User’s Guide and Operator Instructions
CBS-2231 & CBS-2232 Next Generation Brewing System
FETCO Next Generation-NG® Commercial Beverage Equipment
CBS-2231 CBS-2232
(Dispensers not included) (Plastic brew baskets are standard, brewers avalible with optional stainless steel brew baskets)
CONTACT INFORMATION
FETCO® FOOD EQUIPMENT TECHNOLOGIES COMPANY
600 ROSE ROAD
LAKE ZURICH • IL • 60047-0429 • USA
Product made in USA
INTERNET: www.fetco.com
PATENTS:https://www.fetco.com/pl,pages,patents,74.html
©2020-2024 FOOD EQUIPMENT TECHNOLOGIES COMPANY
PHONE: (800) 338-2699 (US & CANADA)
(847) 719-3000 (All Countries and International)
FAX:(847) 719-3001
EMAIL:sales@fetco.com
orders@fetco.com (to order parts and equipment)
techsupport@fetco.com (all service queries)
P215 REV000 January 2024
COFFEE BREWER CBS-2230NG Series
TABLE OF CONTENTS
Rough-In Drawings ...................................................... 2
Electrical and Output Specifications ............................ 3
Programming Menu ..................................................... 5
Brew Recipes ............................................................... 5
Inputs ........................................................................... 7
Service ......................................................................... 7
Hot Water Portions ....................................................... 9
Calibration .................................................................. 10
Outputs ....................................................................... 11
Counters ..................................................................... 12
Brewer Setup .............................................................. 13
Installation Guide........................................................ 15
Operator Training ....................................................... 16
Parts diagrams ........................................................... 18
fetco.com
2 P215 REV000 February 2023
Specifications and Requirements
FETCO CBS-2230 Brewers have unique construction only available for these models.
Water Requirements:
Coffee Filter Size:
CBS-2230 20-75 psig, (138-517kPa) 1½ gpm/(5.7 lpm)
13” X 5 or FETCO# F002”
Optimal water hardness between 125-250 TDS (6-13 grain)
Important! Please use a water filter for all beverage equipment
Temperature, as set by factory:
200°F (93°C) inside water tank (at sea level)
Water inlet fitting: 3/8 inch male flare.
Brewer supplied with inlet valve adaptor for BSP to SAE
Electrical: See electrical configuration chart Pg 3.
Brew Volume: Full Batch
3.8 L/1.0 gal brew
Brew Capacity
(approximate)
CBS-2231 4-8 brews per hour
CBS-2232 5-16 brews per hour
Output is controlled by heater power and water temperature
Total Brew Cycle: Factory setting: 6 minutes consisting of 4 min. brew time and 2.0 min. drip delay
Individual menu brew-process parameters are user controllable for:
Basic user controls for brew volume, brew time, units of measure, recipe name
Advanced user controls for pulse count, prewet percent and prewet delay, drip delay, programmable energy saving
See pages 4-5 for how to adjust controls for temperature, brew volume, units - and all other settings
Weights and Capacities
Model Height Width Depth
Water tank
capacity
Empty
Weight
Filled
Weight
Shipping
Weight
Shipping Dimensions
CBS-2231
Brewer
27 3/4 in
700 mm
11 3/4 in
300 mm
20 3/8 in
520 mm
3.3 gallon
12.4 L
29 lbs
13.2 kg
55 lbs
25.0 kg
41 lbs
18.6 kg
30” x 17” x 22”
76.2 x 43.2 x 55.9 cm
CBS-2232
Brewer
27 3/4 in
700 mm
19 ¾ in
500 mm
20 3/8 in
520 mm
6.0 gallon
22.4 L
47 lbs
21.3 kg
92 lbs
41.7 kg
55 lbs
25.0 kg
30” x 23” x 25”
76.2 x 58.4 x 63.5 cm
Calibrated for
3.8 L/1.0 gal brew
Brew Basket 13” X 5” Coffee Filter 13” X 5 or FETCO# F002”
1” legs standard
2.5” legs optional
Rough-In Drawings
CBS-2231 Front CBS-2232 Front CBS-2231 1 & CBS-2232 Side Power cord plug
EXAMPLE: SKU E2231US-1X117-PM001 SKU NUMBER IDENTIFICATION KEY
Product Line
Level Family Region ID Phase Voltage Range
# Heaters
Individual Heater
Wattage
Brew
Basket
Hot Water
Faucet
Bypass
Brew Basket
Locks
Power Cord
E
2
2
3
1
U
S
1
A
1
1
5
P
M
0
0
1
E=extractor
US =United
States
1 A = 100-120 1 1.5 P=plastic M=manual 1=Yes 1=Yes 0=Terminal Block
12=PLUS
Series
31=
single side
IN =
International
2 B = 200-240 2 1.7 M=metal A=automatic 0=No 0=No 1= NEMA 5-15P
22=Next
Generation
32=
dual side
CE = IEC 3 C = 380-415 3 2.3
C=metal
with clips
N=None
2=NEMA 5-20P
NM = NOM
U = 1 or 3
D = 440-480
6
3.0
3=NEMA 6-15P
4.0
4=NEMA 6-30P
X=120 or 240
Dual Voltage
5.0
5=CEE 7/7
Schuko
6=UK1-13P
7= AUSTRALIAN
AS3112 (YP-35)
3 P215 REV000 February 2023
Electrical and Output Specifications
Customer options
BREW BASKET TYPE
(P, M )
HOT WATER FAUCET
(M, A OR N)
BYPASS
(1 OR 0)
Brew Basket Lock
(1 OR 0)
* is factory standard feature
Add all the following numbers
after all SKU numbers
*P=Plastic
M=Gourmet Metal
*M=Standard manual
A=Automatic electronic
N=No hot water faucet
*1=With
0=None
*1=With
0=None
CBS-2231Next Gen Single 3.0-4.0 Liter Coffee Brewers Field configurable Domestic
Electrical and Output Specifications Brewer has factory installed cord and plug & terminal block 50Hz or 60Hz
SKU
Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2231US-1X117-PA011
120
1 X 1.7 kW
2+G
1.7
NEMA 15-5P
1
14.7
3.9 gal/14.8 L
Domestic-Dual Voltage
208-240
2 X 1.7 kW
2+G
2.6-3.4
Terminal Block
1
12.8-14.7
5.8 gal/22 L
Electrical Specifications, Domestic Single brewer
-single voltage 120 volt cord and plug single phase 50Hz or 60Hz
CBS-2231Next Gen Single 3.0-4.0 Liter Coffee Brewers Domestic models
Electrical and Output Specifications All brewers have factory installed cord and plug 50Hz or 60Hz
SKU
Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2231US-1A115-PA011
120
1 X 1.5 kW
2+G
1.5
NEMA 15-5P
1
13.0
4.0 gal/15.1 L
E2231US-1A123-PA012
120
1 X 2.3 kW
2+G
2.3
NEMA 5-20P
1
19.7
5.8 gal/22 L
CBS-2231Next Gen Single 3.0-4.0 Liter Coffee Brewers Field configurable NOM (Mexico) In Spanish
Electrical and Output Specifications Brewer has factory installed cord and plug & terminal block 50Hz or 60Hz
SKU
Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2231NM-1X123-PA012
120
1 X 2.3 kW
2+G
2.3
NEMA 5-20P
1
19.7
6.1 gal/23.2 L
Dual Voltage
208-240
2 X 2.3 kW
2+G
4.6
Terminal Block
1
17.1-19.7
7.6 gal/30 L
NM in SKU suffix (above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide
CBS-2231Next Gen Single 3.0-4.0 Liter Coffee Brewers International models
Electrical and Output Specifications All brewers have terminal block electrical utility connection 50Hz or 60Hz
SKU
Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2231NM-1A123-PA012
120
1 X 2.3 kW
2+G
2.3
NEMA 5-20P
1
19.7
5.8 gal/22 L
E2231NM-1A123-PA012
208-240
1 X 3.0 kW 2+G 2.3-3.0
NEMA 6-15P 1 11.3-13.0
7.9
gal/30.0 L
NM in SKU suffix
(above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide
E2231IN-1B123-PA010
200-240
1 X 2.3 kW
2+G
1.6-2.3
Terminal Block
1
8.5-10.1
5.8 gal/22 L
E2231IN-1B130-PA010
200-240
1 X 3.0 kW 2+G 2.1-3.0
Terminal Block
1 10.9-13.0
7.7 gal/29.1 L
CBS-2231Next Ge n 3.0-4.0 Lit er C off ee Br ewer s CE m o dels
Elect ric al an d O utp ut Spe cifi cat ion s Sch uko cor d an d pl ug 50Hz
SKU Voltag e Heater Configuration Wir es KW Elec tri cal C on necti on Phase Amp Dr aw Brew-V olum e per ho ur
E223 1CE-1B123-PA0 15
230
1 X 2.3 kW
L/N/ PE
2.1
CEE 7/7 Shuko
1
9.7
5.8 g al/ 22 L
E223 1CE-1B130-PA0 15 230 1 X 3.0 kW L/N/PE 2.8 CEE 7/7Shuk o 1 12.5 7.7 g al/ 29. 1 L
CBS-2232Next Gen Dual 3.0-4.0 Liter Coffee Brewers Domestic models
Electrical and Output Specifications All brewers have terminal block electrical utility connection 50Hz or 60Hz
SKU Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2232US-1B223-PA010
208-240
2 X 2.3 kW
2+G
3.5-4.6
Terminal Block
1
17.1-19.7
11.0 gal/42.0 L
E2232US-1B223-MA110
208-240
2 X 2.3 kW
2+G
3.5-4.6
Terminal Block
1
17.1-19.7
11.0 gal/42.0 L
E2232US-1B230-PA010
208-240
2 X 3.0 kW
2+G
4.5-6.0
Terminal Block
1
22.2-25.5
14.3 gal/54 L
E2232US-1B230-PA110
208-240
2 X 3.0 kW
2+G
4.5-6.0
Terminal Block
1
22.2-25.5
14.3 gal/54 L
E2232US-1B230-MA110
208-240
2 X 3.0 kW
2+G
4.5-6.0
Terminal Block
1
22.2-25.5
14.3 gal/54 L
CBS-2232Next Gen Dual 3.0-4.0 Liter Coffee Brewers International models
Electrical and Output Specifications All brewers have terminal block electrical utility connection 50Hz or 60Hz
SKU Voltage
Heater
Configuration
Wires KW
Electrical
Connection
Phase Amp Draw
Brew-Volume
per hour
E2232IN-1B223-PA010
200-240
2 X 2.3 kW
2+G
3.2-4.6
Terminal Block
1
16.5-19.7
12.2 gal/46.3L
E2232IN-1B230-PA010
200-240
2 X 3.0 kW
2+G
4.2-6.0
Terminal Block
1
21.3-25.5
15.8 gal/60 L
E2232IN-1B230-MA110
200-240
2 X 3.0 kW
2+G
4.2-6.0
Terminal Block
1
21.3-25.5
15.8 gal/60 L
E2232NM-1B230-PA010
208-240
2 X 3.0 kW
2+G
4.5-6.0
Terminal Block
1
22.2-25.5
15.8 gal/60 L
NM in SKU suffix (above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide
CBS-1232PLU S Du al 3. 0-4.0 Lite r Cof fe e B rewe rs CE m od els
Elect rical an d Outp ut Spe cific ation s Al l br ewers h ave t erm in al bl oc k el ectri cal uti lity co nnec ti on 50Hz
SKU
Voltag e
Heater Configuration
Wir es
KW
Elec tric al C onn ecti on
Phas e
Amp Dr aw
Brew-V olum e per ho ur
E223 2CE-1B223-PA0 10
230
2 X 2.3 kW
L/N/ PE
4.2
Term inal Bl ock
1
18.9
11.0 gal/42.0 L
E223 2CE-1B230-PA0 10
230
2 X 3.0 kW
L/N/ PE
5.5
Term inal Bl ock
1
25.5
14.9 gal/56 L
E223 2CE-2B223-PA0 10
230/ 400
2 X 2.3 kW
2L/N/PE
4.2
Term inal Bl ock
2
9.7
11.0 gal/42.0 L
E223 2CE-2B230-PA0 10
230/ 400
2 X 3.0 kW
2L/N/PE
5.5
Term inal Bl ock
2
12.5
14.9 gal/56 L
4 P215 REV000 February 2023
Layout of the brewer
Operation and service
Operation
.
