Before using the TV, please read this guide thoroughly and
retain it for future reference.
English
100U7SAU
20237451
A
NOTE
The accessories may be dierent from the list above due to dierent models, countries
/
regions.
Please refer to the actual accessory bag.
Declaration
Any content and service accessed through this
device, while only intended for individual non-
commercial use, shall be the property of the
applicable third party and subject to protection by
regulations and laws on copyright, patent, trademark
and other intellectual property rights. No part of such
content and service may be modified, duplicated,
published, uploaded, distributed, translated,
marketed, or used to make and distribute products
derived from it without the prior permission of the
content owner or service provider.
You acknowledge and agree explicitly that you will
solely bear the risk associated with the use of this
device, and further you will solely bear any risk
related to satisfactory quality, performance and
accuracy for any content and service accessed
through this device. To the maximum extent permitted
by applicable law, this device and any third party’s
content and service is provided as it is without any
guarantee, express or implied.
Figures and illustrations in this manual are provided for reference only and may differ from
actual product appearance.
Parts of the software function changes with the system upgrade.
If you encountered difficulty when setting up your TV, we suggest you refer to the
troubleshooting tips in the User Manual or the E-Manual.
Accessories List
The following accessories are included with TV:
Quick Setup Guide × 1 Remote Control × 1 Power Cord × 1
Base Stand × 2 Screw × 4
Contents
Installation ....................................................................................................................................... 1
Appearance and Connection ........................................................................................................... 3
Remote Control ............................................................................................................................... 5
Specifications .................................................................................................................................. 7
Other Information............................................................................................................................. 8
Manufacturer hereby declare explicitly that
Manufacturer shall not be held liable for any guarantee
and conditions, express or implied, related to this
device and any content and service, including but
not limited to warranty on marketability, satisfactory
quality, fitness for a particular purpose, accuracy,
quiet use and non-violation of any third party’s rights;
to the maximum extent permitted by applicable law,
Manufacturer gives no guarantee on the accuracy,
validity, timeliness, legitimacy and completeness of
any content or service provided through this device,
or the fitness of such device, content or service for
your particular requirement, or the protection from
interruption and error during operation of such device,
content or service; to the maximum extent permitted by
applicable law, in any case, including fault or neglect,
Manufacturer shall not be held liable for legal actions
or indemnity obligation arising from any consequence
as a result of or related to any information loaded in
this device or use of such device, content or service by
you or any third party.
This TV is equipped with a quick setup guide and embedded E-Manual (Settings > Support > E-Manual).
Find the E-Manual
E-Manual support functions
Find the help you are looking
for.
Search
Go directly to the function
page and try it.
Try Now
Scan to open the E-Manual
on your mobile device.
QR Code
B
Warning
Stability Hazard
A television set may fall, causing serious personal
injury or death. Many injuries, particularly to children,
can be avoided by taking simple precautions such
as:
ALWAYS use cabinets or stands or mounting
methods recommended by the manufacturer of
the television set.
ALWAYS use furniture that can safely support
the television set.
ALWAYS ensure the television set is not
overhanging the edge of the supporting furniture.
ALWAYS educate children about the dangers of
climbing on furniture to reach the television set
or its controls.
ALWAYS route cords and cables connected to
your television so they cannot be tripped over,
pulled or grabbed.
NEVER place a television set in an unstable
location.
NEVER place the television set on tall furniture
(for example, cupboards or bookcases) without
anchoring both the furniture and television set to
a suitable support.
Safeguards
Please read the following safeguards for your TV and
retain for future reference.
Always follow all warnings and instructions marked
on the television.
1. A note about safety and operating instructions
Read and follow all safety and operating instructions,
and retain them safely for future reference.
2. Heed Warnings
Adhere to all warnings on the appliance and in the
operating instructions.
3. Cleaning
Unplug the TV from the wall outlet before cleaning.
Do not use liquid, abrasive, or aerosol cleaners.
Cleaners can permanently damage the cabinet and
screen. Use a lightly dampened cloth for cleaning.
4. Wall Mount Bracket
Wall mount bracket is only available for some models.
If wall mount bracket is not supplied with this product,
you can buy it at the local market.
Please refer to the Installing the Wall Mount Bracket
page for dimensions.
5. Water and Moisture
Avoid dripping or splashing of liquids onto the
product. Objects filled with liquids, such as vases,
should not be placed above the product.
6. Setting
Do not place this TV on an unstable cart, stand or
table. Placing the TV on an unstable base can cause
the TV to fall, resulting in serious personal injuries
as well as damage to the TV. Use only a cart, stand,
bracket or table recommended by the manufacturer
or salesperson.
