Installation Instructions for
TA-44 Pan Rack Slides
and
TA-45 Glass Rack Slides
CHECK FOR CONCEALED DAMAGE
FILE CLAIM WITH DELIVERING FREIGHT CARRIER
Pan Racks manufactured by ADVANCE TABCO
®
are designed and constructed for the use of product
storage and the like. ADVANCE TABCO
®
does not recommend product use for activities employing harsh
and active chemicals. Please consult factory regarding unusual applications.
Edgewood, New York 11717-8380
6-2007
TA-44
Pan Rack Slides
TA-45
Glass Rack Slides
• (2) Ladder Assemblies
• (2) Bottom Connecting Tubes and Fasteners
• Mounting Hardware
• 3/8" Open End Wrench
Step 1:
Insert bottom Connecting Tubes to one ladder Assembly and secure with
provided Hardware (Figure 1).
Step 2:
Repeat Step 1 for opposing Ladder Assembly.
Step 3:
Align top angle of the Ladder Assembly to the INSIDE of the Mounting
Angles on Table Top and secure with provided Fasteners (
Figure 2).
INSTALLATION INSTRUCTIONS
(Continued)
INSTALLATION INSTRUCTIONS
CONTENTS INCLUDE:
TOOLS REQUIRED:
Figure 2
Figure 1
