Light Modes: press for 1 second to change to the next light mode
Press and hold for 2 seconds to turn off or on the lights
Source (Bluetooth / TF & SD card/ USB Flash Drive /Aux input):
press for 1 second to change to the next source
Power Button
Light Switch
Mode Switch
Driver Unit:
Woofer: 189*114mm
Midrange :2*89mm
Tweeter: 2*38mm
Power : 200W
Battery Capacity: 30000mAh ( 14.8V / 7500mAh)
Charging Port: USB Type C
Charging Method : Fast Charge 5V / 9V / 12V / 15V /20V
Charging time: About 4 Hours ( 20V / 3A)
Playing Time : 16H (Depends on volume and audio source)
Wireless Version: V5.3
Audio Code: SBC
Frequency Response:40Hz-20KHz
Signal to Noise Ratio: ＞80dB
Product Size: 525*21 0*268mm
Bare Unit
Weight: 7.64KG
Power On / Off
Play / Pause
Bluetooth / Dual pairing
Bass+
Charging Indicators
Mode Switch
Volume- / Previous Track
Volume+ / Next Track
EQ Switch
Light Options
Wired Microphone
User Maunal
3.5mm Aux Cable
Type-C Charging Cable User Manual
Package Content
1 2 3 4 5 6 7 8
Bluetooth Pairing
Product Specifications
-Turn on the speaker and find the speaker name 'OontZ Angle 3XL ULTRA
Gen2' in the Bluetooth settings on your phone.
-Select the device 'OontZ Angle 3XL ULTRA Gen2' to connect.
Friendly reminder
: If the speaker name doesn't appear in the Bluetooth
settings on your smartphone, make sure the speaker is in pairing mode.
Pairing button should be flashing. If solid, the speaker is connected to
another device, press the Pairing button for 1 second to disconnect from
the other device.
1. Pair and connect to your device
This speaker is able to charge your smartphone while playing audio.
Connect your smartphone to the Port labeled USB with a USB-A
cable. If there is no audio being played the speaker will automatically
shut off after 30 minutes and will no longer charge your Smartphone.
Other Functions
Button Configuration
Play/Pause: Press Once
Play /
Pause Button
Turn up Volume: Short press Once
Next Song: Press and hold for 2 seconds
Volume+
Turn down Volume: Short press Once
Previous Song: Press and hold for 2 seconds
Volume-
Power on/off：long press for 2 seconds
Bluetooth pairing: If flashing ready to pair to your device. If solid
connected to another device, press for 1 second to disconnect the other
device. Refer to Page 7 - '1. Pair and connect your
device' for pairing and connecting with your smartphone.
BASS BOOST ON/ BASS BOOST OFF
Indoor / Outdoor
Dual speaker mode: Connect two speakers together to play in
dual stereo. Press for 2 seconds to enter or exit Dual speaker
mode. Refer to Page 7 - '2. Dual speaker mode' for pairing and
connecting two speakers together.
Speaker does not respond: Press and hold for 8 seconds to reset
Pairing Button
OontZ Angle 3XL ULTRA Gen2
My device
BT
Settings Bluetooth
USB flash drive /
USB-A Smartphone Charging
Wired Microphone
Reset Port
TF card Slot
Aux input
Type C charging
User Guide
Port Configuration
Button Function Details
2. Dual speaker mode
-Power on both speakers. Both should have a flashing 'Pairing button'
to indicate in pairing mode.
-Press and hold the "Pairing button" on Speaker A for 2 seconds until
the White light starts to flash.
-Speaker B will automatically search for and pair with Speaker A.
-Once successfully paired together, the 'Pairing button' on Speaker A
will flash White quickly and Speaker B will flash White slowly.
-Select Speaker A in the Bluetooth settings on your smartphone.
Aux input
Connect the speaker to a music player/mobile via 3.5mm audio cable
(provide as accessory) and the music can be played automatically.
TF/SD card mode
Insert a card to the speaker and it can play music automatically.
Reset
EQ Switch
USB flash drive mode
Long Press“ ” 8s to reset the speaker, If the reset is successful, the
speaker will automatically shut down
Automatic shutdown
1)If not paired with any device or if there is no playback after pairing,
the speaker will automatically shut down after 30 minutes.
2)When the speaker battery is low, it will also automatically shut down
RF exposure statement
FCC Warning
This equipment complies with the FCC radiation exposure limits
set forth for an uncontrolled environment. This transmitter must
not be co-located or operating in conjunction with any other
antenna or transmitter.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interfer-
ence that may cause undesired operation.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
Note 2: Any changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user's authority to operate the equipment.
9
USB-A smartphone Changring
Insert a USB flash drive to the speaker and it can play music
automatically.Supports MP3, WAV and FLAC audio formats.
Press the EQ button once to switch EQ. Green light is indoor
mode,Blue light is outdoor mode.
Bass+
Press the bass+ button once to switch. White light is bass boost
off,Blue light is bass boost on.
Microphone:
Plug in a wired microphone to use the microphpne function.
3 Gen2
User Guide
3 Gen2