Service
Layout for installing brewer (back side)
Brew basket sensor (internal)
LED Status indicator bar
Touch-screen
(for brewer operation)
Brew basket
Hot Water Service Faucet
(not on all models)
Air pot or Dispenser Locator
(1 gallon/3 liter models)
Main power switch
Fast Start brewing
Programming
To enter
programming
1.
Turn the power switch
“OFF”, then “ON”
Bootup will begin.
After 15 second bootup
.
Tap the FETCO of the
screen, shown on
right
2.
(Shown right)
Operator
password is
1,2,3,4: Note: For
general use
Service password
is 9,8,7,6 Note:
Do
not distribute this
number
3.
Make changes and
adjustments from
the Programming
Menu screen
(Shown right)
See progamming
menu layout next
page
Bootup screen
Password screen
Programming access
Enter Password
_ _ _ _
CANCEL
MAIN
Brew
Recipes
Hot Water
Portions
Settings
Calibration
Outputs
Inputs
Counters
Service
EXIT
Starting The Brew
1. Turn the power switch “ON”. (Twin Shown)
2. Prepare a brew basket with the correct size filter and appropriate
amount of coffee. (4-8 ounces or 113-227 grams for 1 gal/3.8 liters)
3. Slide the brew basket completely into the rails.
4. Place a clean, empty, preheated dispenser under the brew basket.
5. Select a batch & touch the corresponding BREW icon
(Batch #1 selected in illustration), then press “START”
6. -STOP icon will illuminate,
-Countdown time will display, with proportional graphic circle icon
-LED indicator will pulse.
-All other BREW icons for that brew head will be hidden.
….-Opposite side BREW icons on dual brewer remain active
7. When the brew cycle is finished,
-Spray icon will extinguish, and the BREW circular icon will remain.
This indicates that coffee may still be dripping from the brew basket
For safety- do not remove brew basket until drip-out is complete.
Twin Brewer ready to brew.
Batch one-top left brew position selected
Brew in process
Batch one selected
START
12:35pm 04.14.2020 87°C/93°C
Batch 1
1.5 gal
6:00
Batch 5
1.5 gal
6:00
Batch 6
1.5 gal
6:00
Batch 7
1.5 gal
6:00
Batch 8
1.5 gal
6:00
CANCEL
HOT WATER
Batch 1
1.5 gal
6:00
6:00
12:35pm
04.14.2020 87°C/93°C
Batch 5
1.5 gal
6:00
Batch 6
1.5 gal
6:00
Batch 7
1.5 gal
6:00
Batch 8
1.5 gal
6:00
S
TOP
HOT WATER
5 P215 REV000 February 2023
Programming Menu
Layout
Brew Recipes
Settings
Inputs
Service
Hot Water Portions
Calibrations
Outputs
Counters
|
|
|
|
|
|
|
Batch On/Off & Name
Temperature
Brew Basket
Select Model
Continuous
Flow Rates
Brew Valve(s)
(For Service)
|
|||
|||
|
|
|||
|
BREW TIME
(Tank Temperature)
(Sensor)
Backup or Restore
Volume 1.
(Water Valves)
Fill Valve
|
|||
|||
|
|
|||
|
Prewet
(Brew at Temp.)
(Lock Sensor)
Restore to factory
Volume 2
((Brew left))
Heater SSR
|||
|||
|
|
|||
|
(Prewet Percent)
(Show tank temp?)
Liquid Level
Volume 3
((Brew right))
Light Bar
|||
|||
|
|||
|
(Prewet Delay)
(Show setpoint temp?)
Temp Sensor
((Bypass left))
Bypass Valve(s)
|
|
|
|||
|
Bypass Percent
Units Of Measure
Peripherals
((Bypass right))
Faucet Valve
|
|||
|||
|
Drip Delay
(Temperature)
(Faucet Valve)
Brew Basket Lock
|
|||
|||
|
Volume
(Volume)
(Fill Compenstion)
Extra Outputs
|
|||
|||
Number of Pulses
(Faucet)
((Off))
|
|
|||
Bypass
Demo Mode
((1.5x))
|
|
|||
Copy Batch
Date And Time
((2.0x))
||
|
|
Copy Batch: From
Status Light
LLC Sensitivity
||
|
|
Copy Batch: To
Hot Water
((Normal))
|
((High))
For electronic faucet
Activates for service
TO ACCESS PROGRAMMING
Turn brewer OFF then ON
When the bootup screen
appears touch the FETCO
logo
Touch the FETCO logo when
the password screen appears
Touch Brew Recipes for
setting the brew
er parameters
for each menu item
Batch 1 will be selected
Touch Batch 1 to set the brew
parameters.
Prewet will be selected
Touch Prewet icon to adjust
prewet
The chart below describes the
icons shown on this screen
Touch and slide to desired
setting. Touch BACK when
complete and make further
adjustments or press BACK
and SAVE & EXIT.
Brew Recipes
Program Items
Factory set Default
Programming Range
Notes
Batch Name
Batch On/Off
All “ON”
On/Off
Only top batch(s) are always enabled
Batch Name
Customize Name
Batch (1-4 L) (5-8 R)
Complete keypad
Scroll and tap three virtual keypads
Brew Time
Time of brew
4:00 minutes
2:00-12:00 mins/secs
Add to prewetting and drip delay times
Prewet Prewet percentage
0 0-25% brew volume
Initial wetting to stabilize very fresh
coffee
Prewet
Prewet delay time
1:00 sec.
0:10 sec to 5:00 min
Pause after coffee bed is prewetted
Drip Delay Pause after brew 2:00 min:sec. 00.30 to 6:00
Time that brew basket remains locked
during drip-out. This is a safety
feature.
Brew Volume
Total volume
1 gallon/3.8 liters
0.5-1.25 gal./0.95-4.75 liters
Factory set for 1 gallon dispenser
Number of Pulses Start/stop in brew 8 4-20
Algorithm evenly divides brew time
cycle
Bypass Percentage
Diverts brew water
0
0-40% of brew volume
Affects flavor, strength and mouth-feel
Copy & Paste Menu
Current recipe
Paste into all other recipes
Will paste selected into the other
CBS-2252
UI ver: 0.0.02t2020-0616a
UI Date: Jun 16 2020 09:12:53
IO ver: 0.0.0.2t2020-0610
IO Date: June 10 2020 10:26:27
Soft . Ver. 09:12:53
Bootloader ver. 0.23
Hardware ver. 1.01
©
2019 Food Equ ipment Technolo gies Com pan y
Enter Password
_ _ _ _
CANCEL
MAIN
Brew
Recipes
Hot Water
Portions
Settings
Calibration
Outputs
Inputs
Counters
Service
EXIT
Main>Recipi es
Batch L1
BATCH 1
1.5 gal/6:00
Batch R1
BATCH 5
1.5 gal/6:00
Batch L2
BATCH 2
1.5 gal/6:00
Batch R2
BATCH 5
1.5 gal/6:00
Batch R3
BATCH 6
1.5 gal/6:00
Batch L3
BATCH 3
1.5 gal/6:00
Batch R4
BATCH 8
1.5 gal/6:00
Batch L4
BATCH 4
1.5 gal/6:00
BACK
Main>Recipes>L1
Batch Name
Batch 1
ON
Volume
1.50 gal
Brew Time
4:00 min
Number of Pulses
4
Bypass
0%
Prewet
0%
0:30 min
Copy Batch
And
Paste To
Drip Delay
1:30 min
BACK
Main>Recipes>L1>Prewet
Prewet Percen tag e 0
0 % 25
--------- ---- ---- -------- ---------
Prewet Delay 0:30
0:10 mm;ss 5:00
--------- ---- ---- ---- ---------
BACK
6 P215 REV000 February 2023
Settings
Program Items
Factory set
Default
Programming Range Notes
Temperature
Tank Temperature
200°F/92°C
170-208°F/77-98°C
Hot water tank, brewing water temp.
