EURODIB INDUCTION SERIES
COMMERCIAL INDUCTION COOKTOP
USER MANUAL FOR INDUCTION COOKTOP
CI1800
2025
SAFETY INFORMATION:
When using electrical appliances, basic safety precautions should always be followed including the
following:
• Read these instructions carefully and keep them safe in case you need them in the future.
• Do NOT touch the surface of the induction. It might be hot and cause injury. Always use the
buttons in the machine and allow the machine to cool down before touching it.
• Do NOT immerse the machine, cord or plug under water or any other liquid.
• This appliance is not suited to be used by children or unqualified personnel.
• To clean the machine, unplug it and allow it to cool down before cleaning it with a damp
cloth.
• Do NOT operate any appliance with a damaged cord or plug, or after the appliance
malfunctions or has been damaged in any manner. Return the appliance to the nearest
authorized service facility for examination, repair, or adjustment.
• Do NOT let the cord hang over the edge of a table/counter or touch hot surfaces.
• Do NOT place on or near a hot gas or electric burner, or in a heated oven.
• Extreme caution must be used when moving an appliance containing hot oil or other hot
liquids.
• Always attach the plug to the appliance first, then plug the cord into the wall outlet (for the
detached power cord). To disconnect, turn o all the controls, then remove the plug from
the wall outlet.
• Do not use the appliance for other than intended use.
• Do not cook on a broken cooktop – If the cooktop is broken, cleaning solutions and
spillovers may penetrate the broken cooktop and create a risk of electric shock.
• Clean the cooktop with caution – If a wet sponge or cloth is used to wipe spills on a hot
cooking area, be careful to avoid steam burns, as some cleaners can produce noxious
fumes if applied to a hot surface.
• Do not overheat or heat when the pot is empty.
• Do not place metallic objects, such as knives, forks, spoons, lids, cans, and aluminum foil,
on the top plate.
• Allow suicient space around the cooking area.
• Never use the unit on low-heat-resistant materials (carpet, vinyl).
• Be aware that the unit surface will remain hot for a short period of time.
• Items with a magnetic field, such as radios, televisions, automatic-banking cards, and
cassette tapes, may aect the unit.
TECHNICAL SPECIFICATIONS:
Model
CI1800
Power
1800 W
Voltage
120V – 60Hz
Temperature
140°F – 460°F (60 °C – 238 °C)
OPERATIONAL INSTRUCTIONS:
1. Before turning on the machine, make sure the pot or pan is on the ceramic plate.
2. After plugging the machine, the LED indicator will light up showing the initial power.
(CI1800=1200W). If there is no cookware on the ceramic plate or the cookware is not
induction compatible, the unit buzzer will sound for a minute and automatically turn o.
3. To turn the power on, press the ON/OFF button once.
4. To select the proper heat setting, press the arrows button to reduce or increase the setting
until the correct heat is displayed.
5. To select the temperature setting, press the TEMP button (default = 210 °F (99 °C)), the
temperature light will turn a steady red. Then press the arrows to reduce or increase the
setting until the correct temperature is displayed (temperature stages: 140 °F (60 °C), 180
°F (82 °C)，210 °F (99 °C)，250 °F (121 °C)，280 °F (138 °C)，320 °F (160 °C)，360 °F
(182°C)，390 °F (199 °C)，430 °F (221 °C), and 460 °F (238 °C)).
6. To set the automatic timer, press the TIMER button. The light will turn steady read. Press the
arrows to reduce or increase the selection until the correct time is displayed. The maximum
programmable time is 170 minutes. From 0 to 30 minutes, the time interval will be 1 minute.
From 30-170 minutes, the time interval is 10 minutes. You can change the duration of the
timer at any time by pressing the arrows.
7. After cooking is complete, press the ON/OFF button again to turn o the unit.
8. If a timer was not set at the beginning of the preparation, the unit will enter standby mode
automatically after 120 minutes of operation. To restart, press the ON/OFF button and
follow step one.
NOTE: The machine will automatically turn o within 1 minute if no cookware is placed on the unit
or if the cookware is not induction compatible.
COMPATIBLE COOKWARE
Compatible pans/pots: Steel or cast iron, enameled iron, stainless steel, flat bottom with a
diameter of 12 to 26 cm
Non-compatible pans/pots: Heat-resistant glass, ceramic container, copper, aluminum, rounded
bottom with a base measuring less than 12 cm.
TROUBLES SHOOTING:
If the LED display shows an error code, please refer to the solutions below:
Problem
Cause
Solution
E0 or buzzer warning
There is no cookware on the
ceramic plate, or non-
compatible cookware is on the
ceramic plate.
Place an induction compatible
pot or pan on the cooking
plate.
E1/E01
Machine is too hot.
Clean the ventilation slots and
let the unit cool down.
E2/E02
Overheating protection is
active
Remove the cookware from
the ceramic plate, turn it o
and let it cool down.
E3/E03
Power input has changed
Switch o the unit and allow it
to cool down. If the problem
continues contact your local
retailer or service department.
NOTE: Any other service should be done by an authorized service representative or else the
warranty may be void.
MAINTENANCE
• Before cleaning the machine, allow it to cool down. Always disconnect it before cleaning if
after each use.
• Wipe down the machine with a damp cloth and a drop of dishwashing soap.
• Use a vacuum cleaner to remove dirt from the vents.
• Do NOT use a scrubbing sponge or brush to clean the induction cooker as it might damage
it.
• Using dirty pots or pans may cause discoloration or stains on the ceramic plate.
WARRANTY
This machine has a warranty of 1 year for parts and labor.
In case you have any questions or concerns, you can contact our service department to help you
resolve any issues with your machine.
Eurodib
1-888-956-6866
service@eurodib.com
www.eurodib.com
EXPLODED VIEWS
SPARE PARTS
1. Microcrystalline plate
2. Anti-collision strip
3. Front shell
4. Cable spial connector
5. Lamp board support
6. Control panel
7. Insulating adhesive
8. Adhesive
9. Main board
10. Fan
11. Sensor
12. Wire reel
13. Inner reel
14. 110m Yellow green connection wire
15. 250 mm yellow green wire
16. Power cord
17. Base plate
18. Stove foot/leg
