Instruction Manual
Hot Pressure Washer
HY145HPW-1
WARNING: Read the instructions carefully before use.
www.hyundaipowerproducts.co.uk
2
Contents
Introduction……..……………………………3
Safety Information…..…………………..4-14
Understand Your Machine.…..…………...4
Personal Safety...…….……………………4-5
Inspect Your Machine…………………...5-6
Work Area…….……………………………....6
During Use…….…………………………….7-8
Batteries…….…………………………………9
Electricity…….………………...………….9-10
Double Insulated Devices…......…….......10
Vibrations….…………………………..........11
Noise…….……………………………..........11
Residual Risks…………………....................11
Intended Use………………………............12
Personal Protective Equipment…...........13
Symbols On The Machine………………..14
Unboxing…………………………...............15
In The Box………………………..................16
Features………………………….................17
Assembly……..…………………….......18-20
Assembly Overview……………………….18
Handle Assembly……………….…………18
Water Supply Hose Attachment…….....19
High Pressure Hose Attachment………..20
Maintenance & Care………………….29-30
General Maintenance……………………29
Storage………………………………………29
Troubleshooting…………………………….30
Specifications……………………...............31
Recycling And Disposal..………………...32
Declaration Of Conformity…..…………..33
Useful Information…..……………………..34
Our YouTube Channel…..………………..34
Warranty…………………………………….34
Manual Updates….……………………….34
Returning Your Product….……………….34
Leaving A Review….……………………...34
Ordering Spare Parts.……………………..34
Product Record…..………………………...35
Contact Us…..……………………………....36
Operation……...………………………..21-46
Filling with Fuel...…………………………....21
Starting Preparations.………………….22-23
Lance Attachment………………………...24
Lance Operation…………………………...25
Detergent Attachment……………………26
Hot Water Function……………….……..…27
Stopping……………………………………...28
www.hyundaipowerproducts.co.uk
3
Introduction
Thank You For Purchasing Your HYUNDAI Product
We work very hard to give all of our customers the best possible service. If you
have any problems, before leaving negative feedback, please contact us to give
us a chance to resolve the issue. We would be delighted if you left us positive
feedback! Thank you for purchasing this product.
Important!
This manual has been produced by Hyundai Power Products and should be kept
with the product. Please read and understand these instructions before you use
your product. Failure to do this may result in personal injury or damage to the
product.
The safety precautions and warnings are to ensure your safety and protect you
from harm or damage to the product.
The information contained in this manual was accurate at the time of production,
however HYUNDAI Power Products may make modifications to the product
without notification.
WARNING: READ THE INSTRUCTION BOOKLET THOROUGHLY BEFORE USING
THE MACHINE. Keep for future reference and pass it on if the machine is
loaned or sold to another user.
!
www.hyundaipowerproducts.co.uk
4
Safety Information
Understand Your Machine
• WARNING! You must read these instructions carefully before operating the
machine. Make sure that you are familiar with the controls and properly operate
the machine. You must learn how to stop the machine quickly. If you do not follow
the warnings and instructions, it may result in fire and/or serious injury. Make sure to
save all warnings and instructions for future reference.
• Read this manual and labels affixed to the machine to understand its limitations
and potential hazards.
• Be thoroughly familiar with the controls and their proper operation. Know how to
stop the machine and disengage the controls quickly.
• If the unit is to be used by someone other than original purchaser, or is to be
loaned, rented, or sold, always provide this manual and any needed safety
training before operation. The user can prevent and is responsible for accidents or
injuries that may occur to themselves, to other people, or to property.
• Do not force the machine beyond its limits. Use the correct machine for your
application.
• Know how to stop the machine quickly in case of emergency. Understand the
use of all controls.
• ALL MAINTENANCE other than that listed in this manual, should be carried out by
professionally trained and certified personnel.
• When using this machine for the first time and before actual work, you MUST
learn how to handle the machine from an experienced or skilled person.
Personal Safety
• WARNING! Never allow children or people unfamiliar with these instructions to
use the product. Local regulations can restrict the minimum age of the operator.
• Keep children, pets, and other people not using the unit away from the work
area (at least 15m). Be alert and shut off the unit if anyone enters work area. Keep
children under the watchful care of a responsible adult.
• Stay alert, watch what you are doing and use common sense when operating
the machine. Never operate the machine when unwell or tired, or if you have
taken alcohol, medicine, drugs or any substances which may slow your reflexes
and compromise judgment. A moment of inattention while operating the machine
may result in serious personal injury.
