User’s Guide and Operator Instructions
CBS-2241 & CBS-2242 Next Generation Brewing System
FETCO Next Generation-NG® Commercial Beverage Equipment
CBS-2241 CBS-2242
(Dispensers not included) (Plastic brew baskets are standard, brewers avalible with optional stainless steel brew baskets)
CONTACT INFORMATION
FETCO® FOOD EQUIPMENT TECHNOLOGIES COMPANY
600 ROSE ROAD
LAKE ZURICH • IL • 60047-0429 • USA
Product made in USA
INTERNET: www.fetco.com
PATENTS:https://www.fetco.com/pl,pages,patents,74.html
©2020-2024 FOOD EQUIPMENT TECHNOLOGIES COMPANY
PHONE: (800) 338-2699 (US & CANADA)
(847) 719-3000 (All Countries and International)
FAX:(847) 719-3001
EMAIL:sales@fetco.com
orders@fetco.com (to order parts and equipment)
techsupp[email protected]om (all service queries)
P216 January 2024
COFFEE BREWER CBS-2240NG Series
fetco.com
Go to fetco.com for the latest versions of all information Page 2 P216 January 2024
Specifications and Requirements
FETCO CBS-2240 Brewers have unique construction only available for these models.
Water Requirements:
Coffee Filter Size:
CBS-2240 20-75 psig, (138-517kPa) 1½ gpm/(5.7 lpm)
13” X 5 or FETCO# F002”
Optimal water hardness between 125-250 TDS (6-13 grain)
Important! Please use a water filter for all beverage equipment
Temperature, as set by factory:
200°F (93°C) inside water tank (at sea level)
Water inlet fitting: 3/8 inch male flare.
Brewer supplied with inlet valve adaptor for BSP to SAE
Electrical: See electrical configuration chart Pg 3.
Brew Volume: Full Batch
3.8 L/1.0 gal brew
Brew Capacity
(approximate)
CBS-2241 4-10 brews per hour
CBS-2242 11-16 brews per hour
Output is controlled by heater power and water temperature
Total Brew Cycle: Factory setting: 6 minutes consisting of 4 min. brew time and 2.0 min. drip delay
Individual menu brew-process parameters are user controllable for:
Basic user controls for brew volume, brew time, units of measure, recipe name
Advanced user controls for pulse count, prewet percent and prewet delay, drip delay, programmable energy saving
See pages 4-5 for how to adjust controls for temperature, brew volume, units - and all other settings
Weights and Capacities
Model Height Width Depth
Water tank
capacity
Empty
Weight
Filled
Weight
Shipping
Weight
Shipping Dimensions
CBS-2241
Brewer
34 1/2 in
880 mm
11 3/4 in
300 mm
20 3/8 in
520 mm
4.5 gallon
17 L
29 lbs
13.2 kg
55 lbs
25.0 kg
41 lbs
18.6 kg
35” x 17” x 22”
88.9 x 43.2 x 55.9 cm
CBS-2242
Brewer
34 1/2 in
880 mm
19 ¾ in
500 mm
20 3/8 in
520 mm
8.5 gallon
32 L
47 lbs
21.3 kg
92 lbs
41.7 kg
58 lbs
26.. kg
35” x 23” x 25”
88.9 x 58.4 x 63.5 cm
Calibrated for 1.0 gal brew/3.75 L Brew Basket 13” X 5” Coffee Filter 13” X 5 or FETCO# F002
Rough-In Drawings
CBS-2231 Front CBS-2232 Front CBS-2231 1 & CBS-2232 Side Power cord plug
SKU NUMBER IDENTIFICATION KEY EXAMPLE: SKU E2241US-1X117-PM001
Product Line
Level Family Region ID Phase Voltage Range
# Heaters
Individual Heater
Wattage
Brew
Basket
Hot Water
Faucet
Bypass
Brew Basket
Locks
Power Cord
E
2
2
4
1
U
S
1
A
1
1
5
P
M
0
0
1
E=extractor
US =United
States
1 A = 100-120 1 1.5 P=plastic M=manual 1=Yes 1=Yes 0=Terminal Block
12=PLUS
Series
41=
single side
IN =
International
2 B = 200-240 2 1.7 M=metal A=automatic 0=No 0=No 1= NEMA 5-15P
22=Next
Generation
42=
dual side
CE = IEC 3 C = 380-415 3 2.3
C=metal
with clips
N=None
2=NEMA 5-20P
NM = NOM
U = 1 or 3
D = 440-480
6
3.0
3=NEMA 6-15P
4.0
4=NEMA 6-30P
X=120 or 240
Dual Voltage
5.0
5=CEE 7/7
Schuko
6=UK1-13P
7= AUSTRALIAN
AS3112 (YP-35)
G
NEMA 5-15P; 120 V
Plug Configuration
G
NEMA 5-20P; 120 V
Plug Configuration
1
NEMA 6-15P; 240 V
Plug Configuration
Domestic Plug
Configuration
Go to fetco.com for the latest versions of all information Page 3 P216 January 2024
Electrical and Output Specifications
Customer options
e.g. E2241US-1X117-P
1
A
2
0
3
1
4
1
BREW BASKET TYPE
(P, M )
HOT WATER FAUCET
(M, A OR N)
BYPASS
(1 OR 0)
Brew Basket Lock
(1 OR 0)
Factory standard features
Add all the following numbers
after all SKU numbers
1
P=Plastic
(most versions)
M=Gourmet Metal
2
A=Automatic electronic
M=Standard manual
N=No hot water faucet
3
0=None
1=With
4
1=With
0=None
CBS-2241Next Gen Single 3.0-4.0 Liter Coffee Brewers Field configurable Domestic
Electrical and Output Specifications Brewer has factory installed cord and plug & terminal block 50Hz or 60Hz
SKU
Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase
Amp Draw
Brew-Volume
per hour
E2241US-1X117-PA011
120
1 X 1.7 kW
2+G
1.7
NEMA 15-5P
1
14.7
3.9 gal/14.8 L
Domestic-Dual Voltage
208-240
2 X 1.7 kW
3+G
2.6-3.4
Terminal Block
1
12.8-14.7
5.8 gal/22 L
Electrical Specifications, Domestic Single brewer-single voltage 120 volt cord and plug single phase 50Hz or 60Hz
CBS-2241Next Gen Single 3.0-4.0 Liter Coffee Brewers Domestic models
Electrical and Output Specifications All brewers have factory installed cord and plug 50Hz or 60Hz
SKU
Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase
Amp Draw
Brew-Volume
per hour
E2241US-1A115-PA011
120
1 X 1.5 kW
2+G
1.5
NEMA 15-5P
1
13.0
4.0 gal/15.1 L
E2241US-1A115-PA011
120
1 X 2.3 kW
2+G
2.3
NEMA 5-20P
1
19.7
5.8 gal/22 L
E2241US-1A123-PM112
120
1 X 2.3 kW
2+G
2.3
NEMA 5-20P
1
19.7
5.8 gal/22 L
CBS-2241Next Gen Single 3.0-4.0 Liter Coffee Brewers Field configurable NOM (Mexico) In Spanish
Electrical and Output Specifications Brewer has factory installed cord and plug & terminal block 50Hz or 60Hz
SKU
Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase
Amp Draw
Brew-Volume
per hour
E2241NM-1X123-PA012
120
1 X 2.3 kW
2+G
2.3
NEMA 5-20P
1
19.7
6.1 gal/23.2 L
Dual Voltage
208-240
2 X 2.3 kW
3+G
4.6
Terminal Block
1
17.1-19.7
7.6 gal/30 L
NM in SKU suffix (above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide
CBS-2241Next Gen Single 3.0-4.0 Liter Coffee Brewers International models
Electrical and Output Specifications All brewers have terminal block electrical utility connection 50Hz or 60Hz
SKU
Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2241NM-1B140-PA010
208-240
1 X 4.0 kW 2+G 2.8-4.0
Terminal Block
1 14.9-17.2 10.0 gal/37.9 L
NM in SKU suffix
(above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide
E2241IN-1B140-PA010
208-240
1 X 4.0 kW
2+G
2.8-4.0
Terminal Block
1
14.9-17.2
10.0 gal/37.9 L
E2241IN-1B123-PA010
200-240
1 X 2.3 kW 2+G 1.6-2.3
Terminal Block
1 8.5-10.1 5.8 gal/22 L
E2241IN-1B130-PA010
200-240
1 X 3.0 kW
2+G
2.1-3.0
Terminal Block
1
10.9-13.0
7.7 gal/29.1 L
CBS-2241Next Ge n 3.0-4.0 Lit er Cof fee Br ew ers C E mo dels
Elect ric al an d O utp ut Spe cifi cat ion s Sch uko cor d an d pl ug 50Hz
SKU Voltag e Heater Configuration Wir es KW Elec tric al C onn ecti on Ph ase Amp Dr aw
Brew
-Vol ume per ho ur
E223 1CE-1B123-PA0 15
230
1 X 2.3 kW
L/N/ PE
2.1
CEE 7/7 Shuko
1
9.7
5.8 g al/ 22 L
E223 1CE-1B130-PA0 15 230 1 X 3.0 kW L/N/PE 2.8 CEE 7/7Shuk o 1 12.5
7.7 g al/ 29. 1 L
CBS-2242Next Gen Dual 3.0-4.0 Liter Coffee Brewers Domestic models
Electrical and Output Specifications All brewers have terminal block electrical utility connection 50Hz or 60Hz
SKU Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase
Amp Draw
Brew-Volume
per hour
E2242US-1B223-PA010
208-240
2 X 2.3 kW
2+G
3.5-4.6
Terminal Block
1
17.1-19.7
11.0 gal/42.0 L
E2242US-1B230-PA010
208-240
2 X 3.0 kW
2+G
4.5-6.0
Terminal Block
1
22.2-25.5
14.3 gal/54 L
E2242US-1B230-MA110
208-240
2 X 3.0 kW
2+G
4.5-6.0
Terminal Block
1
22.2-25.5
14.3 gal/54 L
CBS-2242Next Gen Dual 3.0-4.0 Liter Coffee Brewers International models
Electrical and Output Specifications All brewers have terminal block electrical utility connection 50Hz or 60Hz
SKU Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2242IN-1B223-PA010
200-240
2 X 2.3 kW
2+G
3.2-4.6
Terminal Block
1
16.5-19.7
12.2 gal/46.3L
E2242IN-1B230-PA010
200-240
2 X 3.0 kW
2+G
4.2-6.0
Terminal Block
1
21.3-25.5
15.8 gal/60 L
E2242NM-1B230-PA010
208-240
2 X 3.0 kW
2+G
4.5-6.0
Terminal Block
1
22.2-25.5
15.8 gal/60 L
NM in SKU suffix (above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide
CBS-2242PLU S Du al 3. 0-4.0 Lite r Co ffe e B rew ers C E mod els
Elect rical an d Outp ut Spe cific ation s Al l br ewers h ave t erm in al bl oc k el ectri cal uti lity co nnec tion 50Hz
SKU
Voltag e
Heater Configuration
Wir es
KW
Elec tric al C onn ecti on
Phas e
Amp Dr aw
Brew-V olum e per ho ur
E223 2CE-1B223-PA0 10
230
2 X 2.3 kW
L/N/ PE
4.2
Term inal Bl ock
1
18.9
11.0 gal/42.0 L
E223 2CE-1B230-PA0 10
230
2 X 3.0 kW
L/N/ PE
5.5
Term inal Bl ock
1
25.5
14.9 gal/56 L
E223 2CE-2B223-PA0 10
230/ 400
2 X 2.3 kW
2L/N/PE
4.2
Term inal Bl ock
2
9.7
11.0 gal/42.0 L
E223 2CE-2B230-PA0 10
230/ 400
2 X 3.0 kW
2L/N/PE
5.5
Term inal Bl ock
2
12.5
14.9 gal/56 L
Go to fetco.com for the latest versions of all information Page 4 P216 January 2024
Layout of the brewer
Operation and service
Operation
.
