Watch Operation Guide 5744
1
MA2508-EB
OPUM-J
© 2025 CASIO COMPUTER CO., LTD.
Published: 8/2025
Sunrise and Sunset Times
Looking Up Today’s Sunrise and Sunset
Times
Looking Up Sunrise and Sunset Times by
Specifying a Day
Stopwatch
Measuring Elapsed Time
Measuring a Split Time
Timer
Using the CASIO WATCHES Phone App to
Configure Timer Settings
Setting the Timer Start Time
Using the Timer
Step Count
Counting Steps
Causes of Incorrect Step Count
Hand Alignment Adjustment
Using the CASIO WATCHES Phone App to
Adjust Hand Alignment
Adjusting Hand Alignment
Other Settings
Enabling the Button Operation Tone
Reflecting Altitude Differential in Activity
Measurements
Resetting Watch Settings
Specifications
Other Information
City Table
Summer Time Table
Supported Phones
Copyrights and Registered Copyrights
Troubleshooting
Precautions
Operating Precautions
User Maintenance
Battery Replacement
Mobile Link Precautions
Watch Operation Guide 5744
2
About This Watch
This section provides an overview of the watch
and introduces convenient ways it can be
used.
●
Watch Features
●
Phone Linking
The watch supports connection and
communication with a Bluetooth capable
phone.
●
World Time
World Time displays the current time in any
of 38 cities (38 time zones)* around the
globe and UTC.
* Subject to being updated when
connected with a phone.
●
Alarm
An alarm sounds whenever a time specified
by you is reached.
●
Digital Compass
You can use the Compass Mode to
determine the direction of north, and to
check your bearing to a destination.
●
Altitude Measurement
You can use this function to take an altitude
reading at your current location.
You can record the altitude, along with the
date and time of the measurement.
You can also measure the altitude
differential between two points.
●
Barometric Pressure Measurement
You can display the current barometric
pressure tendency, which helps you be on
the alert for noteworthy pressure changes.
●
Temperature Measurement
The watch can be used to take current air
temperature readings.
●
Viewing Altitude Records
You can view or delete records of altitude
measurements.
●
Sunrise and Sunset Times
You can look up the sunrise and sunset
times for a specified date.
●
Stopwatch
The stopwatch measures elapsed time in
1/100-second units for the first hour, and in
1-second units after that for up to 24 hours.
●
Timer
Countdown from a start time specified by
you. An alarm sounds when the countdown
reaches zero.
Important!
●
This watch is not a special-purpose
measuring instrument. Measurement
function readings are intended for
general reference only.
●
Whenever using the Digital Compass
of this watch for serious trekking,
mountain climbing, or other activities,
be sure to always take along another
compass to confirm readings. If the
readings produced by the Digital
Compass of this watch are different
from those of the other compass,
perform figure 8 calibration or 2-point
calibration of the watch compass to
ensure better accuracy.
ー
Compass readings and calibration
will not be possible if the watch is in
the vicinity of a permanent magnet
(magnetic accessory, etc.), metal
objects, high-voltage wires, aerial
wires, or electrical household
appliances (TV, computer,
cellphone, etc.)
l
Digital Compass
●
The watch’s altimeter function
calculates and displays relative
altitude based on barometric pressure
readings produced by its pressure
sensor. Because of this, altitude
values displayed by the watch may be
different from your actual elevation
and/or sea level elevation indicated for
the area where you are located.
Regular calibration in accordance with
the local altitude (elevation)
indications is recommended.
l
Altitude Measurement
Note
●
The illustrations included in this
operation guide have been created to
facilitate explanation. An illustration
may differ somewhat from the item it
represents.
General Guide
④
⑤
①③②
A Hour hand
B Second hand
C Minute hand
D Day of the week
E Month, day
A button
Pressing this button in the Timekeeping Mode
enters the Altimeter Mode.
B button
Press to connect with a paired phone.
C button
Pressing this button in the Timekeeping Mode
enters the Compass Mode.
D button
Pressing this button in the Timekeeping Mode
cycles between displays.
E button
Each press cycles between watch modes.
In any mode, hold down this button for at least
two seconds to return to the Timekeeping
Mode.
L button
Press to turn on illumination.
Watch Operation Guide 5744
3
Watch Face and Display
Indicators
④
⑥
③
⑧⑨⑩⑪⑫ ⑬⑭
⑦
②①
⑤
A The second hand points to [R] when the
watch is standing by for connection with a
phone.
B The second hand points to [C] when the
watch is connected with a phone.
C With 12 o’clock as the reference point, the
second hand indicates either north
(compass reading) or the approximate
angle differential from your current
location to a destination (Location
Indicator).
D The second hand indicates altitude/
barometric pressure differential.
E Flashes while the watch’s hands are
shifted for easier reading.
F Displayed when the indicated time is
summer time.
G Displayed when an alarm is turned on.
H Displayed during p.m. times while 12-hour
timekeeping is being used.
I
Displayed while Auto Light is enabled.
J Displayed while Mission Log is enabled.
K Displayed while barometric pressure
trend information is enabled.
L Shows the barometric pressure
measurement unit.
M Shows the altitude and distance
measurement unit.
N Appears when the hourly time signal is on.
●
Battery Replacement
When battery power goes low, will start
to flash and some functions will become
disabled. If continues to flash, replace
the battery.
Request battery replacement from a CASIO
service center or your original retailer.
Navigating Between Modes
Your watch has the modes shown below.
●
To return to the Timekeeping Mode from
any other mode, hold down (E) for at least
two seconds.
E
E
E
E
EE
EAEC
E
E
E
A
C
Altitude Record Recall
Mode
Thermometer Mode
Barometer Mode
Digital Compass ModeAltimeter Mode
Sunrise/Sunset Mode
Stopwatch Mode
Timer Mode
World Time Mode
Timekeeping Mode
Alarm Mode
Use the buttons in the illustration above to
navigate between modes.
Note
●
You can use CASIO WATCHES to
change the arrangement of modes, or
to delete or add modes.
l
Mode Customization
●
To perform operations with CASIO
WATCHES, you first need to pair the
watch with the phone where the app is
installed.
l
C
Pair the watch with a phone.
Watch Operation Guide 5744
4
Mode Overview
●
Timekeeping Mode
This mode shows the current time and date.
You can also configure settings to show a
barometric pressure graph, World Time, step
count, and/or sunrise and sunset times.
You can navigate between display screens by
pressing (D).
D
D
D
D
Day of the week, month, day
Hour, minute, second
Barometric pressure
graph, month, day
Step count
Barometric
pressure graph
Daily step
count
One second
later
Note
●
You can use CASIO WATCHES to
add the items below to the display.
You can also remove items from the
display and rearrange their display
locations.
ー
Year, month, day
ー
Barometric pressure graph
ー
World Time hour and minute
ー
Home City sunrise and sunset times
l
Customizing the Timekeeping
Mode Screen
●
To perform operations with CASIO
WATCHES, you first need to pair the
watch with the phone where the app is
installed.
l
C
Pair the watch with a phone.
Connecting with a Paired Phone to
Correct the Watch’s Time
Press (B).
l
Triggering Immediate Time Correction
Searching for a Paired Phone
Hold down (B) for about 5 seconds.
l
Phone Finder
●
Digital Compass Mode
Use this mode to take direction and bearing
angle readings.
l
Digital Compass
③
①
②
D
Remeasure
Display screen
navigation
Objective
A North indication
B Bearing at 12 o’clock
C Bearing angle at 12 o’clock
●
Altimeter Mode
Use this mode to take an altitude reading for
your current location.
l
Altitude Measurement
①
② ③
Remeasure
Display screen
navigation
A Altitude differential/current time seconds
B Altitude graph
C Altitude
●
Barometer Mode
Use this mode to take barometric pressure
readings at your current location.
l
Barometric Pressure Measurement
①
② ③
Remeasure
Display screen
navigation
A Barometric pressure differential/current
time seconds
B Barometric pressure graph
C Barometric pressure
●
Thermometer Mode
Use this mode to take temperature readings
at your current location.
l
Temperature Measurement
①
Remeasure
A Temperature
Watch Operation Guide 5744
5
●
Altitude Record Recall Mode
Use this mode to view altitude records.
l
Viewing Altitude Records
①
Data search
Data search
A Number of the record displayed last time
the Altitude Record Recall Mode was
used
●
Sunrise/Sunset Mode
Use this mode to check the sunrise and sunset
times for your Home City.
l
Sunrise and Sunset Times
⑤
③②
①
④
Date search
Date search
A Year, month, day
B Sunrise time
C Sunrise indicator
D Sunset time
E Sunset indicator
●
Stopwatch Mode
Use this mode to measure elapsed time.
l
Stopwatch
②①
③
Start/Stop
Split/reset
A Stopwatch minutes
B Stopwatch seconds
C Stopwatch: 1/100 second
●
Timer Mode
Use this mode to countdown from a desired
start time.
l
Timer
②①
③
Start/Stop
Reset
A Timer hours
B Timer minutes
C Timer seconds
●
Alarm Mode
The watch will beep when an alarm time is
reached.
l
Alarm
When the last screen was an alarm screen
②
②
③
①
Select alarm/
hourly time signal
Select alarm/
hourly time signal
On/off
When the last screen was the hourly time
signal screen
④
Select alarm/
hourly time signal
Select alarm/
hourly time signal
On/off
A Alarm number
B Alarm enabled/disabled
C Alarm hour/minute
D Hourly time signal enable/disable
●
World Time Mode
This mode shows the current time in 38 cities
and UTC (Coordinated Universal Time) time.
l
World Time
①
③
②
Select cityShow current city
Select city
A Home City time
B World Time City
C World Time City current time
Shifting the Hands
Hand shift moves the hands out of the way for
easy viewing of display information.
1. While holding down (L), press (E).
This shifts the analog hands to allow easy
viewing of display information.
2. To return the hands to their normal
timekeeping positions, hold down (L) as
you press (E) again, or press (E) to change
to another mode.
Note
●
The hands will resume normal
timekeeping automatically if you
change modes or if you leave the
watch with its hands shifted and do not
perform any operation for about one
hour.
Watch Operation Guide 5744
6
Viewing the Face in the Dark
The face of the watch can be illuminated for
viewing in the dark.
●
To illuminate the face manually
Pressing (L) turns on illumination.
●
Illumination turns off automatically if an
alarm starts to sound.
●
To illuminate the face when Auto Light
is enabled
If Auto Light is enabled, face illumination will
turn on automatically whenever the watch is
positioned at an angle of 40 degrees or more.
40
degrees
or more
Important!
●
Auto Light may not operate properly
when the watch is at a horizontal angle
of 15 degrees or greater from
horizontal as shown in the illustration
below.
●
Electro-static charge or magnetism
can interfere with proper auto light
operation. If this happens, try lowering
your arm and then angle it towards
your face again.
●
When moving the watch you may note
a slight rattling sound. This is due to
operation of the auto light switch,
which determines the current
orientation of the watch. It does not
indicate malfunction.
Note
●
Auto Light is disabled when any one of
the conditions below exists.
ー
While an alarm, timer alert, or other
beeper is sounding
ー
While a hand movement operation
is in progress
ー
While in the Compass Mode
●
Configuring the Auto Light Setting
Holding down (L) for at least three seconds in
the Timekeeping Mode toggles Auto Light
between enabled and disabled.
●
[LT] is displayed while Auto Light is
enabled.
●
If you do not disable it manually, Auto Light
remains enabled for approximately six
hours. After that, it becomes disabled
automatically.
On
●
Specifying the Illumination Duration
You can select either 1.5 seconds or three
seconds as the illumination duration.
1. Enter the Timekeeping Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Home City
3. Press (E) three times so [LT] is displayed.
4. Press (A) to toggle between the two
illumination duration settings.
[1]: 1.5-second illumination
[3]: 3-second illumination
5. Press (D) twice to exit the setting screen.
Useful Features
Pairing the watch with your phone makes a
number of the watch’s features easier to use.
Auto time correction
l
Auto Time Correction
12:30
Selection of More Than 300 World Time
cities
l
Configuring World Time Settings
Data transfer to a phone
l
Viewing Step Count Data
Watch Operation Guide 5744
7
Use your phone to check the distance and
bearing to a point in Location Memory
l
Checking the Distance and Bearing to a
Location Memory Point (Location Indicator)
Use your phone to record route waypoints
and their altitudes
l
Recording Waypoints and Their Altitudes
(Mission Log)
In addition, a number of other watch settings
can be configured using your phone.
To transfer data to a watch and to
configure settings, you first need to pair
the watch with your phone.
l
Getting Ready
●
Your phone needs to have the “CASIO
WATCHES” phone app installed to pair with
the watch.
Linking with a Phone
While there is a Bluetooth connection
between the watch and phone (Mobile Link),
the watch’s current time setting is corrected
automatically. You can also change the
watch’s other settings.
Note
●
This function is available only while
the CASIO WATCHES phone app is
running on the phone.
●
This section describes watch and
phone operations.
X
: Watch operation
Y
: Phone operation
Getting Ready
To use your watch in combination with a
phone, you first need to pair them. Perform the
steps below to pair the watch with a phone.
A
Install the app on your phone.
B
Configure Bluetooth settings.
C
Pair the watch with a phone.
●
A
Install the required app on your
phone.
In Google Play or the App Store, search for the
“CASIO WATCHES” phone app and install it
on your phone.
●
B
Configure Bluetooth settings.
Enable the phone’s Bluetooth.
Note
●
For details about setting procedures,
see your phone documentation.
●
C
Pair the watch with a phone.
1. Move the phone to be paired with close to
(within one meter of) the watch.
2.
Y
Tap the “CASIO WATCHES” icon.
3.
Y
Tap the of the “My Watch” tab.
4.
Y
Perform the operation shown on the
phone screen to register the watch to the
CASIO WATCHES phone app.
5.
X
Hold down (B) for at least two seconds
until the second hand points to [R].
When a connection is established
between the watch and phone, [APP] will
change to [OK], and the second hand will
move from [R] to [C].
At this time the time settings of your phone
and watch will be synced with each other.
●
To pair a watch that is already paired
with one phone to another phone, press
and hold (B) until the second hand
points to [R] twice.
●
If pairing fails, the watch returns to the
state it was in before starting this
procedure. Perform the pairing
procedure again from the beginning.
This completes the pairing operation.
Once paired, the smartphone and watch
automatically connect to synchronize the
watch’s time setting with that of the
smartphone.
Note
●
The first time you start up the CASIO
WATCHES phone app, a message
will appear on your phone asking if you
want to enable location information
acquisition. Configure settings to
allow background use of location
information.
Watch Operation Guide 5744
8
Auto Time Correction
The watch will connect with a phone at preset
times each day and adjust its time settings.
●
Using This Function
Your watch corrects its time setting four times
a day according to a preset schedule. If you
leave your watch in the Timekeeping Mode, it
will perform the correction operation
automatically as you go about your daily life,
without any operation required by you.
12:30
Important!
●
The watch may not be able to perform
auto time correction under the
conditions described below.
ー
While the watch is too far away from
its paired phone
ー
While communication is not possible
due to radio interference, etc.
ー
While the phone is updating its
system
ー
While the CASIO WATCHES phone
app is not running on the phone
Note
●
If the watch does not indicate the
correct time even if it is able to connect
with a phone, adjust the hand and day
indicator alignment.
l
Adjusting Hand Alignment
●
If there is a World Time City specified
with the CASIO WATCHES phone
app, its time will also be corrected
automatically.