• Appropriate Personal Protective Equipment (PPE), MUST be worn at all times
when operating or repairing the machine. Always wear anti-slip and resistant work
footwear and long trousers while using the machine. Do not use the machine
when barefoot, wearing sandals or similar lightweight footwear. Do not wear
chains, bracelets or clothing that is loose fitting or hanging ties or cords. Tie long
hair back. Always wear protective earplugs. Loose clothes, jewellery, or long hair
can be caught in moving parts. Protect eyes, face, and head from objects that
may be thrown from the unit. Always wear safety goggles or safety glasses with
side shields when operating.
•Always keep hands and feet away from all moving parts during operation.
Moving parts can cut or crush body parts. Always keep hands and feet away from
all pinch points.
!
!
www.hyundaipowerproducts.co.uk
5
Safety Information
Personal Safety (Continued)
• Do not touch parts that might be hot from operation. Allow parts to cool before
attempting to maintain, adjust, or service.
• Do not overreach. Keep proper footing and balance at all times. This enables
better control of the machine in unexpected situations. Extending your body too
far can result in a loss of balance and you may fall which will result in injury.
• Never place any part of your body where it would be in danger if movement
should occur during assembly, installation, and operation, maintenance, repairing
or moving.
• Keep in mind that the operator or user is responsible for accidents, hazards or
unexpected events involving the machine that occur to other people or their
property. It is the responsibility of the user to assess the potential risk of the area
where work is being carried out. The operator or user must take all necessary
precautions to ensure their own safety and that of others, especially on slopes or
rough, slippery and unstable ground.
Inspect Your Machine
• Check your machine before starting it. Keep guards in place and in working
order. Make sure all nuts, bolts, etc., are securely tightened.
• You must check the general condition of the machine before use.
• Never operate the machine when it is in need of repair or is in poor mechanical
condition. Replace damaged, missing, or failed parts before using it. Check for fuel
leaks. Keep the machine in safe working condition.
• Do not use the machine if the machine’s switch does not turn off the machine
when running. Any machine that can’t be controlled with the switch is dangerous
and must be replaced.
• Regularly check to see that keys and adjusting wrenches are removed from the
machine area before starting it. A wrench or a key that is left attached to a
rotating part of the machine may result in personal injury.
• If the machine should start to vibrate abnormally, stop the machine and check
immediately for the cause. Vibration is generally a warning sign of trouble.
• Avoid accidental starting. Be sure the switch is off before transporting the
machine or performing any maintenance or service on the unit. Transporting or
performing maintenance or service on a machine with its switch on invites
accidents.
• Do not tamper with or disable safety systems.
• Only use manufacturer-recommended attachments.
• Before using, always visually inspect to see that the tools are not worn out or
damaged. Replace worn out or damaged elements and bolts in set to preserve
balance.
• Keep the machine in good operating condition. Operating the machine in poor
or questionable condition could result in serious injury.
• Be sure all safety devices are in working order and warning labels are in place.
These items are installed for your safety.
!
!
www.hyundaipowerproducts.co.uk
6
Safety Information
Work Area
• You must only work in daylight or with good artificial light in good visibility
conditions. Do not work at night, at times of heavy fog, or at any other times when
your field of vision might be limited and it would be difficult to gain a clear view of
the area.
• Keep people, children and animals away from the working area.
• Operate on flat, level ground.
• DO NOT work on wet ground. If there has been heavy rain on the working site,
wait until the ground has dried up.
• Never park the machine in a place with unstable ground which could give way.
• You must be careful near ravines, ditches or embankments.
• Exercise extreme caution when operating on or crossing gravel drives, walks, or
roads. Stay alert for hidden hazards or traffic.
• Do not work in the rain, when there is a thunderstorm or lightning risk, at times of
strong or gale force winds, or at any other times when the weather conditions
might make it unsafe to use this product. If there is bad weather conditions, do not
use the machine.
• Make sure you thoroughly inspect the entire work area and remove all objects
and anything that could be thrown by the machine or could damage the
machine (branches, stones, wire, toys, etc). Attempting to clear the work area
whilst using the machine will reduce your concentration and creates a trip hazard.
Any liquid spilled on the floor may result in you slipping.
• DO NOT operate power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases or dust. Power tools may create sparks, which may
ignite the dust or fumes.
• This machine is only for outdoor use.
!
Inspect Your Machine (Continued)
• Keep the machine in good operating condition. Operating the machine in poor
or questionable condition could result in serious injury.
• Be sure all safety devices are in working order and warning labels are in place.
These items are installed for your safety.
!
www.hyundaipowerproducts.co.uk
7
Safety Information
During Use
!
• Do not operate the machine in confined areas where there may be a risk of
crushing the operator between the machine and another object.
• Never attempt to make any adjustments, while the machine is running.
• You must switch off the machine:
- Before checking or working on the machine.
- When transporting the machine.
- Whenever you leave the machine unattended.
- If the machine starts to vibrate abnormally.