Temperature
Brew at Temperature*
ON
OFF/ON
See note below
Temperature
Show Tank Temp.
ON
OFF/ON
Shows 1
st
at top right screen
Temperature
Show Setpoint Temp.
ON
OFF/ON
Shows 2
nd
at top right screen
Units of Measure
Temperature
Volume
Hot water Faucet
F° - Fahrenheit
Gal-Gallons
ml - Milliliters
NO or YES
Main>Settings>UNITS
Temperature °F °C °
Volume gal L
Faucet
oz ml
ECO Mode
ON/OFF
Eco idle time (to start)
Eco Tank temperature
OFF (default)
(if activated)
1 hour 169°F
Turn on or off
1-6 hours
158°F to 176°F
Screen will display Eco Mode when
activated-will take time to reheat to
set brew water temperature
Water Filter
Water filer installed
Rated filtering volume
NO
2625 gallons
NO or YES
250 gallons to 3950 gallons
Demo Mode
Brewer ON Disables
valves & heaters
OFF OFF/ON For training and user familiarization
Hot Water
Digital H. Wtr Faucet
Auto
ON/OFF/Automatic
Automatic activates portion control
Status Light
READY LED color
White
White/Blue/Green
Color when brewer is ready to brew
Screen Saver
Covers recipe screen
OFF
ON/OFF & Timeout setting
“OFF” leaves recipe screen
Date and Time
Set unit date and time
12 hour format
12/24 hour format & date
Store in real time clock
NOTES: Brew at Temperature*
Brew At Temp: “ON”
(Default: factory programmed into brewer)
“BREW START” will not be accessible until tank temperature is at set point.
“BREW START” becomes accessible when hot water tank is at the selected temperature.
Menu screen will be dimmed if tank temperature is low
Brew At Temp: “OFF” USER SELECTABLE (Not recommended)
Allows brewing at any temperature above 170°F/77°C.
May not apply for two sided brewer if one side is in brew cycle
Altitude Correction Chart
Chart to correct for altitude for boiling point
in tank water temperature.
[ft] [m]
Suggested
Setting[°F]
Boiling
point[°F]
Suggested
Setting[°C]
Boiling
point [°C]
0
0
205
212.0
96
100.0
500
152
205
211.0
96
99.5
1000
305
200
210.1
93
98.9
2000
610
200
208.1
93
97.8
2500
762
200
207.2
93
97.3
3000
914
200
206.2
93
96.8
3500
1067
197
205.3
92
96.3
4000
1219
195
204.3
91
95.7
4500
1372
194
203.4
90
95.2
5000
1524
194
202.4
90
94.7
5500
1676
193
201.5
89
94.2
6000
1829
192
200.6
89
93.6
6500
1981
191
199.6
88
93.1
7000
2134
190
198.7
87
92.6
7500
2286
188
197.8
86
92.1
8000
2438
187
196.9
86
91.6
8500
2591
185
196.0
85
91.1
Brew At Temperature
Ideal brew water temperature is 200°F/93°C. After brewing, brewers can take time to
recover the hot water tank temperature and signal READY to brew. This is called
“recovery time”. The lag in recovery time is caused rapid brewing cycles in a rush, low
power heating elements, cold water supply temperature even the barometric pressure.
Operators will adjust the “Brew At” temperature to allow the brewing at lower
temperatures. This will allow a slightly faster recovery time and give a small increase
in brew cycles per hour.
Reduced brew temperature will always compromise the quality
of the finished brew and
lower the temperature of the customers coffee.
Faster Brew Cycle/reduced extraction lower temperature Correct flavor/proper extraction temperature
Faster brew cycle Correct brew water temperature
Compromised Extraction Proper Extraction
170°F/77°C 180°F/82°C 190°F/88°C 200°F/93°C
7 P215 REV000 February 2023
Inputs
Program Items
Factory set
Default
Programming Range Notes
Brew Basket
Sensor
Displays activity
Brew basket in place?
LEFT RIGHT (green=on;red=off)
Brew Basket
Lock Sensor
Displays activity
Brew basket locked?
LEFT RIGHT (green=on;red=off)
Liquid Level
LOW
Not used
Not used
Not used
Liquid Level
HIGH
Hot water tank fill
Filled/Not Filled & signal
Green=Filled/Red=Not Filled
Temp. Sensors
Sensor 1
Hot water tank temp.
Actual temperature & signal
Temp. Sensors
Sensor 2
Not used
Not used
Not used
Peripherals
USB1
Digital input/output
Displays activity
(green=active;red=off)
Peripherals
USB2
Not used
Not used
Not used
Peripherals
RS-232
Digital input/output
Displays activity
(green=active;red=off)
Service
Program Items
Factory set
Default
Programming Range Notes
Select Model Set brewer model CBS-2232
MODEL
(single side)
1
(dual side)
2
223x
224x
225x
226x
To select: touch icon for brewer, touch
“BACK” and got to EXIT & SAVE
Enable Options
Options
Electric HW faucet OFF ON
Bypass Valve(s) OFF ON
Brew Basket Lock(s) OFF ON
Expansion Board OFF ON
Overrides
Override Safety Features
Left Right
Brew Basket Sensor OFFON OFFON
Brew Basket Lock OFFON OFFON
Br. Basket Lock SensorOFFON OFFON
HW Press and hold OFFON OFFON
Backup or Restore
Backup current
configuration
Will save all
programmed settings
Requires USB thumb drive
Insert USB thumb drive and touch
“BACKUP” & follow instructions
Backup or Restore
Installs saved
settings
USB thumb drive
with one file-
One file, must be titled:
backup.txt
Insert USB thumb drive and touch
“RESTORE” & follow instructions
HW/SW/BL Version
Software
UI 0.2.221011a
IO 0.3.20221119a
Bootloader UI
Bootloader IO
Compilation Time
UI Oct 11 2022 13:28:09
IO Nov 29 2022 15:12: 20
Hardware
Main Board rev
IO Board rev
Restore Defaults Return factory sets
Will overwrite all settings Touch and hold icon 5 seconds
Error Codes
Error Log
Error Code
Code & definition Date/time stamp
Export Log To USB
Follow prompts to export
Error Statistics
Error code frequency
Error Statistics
Follow prompts to delete
Reset Passcodes Overrides default
Operator Code
Follow prompts to change
Service Code
Follow prompts to change
Languages
Reserved for future use
8 P215 REV000 February 2023
Error Codes
(From SERVICE – Page7)
DO NOT CLEAR ERROR CODES UNTIL ERROR IS IDENTIFIED AND CORRECTED
Contact factory or specialized personnel for error codes
Code Description Possible Cause Corrective Action
001
Software error-error on start up or
corrupted software
Improper start-up or
shutdown
Restart, if still fault: reload software
002
Internal flash corrupted
internal data memory malfunction
Error found in cyclic
redundancy check CRC
Restart, if still fault: reload software
If not corrected: replace board
010
Front U/I board loses communication
with the interior O/I board
No communication between
front panel
Cycle brewer Off then On.
Check cable connections
011
Front U/I board bad communication
with the interior O/I board
Disrupted communication
Cable connections loose
Cycle brewer Off then On.
Check cable connections
Error codes 10 and 11 may be generated by loose connections, electronic interference, or a software/bootloader issue.
For assistance by email: open the SERVICE menu and go to the HW/SW/BL Version. Send a cellphone picture of this
screen to techsupport@fetco.com with the serial number of the equipment and your return phone number.
For live service, write down the screen information or have the HW/SW/BL Version available and contact FETCO by
phone at (800) 338-2699 option 2) to discuss with Technical Service. (Email support is usually faster)
The correction for ERROR 10 or 11 may require a simple Off/On power cycle or a bootloader/firmware update that can
be sent by email. Contact FETCO as above if cycling power or connections do not correct the fault.
050
Short-circuit in temperature probe
Probe failure.
Replace probe.
051 Open temperature probe.
Bad probe connection, or
probe failure.
Check all connections. Replace probe if
necessary.
100
Initial Fill Error.
Initial fill time took longer than
expected after powering up.
Water supply flow rate is
too low, fill valve is stuck,
water line kinked or closed.
Reboot machine. If persists-investigate
cause of low flow rate. (Clogged water
filter, kinked line, stuck fill valve)
101
Error on refill-.
Tank did not refill within expected time.
Water supply flow rate to
hot water tank is too low, or
fill valve stuck or damaged
(SEE PAGE 13)
Check water supply line. Flow should be
20-75 psig, (138-517kPa) >1gal/3.8L/min
Investigate cause of low flow rate. If the
flow rate is in range-replace fill valve
200 Heating flatline-Tank is boiling
Heater is on, temperature is
not rising/dropping
High elevation correction. Bad heaters
or temperature probe or position
201
If the hot water tank heaters are turned
on during a heating cycle and tank
temperature is not increasing
according to software logic and the
tank temperature is below setpoint
1) Failure of SSR, high limit,
temperature probe, or
heating element.
2) Water being removed by
hot water faucet during
heating (control displays
“heating”)
1)Test and check SSRs, high limit
devices temperature probe. Check
heating elements with current clamp,
replace if necessary.
2)Advise staff to refrain from taking large
amounts of water from hot water tank,
especially during “heating”.
202 Heater Shorted or Stuck SSR
Heater is off and heating
SSR is stuck “ON”
Check ohms on heater (15-60Ω). SSR
may be stuck in ON mode-replace SSR.
255
Keyboard [HID] error
(Human Interface Device)
Usually from longer than 10
seconds’ contact. Or faulty
reassembly after service
Restart, if still fault: reload software. If
mechanical: replace module
NO
BSKT
Insert Brew Basket
Brew basket must be in
place
This is a
SAFETY FEATURE
Insert brew basket into brewer rails to
enable brewer
9 P215 REV000 February 2023
Hot Water Portions
Program
Items
Factory set
Default
Programming Range Notes
This setting is only for brewers with an electronic hot water faucet. In the SETTINGS menu, the “Automatic” feature must be enabled
Hot Water Portions
Enabled
“ON”
OFF/ON
Hot Water Portions
Name
Continuous
Rename on keypad
Scroll and tap three virtual keypads
Safety Timeout 0:25
0:10 min 0:60
------------------
Scroll and go to EXIT&SAVE
Sets limit for touch and dispense
Hot Water Portions
Volume 1
6 oz.