7. Ventilation
Slots and openings in the cabinet are provided for
ventilation, to ensure reliable operation of the TV
and to protect it from overheating. Do not cover
the ventilation openings in the cabinet and never
place the set in a confined space such as built-in
cabinet unless proper ventilation is provided. Leave a
minimum 10cm gap all around the unit, the rear of the
TV should be 6cm away from the wall.
8. Power Source
This TV should be operated only from the type of
power source indicated on the marking label. If you
are not sure of the type of power supplied to your
home, consult your appliance dealer or local power
company.
NEVER place the television set on cloth or other
materials that may be located between the
television set and supporting furniture.
NEVER place items that might tempt children
to climb, such as toys and remote controls, on
the top of the television or furniture on which the
television is placed.
If your existing television set is being retained or
relocated, the same considerations as above should
be applied.
This symbol alerts user about the presence
of a dangerous voltage not isolated inside
the product which can be sufficiently
powerful to constitute a risk of electrocution.
This symbol alerts user about the presence
of important operating instructions and
maintenance in the document enclosed in
the package.
ATTENTION
RISK OF ELECTRIC
SHOCK
Do not open the back cover.
In no case the user is allowed to operate inside
the TV set. Only a qualified technician is entitled
to operate.
Any content and service provided as it is together with
this device shall be the property of the applicable third
party, therefore Manufacturer gives no declaration or
warranty on modification, suspension, cancellation,
termination or abortion thereof, and shall not be held
liable for legal actions or indemnity obligation arising
thereof.
Manufacturer reserves the rights to restrict the use or
access of certain content or service. As the content
and service are transmitted through third party’s
network and transmission facilities, Manufacturer
undertakes no customer service thereof or the
obligation for such customer service.
C
To fully disconnect the TV, remove power
plug from wall socket. Be sure to have
the wall socket and power plug readily
accessible.
Do not mix and use new batteries with old
batteries, or batteries with different types. Do
not expose batteries to heat such as direct
sunlight or fire. Make sure the batteries'
positive and negative ends are facing the
correct direction.
The device should not be exposed to
dripping and spraying and it cannot be
placed under objects filled with liquids.
Class II product : This symbol indicates that
it does not require a safety connection of
protective earthing (ground).
AC voltage: This symbol indicates that the
rated voltage marked with the symbol is AC
voltage.
9. Power-Cord Protection
Power- supply cords should be routed so that they
are not likely to be walked on or pinched by items
placed upon or against them, paying particular
attention to cords at plug, wall outlets, and the point
where they exit from the TV. MAIN plug on the power
cord is used as the disconnect device, the disconnect
device and socket-outlet shall be easily accessible.
10. Lightning
For added protection for this TV during a lightning
storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet
and disconnect the antenna or cable system. This will
prevent damage to the TV due to lightning or power-
line surge.
11. Power Lines
An outside antenna system should not be located in
the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such
power lines or circuits. Where installing an outside
antenna system, extreme care should be taken to
keep from touching such power lines or circuits as
contact with them might be fatal.
12. Overloading
Do not overload wall outlets and extension cords as
this can result in a risk of fire or electric shock.
13. Object and Liquid Entry
Never push objects of any kind into this TV through
openings as they may touch dangerous voltage
points or short-out parts that could result in fire or
electric shock. Never spill liquid of any kind on or into
the TV.
14. Outdoor Antenna Grounding
If an outside antenna or cable system is connected
to the TV, be sure the antenna or cable system is
grounded so as to provide some protection against
voltage surges and built-up static charges.
15. Servicing
Do not attempt to service this TV yourself as opening
or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to
qualified service personnel.
16. Damage Requiring Service
Unplug the TV from the wall outlet and refer servicing
to qualified service personnel under the following
conditions:
(a) When the power - supply cord or plug is
damaged.
(b) If liquid has been spilled, or objects have fallen
into the TV.
(c) If the TV has been exposed to rain or water.
(d) If the TV does not operate normally by following
the operating instructions. Adjust only those
controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the TV to its normal operation.
(e) If the TV has been dropped or the cabinet has
been damaged.
(f) When the TV exhibits a distinct change in
performance - this indicates a need for service.
17. Replacement Parts
When replacement parts are required, be sure the
service technician has used replacement parts
specified by the manufacturer or have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock or other
hazards.
18. Safety Check
Upon completion of any service or repair to the TV,
ask the service technician to perform safety checks to
determine that the TV is in safe operating condition.