• WARNING! If something breaks or an accident happens whilst working, you must
turn off the machine immediately and move the machine away to prevent
further damage. If an accident happens with injuries or third parties are injured,
carry out the first aid measures most suitable for the situation immediately and
contact the medical authorities for any necessary health care. Carefully remove
any debris that might cause damage or harm persons or animals should it not
be seen.
• After striking a foreign object, stop the machine immediately and inspect the
machine thoroughly for damage. Repair the damage before continuing.
• Never operate the machine without the defective guards or shields, or without
safety devices, or if the cord is damaged or worn.
• Always disconnect the electricity and water supplies on completion of every job.
• This appliance has been de-signed for use with the detergent provided or the
detergent specified by the manufacturer, such as a neutral shampoo based on
biodegradable anionic surface active deter-gents. The use of other detergents
or chemicals may put the appliance’s safety at risk.
• Do not touch the plug and the appliance with wet hands or when barefoot.
• Do not direct the nozzle toward mechanical parts containing lubricant grease,
as the grease will dissolve and spread over the surrounding ground. Vehicle
tyres/tyre valves may only be cleaned from a minimum distance of 30 cm,
otherwise the vehicle tyre/tyre valve could be damaged by the high-pressure
jet. The first indication of this is a discoloration of the tyre. Damaged vehicle
tyres/tyre valves can be deadly dangerous.
• High pressure jets can be dangerous if subject to misuse. The jet must not be
directed at persons, animal, live electrical equipment or the machine itself.
• High pressure hoses, fittings and couplings are important for the safety of the
machine. Use only hoses, fittings and couplings recommended by the
manufacturer. (it is extremely important to protect these components against
damage by avoiding their improper use and protecting them against bending,
knocks and scratches).
• Do not direct the jet against yourself or others in order to clean clothes or
footwear.
• Risk of explosion — Do not spray flammable liquids.
• Appliance with fluid under pressure. Keep a firm hold on the gun and be
prepared to take the kickback pressure. Only use the high pressure nozzle
provided with the appliance.
www.hyundaipowerproducts.co.uk
8
Safety Information
During Use
!
• Do not leave the machine during standby for more then 5 minutes.
• Any automatic start of the machine without pressing the gun trigger is
attributable to air bubbles in the water or other similar phenomena which do not
imply the existence of any defects in the machine.
• When winding and unwinding the pipe take care not to cause the high-pressure
cleaner to overturn.
• Before unwinding or winding the hose, switch the machine off and release the
pressure in the hose itself (switching off).
• If an extension cord is used, the plug and socket must be of watertight
construction.
• DO NOT direct the spray at people, animals, live electrical equipment or the
appliance.
• Do not allow the high pressure hose to bend.
• Do not put any weight on the high pressure hose.
• Do not use the high pressure hose if it is in a knot or loop.
• Never start the high-pressure cleaner without first completely unwinding the
• high-pressure hose.
• Make sure the high pressure hose does not have any loops or tangles.
www.hyundaipowerproducts.co.uk
9
Safety Information
Batteries (Where Present)
Batteries present a risk if they become damaged by the possible leaking of
electrolyte. This electrolyte is an acid and can cause serious burn injuries. Care
should be taken when working on or near them. NOTE: the electrolyte may be in a
liquid or gel form.
Should you come in to contact with electrolyte you should;
• Remove all clothing contaminated with electrolyte. If you cannot remove then
saturate them in water.
• Get medical assistance as soon as possible.
You must advise the medical staff of the type of acid.
• Lead/acid battery = dilute sulphuric acid.
• Nickel/cadmium = potassium hydroxide alkali electrolyte.
• Use fresh running water to wash off excess electrolyte, continue this until medical
assistance arrives. Make sure that you do not wash the electrolyte to another part
of your body or face.
• If electrolyte comes in to contact with Eyes the electrolyte needs to be
immediately washed away with large amounts of water. Make sure that you do
not wash the electrolyte to another part of your face or body.
• Gasses from charging batteries are highly flammable and great care should be
taken to charge in well ventilated areas.
• There is an explosion risk if the battery terminals are short circuited,
when connecting/disconnecting ALWAYS exercise great care so that
the terminals or battery leads are NOT allowed to touch and cause a
spark. ALWAYS use suitable insulated tools.
Electricity (Where Applicable)
DANGER : ELECTRICITY CAN KILL – NEVER WORK ON LIVE / ENERGISED EQUIPMENT.
!
!
• Prior to carrying out any maintenance work you MUST identify electrical
. isolation methods and isolate all electrical supplies.
• Prior to use and with all electrical supplies isolated, you MUST check all
electrical cables, plugs and connectors for the following;
- Are intact and have no signs of damage, to include but not limited to bare wires,
chaffing, cuts and loose wiring.
- If there are any signs of damage, the damaged item MUST be taken out of
service until the damage has been repaired by an electrically competent person.