Enabled
ON
Turns “ON” or “OFF”
OFF/ON
Name
Volume 1
Rename on keypad
Scroll and tap three virtual keypads
Volume
dispensed
6 oz
Volume 6
2 oz 30
------------------
Scroll and go to EXIT&SAVE
Sets limit for #1 touch and dispense
Hot Water Portions
Volume 2
8 oz
Enabled
ON
Turns “ON” or “OFF”
OFF/ON
Name
Volume 2
Rename on keypad
Scroll and tap three virtual keypads
Volume
dispensed
8 oz
Volume 8
2 oz 30
----------------
Scroll and go to EXIT&SAVE
Sets limit for #2 touch and dispense
Hot Water Portions
Volume 3
8 oz
Enabled
ON
Turns “ON” or “OFF”
OFF/ON
Name
Volume 3
Rename on keypad
Scroll and tap three virtual keypads
Volume
dispensed
12 oz
Volume 12
2 oz 30
-----------
Scroll and go to EXIT&SAVE
Sets limit for #3 touch and dispense
10 P215 REV000 February 2023
How to calibrate the flow rate
Set the flow rates of the brewer valves to adjust for over or under potting.
Built-in algorithms in brewer controller software corrects brew parameter to customer preferences or to trim variations in flow control components
The control software uses the new flow rate entered in the CALIBRATION screen to adjust and correct the amount of water delivered by the valve
Increasing the flow rate value DECREASES the volume of brew water dispensed
Decreasing the flow rate value INCREASES the volume of brew water dispensed
Flow rate adjustment will control all batches made by the valve. All batches on the side of the valve will be adjusted, (left or right)
-Obtain the VOLUME DISPENSED of water only, by brewing a batch without coffee or filter paper.
-Obtain the PROGAMMED VALUE of the same brew. This is displayed on the home screen in the batch box
-Obtain the CURRENT SETTING for the flow rate from the brewer. Do this by entering PROGRAMMING and
Tap to “CALIBRATION” then, tap “Flow Rates” and then “Water Valves”. The valves flow rate is in the top right corner.
Using the values obtained above to obtain the new flow rate setting to correct the volume dispensed:
Divide the volume dispensed by the programmed volume and then multiply by the current setting
VOLUME DISPENSED
PROGRAMMED VALUE
×CURRENT SETTING
=
NEW FLOW RATE SETTING
-Enter programming mode, tap to “CALIBRATION”
-Tap back to “Flow Rates” and then to “Water Valves”
-Enter the new flow rate into the calibration slider for the valve tested
Note: values for brewers set in gallons are in decimal format. Place all quantities in ounces and divide by 128 (One gallon =128 ounces)
to obtain decimal format
3 quarts delivered=96oz, 96oz÷128=0.75 gal.
Example below shows shortpotting of 16oz over 0.08 gal. batch corrected by recalibration using the formula above
Obtain Volume Dispensed
Example:
A CBS
-223
2 delivered 3qts or 6oz
over the 0.8 gallon (102oz) setting
for Batch 2
-Left Side
(96oz÷128=0.75)
The value is 0.75
Obtain Programmed Value
The Programmed value
for batch 2 -left side of
the CBS-2232 is on the
home screen in the
batch box.
The value is 0.8 gallon
Obtain Current Setting
The valves flow rate is in the
top right corner
Brew Left
0.50 (gal)
0.40 gal/min 0.58
--------------
The value is 0.50
Use the formula above
0.75
0.8
× 0.50 = .
The new flow rate is
0.47
Enter the New Flow Rate
Brew Left
0.47 (gal)
0.40 gal/min 0.58
--------------
Enter new setting on the slider
as shown and EXIT to save.
Retesting recommended
By entering the new flow rate number into the brewer, the software automatically corrects the volume discrepancy
Calibration
Program Items
Factory set
Default
Programming Range Notes
Flow Rates
Water Valves
Brew left 1800 ml/min
Brew Left 1800
(ml)
1450 ml/min 2100
-------------------------
Scroll and go to EXIT&SAVE
Use to attenuate and compensate for
variations in brew valve output
Flow Rates
Water Valves
Brew right 1800 ml/min
Brew Right 1800
(ml)
1450 ml/min 2100
-------------------------
Scroll and go to EXIT&SAVE
Use to attenuate and compensate for
variations in brew valve output
Flow Rates
Water Valves
Bypass left 1350 ml/min
Bypass left 1350
(ml)
1050 ml/min 1600
----------------------
Scroll and go to EXIT&SAVE
Use to attenuate and compensate for
variations in bypass valve output
Flow Rates
Water Valves
Bypass right 1350 ml/min
Bypass right 1350
(ml)
1050 ml/min 1600
----------------------
Scroll and go to EXIT&SAVE
Use to attenuate and compensate for
variations in bypass valve output
Flow Rates
Faucet Valve
For automatic hot
water faucet
1500 ml/min
Faucet 1500
500 ml/min 5000
----------------
Scroll and go to EXIT&SAVE
To compensate variations in timed
dispense from automatic hot water
faucet
Fill Compensation
Slow Flow
Compensation
OFF
Off
o .. 1.5x
o 2.5x
Scroll and go to EXIT&SAVE
Use for FloJet bottled water supply or
for reduced water supply from mains.
Display
Display %
Contrast 70
10 ------------ 100
Brightness % 70
20 ------------ 100
LLC
NORMAL
Normal
o .. High
Scroll and go to EXIT&SAVE
Liquid level control sensitivity.
Normal for most water.
High is for reverse osmosis water or
very pure water.
11 P215 REV000 February 2023
Outputs
Program Items
Factory set
Default
Programming Range Notes
These settings are used to activate individual controls for testing verifications and servicing operations
Brew Valve(s)
Momentarily
operate Left or
Right Brew valves
Left Right
Brew
Have dispenser under spray head!
Touch to activate flow
Fill Valve
Momentarily
operate fill valve
Fill
Have dispenser under spray heads!
Touch to activate flow
Heater SSR
Turns on all
heaters
Heater
3 sec max
Activates SSRs to turn on heaters
Light Bar
Momentarily
operate light bar(s)
Status Light
Bypass Valve(s)
Momentarily
operates Left or
Right Bypass
valves
Left Right
Bypass
Have dispenser under bypass port!
Touch to activate flow
Faucet Valve
Momentarily
operate faucet
valve
For brewers with
automatic hot water
faucet
Faucet
Have dispenser under faucet!
Touch to activate flow
Brew Basket Lock
Operates brew
basket locks,
toggling them on
and off
Left Right
BBL lock
Left Right
BBL Unlock
Left Right
BBL Sensor
Will toggle brew basket locks to be
engaged then OFF.
Extra Outputs
For future use
Not used
Not used
Not used
12 P215 REV000 February 2023
Counters
Program
Items
Factory set
Default
Programming Range Notes
This setting shows usage of the brewers functions
Lifetime Counters
Service Counters
Main>Counters>Lifetime>Service
Lifetime Counters
(units in hours and liters)
Unit Uptime 0
Fill Valve
Volume 0
Activation 0
Heater
Time On 0
Activation 0
Hot Water
Dispense Count 0
Hot Water Valve
Volume 0
Activation 0
Brewer
Volume 0
Left Right
Brew Count 0 0
Brew Valve
Volume 0 0
Activation 0 0
Bypass Valve
Volume 0 0
Activation 0 0
Locks
Activation 0 0
Hot Water
Counters
Main>Counters>Lifetime>Faucet
Lifetime Counters
(units in liters)
Volume Activation
Continues 0 0
1 0 0
2 0 0
3 0 0
Brew Counters
Main>Counters>Lifetime>Brew
Lifetime Counters
(units in liters)
Recipe Number Volume Activation
1 0 0
2 0 0
3 0 0
4 0 0
5 0 0
6 0 0
7 0 0
8 0 0
Data Counters
Reserved for future
Water Filter
Water Filer Life Time
13 P215 REV000 February 2023
Brewer Setup
NOTE-Assemble legs after unpacking the brewer and before connection to utilities
1) attach legs for 3 Liter/ 1 Gallon dispensing
1” legs -
Attach this length for
3 Liter air pot configuration
3 required for CBS-2232
4 required for CBS-2231
2-1/2” legs -
Attach this length for
1 Gallon dispenser or 3 liter air pot.
Part number 1073.00016.00
3 required for CBS-2232
4 required for CBS-2231
Legs are sent from factory inside brew basket. Attach legs before installing
2) Adjust dispenser locator for either 3 Liter / 1 Gallon dispensing
Set Dispenser Locator
Shown with 1 gallon dispenser
locator
-(User option)
Shown with 3 liter air pot Locator
-(Factory installed)
Layout of the brewer
Operation and service
For installing brewer
Brew basket
Keypad for brewer operation
Hot Water Faucet
ON/OFF Switch
Air pot or Dispenser Locator
(Two for twin side)
USB
Connection
Power
Switch
Electrical
Connection
Water
Supply
Connection
14 P215 REV000 February 2023
Brewer Setup
Attach water inlet adapter
Place rubber washer with screen in adapter. Hand tighten only-and 1/4 turn with wrench
Install the adapter on inlet valve first before attaching water line. Adapter is shipped in the brew basket
The valve threads are 3/4" BSP MALE THREAD and are not 3/4 garden hose fittings.
Use of any other connector to valve will damage the valve
DO NOT use USA dishwasher water adapter or USA washing machine adapter for this connection.
The threads on these USA adapters are unusable for the valve
TO PREVENT DAMAGE AND INSURE PROPER EQUIPMENT OPERATION
The inlet valve thread is 3/4 INCH BSP (British Standard Pipe).