19. Heat
The product should be situated away from heat
sources such as radiators, heat registers, stoves,
or other products (including amplifiers) that produce
heat.
20. Fire
The product should be situated away from naked
flame sources such as lighted candle.
21. Off-gassing
The TV smells of plastic is normal and will dissipate
over time.
1
Follow the illustrations and textual instructions below to complete the installation steps:
Installation
Installing the stand
CAUTION
Be sure to disconnect the AC power cord before installing a stand or wall mount brackets.
The display on your TV is fragile. Make sure the TV screen is not scratched or damaged by hard
objects or from pressure.
After the installation is completed, make sure the TV is steady on a table or firmly attached to a
wall mount, before removing all protective film, if any.
1. One person holds the side of the TV, and the others remove the side cushions. Do not pinch
the screen when hold the TV.
2. Insert the TV base stands into the bottom slots on your TV. Use the screws provided to
secure each base stand tightly.
3. It takes three persons to transport the TV. The weight of TV with base stands is 140.0 lbs (63.5
kg), the furniture where the TV is placed should be tough enough to support. Please make
sure the width of the furniture is above 18.9 inches (480 mm).
NOTE: Three or more persons are needed to install the TV. One person holds the TV to prevent
tipping through the whole installation process.
side cushions
Base Stand
Screws:
M5×16
Base Stand
Screws:
M5×16
2
Please place the TV on a horizontally stable surface, and then use P-Clip to connect the TV and the
wall or pillar. (Marked in the illustration below.)
NOTE
Insecure installation may cause the tilt or falling of the product, and further lead to personal injuries
or product damages. If the method above can not fix the product, please consult the manufacturers.
P-clip and corresponding screws may not included with TV set, please purchase them by yourself if
necessary.
1. Fix the larger side of P-Clip to the screw hole on the back of TV set with a M8×30 screw.
2. Fix the other side of P-Clip to the wall or pillar.
P-Clip
Screw
Select a suitable screw hole based on
the actual situation.
Wall Mount Bracket
Wall Mount Screw
Wall Mount Spacer
Rear cover
of the TV
CAUTION
When mounting the TV on a wall, follow instructions provided with the wall mount bracket. If it is not
correctly mounted, the TV may fall and cause property damage or personal injury.
NOTE
The diameter and length of the screws differ depending on the wall mount bracket model.
Wall mount bracket is optional. Your TV may not have wall mount bracket. Please refer to the
actual accessories.
Place spacers between the TV and bracket.
Standard dimensions are shown below.
We do not recommend hanging the TV on a slanted wall, and when
wall mounting make sure your television remains parallel to the wall
and does not lean forward.
TV screen
Vertical
surface
Wall mount hole pattern
(mm)
800 × 400
Wall mount screw size M8
Number of wall mount screw 4
11.0 - 13.0 mm
Installing the P-Clip
Installing the wall mount bracket
Before mounting the TV, remove the TV stand if you have already attached it, and make sure the
wall mount bracket supports the weight of your TV.
screw hole
3
Appearance and Connection
• Power indicator
• Power button(Standby/Source)
• Light sensor
• MIC
• Voice indicator
• Built-in microphone control button
Item Description
Power indicator The light is white in standby mode.
Power button
(Standby / Source)
Press the button to turn the TV on. Press it again to bring up
the control menu and move the focus between different inputs.
Long press the button to make a selection.
Light sensor
The light-sensing function automatically adjusts the TV's
backlight brightness to match the ambient light levels in the
room, providing an optimised viewing experience. To enable or
disable light sensor, please go to Settings > Picture > Picture
Mode Settings > Advanced Settings > Brightness > Light
Sensor settings, and toggle on or off Automatic Light Sensor
as needed.
Built-in microphone
control button
To use Hands-Free Wake-up
,
first turn on the built-in
microphone control button.
ANT (DVB-T/T2/C) Connect an outdoor VHF/UHF antenna or cable.
ANT (DVB-S/S2) Connect an outdoor Satellite antenna.
HDMI Connect an HDMI cable from an external equipment.
HDMI (eARC)
Connect an HDMI cable from an external digital audio system.
Please note that it works only when the TV is connected to the
audio receiver that supports the eARC function.
AV IN
Connect a composite video cable and left-right audio cables
from an external AV device.
DIGITAL AUDIO OUT
Connect an optical cable from an external digital audio
system.
AC INPUT
4
USB
Connect a USB device for browsing photos, listening to music and
watching movies.