- All trailing cables should be routed so as not to cause any kind of trip hazard.
- NEVER work on or near electricity with wet hands, wet clothing and wet gloves.
www.hyundaipowerproducts.co.uk
10
Safety Information
Electricity (Continued)
• Power tools plug must match the outlet. Never modify the plug in any way. DO
NOT use any adapter plugs with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of electric shock.
• DO NOT expose this power tool to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock. DO NOT abuse the power cord. Never
use the cord for carrying, pulling or unplugging the power tool. Keep the cord
away from heat, oil and sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock. When operating a power tool, use an
extension cord suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
• IMPORTANT: Make sure that the electric circuit is fused, and that the power,
voltage and frequency of the motor is supported by your mains supply. Also, make
sure that your power supply is earthed. Connect your machine to earth. Never
open the ON/OFF switchbox. However, if it should become necessary to do so,
contact a qualified electrician. Make sure that you will never touch live contacts,
specifically when you plug or unplug your machine. This machine and its power
cord must never get into contact with water.
• Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
• To prevent electric shock, use only with an extension cord suitable for outdoor
use. For additional protection, the installation of a residual current device (RCD)
having a rated residual operating current not exceeding 30mA is advisable.
• Before use, check that the extension cord is in good condition. When using an
extension cord, make sure to use one heavy enough to carry the current your
product will draw. An undersized cord will cause a drop in line voltage resulting in
loss of power and overheating.
• Do not allow any part of the machine to make contact with water while it is in
operation. If the appliance becomes wet while turned off, wipe dry before starting.
Do not touch the appliance or its plug with wet hands or while standing in water.
Wearing rubber boots offers some protection.
• Before use, check the supply and extension cord for signs of damage or aging. If
the cord becomes damaged during use, disconnect the cord from the supply
immediately. If the supply cord is damaged, it must be replaced by the
manufacturer or a qualified person in order to avoid a hazard.
!
Double-Insulated Appliances
In a double-insulated appliance, two systems of insulation are provided instead of
grounding. No grounding means that it is already provided on a double-insulated
appliance. Servicing a double-insulated appliance requires extreme care and
knowledge of the system, and should be performed only by qualified service
personnel. Replacement parts for a double-insulated appliance must be identical
to the parts they replace.
!
www.hyundaipowerproducts.co.uk
11
Safety Information
Vibrations (Where Applicable)
• Prolonged use of hand held (operated) machines will cause the user to feel the effects
of/from vibrations. These vibrations can lead to white finger (Raynaud’s phenomenon) or
carpal tunnel syndrome. This condition reduces the ability of the hand to feel and regulate
temperature, causing numbness and heat sensations and may cause nerve damage and
circulatory tissue death.
• Not all factors that lead to white finger disease are known, but cold weather, smoking
and other diseases that affect blood vessels and blood circulation as well as large and
long-lasting impact of shocks are considered factors in the formation of white finger. Note
the following to reduce the risk of white finger and carpal tunnel syndrome;
• Wear gloves and keep your hands warm.
• Take regular breaks.
• All of the above precautions may help reduce the risk of white finger disease but not rule
out the carpal tunnel syndrome. Long-term and regular users are therefore recommended
to observe the condition of your hands and fingers. Seek medical attention immediately if
any of the above symptoms should occur.
Noise (Where Applicable)
• The operating noise of the machine can damage your hearing. When wearing
protection such as earplugs or ear defenders to protect your hearing. Long-term and
regular users are advised to have hearing checked regularly. Be especially vigilant and
cautious when wearing ear protection because your ability to hear alarm warnings will be
reduced.
• Noise emissions for this equipment is unavoidable. Carry out noisy work at approved
times and for certain periods. Limit the working time to a minimum. For your personal
protection and protection of people working nearby it is also advisable for them to wear
hearing protection.
• See Certificate of Conformity section for Outdoor Noise declaration of .
. conformity.
!
!
Residual Risks
Even when tool is used as prescribed it is not possible to eliminate all residual risk
factors. The following hazards may arise in connection with the tool’s construction
and design:
1. Damage to lungs if an effective dust mask is not worn.
2. Damage to hearing if effective hearing protection is not worn.
Health defects resulting from vibration emission if the power tool is being used over
longer period of time or not adequately managed and properly maintained.
WARNING! This machine produces an electromagnetic field during operation.
This field may under some circumstances interfere with active or passive medical
implants. To reduce the risk of serious or fatal injury, we recommend persons with
medical implants to consult their physician and the medical implant manufacturer
before operating this machine.
!
!
www.hyundaipowerproducts.co.uk
12
Safety Information
Intended Use
The HY145HPW-1 is a Hot Pressure Washer from HYUNDAI. Using a 2.3kW electric
motor, paired with a diesel heater.