Service
Layout for installing brewer (back side)
Brew basket sensor (internal)
LED Status indicator bar
Touch-screen
(for brewer operation)
Brew basket
Hot Water Service Faucet
(not on all models)
Air pot or Dispenser Locator
(not on all models)
Main power switch
Fast Start Brewing
Starting The Brew
1. Turn the power switch “ON”. (Twin Shown)
2. Prepare a brew basket with the correct size filter and appropriate
amount of coffee. (4-8 ounces or 113-227 grams for 1 gal/3.8 liters)
3. Slide the brew basket completely into the rails.
4. Place a clean, empty, preheated dispenser under the brew basket.
5. Select a batch & touch the corresponding BREW icon
(Batch #1 selected in illustration), then press “START”
6. -STOP icon will illuminate,
-Countdown time will display, with proportional graphic circle icon
-LED indicator will pulse.
-All other BREW icons for that brew head will be hidden.
….-Opposite side BREW icons on dual brewer remain active
7. When the brew cycle is finished,
-Spray icon will extinguish and the BREW circular icon will remain.
This indicates that coffee may still be dripping from the brew basket
For safety- do not remove brew basket until drip-out is complete.
Twin Brewer ready to brew.
Batch one-top left brew position selected
Brewing in process
Batch one selected
Programming
To enter programming
1.
Turn the power switch
“OFF”, then “ON”:
Bootup will begin
.
Touch the
cen of the
screen
(shown on
right
)
2.
(shown right)
Operator password
is 1,2,3,4: Note: For
general use
Service password is
9,8,7,6 Note:
Do not
distribute this number
3.
Make changes and
adjustments from
the
Programming
Menu screen
(Shown right)
See progamming
menu layout next
page
Bootup screen
Password Screen
Programming access
Batch 1
1.5 gal
6:00
6:00
12:35pm 04
.14.2020 87°C/93°C
Batch 5
1.5 gal
6:00
Batch 6
1.5 gal
6:00
Batch 7
1.5 gal
6:00
Batch 8
1.5 gal
6:00
ST
OP
HOT WATER
Enter Password
_ _ _ _
CANCEL
MAIN
Brew
Recipes
Hot Water
Portions
Settings
Calibration
Outputs
Inputs
Counters
Service
EXIT
CBS-2252
UI ver: 0.0.02t2020-0616a
UI Date: Jun 16 2020 09:12:53
IO ver: 0.0.0.2t2020-
0610
IO Date: June 10 2020 10:26:27
Soft . Ver. 09:12:53
Bootloader ver. 0.23
Hardware ver. 1.0
1
©
2019 Food Equ ipment Technologies Company
Go to fetco.com for the latest versions of all information Page 5 P216 January 2024
Programming Menu
Layout
Brew Recipes
Settings
Inputs
Service
Hot Water Portions
Calibrations
Outputs
Counters
|
|
|
|
|
|
|
Batch On/Off & Name
Temperature
Brew Basket
Select Model
Continuous
Flow Rates
Brew Valve(s)
Counters
(permanent)
|
|||
|||
|
|
|||
|
|||
BREW TIME
(Tank Temperature)
(Sensor)
Enable Options
Volume 1.
(Water Valves)
Fill Valve
Lifetime Counters
|
|||
|||
|
|
|||
|
|||
Prewet
(Brew at Temp.)
(Lock Sensor)
Overrides
Volume 2
((Brew left))
Heater SSR
Service Counters
|||
|||
|
|
|
|||
|
|||
(Prewet Percent)
(Show tank temp?)
Liquid Level
Backup or Restore
Volume 3
((Brew right))
Light Bar
Hot Water Counters
|||
|||
|
|
|||
|
|||
(Prewet Delay)
(Show setpoint temp?)
Temp Sensor
HW/SW/BL Version
((Bypass left))
Bypass Valve(s)
Brew Counters
|
|
|
|
|||
|
|||
Bypass Percent
Units Of Measure
Peripherals
Restore Defaults
((Bypass right))
Faucet Valve
Data Counters
|
|||
|
|||
|
|
Drip Delay
(Temperature)
Error Codes
(Faucet Valve)
Brew Basket Lock
Water Filter
|
|||
|
|||
|
|
Volume
(Volume)
Reset Passcodes
(Fill Compensation)
Extra Outputs
Statistics
|
|||
|
|||
|||
Number of Pulses
(Faucet)
Languages
((Off))
Brew Statistics
|
|
|||
|||
Bypass
ECO Mode
((1.5x))
Energy Statistics
|
|
|||
|||
Copy Batch
Water Filter (life)
((2.0x))
Hot Water Statistics
||
|
|
|
Copy Batch: From
Demo Mode
LLC Sensitivity
Counters (resettable)
||
|
|
|||
Copy Batch: To
Hot Water (faucet)
((Normal))
Lifetime Counters
|
|
|||
Status Light
((High))
Service Counters
|
For electronic faucet
Activates for service
|||
Screen Saver
Hot Water Counters
|
|||
Date and Time
Brew Counters
|||
Data Counters
TO ACCESS PROGRAMMING
Turn brewer OFF then ON
When the bootup screen
appears touch the FETCO
logo
Touch the FETCO logo when
the password screen appears
Touch Brew Recipes for
setting the brew
er parameters
for each menu item
Batch 1 will be selected
Touch Batch 1 to set the brew
parameters.
Prewet will be selected
Touch Prewet icon to adjust
prewet
The chart below describes the
icons shown on this screen
Touch and slide to desired
setting. Touch BACK when
complete and make further
adjustments or press BACK
and SAVE & EXIT.
Brew Recipes
Program Items
Factory set Default
Programming Range
Notes
Batch Name
Batch On/Off
All “ON”
On/Off
Only top batch(s) are always enabled
Batch Name
Customize Name
Batch (1-4 L) (5-8 R)
Complete keypad
Scroll and tap three virtual keypads
Brew Time
Time of brew
4:00 minutes
2:00-12:00 mins/secs
Add to prewetting and drip delay times
Prewet Prewet percentage
0 0-25% brew volume
Initial wetting to stabilize very fresh
coffee
Prewet
Prewet delay time
1:00 sec.
0:10 sec to 5:00 min
Pause after coffee bed is prewetted
Drip Delay Pause after brew 2:00 min:sec. 00.30 to 6:00
Time that brew basket remains locked
during drip-out. This is a safety
feature.
Brew Volume
Total volume
1 gallon/3.8 liters
0.5-1.25 gal./0.95-4.75 liters
Factory set for 1 gallon dispenser
Number of Pulses Start/stop in brew 8 4-20
Algorithm evenly divides brew time
cycle
Bypass Percentage
Diverts brew water
0
0-40% of brew volume
Affects flavor, strength and mouth-feel
Copy & Paste Menu
Current recipe
Paste into all other recipes
Will paste selected into the other
CBS-2252
UI ver: 0.0.02t2020-0616a
UI Date: Jun 16 2020 09:12:53
IO ver: 0.0.0.2t202
0-0610
IO Date: June 10 2020 10:26:27
Soft . Ver. 09:12
:53
Bootloader v er.
0.23
Hardwar e ver. 1
.01
©
2019 Food Equipm ent Techno lo gi es Company
Enter Password
_ _ _ _
CANCEL
MAIN
Brew
Recipes
Hot Water
Portions
Settings
Calibration
Outputs
Inputs
Counters
Service
EXIT
Main>Recipies
Batch L1
BATCH 1
1.5 gal/6:00
Batch R1
BATCH 5
1.5 gal/6:00
Batch L2
BATCH 2
1.5 gal/6:00
Batch R2
BATCH 5
1.5 gal/6:00
Batch R3
BATCH 6
1.5 gal/6:00
Batch L3
BATCH 3
1.5 gal/6:00
Batch R4
BATCH 8
1.5 gal/6:00
Batch L4
BATCH 4
1.5 gal/6:00
BACK
Main>Recipes>L1
Batch Name
Batch 1
ON
Volume
1.50 gal
Brew Time
4:00 min
Number of Pulses
4
Bypass
0%
Prewet
0%
0:30 min
Copy Batch
And
Paste To
Drip Delay
1:30 min
BACK
Main>Recip es>L 1>Prewet
Prewet Percen tag e 0
0 % 25
----------------- ---- ---- ---------
Prewet Delay 0:30
0:10 mm;ss 5:00
------------------------------
BACK
Go to fetco.com for the latest versions of all information Page 6 P216 January 2024
Settings
Program Items
Factory set
Default
Programming Range Notes
Temperature
Tank Temperature
200°F/92°C
170-208°F/77-98°C
Hot water tank, brewing water temp.
Temperature
Brew at Temperature*
ON
OFF/ON
See note below
Temperature
Show Tank Temp.
ON
OFF/ON
Shows 1
st
at top right screen
Temperature
Show Setpoint Temp.