Note:
When connecting a hard disk or a USB hub, always connect the
mains adapter of the connected device to the power supply. If a
USB 1.1 or USB2.0 device requires more than 500mA or 5V, the
USB device may not be supported. Max supported current for USB
3.0 device is 1A
(only for some models). Exceeding the max
supported current may result in damage or data loss.
Certain digital cameras may not be compatible with the TV.
LAN Connect an Ethernet cable to access a network or the Internet.
COMMON INTERFACE
Insert the CI+ module for watching scrambled services like pay-tv
channels or some HD channels.
Note:
Do not repeatedly insert or remove the Common Access Module as
this may damage the interface and cause a malfunction.
You must obtain a CI+ module and card from the service provider of
the channels you want to watch.
CI+ is not supported in some countries and regions.
HEADPHONE
Connect headphone for audio out of the TV.
Note: Excessive sound pressure from earphones and headphones
can cause hearing loss.
NOTE
ANT2 Jack supports power supply for satellite antenna (13/18V, 420mA max).
DVB-S/S2 may not be applicable in some models/countries/regions.
Check the jacks for position and type before making any connections. Loose connections can
result in image or colour problems. Make sure that all connections are tight and secure.
Not all A/V devices have the ability to connect to a TV, please refer to the user’s manual of
your A/V device for compatibility and connections procedure.
Before connecting external equipment, remove the mains plug from the wall socket.
Otherwise, it may cause electric shock.
Powering on the TV requires several seconds to load programmes. Do not rapidly turn the TV
off as it may cause the TV work abnormally.
The Picture is Only for Reference.
Before using Hands-Free Wake-up, connect your TV to the network. The Hands-Free Wake-
up and some of its features are available on limited country/region/language.
The location and names of the terminals on the TV may vary according to TV model, and not
all terminals available on all models.
5
Remote Control
Buttons of remote control
NOTE
The included remote control will vary depending on model, country/region. Check information
according to the actual remote control in the accessory bag.
Buttons listed here are for reference only. Actual remote control may vary depending on
model, country/region.
BUTTON DESCRIPTION
Power on/Standby
Home Open V Home experience
Four colour buttons Special function buttons
Press to enter Menu
Activate AI assistant. This feature cannot be enabled in some scenarios.
Playpad keys
(˄
/
˅
/
˂
/
˃)
D-pad (up/down/left/right navigation buttons); when watching TV pro-
grammes, press left or right button to display the current programme
information
OK Conrmation button
Under the Menu or App, return to the previous place; for some models,
long press to be used as EXIT
EXIT Exit the menu or exit the application
Mute and restore sound; for models with button, long press to be
used as SUBTITLE
Display the Home screen
Select input sources
VOL Volume (up/down)
CH Channel (up/down)
Activate the microphone
Number button Select a channel or input numbers
SUBTITLE Activate or deactivate the subtitle mode
GUIDE
Display the Electronic Programme Guide; for models with
button,
long press to be used as CH.LIST
CH.LIST Display the Channel List on the screen
INFO
Display the current programme information; for models with
button, long press to be used as TEXT
TEXT Turn on/o the teletext function
Custom button, provides quick access to its user-dened function
APP buttons Quick access buttons to APP
6
Charging the Remote Control (for solar powered remote)
You can charge the remote by exposing the solar cell to
light or using a USB
type-C cable(not provided).
The type-C port is used for quick charging. When charging
by type-C port, the red indicator will blink. When fully
charged, the indicator will stop blinking first and then turn off.
solar cell
type-C port
(5V,
≥
500mA)
NOTE
Product image is only for reference, actual product may vary in appearance.
The battery is not user replaceable. Do not try to remove or change the internal battery by
yourself, cause it may cause damage to the battery/device, personal injury, fire or explosion.
When you do not use the remote control, place it face up to make the solar cell expose to
light. This will extend the remote control's operating time.
Leaving a battery in an extremely high temperature surrounding environment that can result
in an explosion or the leakage of flammable liquid or gas.
Battery chemicals can cause a rash. If chemicals touch your skin, wash immediately.
Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery,
that can result in an explosion.
Place the remote control correctly to prevent it from falling down.
A battery subjected to extremely low air pressure that may result in an explosion or the
leakage of flammable liquid or gas.
Pairing the Remote Control (only for Bluetooth remote control)
Pair the remote to the TV after you power it on. Keep the remote control within 3 metres from the
TV. Press any button (except power and mic button) to pair.
NOTE
In special cases, press and hold [ ] button to pair.
If an unknown error occurred with the remote, then it could have been caused by interference.
Try to remove what's causing the interference and pair it again.
