small pieces of meat
can be kept warm for up to 45minutes and large
pieces for up to 2hours.
12.2 Starting the "Low-temperature cooking"
function
1.
Only use suitable cookware made from glass, porcel-
ain or ceramic with a lid, e.g. a glass roasting dish.
2.
If no lid is available for the cookware, use heat-resist-
ant cling film to cover the cookware.
3.
Place the cookware on the bottom of the appliance.
4.
Press to preheat the cookware.
5.
Close the appliance.
The operation indicator flashes while the appliance is
preheating.
The operation indicator lights up, the appliance heats
up and the fan runs.
6.
Rapidly heat a little fat in a pan.
7.
Sear the meat.
8.
Place food into the preheated cookware.
9.
Put the lid on the cookware or cover it using heat-res-
istant cling film.
10.
Place the cookware with the meat in the appliance.
11.
Press .
The default temperature lights up in colour.
The available temperatures light up.
12.
If required, select another temperature.
13.
Close the appliance.
The operation indicator flashes while the appliance is
preheating.
The operation indicator lights up, the appliance heats
up and the fan runs.
12.3 Ending the "Low-temperature cooking"
function
WARNING‒Risk of burns!
The accessories and cookware become very hot during
operation.
Always use oven gloves when removing hot ac-
cessories or cookware from the appliance.
1.
Open the appliance.
2.
Switch off the appliance.
3.
Remove the cookware.
Additional applications13 Additional applications
Your appliance offers additional useful applications. Note the recommended settings.
"Recommended settings for other applications",
Page10
8
Defrosting en
Defrosting14 Defrosting
You can use your appliance to defrost frozen food
gently and more evenly than in the microwave.
Note the recommended settings.
"Recommended settings for defrosting", Page11
14.1 Defrosting food
WARNING‒Risk of harm to health!
When defrosting food from animal sources, the trans-
mission of germs is possible.
When defrosting food from animal sources, you must
remove the liquid that escapes during defrosting.
Ensure that the liquid that escapes during defrosting
never comes into contact with other foods.
1.
Remove the food from the packaging before defrost-
ing.
2.
Only defrost the amount of food that you require im-
mediately.
3.
Turn the meat or fish after half of the defrosting time
has elapsed.
4.
Break up frozen clumps of food comprising many
pieces, e.g. berries and pieces of meat.
Notes
The defrosting time depends on the size, weight and
shape of the frozen food. To reduce the defrosting
time, freeze food flat or in individual portions.
In some cases, defrosted food may no longer be kept
for as long and it may spoil more quickly than fresh
food. Prepare defrosted food immediately and cook it
thoroughly.
Fish does not need to be fully defrosted. It is suffi-
cient to defrost fish until the surface is soft enough for
seasoning/spices to stick.
How it works15 How it works
15.1 Recommended settings for keeping food warm
Observe the following recommended settings when keeping food warm. To prevent the food from drying out, observe
the maximum duration in the overview.
Food Preheating cookware Temperature in °C Duration in minutes Information
Boiled eggs,
scrambled eggs
Yes 50 Maximum 60 Cover the food
Toasting bread, rolls Yes 60 Maximum 60
Delicate foods, e.g.
cooked meat
No 60 Maximum 60 Carve the meat just
before serving; cover
the food
Food Yes 80 Maximum 60 Cover the food
Beverages Yes 70 Maximum 60 Cover beverages
15.2 Recommended settings for making yeast dough or yoghurt
Observe these recommended settings.
Food Temperature in °C Duration in minutes Information
Yeast dough 40 45-60 Bowl, dish or baking tray;
cover the yeast dough
Yoghurt 40 420 Close the yoghurt jars with
the lids
15.3 Recommended settings for low-temperature cooking
The following settings have been specially tested for your appliance.
All tender joints of beef, pork, veal, lamb, pork, game and poultry are suitable for low-temperature cooking. The sear-
ing and cooking times depend on the size of the piece of meat. The searing times apply to food placed into the hot
oil.