ON
OFF/ON
Shows 2
nd
at top right screen
Units of Measure
Temperature
Volume
Hot water Faucet
F° - Fahrenheit
Gal-Gallons
ml - Milliliters
NO or YES
Main>Settings>UNITS
Temperature °F °C °
Volume gal L
Faucet
oz ml
ECO Mode
ON/OFF
Eco idle time (to start)
Eco Tank temperature
OFF (default)
(if activated)
1 hour 169°F
Turn on or off
1-6 hours
158°F to 176°F
Screen will display Eco Mode when
activated-will take time to reheat to
set brew water temperature
Water Filter
Water filer installed
Rated filtering volume
NO
2625 gallons
NO or YES
250 gallons to 3950 gallons
Demo Mode
Brewer ON Disables
valves & heaters
OFF OFF/ON For training and user familiarization
Hot Water
Digital H. Wtr Faucet
Auto
ON/OFF/Automatic
Automatic activates portion control
Status Light
READY LED color
White
White/Blue/Green
Color when brewer is ready to brew
Screen Saver
Covers recipe screen
OFF
ON/OFF & Timeout setting
“OFF” leaves recipe screen
Date and Time
Set unit date and time
12 hour format
12/24 hour format & date
Store in real time clock
NOTES: Brew at Temperature*
Brew At Temp: “ON”
(Default: factory programmed into brewer)
“BREW START” will not be accessible until tank temperature is at set point.
“BREW START” becomes accessible when hot water tank is at the selected temperature.
Menu screen will be dimmed if tank temperature is low
Brew At Temp: “OFF” USER SELECTABLE (Not recommended)
Allows brewing at any temperature above 170°F/77°C.
May not apply for two sided brewer if one side is in brew cycle
Altitude Correction Chart
Chart to correct for altitude for boiling point
in tank water temperature.
[ft] [m]
Suggested
Setting[°F]
Boiling
point[°F]
Suggested
Setting[°C]
Boiling
point [°C]
0
0
205
212.0
96
100.0
500
152
205
211.0
96
99.5
1000
305
200
210.1
93
98.9
2000
610
200
208.1
93
97.8
2500
762
200
207.2
93
97.3
3000
914
200
206.2
93
96.8
3500
1067
197
205.3
92
96.3
4000
1219
195
204.3
91
95.7
4500
1372
194
203.4
90
95.2
5000
1524
194
202.4
90
94.7
5500
1676
193
201.5
89
94.2
6000
1829
192
200.6
89
93.6
6500
1981
191
199.6
88
93.1
7000
2134
190
198.7
87
92.6
7500
2286
188
197.8
86
92.1
8000
2438
187
196.9
86
91.6
8500
2591
185
196.0
85
91.1
Brew at Temperature
Ideal brew water temperature is 200°F/93°C. After brewing, brewers can take time to
recover the hot water tank temperature and signal READY to brew. This is called
“recovery time”. The lag in recovery time is caused by rapid brewing cycles in a rush, low
power heating elements, low incoming electrical voltage, water supply temperature, even
the barometric pressure.
Operators will adjust the “Brew At” temperature to allow the brewing at lower
temperatures. This will allow a slightly faster recovery time and give a small increase in
brew cycles per hour.
Reduced brew temperature will always compromise the quality of the finished brew and
lower the temperature of the customers coffee.
Faster Brew Cycle/reduced extraction lower temperature Correct flavor/proper extraction temperature
Faster brew cycle with reduced temperature Correct brew water temperature
Compromised Extraction Proper Extraction
170°F/77°C 180°F/82°C 190°F/88°C 200°F/93°C
Go to fetco.com for the latest versions of all information Page 7 P216 January 2024
Inputs
Program Items
Factory set
Default
Programming Range Notes
Brew Basket
Sensor
Displays activity
Brew basket in place?
LEFT RIGHT (green=on;red=off)
Brew Basket
Lock Sensor
Displays activity
Brew basket locked?
LEFT RIGHT (green=on;red=off)
Liquid Level
LOW
Not used
Not used
Not used
Liquid Level
HIGH
Hot water tank fill
Filled/Not Filled & signal
Green=Filled/Red=Not Filled
Temp. Sensors
Sensor 1
Hot water tank temp.
Actual temperature & signal
Temp. Sensors
Sensor 2
Not used
Not used
Not used
Peripherals
USB1
Digital input/output
Displays activity
(green=active;red=off)
Peripherals
USB2
Not used
Not used
Not used
Peripherals
RS-232
Digital input/output
Displays activity
(green=active;red=off)
Service
Program Items
Factory set
Default
Programming Range Notes
Select Model Set brewer model CBS-2242
MODEL
(single side)
1
(dual side)
2
223x
224x
225x
226x
To select: touch icon for brewer, touch
“BACK” and got to EXIT & SAVE
Enable Options
Options
Electric HW faucet OFF ON
Bypass Valve(s) OFF ON
Brew Basket Lock(s) OFF ON
Expansion Board OFF ON
Overrides
Brew Basket Sensor
Brew Basket Lock
Brew Basket Lock Sensor
HW Press and hold
Override Safety Features
Left Right
Brew Basket Sensor OFFON OFFON
Brew Basket Lock OFFON OFFON
Br. Basket Lock SensorOFFON OFFON
HW Press and hold OFFON OFFON
Overriding deactivates onboard safety
systems. This is not recommended for
normal operation. A warning/reminder
will display in the start scren
Backup or Restore
Backup current
configuration
Will save all
programmed settings
Requires USB thumb drive
Insert USB thumb drive and touch
“BACKUP” & follow instructions
Backup or Restore
Installs saved
settings
USB thumb drive
with one file-
One file, must be titled:
backup.txt
Insert USB thumb drive and touch
“RESTORE” & follow instructions
HW/SW/BL Version
Software
UI 0.2.221011a
IO 0.3.20221119a
Bootloader UI
Bootloader IO
Compilation Time
UI Oct 11 2022 13:28:09
IO Nov 29 2022 15:12: 20
Hardware
Main Board rev
IO Board rev
Restore Defaults Return factory sets
Will overwrite all settings Touch and hold icon 5 seconds
Error Codes
Error Log
Error Code
Code & definition Date/time stamp
Export Log To USB
Follow prompts to export
Error Statistics
Error code frequency
Error Statistics
Follow prompts to delete
Reset Passcodes Overrides default
Operator Code
Follow prompts to change
Service Code
Follow prompts to change
Languages
Reserved for future use
Go to fetco.com for the latest versions of all information Page 8 P216 January 2024
Error Codes
(From SERVICE – Page7)
DO NOT CLEAR ERROR CODES UNTIL ERROR IS IDENTIFIED AND CORRECTED
Contact factory or specialized personnel for error codes
Code Description Possible Cause Corrective Action
001
Software error-error on start up or
corrupted software
Improper start-up or
shutdown
Restart, if still fault: reload software
002
Internal flash corrupted
internal data memory malfunction
Error found in cyclic
redundancy check CRC
Restart, if still fault: reload software
If not corrected: replace board
010
Front U/I board loses communication
with the interior O/I board
No communication between
front panel
Cycle brewer Off then On.
Check cable connections
011
Front U/I board bad communication
with the interior O/I board
Disrupted communication
Cable connections loose
Cycle brewer Off then On.
Check cable connections
Error codes 10 and 11 may be generated by loose connections, electronic interference, or a software/bootloader issue.
For assistance by email: open the SERVICE menu and go to the HW/SW/BL Version. Send a cellphone picture of this
screen to techsupp[email protected]om with the serial number of the equipment and your return phone number.
For live service, write down the screen information or have the HW/SW/BL Version available and contact FETCO by
phone at (800) 338-2699 option 2) to discuss with Technical Service. (Email support is usually faster)
The correction for ERROR 10 or 11 may require a simple Off/On power cycle or a bootloader/firmware update that can
be sent by email. Contact FETCO as above if cycling power or connections do not correct the fault.
050
Short-circuit in temperature probe
Probe failure.
Replace probe.
051 Open temperature probe.
Bad probe connection, or
probe failure.
Check all connections. Replace probe if
necessary.
100
Initial Fill Error.
Initial fill time took longer than
expected after powering up.
Water supply flow rate is
too low, fill valve is stuck,
water line kinked or closed.
Reboot machine. If persists-investigate
cause of low flow rate. (Clogged water
filter, kinked line, stuck fill valve)
101
Error on refill-.
Tank did not refill within expected time.
Water supply flow rate to
hot water tank is too low, or
fill valve stuck or damaged
(SEE PAGE 13)
Check water supply line. Flow should be
20-75 psig, (138-517kPa) >1gal/3.8L/min
Investigate cause of low flow rate. If the
flow rate is in range-replace fill valve
200 Heating flatline-Tank is boiling
Heater is on, temperature is
not rising/dropping
High elevation correction. Bad heaters
or temperature probe or position
201
If the hot water tank heaters are turned
on during a heating cycle and tank
temperature is not increasing
according to software logic and the
tank temperature is below setpoint
1) Failure of SSR, high limit,
temperature probe, or
heating element.
2) Water being removed by
hot water faucet during
heating (control displays
“heating”)
1)Test and check SSRs, high limit
devices temperature probe. Check
heating elements with current clamp,
replace if necessary.
2)Advise staff to refrain from taking large
amounts of water from hot water tank,
especially during “heating”.
202 Heater Shorted or Stuck SSR
Heater is off and heating
SSR is stuck “ON”
Check ohms on heater (15-60Ω). SSR
may be stuck in ON mode-replace SSR.
255
Keyboard [HID] error
(Human Interface Device)
Usually from longer than 10
seconds’ contact. Or faulty
reassembly after service
Restart, if still fault: reload software. If
mechanical: replace module
NO
BSKT
Insert Brew Basket
Brew basket must be in
place
This is a
SAFETY FEATURE
Insert brew basket into brewer rails to
enable brewer
Go to fetco.com for the latest versions of all information Page 9 P216 January 2024
Hot Water Portions
Program
Items
Factory set
Default
Programming Range Notes
This setting is only for brewers with an electronic hot water faucet. In the SETTINGS menu, the “Automatic” feature must be enabled
Hot Water Portions
Enabled
“ON”
OFF/ON
Hot Water Portions
Name
Continuous
Rename on keypad
Scroll and tap three virtual keypads
Safety
Timeout
0:25
0:10 min 0:60
------------------
Scroll and go to EXIT&SAVE
Sets limit for touch and dispense
Hot Water Portions
Volume 1
6 oz.