●
The watch connects with the phone
and performs auto time correction at
around 12:30 a.m., 6:30 a.m., 12:30
p.m. and 6:30 p.m. The connection is
automatically terminated after auto
time correction is complete.
●
Triggering Immediate Time Correction
The watch’s time setting is corrected
automatically whenever you establish a
connection between the watch and a phone.
Whenever you want to trigger immediate time
correction, perform the procedure below to
connect with a phone.
1. Move the phone close to (within one meter
of) the watch.
2.
X
Press (B).
[TIME] flashes to indicate that the watch
has started the connection operation.
When a connection is established
between the watch and phone, [OK] will
appear, time information will be acquired,
and then the watch’s time setting will be
adjusted.
Trying to connect
Following time
adjustment
Note
●
You can perform the above operation
for time adjustment from any watch
mode.
●
The connection is terminated
automatically after time correction is
complete.
●
If time correction fails for some
reason, [ERR] will appear.
Mode Customization
You can use CASIO WATCHES to customize
modes by rearranging them on the screen,
and by deleting or adding modes.
Important!
●
You cannot perform mode
customization operations on the
watch. Use CASIO WATCHES to
configure settings.
The modes below can be rearranged or
deleted.
●
Barometer Mode
●
Thermometer Mode
●
Altitude Record Recall Mode
●
Sunrise/Sunset Mode
●
Stopwatch Mode
●
Timer Mode
●
Alarm Mode
●
World Time Mode
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Hold down (B) for at least two seconds
until the second hand points to [R] twice.
When a connection is established
between the watch and phone, [APP] will
change to [OK], and the second hand will
move from [R] to [C].
Trying to connect Connected
3.
Y
Perform the operations shown on the
phone screen to configure mode settings.
Watch Operation Guide 5744
9
Note
●
Increasing or decreasing the number
of modes may change mode functions
and/or settings.
●
Even if you remove the Barometer
Mode, you can still display the
barometric pressure graph on the
Timekeeping Mode screen.
●
Even if you remove the Sunrise/
Sunset Mode, you can still display
sunrise and sunset times on the
Timekeeping Mode screen.
●
To initialize Mode Customization
Important!
●
Initializing Mode Customization also
initializes watch settings.
Note
●
Mode Customization cannot be
initialized while Mission Log is
enabled.
1.
X
Enter the Timekeeping Mode.
l
Navigating Between Modes
2.
X
Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Home City
3.
X
Press (D).
This causes the seconds to flash.
Seconds
4.
X
Hold down (C) for at least five seconds.
Release it when [RESET] stops flashing.
This initializes Mode Customization.
5.
X
Press (D) to exit the setting screen.
Customizing the
Timekeeping Mode Screen
You can use CASIO WATCHES to rearrange
display items on the Timekeeping Mode, and
to add or remove items.
Important!
●
Note that you cannot use watch
operations to configure display item
settings. Use CASIO WATCHES to
configure settings.
The items below can be displayed.
●
Day of the week, month, day
●
Year, month, day *
●
Barometric pressure graph, month, day
●
Barometric Pressure Graph *
●
Hour, minute, second
●
World Time hour, minute *
●
Step count
●
Home Time City sunrise/sunset times *
* Item that can be added using CASIO
WATCHES. These items are not displayed
under initial default settings.
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Hold down (B) for at least two seconds
until the second hand points to [R] twice.
When a connection is established
between the watch and phone, [APP] will
change to [OK], and the second hand will
move from [R] to [C].
Trying to connect Connected
3.
Y
Perform the operations shown on the
phone screen to configure mode settings.
Watch Operation Guide 5744
10
Viewing Step Count Data
The CASIO WATCHES phone app can be
used to view the information below, which is
measured by the watch.
●
24-hour step count, calories burned
●
Weekly step count, calories burned
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Hold down (B) for at least two seconds
until the second hand points to [R] twice.
When a connection is established
between the watch and phone, [APP] will
change to [OK], and the second hand will
move from [R] to [C].
Trying to connect Connected
3.
Y
Follow the instructions on the screen to
display pedometer data.
Note
●
You can also use CASIO WATCHES
to specify a daily step target.
●
Though the step count is displayed on
the watch in real time, CASIO
WATCHES displays step counts at
the time when a connection is
established between the watch and
phone. Because of this, the step
counts displayed by CASIO
WATCHES may be different from
those displayed by the watch.
Recording Your Current
Location (Location Memory)
You can use CASIO WATCHES to record
current location information.
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Enter the Timekeeping Mode or
Compass Mode.
l
Navigating Between Modes
3.
X
Hold down (C) for at least five seconds
until [MEMORY] starts to flash. Release
the button when the second hand points
to [R] twice.
If location information is successfully
acquired after a connection is established
between the watch and phone,
[MEMORY] will change to [OK], and the
second hand will move from [R] to [C].
●
[ERR] will appear on the display if
connection fails for some reason.
●
[FAILED]
n
[POSITION] will appear in
sequence if location information
acquisition fails for some reason.
Trying to connect Connected
4.
Y
Perform the operation shown on the
phone screen to view the Location
Memory information record.
●
You can have only one location record
in memory. Saving location information
while there is already a location record
in memory will overwrite the existing
record with the new information.
Note
●
You can use the CASIO WATCHES
phone app to change the information
recorded in Location Memory to
something else. Note that this
operation is not supported while the
watch is being used inside of China.
●
If there is location information stored
in Location Memory, you can use
Location Indicator to check the
distance and bearing to the stored
location.
l
Checking the Distance and
Bearing to a Location Memory
Point (Location Indicator)
Checking the Distance and
Bearing to a Location
Memory Point (Location
Indicator)
The watch acquires current location
information from the phone, and then displays
the bearing and distance from your current
location to the location recorded in Location
Memory.
l
Recording Your Current Location (Location
Memory)
Bearing to memory point
Distance to memory point
Memory point
Important!
●
Note that CASIO WATCHES
operation is disabled while Location
Indicator is in use.
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Enter the Timekeeping Mode or
Compass Mode.
l
Navigating Between Modes
Watch Operation Guide 5744
11
3.
X
Hold down (C) for at least two seconds
until [INDICATE] starts to flash. Release
the button when the second hand moves
to [R].
When a connection is established
between the watch and phone and
location information acquisition is
successful, [INDICATE] will change to
[OK], and the second hand will move from
[R] to [C].
After two seconds the distance from your
current location to the recorded location
will appear on the display, and the second
hand will indicate the bearing to the
destination.
*2
Distance from your current
location
Bearing to destination
After two seconds
*1
Second hand
*1
When the second hand is within the range
between 55 seconds to 05 seconds
(indicating that you are within 30 degrees
of the bearing to the destination), [
] will
be displayed as a light figure on a dark
background.
*2
[G] is shown on the display when you are
within 80 meters of the destination. [G] will
disappear from the display if you move to
a distance of 161 meters or more from the
destination.
4.
X
Check the display distance and the
bearing to your destination on the display.
Note
●
Location Indicator remains enabled
for three minutes.
●
The watch connects with the phone
and acquires location information
every 10 seconds or each time (B) is
pressed, and uses the information to
refresh the distance and the bearing to
the point stored in Location Memory.
●
Location Indicator will become
disabled automatically about three
minutes after it is enabled. You can
also disable it manually by pressing
any button besides (B) or (L).
●
Pressing (B) or (L) while Location
Indicator is enabled will cause it to
remain enabled for three minutes after
the button is pressed.
●
Pressing (B) to update data causes [
TRY] to appear on the display and
remain displayed until data updating is
complete.
●
[
FAIL] will appear on the display in
the cases below.
ー
When it has been 30 seconds or
more since the last update and
location information acquisition fails
ー
When it has been 60 seconds or
more since the last update
ー
When data acquisition fails after
you press (B)
●
The display range for the distance to
a destination is 0 to 99,999 meters (0
to 327,995 feet). [
-----] will be
shown for the distance to the
destination when it is outside the
display range.
●
[ERR] will appear on the display if
connection fails for some reason.
●
The message [NO-DATA] will appear
when there is no data in Location
Memory.
●
[FAILED]
n
[POSITION] will appear
in sequence if the first location
information acquisition fails.
●
[
] or [G] will flash on the display if the
watch detects abnormal magnetism
while Location Indicator is in use.
●
[
ERR] will appear on the display if
a direction sensor error occurs while
Location Indicator is in use.
Auto Altitude Calibration
Enabling auto altitude calibration with CASIO
WATCHES will cause altitude values to be
acquired by CASIO WATCHES, which will be
used to automatically correct the watch’s
altitude reading.
Important!
●
Use CASIO WATCHES to enable or
disable auto altitude calibration. It
cannot be enabled or disabled on the
watch.
Note
●
If an altitude value acquired by CASIO
WATCHES satisfies accuracy
conditions, the watch will
automatically correct is altitude
reading.
●
Auto altitude calibration is performed
at the same time as auto time
correction.
●
Auto altitude calibration is not
performed for 12 hours after the time
setting is adjusted manually.
Watch Operation Guide 5744
12
Recording Waypoints and
Their Altitudes (Mission Log)
Mission Log uses CASIO WATCHES GPS to
record the waypoints of your routes. At the
same time, the watch takes altitude readings
every two minutes and stores them in memory,
and automatically transfers altitude data to
CASIO WATCHES every hour.
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Enter the Timekeeping Mode or
Altimeter Mode.
l
Navigating Between Modes
3.
X
Hold down (A) for at least five seconds
until [LOG] starts to flash. Release the
button when the second hand moves to
[R].
When a connection is established
between the watch and phone, [LOG] will
change to [LOG ON], and the second
hand will move from [R] to [C].
●
This indicates that Mission Log is
enabled.
Trying to connect Connected
●
To disable Mission Log, hold down (A)
again for at least five seconds.
Note
●
[LOG] is displayed while Mission Log
is enabled.
●
Mission Log becomes disabled
automatically 12 hours after it is
enabled.
●
Mission Log remains enabled even if
you change to another mode.
●
The watch has enough memory to
hold up to 60 altitude records.
Recording data when there are
already 60 records in memory will
automatically delete the oldest record
to make room for the new one.
●
Data Transfer
After Mission Log is enabled, data transfer
starts when the number of altitude records in
watch memory reaches 30.
●
Auto data transfer is performed during the
normal state of each mode.
The display cycles as shown below as data is
being transferred.
●
The second hand will point to [R].
●
If data transfer fails for some reason, the
watch will return to the previous screen with
[LOG] flashing.
Note
●
If auto transfer fails for some reason,
the watch will keep trying up to five
times at 10-minute intervals. Or data
is transferred when a CASIO
WATCHES connection is established.
Configuring World Time
Settings
Specifying a World Time City with the CASIO
WATCHES phone app causes the watch’s
World Time City to change accordingly. The
standard time/summer time setting of the
World Time will be corrected automatically
without any watch operation required by you.
Note
●
The CASIO WATCHES phone app
World Time lets you select from
among approximately 300 cities as
the World Time City.
●
To select a World Time City
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Hold down (B) for at least two seconds
until the second hand points to [R] twice.
When a connection is established
between the watch and phone, [APP] will
change to [OK], and the second hand will
move from [R] to [C].
●
If connection fails for some reason,
[ERR] will appear on the display
momentarily and then the watch will
return to the mode it was in before you
started the connection procedure.
Trying to connect Connected
3.
Y
Perform the operation shown on the
phone screen. The World Time setting will
be reflected on the watch.
Note
●
You can use CASIO WATCHES to
configure settings for user cities that
are not included in the watch’s built-in
World Time Cities. You must use
CASIO WATCHES to select a user
city as your World Time City.
Watch Operation Guide 5744
13
●
Configuring the Summer Time Setting
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Hold down (B) for at least two seconds
until the second hand points to [R] twice.
When a connection is established
between the watch and phone, [APP] will
change to [OK], and the second hand will
move from [R] to [C].
●
If connection fails for some reason,
[ERR] will appear on the display
momentarily and then the watch will
return to the mode it was in before you
started the connection procedure.
Trying to connect Connected
3.
Y
Perform the operation shown on the
phone screen to select a summer time
setting.
●
“Auto”
The watch switches between standard
time and summer time automatically.
●
“OFF”
The watch always indicates standard
time.
●
“ON”
The watch always indicates summer
time.
Note
●
While the summer time setting is
“Auto”, the watch switches between
standard time and summer time
automatically. You do not need to
switch between standard time and
summer time manually. Even if you
are in an area that does not observe
summer time, you can leave the
watch’s summer time setting as
“Auto”.
●
For information about summer time
periods, refer to the “Summer Time
Table”.
●
Swapping Your World Time and Home
Time
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Hold down (B) for at least two seconds
until the second hand points to [R] twice.
When a connection is established
between the watch and phone, [APP] will
change to [OK], and the second hand will
move from [R] to [C].
●
If connection fails for some reason,
[ERR] will appear on the display
momentarily and then the watch will
return to the mode it was in before you
started the connection procedure.
Trying to connect Connected
3.
Y
Perform the operation shown on the
phone screen to swap your Home Time
with your World Time.
Note
●
Auto time correction does not work for
24 hours after swapping the Home
Time and World Time.
Adjusting Hand Alignment
If the hands are out of alignment even though
auto time correction is being performed, you
can use the CASIO WATCHES phone app to
adjust them.
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Hold down (B) for at least two seconds
until the second hand points to [R] twice.
When a connection is established
between the watch and phone, [APP] will
change to [OK], and the second hand will
move from [R] to [C].
●
If connection fails for some reason,
[ERR] will appear on the display
momentarily and then the watch will
return to the mode it was in before you
started the connection procedure.
Trying to connect Connected
3.
Y
Perform the operation shown on the
phone screen to correct hand alignment.
Watch Operation Guide 5744
14
Phone Finder
You can use phone finder to trigger a tone on
the phone to make it easy to find. The tone is
forced to sound even if the phone is in vibrate
mode.
Important!
●
Do not use this function in areas where
phone call tones are restricted.
●
The tone sounds at a high volume. Do
not use this function when listening to
phone output over earphones.
1.
X
If the watch is connected with a phone,
press any button besides (L) to terminate
the connection.
●
After the connection is terminated, the
watch will return to the mode it was in
before connection was established.
Example: After connecting from the
Timekeeping Mode
Connected Disconnected
2.
X
Hold down (B) for at least five seconds
until the second hand points to [R] three
times.
The phone sounds a tone when it
establishes a connection with the watch.
●
It takes a few seconds before the phone
tone sounds.
ConnectedSearching for phone
3.
X
Press any button besides (L) to stop the
tone.
●
You can press any watch button to stop
the phone tone only during the first 30
seconds after it starts to sound.
Configuring Watch Settings
You can use CASIO WATCHES to configure
the settings below.
●
Timer start time
●
Alarm
●
Altimeter
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Hold down (B) for at least two seconds
until the second hand points to [R] twice.
When a connection is established
between the watch and phone, [APP] will
change to [OK], and the second hand will
move from [R] to [C].
●
If connection fails for some reason,
[ERR] will appear on the display
momentarily and then the watch will
return to the mode it was in before you
started the connection procedure.
Trying to connect Connected
3.
Y
Select the setting you want to change
and then perform the operation shown on
the phone screen.
Changing the Home City
Summer Time Setting
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Hold down (B) for at least two seconds
until the second hand points to [R] twice.
When a connection is established
between the watch and phone, [APP] will
change to [OK], and the second hand will
move from [R] to [C].