This valve is not a standard USA washing machine or dishwasher thread (¾” GHT)
-Use only the plumbing adaptor kit included with this equipment. Use the gasket included in adaptor kit
-Plumber’s tape is not recommended for the adapter to valve connection
-Hand tighten adapter on valve with gasket, then very lightly wrench 1/4 turn to set
-DO NOT SUBSTITUTE FITTINGS FOR CONNECTING TO WATER SUPPLY
Damage to inlet valve from improper installation will void the warranty
NOTE: DO NOT TANK PLUMB DRAIN. DRAIN IS FOR SERVICE AND MAINTENANCE.
FETCO
Inlet valve
Rubber washer
with screen
(Included with
adapter)
Inlet valve
adapter
90 degree 3/8” flare fitting
This may be removed
and replaced with a 3/8”
compression fitting or
other connection.
Fitting to base is ¼” NPT
Use thread sealing
plumber tape or sealant
paste on threads
3/8”
flare fitting
¼” fnpt base
15 P215 REV000 February 2023
Installation Guide
(For Qualified Service Technicians Only)
General:
If not installed correctly by qualified personnel, the brewer will not operate properly and damage may result.
Utilize only qualified beverage equipment service technicians for service and installation.
Always have an empty dispenser under spray head of all coffee brewing equipment-including when at idle
Damages resulting from improper installation are not covered by the warranty, and will void the warranty.
Electrical:
All FETCO brewers require an electrical ground wire. Installation without grounding is dangerous.
Note Equipotentiality Terminal, if present,
(To identify the terminals which, when connected together, bring the various parts of equipment
or of a system to the same potential, not necessarily being the earth (ground) potential, e.g. for local bonding.)
Verify voltages, polarity, circuits, and circuit breaker access before attaching equipment.
Brewers in this series wire differently in regards to a neutral wire. Review the wire diagrams.
The electrical diagram is located in the User’s Guide and online at www.fetco.com.
Make sure of the tight grounding of the equipment and use the external ground bolt.
The installation must comply with applicable federal, state, and local codes having jurisdiction at your location. Check with your
local inspectors to determine what codes will apply.
See wiring diagrams for connections
Plumbing:
North America: All installations must comply with applicable federal, state, or local plumbing codes.
All Others: The water and waste piping and connections shall comply with the International Plumbing Code 2003, International
Code Council (ICC), or to the Uniform Plumbing Code 2003 (IAPMO).
Use an inline water filter for all beverage equipment.
Install the filter unit after a water shutoff valve and in a position to facilitate filter replacement.
The water line and newly installed filter cartage must be flushed thoroughly prior to connecting it to the brewer to prevent debris
from contaminating the machine.
Verify that the water line will provide a flow rate of at least 1½gpm/(5.7lpm) per minute and the water pressure is between 20-75
psig (138-517kPa) before making any connections.
Use a wrench on the factory fitting when connecting the incoming water line. This will reduce stress on the internal connections
and reduce the possibility of leaks developing after the install has been completed
Install a backflow prevention device. Most municipalities require a recognized backflow preventer.
Usable on all hot beverage and cold beverage equipment is a WATTS® SD-2 or SD-3.
WATTS spring loaded double check valve models are accepted by most zoning authorities.
The check valve should be as close to the water supply inlet of the beverage equipment as possible.
Tank Drain
The water tank must be drained before maintenance procedures, and when the unit is to be relocated or shipped
Disconnect power and water to unit. DANGER: Insure that all utility connections to the brewer are broken.
Move the unit near a sink or obtain a container large enough to hold four gallons of water.
Note: the hot water tank may hold more than four gallons.
Remove the front panel and tank cover and allow the tank to cool to a safe temperature
The tank drain line and clamp are located inside-under the hot water tank. Pinch the drain line clamp to close
Locate the fill valve against the back wall, using pliers, loosen the hose clamp and move it back over the tube.
Note Do not loosen the hose clamp to the bottom of the hot water tank
Crimp the tube an inch or two away from the drain plug to prevent water from flowing and pull it off the valve.
Pull the tube end out of the brewer and position over sink or bucket.
Release the crimped tube and hose clamp and allow the water to flow into the sink or container.
Multiple buckets may be needed during the draining, see tank volumes below.
Brewer Hot Water Tank Capacity
OPEN
Leave open for use
PINCH SHUT
To drain tank & service brewer
AI
!
CBS-1231 Single 3.3 gal 12.3 liter
CBS-1232 Twin 6.0 gal 22.4 liter
16 P215 REV000 February 2023
Operator Training
Review the operating procedures with whoever will be using the brewer.
Pay particular attention to the following areas:
Always pre-heat the dispensers before the first use of each day by filling them halfway with hot water and letting them stand for at
least 5 minutes.
Do not remove the brew basket from a coffee brewer until it has stopped dripping.
Make sure the dispenser is empty before brewing into it.
Show how to attach covers, close, and or secure the dispensers for transporting.
Show the location and operation of the water shut off valve as well as the circuit breaker for the brewer.
Steam from the tank will form condensation in the vent tubes. This condensation will drip into and then out of the brew baskets.
Up to 1/4 cup/118cc discharging overnight is possible. Place an appropriate container under each brew basket when not in use.
We recommend leaving the power to the brewer on overnight. The water tank is well insulated and very little electricity is used to
keep the tank hot. Leaving the brewer in the “ON” position will also avoid delays at the beginning of shifts for the brewer to reach
operating temperature.
Cleaning & Maintenance
After Each Brew:
Dispose of grounds and rinse brew basket.
Never strike a brew basket or hit it against a hard surface.
This will damage the brew cone, and may damage the brew basket support rails
Rinse dispensers before reuse.
Every Day:
Wash brew basket with hot sudsy water.
Pull CSD from the spray head, it is magnetically attached. Use gloves or a heavy towel.
Wash off any film and reattach. Use vinegar if limescale filming is present.
Clean dispensers with hot suds water and a brush, rinse and air dry.
Use only a soft cloth and hot suds on the outside to avoid scratches. Never use abrasives that will scratch surface.
Weekly
Use a commercial coffee dispenser cleaner such as URNEX™, TABZ™, DIP-IT™ or Squeak 'n Clean™.
Carefully Follow the instructions supplied with the cleaning product
Never use spray cleaners, solvent, solvent based cleaner or petroleum based polish anywhere on dispensers
Warning
Turn off power before any cleaning procedure, including wiping the exterior for appearance reasons.
Dry the exterior, especially the face panel, before turning on power.
Do not apply any type of spray cleaner on the face panel of this equipment.
Never use solvent or solvent-based cleaner or petroleum based polish anywhere on this equipment.
Dry the face of the touch pad before turning on power
Do not electrically energize this equipment or attempt operation without all covers in place and all screws fastened.
Unplug machine before disassembly or servicing.
Safety Notes
Professional installation is required. This appliance is manufactured only for commercial use
Operational requirements and maintenance for commercial cooking appliances differ from household appliances.
Operators must be trained for this equipment and must understand the use, maintenance and hazards.
Access to the service area is restricted to persons having safety/hygiene knowledge and practical experience of the coffee brewer. This
appliance must be installed in locations where it can be overseen by adult trained personnel.
Do not attempt to move hot beverage equipment once it is filled. Drain equipment before moving.
FETCO commercial coffee brewers prepare large amounts of coffee or tea in a single batch using very hot water
Commercial coffee brewers provide very hot water from the spray head, brew basket and faucet when it is pulled.
Coffee brewers may continue to dispense very hot water from the mechanically operated faucet after the electronic touchpad is
completely disabled by turning off the power switch on the lower back of the unit or unplugging the unit.
For safety, the brewer control locks the brew basket for 6.0 minutes after starting the brew.
Never attempt to defeat the factory set (default) time that the brew basket is locked for safety from start of brew.
Keep these instructions for training and future reference.
17 P215 REV000 February 2023
Warning
Turn off power before any cleaning procedure, including wiping the exterior for appearance reasons.
Dry the exterior, especially the face panel, before turning on power.
Do not apply any type of spray cleaner on the face panel of this equipment.
Never use solvent or solvent-based cleaner or petroleum based polish anywhere on this equipment.
Dry the face of the touch pad before turning on power
Do not electrically energize this equipment or attempt operation without all covers in place and all screws fastened.
Unplug machine before disassembly or servicing.
Installation safety and hygiene directions-For International and CE equipment
Access to the service area is restricted to persons having safety/hygiene knowledge and practical experience of the coffee brewer.
This appliance must be installed in locations where it can be overseen by trained personnel.
For proper operation, this appliance must be installed indoors where the temperature is between 10°C/50°F to 35°C/95°F. Drain
and remove all liquid from equipment and lines if exposed to freezing temperatures.
All commercial cooking equipment, including this unit, is not intended for use by children or persons with reduced physical, sensory,
or mental capabilities. Ensure proper supervision of children and keep them away from the unit.
Children should be supervised to ensure that they do not play hot beverage equipment.
This unit must be installed and serviced by qualified personnel only.
Installation must conform to all local electrical and plumbing codes. Installation by unqualified personnel will void the unit warranty
and may lead to electric shock or burn, as well as damage to unit and/or its surroundings.
If the power cord requires repair or replacement-it must be performed by the manufacturer or authorized service personnel with the
specified cord only from the manufacturer in order to avoid a hazard.
Review the dimensions for the unit and verify that it will fit properly in the space intended for it. Verify that the counter or table will
support the total weight of the brewer and dispensers when filled (See: Technical Data).
Place the brewer on the counter or stand. When the brewer is in position, level it front to back as well as side-to-side by adjusting
the legs.
Brewers will need a sturdy supported surface for operation. Do not move brewers when filled.
Do not tilt appliance more than 10° to insure safe operation.
Unit is for protected indoor use only. Do not steam clean or use excessive water on unit.
This unit is not “jet-proof” construction. Do not pressure wash or use jet spray to clean this unit.
The unit is not waterproof-do not submerge or saturate with water.
Equipment exposed to flood and contaminated must not be used due to electrical and food safety.
Do not operate if unit has been submerged or saturated with water.
Labels and
warnings for
hot beverage
equipment
Label for
BACK PANEL
of equipment
(1046.00035.00)
18 P215 REV000 February 2023
Parts diagrams
Ref
Qty
PartNumber
Description Drawing 1101.00563.00 CBS-2232
1
1
1111.00101.00
WELDMENT BODY, CBS-2232
2
8
1084.00051.00.