Enabled
ON
Turns “ON” or “OFF”
OFF/ON
Name
Volume 1
Rename on keypad
Scroll and tap three virtual keypads
Volume
dispensed
6 oz
Volume 6
2 oz 30
------------------
Scroll and go to EXIT&SAVE
Sets limit for #1 touch and dispense
Hot Water Portions
Volume 2
8 oz
Enabled
ON
Turns “ON” or “OFF”
OFF/ON
Name
Volume 2
Rename on keypad
Scroll and tap three virtual keypads
Volume
dispensed
8 oz
Volume 8
2 oz 30
----------------
Scroll and go to EXIT&SAVE
Sets limit for #2 touch and dispense
Hot Water Portions
Volume 3
8 oz
Enabled
ON
Turns “ON” or “OFF”
OFF/ON
Name
Volume 3
Rename on keypad
Scroll and tap three virtual keypads
Volume
dispensed
12 oz
Volume 12
2 oz 30
-----------
Scroll and go to EXIT&SAVE
Sets limit for #3 touch and dispense
Go to fetco.com for the latest versions of all information Page 10 P216 January 2024
Calibration
Program Items
Factory set
Default
Programming Range Notes
Flow Rates
Water Valves
Brew left 0.50gal/min
Brew Left 0.50
(gal)
0.40 gal/min 0.58
--------------
Use to attenuate and compensate for
variations in brew valve output
Flow Rates
Water Valves
Brew right 0.50gal/min
Brew Right 0.50
(gal)
0.40 gal/min 0.58
--------------
Use to attenuate and compensate for
variations in brew valve output
Flow Rates
Water Valves
Bypass left 0.36gal/min
Bypass left 0.36
(gal)
0.29 gal/min 0.43
--------------
Use to attenuate and compensate for
variations in bypass valve output
Flow Rates
Water Valves
Bypass right 0.36gal/min
Bypass right 0.36
(gal)
0.29 gal/min 0.43
--------------
Use to attenuate and compensate for
variations in bypass valve output
Flow Rates
Faucet Valve
For automatic hot
water faucet
1500 ml/min
Faucet 1500
500 ml/min 5000
----------------
To compensate variations in timed
dispense from automatic hot water
faucet
Fill Compensation
Slow Flow
Compensation
OFF
Off
o .. 1.5x
o 2.5x
Use for FloJet bottled water supply or
for reduced water supply from mains.
Display
Display %
Contrast 70
10 ------------ 100
Brightness % 70
20 ------------
100
LLC
NORMAL
Normal
o .. High
Liquid level control sensitivity.
Normal for most water.
High is for reverse osmosis water or
very pure water.
How to calibrate the flow rate
Set the flow rates of the brewer valves to adjust for over or under potting.
Built-in algorithms in brewer controller software corrects brew parameter to customer preferences or to trim variations in flow control components
The control software uses the new flow rate entered in the CALIBRATION screen to adjust and correct the amount of water delivered by the valve
Increasing the flow rate value DECREASES the volume of brew water dispensed
Decreasing the flow rate value INCREASES the volume of brew water dispensed
Flow rate adjustment will control all batches made by the valve. All batches on the side of the valve will be adjusted, (left or right)
-Obtain the VOLUME DISPENSED of water only, by brewing a batch without coffee or filter paper.
-Obtain the PROGAMMED VALUE of the same brew. This is displayed on the home screen in the batch box
-Obtain the CURRENT SETTING for the flow rate from the brewer. Do this by entering PROGRAMMING and
Tap to “CALIBRATION” then, tap “Flow Rates” and then “Water Valves”. The valves flow rate is in the top right corner.
Using the values obtained above to obtain the new flow rate setting to correct the volume dispensed:
Divide the volume dispensed by the programmed volume and then multiply by the current setting
VOLUME DISPENSED
PROGRAMMED VALUE
×CURRENT SETTING
=
NEW FLOW RATE SETTING
-Enter programming mode, tap to “CALIBRATION”
-Tap back to “Flow Rates” and then to “Water Valves”
-Enter the new flow rate into the calibration slider for the valve tested
Note: values for brewers set in gallons are in decimal format. Place all quantities in ounces and divide by 128 (One gallon =128 ounces)
to obtain decimal format 3 quarts delivered=96oz, 96oz÷128=0.75 gal.
Example below shows shortpotting of 16oz over 0.08 gal. batch corrected by recalibration using the formula above
Obtain Volume Dispensed
Example:
A CBS
-2242 delivered
3qts or 6oz
over the
0.8 gallon (10
2oz) setting
for Batch
2-Left Side
(96oz÷128=0.75)
The value is 0.75
Obtain Programmed Value
The Programmed value
for batch 2 -left side of
the CBS-2242 is on the
home screen in the
batch box.
The value is 0.8 gallon
Obtain Current Setting
The valves flow rate is in the
top right corner
Brew Left
0.50 (gal)
0.40 gal/min 0.58
--------------
The value is 0.50
Use the formula above
0.75
0.8
× 0.50 = .
The new flow rate is
0.47
Enter the New Flow Rate
Brew Left
0.47 (gal)
0.40 gal/min 0.58
--------------
Enter new setting on the slider
as shown and EXIT to save.
Retesting recommended
By entering the new flow rate number into the brewer, the software automatically corrects the volume discrepancy
Go to fetco.com for the latest versions of all information Page 11 P216 January 2024
Outputs
Program Items
Factory set
Default
Programming Range Notes
These settings are used to activate individual controls for testing verifications and servicing operations
Brew Valve(s)
Momentarily
operate Left or
Right Brew valves
Left Right
Brew
Have dispenser under spray head!
Touch to activate flow
Fill Valve
Momentarily
operate fill valve
Fill
Have dispenser under spray heads!
Touch to activate flow
Heater SSR
Turns on all
heaters
Heater
3 sec max
Activates SSRs to turn on heaters
Light Bar
Momentarily
operate light bar(s)
Status Light
Bypass Valve(s)
Momentarily
operates Left or
Right Bypass
valves
Left Right
Bypass
Have dispenser under bypass port!
Touch to activate flow
Faucet Valve
Momentarily
operate faucet
valve
For brewers with
automatic hot water
faucet
Faucet
Have dispenser under faucet!
Touch to activate flow
Brew Basket Lock
Operates brew
basket locks,
toggling them on
and off
Left Right
BBL lock
Left Right
BBL Unlock
Left Right
BBL Sensor
Will toggle brew basket locks to be
engaged then OFF.
Extra Outputs
For future use
Not used
Not used
Not used
Go to fetco.com for the latest versions of all information Page 12 P216 January 2024
Counters
Program
Items
Factory set
Default
Programming Range Notes
This setting shows usage of the brewers functions
Lifetime Counters
These counters are
permanent and
cannot be deleted.
The quantities
shown are a
permanent record for
the machine,
Service Counters
Main>Counters>Lifetime>Service
Lifetime Counters
(units in hours and liters)
Unit Uptime 0
Fill Valve
Volume 0
Activation 0
Heater
Time On 0
Activation 0
Hot Water
Dispense Count 0
Hot Water Valve
Volume 0
Activation 0
Brewer
Volume 0
Left Right
Brew Count 0 0
Brew Valve
Volume 0 0
Activation 0 0
Bypass Valve
Volume 0 0
Activation 0 0
Locks
Activation 0 0
Hot Water
Counters
Main>Counters>Lifetime>Faucet
Lifetime Counters
(units in liters)
Volume Activation
Continues 0 0
1 0 0
2 0 0
3 0 0
Brew Counters
Main>Counters>Lifetime>Brew
Lifetime Counters
(units in liters)
Recipe Number Volume
Activation
1 0 0
2 0 0
3 0 0
4 0 0
5 0 0
6 0 0
7 0 0
8 0 0
Data Counters
Reserved for future
Water Filter
Water Filer Life Time
Main>Counters>Reset Filter
Water Filter Life Time
Filter
Life Time 0% of 10,000
Press and hold button for 5 seconds
To Reset Filter
Statistics
Brew Statistics
Reserved for future
Energy Statistics
Reserved for future
Hot Water Statistics
Reserved for future
Resettable Counters
These are the same
screens as above in
“lifetime counters”.
These can be reset
Service Counters
See screen above
Main>Counters>Reset>Clear
Clear Resettable Counters
Press and hold button for 5 seconds
To Clear Error Log
Hot Water
Counters
See screen above
Brew Counters
See screen above
Service Counters
See screen above
!
!
Go to fetco.com for the latest versions of all information Page 13 P216 January 2024
Brewer Setup
NOTE-Assemble legs immediately after unpacking the brewer and before connection to utilities
1) Attach legs
4” flange foot legs -
Part number 1073.00007.00
3 required for CBS-2242
4 required for CBS-2241
Legs are sent from factory inside brew basket. Attach legs before installing
Brewer Setup
2) Attach water inlet adapter
Place rubber washer with screen in adapter. Hand tighten only-and 1/4 turn with wrench
Install the adapter on inlet valve first before attaching water line. Adapter is shipped in the brew basket
The valve threads are 3/4" BSP MALE THREAD and are not 3/4 garden hose fittings.
Use of any other connector to valve will damage the valve
DO NOT use US dishwasher water adapter or US washing machine adapter for this connection.
The threads on the USA adapters are unusable for the valve
TO PREVENT DAMAGE AND INSURE PROPER EQUIPMENT OPERATION
The inlet valve thread is 3/4 INCH BSP (British Standard Pipe).
This valve is not a standard USA washing machine or dishwasher thread (¾” GHT)
-Use only the plumbing adaptor kit included with this equipment. Use the gasket included in adaptor kit
-Plumber’s tape is not recommended for the adapter to valve connection
-Hand tighten adapter on valve with gasket, then very lightly wrench 1/4 turn to set
-DO NOT SUBSTITUTE FITTINGS FOR CONNECTING TO WATER SUPPLY
Damage to inlet valve from improper installation will void the warranty
NOTE: DO NOT TANK PLUMB DRAIN. DRAIN IS FOR SERVICE AND MAINTENANCE.
FETCO
Inlet valve
Rubber washer
with screen
(Included with
adapter)
Inlet valve
adapter
90 degree 3/8” flare fitting
This may be removed
and replaced with a 3/8”
compression fitting or
other connection.
Fitting to base is ¼” NPT
Use thread sealing
plumber tape or sealant
paste on threads
3/8”
flare fitting
¼” fnpt base
Go to fetco.com for the latest versions of all information Page 14 P216 January 2024
(For Qualified Service Technicians Only)
General:
1. If not installed correctly by qualified personnel, the brewer will not operate properly, and damage may result.
2. Utilize only qualified beverage equipment service technicians for service and installation.
3. Always have an empty dispenser under spray head of all coffee brewing equipment-including when at idle
4. Damages resulting from improper installation are not covered by the warranty and will void the warranty.
Below are the key points to consider before installation:
Electrical:
1. All CBS_Series brewers require an electrical ground wire. Installation without grounding is dangerous.
2. Note Equipotentiality Terminal, if present,
(To identify the terminals which, when connected together, bring the various parts
of equipment or of a system to the same potential, not necessarily being the earth (ground) potential, e.g. for local bonding.)