●
If connection fails for some reason,
[ERR] will appear on the display
momentarily and then the watch will
return to the mode it was in before you
started the connection procedure.
Trying to connect Connected
3.
Y
Perform the operation shown on the
phone screen to change your Home City
summer time setting.
Watch Operation Guide 5744
15
Connection
Connecting with a Phone
This section explains how to establish a
Bluetooth connection with a phone that is
paired with the watch.
●
If the watch is not paired with the phone you
want to connect with, refer to the information
below and pair them.
l
C
Pair the watch with a phone.
1. Move the phone close to (within one meter
of) the watch.
2.
X
Hold down (B) for at least two seconds
until the second hand points to [R] twice.
When a connection is established
between the watch and phone, [APP] will
change to [OK], and the second hand will
move from [R] to [C].
●
If connection fails for some reason,
[ERR] will appear on the display
momentarily and then the watch will
return to the mode it was in before you
started the connection procedure.
Trying to connect Connected
Important!
●
If you have problems establishing a
connection, it could mean that CASIO
WATCHES is not running on the
phone. On the phone’s Home Screen,
tap the “CASIO WATCHES” icon. After
the app starts up, hold down the
watch’s (B) button for at least two
seconds.
Note
●
The connection is terminated if you do
not perform any operation on the
watch or phone for a fixed amount of
time.
To specify the connection limit time,
perform the following operation with
the CASIO WATCHES phone app:
“Watch settings”
n
“Connection time
with the app”. Next, select a setting of
3 minutes, 5 minutes, or 10 minutes.
Canceling a Connection with a
Phone
To terminate a Bluetooth connection, press
any watch button besides (L).
●
After the connection is terminated, the
watch will return to the mode it was in before
connection was established.
Example: After connecting from the
Timekeeping Mode
Connected Disconnected
Using the Watch in a Medical Facility
or Aircraft
Whenever you are in a hospital, on an aircraft,
or in any other location where connection with
a phone may cause problems, you can
perform the procedure below to disable auto
time correction. To re-enable auto time
correction, perform the same operation again.
1.
Y
Tap the “CASIO WATCHES” icon.
2.
X
Hold down (B) for at least two seconds
until the second hand points to [R] twice.
When a connection is established
between the watch and phone, [APP] will
change to [OK], and the second hand will
move from [R] to [C].
●
If connection fails for some reason,
[ERR] will appear on the display
momentarily and then the watch will
return to the mode it was in before you
started the connection procedure.
Trying to connect Connected
3.
Y
Perform the operation shown on the
phone screen to enable or disable auto
time correction.
Unpairing
To unpair the watch from a phone, delete the
pairing information from the CASIO
WATCHES phone app, the phone, and the
watch.
●
Deleting Pairing Information from the
CASIO WATCHES phone app
1.
X
If the watch is connected with a phone,
press any button besides (L) to terminate
the connection.
●
After the connection is terminated, the
watch will return to the mode it was in
before connection was established.
Connected Disconnected
2.
Y
Tap the “CASIO WATCHES” icon.
3.
Y
Perform the operation shown on the
phone screen to unpair.
Watch Operation Guide 5744
16
●
Deleting Pairing Information from the
Watch
1.
X
Hold down (E) for at least two seconds
to enter the Timekeeping Mode.
2.
X
Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Home City
3.
X
Press (D).
This causes the seconds to flash.
Seconds
4.
X
Hold down (C) for at least two seconds.
Release it when [PAIR CLR] stops
flashing.
This deletes the pairing information from
the watch.
5.
X
Press (D) to return to the Timekeeping
Mode.
Important!
●
Pairing information cannot be deleted
from watch memory while Mission Log
is enabled.
l
Recording Waypoints and Their
Altitudes (Mission Log)
●
Deleting the phone’s pairing
information
For details about setting procedures, see your
phone documentation.
“Settings”
n
“Bluetooth”
n
Cancel the
watch’s device registration.
If you purchase another phone
You need to perform the pairing operation
whenever you want to establish a Bluetooth
connection with a phone for the first time.
l
C
Pair the watch with a phone.
Time Correction
Your watch can connect with a phone to obtain
information that it uses to correct its date and
time setting.
Important!
●
Disable auto time correction while on
an aircraft or in any other place where
connecting to a smartphone is not
allowed.
l
Using CASIO WATCHES to
Configure Settings
l
Using Watch Operations to
Configure Settings
Referring to the information below, configure
the time setting in accordance with the method
that suits your own lifestyle.
Do you use a phone?
Time correction by connecting with your
phone is recommended.
l
Auto Time Correction
12:30
If your phone cannot connect with the
watch
You can correct time settings by
performing operations on the watch.
l
Using Watch Operations to Adjust the
Time Setting
Using Watch Operations to
Adjust the Time Setting
If your watch cannot connect with a phone for
some reason, you can use watch operations
to adjust date and time settings.
●
Setting a Home City
Use the procedure in this section to select a
city to use as your Home City. If you are in an
area that observes summer time, you can also
enable or disable summer time.
Note
●
The initial factory default summer time
setting for all cities is [AUTO]. In many
cases, the [AUTO] setting lets you use
the watch without switching between
summer time and standard time.
1. Enter the Timekeeping Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Home City
3. Use (A) and (C) to change the Home City.
●
For details refer to the information
below.
l
City Table
4. Press (E).
5. Use (A) to select a summer time setting.
Each press of (A) cycles through available
settings in the sequence shown below.
●
[AUTO]
The watch switches between standard
time and summer time automatically.
●
[OFF]
The watch always indicates standard
time.
●
[ON]
The watch always indicates summer
time.
6. Press (D) twice to exit the setting screen.
Watch Operation Guide 5744
17
●
Setting the Time/Date
1. Enter the Timekeeping Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Home City
3. Press (D).
This causes the seconds to flash.
4. Keep pressing (E) until the setting item
you want to change is selected.
●
Each press of (E) moves to the next
setting item in the sequence shown
below.
Day
Month
Ye a r
Minutes
Hours
Seconds
5. Configure the date and time settings.
●
To reset the seconds to 00: Press (A). 1
is added to the minutes when the
current count is between 30 and 59
seconds.
●
Use (C) and (A) to change the other
settings.
6.
Repeat steps 4 and 5 to configure time
and date settings.
7. Press (D) to exit the setting screen.
●
Switching between 12-hour and 24-
hour Timekeeping
You can specify either 12-hour format or 24-
hour format for the time display.
1. Enter the Timekeeping Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Home City
3. Press (E) four times.
This causes [12H] or [24H] to flash on the
display.
4. Press (A) to toggle the setting between
[12H] (12-hour timekeeping) or [24H] (24-
hour timekeeping).
24-hour timekeeping12-hour timekeeping
5. Press (D) twice to exit the setting screen.
Using the Watch in a Medical
Facility or Aircraft
Whenever you are in a hospital, on an aircraft,
or in any other location where connection with
a phone may cause problems, you can
perform the procedure below to disable auto
time correction. To re-enable auto time
correction, perform the same operation again.
1. Enter the Timekeeping Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Home City
3. Press (E) five times.
This displays [RCV].
4. Press (A) to change the auto time
correction setting.
[OFF]: Auto time correction disabled.
[ON]: Auto time correction enabled.
5. Press (D) twice to exit the setting screen.
Note
●
If the watch is paired with a phone, you
can use the CASIO WATCHES phone
app to disable auto time correction.
l
Using CASIO WATCHES to
Disable Auto Time Correction
Watch Operation Guide 5744
18
World Time
World Time lets you look up the current time
in any one of 38 cities around the globe, and
UTC (Coordinated Universal Time).
Using the CASIO WATCHES
Phone App to Configure
World Time City Settings
If the watch is paired with a phone, you can
also use the CASIO WATCHES phone app to
set the World Time city.
l
Configuring World Time Settings
Note
●
World Time cities that can be selected
only by using the CASIO WATCHES
phone app cannot be selected using
watch operations.
Checking World Time
1. Enter the World Time Mode.
l
Navigating Between Modes
After the currently selected World Time
City name appears, the watch will display
the current time in that city.
●
To display the World Time City name
while in the World Time Mode, press
(D).
World Time City
World Time
World Time City Setting
Use the procedure in this section to select a
World Time city. If you are in an area that
observes summer time, you can also enable
or disable summer time.
Note
●
The initial factory default summer time
setting for all cities is [AUTO]. In many
cases, the [AUTO] setting lets you use
the watch without switching between
summer time and standard time.
1. Enter the World Time Mode.
l
Navigating Between Modes
2. Use (A) and (C) to display the city you
want.
3. To change the summer time setting, hold
down (D) for at least two seconds.
Release the button when [AUTO], [OFF],
or [ON] starts to flash.
4. Use (A) to select a summer time setting.
Each press of (A) cycles through available
settings in the sequence shown below.
●
[AUTO]
The watch switches between standard
time and summer time automatically.
●
[OFF]
The watch always indicates standard
time.
●
[ON]
The watch always indicates summer
time.
5. Press (D) to exit the setting screen.
Note
●
While [UTC] is selected as the city,
you will not be able to change or check
the summer time setting.
●
If you select a World Time City with the
CASIO WATCHES phone app and
then change to a different city with a
watch operation, the CASIO
WATCHES city information is deleted
from the watch.
l
Configuring World Time Settings
●
Specifying UTC (Coordinated Universal
Time) as Your World Time City
In the World Time Mode, pressing (A) and (C)
at the same time will set UTC (Coordinated
Universal Time) as the World Time City and
display its current time.
Swapping Your Home City
Time and World Time
In the World Time Mode, hold down (L) for at
least two seconds until starts to
flash and the hands start to move.
This will swap your Home City Time and World
Time.
After swappingBefore swapping
World Time
World Time Home Time
Home Time
Note
●
This function comes in handy when
you need to move to another time
zone. For details about how to use it,
go to the section below.
l
International Travel
Watch Operation Guide 5744
19
International Travel
Use the procedure below to easily change day
and time settings of the watch to a destination
location.
●
Before Boarding
1. Configure the World Time to the current
time at your destination.
Destination time
Current time
l
Using CASIO WATCHES to Configure
Settings
l
Using Watch Operations to Configure
Settings
2. Disable auto time correction.
l
Using CASIO WATCHES to Configure
Settings
l
Using Watch Operations to Configure
Settings
●
After Arriving
1. Swap the origin time zone time with the
destination time zone time.
After swappingBefore swapping
Destination time
Destination time
l
Using CASIO WATCHES to Configure
Settings
l
Using Watch Operations to Configure
Settings
2. Enable auto time correction.
l
Using CASIO WATCHES to Configure
Settings
l
Using Watch Operations to Configure
Settings
3. Correct the time setting.
l
Triggering Immediate Time Correction
Alarm
The watch beeps when an alarm time is
reached. You can set up to five different
alarms. The hourly time signal causes the
watch to beep every hour on the hour.
●
The beeper will not sound if battery power
is low.
Using the CASIO WATCHES
Phone App to Configure
Alarm Settings
If the watch is paired with a phone, you can
also use the CASIO WATCHES phone app to
set alarms.
l
Configuring Watch Settings
Configuring Alarm Settings
1. Enter the Alarm Mode.
l
Navigating Between Modes
2. Use (A) and (C) to display the number
([AL1] to [AL5]) of the alarm whose
settings you want to change.
Alarm number
Alarm time
Watch Operation Guide 5744
20
3. Hold down (D) for at least two seconds.
Release the button when the hour digits
start to flash.
●
The (alarm) indicator is displayed
when any alarm is turned on.
Hours
4. Use (A) and (C) to change the hour setting.
●
If you are using 12-hour timekeeping,
[P] indicates p.m.
5. Press (E).
This causes the minutes digits to flash.
Minutes
6. Use (A) and (C) to change the minute
setting.
7. Press (D) to exit the setting screen.
8. Hold down (E) for at least two seconds to
return to the Timekeeping Mode.
●
To stop the alarm
To stop the alarm after it starts to sound when
an alarm time is reached, press any button.
Note
●
A beeper sounds for 10 seconds when
an alarm time is reached.
Configuring the Hourly Time
Signal Setting
1. Enter the Alarm Mode.
l
Navigating Between Modes
2. Press (A) or (C) to display the hourly time
signal screen ([SIG]).
3. Press (D) to toggle the hourly time signal
between enabled (on) and disabled (off).
●
(hourly time signal) is shown on the
display while the hourly time signal is
enabled.
Turning Off an Alarm or the
Hourly Time Signal
To stop an alarm or the hourly time signal from
sounding, perform the steps below to turn it
off.
●
To have an alarm or hourly time signal
sound again, turn it back on.
Note
●
Indicators are displayed while any of
the alarms or the hourly time signal is
turned on.
●
The applicable indicators are not
displayed while all of the alarms are
turned off and/or the hourly time signal
is turned off.
Alarm
Hourly time signal
1. Enter the Alarm Mode.
l
Navigating Between Modes
2. Use (A) and (C) to scroll through alarm
numbers ([AL1] to [AL5]) and the hourly
time signal ([SIG]) screens until the one
whose setting you want to change is
displayed.
Alarm or hourly time signal
3. Press (D) to turn off an alarm or the hourly
time signal.
●
Each press of (D) toggles between on
and off.
●
Turning off all alarms will cause
(alarm) to disappear from the display,
while disabling the hourly time signal
causes (hourly time signal) to
disappear from the display.
Note
●
If (alarm) is still displayed, it
means that another alarm is still turned
on. To turn off all of the alarms, repeat
steps 2 and 3 until the
(alarm)
indicator is no longer displayed.
Watch Operation Guide 5744
21
Digital Compass
You can use the Digital Compass Mode to
determine the direction of north, and to check
your bearing to a destination.
Important!
●
Check the information at the link below
to find out how to ensure correct
readings.
l
Calibrating Compass Readings
l
Digital Compass Reading
Precautions
Taking a Compass Reading
1. Enter the Compass Mode.
l
Navigating Between Modes
●
Entering the Compass Mode starts
compass readings.
2. Keeping the watch level, point 12 o’clock
in the direction of your desired objective.
●
The second hand will point North. The
digital display will show one of 16 literal
direction indications or the bearing
angle.
●
You can toggle between literal direction
indications and bearing angle display
by pressing (D).
●
To retrigger the compass operation,
press (C).
Interpreting Bearing Readings
D
315°
0°
Bearing angle to objective
Bearing to objective
North
Objective
Bearing angle
Directions: N (North), E (East), W (West), S
(South)
Note
●
Normally the compass indicates
magnetic north. You can also
configure settings to indicate true
north.
l
Setting Up for True North
Readings (Magnetic Declination
Calibration)
l
Magnetic North and True North
●
After the initial reading is displayed,
the watch will continue to take
readings about every second for
about the next 60 seconds. The watch
will return to the Timekeeping Mode
automatically about 60 seconds after
you press (C).
●
Auto Light will not illuminate the face
while a compass operation is in
progress.
●
If an alarm or other beeper sounds, or
if you turn on illumination by pressing
(L) while a compass operation is in
progress, the compass operation will
be suspended momentarily. The
compass operation will resume when
the beeper stops or illumination turns
off.
●
You can use CASIO WATCHES to
record location information and then
use the watch to display the distance
and bearing to the recorded location.
l
Recording Your Current Location
(Location Memory)
l
Checking the Distance and
Bearing to a Location Memory
Point (Location Indicator)
●
Aligning a Map with Actual
Surroundings (Setting a Map)
Setting a map means to align the map so the
directions indicated on it are aligned with the
actual directions of your location. Once you
set a map, you can more easily get a grasp of
the relationship between map markings and
actual geographic contours. To set a map with
this watch, align north on the map with the
north indication of the watch. Once you set the
map, you can compare your bearing on the
map with your surroundings, which will help
you determine your current location and
destination.