Small pieces of meat
Food Searing time on the hot-
plate
Continued cooking time in
the warming drawer
Temperature in °C
Cubes or strips On all sides for 1-2minutes 20-30minutes 80
9
en How it works
Food Searing time on the hot-
plate
Continued cooking time in
the warming drawer
Temperature in °C
Small escalopes, steaks or
medallions, approx. 1-2cm
thick
1-2minutes per side 35-50minutes 80
Medium-sized pieces of meat
Food Searing time on the hot-
plate
Continued cooking time in
the warming drawer
Temperature in °C
Fillet, 400-800g On all sides for 4-5minutes 75-120minutes 80
Saddle of lamb, ap-
prox.450g
2-3minutes per side 50-60minutes 80
Lean joints of meat,
800-1000g
On all sides for 6-8minutes 120-180minutes 80
Large pieces of meat
Food Searing time Continued cooking time in
the warming drawer
Temperature in °C
Fillet, from 800-2000g On all sides for 6-8minutes 120-210minutes 80
Sirloin, 1-2kg On all sides for
8-10minutes
180-210minutes 80
Other food
Food Searing time Continued cooking
time in the warming
drawer
Temperature in °C Information
Ragout On all sides for
6-8minutes
15hours 80
80
In the roasting dish
with lid
Confit meat 20hours 80 In the roasting dish
with lid, e.g. confît de
canard (speciality from
South-West France)
15.4 Recommended settings for other applications
Observe the following recommended settings.
Warming
Food Temperature in °C Duration in minutes Information
Egg and flour-based foods,
e.g. crêpes, pancakes,
wraps, tacos
80 10-60 Cover the food
Cakes, e.g. cakes with
crumble topping, muffins
80 30-45 Cover the food
Melting
Food Temperature in °C Duration in minutes Information
Dissolving gelatine 80 10-15 Before melting the gelatine
leaves, soak them in water
and wring them out
Cooking chocolate, couver-
ture chocolate
60 30-45 Break the chocolate into
pieces
Butter 80 30-45 Cut the butter into cubes
10
HomeConnect en
Drying
Food Temperature in °C Duration in minutes Information
Fresh herbs 60 90
Meringues 80 150-180 3-4 cm diameter
Apple rings 70 420-480 Cut the apples into fine
slices or rings
Flavouring oil
Food Temperature in °C Duration in minutes Information
Flavoured oil 80 90-120 E.g. olive oil with lemon,
rosemary, chilli
Heating cotton cloths
Table linen Temperature in °C Duration in minutes Information
Hot cotton cloths 80 60 Moisten and roll up the cot-
ton cloths before heating.
Add the cotton cloths to a
plate or cooking container.
Place the plate or the cook-
ing container in the warming
drawer.
15.5 Recommended settings for defrosting
Take note of the following recommended settings for defrosting food.
Food Temperature in °C Duration in minutes
Delicate frozen food, e.g. butter,
cheese, berries
40 45-60
Bread, bread rolls, baguettes, cake 60 15-30
Meat, fish 60 30-60
HomeConnect16 HomeConnect
This appliance is network-capable. Connecting your ap-
pliance to a mobile device lets you control its functions
via the HomeConnect app, adjust its basic settings and
monitor its operating status.
The HomeConnect services are not available in every
country. The availability of the HomeConnect function
depends on the availability of the HomeConnect ser-
vices in your country. You can find information about
this at:
www.home-connect.com
.
The HomeConnect app guides you through the entire
login process. Follow the instructions, noting the inform-
ation in the HomeConnect app.
Notes
Please note the safety precautions in this instruction
manual and make sure that they are also observed
when operating the appliance via the HomeConnect
app.
"Safety", Page2
Operating the appliance on the appliance itself al-
ways takes priority. During this time it is not possible
to operate the appliance using the HomeConnect
app.
In networked standby mode, the appliance requires a
maximum of2W.
16.1 Setting up HomeConnect
Requirements
The appliance is connected to the power supply and
is switched on.
You have a mobile device with a current version of
the iOS or Android operating system, e.g. a smart-
phone.
The appliance is receiving signals from the WLAN
home network (Wi-Fi) at its installation location.
The mobile device and the appliance are within range
of your home network's Wi-Fi signal.
11
en Cleaning and servicing
1.
Scan the following QR code.
You can install the HomeConnect app and connect
your appliance via the QR code.
2.
Follow the instructions in the HomeConnect app.
16.2 Resetting the Wi-Fi settings and
switching off the Wi-Fi
1.
Press and hold until a signal tone sounds.
flashes white once.
The Wi-Fi is reset. The appliance searches for a con-
nection to another mobile device.
2.