3. Verify voltages, polarity, circuits, and circuit breaker access before attaching equipment.
4. Brewers in this series wire differently in regard to a neutral wire. Review the wire diagrams.
5. The electrical diagram is located in the User’s Guide and online at www.fetco.com.
6. Make sure of the tight grounding of the equipment and use the external ground bolt.
7. The installation must comply with applicable federal, state, and local codes having jurisdiction at your location.
Check with your local inspectors to determine what codes will apply.
See wiring diagrams on pages 29-31 for connections
Plumbing:
1. North America: All installations must comply with applicable federal, state, or local plumbing codes.
2. All Others: The water and waste piping and connections shall comply with the International Plumbing Code,
International Code Council (ICC), or to the Uniform Plumbing Code (IAPMO).
3. Install a backflow prevention device. Most municipalities require a recognized backflow preventer
Usable on all hot beverage and cold beverage equipment is a WATTS® SD-2 or SD-3.
WATTS spring loaded double check valve models are accepted by most zoning authorities.
The check valve should be as close to the water supply inlet of the beverage equipment as possible
4. All beverage equipment must use a water filter. A finishing carbon filter is preferred
5. Install the filter unit after a water shutoff valve and in a position to facilitate filter replacement.
6. The water line and newly installed filter cartridge must be flushed thoroughly prior to connecting it to the brewer to
prevent debris from contaminating the machine
7. Verify that the water line will provide a flow rate of at least 1½ gpm/(5.7lpm) per minute and the water pressure is
between 20-75 psig (138-517kPa) before making any connections
8. IMPORTANT: Only use the supplied factory fitting to attach water supply line to brewer (shipped in brew basket)
9. The suppled fitting is a 3/8” flare/compression fitting for 1/4” supply line. Other adaptors may be substituted.
10. Hand tighten the factory fitting when connecting the stub on the brewer. This will reduce stress on the internal
connections and reduce the possibility of leaks developing after the install has been completed
Tank Drain
The water tank must be drained before maintenance procedures, and when the unit is to be relocated or shipped.
Drain is for service use only and must not be permanently connected. NOTE: Never plumb a water line to the drain.
1. Disconnect power and water to unit. DANGER: Ensure that all utility connections to the brewer are broken.
2. Move the unit near a sink or obtain a container large enough to hold four gallons of water.
Note: The CBS-2241 hot water tank when full holds 3.3 gallons; the CBS-2242 6 gallons.
3. Remove the front panel and tank cover and allow the tank to cool to a safe temperature
4. The tank drain line and clamp are located inside-under the hot water tank. Pinch the drain line clamp to close
5. Locate the fill valve against the back wall, using pliers, loosen the hose clamp and move it back over the tube.
Note Do not loosen the hose clamp to the bottom of the hot water tank
6. Crimp the tube an inch or two away from the drain plug to prevent water from flowing and pull it off the valve.
7. Pull the tube end out of the brewer and position over sink or bucket.
8. Release the crimped tube and hose clamp and allow the water to flow into the sink or container.
9. Reverse steps 4-8 when service is complete. Ensure pinch clamp is open and hose clamps are in place.
Brewer Hot Water Tank Capacity
OPEN
Leave open for use
PINCH SHUT
To drain tank & service
brewer
AI!
CBS-2241 Single 4.5 gallon 17 L
CBS-2242 Twin 8.5 gallon 32 L
Go to fetco.com for the latest versions of all information Page 15 P216 January 2024
Operator Training
Review the operating procedures with whoever will be using the brewer.
Pay particular attention to the following areas:
1. Always pre-heat the dispensers before the first use of each day by filling them half way with hot water, and letting
them stand for at least 5 minutes.
2. Do not remove the brew basket from a coffee brewer until it has stopped dripping.
3. Make sure the dispenser is empty before brewing into it.
4. Show how to attach covers, close, and or secure the dispensers for transporting.
5. Show the location and operation of the water shut off valve as well as the circuit breaker for the brewer.
6. Steam from the tank will form condensation in the vent tubes. This condensation will drip into and then out of the
brew baskets. Up to 1/4 cup/60 cc discharging overnight is possible. Place an appropriate container under each
brew basket when not in use.
7. We recommend leaving the power to the brewer on overnight. The water tank is well insulated and very little
electricity is used to keep the tank hot. Leaving the brewer in the “ON” position will also avoid delays at the
beginning of shifts for the brewer to reach operating temperature.
Cleaning & Maintenance
After Each Brew:
1. Dispose of grounds and rinse brew basket.-
2. Never strike a brew basket or hit it against a hard surface.
This will damage the brew cone, and may damage the brew basket support rails
3. Rinse dispensers before reuse.
Every Day:
1. Wash brew basket with hot sudsy water.
2. Pull CSD from the spray head, it is magnetically attached. Use gloves or a heavy towel.
Wash off any film and reattach. Use vinegar if limescale filming is present.
3. Clean dispensers with hot suds water and a brush, rinse and air dry.
4. Use only a soft cloth and hot suds on the outside to avoid scratches. Never use abrasives that
will scratch surface.
Weekly
1. Use a commercial coffee dispenser cleaner such as URNEX™, TABZ™, DIP-IT™ or Squeak 'n Clean™.
2. Carefully Follow the instructions supplied with the cleaning product
3. Never use spray cleaners, solvent, solvent based cleaner or petroleum based polish anywhere on dispensers
Go to fetco.com for the latest versions of all information Page 16 P216 January 2024
Warning
1. Turn off power before any cleaning procedure, including wiping the exterior for appearance reasons.
2. Dry the exterior, especially the face panel, before turning on power.
3. Do not apply any type of spray cleaner on the face panel of this equipment.
4. Never use solvent or solvent-based cleaner or petroleum based polish anywhere on this equipment.
5. Dry the face of the touch pad before turning on power
6. Do not electrically energize this equipment or attempt operation without all covers in place and all screws fastened.
7. Unplug machine before disassembly or servicing.
Installation safety and hygiene directions-For International and CE equipment
1. Access to the service area is restricted to persons having safety/hygiene knowledge and practical experience of the coffee
brewer. This appliance must be installed in locations where it can be overseen by trained personnel.
2. For proper operation, this appliance must be installed indoors where the temperature is between 10°C/50°F to 35°C/95°F.
Drain and remove all liquid from equipment and lines if exposed to freezing temperatures.
3. All commercial cooking equipment, including this unit, is not intended for use by children or persons with reduced physical,
sensory, or mental capabilities. Ensure proper supervision of children and keep them away from the unit.
4. Children should be supervised to ensure that they do not play hot beverage equipment.
5. This unit must be installed and serviced by qualified personnel only.
6. Installation must conform to all local electrical and plumbing codes. Installation by unqualified personnel will void the unit
warranty and may lead to electric shock or burn, as well as damage to unit and/or its surroundings.
7. If the power cord requires repair or replacement-it must be performed by the manufacturer or authorized service personnel
with the specified cord only from the manufacturer in order to avoid a hazard.
8. Review the dimensions for the unit and verify that it will fit properly in the space intended for it. Verify that the counter or
table will support the total weight of the brewer and dispensers when filled (See: Technical Data).
9. Place the brewer on the counter or stand. When the brewer is in position, level it front to back as well as side-to-side by
adjusting the legs.
10. Brewers will need a sturdy supported surface for operation. Do not move brewers when filled.
11. Do not tilt appliance more than 10° to insure safe operation.
12. Unit is for protected indoor use only. Do not steam clean or use excessive water on unit.
13. This unit is not “jet-proof” construction. Do not pressure wash or use jet spray to clean this unit.
14. The unit is not waterproof-do not submerge or saturate with water.
Equipment exposed to flood and contaminated must not be used due to electrical and food safety.
Do not operate if unit has been submerged or saturated with water.
Labels and warnings for hot beverage equipment Label for BACK PANEL of equipment (1046.00035.00)
Go to fetco.com for the latest versions of all information Page 17 P216 January 2024
Brew Baskets
Plastic Brew Basket For CBS-2241 & CBS-2242
Part Number B014218BN2BK – Complete Plastic Brew Basket 13" X 5", .218 DIA HOLE
Brew basket handle plug
for polymeric brew baskets
is available in optional
colors.
Part Number PLUG INSERT COLOR
1023.00195.00
BROWN PLUG, BB HANDLE
1023.00194.00
BLACK PLUG, BB HANDLE
1023.00190.00
RED PLUG, BB HANDLE
1023.00191.00
GREEN PLUG, BB HANDLE
1023.00192.00
ORANGE PLUG, BB HANDLE
1023.00180.00
BLUE PLUG, BB HANDLE
Stainless Steel Brew Basket For CBS-2241 & CBS-2242
Part Number B003218B1 – Complete Stainless Steel Brew Basket 13" X 5", .218 DIA HOLE
Ref# Qty Part Number Description
1 1 1112.00128.00 BB WLDMNT 13" X 5", .218 DIA HOLE
2 1 1046.00025.00 BREW BASKET WARNING LABEL
3 1 1082.00040.00 SCREW, 1/4-20 X .5, FL HD, PH., W/NYLN
4 1 1009.00006.00 WIRE BASKET
5 1 1102.00064.00 HANDLE W/MAGNET ASY, BLACK
Optional
colored
handle
1102.00065.00 HANDLE W/MAGNET ASY, RED
Optional
colored
handle
1102.00066.00 HANDLE W/MAGNET ASY, GREEN
Optional
colored
handle
1102.00067.00 HANDLE W/MAGNET ASY, ORANGE
Specialty Brew Baskets for Iced Tea/Tea and Specialty Coffee Brewing.
These brew baskets have reduced orifice sizes and may require PROGRAMMING changes to increase brewing time
and pulses to enhance extraction and prevent basket overflow during steeping. SEE Page 5- Brew Recipes
Stainless Steel
Part Number
Orifice Size
Handle Color
Filter Paper Size
B003218B1 (from above)
0.218-Sandard
Black
13” X 5” or FETCO# F002
B003158B1
0.158
Black
13” X 5” or FETCO# F002
B003110G1
0.110
Green
13” X 5” or FETCO# F002
B003110B1
0.110
Black
13” X 5” or FETCO# F002
B003079B1
0.079
Black
13” X 5” or FETCO# F002
Plastic
Part Number
Orifice Size
Plug Color
Filter Paper Size
B014218BN2BK (from above)
0.218-Sandard
Black
13” X 5” or FETCO# F002
B014140G2BK
0.140
Green
13” X 5” or FETCO# F002
Go to fetco.com for the latest versions of all information Page 18 P216 January 2024
Parts diagrams
Ref
Qty
Part Number
Description Drawing 1101.00565.00 CBS-2242
1
1
1111.00101.00
WELDMENT BODY, CBS-2242
2
8
1084.00051.00.