●
Note that map reading skills and experience
are required to determine your current
location and destination on a map.
Watch Operation Guide 5744
22
Calibrating the Compass
Calibrating Compass Readings
Perform figure 8 or two-point calibration
whenever you notice the watch’s compass
readings are different from those of another
compass, or before setting out on a climb or
trek.
●
Note that accurate compass readings
and/or calibration will not be possible in an
area where strong magnetism is present.
l
Digital Compass Reading Precautions
Figure 8 calibration
1. Enter the Compass Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when [SET] starts
flashing and then
appears on the
display.
3. Press (C).
Move your arm in a figure 8 pattern as
shown in the illustrations below.
●
Allow your wrist to twist.
●
Keep your arm as far as possible from
your body as you move it.
●
The
symbol will stop flashing on
the display while calibration is in
progress.
●
When calibration is successful, [OK] will
appear on the display and the watch will
return to the Digital Compass screen.
This completes the calibration
operation.
Note
●
If [ERR] is displayed, press any button
besides (D) and then perform this
procedure again from step 3.
2-Point Calibration
1. Enter the Compass Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when [SET] starts
flashing and then
appears on the
display.
3. Press (E).
This causes [
o
1] to appear on the display.
4. While keeping the watch horizontal, press
(C).
This starts calibration of the first point,
which causes [WAIT] to appear on the
display. When calibration is successful,
indicators will appear on the display in the
following sequence: [OK]
n
[TURN]
n
[180°]
n
[
p
2].
5. Rotate the watch 180 degrees, taking care
to be as exact as possible.
6. Press (C).
●
This starts calibration of the second
point, which causes [WAIT] to appear
on the display.
●
When calibration is successful, [OK] will
appear on the display and the watch will
return to the Digital Compass screen.
This completes the calibration
operation.
Note
●
[ERR] will appear if calibration fails for
some reason. If this happens, restart
the above procedure from step 2.
Auto Calibration
Your watch performs auto bearing calibration.
●
When bearing calibration starts, the second
hand will move to 12 o’clock, and the digital
display contents will flash.
Second hand
Note
●
Auto bearing calibration is performed
when the conditions below exist.
ー
Watch is worn on the wrist.
ー
Watch is in the Timekeeping Mode.
ー
You are walking
●
After calibration is successful, auto
calibration will not be performed again
for 24 hours.
Setting Up for True North Readings
(Magnetic Declination Calibration)
If you want the watch to indicate true north
instead of magnetic north, you need to specify
your current location’s magnetic declination
direction (east or west) and declination angle.
l
Magnetic North and True North
●
The magnetic declination angle value can
be set in 1° (degree) units only. Use a value
that is closest to the angle you want to set.
Example: For an angle of 7.4°, set 7°.
Example: For an angle of 7°40’ (7 degrees,
40 minutes), set 8°.
Note
●
Magnetic declination angles (east or
west) and angle degree values for
specific locations can be found on
geographic maps, mountain climbing
maps, and other maps that include
contour lines.
Watch Operation Guide 5744
23
1. Enter the Compass Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when [SET] starts
flashing and then
appears on the
display.
3. Press (E) twice.
[DEC] will appear on the display, followed
by [0°].
4. Use (A) (East) and (C) (West) to change
the magnetic declination direction and
angle.
Setting range: 90° west to 90° east
[0° (OFF)]: Magnetic north
[E]: East declination (Magnetic north is
east of true north.)
[W]: West declination (Magnetic north is
west of true north.)
●
To return the setting to [0° (OFF)], press
(A) and (C) at the same time.
Magnetic declination angle
Magnetic declination direction
5. Press (D) to exit the setting screen.
Magnetic North and True
North
There are actually two types of north:
magnetic north and true north.
Magnetic north: North indicated by the needle
of a compass
True north: Direction to the North Pole
As shown in the illustration below, magnetic
north and true north are not the same.
Earth
Magnetic north
True north
Note
●
The north indicated on commercially
available maps is normally true north.
Digital Compass Reading
Precautions
Location During Use
Taking readings near sources of strong
magnetism can cause reading error. Keep the
watch away from the following types of items.
Permanent magnets (magnetic accessories,
etc.), metal objects, high-voltage wires, aerial
wires, electrical household appliances (TVs,
computers, cellphones, etc.)
●
Note that correct direction readings are not
possible indoors, especially inside of
reinforced concrete structures.
●
Accurate direction readings are not
possible on electric trains, on boats, on
aircraft, etc.
Storage Location
Exposure of the watch to magnetism can
affect the accuracy of digital compass
readings. Keep the watch away from the types
of items below.
Permanent magnets (magnetic accessories,
etc.), metal objects, electrical household
appliances (TVs, computers, cellphones, etc.)
Altitude
Measurement
The watch takes altitude readings and
displays results based on air pressure
measurements taken by a built-in pressure
sensor.
Important!
●
The altitude readings displayed by the
watch are relative values that are
calculated based on barometric
pressure measured by the watch’s
pressure sensor. This means that
barometric pressure changes due to
weather can cause altitude readings
taken at the same location to be
different. Also note that the value
displayed by the watch may be
different from the actual elevation and/
or sea level elevation indicated for the
area where you are located. When
using the watch’s altimeter while
mountain climbing, it is recommended
that you regularly calibrate its readings
in accordance with local altitude
(elevation) indications.
l
Calibrating Altitude Readings
(Offset)
●
The altitude correction value you
specify and/or barometric pressure
changes may cause a negative value
to be displayed.
●
Check the information at the link below
to find out about how to minimize
differences between readings
produced by the watch, and values
provided by local altitude (elevation)
indications.
l
Altitude Reading Precautions
Watch Operation Guide 5744
24
Checking the Current
Altitude
1. Enter the Altimeter Mode.
l
Navigating Between Modes
Entering the Altimeter Mode will start
altitude measurement and display the
altitude at your current location.
●
You can navigate between display
screens by pressing (D).
D
Altitude
Altitude graph
Altitude graph
●
The watch takes altitude readings every
second for about the first three minutes.
After that, it takes readings according to
the watch’s auto measurement interval
setting.
●
Check the information at the link below
to find out how to configure the auto
measurement interval.
l
Setting the Auto Measurement
Interval
●
To retrigger measurement, press (A).
●
Press (E) to return to the Timekeeping
Mode.
Note
●
When you enter the Altitude Mode, the
second hand will indicate either
timekeeping seconds, or the
differential between altitude
measurements (whichever was
indicated the last time you were in the
Altitude Mode).
You can change what information is
indicated by the second hand.
l
Checking the Altitude Differential
from a Reference Point
●
Measurement range: -700 to 10,000
meters (-2,300 to 32,800 feet)
(Measurement unit: 1 meter (5 feet))
Note that calibrating altitude readings
will cause a change in the
measurement range.
●
[- - -] will appear for the measured
value if it is outside the allowable
range.
Interpreting Altitude Graph Contents
70m*
6 readings ago
Current reading
*
1 square (
v
) is 10 m.
Calibrating Altitude
Readings (Offset)
To minimize the difference between locally
indicated and measured values, you should
update the reference altitude value (offset)
before setting off and during treks or any other
activities where you take altitude readings.
Also, you can ensure accurate measurements
by checking a map local altitude indications or
some other source for your current location’s
altitude, and regularly calibrating watch
readings with the latest information while
mountain climbing.
Note
●
You can find out the altitude at your
current location from signs, maps, on
the Internet, etc.
●
Differences between actual altitude
and watch readings can be caused by
the factors below.
ー
Changes in barometric pressure
ー
Changes in temperature caused by
variations in barometric pressure
and by elevation
●
Though altitude readings can be taken
without calibration, doing so may
produce readings that are very
different from indications by altitude
markers, etc.
1. Enter the Altimeter Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when [SET] starts to
flash and then disappears from the
display.
This displays the current altitude and
enters the Altitude Offset Mode.
3. Use (A) and (C) to change the altitude
value to an elevation value obtained from
another source.
Setting range: -3,000 to 10,000 meters (or
-9,840 to 32,800 feet)
Setting unit: 1 meter (or 5 feet)
●
To return the altitude setting to its initial
factory default, press (A) and (C) at the
same time.
4. Press (D) to exit the setting screen.
Watch Operation Guide 5744
25
Checking the Altitude
Differential from a Reference
Point
After you set a reference altitude, the second
hand of the watch will indicate the difference
between your current altitude and the
reference altitude. This makes it easy to
measure the altitude difference between two
points while climbing or trekking.
●
Changing the Information Indicated by
the Second Hand
1. Enter the Altimeter Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when [SET] starts to
flash and then disappears from the
display.
This displays the altitude for your current
location.
3. Press (E) three times.
This causes the display to show [HAND]
n
[DIFF] or [SEC].
4. Use (A) to select [DIFF].
Each press of (A) cycles through the
settings shown below.
[DIFF]: Second hand indicates altitude
differential.
[SEC]: Second hand indicates the current
time seconds.
5. Press (D) to exit the setting screen.
●
Setting the Altitude Differential
Measurement Range
1. Enter the Altimeter Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when [SET] starts to
flash and then disappears from the
display.
This displays the altitude for your current
location.
3. Press (E) twice.
This displays the altitude differential
measurement range.
4. Use (A) to select [100m] or [1000m].
[100m]: ±100 meters (±328 feet) in 5-
meter (16-foot) units
[1000m]: ±1000 meters (±3280 feet) in
50-meter (164-foot) units
5. Press (D) to exit the setting screen.
●
Measuring Altitude
1. Use the contour lines on your map to
determine the altitude differential between
your current location and your destination.
2. Change the information indicated by the
second hand to [DIFF].
l
Changing the Information Indicated by
the Second Hand
3. Take an altitude reading of your current
location.
l
Checking the Current Altitude
4. Hold down (L) for at least two seconds to
set your current location’s altitude as the
reference altitude.
This causes [DIFF CLR] to stop flashing
and displays the altitude at your current
location.
●
The second hand (Altitude Differential
Indicator) will indicate the difference
between the reference altitude and the
current altitude reading. At this time the
second hand should indicate ±0 m (±0
feet).
Current location altitude
Altitude differential indicator
5. While comparing the difference between
the altitude you found on the map and the
altitude differential indicated by the
watch’s second hand, advance towards
your destination.
●
When the altitude differential you found
on the map is the same as that indicated
by the second hand, it means you are
close to your destination.
Example: Altitude differential of -30 m (-98
feet) (-300 m (-984 feet))
100 50
0
−50
−100
Altitude differential
indicator
Range:
±100 m (1000 m)
(±328 feet (3280 feet))
Unit: m
Note
●
If the altitude differential is outside of
the specified range, the second hand
will indicate [OVER] or [UNDER].
If either of these is indicated while
using the ±100 m (328 feet)
measurement range, change the
range setting to ±1000 m (3280 feet).
●
The second hand will move to 9
o’clock if a reading is outside the
allowable altitude measurement
range (-700 m to 10,000 m (-2,300 to
32,800 feet)), or if a reading error
occurs.
Watch Operation Guide 5744
26
Setting the Auto
Measurement Interval
You can select an auto measurement interval
of either five seconds or two minutes.
1. Enter the Altimeter Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when [SET] starts to
flash and then disappears from the
display.
This displays the altitude for your current
location.
3. Press (E).
This causes the auto measurement
interval to appear on the display.
4. Press (A) to toggle the auto measurement
interval between [0’05] and [2’00].
[0’05]: Readings taken every second for
the first three minutes, and then every five
seconds for about the next one hour.
[2’00]: Readings taken every second for
the first three minutes, and then every two
minutes for about the next 12 hours.
5. Press (D) to exit the setting screen.
Note
●
The watch will automatically return to
the Timekeeping Mode if you do not
perform any operation in the Altimeter
Mode for about one hour while [0’05]
is selected as the measurement
interval or about 12 hours while [2’00]
is selected.
Recording Altitude Readings
Use the procedure below to record altitude
measurements manually. Auto
measurements are also recorded
automatically.
●
Use the Altitude Record Recall Mode to
view or delete records.
l
Viewing Altitude Records
●
Recording Altitude Data Manually
1. Enter the Timekeeping Mode or Altimeter
Mode.
l
Navigating Between Modes
2. Hold down (A) for at least two seconds
until [REC] stops flashing on the display.
This records the current altitude, date,
and time.
●
There is enough memory to hold up to
14 altitude records.
●
Recording data when there are already
14 records in memory will automatically
delete the oldest record to make room
for the new one.
Note
●
If Mission Log is disabled, the watch
will automatically return to normal
Altimeter Mode operation following
recording of altitude data.
●
If Mission Log is enabled and altitude
data is recorded, the watch will
connect with the phone and transfers
the data to it.
When a connection is established
between the watch and phone, [REC]
will change to [OK], and the second
hand will move from [R] to [C].
l
Recording Waypoints and Their
Altitudes (Mission Log)
●
[ERR] will appear on the display if
connection fails for some reason.
●
Auto Altitude Data Recording
The altitude data described below is recorded
automatically while the watch is in the
Altimeter Mode. One record each is
maintained in memory for each of these items.
A
B
CD
F
E
End point
Start point
High Altitude (MAX):
E
Low Altitude (MIN):
F
Cumulative Ascent (ASC):
A
+
C
*
Cumulative Descent (DSC):
B
+
D
*
* Cumulative ascent and cumulative descent
values are updated whenever there is a
difference of at least ±15 m (±49 feet) from
one reading to the next.
Note
●
Auto recording ends when you exit the
Altimeter Mode. Re-entering the
Altimeter Mode restarts recording of
cumulative values from where it was
stopped when you last exited the
Altimeter Mode.
●
Auto measurement continues if you go
from the Altimeter Mode to another
mode while Mission Log is enabled.
●
Every time an auto measurement
operation is performed while Mission
Log is enabled, the watch checks the
currently saved values of the following
data items and updates them as
required: MAX, MIN, ASC, DSC.
l
Recording Waypoints and Their
Altitudes (Mission Log)
●
[ERR] will appear on the display if
connection fails for some reason.
Watch Operation Guide 5744
27
Specifying the Altitude
Measurement Unit
You can select either meters (m) or feet (ft) as
the Altimeter Mode display unit.
Important!
●
When Tokyo (TOKYO) is set as the
Home City, the altitude unit is fixed as
meters (m) and cannot be changed.
1. Enter the Timekeeping Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Example: When your Home City is Los
Angeles
Home City
3. Press (E) seven times.
This causes [UNIT] to appear, with [m] or
[ft] flashing.
4. Press (A) to toggle the altitude unit
between meters and feet.
[m]: Meters
[ft]: Feet
FeetMeters
5. Press (D) twice to exit the setting screen.
Altitude Reading
Precautions
Effects of Temperature
When taking altitude readings, take the steps
below to keep the watch at as stable a
temperature as possible. Changes in
temperature can affect altitude readings.
●
Take readings with the watch on your wrist.
●
Take readings in an area where
temperature is stable.
Altitude Readings
●
Do not use this watch while skydiving, hang
gliding, paragliding, gyrocopter flying, glider
flying, or engaged in other activities where
altitude changes suddenly.
●
Altitude readings produced by this watch
are not intended for special-purpose or
industrial level use.
●
In an aircraft, the watch measures the in-
cabin pressurized air pressure, so readings
will not match altitudes announced by the
crew.