Press and hold until a signal tone sounds.
lights up for approx. 2 seconds.
The Wi-Fi is switched off.
16.3 Software update
Your appliance's software can be updated using the
software update function, e.g. for the purposes of optim-
isation, troubleshooting or security updates.
To do this, you must be a registered HomeCon-
nectuser, have installed the app on your mobile device
and be connected to the HomeConnectserver.
As soon as a software update is available, you will be
informed via the HomeConnectapp and will be able to
start the software update via the app. Once the update
has been successfully downloaded, you can start in-
stalling it via the HomeConnectapp if you are in your
home network (Wi-Fi). The HomeConnectapp informs
you once installation is successful.
You can find the current software version in the
HomeConnect app under the appliance information for
the appliance.
Notes
The software update consists of two steps.
– The first step is downloading.
– The second step is installation on your appliance.
You can continue to use your appliance during down-
loading. Depending on your personal settings in the
app, software updates can also be set to download
automatically.
Installation takes a few minutes. You cannot use your
appliance during installation.
We recommend you install security updates as soon
as possible.
16.4 Remote diagnostics
Customer Service can use Remote Diagnostics to ac-
cess your appliance if you contact them, have your ap-
pliance connected to the HomeConnect server and if
Remote Diagnostics is available in the country in which
you are using the appliance.
Tip: For further information and details about the avail-
ability of Remote Diagnostics in your country, please
visit the service/support section of your local website:
www.home-connect.com
.
16.5 Data protection
Please see the information on data protection.
The first time your appliance is registered on a home
network connected to the Internet, your appliance will
transmit the following types of data to the HomeCon-
nect server (initial registration):
Unique appliance identification (consisting of appli-
ance codes as well as the MAC address of the in-
stalled Wi-Fi communication module).
Security certificate of the Wi-Fi communication
module (to ensure a secure data connection).
The current software and hardware version of your
appliance.
Status of any previous resetting to factory settings.
This initial registration prepares the HomeConnect func-
tions for use and is only required when you want to use
the HomeConnect functions for the first time.
Note: Please note that the HomeConnect functions can
only be utilised with the HomeConnect app. Information
on data protection can be retrieved in the HomeCon-
nect app.
Cleaning and servicing17 Cleaning and servicing
17.1 Cleaning products
You can obtain suitable cleaning products from after-
sales service or the online shop.
ATTENTION
Unsuitable cleaning products may damage the surfaces
of the appliance.
Do not use harsh or abrasive detergents.
Do not use cleaning products with a high alcohol con-
tent.
Do not use hard scouring pads or cleaning sponges.
Only use glass cleaners, glass scrapers or stainless
steel care products if recommended in the cleaning
instructions for the relevant part.
Wash sponge cloths thoroughly before use.
17.2 Cleaning the appliance
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
Do not use steam- or high-pressure cleaners to clean
the appliance.
Do not use the appliance with damp hands.
WARNING‒Risk of burns!
The appliance becomes hot during operation.
Allow the appliance to cool down before cleaning.
Requirement: The appliance is switched off.
12
Troubleshooting en
1.
Clean the appliance with a damp cloth and a neutral
cleaning agent, such as washing-up liquid and water.
2.
Dry with a soft cloth.
17.3 Cleaning the stainless steel surfaces
1.
Always remove limescale, grease, starch or albumin
stains immediately.
Corrosion may form under such stains.
2.
Clean with water and some washing-up liquid.
3.
Dry with a soft cloth.
17.4 Cleaning the glass front
Clean the glass front using a glass cleaning product
and a soft cloth.
Do not use any abrasive sponges that may scratch
or any glass scrapers.
17.5 Cleaning the glass plate
1.
Clean the glass plate using a glass cleaning product
and a soft cloth.
Do not use any abrasive sponges that may scratch
or any glass scrapers.
2.
Dry with a soft cloth.
17.6 Cleaning the control panel
1.
Clean the control panel with a damp cloth and neutral
cleaning agent, such as washing-up liquid and water.
Do not use any abrasive sponges that may scratch
or any glass scrapers.
2.
Dry with a soft cloth.
Troubleshooting18 Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after-
sales service. This will avoid unnecessary costs.
Tip: Permanently connect your appliance to the Home Connect app to automatically receive software updates. This
allows errors to be eliminated, performance to be improved and new functions to be made available.