NUT, HEX LOCKWASHER, #8-32, 18-8 ST. STL
3
1
1102.00448.00
FRONT PANEL ASSEMBLY, CBS-2200 SERIES
4
2
1082.00029.00
SCREW, #6 X 3/8 LG, TRUSS HD PHIL, SHEET MTL
5
4
1082.00058.00
SCREW, # 8-32 X 5/8, FLAT HD, PH, 18-8 SS
6
1
See Drawing Pg 27
ELECTRICAL COMPONENT LATTICE, CBS-2200
7
1
1102.00444.00
VISUAL COMMUNICATION RGB LED BAR, ASSY
8
4
1081.00006.00
SPACER, 6MM OD x 3.2MM ID x 5MM LG, Z/P
9
1
1051.00046.00
CBS-2200 SERIES, I/O BOARD, 24V
10
4
1029.00006.00
NUT, FINGER KNURLED, #4-40
11
2
See Drawing Pg 26
SPRAYHEAD ASSY,CBS-30/40'S, QUICK CONNECT
12
2
1024.00063.00
O-RING, 3 15/16" x 3/32" CS, DASH # 154, BUNA-N, DURO-A50
13
4
1024.00107.00
O-RING, 1 3/16" OD X 1 1/16" ID X 1/16" TH, BYPASS SEAL
14
2
1023.00343.00
VENT INSERT, QUICK CONNECT
15
3
1024.00106.00
O-RING, 13/16"OD X 11/16"ID X 1/16" TH, FOR QUICK CONNECT
16
5
1023.00342.00
QUICK CONNECT CLIP
17
18
1083.00010.00
WASHER, #12 SCREW W/NEOPRENE-BONDED SEAL
Parts list continues next page
Go to fetco.com for the latest versions of all information Page 19 P216 January 2024
Ref
Qty
Part Number
Description Drawing 1101.00565.00 CBS-2242NGContinued from page 16
18
18
1084.00006.00
NUT, 8-32 18-8 HEX MACHINE SCREW
19
2
1024.00098.00
VENT TUBE, CBS- EXTRACTOR SERIES
20
2
1086.00004.00
BUSHING, SNAP, 1" MOUNTING HOLE
21
1
1102.00243.00
ADAPTER ASSY, 3/4" BSP x 1/4" NPT x 3/8" TUBE
22
2
1065.00009.00
GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
23
1
1044.00012.00
LABEL GROUND, CE
24
11
1084.00011.00
NUT, CLIP ON (J-NUT), #6-32, 22-20 GA., BLK-PH FINISH
25
1
1025.00058.00
TUBE, 9/16"OD X 5/16"ID X 25.00"LG
26
1
1086.00009.00
CLAMP, 3/4" MAX TUBE OD FLOW CONTROL
27
5
1086.00003.00
UNICLAMP, 15.9 HOSE OD CLAMP
28
1
1112.00530.00
WELDMENT, RIGHT COVER, CBS-2240
29
2
1023.00354.00
LOCATOR, DISPENSER, CBS-2240
30
2
1023.00355.00
LOCATOR, AIRPOT ADAPTER, CBS-2240
31
1
1001.00408.00
COVER TOP, CBS-2242/42
32
1
1001.00409.00
COVER, UPPER BASE, CBS-2242/42
33
11
1082.00017.00
SCREW, TRUSS HD. PHIL. MACHINE, # 6-32 X 1/2 LG.
34
1
1046.00035.00
LABEL, WARNING "TO REDUCE RISK OF ELECTRIC SHOCK OR FIRE"
35
1
1402.00106.00
HARNESS, CBS-2240/50-NG, LOW AMP, UNIVERSAL
36
1
1402.00107.00
HARNESS ADDITION, CBS-2242/52-NG, LOW AMP, UNIVERSAL
37
1
1063.00042.00
ETHERNET CABLE, CAT-7, 5FT LENGTH
38
2
1046.00003.00
LABEL, CSD WARNING, 1.5" X 5.0"
39
1
1041.00032.00
BLACK EXTRACTOR NG LABEL, LASER ENGRAVED
40
2
1025.00142.00
TUBE, SILICONE, 3/4" OD X 1/2" ID X 3.75" LG, BREW
41
1
See Drawing Pg. 18
TANK ASSEMBLY, CBS-2242
42
1
1402.00037.10
HARNESS HIGH AMP, CBS-2242/42/51, UL
43
1
B014218BN2BK
BREW BASKET ASSY, BLACK, 13" X 5", 0.218" DIA HOLE, BROWN PLUG (Page 28)
44
1
B003218B1
BREW BASKET ASSY, 13" X 5", .218 DIA HOLE, BLACK (Page 28)
45
1
1024.00111.00
GROMMET, SILICONE, W/ POSITION TABS
46
1
1023.00362.00
FITTING VENT, ELBOW, .375" X .375", SELF POSITIONING
47
1
1023.00348.00
HOT WATER INSERT, MANUAL FAUCET
48
1
1071.00055.00
FAUCET, HOT WATER, PSC-BR-8, WITH FLAT AND STEM
49
1
1084.00048.00
JAM NUT, 1/2-20 UNF, NICKEL PLATED BRASS
50
1
1003.00370.00
HOT WATER INSERT LOCK
51
1
1025.00120.00
TUBE, 9/16"OD X 5/16"ID X 13.00"LG
52
1
1023.00346.00
HOT WATER INSERT, AUTO FAUCET
53
1
1029.00041.00
COVER, AUTO HOT WATER FAUCET, SILICONE
54
1
1023.00347.00
VALVE MOUNT, HOT WATER DISPENSER
55
1
1025.00026.00
TUBE, 1/4"OD X 1/8"ID X 30"LG, VENT, HOT WATER VAPOR
56
2
1023.00369.00
ORIFICE INSERT, QUICK CONNECT, 3/16" HOLE
57
2
1057.00076.00
VALVE ASSEMBLY, COMPLETE, NG, DELTROL
58
2
1025.00138.00
TUBE, SILICONE, 3/4" OD X 1/2" ID X 1-1/2" LG, HOT WATER
59
1
1025.00135.00
TUBE, 1/2"OD X 1/4"ID X .75" LG, RESTRICTOR
60
1
1024.00051.00
GROMMET, SILICONE, BLANK
61
1
1023.00349.00
HOT WATER INSERT, NO FAUCET
62
1
1029.00042.00
BYPASS L-TUBE, SILICONE, 2200 SINGLE SERIES
63
1
1023.00344.00
PLUG INSERT, QUICK CONNECT
64
1
1102.00445.00
ASSY, BREW BASKET LOCKER W/FEEDBACK
65
1
1003.00259.00
BRACKET, BREW BASKET LOCK COVER
66
3
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
67
1
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
68
3
1073.00016.00
LEG, THERMOPLASTIC, 2.50"(63mm)
69
3
1073.00019.00
LEG, 3/8-16 THREAD x 1" LG., GRAY
70
1
1086.00008.00
CONNECTOR, CLAMP, NON-METALLIC CABLE, 3/4"
71
1
1003.00348.00
ADAPTER PLATE, CBS-1130-XV+, STRAIN RELIEF, CE
72
1
1086.00029.00
BUSHING, STRAIN RELIEF, .360"-.430" DIA CABLE
73
1
1044.00013.00
LABEL EQUIPOTENTIALITY, CE
74
1
1052.00027.00
EMI FILTER, THREE LINE 30A, 250/440VAC
75
2
1084.00012.00
NUT, HEX, #6-32 MACHINE SCREW
76
1
1112.00246.00
WELDMENT BRACKET TERMINAL BLOCK, 3 POLE
77
1
1052.00022.00
EUROSTRIP HE10 TERM. BLOCK, 3 POLE, 50AMP, 18-8 AWG
78
2
1082.00082.00
SCREW, PHILLIP HD., 8-32 THREAD
79
1
1402.00121.10
WIRE HARNESS ADDITION, HIGH AMP, EMI FILTER, 2-POLE, CE
Go to fetco.com for the latest versions of all information Page 20 P216 January 2024
Hot Water Tank Assembly CBS-2242 Next Generation
CBS-2242 Hot Water Tank Drawing 1104.00187.00
Go to fetco.com for the latest versions of all information Page 21 P216 January 2024
CBS-2242 Hot Water Tank Parts List Drawing 1104.00187.00
Ref#
Qty
Part number
Description
1
1
1114.00171.00
WELDMENT TANK NG-2242, GROMMET DESIGN
2
2
1024.00115.00
TANK GASKET - NG HEATER PLATE, ONE ELEMENT
3
2
1114.00181.00
WELDMENT TANK HEATER BRACKET, NG-SMALL, ONE HEATER
4
2
1024.00053.00
LEVEL AND TEMP PROBE GROMMET
5
5
1024.00050.00
GROMMET, SILICONE, 11.4mm ID
6
2
1053.00052.00
THERMOSTAT, SINGLE SHOT, SCREW CONNECTIONS, 240V/25A
7
12
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
8
12
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
9
2
1107.00037.00
HEATER ASSEMBLY, IMMERSION 2300W/240VAC
9
2
1107.00005.00
HEATER ASSEMBLY, IMMERSION 3000W/240VAC
9
2
1107.00010.00
HEATER ASSEMBLY, IMMERSION 4000W/240VAC
10
1
1003.00140.00
ALUMINUM BRACKET FOR SSR
11
1
1052.00033.00
RELAY, SOLID STATE, 50A/480VAC, W/BUILD IN VARISTOR
12
2
1081.00042.00
STANDOFF, 1/4" HEX
13
1
1112.00019.00
PROBE WELDMENT, WATER LEVEL 2.600" LG
14
1
1102.00161.00
PROBE ASSEMBLY, TEMP. AND LLC, 8" LONG
15
2
1023.00203.00
FITTING, STRAIGHT, GROMMET, .625"
16
1
1023.00166.00
FITTING, COLD WATER INLET, GROMMET DESIGN
17
1
1044.00004.00
LABEL, DANGER, HIGH VOLTAGE
18
2
1023.00212.00
FITTING, ELBOW, GROMMET, .500"
19
1
1022.00066.00
TANK INSULATION FRONT, CBS-2142
20
1
1022.00067.00
TANK INSULATION BACK, CBS-2142
21
4
1082.00136.00
BRASS SCREW, #8-32 X 1/4", PHILLIPS PAN HEAD
Table of authorities for CBS-2242NG replacement hot water tank module-tank is sold complete with insulation
SKU Number. See page 3 for list
Description
Tank Part Number
E2242US-1B223-PA010; E2242IN-1B223-PA010
TANK CBS-2242, 2 X 2.3KW/240VAC
1104.00187.00
E2242US-1B230-MA110, E2242US-1B230-PA010,
E2242IN-1B230-PA010 E2242NM-1B230-PA010
TANK CBS-2242, 2 X 3.0KW/240VAC 1104.00188.00
TANK CBS-2242, 2 X 4.0KW/240VAC
1104.00189.00
Go to fetco.com for the latest versions of all information Page 22 P216 January 2024
Ref
Qty
Part Number
Description Drawing 1101.00566.00 CBS-2241NG
1
1
1111.00104.00
WELDMENT BODY, CBS-2241
2
8
1084.00051.00
NUT, HEX LOCKWASHER, #8-32, 18-8 ST. STL.