Altitude Readings (Relative Altitude)
This watch uses International Standard
Atmosphere (ISA) relative altitude data
defined by the International Civil Aviation
Organization (ICAO). Barometric pressure
generally becomes lower as altitude
increases.
Correct measurement may not be possible
under the conditions below.
●
During unstable atmospheric conditions
●
During sudden temperature changes
●
After the watch has been subjected to
strong impact
Barometric Pressure
Measurement
You can use the Barometer Mode to take a
reading of the barometric pressure at your
current location, and to track reading changes
and trends.
Important!
●
Check the information at the link below
to find out how to ensure correct
readings.
l
Barometric Pressure Reading
Precautions
Watch Operation Guide 5744
28
Checking the Current
Barometric Pressure
1. Enter the Barometer Mode.
l
Navigating Between Modes
Entering the Barometer Mode starts
measurement, and displays the
barometric pressure at your current
location and a barometric pressure graph.
●
After you enter the Barometer Mode,
the watch takes readings about every
five seconds for three minutes. After
that, a measurement is taken about
every two minutes or every five
seconds.
To toggle between measurement
interval settings, hold down (C) for at
least two seconds.
l
Changing the Measurement Interval
of the Barometric Pressure Graph
●
You can navigate between display
screens by pressing (D).
l
Checking Changes in Barometric
Pressure Over Time
D
Barometric pressure
Barometric pressure graph
Barometric pressure graph
●
To retrigger measurement, press (A).
●
To return to the Timekeeping Mode,
hold down (E) for at least two seconds.
Note
●
When you enter the Barometer Mode,
the second hand will indicate either
timekeeping seconds, or the
differential between barometer
measurements (whichever was
indicated the last time you were in the
Barometer Mode).
You can change what information is
indicated by the second hand.
l
Checking the Change in
Barometric Pressure between
Two Readings
●
The watch will automatically return to
the Timekeeping Mode from the
Barometer mode if you do not perform
any operation for about one hour.
●
The measurement range is 260 hPa to
1,100 hPa (7.65 inHg to 32.45 inHg)
(1 hPa (0.05 inHg) units). [- - -] will
appear for the measured value if it is
outside the allowable range.
Checking Changes in
Barometric Pressure Over
Time
The watch can be configured to show a graph
of pressure readings taken every two hours or
every two minutes.
You can display a graph of barometric
pressure readings for the past 20 hours or the
past 20 minutes. The square (
v
) at the far
right of the graph indicates the latest
barometric pressure reading.
Barometric pressure
(0.1 hPa per division)
Time
(2 minute per division)
Two-minute measurement interval
Barometric pressure
(1 hPa per division)
Time
(2 hours per division)
Two-hour measurement interval
●
Changing the Measurement Interval of
the Barometric Pressure Graph
You can select a measurement interval of two
hours or two minutes for the barometric
pressure graph.
1. Hold down (C) for at least two seconds to
toggle between measurement interval
settings.
C
Two-hour interval Two-minute interval
●
When the measurement interval of the
barometric pressure graph is two hours,
measurements are taken every two
minutes.
●
When the measurement interval of the
barometric pressure graph is two
minutes, measurements are taken
every five seconds.
Watch Operation Guide 5744
29
Note
●
If you switch to the two-minute
measurement interval graph, the
watch will automatically return to the
two-hour measurement interval graph
after 24 hours.
●
Note that the graph will not be
displayed immediately after it is
switched to a two-minute
measurement interval graph.
●
Predicting Upcoming Weather
A trend
like this:
Means this:
Rising barometric pressure,
which indicates that upcoming
weather probably will be fair.
Falling barometric pressure,
which indicates that upcoming
weather probably will be bad.
Note
●
Large changes in barometric pressure
and/or temperature can cause past
data readings to be plotted outside of
the visible area of the graph. Though
plots are not visible, the data is still
maintained in watch memory.
●
The barometric pressure graph is not
displayed while Barometric Pressure
Change Indications are displayed.
l
Barometric Pressure Change
Indications
Checking the Change in
Barometric Pressure
between Two Readings
When you perform the procedure below in the
Barometer Mode, the second hand will
indicate the difference between the current
barometric pressure measurement and the
last auto measurement value (taken at two-
hour or two-minute intervals).
1. Enter the Barometer Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when [SET] starts to
flash and then disappears from the
display.
This displays the current barometric
pressure and enters the Barometric
Pressure Offset Mode.
3. Press (E).
This causes the display to show [HAND]
n
[DIFF] or [SEC].
4. Use (A) to select [DIFF].
Each press of (A) cycles through the
settings shown below.
[DIFF]: Second hand indicates barometric
pressure (Barometric Pressure
Differential Indicator)
[SEC]: Second hand indicates the current
time seconds.
Example: Barometric pressure differential
of -3 hPa (-0.09 inHg) (two-hour
measurement interval)
10 5
0
−5
−10
Pressure
Differential
Indicator
Range:
±10 hPa
(1 hPa units)*
Unit: hPa
* Two-hour Measurement Interval: ±10
hPa (1 hPa units)
Two-minute Measurement Interval: ±1
hPa (0.1 hPa units)
5. Press (D) to exit the setting screen.
Note
●
If the barometric pressure differential
is greater than +10 hPa (when the
measurement interval is two hours) or
+1 hPa (when the measurement
interval is two minutes), the second
hand will point to [OVER]. If it is less
than -10 hPa (when the measurement
interval is two hours) or -1 hPa (when
the measurement interval is two
minutes), the second hand will point to
[UNDER].
●
A reading that is outside the allowable
measurement range of 260 hPa to
1,100 hPa (7.65 inHg to 32.45 inHg),
or any measurement error will cause
the second hand to move to 9 o’clock.
Barometric Pressure Change
Indications
Whenever the watch detects a significant
change in air pressure readings (due to
sudden ascent or descent, or to the passage
of a low pressure or high pressure area), it will
beep to let you know. An arrow will also flash
on the display at this time if the watch is in the
Barometer Mode, or if it is in the Timekeeping
Mode with the barometric pressure graph
displayed. The arrow that appears shows the
direction of the pressure change. These alerts
are called “Barometric Pressure Change
Indications”.
This
indication:
Means this:
Sudden drop in pressure
Sudden rise in pressure
Sustained rise in pressure,
shifting to a fall
Sustained fall in pressure, shifting
to a rise
Watch Operation Guide 5744
30
Important!
●
To ensure correct barometric pressure
change indication operation, enable it
in a location where the altitude is
constant (such as a lodge, camp area,
or on the ocean).
●
A change in altitude causes a change
in air pressure. Because of this, correct
readings are impossible. Do not take
readings while ascending or
descending a mountain, etc.
1. Enter the Barometer Mode.
l
Navigating Between Modes
2. Hold down (A) for at least two seconds.
If this turns on barometric pressure trend
information, [INFO ON] will stop flashing
and then the [BARO] indicator will appear
on the display.
3. To disable barometric pressure trend
information, hold down (A) again for at
least two seconds.
Note
●
If Barometric Pressure Change
Indications are on, barometric
pressure readings are taken every two
minutes even while the watch is not in
the Barometer Mode.
●
The barometric pressure change
indication becomes disabled
automatically 24 hours after it is
enabled.
●
You will not be able to turn on
barometric pressure trend information
if the watch’s battery level is low.
●
Low battery power will also cause
barometric pressure trend information
to turn off automatically.
Calibrating Barometric
Pressure Readings (Offset)
The watch’s pressure sensor is adjusted at the
factory and normally does not require
calibration. However, you can calibrate the
displayed value if you notice major errors in
readings.
Important!
●
The watch will not be able to produce
correct barometric pressure readings if
you make a mistake during the
calibration procedure. Check to make
sure that the value you use for
calibration produces correct pressure
readings.
1. Enter the Barometer Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when [SET] starts to
flash and then disappears from the
display.
This displays the current barometric
pressure and enters the Barometric
Pressure Offset Mode.
3. Use (A) and (C) to change the value.
Setting range: 260 to 1,100 hPa (or 7.65
inHg to 32.45 inHg)
Setting unit: 1 hPa (or 0.05 inHg)
●
To return the barometric pressure
setting to its initial factory default, press
(A) and (C) at the same time.
4. Press (D) to exit the setting screen.
Specifying the Barometric
Pressure Unit
You can specify either hectopascals (hPa) or
inches of mercury (inHg) as the display unit for
barometric pressure values.
Important!
●
When Tokyo (TOKYO) is the Home
City, the barometric pressure unit is
fixed as hectopascals (hPa) and
cannot be changed.
1. Enter the Timekeeping Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Example: When your Home City is Los
Angeles
Home City
3. Press (E) eight times.
This causes [UNIT] to appear, with [hPa]
or [inHg] flashing.
4. Press (A) to toggle between barometric
pressure units.
[hPa]: Hectopascals
[inHg]: Inches of mercury
Inches of mercuryHectopascals
5. Press (D) twice to exit the setting screen.
Barometric Pressure
Reading Precautions
●
The barometric pressure graph produced
by this watch can be used to obtain an idea
of upcoming weather conditions. However,
this watch should not be used in place of
precision instruments required for official
weather prediction and reporting.
●
Pressure sensor readings can be affected
by sudden changes in temperature.
Because of this, there may be some error in
the readings produced by the watch.
Watch Operation Guide 5744
31
Temperature
Measurement
The watch can be used to take current air
temperature readings.
Important!
●
Check the information at the link below
to find out how to ensure correct
readings.
l
Temperature Reading
Precautions
Checking the Current
Temperature
1. Enter the Thermometer Mode.
l
Navigating Between Modes
Entering the Thermometer Mode will start
temperature measurement and display
the result.
●
After you enter the Thermometer Mode,
the watch takes readings about every
five seconds for three minutes. After
that, a measurement is taken about
every two minutes.
●
To retrigger measurement, press (A).
Note
●
The watch will automatically return to
the Timekeeping Mode if you do not
perform any operation in the
Thermometer Mode for about one
hour.
●
The measuring range is -10.0 °C to
60.0 °C (14.0 °F to 140.0 °F) (0.1 °C
(0.2 °F) units). [- - .-] will appear for the
measured value if it is outside the
allowable range.
●
To return to the Timekeeping Mode,
hold down (E) for at least two seconds.
Calibrating Temperature
Readings (Offset)
The watch’s temperature sensor is adjusted at
the factory and normally does not require
calibration. However, you can calibrate the
displayed value if you notice major errors in
readings.
Important!
●
Check to make sure that the value you
use for calibration produces correct
temperature readings.
●
Before calibrating the temperature
reading, remove the watch from your
wrist and leave it in the area where you
plan to measure temperature for about
20 or 30 minutes to allow the case
temperature to become the same as
the air temperature.
1. Enter the Thermometer Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when [SET] starts to
flash and then [°C] appears on the display.
This displays the current temperature and
enters the Temperature Offset Mode.
3. Use (A) and (C) to calibrate the
temperature.
Calibration unit: 0.1 °C (0.2 °F)
●
To return the barometric pressure
setting to its initial factory default, press
(A) and (C) at the same time.
4. Press (D) to exit the setting screen.
Specifying the Temperature
Unit
You can select either Celsius (°C) or
Fahrenheit (°F) as the temperature display
unit.
Important!
●
When Tokyo (TOKYO) is the Home
City, the temperature unit is fixed as
Celsius (°C) and cannot be changed.
1. Enter the Timekeeping Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Example: When your Home City is Los
Angeles
Home City
3. Press (E) nine times.
This will display [UNIT °C] with [°C]
flashing, or [UNIT °F] with [°F] flashing.
4. Press (A) to toggle between temperature
units.
[°C]: Celsius
[°F]: Fahrenheit
FahrenheitCelsius
5. Press (D) twice to exit the setting screen.
Temperature Reading
Precautions
Body temperature, direct sunlight, and
humidity all have an effect on temperature
readings. To help ensure more accurate
temperature readings, remove the watch from
your wrist, wipe it dry of any moisture, and
place it in a well-ventilated location not
exposed to direct sunlight. You should be able
to take temperature readings after about 20 to
30 minutes.
Watch Operation Guide 5744
32
Viewing Altitude
Records
You can use the Altitude Record Recall Mode
to view manually recorded and auto recorded
data.
l
Recording Altitude Readings
Viewing Saved Data
1. Enter the Altitude Record Recall Mode.
l
Navigating Between Modes
This displays a record of data recorded in
the Altimeter Mode.
2. Use (A) and (C) to display the data you
want to view.
●
Holding down (A) or (C) scrolls at high
speed.
ACCA
ACCA
A
C
C*
A*
Total Descent
Total Ascent Low Altitude
High Altitude
Auto Recorded Data
Manually Recorded Data
* Each press of a button scrolls to the top
screen of the next manually recorded
data record. There can be up to 14
records in memory, numbered from 1
([-01-]) to 14 ([-14-]).
Note
●
If there is no data left in memory due
to a data delete operation, error, or
some other reason, [- - - -] or [0] will
appear on the display.
●
If the cumulative ascent (ASC) or
cumulative descent (DSC) value
exceeds 99,999 m (327,995 feet), it
will revert to 0 and continue from there.
●
Pressing (D) returns to the top screen
(record number, DSC, ASC, MAX, or
MIN) of the data that you are viewing.
●
Manually Recorded Data
After displaying the top screen of a manually
recorded data record (01 through 14), you can
navigate between the record’s data as shown
below.
Example: Manually recorded Record 01
D
D
2 seconds
2 seconds
2 seconds
Altitude Time
Recording dateRecord number
●
Auto Recorded Data
After displaying an auto recorded data record,
you can navigate between the record’s data
screens as shown below.
High altitude and low altitude
Example: High altitude
D
D
2 seconds
2 seconds
2 seconds
Altitude Time
Recording dateData type
Cumulative ascent and cumulative
descent
Example: Cumulative ascent
D
2 seconds
Date when
accumulation started.
Data type
Cumulative altitude
D
2 seconds
Deleting Data
●
Deleting a Particular Record
1. Enter the Altitude Record Recall Mode.
l
Navigating Between Modes
2. Use the (A) and (C) buttons to scroll
through the top screens of the records and
display the one you want to delete.
3. Hold down the (D) button for
approximately two seconds. Release the
button as soon as [CLEAR] stops flashing.
This deletes the record you selected.
●
Note that holding down (D) for more
than five seconds will delete all data.
●
Deleting All Records
Hold down (D) for at least five seconds until
[ALL CLR] stops flashing. This indicates that
all data was deleted.
Watch Operation Guide 5744
33
Sunrise and Sunset
Times
You can use the watch to check sunrise and
sunset times for your Home City.
Looking Up Today’s Sunrise
and Sunset Times
1. Enter the Sunrise/Sunset Mode.
l
Navigating Between Modes
This will cause the display to alternate at
two-second intervals between the sunrise
and sunset times for the current date in
your Home City.
Sunset timeSunrise time
Every two seconds
Looking Up Sunrise and
Sunset Times by Specifying a
Day
1. Enter the Sunrise/Sunset Mode.
l
Navigating Between Modes
2. Use (A) and (C) to change the selected
date.
This displays the sunrise and sunset
times for the day you specified.
Sunset timeSunrise time
Every two seconds
Note
●
Sunrise and sunset times are
calculated internally by the watch.
Calculation results may contain
errors, with greater errors occurring at
higher latitudes.
●
[--:--] is displayed when calculation
results cannot be output for some
reason or in regions outside of 65.0°
south to 65.0° north latitude.