NUT, HEX LOCKWASHER, #8-32, 18-8 ST. STL
3
1
1102.00448.00
FRONT PANEL ASSEMBLY, CBS-2200 SERIES
4
2
1082.00029.00
SCREW, #6 X 3/8 LG, TRUSS HD PHIL, SHEET MTL
5
4
1082.00058.00
SCREW, # 8-32 X 5/8, FLAT HD, PH, 18-8 SS
6
1
See Drawing
ELECTRICAL COMPONENT LATTICE, CBS-2200
7
1
1102.00444.00
VISUAL COMMUNICATION RGB LED BAR, ASSY
8
4
1081.00006.00
SPACER, 6MM OD x 3.2MM ID x 5MM LG, Z/P
9
1
1051.00046.00
CBS-2200 SERIES, I/O BOARD, 24V
10
4
1029.00006.00
NUT, FINGER KNURLED, #4-40
11
2
See Drawing
SPRAYHEAD ASSY,CBS-30/40'S, QUICK CONNECT
12
2
1024.00063.00
O-RING, 3 15/16" x 3/32" CS, DASH # 154, BUNA-N, DURO-A50
13
4
1024.00107.00
O-RING, 1 3/16" OD X 1 1/16" ID X 1/16" TH, BYPASS SEAL
14
2
1023.00343.00
VENT INSERT, QUICK CONNECT
15
3
1024.00106.00
O-RING, 13/16"OD X 11/16"ID X 1/16" TH, FOR QUICK CONNECT
16
5
1023.00342.00
QUICK CONNECT CLIP
17
18
1083.00010.00
WASHER, #12 SCREW W/NEOPRENE-BONDED SEAL
Parts list continues next page
19 P215 REV000 February 2023
Ref
Qty
PartNumber
Description Drawing 1101.00563.00 CBS-2232NG …Continued from page 16
18
18
1084.00006.00
NUT, 8-32 18-8 HEX MACHINE SCREW
19
2
1024.00098.00
VENT TUBE, CBS- EXTRACTOR SERIES
20
2
1086.00004.00
BUSHING, SNAP, 1" MOUNTING HOLE
21
1
1102.00243.00
ADAPTER ASSY, 3/4" BSP x 1/4" NPT x 3/8" TUBE
22
2
1065.00009.00
GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
23
1
1044.00012.00
LABEL GROUND, CE
24
11
1084.00011.00
NUT, CLIP ON (J-NUT), #6-32, 22-20 GA., BLK-PH FINISH
25
1
1025.00058.00
TUBE, 9/16"OD X 5/16"ID X 25.00"LG
26
1
1086.00009.00
CLAMP, 3/4" MAX TUBE OD FLOW CONTROL
27
5
1086.00003.00
UNICLAMP, 15.9 HOSE OD CLAMP
28
1
1112.00530.00
WELDMENT, RIGHT COVER, CBS-2230
29
2
1023.00354.00
LOCATOR, DISPENSER, CBS-2230
30
2
1023.00355.00
LOCATOR, AIRPOT ADAPTER, CBS-2230
31
1
1001.00408.00
COVER TOP, CBS-2232/42
32
1
1001.00409.00
COVER, UPPER BASE, CBS-2232/42
33
11
1082.00017.00
SCREW, TRUSS HD. PHIL. MACHINE, # 6-32 X 1/2 LG.
34
1
1046.00035.00
LABEL, WARNING "TO REDUCE RISK OF ELECTRIC SHOCK OR FIRE"
35
1
1402.00106.00
HARNESS, CBS-2240/50-NG, LOW AMP, UNIVERSAL
36
1
1402.00107.00
HARNESS ADDITION, CBS-2242/52-NG, LOW AMP, UNIVERSAL
37
1
1063.00042.00
ETHERNET CABLE, CAT-7, 5FT LENGTH
38
2
1046.00003.00
LABEL, CSD WARNING, 1.5" X 5.0"
39
1
1041.00032.00
BLACK EXTRACTOR NG LABEL, LASER ENGRAVED
40
2
1025.00142.00
TUBE, SILICONE, 3/4" OD X 1/2" ID X 3.75" LG, BREW
41
1
See Drawing
TANK ASSEMBLY, CBS-2231
42
1
1402.00037.10
HARNESS HIGH AMP, CBS-2232/42/51, UL
43
1
B014218BN2BK
BREW BASKET ASSY, BLACK, 13" X 5", 0.218" DIA HOLE, BROWN PLUG
44
1
B003218B1
BREW BASKET ASSY, 13" X 5", .218 DIA HOLE, BLACK
45
1
1024.00111.00
GROMMET, SILICONE, W/ POSITION TABS
46
1
1023.00362.00
FITTING VENT, ELBOW, .375" X .375", SELF POSITIONING
47
1
1023.00348.00
HOT WATER INSERT, MANUAL FAUCET
48
1
1071.00055.00
FAUCET, HOT WATER, PSC-BR-8, WITH FLAT AND STEM
49
1
1084.00048.00
JAM NUT, 1/2-20 UNF, NICKEL PLATED BRASS
50
1
1003.00370.00
HOT WATER INSERT LOCK
51
1
1025.00120.00
TUBE, 9/16"OD X 5/16"ID X 13.00"LG
52
1
1023.00346.00
HOT WATER INSERT, AUTO FAUCET
53
1
1029.00041.00
COVER, AUTO HOT WATER FAUCET, SILICONE
54
1
1023.00347.00
VALVE MOUNT, HOT WATER DISPENSER
55
1
1025.00026.00
TUBE, 1/4"OD X 1/8"ID X 30"LG, VENT, HOT WATER VAPOR
56
2
1023.00369.00
ORIFICE INSERT, QUICK CONNECT, 3/16" HOLE
57
2
1057.00076.00
VALVE ASSEMBLY, COMPLETE, NG, DELTROL
58
2
1025.00138.00
TUBE, SILICONE, 3/4" OD X 1/2" ID X 1-1/2" LG, HOT WATER
59
1
1025.00135.00
TUBE, 1/2"OD X 1/4"ID X .75" LG, RESTRICTOR
60
1
1024.00051.00
GROMMET, SILICONE, BLANK
61
1
1023.00349.00
HOT WATER INSERT, NO FAUCET
62
1
1029.00042.00
BYPASS L-TUBE, SILICONE, 2200 SINGLE SERIES
63
1
1023.00344.00
PLUG INSERT, QUICK CONNECT
64
1
1102.00445.00
ASSY, BREW BASKET LOCKER W/FEEDBACK
65
1
1003.00259.00
BRACKET, BREW BASKET LOCK COVER
66
3
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
67
1
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
68
3
1073.00016.00
LEG, THERMOPLASTIC, 2.50"(63mm)
69
3
1073.00019.00
LEG, 3/8-16 THREAD x 1" LG., GRAY
70
1
1086.00008.00
CONNECTOR, CLAMP, NON-METALLIC CABLE, 3/4"
71
1
1003.00348.00
ADAPTER PLATE, CBS-1130-XV+, STRAIN RELIEF, CE
72
1
1086.00029.00
BUSHING, STRAIN RELIEF, .360"-.430" DIA CABLE
73
1
1044.00013.00
LABEL EQUIPOTENTIALITY, CE
74
1
1052.00027.00
EMI FILTER, THREE LINE 30A, 250/440VAC
75
2
1084.00012.00
NUT, HEX, #6-32 MACHINE SCREW
76
1
1112.00246.00
WELDMENT BRACKET TERMINAL BLOCK, 3 POLE
77
1
1052.00022.00
EUROSTRIP HE10 TERM. BLOCK, 3 POLE, 50AMP, 18-8 AWG
78
2
1082.00082.00
SCREW, PHILLIP HD., 8-32 THREAD
79
1
1402.00121.10
WIRE HARNESS ADDITION, HIGH AMP, EMI FILTER, 2-POLE, CE
20 P215 REV000 February 2023
Ref
Qty
Part Number
Description Drawing 1101.00564.00 CBS-2231NG
1
1
1111.00102.00
WELDMENT BODY, CBS-2231
2
8
1084.00051.00
NUT, HEX LOCKWASHER, #8-32, 18-8 ST. STL.
3
1
1102.00448.00
FRONT PANEL ASSEMBLY, CBS-2200 SERIES
4
2
1082.00029.00
SCREW, #6 X 3/8 LG, TRUSS HD PHIL, SHEET MTL
5
3
1082.00058.00
SCREW, # 8-32 X 5/8, FLAT HD, PH, 18-8 SS
6
1
See Drawing
ELECTRICAL COMPONENT LATTICE, CBS-2200
7
1
1102.00444.00
VISUAL COMMUNICATION RGB LED BAR, ASSY
8
4
1081.00006.00
SPACER, 6MM OD x 3.2MM ID x 5MM LG, Z/P
9
1
1051.00046.00
CBS-2200 SERIES, I/O BOARD, 24V
10
4
1029.00006.00
NUT, FINGER KNURLED, #4-40
11
1
See Drawing
QUICK CONNECT SRAYHEAD ASSEMBLY,30/40'S, BASIC
12
1
1024.00063.00
O-RING, 3 15/16" x 3/32" CS, DASH # 154, BUNA-N, DURO-A50
13
2
1024.00107.00
O-RING, 1 3/16" OD X 1 1/16" ID X 1/16" TH, BYPASS SEAL
14
1
1023.00343.00
VENT INSERT, QUICK CONNECT
15
2
1024.00106.00
O-RING, 13/16"OD X 11/16"ID X 1/16" TH, FOR QUICK CONNECT
16
3
1023.00342.00
QUICK CONNECT CLIP
17
9
1083.00010.00
WASHER, #12 SCREW W/NEOPRENE-BONDED SEAL
18
9
1084.00006.00
NUT, 8-32 18-8 HEX MACHINE SCREW
19
1
1024.00098.00
VENT TUBE, CBS- EXTRACTOR SERIES
Parts list continues next page
Drawing 1101.00564.00
CBS-2231 Next Genertion
21 P215 REV000 February 2023
Ref
Qty
PartNumber
Description Drawing 1101.00564.00 CBS-2231NG …Continued from page 20
20
1
1086.00004.00
BUSHING, SNAP, 1" MOUNTING HOLE
21
1
1102.00243.00
ADAPTER ASSY, 3/4" BSP x 1/4" NPT x 3/8" TUBE
22
2
1065.00009.00
GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
23
1
1044.00012.00
LABEL GROUND, CE
24
11
1084.00011.00
NUT, CLIP ON (J-NUT), #6-32, 22-20 GA., BLK-PH FINISH
25
1
1025.00058.00
TUBE, 9/16"OD X 5/16"ID X 25.00"LG
26
1
1086.00009.00
CLAMP, 3/4" MAX TUBE OD FLOW CONTROL
27
4
1086.00003.00
UNICLAMP, 15.9 HOSE OD CLAMP
28
1
1112.00530.00
WELDMENT, RIGHT COVER, CBS-2230
29
1
1023.00354.00
LOCATOR, DISPENSER, CBS-2230
30
1
1023.00355.00
LOCATOR, AIRPOT ADAPTER, CBS-2230
31
1
1001.00413.00
COVER TOP, CBS-2231/41
32
1
1001.00414.00
COVER, UPPER BASE, CBS-2231/41
33
11
1082.00017.00
SCREW, TRUSS HD. PHIL. MACHINE, # 6-32 X 1/2 LG.