This machines are specifically a pedestrian tool, manufactured according to the
latest safety requirements. Every precaution is only effective when it’s followed
exactly.
Intended Use
These machines are designed and manufactured for cleaning surfaces under high
pressure and heat. Domestic uses such as cleaning walls, driveways and vehicles
are what the machine is intended for.
This machine is intended for use in environments with a maximum ambient
temperature of 32
0
C.
User Types
This machine is intended for use by consumers, i.e. non professional operators. The
machine is intended for “DIY” and domestic use only.
Improper Use
Any other usage not in keeping with the above mentioned ones may be
hazardous and harm persons and/or damage things. Examples of improper use
may include, but are not limited to:
• Using the machine to clean people or animals
• Cleaning surfaces which aren’t structurally sound
• Cleaning vehicles with damaged or faulty body or point work.
!
www.hyundaipowerproducts.co.uk
13
Safety Information
Personal Protective Equipment
Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when
operating or repairing the machine. No protective equipment can ensure 100%
protection.
When selecting PPE, make sure it’s CE marked and it suits the user in terms of size,
fit, etc. If more than one item of PPE is worn at the same time, make sure they can
be used together, e.g. wearing safety glasses may disturb the seal of a respirator,
causing air leaks.
!
Hand Protection Must Be Worn
Protective electrically non-conductive gloves are highly
recommended when working.
Foot Protection Must Be Worn
Non-skid heavy duty footwear are highly recommended when
working.
Hearing Protection Must Be Worn
Suitable safety hearing protection is recommended.
Eye Protection Must Be Worn
Always wear safety glasses/goggles and/or face shields. Everyday
eyeglasses have only impact resistant lenses; they are not safety
glasses/goggles.
Protective Clothing Must Be Worn
Do not wear loose clothing, gloves, scarfs, neckties or jewellery (rings,
wrist watches), which can be caught in moving parts.
Head Protection Must Be Worn
Wear a safety helmet with a safety visor.
Face Shield Must Be Worn
Wear a face shield to protect your face.
www.hyundaipowerproducts.co.uk
14
Safety Information
Symbols On The Machine
We have provided safety messages in this manual and on the machine. This
information alerts you to potential hazards that could hurt you or others. Please
read these messages carefully. However, we may not have listed all of the possible
hazards, you must also use your own judgement.
!
Symbol
Description
Symbol
Description
Safety alert – Indicates a
precaution, a warning or
a danger.
Dust mask must be worn
Read operator’s manual. Class II tools symbol.
Hand protection must be
worn
Hearing protection must
be worn
Sharp blades can cut
limbs.
Eye protection must be
worn
The UKCA (UK Conformity
Assessed) marking is a UK
product marking that is
required for goods being
placed on the market in
Great Britain (England,
Wales and Scotland).
This product complies
with the European
directives and an
evaluation method of
conformity for these
directives was done.
This product should not
be disposed of in
domestic waste. Please
contact your local
recycling centre for
disposal service.
Sound power level LWA
data in dB.
www.hyundaipowerproducts.co.uk
15
Unboxing
WARNING : Unboxing and assembling the machine should be done on a flat,
surface with enough room. Disposal of the packaging should be done in
accordance with the local regulations in force.
!
WARNING : Some of the packaging material may be harmful to children. Keep
out of reach of children.
1. Carefully remove the product from the packaging and examine it for any sign of
damage caused during shipping.
2. Lay the contents out and check them. If any part is damaged or missing, you
must not use the machine. Contact HYUNDAI POWER PRODUCTS immediately.
3. You must keep the packaging material in case the machine needs to be
returned or repaired.
4. Ensure that you have all the accessories and tools you need for assembly and
operation including the suitable personal protective equipment.
We recommend that you fill out the information in the ‘Product Record’ section. If
you need to contact an authorised dealer or customer service, you may need to
provide this information.
!
www.hyundaipowerproducts.co.uk
16
Unboxing
*Not To Scale
A
B
C
D
E
F
G
H
I
K
A. Main Body
B. Handle
C. Lance Holder
D. Wire Holder
E. Water Filter
F. Inlet Adapter
G. Gun Handle
H. Lance
I. High Pressure Hose
J. Detergent Attachment
K. Power Cable (attached to Main Body)
J
www.hyundaipowerproducts.co.uk
17
Features
*Not To Scale
11
12
1. Handle – used to move the machine.
2. On/Off Switch
3. Detergent Attachment – Used to dispense detergent.
4. Water Outlet – Motor outlet for pressurized water
5. High Pressure Hose – Connects the Lance Handle and
Water Outlet.
6. Lance Handle – The Trigger, Trigger Safety Button and
hose release are apart of the handle.