If an unknown error occurred in the remote control, please recharge by using type-C port and
activate the remote control.
The remote cannot be paired to the TV while the TV is in standby mode.
6m
8m
6m
6m
8m
6m
30° 30°
15°
15°
Remote Control Operation Range
1. The remote control can work at a distance of up to 8 metres
in
front of the TV set.
2. The remote control angle: taking the remote sensor as an
apex, 6 metres away, its controlled horizontal angle is within
±30°, while the vertical angle is within ±15°.
3. The operating distance may vary depending on the
brightness of the room.
Disposal of this unit
Product should not be damaged, dismantled or thrown in municipal waste.
It should be packed and handed over to authorised re-cycler.
7
Features, appearance and specifications are subject to change without notice.
Specications
Item
100"
Dimension (mm)
(W × H × D)
Without Stand 2229 × 1282 × 82
With Stand
2229 × 1317 × 480
Weight (kg)
Without Stand 62.0
With Stand 63.5
Active Screen Size
(Diagonal) (cm)
253
Audio power 15W × 2 + 20W + 5W × 2
Screen resolution 3840 × 2160
Power consumption Please refer to the rating label.
Power supply Please refer to the rating label.
Standby Power 0.5W
Receiving
systems
Analog PAL-D/K, B/G, I, SECAM-D/K, B/G
Digital DVB-T/T2, DVB-C, DVB-S/S2
Environmental conditions
Temperature: 5°C - 40°C
Humidity: 20% - 80% RH
Atmospheric pressure: 86 kPa - 106 kPa
HDMI Input
RGB / 60Hz (640×480, 800×600, 1024×768)
YUV / 60Hz (480i, 480p, 720p, 1080i, 1080p)
YUV / 50Hz (576i, 576p, 720p, 1080i, 1080p)
24Hz 25Hz 30Hz 50Hz 60Hz (3840×2160)
120Hz 144Hz 165Hz (3840×2160)
120Hz 144Hz 165Hz 240Hz 288Hz 330Hz (2560×1440)
120Hz 144Hz 165Hz 240Hz 288Hz 330Hz (1920×1080)
Wireless LAN Standards IEEE
802.11a/b/g/n/ac
8
Other Information
Packaging and electrical goods should be recycled appropriately, and not treated as household
waste. Please dispose of this equipment at your applicable collection point for the recycling of
electrical & electronic equipment waste. By ensuring the correct disposal of this product, you
will help prevent potentially hazardous to the environment and to human health, which could
otherwise be caused by unsuitable waste handling of this product. The recycling of materials
will help conserve natural resources. Please do not therefore dispose of your old electrical and
electronic equipment with your household waste. For more detailed information about recycling
of this product, please contact your local city office, your household waste disposal service or
the shop where you purchased the product.
Disposal of Used Electrical & Electronic Equipment
License
What is Freeview Plus?
Freeview Plus is a new television service delivered via broadband providing a state of the art Electronic
Program Guide (EPG) and seamless access to catch-up TV across the free-to-air networks with the simple
press of a button.
How does it work?
First ensure the TV is connected to internet and an antenna system. Then when you’re watching TV, you’ll
briey see a prompt at the top left of the screen. Press the ‘Green’ button on your remote to launch Freeview
Plus. More information about Freeview Plus can be found on http://www.freeview.com.au/
The terms HDMI, HDMI High-Denition Multimedia Interface, HDMI Trade dress
and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.
Dolby, Dolby Vision, Dolby Atmos, and the double-D symbol are registered
trademarks of Dolby Laboratories Licensing Corporation. Dolby Vision IQ is a
trademark of Dolby Laboratories Licensing Corporation. Manufactured under
license from Dolby Laboratories. Condential unpublished works. Copyright ©
2012-2024 Dolby Laboratories. All rights reserved.
Manufactured under license from IMAX Corporation. IMAX
®
is a registered trademark
of IMAX Corporation in the United States and/or other countries. For DTS patents,
see http://patents.dts.com. Manufactured under license from DTS Licensing Limited.
DTS and the DTS logo are registered trademarks or trademarks of DTS, Inc. in the
United States and other countries. © 2020 DTS, Inc. ALL RIGHTS RESERVED.
Manufactured under license from DTS, Inc. and/or its affiliates. For patents, see
https://xperi.com/dts-patents/. DTS, the DTS logo, DTS:X, and the DTS:X logo are
trademarks or registered trademarks of DTS, Inc. and/or its affiliates in the U.S.
and/or other countries. © DTS, Inc. and/or its affiliates. All rights reserved.
