Wait until the LED is solid on (blue or red) before
moving on.
4
The LED is on the front panel of the router.
1. Download the Tether app.
To enjoy a more complete service from TP-Link,
bind your TP-Link ID to the router.
Scan for Tether
Tether
or
2. Open the Tether app and log in with your
TP-Link ID.
Note: If you don’t have an account, create one rst.
Method ONE: Via the TP-Link Tether App
Set Up the Network
2
• Unplug the power
backup battery if it has one.
• Keep the router vertical while working. Refer to Q4 of Need Help to
place the router for optimal Wi-Fi performance.
1
Connect the Hardware
LED Explanation
You can check the router’s working
status by following the LED Explanation.
Pulsing Blue The router is being upgraded.
Blinking Blue WPS connection is being
established, or the router is
your router.
Solid Blue The router is working normally.
Pulsing Orange The system is starting up.
Solid Orange
Blinking Red The router is disconnected from
Solid Red The router is disconnected from
the internet.
Button Explanation
Physical buttons are located on the
back of the router.
Press the WPS button,
and immediately press
the WPS button on your
client device to start the
WPS process.
Press the LED button
to turn on or o the
LED of your router.
Press to turn
on/o the router.
Power Button
Press and hold this
button for about 2
seconds to turn on
or o the wireless
function of your
router.
LED Button
Wi-Fi Button
WPS Button
RESET Button
Press and hold this button
until the LED blinks to
reset the router to its
factory default settings.
Modem
Unplug the power
Power on the modem, and then wait
about 2 minutes for it to restart.
2
Connect the powered-o modem to the
router’s Internet port with an Ethernet cable.
1
Internet
Keep the router vertical
Connect the power adapter to the router. Then
press the Power button to turn it on.
3
1. Connect your device to the router
wirelessly or with an Ethernet cable.
Method TWO: Via a Web Browser
2. Launch a web browser and enter
http://tplinkwi.net or http://192.168.0.1 in
the address bar. Create a password to log in.
3. Follow the step-by-step instructions to set
up the internet connection and register for
the TP-Link Cloud service.
Note: If the login window does not appear, please
refer to Q1 of Need Help in this guide.
The default wireless network names (SSIDs) and
password are printed on the label at the bottom
of the router.
New Password:
Let’s Get Started
You can also nd them on the Wi-Fi info card
provided in the package.
Wireless Password/PIN:XXXXXXXX
SSID:TP-Link_XXXX
SSID:TP-Link_XXXX_5G
SSID:TP-Link_XXXX_6G
Note: Due to Tether app updates, your actual user
interface and pathway may differ from those
depicted here.
Add Device
Create a new Wi-Fi network.
Add a Router
Extend your existing wireless network
with a range extender.
Add a Range Extender
>
>
3. Tap the button in the Tether app and
select Add a Router. Follow app instructions
to complete the setup and connect to the
internet.
Q1. What should I do if I can’t access the web
management page?
•
Reboot your router and try again.
•
If the computer is set to a static IP, change its
settings to obtain an IP address automatically.
•
Verify that http://tplinkwi.net is correctly
entered in the web browser. Alternatively, enter
http://192.168.0.1 or http://192.168.1.1 in the
web browser.
•
Use another web browser and try again.
•
Disable and enable the network adapter in use.
Q2. What should I do if I can’t access the internet?
•
Power o your modem for about 5 minutes, then
power it on and check the internet. If your
modem has more than one Ethernet port, keep
the other ports unconnected.
•
Check if the internet is working normally by
connecting a computer directly to the modem
via an Ethernet cable. If it is not, contact your
internet service provider.
•
L
og in to the web management page, and go to
the Network Map page to check whether the
internet IP address is valid or not. If it’s valid, go to
Advanced > Network > Internet, click Advanced
Settings, select Use the Following DNS
Addresses, set the primary DNS to 8.8.8.8, and
set the secondary DNS to 8.8.4.4. If it is not,
check the hardware connection or contact your
internet service provider.
•
For cable modem users, log in to the web
management page of the router and go to
Advanced > Network > Internet > MAC Clone.
Select Clone Current Device MAC and click
SAVE. Then reboot both the modem and the
r
outer.
Q3. What should I do if I forget my wireless
password?
• If you have not changed the default wireless
Need Help?
For technical support, replacement services, user
guides, and other information, please visit
https://www.tp-link.com/support.
With the USB port, it’s easy to share les and media with multiple devices. Visit
https://www.tp-link.com/app/usb to learn more about the USB applications.
Media Server: Play media from the USB drive on your computer
Local Storage Sharing:
Remote Access: Access the USB drive when you are away from home
USB Applications
For more details, visit
https://www.tp-link.com/homeshield.
Parental Controls
Manage online time and block
inappropriate content to
maintain healthy online habits.
Comprehensive Reports
Gain full statistics and insights
to help you know your home
network better.
Quality of Service (QoS)
Prioritize your bandwidth
needs for a better networking
experience.
Network Protection
Detects cyber threats to keep
your privacy and connected
devices well protected.
TP-Link HomeShield premium security
services keep your home network safe
with cutting-edge features. Download the
Tether app to enjoy HomeShield features.
TP-Link HomeShield
EasyMesh-Compatible
Flexible Scalability
One-Click Settings
Press the WPS button on the main router and the
satellite device within 2 minutes of each other, then
the EasyMesh network is all set up.
Seamless Roaming
Connects mobile devices to your routers or
extenders that provide the best coverage. Devices
compatible with EasyMesh also share a single
Wi-Fi name so you stay connected in every room.
For more information, visit
https://www.tp-link.com/easymesh/
can be established between all APs from TP-Link.
You can experience strong, stable, and
seamless wireless connections
throughout your home with EasyMesh.
Setup Video
environments.
· Do not attempt to disassemble, repair, or modify the device. If
you need service, please contact us.
· Do not use any other chargers than those recommended.
· Do not use damaged charger or USB cable to charge the
device.
· Do not use the device where wireless devices are not allowed.
· Adapter shall be installed near the equipment and shall be
easily accessible.
Tri-Band Wi-Fi 7 Router
Quick Installation Guide
password, it can be found on the label at the
bottom of the router.
• Connect a computer directly to the router using
an Ethernet cable. Log in to the router’s web
management page at
and go
to the Wireless page to retrieve or reset your
wireless password.
Q4. How should I position my router for optimal
Wi-Fi performance?
• Keep the router vertical while working.
• Don’t place your router in a corner or in a closet.
• Avoid obstacles and high-powered appliances.
• Keep your router in a central location at a certain
height.
TP-Link hereby declares that the Tri-Band Wi-Fi 7 Router is in
compliance with the essential requirements and other relevant
provisions of directives 2014/53/EU, 2009/125/EC, 2011
/65/EU and (EU) 2015/863.
The original EU declaration of conformity may be found at
https://www.tp-link.com/en/support/ce
TP-Link hereby declares that the Tri-Band Wi-Fi 7 Router is in
compliance with the essential requirements and other relevant
provisions of the Radio Equipment Regulations 2017.
The original UK declaration of conformity may be found at
https://www.tp-link.com/support/ukca
©2025 TP-Link 7100001579 REV1.2.1