WARNING‒Risk of injury!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
If the appliance is defective, call Customer Service.
"Customer Service", Page15
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
Only use genuine spare parts when repairing the appliance.
If the power cord or the appliance power cable of this appliance is damaged, it must be replaced with a special
power cord or special appliance power cable, which is available from the manufacturer or its Customer Service.
If the power cord of this appliance is damaged, it must be replaced by trained specialist staff.
18.1 Fault indicator
In the event of a fault, the operation indicator flashes
quickly. A signal tone sounds. When you open the appli-
ance, symbols light up on the control panel, depending
on the cause.
Touch any touch field to switch off the signal tone. If you
then touch , the display goes out.
18.2 Malfunctions
Fault Cause and troubleshooting
The appliance is not working. The circuit breaker in the fuse box has tripped.
Check the circuit breaker in the fuse box.
There has been a power cut.
Check whether the lighting in your room or other appliances are working.
1.
Open the appliance.
Following a power cut, the touch fields light up in ascending order from left to
right.
The display goes out after approx. 30 seconds and the appliance is ready for op-
eration.
2.
Start the required operating mode.
The appliance is switched on.
The operation indicator does not
light up.
The operation indicator is defective.
Call Customer Service
Page15
.
13
en Troubleshooting
Fault Cause and troubleshooting
The operation indicator flashes. The appliance heats up.
Wait until the appliance has finished heating up.
The cookware or food is not heat-
ing up.
There has been a power cut.
Check whether the lighting in your room or other appliances are working.
The appliance is switched off.
Switch the appliance on.
The appliance is not completely closed.
Close the appliance.
The cookware covers the ventilation system slots and the appliance switches on
the overheating protection.
1.
Wait until the appliance has cooled down.
2.
Ensure that the ventilation slots on the rear panel of the appliance are not
covered.
3.
Use the main switch to switch the appliance off and back on again.
4.
Select the required operating mode and temperature.
If the problem persists, contact customer service.
"Customer Service", Page15
The cookware or food does not
get warm enough.
There has been a power cut.
Check whether the lighting in your room or other appliances are working.
The cookware or food has not been heated for long enough.
Heat the cookware or the food for a longer period of time.
The appliance is not completely closed.
Close the appliance.
The appliance switches off. and
light up.
The appliance has overheated.
1.
Wait until the appliance has cooled down.
2.
Ensure that the ventilation slots on the rear panel of the appliance are not
covered.
3.
Check whether an oven integrated above is in pyrolytic self-cleaning mode.
The appliance switches off. A sig-
nal tone sounds. and flash
quickly.
Electronics fault
1.
Disconnect the appliance from the mains.
2.
Wait approx.30seconds.
3.
Switch the appliance back on.
If the problem persists, contact customer service.
"Customer Service", Page15
The appliance switches off. A sig-
nal tone sounds. and flash
quickly.
Electronics fault
1.
Disconnect the appliance from the mains.
2.
Wait approx.30seconds.
3.
Switch the appliance back on.
If the problem persists, contact customer service.
"Customer Service", Page15
The appliance switches off. All
displays are off.
The safety shut-off has switched the appliance off.
Switch the appliance back on.
The indicators light up. The appli-
ance is not heating up.
Demo mode is activated.
Deactivate demo mode.
Page14
Home Connect display flashes in
colour.
Network fault
1.
Check the connection to the home network, e.g. with a mobile phone near the
appliance.
2.
Restart the router.
If the problem persists, contact customer service.
"Customer Service", Page15
The front panel is not aligned. The front panel was not aligned during installation.
Adjust the front panel.
Page21
18.3 Demo mode
If demo mode is activated, the indicators light up but the
appliance does not heat up.
Deactivating demo mode
1.
Disconnect the appliance from the mains briefly.
Unplug the appliance from the mains or switch off
the household fuse or circuit breaker in the fuse
box.
14
Disposal en
2.
Deactivate demo mode within the next 3minutes.
Press and hold and at the same time until
and 30° light up in colour.
Press 30° until 30° lights up white.
3.
To save the settings, press and hold until all indic-
ators go out.
Disposal19 Disposal
19.1 Disposing of old appliance
Valuable raw materials can be reused by recycling.
1.
Unplug the appliance from the mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are avail-
able from your specialist dealer or local authority.
