EG10.17 Rev. 01/24
Catalog Specification Sheet No.
EG10.17
Spec-Master
®
Demo Tables and Ceiling Mounted Demo Mirrors
Short Form Specifications
Eagle Spec-Master
®
Demo Table, model _______________.
Top is 14/304 stainless steel with marine counter edge on all
sides. Top reinforced with welded hat channel. Features include
stainless steel adjustable undershelf, acrylic mirror supported
in tilting frame, and 1
5
⁄8˝ O.D. stainless steel tubular legs with
adjustable stainless steel bullet feet.
Eagle Ceiling Mounted Demo Mirror, model ______________.
Acrylic mirror supported in tilting frame, and 1
5
⁄8˝ O.D. stainless
steel posts with stainless steel plates. Mounting hardware not
included.
Item No.:
Project No.:
S.I.S. No.:
Specification Sheet
Spec-Master
®
Demo Tables and
Ceiling Mounted Demo Mirrors
MODELS:
DT3660SE
DT3672SE
CMM49
CMM61
Options / Accessories (for Demo Tables only)
Drawer assemblies
Casters
Demo Tables
• Tabletop:
- 14 gauge type 304 stainless steel.
- 36˝ (914mm)-wide.
- Marine counter edge on all sides.
- Reinforced with welded-on hat channels.
• Undershelf
- Heavy gauge stainless steel.
- Adjustable.
• Legs
- Heavy duty stainless steel.
- 1
5
⁄8˝ (41mm)-diameter.
- Stainless steel gussets.
- Adjustable stainless steel bullet feet.
Ceiling Mounted Demo Mirrors
• 1
5
⁄8˝ (41mm)-diameter 16 gauge stainless steel posts (length
of posts must be specified when ordering).
• Pair of heavy gauge stainless steel plates.
Mirror—on all units
• 24
1
⁄4˝ (616mm)-wide.
• Acrylic.
• Supported in tilt framing.
• Locking knob on each side.
demo table
ceiling mounted
demo mirror
Patented uni-lok
®
System
(Patent No. 5,165,349)
Certifications / Approvals
For custom configuration or fabrication needs, contact our SpecFAB
®
Division.
Phone: 302-653-3000 • Fax: 302-653-2065 • e-mail: [email protected]
Eagle Foodservice Equipment, Eagle MHC, and SpecFAB
®
are divisions of Eagle Group. ©2024 by the Eagle Group
Spec sheets available for viewing, printing or downloading from our online literature library at our websites
EAGLE GROUP
100 Industrial Boulevard, Clayton, DE 19938-8903 USA
Phone: 302-653-3000 • 800-441-8440 • Fax: 302-653-2065
www.eaglegrp.com
www.eaglemhc.com
TABLE SIZE MIRROR SIZE
width x length width x length weight
model # in. mm in. mm lbs. kg
DT3660SE 36˝x60˝ 914x1524 24
1
⁄4˝x49
1
⁄2˝ 616x1257 305 138.4
DT3672SE 36˝x72˝ 914x1829 24
1
⁄4˝x61
1
⁄2˝ 616x1562 327 148.3
FRONT VIEW
SIDE VIEW
TOP VIEW
EAGLE GROUP
100 Industrial Boulevard, Clayton, DE 19938-8903 USA
Phone: 302-653-3000 or 800-441-8440 • Fax: 302-653-2065
www.eaglegrp.com • www.eaglemhc.com
Spec sheets available for viewing, printing or downloading from our online literature library at our websites
Although every attempt has been made to ensure the accuracy of the information provided, we cannot be held responsible for
typographical or printing errors. Information and specifications are subject to change without notice. Please confirm at time of order.
Rev. 01/24
Printed in U.S.A.
©2024 by Eagle Group
Catalog Specification Sheet No.
EG10.17
Spec-Master
®
Demo Tables and Ceiling Mounted Demo Mirrors
Item No.:
Project No.:
S.I.S. No.:
Spec-Master
®
Demo Tables
FRONT VIEW
TOP VIEW
SIDE VIEW
* Does not include post length.
MIRROR SIZE
width length* weight
model # in. mm in. mm lbs. kg
CMM49 24
1
⁄4˝ 616 49
1
⁄2˝ 1257 125 56.7
CMM61 24
1
⁄4˝ 616 61
1
⁄2˝ 1562 160 72.6
Ceiling Mounted Demo Mirrors
DIMENSIONS
OF MOUNTING
PLATE