7. Lance – Creates a spray pattern
8. Diesel Tank – 2L tank for Hot Water Function.
9. Power Cable
10. Water Inlet Adapter and Water Filter
11. Hose Holder
12. Lance Holder
www.hyundaipowerproducts.co.uk
18
Assembly
HY145HPW-1 Handle Assembly
1. Press the Handle into the 2 prongs at the top of machine. An
Audible click will be heard when the handle is secured.
2. Push the Lance holder into position on the Handle, and secure with
2 screws.
3. Secure the Hose Holder into position using 2 screws
!
WARNING : Ensure the machine is not plugged in, and the switch is in the off
position before starting any assembly.
HY145HPW-1 Assembly Overview
Page 18 – Handle Assembly
Page 19 – Water Supply Hose Attachment
Page 20 – High Pressure Hose Attachment
www.hyundaipowerproducts.co.uk
19
Assembly
HY145HPW-1 Water Supply Hose Attachment
!
WARNING : Ensure the machine is not plugged in, and the switch is in the off
position before starting any assembly.
1. Ensure the Water Filter is fitted to the machines Water Inlet.
2. Screw the Water Inlet Adapter onto the Water Inlet Port until hand
tight (no tools required)
3. Now connect your water supply hose, with connector (not
included) to the Water Inlet Adapter.
4. Ensure your Water Supply Hose is attached to your water supply
!
WARNING : Ensure your Water Supply Hose is attached to a water source that
can provide 15l/min of water, max pressure 1 Mpa at a Maximum temperature
of 40
0
C. Only clean water can be used with his machine
www.hyundaipowerproducts.co.uk
20
Assembly
HY145HPW-1 High Pressure Hose Attachment
!
WARNING : Ensure the machine is not plugged in, and the switch is in the off
position before starting any assembly.
1. Fasten the end of the High Pressure Hose to the Water Outlet,
ensure this is hand tight (no tools required)
2. With the other end of the High Pressure Hose, insert in the Lance
Handle until you hear an audible click.
3. To remove the hose, simply press the tab on the Lance Handle and
pull the hose downward.
www.hyundaipowerproducts.co.uk
21
Operation
HY145HPW-1 Filling with Fuel
A
B
!
WARNING : When handling Volatile and Corrosive Fuels always use correct PPE
and due caution
1. Remove the Fuel Cap (A).
2. Fill the Diesel Tank with Diesel from a fuel station. The tank capacity
is 2 Litres.
3. Use the Fuel Tank Window to see if there is fuel in the machine
before filling.
4. When finished filling, secure the Fuel Cap (A) back on the machine.
!
WARNING :Before Operating the machine, you MUST understand the whole user
manual
www.hyundaipowerproducts.co.uk
22
Operation
HY145HPW-1 Starting Preparations
Continued on next page
1. With the water supply hoses attached to machine, turn on your
water supply. The minimum supply rate must be 15 Litres per
minute, maximum pressure of 1MPa(mega pascals). The temperate
of the water should be between 5-40 degrees Celsius.
2. Put the machines plug into a power source. Do not turn the power
source on at this point.
Off
5-40°C
Min. 15L/min
Max. 1MPa
www.hyundaipowerproducts.co.uk
23
Operation
HY145HPW-1 Starting Preparations continued
1. Firstly press the Unlock Trigger Safety button on the Lance Handle.
2. Then purge the air from the system. With the water supply on, pull
the trigger on the Lance Handle, this can take up to 1 minute.
3. Attach a Lance accessory (page 24+26).
On/Off Switch
Lock
Unlock
!
*Note* - The On/Off Switch MUST be in the Off (O) position
www.hyundaipowerproducts.co.uk
24
Operation
HY145HPW-1 Lance Attachment
The Lance attaches to the Lance Handle by inserting and twisting
clockwise. When rotation stops, this means it’s locked into position.
To remove the Lance, push the Lance into the handle and rotate anti-
clockwise.
NOTE : If the Lance won’t rotate into place, try applying more force
pushing the Lance into the Handle, this will help to seat the Lance
correctly. This is also the case when removing the lance.
The Lance has an adjustable spray pattern. By rotating the end
clockwise and anti-close you can adjust the spray pattern to focus the
water into a single beam or wider spread.
www.hyundaipowerproducts.co.uk
25
Operation
HY145HPW-1 Lance Operation
Turn the Power Source to the machine on, and put the On/Off Switch
into the On (I) Position. Allow the machine to build pressure.
ALWAYS hold the Lance with 2 hands AT ALL TIMES. The pressure
created by the machine can cause kick back. Using 2 hands provides
additional control and prevents unintentional spraying. Using only 1
can lead to injury and accidents.
Pull the trigger on the Lance Handle, and the machine will start to
operate.
!