This appliance is labelled in accordance
with European Directive 2012/19/EU
concerning used electrical and elec-
tronic appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the framework
for the return and recycling of used ap-
pliances as applicable throughout the
EU.
Customer Service20 Customer Service
Function-relevant genuine spare parts according to the
corresponding Ecodesign Directive can be obtained
from Customer Service for a period of at least 10years
from the date on which your appliance was placed on
the market within the European Economic Area.
Furthermore, our Customer Service will continue to
provide you with other function-relevant and storable
genuine spare parts for up to 15years from the date on
which your appliance was placed on the market.
For more information, please contact our Customer Ser-
vice team.
Note: Under the terms of the manufacturer's warranty
the use of Customer Service is free of charge.
Detailed information about the warranty period and the
warranty conditions in your country is available via the
QR code on the enclosed document on service con-
tacts and warranty conditions, from our customer ser-
vice or on our website.
You can find the contact details for our customer ser-
vice via the QR code on the enclosed document on ser-
vice contacts and warranty conditions or on our website.
You can find the information required as per Regulation
(EU) 2023/826 online at siemens-home.bsh-group.com
on the product and service pages for your appliance, in
the area of user manuals and additional documents.
20.1 Product number (E-Nr.), production
number (FD) and consecutive numbering (Z-
Nr.)
If you contact Customer Service, you will require the
product number (E-Nr.), the production number (FD)
and the consecutive numbering (Z-Nr.), which you can
find on the appliance's rating plate.
You can see the rating plate with these numbers when
you open the drawer.
Make a note of your appliance's details and the Cus-
tomer Service telephone number to find them again
quickly.
Information regarding Free and Open Source Software21 Information regarding Free and Open Source Software
This product includes software components that are li-
censed by the copyright holders as free software or
open source software.
The applicable licence information is stored on your
home appliance. You can also access the applicable li-
cence information via your HomeConnect app: "Profile
-> Legal information -> Licence Information".
1
You can
also download the licence information on the brand
product website. (Please search on the product website
for your appliance model and additional documents). Al-
ternatively, you can request the relevant information
from [email protected] or BSH Hausgeräte GmbH,
Carl-Wery-Str. 34, 81739 Munich, Germany.
The relevant source code will be made available on re-
quest.
Please send your request to [email protected] or
BSH Hausgeräte GmbH, Carl-Wery-Str.34, 81739 Mu-
nich, Germany.
Subject: „OSSREQUEST“
The cost of performing your request will be charged to
you. This offer is valid for three years from the date of
purchase or at least as long as we offer support and
spare parts for the relevant appliance.
1
Depending on the appliance specifications
15
en Declaration of Conformity
Declaration of Conformity22 Declaration of Conformity
BSH Hausgeräte GmbH hereby declares that the appliance with Home Connect functionality conforms to the essen-
tial requirements and other relevant provisions of Directive 2014/53/EU.
A detailed RED Declaration of Conformity can be found online at siemens-home.bsh-group.com among the additional
documents on the product page for your appliance.
Hereby, BSH Hausgeräte GmbH declares that the appliance with HomeConnect functionality is in compliance with
relevant statutory requirements.
1
A detailed Declaration of Conformity can be found online at siemens-home.bsh-group.com/uk/ among the additional
documents on the product page for your appliance.
1
2.4 GHz band (2400–2483.5MHz): Max. 100mW
5-GHz band (5150–5350MHz + 5470–5725MHz): max. 150mW
BE BG CZ DK DE EE IE EL ES
FR HR IT CY LI LV LT LU HU
MT NL AT PL PT RO SI SK FI
SE NO CH TR IS UK (NI)
5GHz WLAN (Wi-Fi): For indoor use only.
AL BA MD ME MK RS UK UA
5GHz WLAN (Wi-Fi): For indoor use only.
22.1 Statement of Compliance for Great
Britain
Product type
This statement of compliance covers the products de-
scribed in this information for use whose model identi-
fier group is seen on the title page. The full model identi-
fier is made up of the characters before the slash in the
product number (E no.) which can be found on the rat-
ing plate. Alternatively, you can also find the model iden-
tifier in the first line of the UK Energy Label.
Name and address of manufacturer
BSH Hausgeräte GmbH, Carl-Wery-Strasse 34, 81739
München, Germany
This statement of compliance is prepared by the manu-
facturer.