Stopwatch
The stopwatch measures elapsed time in
1/100-second units for the first hour, and in 1-
second units after that for up to 24 hours.
It can also measure split times.
Measuring Elapsed Time
1. Enter the Stopwatch Mode.
l
Navigating Between Modes
2. Use the operations below to measure
elapsed time.
Stop
Resume
Stop
Start
After first hour
Hour, minute, secondMinutes, seconds,
1/100 seconds
First hour
3. Press (C) to reset the elapsed time to all
zeroes.
Watch Operation Guide 5744
34
Measuring a Split Time
1. Enter the Stopwatch Mode.
l
Navigating Between Modes
2. Use the operations below to measure
elapsed time.
A
C
C
A
Stop
Split release
Split
Start
After first hour
Hour, minute, secondMinutes, seconds,
1/100 seconds
First hour
3. Press (C) to reset the elapsed time to all
zeroes.
Timer
The timer counts down from a start time
specified by you. A beeper sounds when the
end of the countdown is reached.
●
The beeper will not sound if battery power
is low.
Using the CASIO WATCHES
Phone App to Configure
Timer Settings
If the watch is paired with a phone, you can
also use the CASIO WATCHES phone app to
set the timer start time.
l
Configuring Watch Settings
Setting the Timer Start Time
The countdown start time can be set in 1-
minute units up to 24 hours.
1. Enter the Timer Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when the minutes
digits start to flash.
This causes the minutes digits to flash.
Minutes
3. Use (A) and (C) to change the timer
minutes setting.
4. Press (E).
This causes the hours digit to flash.
Hours
5. Use (A) and (C) to change the timer hours
setting.
6. Press (D) to exit the setting screen.
Using the Timer
1. Enter the Timer Mode.
l
Navigating Between Modes
2. Use the operations below to perform a
timer operation.
A
A
A
(Time up)
Resume
Pause
(Countdown starts)
Start
●
A beeper sounds for 10 seconds to let
you know when the end of a countdown
is reached.
●
To reset a paused countdown to the
start time, press (C).
3. Press any button to stop the tone.
Watch Operation Guide 5744
35
Step Count
You can use your watch to keep track of your
step count while walking, engaging in your
normal daily activities, etc.
Counting Steps
If you are wearing the watch correctly, the
watch will count your steps as you walk or
engage in your normal daily activities.
Important!
●
Since this watch is a wrist-worn device,
it may detect non-step movements and
count them as steps. Also, abnormal
arm movements while walking may
cause a miss count of steps.
●
Getting Ready
To enable the most accurate step count, wear
the watch with the face on the outside of your
wrist and tighten the band securely. A loose
band may make it impossible to obtain correct
measurement.
NOYES
●
Performing Measurement
The pedometer will start counting your steps
when you start walking.
●
To check the step count
Displaying the step count screen.
l
Mode Overview
Note
●
The step count can show a value up to
999,999 steps. If the step count
exceeds 999,999, the maximum value
(999,999) remains on the display.
●
To prevent miscounts, the displayed
count does not increase for about 10
seconds after you start walking. After
you have been walking for about 10
seconds, the correct count appears,
including the steps you took during the
previous 10 seconds.
●
The step count is reset to zero at
midnight each day.
●
To save power, step counting stops
automatically if you take off the watch
(no detectable watch movement) and
you do not perform any operation for
two or three minutes.
Causes of Incorrect Step
Count
Any of the conditions below may make proper
counting impossible.
●
Walking while wearing slippers, sandals, or
other footwear that encourages a shuffling
gait
●
Walking on tile, carpeting, snow, or other
surface that causes a shuffling gait
●
Irregular walking (in a crowded location, in
a line where walking stops and starts at
short intervals, etc.)
●
Extremely slow walking or extremely fast
running
●
Pushing a shopping cart or baby stroller
●
In a location where there is a lot of vibration,
or riding on a bicycle or in a vehicle
●
Frequent movement of the hand or arm
(clapping, fanning movement, etc.)
●
Walking while holding hands, walking with
a cane or stick, or engaging in any other
movement in which your hand and leg
movements are not coordinated with each
other
●
Normal daily non-walking activities
(cleaning, etc.)
●
Wearing the watch on your dominant hand
●
Walking for 10 seconds or less
Hand Alignment
Adjustment
Strong magnetism or impact can cause the
time indicated by the analog hands to become
different from the time on the digital display. If
this happens, adjust hand alignment.
Using the CASIO WATCHES
Phone App to Adjust Hand
Alignment
If the watch is paired with a phone, you can
also use CASIO WATCHES to adjust hand
alignment.
l
Adjusting Hand Alignment
Adjusting Hand Alignment
1. Enter the Timekeeping Mode.
l
Navigating Between Modes
2. Hold down (D) for at least five seconds.
Release the button when [00] starts to
flash.
This enables adjustment of second hand
alignment.
Second hand
After 3.5 seconds
After five seconds
3. If the second hand is not at 12 o’clock, use
(A) and (C) to align it.
4. Press (E).
This enables adjustment of the hour and
minute hands.
Minute handHour hand
5. If the hour hand and minute hand are not
at 12 o’clock, use (A) and (C) to align them.
6. Press (D) to exit the setting screen.
Watch Operation Guide 5744
36
Other Settings
This section explains other watch settings you
can configure.
Enabling the Button
Operation Tone
Use the procedure below to enable or disable
the tone that sounds when you press a button.
1. Enter the Timekeeping Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Home City
3. Press (E) twice.
This causes [KEY♪] or [MUTE] to flash on
the display.
4. Use (A) to select [KEY♪] or [MUTE].
[KEY♪]: Operation tone enabled.
[MUTE]: Operation tone muted.
5. Press (D) twice to exit the setting screen.
Note
●
Note that alarm and timer tones still
sound even while the operation tone is
muted.
Reflecting Altitude
Differential in Activity
Measurements
You can use the procedure below to specify
whether or not you want to reflect altitude
differential in physical exertion
measurements.
Note
●
Reflecting altitude differential
information in activity measurements
makes it possible to obtain more
accurate activity calculations.
●
CASIO WATCHES is used to specify
your height and weight, and to
calculate physical exertion.
This information is not displayed on
the watch.
1. Enter the Timekeeping Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Home City
3. Press (E) six times.
This will display [SLOPE], followed by a
flashing [ON] or [OFF].
4. Use (A) to select [ON] or [OFF].
[ON]: Altitude differential reflected in
physical exertion measurements.
[OFF]: Altitude differential not reflected in
physical exertion measurements.
5. Press (D) twice to exit the setting screen.
Resetting Watch Settings
This section explains how to return the watch
settings below to their initial factory defaults.
●
Watch Settings
●
Compass
●
Altimeter
●
Barometer
●
Thermometer
●
Altitude recording
●
Step count data
●
Stopwatch
●
Timer
●
Alarm
1. Enter the Timekeeping Mode.
l
Navigating Between Modes
2. Hold down (D) for at least two seconds.
Release the button when the name of the
currently selected Home City appears on
the display.
Home City
3. Press (D).
This causes the seconds to flash.
Seconds
4. Hold down (C) for at least five seconds.
Release it when [RESET] stops flashing.
5. Press (D) to exit the setting screen.
Important!
●
Reset cannot be performed while
Mission Log is enabled.
l
Recording Waypoints and Their
Altitudes (Mission Log)
Note
●
Resetting the watch also deletes
information for pairing the watch with
a phone, and unpair them.
Watch Operation Guide 5744
37
Specifications
Accuracy :
±15 seconds per month when time
adjustment by communication with a phone
is not possible.
Basic Functions :
Analog
Hour, minute (moves every 10 seconds),
second
Digital
Hour, minute, second, month, day, day of
the week
p.m. (P), 24-hour timekeeping
Full Auto Calendar (2000 to 2099)
Digital Compass :
Measurement range: 0° to 359°
Measurement Units: LCD: 1°, Analog: 6°
Continuous Bearing Measurement (1
minute)
North Indication Hand
Bearing calibration (2-point calibration,
figure 8 calibration, magnetic declination
calibration)
Auto bearing calibration
Altimeter (relative altitude) :
Measuring range: -700 to 10,000 m (or
-2,300 to 32,800 ft.)
Display range: -3,000 to 10,000 m (or -9,840
to 32,800 ft.)
(Altitude calibration can be used to display
any 10,700 m within the range above.)
Measuring unit: 1 m (or 5 ft.)
Auto measurement interval (2 minutes, 5
seconds)
Altitude calibration
Altitude graph
Altitude differential measurement (-100 to
+100 m/-1,000 to +1,000 m (or -325 to +325
ft./-3,280 to +3,280 ft.))
Altitude Memory
(Manually recorded data: Up to 14 records
of altitude, year, month, day, and time
recorded with the press of a button; Auto
recorded data: One record of high altitude,
low altitude, cumulative ascent, cumulative
descent)
Barometer :
Measurement range: 260 to 1,100 hPa (or
7.65 to 32.45 inHg)
Display range: 260 to 1,100 hPa (or 7.65 to
32.45 inHg)
Measurement unit: 1 hPa (or 0.05 inHg)
Barometric pressure graph
Barometric pressure indicator (-10 to +10
hPa/-1 to +1 hPa (or -0.25 to +0.25
inHg/-0.05 to +0.05 inHg))
Barometric Pressure Change Indications
Temperature :
Measuring range: -10.0 to 60.0 °C (or 14.0
to 140.0 °F)
Display range: -10.0 to 60.0 °C (or 14.0 to
140.0 °F)
Measuring unit: 0.1 °C (or 0.2 °F)
Temperature Correction
Sensor Accuracy :
Direction sensor
Measurement accuracy: Within ±10°
(Guaranteed accuracy temperature
range: 10 °C to 40 °C (50 °F to 104 °F))
Bearing hand indication: Within ±2
gradations
Pressure sensor
Measurement accuracy: Within ±3 hPa
(0.1 inHg)
(Altimeter measurement accuracy:
Within ±75 m (246 ft.))
●
Guaranteed accuracy temperature
range: -10 °C to 40 °C (14 °F to 104 °F)
●
Strong impact or prolonged exposure to
temperature extremes may negatively
affect accuracy.
Temperature Sensor
Measurement accuracy: Within ±2 °C
(3.6 °F)
(Guaranteed accuracy temperature
range: -10 °C to 60 °C (14 °F to 140 °F))
Pedometer :
Step count measurement using a 3-axis
accelerometer
Step count display range: 0 to 999,999
steps
Step count reset: Auto reset at midnight
each day
Step count accuracy: ±3% (According to
vibration testing)
Power Saving
Sunrise/Sunset Functions :
Sunrise/Sunset times ([--:--] displayed
when calculation results cannot be output
for some reason or in regions outside of
65.0° south to 65.0° north latitude.)
Day select
Stopwatch :
Measuring units: 1/100 seconds (first hour);
1 second (after first hour)
Measuring capacity: 23:59’59” (24 hours)
Measurement functions: Elapsed time, split
times
Timer :
Setting unit: 1 minute
Countdown range: 1 minute to 24 hours
Countdown unit: 1 second
Time up alert duration: 10 seconds
Alarm :
Daily alarm
Number of alarms: 5
Setting units: Hours, minutes
Alarm tone duration: 10 seconds
Hourly time signal: Beep every hour on the
hour
World Time :
Current time in 38 cities (38 time zones),
and UTC (Coordinated Universal Time)
time
Auto summer time setting
Swapping with Home City
One-touch UTC display
Mobile Link :
Auto Time Correction
Time setting adjusted automatically at
preset time.
One-touch Time Correction
Manual connection and time adjustment
Phone finder
Watch operation sounds the alert sound
of the phone.
World Time
A selection of more than 300 World Time
cities
Auto Daylight Saving Time (summer time)
switching
Automatic switching between standard
time and summer time.
Mission Log
Recording of waypoints and their
altitudes
Location Indicator
Shows the bearing and distance to a
location registered on the watch.
Auto altitude calibration
Automatic altitude calibration at a preset
time
Timer Settings
Alarm Settings
Mode sort sequence and number of modes
setting
Timekeeping Mode display item setting
Altimeter settings
Step count data transfer
Calories burned calculation (speed
information + altitude information)
Hand alignment correction
Communication Specifications
Bluetooth
®
Frequency band: 2400 MHz to 2480 MHz
Maximum transmission power: 0 dBm (1
mW)
Communication range: Up to 2 meters
(depends on environment)
Watch Operation Guide 5744
38
Other :
High-brightness DOUBLE LED light (Auto
Light, afterglow); illumination duration
setting; low battery alert; operation tone ON/
OFF; hand shift feature
Power Supply :
CR2025 x 1
Battery nominal voltage: 3V
Battery life: Approximately 2 years
Conditions
Auto Time Correction: 4 times/day
Alarm: Once (10 seconds)/day
Illumination: Once (1.5 seconds)/day
Direction readings: 60 seconds
continuous, 20 times/month
Climbs: 1/month
ー
Altitude Measurement
Every second for 3 minutes + every 5
seconds for 57 minutes
ー
Barometric Pressure Change
Indications
Every second for 3 minutes + every 2
minutes for 23 hours and 57 minutes
ー
Mission Log Measurement
Every 2 minutes for 12 hours
ー
Location Indicator Measurement
10 times for 3 minutes each
Step counting: 12 hours/day
Auto bearing calibration measurements:
10 times/day
Barometric pressure graph
measurements: 12 times/day
Specifications are subject to change without
notice.
Other Information
This section provides non-operational
information you also need to know. Refer to
this information as required.
City Table
City Offset
UTC
Coordinated
Universal Time
0
LONDON London 0
PARIS Paris +1
ATHENS Athens +2
JEDDAH Jeddah +3
TEHRAN Tehran +3.5
DUBAI Dubai +4
KABUL Kabul +4.5
KARACHI Karachi +5
DELHI Delhi +5.5
KATHMANDU Kathmandu +5.75
DHAKA Dhaka +6
YANGON Yangon +6.5
BANGKOK Bangkok +7
HONG KONG Hong Kong +8
EUCLA Eucla +8.75
TOKYO Tokyo +9
ADELAIDE Adelaide +9.5
SYDNEY Sydney +10
LORD HOWE
ISLAND
Lord Howe
Island
+10.5
NOUMEA Noumea +11
WELLINGTON Wellington +12
CHATHAM
ISLAND
Chatham
Islands
+12.75
NUKU’ALOFA Nuku’alofa +13
KIRITIMATI Kiritimati +14
BAKER ISLAND Baker Island -12
PAGO PAGO Pago Pago -11
HONOLULU Honolulu -10
MARQUESAS
ISLANDS
Marquesas
Islands
-9.5
ANCHORAGE Anchorage -9
LOS ANGELES Los Angeles -8
DENVER Denver -7
CHICAGO Chicago -6
NEW YORK New York -5
HALIFAX Halifax -4
ST. JOHN’S St. John’s -3.5
RIO DE JANEIRO Rio de Janeiro -3
F. DE NORONHA
Fernando de
Noronha
-2
PRAIA Praia -1
●
The information in the above table is current
as of January 2025.
●
Time zones may change and UTC
differentials may become different from
those shown in the table above. If this
happens, connect the watch with a phone
to update the watch with the latest time zone
information.
Summer Time Table
When [AUTO] is selected for a city that
observes summer time, switching between
standard time and summer time will be
performed automatically at the timing shown
in the table below.
Note
●
Summer time start and end dates for
your current location may be different
from those shown below. If this
happens, you can have new summer
time information for your Home City
and World Time City sent to the watch
by connecting the watch with a phone.