3
1
1102.00448.00
FRONT PANEL ASSEMBLY, CBS-2200 SERIES
4
2
1082.00029.00
SCREW, #6 X 3/8 LG, TRUSS HD PHIL, SHEET MTL
5
2
1082.00058.00
SCREW, # 8-32 X 5/8, FLAT HD, PH, 18-8 SS
6
1
See Drawing Pg 27
ELECTRICAL COMPONENT LATTICE, CBS-2200
7
1
1102.00444.00
VISUAL COMMUNICATION RGB LED BAR, ASSY
8
4
1081.00006.00
SPACER, 6MM OD x 3.2MM ID x 5MM LG, Z/P
9
1
1051.00046.00
CBS-2200 SERIES, I/O BOARD, 24V
10
4
1029.00006.00
NUT, FINGER KNURLED, #4-40
11
1
See Drawing Pg 26
SPRAYHEAD ASSY,CBS-30/40'S, QUICK CONNECT
12
1
1024.00063.00
O-RING, 3 15/16" x 3/32" CS, DASH # 154, BUNA-N, DURO-A50
13
2
1024.00107.00
O-RING, 1 3/16" OD X 1 1/16" ID X 1/16" TH, BYPASS SEAL
14
1
1023.00343.00
VENT INSERT, QUICK CONNECT
15
2
1024.00106.00
O-RING, 13/16"OD X 11/16"ID X 1/16" TH, FOR QUICK CONNECT
16
3
1023.00342.00
QUICK CONNECT CLIP
17
9
1083.00010.00
WASHER, #12 SCREW W/NEOPRENE-BONDED SEAL
18
9
1084.00006.00
NUT, 8-32 18-8 HEX MACHINE SCREW
19
1
1086.00004.00
BUSHING, SNAP, 1" MOUNTING HOLE
Parts list continues next page
#24 part number
1084.00011.00
J-N ut
Go to fetco.com for the latest versions of all information Page 23 P216 January 2024
Ref Qty PartNumber
Description Drawing 1101.00566.00 CBS-2241NG …Continued from page
20
20
1
1024.00098.00
VENT TUBE, CBS- EXTRACTOR SERIES
21
1
1102.00243.00
ADAPTER ASSY, 3/4" BSP x 1/4" NPT x 3/8" TUBE
22
2
1065.00009.00
GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
23
1
1044.00012.00
LABEL GROUND, CE
24
12
1084.00011.00
NUT, CLIP ON (J-NUT), #6-32, 22-20 GA., BLK-PH FINISH
25
1
1025.00058.00
TUBE, 9/16"OD X 5/16"ID X 25.00"LG
26
1
1086.00009.00
CLAMP, 3/4" MAX TUBE OD FLOW CONTROL
27
4
1086.00003.00
UNICLAMP, 15.9 HOSE OD CLAMP
28
1
1112.00531.00
WELDMENT FRONT COVER, CBS-2240
29
1
1001.00413.00
COVER TOP, CBS-2231/41
30
1
1001.00414.00
COVER, UPPER BASE, CBS-2231/41
31
12
1082.00017.00
SCREW, TRUSS HD. PHIL. MACHINE, # 6-32 X 1/2 LG.
32
1
1046.00035.00
LABEL, WARNING "TO REDUCE RISK OF ELECTRIC SHOCK OR FIRE"
33
1
1402.00106.00
HARNESS, CBS-2240/50-NG, LOW AMP, UNIVERSAL
34
1
1063.00042.00
ETHERNET CABLE, CAT-7, 5FT LENGTH
35
1
1046.00003.00
LABEL, CSD WARNING, 1.5" X 5.0"
36
1
1041.00032.00
BLACK EXTRACTOR NG LABEL, LASER ENGRAVED
37 1
See Drawing
Pages 22 & 23
TANK ASSEMBLY, CBS-2241, 2 X 1.5KW/120VAC
38
1
1402.00039.10
HARNESS HIGH AMP, CBS-2231/41/51, UL
39
1
B014218BN2BK
BREW BASKET ASSY, BLK, 13" X 5", 0.218" DIA HOLE, BWN PLUG (Page 28)
40
1
B003218B1
BREW BASKET ASSY, 13" X 5", .218 DIA HOLE, BLK (Page 28)
41
1
1024.00111.00
GROMMET, SILICONE, W/ POSITION TABS
42
1
1023.00362.00
FITTING VENT, ELBOW, .375" X .375", SELF POSITIONING
43
1
1013.00130.00
TUBE, 304SS, .562OD X .028 WALL X 9-1/4" LG.
44
1
1023.00348.00
HOT WATER INSERT, MANUAL FAUCET
45
1
1071.00055.00
FAUCET, HOT WATER, PSC-BR-8, WITH FLAT AND STEM
46
1
1084.00048.00
JAM NUT, 1/2-20 UNF, NICKEL PLATED BRASS
47
1
1003.00370.00
HOT WATER INSERT LOCK
48
1
1025.00120.00
TUBE, 9/16"OD X 5/16"ID X 13.00"LG
49
1
1023.00346.00
HOT WATER INSERT, AUTO FAUCET
50
1
1029.00041.00
COVER, AUTO HOT WATER FAUCET, SILICONE
51
1
1023.00347.00
VALVE MOUNT, HOT WATER DISPENSER
52
2
1023.00369.00
ORIFICE INSERT, QUICK CONNECT, 3/16" HOLE
53
2
1057.00076.00
VALVE ASSEMBLY, COMPLETE, NG, DELTROL
54
2
1025.00138.00
TUBE, SILICONE, 3/4" OD X 1/2" ID X 1-1/2" LG, HOT WATER
55
1
1025.00135.00
TUBE, 1/2"OD X 1/4"ID X .75" LG, RESTRICTOR
56
1
1025.00026.00
TUBE, 1/4"OD X 1/8"ID X 30"LG, VENT, HOT WATER VAPOR
57
2
1024.00051.00
GROMMET, SILICONE, BLANK
58
1
1023.00349.00
HOT WATER INSERT, NO FAUCET
59
1
1029.00042.00
BYPASS L-TUBE, SILICONE, 2200 SINGLE SERIES
60
1
1023.00344.00
PLUG INSERT, QUICK CONNECT
61
1
1102.00445.00
ASSY, BREW BASKET LOCKER W/FEEDBACK
62
1
1003.00259.00
BRACKET, BREW BASKET LOCK COVER
63
4
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
64
2
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
65
4
1073.00002.00
LEG, FLANGE FOOT, 4.0" HIGH
66
1
1086.00008.00
CONNECTOR, CLAMP, NON-METALLIC CABLE, 3/4"
67
1
1083.00032.00
WASHER, FLAT, 1.250"OD X 0.835"ID, SS
68
1
1086.00048.00
SKINTOP, 1/2" NPT, Ø.157"-.354" CABLE, BLK
69
1
1086.00049.00
LOCKNUT, SKINTOP, 1/2" NPT, BLACK HEX
70
1
1044.00013.00
LABEL EQUIPOTENTIALITY, CE
71
1
1052.00029.00
EMI FILTER, TWO LINE 20A, 120/250VAC
72
2
1084.00012.00
NUT, HEX, #6-32 MACHINE SCREW
73
1
1063.00016.00
POWER CORD, 120VAC W/NEMA 5-15P PLUG
74
1
1063.00015.00
CORD, 120 VAC, 12/3 AWG ,20 AMP , W/5-20P NEMA PLUG
75
1
1402.00039.11
HARNESS ADDITION, HIGH AMP, CBS-2231/41/51, UL
76
1
1402.00121.10
WIRE HARNESS ADDITION, HIGH AMP, EMI FILTER, 2-POLE, CE
77
1
1025.00142.00
TUBE, SILICONE, 3/4" OD X 1/2" ID X 3.75" LG, BREW
Go to fetco.com for the latest versions of all information Page 24 P216 January 2024
CBS-2241Next Generation Hot Water Tank Assembly, Single Heater
TANK ASSY, CBS-2241 Single Heater
For drawing numbers: 1104.00178.00; 1104.00180.00; 1104.00182.00; 1104.00184.00; 1104.00185.00; 1104.00186.00
Go to fetco.com for the latest versions of all information Page 25 P216 January 2024
TANK ASSY, CBS-2241 Single Heater Parts List
Ref
Qty
PART NO
DESCRIPTION
1
1
1114.00170.00
WELDMENT, TANK, CBS-2241
2
1
1024.00114.00
TANK GASKET - NG HEATER PLATE, TWO ELEMENT
3
1
1114.00184.00
WELDMENT TANK HEATER BRACKET, NG-LARGE, TWO HEATER
4
2
1024.00053.00
LEVEL AND TEMP PROBE GROMMET
5
3
1024.00050.00
GROMMET, SILICONE, 11.4mm ID
6
1
1053.00052.00
THERMOSTAT, SINGLE SHOT, SCREW CONNECTIONS, 240V/25A
7
8
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
8
8
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
9
1
1107.00030.00
HEATER ASSEMBLY, IMMERSION 1500W/120VAC (Tank 1104.00178.00)
9
1
1107.00031.00
HEATER ASSEMBLY, IMMERSION 1700W/120VAC (Tank 1104.00180.00)
9
1
1107.00029.00
HEATER ASSEMBLY, IMMERSION 2300W/120VAC (Tank 1104.00182.00)
9
1
1107.00037.00
HEATER ASSEMBLY, IMMERSION 2300W/240VAC (Tank 1104.00184.00)
9
1
1107.00005.00
HEATER ASSEMBLY, IMMERSION 3000W/240VAC (Tank 1104.00185.00)
9
1
1107.00010.00
HEATER ASSEMBLY, IMMERSION 4000W/240VAC (Tank 1104.00186.00)
10
1
1003.00140.00
ALUMINUM BRACKET FOR SSR
11
1
1052.00033.00
RELAY, SOLID STATE, 50A/480VAC, W/BUILD IN VARISTOR
12
2
1081.00042.00
STANDOFF, 1/4" HEX
13
1
1112.00019.00
PROBE WELDMENT, WATER LEVEL 2.600" LG
14
1
1102.00161.00
PROBE ASSEMBLY, TEMP. AND LLC, 8" LONG
15