The manufacturer, BSH Hausgeräte GmbH deems that it
has complied with
provision 5.1-1 of ETSI EN 303 645 v3.1.3 and,
where relevant, provision 5.1-2 of ETSI EN 303 645
v3.1.3;
provision 5.2-1 of ETSI EN 303 645 v3.1.3;
provision 5.3-13 of ETSI EN 303 645 v3.1.3.
Support period
BSH Hausgeräte GmbH will provide security updates
that are necessary to maintain the main functions free of
charge until at least 28/02/2036.
Installation instructions23 Installation instructions
Observe this information when installing the appliance.
23.1 Included with the appliance
After unpacking all parts, check for any transport dam-
age and for completeness of delivery.
1
Only applies to Great Britain
16
Installation instructions en
14cm
29cm
23.2 Appliance dimensions
You will find the dimensions of the appliance here
23.3 Installation in the cabinet
You will find the dimensions of the appliance here
14cm
29cm
17
en Installation instructions
23.4 Instructions for the electrical
connection
In order to safely connect the appliance to the electrical
system, follow these instructions.
WARNING‒Risk of electric shock!
It must always be possible to disconnect the appliance
from the electricity supply. The appliance must only be
connected to a protective contact socket that has been
correctly installed.
The mains plug for the mains power cable must be
easily accessible after the appliance is installed.
If this is not possible, an all-pole isolating switch must
be integrated into the permanent electrical installation
according to the conditions of overvoltage category III
and according to the installation regulations.
The permanent electrical installation must only be
wired by a professional electrician. We recommend
installing a residual-current circuit breaker (RCCB) in
the appliance's power supply circuit.
The appliance must only be connected using the power
cable provided. Connect the power cable to the back of
the appliance.
Connecting cables with various plug types are available
from customer service.
Do not use multi-socket adaptors, power strips or exten-
sion leads. Overloading causes a risk of fire.
23.5 Safe installation
Follow these safety instructions when installing
the appliance.
WARNING‒Risk of suffocation!
Children may put packaging material over their
heads or wrap themselves up in it and suffoc-
ate.
Keep packaging material away from chil-
dren.
Do not allow children to play with packaging
material.
WARNING‒Risk of fire!
It is dangerous to use an extended power cord
and non-approved adapters.
Do not use extension cables or multiple
socket strips.
Only use adapters and power cords ap-
proved by the manufacturer.
If the power cord is too short and a longer
one is not available, please contact an elec-
trician to have the domestic installation ad-
apted.
WARNING‒Risk of electric shock!
If the insulation of the power cord is damaged,
this is dangerous.
Never let the power cord come into contact
with hot appliance parts or heat sources.
Never let the power cord come into contact
with sharp points or edges.
Never kink, crush or modify the power cord.
WARNING‒Risk of injury!
The drawer may open suddenly during trans-
port.
Transport the appliance in such a way that
the drawer does not accidentally open.
Sharp-edged parts may be accessible during
installation.
Wear protective gloves.
ATTENTION
When the door is opened, the appliance may
tip over.
Above the appliance, provide a fixed inter-
mediate floor in the fitted unit.
When combined with an oven, provide a
fixed intermediate floor above the oven.
WARNING‒Risk of electric shock!
Incorrect installation is dangerous.
Connect and operate the appliance only in
accordance with the specifications on the
rating plate.
Connect the appliance to a power supply
with alternating current only via a properly in-
stalled socket with earthing.
18
Installation instructions en
The protective conductor system of the do-
mestic electrical installation must be properly
installed.
Never equip the appliance with an external
switching device, e.g. a timer or remote con-
trol.
When installing the appliance, check that the
power cable is not trapped or damaged.
23.6 Installation
Fitted units
This is where you can find information about safe install-
ation.
ATTENTION
Covering the ventilation slots and air intake openings
causes the appliance to overheat.
Do not cover ventilation slots and air intake openings.
If the appliance is installed behind a decorative panel,
this may cause it to overheat.
Do not install the appliance behind a decorative
panel.
When the door is opened, the appliance may tip over.
Above the appliance, provide a fixed intermediate
floor in the fitted unit.
When combined with an oven, provide a fixed inter-
mediate floor above the oven.
The built-in unit must not have arear panel behind
theappliance.
Combining with other appliances
You can combine the warming drawer with a maximum
of one more appliance from the same appliance series.
No intermediate floor is required between the appli-
ances.