If the watch is not connected with a
phone, you can change the summer
time setting manually.
Watch Operation Guide 5744
39
City Name
Summer Time
Start
Summer Time
End
London
01:00, last
Sunday in March
02:00, last
Sunday in
October
Paris
02:00, last
Sunday in March
03:00, last
Sunday in
October
Athens
03:00, last
Sunday in March
04:00, last
Sunday in
October
Tehran
00:00, March 22
or 21
00:00,
September 22 or
21
Sydney,
Adelaide
02:00, first
Sunday in
October
03:00, first
Sunday in April
Lord Howe
Island
02:00, first
Sunday in
October
02:00, first
Sunday in April
Wellington
02:00, last
Sunday in
September
03:00, first
Sunday in April
Chatham
Islands
02:45, last
Sunday in
September
03:45, first
Sunday in April
Anchorage
02:00, second
Sunday in March
02:00, first
Sunday in
November
Los
Angeles
02:00, second
Sunday in March
02:00, first
Sunday in
November
Denver
02:00, second
Sunday in March
02:00, first
Sunday in
November
Chicago
02:00, second
Sunday in March
02:00, first
Sunday in
November
New York
02:00, second
Sunday in March
02:00, first
Sunday in
November
Halifax
02:00, second
Sunday in March
02:00, first
Sunday in
November
St. John’s
02:00, second
Sunday in March
02:00, first
Sunday in
November
Rio de
Janeiro
Midnight, first
Sunday in
November
00:00, third
Sunday in
February or
00:00, fourth
Sunday in
February
●
The information in the above table is current
as of July 2022.
Supported Phones
For information about phones that can
connect with the watch, visit the CASIO
website.
https://world.casio.com/os_mobile/wat/
Copyrights and Registered
Copyrights
●
The Bluetooth
®
word mark and logos are
registered trademarks owned by the
Bluetooth SIG, Inc. and any use of such
marks by CASIO Computer Co., Ltd. is
under license.
●
iPhone and App Store are trademarks of
Apple Inc. in the United States and other
countries.
●
IOS is a trademark or registered trademark
of Cisco Systems, Inc.
●
Android and Google Play
TM
are trademarks
or registered trademarks of Google LLC.
●
Other company names and product names
used herein are trademarks or registered
trademarks of their respective companies.
Watch Operation Guide 5744
40
Troubleshooting
I can’t pair the watch with a
phone.
Q1
I’ve never been able to establish a
(pairing) connection between the
watch and phone.
Are you using a supported phone model?
Check if the phone model and its
operating system are supported by the
watch.
For information about supported phone
models, visit the CASIO Website.
https://world.casio.com/os_mobile/wat/
Did you install the CASIO WATCHES
phone app on your phone?
The CASIO WATCHES phone app needs
to be installed on your phone in order to
connect with the watch.
l
A
Install the required app on your
phone.
Are your phone’s Bluetooth settings
configured correctly?
Configure the phone’s Bluetooth settings.
For details about setting procedures, see
your phone documentation.
iPhone Users
●
“Settings”
n
“Bluetooth”
n
On
●
“Settings”
n
“Privacy”
n
“Bluetooth”
n
“CASIO WATCHES”
n
On
Android Users
●
Enable Bluetooth.
Other than the above.
Some phones need to have BT Smart
disabled to use the CASIO WATCHES
phone app. For details about setting
procedures, see your phone
documentation.
On the Home Screen, tap: “Menu”
n
“Settings”
n
“Bluetooth”
n
“Menu”
n
“BT Smart settings”
n
“Disable”.
I can’t reconnect the watch
and phone.
Q1
The watch will not re-connect with the
phone after they are disconnected.
Is the CASIO WATCHES phone app
running?
The watch cannot re-connect with the
phone unless CASIO WATCHES is
running on the phone. On the phone’s
Home Screen, tap the “CASIO
WATCHES” icon. Then on the watch, hold
down (B) for at least two seconds until the
second hand points to [R] twice.
Have you tried turning your phone off and
then back on again?
Turn the phone off and then back on, and
then tap the “CASIO WATCHES” icon.
Then on the watch, hold down (B) for at
least two seconds until the second hand
points to [R] twice.
Is a timer countdown operation in
progress?
Connection with a phone is not possible
while there is 30 seconds or less
remaining on a countdown timer
operation. Stop the countdown operation
before connecting with the phone.
Q2
I can’t connect while my phone is in
the Airplane Mode.
Connection with the watch is not possible
while the phone is in the Airplane Mode. After
exiting the phone’s Airplane Mode, go to the
Home Screen and tap the “CASIO
WATCHES” icon. Then on the watch, hold
down (B) for at least two seconds until the
second hand points to [R] twice.
Q3
I changed the phone’s Bluetooth
from enabled to disabled, and now I
can’t connect anymore.
On the phone, turn Bluetooth off and then back
on, and then tap the “CASIO WATCHES” icon
on the Home Screen. Then on the watch, hold
down (B) for at least two seconds until the
second hand points to [R] twice.
Q4
I can’t connect after turning off the
phone.
Turn on the phone and then tap the “CASIO
WATCHES” icon. Then on the watch, hold
down (B) for at least two seconds until the
second hand points to [R] twice.
Watch Operation Guide 5744
41
Phone-Watch Connection
Q1
I can’t establish a connection
between the phone and watch.
Have you tried turning your phone off and
then back on again?
Turn the phone off and then back on, and
then tap the “CASIO WATCHES” icon.
Then on the watch, hold down (B) for at
least two seconds until the second hand
points to [R] twice.
Has the watch been re-paired with the
phone?
After deleting the pairing information from
the CASIO WATCHES phone app and
your phone, re-pair the watch and phone.
l
Deleting Pairing Information from the
CASIO WATCHES phone app
l
Deleting the phone’s pairing
information
l
C
Pair the watch with a phone.
If you are unable to establish a
connection...
After deleting pairing information from the
watch, re-pair it with your phone.
l
Deleting Pairing Information from the
Watch
l
C
Pair the watch with a phone.
Changing to a Different
Phone Model
Q1
Connecting the current watch to
another phone.
Pair the watch with the phone.
l
If you purchase another phone
Auto Time Correction by
Bluetooth Connection
Q1
When does the watch correct its
time?
The watch will connect with the phone and
perform auto time correction at around 12:30
a.m., 6:30 a.m., 12:30 p.m. and 6:30 p.m. The
connection is automatically terminated after
auto time correction is complete.
Q2
Auto time correction is performed,
but the time setting is not correct.
Is auto time correction not being
performed according to its normal
schedule?
Note that auto time correction is not
performed for 24 hours after swapping of
the Home Time and World Time, or after
the time setting is corrected manually on
the watch. Auto time correction will
resume 24 hours after either of the above
operations is performed.
Is auto time correction enabled?
Auto time correction is not performed at
the scheduled times if it is not enabled.
Enable auto time correction.
l
Using the Watch in a Medical Facility or
Aircraft
Q3
Time is not displayed correctly.
If your phone is unable to receive a signal
because you are outside its service range or
for some other reason, the watch may not be
able to display the correct time. If this
happens, connect the phone to its network
and then correct the time setting.
Altitude Measurement
Q1
Readings produce different results at
the same location.
Watch readings are different from
altitude information available from
other sources.
Correct altitude readings are not
possible.
Relative altitude is calculated based on
changes in barometric pressure measured by
the watch’s pressure sensor. This means that
barometric pressure changes can cause
readings taken at the same location to be
different. Also note that the value displayed by
the watch may be different from the actual
elevation and/or sea level elevation indicated
for the area where you are located. When
using the watch’s altimeter while mountain
climbing, it is recommended that you regularly
calibrate its readings in accordance with local
altitude (elevation) indications.
l
Calibrating Altitude Readings (Offset)
Q2
Following a relative altitude reading,
the watch’s second hand points to 9
o’clock.
The second hand will move to 9 o’clock if a
reading is outside the allowable altitude
measurement range (-700 m to 10,000 m
(-2,300 to 32,800 feet)). If [ERR] is displayed,
there may be a problem with the sensor.
l
Checking the Altitude Differential from a
Reference Point
Q3
[ERR] appears during measurement.
There may be a problem with the sensor. Try
taking another measurement.
If [ERR] keeps appearing after multiple
measurement attempts, contact a CASIO
service center or your original retailer.
Watch Operation Guide 5744
42
Digital Compass
Q1
The entire display is flashing.
Abnormal magnetism has been detected.
Move away from any potential source of
strong magnetism and try taking a reading
again.
l
Digital Compass Reading Precautions
●
If the display flashes again, it could mean
that the watch itself has become
magnetized. Move away from any potential
source of strong magnetism, perform figure
8 calibration or 2-point calibration, and then
try taking a reading again.
l
Calibrating Compass Readings
Q2
[ERR] appears during measurement.
There is a problem with the sensor or there
may be a source strong magnetic force
nearby. Move away from any potential source
of strong magnetism and try taking a reading
again. If [ERR] keeps appearing after multiple
measurement attempts, contact a CASIO
service center or your original retailer.
l
Digital Compass Reading Precautions
Q3
[ERR] displayed following figure 8 or
2-point calibration.
[ERR] on the display could indicate a sensor
problem.
●
If [ERR] disappears after about one second,
try performing 2-point calibration again.
●
If [ERR] keeps appearing after multiple
attempts, contact a CASIO service center or
your original retailer.
Q4
Direction information indicated by the
watch is different from that indicated
by a backup compass.
Move away from any potential source of
strong magnetism, perform 2-point
calibration, and then try taking a reading
again.
l
Calibrating Compass Readings
l
Digital Compass Reading Precautions
Q5
Readings at the same location
produce different results.
Cannot take readings indoors.
Move away from any potential source of
strong magnetism and try taking a reading
again.
l
Digital Compass Reading Precautions
Location Memory
Q1
Location Memory does not work.
Is the watch paired with a phone?
The watch needs to be paired with a
phone for Location Memory to work. Pair
the watch with a phone.
l
C
Pair the watch with a phone.
Are phone settings configured to acquire
location information?
The phone needs to be used to allow use
of CASIO WATCHES location information
for Location Memory to work. Allow use of
location information.
Are phone settings configured to acquire
GPS information?
You may experience problems acquiring
GPS information in environments like the
ones described below.
●
Where the view of the sky above is
narrow
●
Near trees or buildings
●
Near a train station, airport, or other
congested areas
●
Locations where there is heavy traffic
and radio wave interference
●
Near railway aerial wires, high-voltage
lines, TV towers, etc.
Signal reception is not possible in the
locations described below.
●
Where the sky is not visible
●
Underground, in a tunnel, under water
●
Indoors (Reception may be possible
near a window.)
●
Near radio communication equipment
or other devices that generate
electromagnetic waves
Location Indicator
Q1
Location Indicator does not appear
on the display.
Is the watch paired with a phone?
The watch needs to be paired with a
phone for Location Indicator to work. Pair
the watch with a phone.
l
C
Pair the watch with a phone.
Is Location Memory information being
recorded?
Location information needs to be
recorded in Location Memory for Location
Indicator to work. Record location
information in Location Memory.
l
Recording Your Current Location
(Location Memory)
Are phone settings configured to acquire
location information?
The phone needs to be used to allow use
of CASIO WATCHES location information
for Location Indicator to work. Allow use
of location information.
Are phone settings configured to acquire
GPS information?
You may experience problems acquiring
GPS information in environments like the
ones described below.
●
Where the view of the sky above is
narrow
●
Near trees or buildings
●
Near a train station, airport, or other
congested areas
●
Locations where there is heavy traffic
and radio wave interference
●
Near railway aerial wires, high-voltage
lines, TV towers, etc.
Signal reception is not possible in the
locations described below.
●
Where the sky is not visible
●
Underground, in a tunnel, under water
●
Indoors (Reception may be possible
near a window.)
●
Near radio communication equipment
or other devices that generate
electromagnetic waves
Watch Operation Guide 5744
43
Barometric Pressure
Measurement
Q1
Following a relative barometric
pressure reading, the watch’s
second hand points to 9 o’clock.
The second hand will move to 9 o’clock if a
reading is outside the allowable barometric
pressure measurement range (260 hPa to
1,100 hPa (7.65 inHg to 32.45 inHg)). If [ERR]
appears on the display, there may be a
problem with the sensor.
l
Checking the Current Barometric Pressure
Q2
[ERR] appears during measurement.
There may be a problem with the sensor. Try
taking another measurement. If [ERR] keeps
appearing after multiple measurement
attempts, contact a CASIO service center or
your original retailer.
Temperature Measurement
Q1
[ERR] appears during measurement.
There may be a problem with the sensor. Try
taking another measurement. If [ERR] keeps
appearing after multiple measurement
attempts, contact a CASIO service center or
your original retailer.
World Time
Q1
The time for a World Time City is not
correct.
The summer time setting (standard time/
summer time) may be wrong.
l
World Time City Setting
Pedometer
Q1
Displayed step count is not correct.
While the watch is on your wrist, it may detect
non-step movements and count them as
steps.
l
Step Count
Also, step count problems can also be caused
by how the watch is being worn and abnormal
arm movement while walking.
l
Causes of Incorrect Step Count
Q2
The step count does not increase.
To avoid miscounting of non-walking
movements, the step count is not displayed at
the beginning of a walk.
It appears only after you have continued
walking for about 10 seconds, with the number
of steps you took during the first 10 seconds
included in to the total.
Q3
[ERR] appears when counting steps.
[ERR] (error) indicates that sensor operation
is disabled because of sensor or internal
circuitry malfunction.
If the indicator remains on the display for more
than three minutes or if it frequently appears,
it could indicate a faulty sensor.
Contact a CASIO service center or your
original retailer.
Alarm and Hourly Time
Signal
Q1
An alarm does not sound.
The alarm’s settings may not be configured.
Configure the alarm settings.
l
Configuring Alarm Settings
Q2
The hourly time signal does not
sound.
The hourly time signal may be disabled.
Enable the hourly time signal.
l
Configuring the Hourly Time Signal Setting
Hand Movement and Watch
Screen Indications
Q1
I don’t know what mode the watch is
in.
You can determine the current mode by
checking the watch display. Use (E) to
navigate between modes.
l
Navigating Between Modes
Q2
All hands are stopped and buttons do
not work.
The battery is dead. Have the battery
replaced.
l
Battery Replacement
Q3
The hands suddenly start moving at
high speed.
This is due to the reason (or one of the
reasons) below, and does not indicate
malfunction. Simply wait until normal hand
movement resumes.
●
Watch is connected with a phone to correct
its time setting.
l
Auto Time Correction
Q4
The current time indicated by the
watch is off by one hour or 30
minutes.
The summer time setting may not be correct.
Select the correct setting.
l
Changing the Home City Summer Time
Setting
Q5
The time indicated by the hands is
different from the digital time.
Strong magnetism or impact can cause the
hands to go out of alignment. Adjust hand
alignment.
l
Adjusting Hand Alignment
●
Check the information below to find out how
to align the hands manually.
l
Hand Alignment Adjustment
Watch Operation Guide 5744
44
Battery
Q1
is flashing on the digital
display.
This indicates that battery power is getting
low.
Have the battery replaced.
l
Battery Replacement
Q2
[RECOVER] is flashing on the digital
display.
[RECOVER] may appear on the display when
the watch’s battery power is low, or if you use
the light or other function a number of times
during a short period, which momentarily
causes the battery level to go low. If this
happens, all watch functions, except for
timekeeping, are disabled.