1
1023.00203.00
FITTING, STRAIGHT, GROMMET, .625"
16
1
1023.00166.00
FITTING, COLD WATER INLET, GROMMET DESIGN
17
1
1044.00004.00
LABEL, DANGER, HIGH VOLTAGE
18
1
1024.00051.00
GROMMET, SILICONE, BLANK
19
1
1023.00212.00
FITTING, ELBOW, GROMMET, .500"
20
1
1022.00115.00
TANK INSULATION, CBS-2241
21
2
1082.00136.00
BRASS SCREW, #8-32 X 1/4", PHILLIPS PAN HEAD
Table of authorities for CBS-2241NG replacement hot water tank module-tank is sold complete with insulation
SKU Number. See page 3 for list
Description
Tank Part Number
E2241US-1A115-PA011
TANK , CBS-2241, 1 X 1.5KW/120VAC
1104.00178.00
E2241US-1A115-PA011; E2241US-1A123-PM112
TANK , CBS-2241, 1 X 2.3KW/120VAC
1104.00182.00
E2241IN-1B123-PA010
TANK , CBS-2241, 1 X 2.3KW/240VAC
1104.00184.00
E2241IN-1B130-MM010; E2241IN-1B130-MM010
E2241KS-1B130-PM010; E2241CE-1B130-PA0005
TANK , CBS-2241, 1 X 3.0KW/240VAC 1104.00185.00
E2241NM-1B140-PA010
TANK , CBS-2241, 1 X 4.0KW/240VAC
1104.00186.00
Go to fetco.com for the latest versions of all information Page 26 P216 January 2024
CBS-2241Next Generation Hot Water Tank Assembly, Dual Heaters
TANK ASSY, CBS-2241 Two Heater Drawing number 1104.000171.00, 1104.000173.00
Go to fetco.com for the latest versions of all information Page 27 P216 January 2024
TANK ASSY, CBS-2241 Dual Heater Parts List
REF
QTY
Part number
Description
1
1
1114.00168.00
WELDMENT, TANK, CBS-2241
2
1
1024.00114.00
TANK GASKET - NG HEATER PLATE, TWO ELEMENT
3
1
1114.00176.00
WELDMENT TANK HEATER BRACKET, NG-2231
4
2
1024.00053.00
LEVEL AND TEMP PROBE GROMMET
5
3
1024.00050.00
GROMMET, SILICONE, 11.4mm ID
6
2
1053.00052.00
THERMOSTAT, SINGLE SHOT, SCREW CONNECTIONS, 240V/25A
7
10
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
8
10
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
9
2
1107.00022.00
HEATER ASSEMBLY, IMMERSION 1700W/120VAC
9
2
1107.00019.00
HEATER ASSEMBLY, IMMERSION 2300W/120VAC
10
2
1003.00140.00
ALUMINUM BRACKET FOR SSR
11
2
1052.00033.00
RELAY, SOLID STATE, 50A/480VAC, W/BUILD IN VARISTOR
12
4
1081.00042.00
STANDOFF, 1/4" HEX
13
1
1112.00002.00
PROBE WELDMENT, WATER LEVEL 2.25" LG
14
1
1102.00161.00
PROBE ASSEMBLY, TEMP. AND LLC, 8" LONG
15
1
1023.00168.00
FITTING, STRAIGHT, GROMMET, .400"
16
1
1023.00166.00
FITTING, COLD WATER INLET, GROMMET DESIGN
17
1
1044.00004.00
LABEL, DANGER, HIGH VOLTAGE
18
1
1023.00212.00
FITTING, ELBOW, GROMMET, .500"
19
1
1024.00051.00
GROMMET, SILICONE, BLANK
20
1
1022.00114.00
TANK INSULATION, CBS-2241
21
4
1082.00136.00
BRASS SCREW, #8-32 X 1/4", PHILLIPS PAN HEAD
Table of authorities for CBS-2241NG replacement hot water tank module-tank is sold complete with insulation
SKU Number. See page 3 for list
Description
Part Number
E2231NM-1X123-PA012, E2231NM-1A123-PA012
TANK CBS-2241, 2 X 2.3KW/120VAC
1104.00173.00
E2231US-1X117-PA011
TANK CBS-2241, 2 X 1.7KW/120VAC
1104.00171.00
Go to fetco.com for the latest versions of all information Page 28 P216 January 2024
Part number 1102.00451.00 Small Spray Assembly Parts-Quick connect version
Ref#
Qty
Part number
Description
1
1
1000.00143.00
SPRAY HEAD BASE (KIT), QUICK CONNECT, 30/40'S
2
1
1024.00063.00
O-RING, 3 15/16" x 3/32" CS, DASH # 154, BUNA-N, DURO-A50
3
2
1024.00107.00
O-RING, 1 3/16" OD X 1 1/16" ID X 1/16" TH, BYPASS SEAL
4
1
1102.00113.00
SWITCH, REED, ASSEMBLY
5
1
1102.00479.00
ASSEMBLY, CASCADE SPRAY DOME, NEXT GEN, ORANGE
6 2 1057.00076.00
VALVE ASSEMBLY, COMPLETE, NG, DELTROL
(interchangeable with 1057.00078.00)
6 2 1057.00078.00
VALVE ASSEMBLY, COMPLETE, NG, RPE
(interchangeable with 1057.00076.00)
7
3
1023.00342.00
QUICK CONNECT CLIP
8
1
1023.00343.00
VENT INSERT, QUICK CONNECT
9
2
1024.00106.00
O-RING, 13/16"OD X 11/16"ID X 1/16" TH, FOR QUICK CONNECT
10
1
1024.00098.00
VENT TUBE, CBS- EXTRACTOR SERIES
11
1
1023.00369.00
ORIFICE INSERT, QUICK CONNECT, 3/16" HOLE
12
1
1023.00344.00
PLUG INSERT, QUICK CONNECT
Go to fetco.com for the latest versions of all information Page 29 P216 January 2024
Ref
Qty
Part Number
Description Electrical component lattice, CBS-2200 Part#1102.00449.00
1102.00449.00
COMPLETE ELECTRICAL COMPONENT LATTICE, CBS-2200
1
1
1023.00350.00
ELECTRICAL MOUNTING LATTICE, COMMON
2
1
1052.00023.00
EUROSTRIP HE16 TERM. BLOCK, 4 POLE, 63 AMP, 18-8 AWG
3
2
1082.00056.00
SCREW, #8-11 X 1" PAN HD PHIL, THREAD FORMING
4
1
1058.00024.00
SWITCH, POWER, DOUBLE POLE, 16A, 125/250 VAC
5
1
1057.00043.00
SOLENOID VALVE, 5.5L/min, 180 DEG, 24VDC
6
2
1082.00010.00
SCREW, PAN HD. PHIL. MACH., M4x10 ZINC-PLATED
7
1
1052.00059.00
POWER SUPPLY, 90-264VAC/24VDC, 2.25A
8
2
1082.00020.00
SCREW, #6 X 5/8, TRUSS HD PHIL, SHEET MTL
9
1
1058.00055.00
USB CONNECTOR
10
1
1058.00162.00
ETHERNET PLUG IN CONNECTOR, W/COVER
CBS-2200 Electical component lattice
Part# 1102.00449.00
Go to fetco.com for the latest versions of all information Page 30 P216 January 2024
Wiring diagrams
Wiring diagram 1401.00178.10 CBS-2241-two heater model
Wiring diagram for the following SKU numbers-see page 3
E2241US-1X117-PA011 CBS-2241,DUAL VOLT, 1Ph, 2+G/3+G, 2x1.7xW/120VAC, 120/208-240VAC
E2241NM-1X123-PA012 CBS-2241,NOM,DUAL VOLT,1Ph, 2+G/3+G, 2x2.3xW/120VAC, 120/208-240VAC
E2241US-1A123-PM112 CBS-2241, 1Ph, 2+G, 2.3xW/120VAC
E2241US-1A123-PA012 CBS-2241, 1Ph, 2+G, 2.3xW/120VAC
E2241US-1A115-PA011 CBS-2241, 1Ph, 2+G, 1.5xW/120VAC
E2241NM-1B140-PA010 CBS-2241, NOM, 1Ph, 2+G, 4.0xW/240VAC
E2241IN-1B140-PA010 CBS-2241, INTL, 1Ph, 2+G, 4.0xW/240VAC
E2241IN-1B130-PA010 CBS-2241, INTL, 1Ph, 2+G, 3.0xW/240VAC
E2241IN-1B123-PA010 CBS-2241, INTL, 1Ph, 2+G, 2.3xW/240VACC
Go to fetco.com for the latest versions of all information Page 31 P216 January 2024
Wiring diagram 1401.00177.10 CBS-2241
Wiring diagram for the following SKU numbers-see page 3
E2241US-1A123-PM112 CBS-2241, 1Ph, 2+G, 2.3xW/120VAC
Go to fetco.com for the latest versions of all information Page 32 P216 January 2024
Wiring diagram 1401.00172.10 CBS-2242
Wiring diagram for the following SKU numbers-see page 3
E2242US-1B230-PA010 1Ph, 2+G, 2x3kW/240VAC Terminal Block
E2242US-1B230-MA110 1Ph, 2+G, 2x3kW/240VAC Terminal Block
E2242US-1B223-PA010 1Ph, 2+G, 2x2.3kW/240VAC Terminal Block
E2242NM-1B230-PA010 NOM, 1Ph, 2+G, 2x3kW/240VAC Terminal Block
E2242IN-1B230-PA010 , INTL, 1Ph, 2+G, 2x3kW/240VAC Terminal Block
E2242IN-1B223-PA010 , INTL, 1Ph, 2+G, 2x2.3kW/240VAC Terminal Block
SSR