WARNING :Before Operating the machine, you MUST understand the
whole user manual
On
www.hyundaipowerproducts.co.uk
26
Operation
HY145HPW-1 Detergent Attachment
Remove the top from the Detergent attachment and fill with a suitable
cleaning product. It has a 0.5 litre (500ml) capacity.
The Detergent Attachment connects to the Lance Handle in the same
way as the normal lance. Press the attachment into the Lance and
rotate clockwise. Repeat in reverse to remove the Detergent
Attachment from the Lance Handle.
Refer to Page 25 for operation.
!
WARNING : Never use Soaps, Foams or Detergents high in Acid or
Alkaline. This will cause damage and void warranty.
www.hyundaipowerproducts.co.uk
27
Operation
HY145HPW-1 Hot Water Function
On/Off Switch
Ensuring your HY145HPW-1 has an active Water Supply and filled with
fuel, turn the On/Off Switch to the Hot Water Position ( ).
NOTE : Allow the Diesel Heating element some time to heat the water
under pressure. The first few seconds of use, the water may not be up
to full temperature.
www.hyundaipowerproducts.co.uk
28
Operation
HY145HPW-1 Stopping
When finished using the machine, release the trigger and put the
machine On/Off switch into the Off position, with the water supply off.
Switch off the power source and unplug the machine. Press the Lock
button on the Trigger Safety Switch.
Lock
www.hyundaipowerproducts.co.uk
29
Maintenance & Care
General Maintenance
WARNING : Turn OFF the machine, allow all moving parts to come to a
complete stop, and disconnect the power cord before maintaining the machine.
You need to wear proper clothing and protective gloves whenever your hands are
at risk.
• Keep all nuts, bolts and screws tight to be sure the machine is in a safe working
condition.
• Replace worn or damaged parts for safety. Only use manufacturer-
recommended parts and accessories.
!
Storage
Keep the machine stored in a dry, level area away from damp, moisture and
rain fall. Allow the machine to cool down before storing.
• Make sure the machine is clean and dry before storing.
• Ensure the machine is stored in a position, where any persons cannot step on, to
attempt to reach items up high, due to risk of movement.
• DO NOT store the machine near an ignition source, such as a wood stove, gas
or electric heater, or an appliance or heater with a pilot light.
• Store the machine out of reach of children or anyone who is not familiar with
operation.
• DO NOT stack other items on top of the machine when in storage.
• Make sure the machine is stored away from direct sunlight. Store indoors or in a
safe, frost-free area during severe weather and winter months.
!
www.hyundaipowerproducts.co.uk
30
Maintenance & CareMaintenance & Care
Troubleshooting
Problem Possible Solution
Machine will not start. Check fuse in mains plug and replace if
necessary.
Check whether the voltage shown on the
rating plate corresponds to that of the
power source.
The cable could be damaged. Check the
cable for damage.
Machine does not reach operational
pressure.
Vent the appliance: allow the pump to
operate without the high-pressure hose
until water appears at the high-pressure
outlet without any more bubbles. Then
re-attach the high-pressure hose.
Clean the strainer
in the water connection.
Clean the filter placed inside the hose
coupling (if set).
Check the inlet water flow rate.
Check all inlet pipes to the pump for leaks
or blockage.
Strong pressure fluctuations. Clean the high-pressure nozzle. Remove
dirt from the nozzle hole with a needle (not
included) and then rinse out with water
from the front.
Pump leaks. 10 drops per minute are permissible. In the
case of more serious leakage, you should
contact your service dealer.
!
WARNING : The appliance is equipped with a motor protection device: in case
of intervention, wait a few minutes then disconnect and re-connect the product to
the electric system. If this problem happens again or if the product does not start
again, take the product to your service dealer.
!
NOTE : All corrective actions should be carried out by suitably qualified person/s.
www.hyundaipowerproducts.co.uk
31
Technical Data
Specification
Model HY145HPW-1
Maximum Pump Pressure 145bar / 2103psi
Motor Output 2.3kW - 230V
Fuel Tank Capacity 2L
Fuel Consumption 1.5L/hr
Net Weight 26.9kg
Wheel Dimension 246mm
High Pressure Hose Length 10M
Maximum Water Outlet Temperature 80
0
C (Degrees Celsius)
Water Flow Rate 450 L/hr
www.hyundaipowerproducts.co.uk
32
Recycling & Disposal
Recycling & Disposal
We do not offer a takeback scheme for the recovery of Waste Electrical Electronic
Equipment (WEEE) & Batteries. Instead the responsibility to dispose of WEEE and/or
Batteries is passed onto you by us.
So when it becomes necessary to dispose of your machine you must take it to your
local Civic Amenity Site. For further information please contact your local Authority
for disposal advice.
You MUST make sure that all unused oil and fuel is disposed of correctly either
beforehand or at your local Civic Amenity Site.
• Under NO circumstances must any fuel or oil be put down any drains.