If [RECOVER] remains on the display or if it
keeps appearing, it may indicate that the
battery needs to be replaced.
Other
Q1
I can’t find the information I need
here.
Visit the website below.
https://world.casio.com/support/
Watch Operation Guide 5744
45
Precautions
Operating Precautions
●
Water Resistance
●
The information below applies to watches
with WATER RESIST or WATER
RESISTANT marked on the back cover.
Water Resistance Under Daily Use
Marking on watch front or on
back cover
No BAR
mark
Example of Daily Use
Hand washing, rain Yes
Water-related work, swimming No
Windsurfing No
Skin diving No
Enhanced Water Resistance Under Daily
Use
5 Atmospheres
Marking on watch front or on
back cover
5BAR
Example of Daily Use
Hand washing, rain Yes
Water-related work, swimming Yes
Windsurfing No
Skin diving No
10 Atmospheres
Marking on watch front or on
back cover
10BAR
Example of Daily Use
Hand washing, rain Yes
Water-related work, swimming Yes
Windsurfing Yes
Skin diving Yes
20 Atmospheres
Marking on watch front or on
back cover
20BAR
Example of Daily Use
Hand washing, rain Yes
Water-related work, swimming Yes
Windsurfing Yes
Skin diving Yes
●
Do not use your watch for scuba diving or
other types of diving that requires air tanks.
●
Watches that do not have WATER RESIST
or WATER RESISTANT marked on the
back cover are not protected against the
effects of sweat. Avoid using such a watch
under conditions where it will be exposed to
large amounts of sweat or moisture, or to
direct splashing with water.
●
Even if a watch is water resistant, note the
usage precautions described below. Such
types of use reduce water resistance
performance and can cause fogging of the
glass.
ー
Do not operate the crown or buttons while
your watch is submersed in water or wet.
ー
Avoid wearing your watch while in the
bath.
ー
Do not wear your watch while in a heated
swimming pool, sauna, or any other high
temperature/high humidity environment.
ー
Do not wear your watch while washing
your hands or face, while doing
housework, or while performing any other
task that involves soaps or detergents.
●
After submersion in seawater, use plain
water to rinse all salt and dirt from your
watch.
●
To maintain water resistance, have the
gaskets of your watch replaced periodically
(about once every two or three years).
●
A trained technician will inspect your watch
for proper water resistance whenever you
have its battery replaced. Battery
replacement requires the use of special
tools. Always request battery replacement
from your original retailer or from an
authorized CASIO service center.
●
Some water-resistant watches come with
fashionable leather bands. Avoid
swimming, washing, or any other activity
that causes direct exposure of a leather
band to water.
●
The inside surface of the watch glass may
fog when the watch is exposed to a sudden
drop in temperature. No problem is
indicated if the fogging clears up relatively
quickly. Sudden and extreme temperature
changes (such as coming into an air
conditioned room in the summer and
standing close to an air conditioner outlet,
or leaving a heated room in the winter and
allowing your watch to come into contact
with snow) can cause it to take longer for
glass fogging to clear up. If glass fogging
does not clear up or if you notice moisture
inside of the glass, immediately stop using
your watch and take it to your original
retailer or to an authorized CASIO service
center.
●
Your water-resistant watch has been tested
in accordance with International
Organization for Standardization
regulations.
●
Band
●
Tightening the band too tightly can cause
you to sweat and make it difficult for air to
pass under the band, which can lead to skin
irritation. Do not fasten the band too tightly.
There should be enough room between the
band and your wrist so you can insert your
finger.
●
Deterioration, rust, and other conditions can
cause the band to break or come off of your
watch, which in turn can cause band pins to
fly out of position or to fall out. This creates
the risk of your watch falling from your wrist
and becoming lost, and also creates the risk
of personal injury. Always take good care of
your band and keep it clean.
●
Immediately stop using a band if you even
notice any of the following: loss of band
flexibility, band cracks, band discoloration,
band looseness, band connecting pin flying
or falling out, or any other abnormality. Take
your watch to your original retailer or to a
CASIO service center for inspection and
repair (for which you will be charged) or to
have the band replaced (for which you will
be charged).
●
Temperature
●
Never leave your watch on the dashboard
of a car, near a heater, or in any other
location that is subject to very high
temperatures. Do not leave your watch
where it will be exposed to very low
temperatures. Temperature extremes can
cause your watch to lose or gain time, to
stop, or otherwise malfunction.
●
Leaving your watch in an area hotter than
+60 °C (140 °F) for long periods can lead to
problems with its LCD. The LCD may
become difficult to read at temperatures
lower than 0 °C (32 °F) and greater than
+40 °C (104 °F).
●
Impact
●
Your watch is designed to withstand impact
incurred during normal daily use and during
light activity such as playing catch, tennis,
etc. Dropping your watch or otherwise
subjecting it to strong impact, however, can
lead to malfunction. Note that watches with
shock-resistant designs (G‑SHOCK,
BABY‑G, G‑MS) can be worn while
operating a chain saw or engaging in other
activities that generate strong vibration, or
while engaging in strenuous sports
activities (motocross, etc.)
Watch Operation Guide 5744
46
●
Magnetism
●
The hands of analog and combination
(analog-digital) watches are moved by a
motor that uses magnetic force. When such
a watch is close to a device (audio
speakers, magnetic necklace, cell phone,
etc.) that emits strong magnetism, the
magnetism can cause timekeeping to slow
down, speed up, or stop, resulting in the
incorrect time being displayed.
●
Timekeeping accuracy may be affected if
the watch itself becomes magnetized. Also,
very strong magnetism (from medical
equipment, etc.) should be avoided
because it can cause malfunction of your
watch and damage to electronic
components.
●
Electrostatic Charge
●
Exposure to very strong electrostatic
charge can cause your watch to display the
wrong time. Very strong electrostatic
charge even can damage electronic
components.
●
Electrostatic charge may cause temporary
blotching in blank areas of the LCD.
●
Chemicals
●
Do not allow your watch to come into
contact with thinner, gasoline, solvents,
oils, or fats, or with any cleaners, adhesives,
paints, medicines, or cosmetics that contain
such ingredients. Doing so can cause
discoloration of or damage to the resin
case, resin band, leather, and other parts.
●
Storage
●
If you do not plan to use your watch for a
long time, thoroughly wipe it free of all dirt,
sweat, and moisture, and store it in a cool,
dry place.
●
Resin Components
●
Allowing your watch to remain in contact
with other items or storing it together with
other items for long periods while it is wet
can cause color on resin components to
transfer to the other items, or the color of the
other items to transfer to the resin
components of your watch. Be sure to dry
off your watch thoroughly before storing it
and make sure it is not in contact with other
items.
●
Leaving your watch where it is exposed to
direct sunlight (ultraviolet rays) for long
periods or failure to clean dirt from your
watch for long periods can cause it to
become discolored.
●
Friction caused by certain conditions
(strong external force, sustained rubbing,
impact, etc.) can cause discoloration of
painted components.
●
If there are printed figures on the band,
strong rubbing of the printed area can cause
discoloration.
●
Leaving your watch wet for long periods can
cause fluorescent color to fade. Wipe the
watch dry as soon as possible after it
becomes wet.
●
Semi-transparent resin parts can become
discolored due to sweat and dirt, and if
exposed to high temperatures and humidity
for long periods.
●
Daily use and long-term storage of your
watch can lead to deterioration, breaking, or
bending of resin components. The extent of
such damage depends on usage conditions
and storage conditions.
●
Leather Band
●
Allowing your watch to remain in contact
with other items or storing it together with
other items for long periods while it is wet
can cause the color of the leather band to
transfer to the other items or the color of the
other items to transfer to the leather band.
Be sure to dry off your watch thoroughly with
a soft cloth before storing it and make sure
it is not in contact with other items.
●
Leaving a leather band where it is exposed
to direct sunlight (ultraviolet rays) for long
periods or failure to clean dirt from a leather
band for long periods can cause it to
become discolored.
CAUTION:
Exposing a leather band to rubbing or dirt
can cause color transfer and discoloration.
●
Metal Components
●
Failure to clean dirt from metal components
can lead to formation of rust, even if
components are stainless steel or plated. If
metal components exposed to sweat or
water, wipe thoroughly with a soft,
absorbent cloth and then place the watch in
a well-ventilated location to dry.
●
Use a soft toothbrush or similar tool to scrub
the metal with a weak solution of water and
a mild neutral detergent, or with soapy
water. Next, rinse with water to remove all
remaining detergent and then wipe dry with
a soft absorbent cloth. When washing metal
components, wrap the watch case with
kitchen plastic wrap so it does not come into
contact with the detergent or soap.
●
Bacteria and Odor Resistant Band
●
The bacteria and odor resistant band
protects against odor generated by the
formation of bacteria from sweat, which
ensures comfort and hygiene. In order to
ensure maximum bacteria and odor
resistance, keep the band clean. Use an
absorbent soft cloth to thoroughly wipe the
band clean of dirt, sweat, and moisture. A
bacteria and odor resistant band
suppresses the formation of organisms and
bacteria. It does not protect against rash
due to allergic reaction, etc.
Watch Operation Guide 5744
47
●
Liquid Crystal Display
●
Display figures may be difficult to read when
viewed from an angle.
●
Watch with Data Memory
●
Allowing the battery to go dead, replacing
the battery, or having your watch repaired
can cause all data in watch memory to be
lost. Note that CASIO Computer Co., Ltd.
assumes no responsibility for any damages
or losses caused by data lost due to
malfunction or repair of your watch,
replacement of the battery, etc. Be sure to
keep separate written copies of all
important data.
●
Watch Sensors
●
A watch sensor is a precision instrument.
Never try to take it apart. Never try to insert
any objects into the openings of a sensor,
and take care to ensure that dirt, dust, or
other foreign matter does not get into it.
After using your watch where it has been
immersed in saltwater, rinse it thoroughly
with fresh water.
Note that CASIO Computer Co., Ltd.
assumes no responsibility for any
damage or loss suffered by you or any
third party arising through the use of your
watch or its malfunction.
User Maintenance
●
Caring for Your Watch
Remember that you wear your watch next to
your skin, just like a piece of clothing. To
ensure your watch performs at the level for
which it is designed, keep it clean by
frequently wiping with a soft cloth to keep your
watch and band free of dirt, sweat, water and
other foreign matter.
●
Whenever your watch is exposed to sea
water or mud, rinse it off with clean fresh
water.
●
For a metal band or a resin band with metal
parts, use a soft toothbrush or similar tool to
scrub the band with a weak solution of water
and a mild neutral detergent, or with soapy
water. Next, rinse with water to remove all
remaining detergent and then wipe dry with
a soft absorbent cloth. When washing the
band, wrap the watch case with kitchen
plastic wrap so it does not come into contact
with the detergent or soap.
●
For a resin band, wash with water and then
wipe dry with a soft cloth. Note that
sometimes a smudge like pattern may
appear on the surface of a resin band. This
will not have any effect on your skin or
clothing. Wipe with a cloth to remove the
smudge pattern.
●
Clean water and sweat from a leather band
by wiping with a soft cloth.
●
Not operating a watch crown, buttons, or
rotary bezel could lead to later problems
with their operation. Periodically rotate the
crown and rotary bezel, and press buttons
to maintain proper operation.
●
Dangers of Poor Watch Care
Rust
●
Though the metal steel used for your watch
is highly rust-resistant, rust can form if your
watch is not cleaned after it becomes dirty.
ー
Dirt on your watch can make it impossible
for oxygen to come into contact with the
metal, which can lead to breakdown of
the oxidization layer on the metal surface
and the formation of rust.
●
Rust can cause sharp areas on metal
components and can cause band pins to fly
out of position or to fall out. If you ever notice
any abnormality immediately stop using
your watch and take it to your original
retailer or to an authorized CASIO service
center.
●
Even if the surface of the metal appears
clean, sweat and rust in crevasses can soil
the sleeves of clothing, cause skin irritation,
and even interfere with watch performance.
Premature Wear
●
Leaving sweat or water on a resin band or
bezel, or storing your watch an area subject
to high moisture can lead to premature
wear, cuts, and breaks.
Skin Irritation
●
Individuals with sensitive skin or in poor
physical condition may experience skin
irritation when wearing a watch. Such
individuals should keep their leather band
or resin band particularly clean. Should you
ever experience a rash or other skin
irritation, immediately remove your watch
and contact a skin care professional.
Watch Operation Guide 5744
48
Battery Replacement
●
Leave battery replacement up to your
original retailer or authorized CASIO
service center.
●
Have the battery replaced only with the type
specified in the “Specifications”. Use of a
different battery type can cause
malfunction.
●
When replacing the battery, also request a
check for proper water resistance.
●
Ornamental resin components may
become worn, cracked, or bent over time
when subjected to normal daily use. Note
that if cracking or any other abnormality
indicating possible damage is noticed in a
watch submitted for battery replacement,
your watch will be returned with an
explanation of the abnormality, without the
requested servicing being performed.
●
Initial Battery
●
The battery that comes loaded in your watch
when you purchase it is used for function
and performance testing at the factory.
●
The test battery may go dead quicker than
the normally rated battery life noted in the
“Specifications”. Note that you will be
charged for replacement of this battery,
even if replacement is required within your
watch’s warranty period.
●
Low Battery Power
●
Low battery power is indicated by large
timekeeping error, by dim display contents,
or by a blank display.
●
Operation while battery power is low can
result in malfunction. Replace the battery as
soon as possible.
Mobile Link Precautions
●
Legal Precautions
●
This watch complies with or has received
approval under the radio laws of various
countries and geographical areas. Using
this watch in an area where it does not
comply with or has not received approval
under applicable radio laws may be a
criminal offense. For details, visit the CASIO
Website.
https://world.casio.com/ce/BLE/
●
Use of this watch inside of aircraft is
restricted under the aviation laws of each
country. Be sure to follow the instructions of
airline personnel.
●
Precautions when using Mobile Link
●
When using this watch in combination with
a phone, keep the watch and phone close
to each other. A range of two meters is
recommended as a guideline, but the local
environment (walls, furniture, etc.), the
structure of a building, and other factors
may require a much closer range.
●
This watch can be affected by other devices
(electrical devices, audio-visual equipment,
office equipment, etc.) In particular, it can
be affected by operation of a microwave
oven. The watch may not be able to
communicate normally with a phone if a
microwave oven is operating nearby.
Conversely, this watch may cause noise in
radio reception and the video image of a TV.
●
Bluetooth of this watch uses the same
frequency band (2.4 GHz) as wireless LAN
devices, and use of such devices in close
proximity of this watch may result in radio
interference, slower communication
speeds and noise for the watch and the
wireless LAN device, or even
communication failure.
●
Stopping Radio Wave Emission by This
Watch
The watch is emitting radio waves whenever
the second hand is pointing to [R] or [C].
Also, the watch connects with a phone
automatically as described below.
●
Auto Time Correction (4 times per day)
●
While Mission Log is enabled (data
transferred each hour)
When in a hospital, on an aircraft, or in any
other area where the use of radio waves is not
allowed, use the operation below to stop radio
wave generation.
●
Stopping Radio Wave Generation
Press any button besides (L) to terminate
the Bluetooth connection.
Connected Disconnected
●
Disabling Auto Time Correction
Configure CASIO WATCHES phone app
settings to disable synchronization
between the watch and phone.
l
Using CASIO WATCHES to Disable
Auto Time Correction
Watch Operation Guide 5744
49