34
1
1046.00035.00
LABEL, WARNING "TO REDUCE RISK OF ELECTRIC SHOCK OR FIRE"
35
1
1402.00106.00
HARNESS, CBS-2240/50-NG, LOW AMP, UNIVERSAL
36
1
1063.00042.00
ETHERNET CABLE, CAT-7, 5FT LENGTH
37
1
1046.00003.00
LABEL, CSD WARNING, 1.5" X 5.0"
38
1
1041.00032.00
BLACK EXTRACTOR NG LABEL, LASER ENGRAVED
39
1
See Drawing
TANK ASSEMBLY, CBS-2231
40
1
1402.00039.10
HARNESS HIGH AMP, CBS-2231/41/51, UL
41
1
B014218BN2BK
BREW BASKET ASSY, BLACK, 13" X 5", 0.218" DIA HOLE, BROWN PLUG
42
1
B003218B1
BREW BASKET ASSY, 13" X 5", .218 DIA HOLE, BLACK
43
1
1024.00111.00
GROMMET, SILICONE, W/ POSITION TABS
44
1
1023.00362.00
FITTING VENT, ELBOW, .375" X .375", SELF POSITIONING
45
1
1023.00348.00
HOT WATER INSERT, MANUAL FAUCET
46
1
1071.00055.00
FAUCET, HOT WATER, PSC-BR-8, WITH FLAT AND STEM
47
1
1084.00048.00
JAM NUT, 1/2-20 UNF, NICKEL PLATED BRASS
48
1
1003.00370.00
HOT WATER INSERT LOCK
49
1
1025.00120.00
TUBE, 9/16"OD X 5/16"ID X 13.00"LG
50
1
1023.00346.00
HOT WATER INSERT, AUTO FAUCET
51
1
1029.00041.00
COVER, AUTO HOT WATER FAUCET, SILICONE
52
1
1023.00347.00
VALVE MOUNT, HOT WATER DISPENSER
53
2
1023.00369.00
ORIFICE INSERT, QUICK CONNECT, 3/16" HOLE
54
2
1057.00076.00
VALVE ASSEMBLY, COMPLETE, NG, DELTROL
55
2
1025.00138.00
TUBE, SILICONE, 3/4" OD X 1/2" ID X 1-1/2" LG, HOT WATER
56
1
1025.00135.00
TUBE, 1/2"OD X 1/4"ID X .75" LG, RESTRICTOR
57
1
1024.00051.00
GROMMET, SILICONE, BLANK
58
1
1023.00349.00
HOT WATER INSERT, NO FAUCET
59
1
1025.00026.00
TUBE, 1/4"OD X 1/8"ID X 30"LG, VENT, HOT WATER VAPOR
60
1
1029.00042.00
BYPASS L-TUBE, SILICONE, 2200 SINGLE SERIES
61
1
1023.00344.00
PLUG INSERT, QUICK CONNECT
62
1
1102.00445.00
ASSY, BREW BASKET LOCKER W/FEEDBACK
63
1
1003.00259.00
BRACKET, BREW BASKET LOCK COVER
64
4
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
65
2
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
66
4
1073.00016.00
LEG, THERMOPLASTIC, 2.50"(63mm)
67
4
1073.00019.00
LEG, 3/8-16 THREAD x 1" LG., GRAY
68
1
1086.00008.00
CONNECTOR, CLAMP, NON-METALLIC CABLE, 3/4"
69
1
1003.00348.00
ADAPTER PLATE, CBS-1130-XV+, STRAIN RELIEF, CE
70
1
1086.00029.00
BUSHING, STRAIN RELIEF, .360"-.430" DIA CABLE
71
1
1044.00013.00
LABEL EQUIPOTENTIALITY, CE
72
1
1052.00029.00
EMI FILTER, TWO LINE 20A, 120/250VAC
73
2
1084.00012.00
NUT, HEX, #6-32 MACHINE SCREW
74
1
1063.00016.00
POWER CORD, 120VAC W/NEMA 5-15P PLUG
75
1
1063.00015.00
CORD, 120 VAC, 12/3 AWG ,20 AMP , W/5-20P NEMA PLUG
76
1
1063.00032.00
CORD, POWER, NEMA 6-15P, 15A/250V, W/O TERMINALS
77
1
1402.00039.11
HARNESS ADDITION, HIGH AMP, CBS-2231/41/51, UL
78
1
1402.00121.10
WIRE HARNESS ADDITION, HIGH AMP, EMI FILTER, 2-POLE, CE
79
1
1025.00142.00
TUBE, SILICONE, 3/4" OD X 1/2" ID X 3.75" LG, BREW
22 P215 REV000 February 2023
CBS-2231 Tank Assembly-single heater
TANK ASSY, CBS-2231 Single Heater
Drawing number 1104.000169.00, 1104.000170.00, 1104.000172.00, 1104.000174.00, 1104.000175.00
REF
QTY
Part number
Description
1
1
1114.00168.001
WELDMENT, TANK, CBS-2231
2
1
1024.00114.00
TANK GASKET - NG HEATER PLATE, TWO ELEMENT
3
1
1114.00184.00
WELDMENT TANK HEATER BRACKET, NG-2231, SINGLE
4
2
1024.00053.00
LEVEL AND TEMP PROBE GROMMET
5
3
1024.00050.00
GROMMET, SILICONE, 11.4mm ID
6
1
1053.00052.00
THERMOSTAT, SINGLE SHOT, SCREW CONNECTIONS, 240V/25A
7
8
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
8
8
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
9
1
1107.00021.00
HEATER ASSEMBLY, IMMERSION 1500W/120VAC
9
1
1107.00020.00
HEATER ASSEMBLY, IMMERSION 2300W/240VAC
9
1
1107.00019.00
HEATER ASSEMBLY, IMMERSION 2300W/120VAC
9
1
1107.00018.00
HEATER ASSEMBLY, IMMERSION 3000W/240VAC
10
1
1003.00140.00
ALUMINUM BRACKET FOR SSR
11
1
1052.00033.00
RELAY, SOLID STATE, 50A/480VAC, W/BUILD IN VARISTOR
12
2
1081.00042.00
STANDOFF, 1/4" HEX
13
1
1112.00002.00
PROBE WELDMENT, WATER LEVEL 2.25" LG
14
1
1102.00161.00
PROBE ASSEMBLY, TEMP. AND LLC, 8" LONG
15
1
1023.00168.00
FITTING, STRAIGHT, GROMMET, .400"
16
1
1023.00166.00
FITTING, COLD WATER INLET, GROMMET DESIGN
17
1
1044.00004.00
LABEL, DANGER, HIGH VOLTAGE
18
1
1023.00212.00
FITTING, ELBOW, GROMMET, .500"
19
1
1024.00051.00
GROMMET, SILICONE, BLANK
20
1
1022.00114.00
TANK INSULATION, CBS-2231
21
2
1082.00136.00
BRASS SCREW, #8-32 X 1/4", PHILLIPS PAN HEAD
Table of authorities for CBS-2231NG replacement hot water tank module-tank is sold complete with insulation
SKU Number. See page 3 for list
Description
Tank Part Number
E2231US-1A115-PA011
TANK , CBS-2231, 1 X 1.5KW/120VAC
1104.00169.00
E2231US-1A123-PA012
TANK , CBS-2231, 1 X 2.3KW/120VAC
1104.00172.00
E2231CE-1B123-PA015
TANK , CBS-2231, 1 X 2.3KW/240VAC
1104.00174.00
E2231NM-1B130-PA013; E2231CE-1B130-PA015
TANK , CBS-2231, 1 X 3.0KW/240VAC
1104.00175.00
23 P215 REV000 February 2023
CBS-2231 Tank Assembly-two heaters
TANK ASSY, CBS-2231 Two Heater Drawing number 1104.000171.00, 1104.000173.00
REF
QTY
Part number
Description
1
1
1114.00168.00
WELDMENT, TANK, CBS-2231
2
1
1024.00114.00
TANK GASKET - NG HEATER PLATE, TWO ELEMENT
3
1
1114.00176.00
WELDMENT TANK HEATER BRACKET, NG-2231
4
2
1024.00053.00
LEVEL AND TEMP PROBE GROMMET
5
3
1024.00050.00
GROMMET, SILICONE, 11.4mm ID
6
2
1053.00052.00
THERMOSTAT, SINGLE SHOT, SCREW CONNECTIONS, 240V/25A
7
10
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
8
10
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
9
2
1107.00022.00
HEATER ASSEMBLY, IMMERSION 1700W/120VAC
9
2
1107.00019.00
HEATER ASSEMBLY, IMMERSION 2300W/120VAC
10
2
1003.00140.00
ALUMINUM BRACKET FOR SSR
11
2
1052.00033.00
RELAY, SOLID STATE, 50A/480VAC, W/BUILD IN VARISTOR
12
4
1081.00042.00
STANDOFF, 1/4" HEX
13
1
1112.00002.00
PROBE WELDMENT, WATER LEVEL 2.25" LG
14
1
1102.00161.00
PROBE ASSEMBLY, TEMP. AND LLC, 8" LONG
15
1
1023.00168.00
FITTING, STRAIGHT, GROMMET, .400"
16
1
1023.00166.00
FITTING, COLD WATER INLET, GROMMET DESIGN
17
1
1044.00004.00
LABEL, DANGER, HIGH VOLTAGE
18
1
1023.00212.00
FITTING, ELBOW, GROMMET, .500"
19
1
1024.00051.00
GROMMET, SILICONE, BLANK
20
1
1022.00114.00
TANK INSULATION, CBS-2231
21
4
1082.00136.00
BRASS SCREW, #8-32 X 1/4", PHILLIPS PAN HEAD
Table of authorities for CBS-2231NG replacement hot water tank module-tank is sold complete with insulation