When installing appliances under an oven, combi-steam
oven or steam oven, no tilt protection is required.
When installing under the fully automatic coffee ma-
chine, install the tilt protection for the fully automatic cof-
fee machine.
For the following combinations, install tilt protection on
the warming drawer:
Warming drawer separately, including when installing
below an intermediate floor
Warming drawer underneath a microwave
Warming drawer underneath a hob
Warming drawer with warming drawer, at least on the
upper appliance
Warming drawer with accessories drawer, at least on
the upper appliance
Warming drawer with vacuuming drawer, at least on
the upper appliance
Always install the vacuuming drawer below the culinary
warming drawer.
Suitable tilt protection can be obtained from customer
service, on our website or in the online shop.
"Fitting tilt protection", Page19
Do not install the appliance above an appliance that
generates steam, e.g. above a dishwasher, a combi-
steam oven or a steam oven.
Observe the installation
Page21
instructions when
combining with other appliances.
Fitting tilt protection
Suitable tilt protection (order number: 12039458) can
be obtained from customer service, on our website or in
the online shop.
1.
Align the two brackets at the mark.
2.
Screw the two brackets into the elongated hole be-
hind the mark.
3.
Place the appliance on a flat surface.
4.
Unscrew the two lower screws on the back of the ap-
pliance.
19
en Installation instructions
5.
Use the two screws to tighten the two metal retainers
on the back of the appliance.
Ensure that the metal retainers are aligned exactly
with the edge of the appliance.
6.
Slide the appliance into the fitted unit and check
whether the tilt protection engages.
7.
If required, correct the position of the bracket with the
elongated hole.
8.
Finally, screw the brackets to the fitted unit.
9.
Insert the power cable fully into the appliance.
10.
Push the appliance into the fitted unit.
Do not pinch the power cable.
11.
Remove the adhesive strips from the front panel.
12.
Open the appliance carefully and check whether the
tilt protection is working.
Installing the appliance
WARNING‒Risk of injury!
When the door is opened, the appliance may tip over.
In the case of installation without an intermediate
floor, weigh down the appliance with a suitable weight
before opening.
ATTENTION
Tightening the screws too tight causes the side panel to
become misshapen. The appliance will then no longer
be flush with the other appliances.
Do not use excessive force when tightening.
1.
Insert the power cable fully into the appliance.
2.
Push the appliance all the way into the fitted unit.
Do not pinch the power cable.
3.
Centre the appliance.
4.
Remove the adhesive strips from the front panel.
5.
Open the appliance.
6.
Screw the appliance to the built-in unit.
20
Installation instructions en
7.
Fit the two plastic covers on the left and right of the
profile.
8.
Insert the power cord into a protective contact socket.
The power cord must not touch the rear and base of
the appliance after installation.
Adjusting the front panel
Adjust the front panel upwards or downwards as neces-
sary.
1.
Open the appliance.
2.
Only loosen the screws on the side of the front panel
– do not unscrew them completely.
3.
Align the front panel upwards or downwards.
A maximum alignment of -3 to +3mm is possible.
4.
Tighten the screws.
If the screws do not tighten when screwed in
tightly, loosen the screws fully, move the furniture
panel upwards and downwards until the thread is
visible.
Combining the warming drawer with another
appliance
ATTENTION
Sharp edges on the appliance may damage the front
panel of the warming drawer.
Do not damage the front panel of the warming drawer
when sliding the appliance in.
Before installing another appliance, open the warming
drawer, place a cloth over the front panel and close
the warming drawer to protect the front panel of the
warming drawer from damage.
1.
Only combine suitable appliances of the same brand
and series.
2.
Observe the instructions for combining with other ap-
pliances
Page19
.
3.
Install the warming drawer first.
4.
Slide the appliance, on the warming drawer, into the
built-in cabinet.
5.
Observe the installation instructions for the appliance.
6.
Remove the cloth from the warming drawer.
21
Siemens Home Appliances
App
Connect your home appliance today and enjoy the following
benefits:
• Enjoy smart control and have easy access to device information -
from anywhere, even per voice.
• Optimize product performance with regular software updates,
cooking assistance and feature explanation.
• Improve product care thanks to useful maintenance and cleaning
reminders and a device status dashboard.
EN Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
siemens-home.bsh-group.com
*9001674174*
9001674174 (060608) REG25
en