• Certain products contain WEEE waste which should not be disposed of in your
domestic waste.
• You MUST recycle WEEE in accordance with your local authority or recycling
centre.
• Certain products contain batteries which should not be disposed of in your
domestic waste.
• You MUST recycle batteries in accordance with your local authority or recycling
centre.
• Unwanted packaging and materials should be stored and taken to a recycling
centre so it can be disposed of in a manner which is compatible with the
environment.
We are a Member of the VALPAK National Compliance Scheme and our
registration number is RM08660. For further information about disposal please
contact your Local Authority.
You can also get more advice and guidance about recycling at the following
website http://www.recycle-more.co.uk
Should you pass this product on to another user either sold or loaned, you MUST
pass on this user manual. This will make sure that all other users can use and
maintain this machine safely.
1. Environmental protection should be a priority of considerable importance when
using the machine, for the benefit of both social coexistence and the environment
in which we live. Try not to cause any disturbance to the surrounding area.
2. You must comply with local regulations and provisions for the disposal of
packaging, oils, fuel, filters, damaged parts or any elements which have a strong
impact on the environment. This waste must not be disposed of as normal waste. It
needs to be separated and taken to specified waste disposal centres where the
material will be recycled.
3. You must comply with local regulations for the disposal of waste materials after
mowing.
4. When disposing, do not pollute the environment with the machine, but hand it
over to a disposal centre, in accordance with the local laws in force.
Environmental Protection
www.hyundaipowerproducts.co.uk
33
EU Declaration Of Conformity
Importer and Authorised Representative
Genpower Ltd
Isaac Way, Pembroke Dock, SA72 4RW
Country of Origin: Italy
Description: 2.3kW Diesel Hot Pressure Washer
SKU Code: HY145HPW-1
Date of Issue: 06/12/2021
Regulations and Directives of Compliance
• 2006/42/EC The Machine Directive
• 2014/30/EU EMC Directive
• 2000/14/EC Noise Emissions
• 2011/65/EU RoHS
Statement of Declaration
We the importer and authorised representative of the product described confirm
conformity within the provisions of applicable regulations and directives listed
within this document.
Signed on Behalf of Genpower Ltd
Place of Issue: Genpower Ltd
Signatory Name: Roland Llewellin
Position: Managing Director
……………………………………
www.hyundaipowerproducts.co.uk
34
Useful Information
Check Out Our YouTube Channel
Our videos on YouTube include:
• Unboxing
• Assembly of your machine
• How to service your machine
• Products in use
• ‘How To’ videos
• Product features
Go to YouTube and search ‘Hyundai Power Products’.
Manual Updates
Our manuals are constantly being reviewed and updated. Should you find an
error, omission or something unclear, please contact us for assistance. We reserve
the right to make any modifications without prior notice whenever necessary.
Our latest manuals are also placed online. All our manuals can be downloaded at:
www.hyundaipowerproducts.co.uk
Returning Your Product
If you are returning your product, please contact the dealer for their returns policy.
Leaving A Review
We work very hard to give all of our customers the best possible service. If you have
any problems, before leaving negative feedback, please contact us to give us a
chance to resolve the issue. We would be delighted if you left us positive
feedback! To leave a review, please go to:
uk.trustpilot.com/review/hyundaipowerequipment.co.uk
Ordering Spare Parts
You can find the spare part you are looking for at power-spares.co.uk
Warranty
Proof of purchase will be required before you make a warranty claim. Full warranty
terms and conditions can be found on the HYUNDAI POWER PRODUCTS website:
www.hyundaipowerproducts.co.uk
www.hyundaipowerproducts.co.uk
35
Product Record
Information
As soon as you have purchased the machine, we recommend that you fill out the
following. If you need to contact an authorised dealer or customer service for
information on servicing, you may need to provide the following information.
Date Of Purchase:……………………………………………………………………………….....
Dealer Name:………………………………………………………………………………………..
Dealer Phone:…………………………………………………………………………………….....
Model Number:…………………………………………………………………………………......
Serial/Batch Number:………………………………………………………..………………........
www.hyundaipowerproducts.co.uk
36
Contact Us
Need Help? Talk To Our Experts
Our friendly aftersales team will be more than happy to help you.
Phone
Call our team on 01646 687 880
Email
Online Live Chat
Go to www.hyundaipowerproducts.co.uk
Post
Genpower Ltd, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW.
Hyundai Support Website
Go to hyundaisupport.co.uk
Importer:
GENPOWER LTD
Isaac Way, London Road,
Pembroke Dock, UK, SA72 4RW.
T: +44 (0) 1646 687 880
www.hyundaipowerproducts.co.uk
Imported / Distributed by Genpower Ltd for the United Kingdom & Ireland
Licensed by Hyundai Corporation, Korea