SKU Number. See page 3 for list
Description
Part Number
E2231NM-1X123-PA012, E2231NM-1A123-PA012
TANK CBS-2231, 2 X 2.3KW/120VAC
1104.00173.00
E2231US-1X117-PA011
TANK CBS-2231, 2 X 1.7KW/120VAC
1104.00171.00
24 P215 REV000 February 2023
CBS-2232 Tank Assembly
CBS-2232 Hot Water Tank Drawing 1104.00176.01
Ref#
Qty
Part number
Description
1
1
1114.00169.00
WELDMENT TANK CBS-2232, GROMMET DESIGN
2
2
1024.00115.00
TANK GASKET - NG HEATER PLATE, ONE ELEMENT
3
2
1114.00181.00
WELDMENT TANK HEATER BRACKET, NG-2232
4
2
1024.00053.00
LEVEL AND TEMP PROBE GROMMET
5
5
1024.00050.00
GROMMET, SILICONE, 11.4mm ID
6
1
1112.00002.00
PROBE WELDMENT, WATER LEVEL 2.25" LG
7
1
1102.00161.00
PROBE ASSEMBLY, TEMP. AND LLC, 8" LONG
8
2
1023.00212.00
FITTING, ELBOW, GROMMET, .500"
9
2
1023.00168.00
FITTING, STRAIGHT, GROMMET, .400"
10
1
1023.00166.00
FITTING, COLD WATER INLET, GROMMET DESIGN
11
2
1107.00019.00
HEATER ASSEMBLY, IMMERSION 2300W/120VAC
11
2
1107.00018.00
HEATER ASSEMBLY, IMMERSION 3kW/240VAC
11
2
1107.00040.00
HEATER ASSEMBLY, IMMERSION 4kW/240VAC
12
2
1053.00052.00
THERMOSTAT, SINGLE SHOT, SCREW CONNECTIONS, 240V/25A,
13
12
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
14
12
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
15
2
1003.00140.00
ALUMINUM BRACKET FOR SSR
16
2
1052.00033.00
RELAY, SOLID STATE, 50A/480VAC, W/BUILD IN VARISTOR
17
4
1081.00042.00
STANDOFF, 1/4" HEX
18
1
1044.00004.00
LABEL, DANGER, HIGH VOLTAGE
19
1
1022.00113.00
TANK INSULATION, CBS-2232 FRONT
20
1
1022.00116.00
TANK INSULATION, CBS-2232 BACK
21
4
1082.00136.00
BRASS SCREW, #8-32 X 1/4", PHILLIPS PAN HEAD
Table of authorities for CBS-2232NG replacement hot water tank module-tank is sold complete with insulation
SKU Number. See page 3 for list
Description
Tank Part Number
E2232US-1B223-PA010, E2232US-1B223-MA110,
E2232IN-1B223-PA010, E2232CE-1B223-PA010
TANK
CBS-2232, 2 X 2.3KW/240VAC
1104.00176.00
E2232US-1B230-MA110, E2232US-1B230-PA010,
E2232US
-1B230-PA110, E2232IN-1B230-PA010,
E2232IN
-1B230-MA110, E2232NM-1B230-PA010
E2232CE-1B230-PA010
TANK
CBS-2232, 2 X 3.0KW/240VAC
1104.00177.00
25 P215 REV000 February 2023
Ref
Qty
PartNumber
Description Electrical component lattice, CBS-2200 Part#1102.00449.00
1102.00449.00
COMPLETE ELECTRICAL COMPONENT LATTICE, CBS-2200
1
1
1023.00350.00
ELECTRICAL MOUNTING LATTICE, COMMON
2
1
1052.00023.00
EUROSTRIP HE16 TERM. BLOCK, 4 POLE, 63 AMP, 18-8 AWG
3
2
1082.00056.00
SCREW, #8-11 X 1" PAN HD PHIL, THREAD FORMING
4
1
1058.00024.00
SWITCH, POWER, DOUBLE POLE, 16A, 125/250 VAC
5
1
1057.00043.00
SOLENOID VALVE, 5.5L/min, 180 DEG, 24VDC
6
2
1082.00010.00
SCREW, PAN HD. PHIL. MACH., M4x10 ZINC-PLATED
7
1
1052.00059.00
POWER SUPPLY, 90-264VAC/24VDC, 2.25A
8
2
1082.00020.00
SCREW, #6 X 5/8, TRUSS HD PHIL, SHEET MTL
9
1
1058.00055.00
USB CONNECTOR
10
1
1058.00162.00
ETHERNET PLUG IN CONNECTOR, W/COVER
#6 Part Number 1102.00449
.00
ELECTRICAL COMPONENT LATTI C E
26 P215 REV000 February 2023
Part number 1102.00451.00 Small Spray Assembly Parts-Quick connect version
Ref#
Qty
Part number
Description
1
1
1000.00143.00
SPRAY HEAD BASE (KIT), QUICK CONNECT, 30/40'S
2
1
1024.00063.00
O-RING, 3 15/16" x 3/32" CS, DASH # 154, BUNA-N, DURO-A50
3
2
1024.00107.00
O-RING, 1 3/16" OD X 1 1/16" ID X 1/16" TH, BYPASS SEAL
4
1
1102.00113.00
SWITCH, REED, ASSEMBLY
5
1
1102.00479.00
ASSEMBLY, CASCADE SPRAY DOME, NEXT GEN, ORANGE
6
2
1057.00076.00
VALVE ASSEMBLY, COMPLETE, NG, DELTROL (interchangeable with 1057.00078.00)
6
2
1057.00078.00
VALVE ASSEMBLY, COMPLETE, NG, RPE (interchangeable with 1057.00076.00)
7
3
1023.00342.00
QUICK CONNECT CLIP
8
1
1023.00343.00
VENT INSERT, QUICK CONNECT
9
2
1024.00106.00
O-RING, 13/16"OD X 11/16"ID X 1/16" TH, FOR QUICK CONNECT
10
1
1024.00098.00
VENT TUBE, CBS- EXTRACTOR SERIES
11
1
1023.00369.00
ORIFICE INSERT, QUICK CONNECT, 3/16" HOLE
12
1
1023.00344.00
PLUG INSERT, QUICK CONNECT
27 P215 REV000 February 2023
Brew Baskets
Plastic Brew Basket For CBS-2241 & CBS-2242
Part Number B014218BN2BK – Complete Plastic Brew Basket 13" X 5", .218 DIA HOLE
Brew basket handle plug for polymeric brew baskets
is available in optional colors.
Part
Number
PLUG INSERT
COLOR
1023.00
195.00
BROWN PLUG,
BB HANDLE
1023.00
194.00
BLACK PLUG,
BB HANDLE
1023.00
190.00
RED PLUG, BB
HANDLE
1023.00
191.00
GREEN PLUG,
BB HANDLE
1023.00
192.00
ORANGE PLUG,
BB HANDLE
1023.00
180.00
BLUE PLUG, BB
HANDLE
Stainless Steel Brew Basket For CBS-2241 & CBS-2242
Part Number B003218B1 – Complete Stainless Steel Brew Basket 13" X 5", .218 DIA HOLE
Ref# Qty Part Number Description
1 1 1112.00128.00 BB WLDMNT 13" X 5", .218 DIA HOLE
2 1 1046.00025.00 BREW BASKET WARNING LABEL
3 1 1082.00040.00 SCREW, 1/4-20 X .5, FL HD, PH., W/NYLN
4 1 1009.00006.00 WIRE BASKET
5 1 1102.00064.00 HANDLE W/MAGNET ASY, BLACK
Optional
colored handle
1102.00065.00 HANDLE W/MAGNET ASY, RED
Optional
colored handle
1102.00066.00 HANDLE W/MAGNET ASY, GREEN
Optional
colored handle
1102.00067.00 HANDLE W/MAGNET ASY, ORANGE
Specialty Brew Baskets for Iced Tea/Tea and Specialty Coffee Brewing.
These brew baskets have reduced orifice sizes and may require PROGRAMMING changes to increase brewing time and
pulses to enhance extraction and prevent basket overflow during steeping. Orifice reduction is not linear and might not
be intuitive because the changes are in area (exponential as πr²) Because the reduction is to surface area, the reduced
diameter of the orifice can greatly affect (slow) the brew basket flow rate. This may cause the brew basket to overflow.
SEE Page 5- Brew Recipes
Stainless Steel
Part Number
Orifice Size
% of Standard*
Handle Color
Filter Paper Size
B003218B1 (from above)
0.218-Sandard
100%
Black
13” X 5” or FETCO# F002
B003158B1
0.158
52%
Black
13” X 5” or FETCO# F002
B003110G1
0.110
25%
Green
13” X 5” or FETCO# F002
B003110B1
0.110
25%
Black
13” X 5” or FETCO# F002
B003079B1
0.079
13%
Black
13” X 5” or FETCO# F002
Plastic
Part Number
Orifice Size
Plug Color
Filter Paper Size
B014218BN2BK (from above)
0.218-Sandard
100%
Black
13” X 5” or FETCO# F002
B014140G2BK
0.140
41%
Green
13” X 5” or FETCO# F002
28 P215 REV000 February 2023
Wiring Diagrams
29 P215 REV000 February 2023
