Part# FSK 3085
Front Stacking Kit
(For Stacking Dryers on Washers)
Enclosed: 3pcs (2 sides + Front) + 4 Phillips Screws + 2 Allen Bolts + Allen Key
For Models: Washer - 822, 826, 828
Dryer - 850, 852, 866, 868
Allen Key
2 Allen Bolts
4 Phillips Screws
Do not attempt installation alone.
Incorrect installation can cause accidents or injuries.
Because of the dryer’s weight and height, at least two trained people are required.
Always follow safety guidelines and wear protective gloves and safety glasses.
Do not use stacking kits with gas dryers in unstable conditions (e.g., mobile homes).
Place the washer on a stable, level oor.
SAFETY
!
CONTENTS
Appliance Desk Inc.
5006 Steffani Lane, Houston, Texas, 77041, USA.
Tel: 1800-490-8018 Web: www.ApplianceDesk.com
Installation Instructions
3. Carefully place the dryer on top, sliding it into the side brackets.
2. Attach the left and right side brackets using the screws (included).
5. Secure the front bracket with 2 Bolts with Allen key (included).
To ensure safe and secure installation, please observe the instructions below.
4. Insert the front bracket and push it back into place.
1. Remove the 2 rear Phillips screws holding the washer’s top panel (reinstall after #2).
Self-tapping screws can be installed
without pre-drilled holes.
NOTE FOR SIDE BRACKETS
Start with high torque to create the hole,
then lower torque to prevent stripping.
