1
MARINER
®
MX OUTDOOR SPEAKERS
MX52 | MX56 | MX62 | MX66 | MX86 | MX52 SST | MX62 SST
INSTRUCTION MANUAL
2
TABLE OF CONTENTS
2 Product Description
2 Box and Contents
3 Product Features
4 Wire Selection
4 Speaker Placement
4 Pivoting the Speaker
4 Grille and Speaker Shell Painting
5 Installation
7 Technical Specifications
14 Technical Assistance and Service
15 Warranty
IMPORTANT SAFETY INSTRUCTIONS
This product is intended to be installed by professional
AV integrators and installers only. This product manual
is intended to serve as a general guideline for most
applications. It is the installer’s responsibility to ensure
this product is installed in accordance with local
building codes and regulations. Consult a local authority
for specific requirements, regulations, and building
codes of the jurisdiction in which this product is to be
installed.
READ THIS DOCUMENT IN ITS
ENTIRETY BEFORE ATTEMPTING USE
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Clean only with a dry cloth.
6. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
7. Do not install near a heat source such as radiators,
heat registers, stoves, fireplaces, or other apparatus
(including amplifiers) that produce heat.
8. Only use attachments/accessories specified by
Sonance.
9. This product is IP66 rated, suitable for installation in
outdoor environments.
10. Refer all servicing to qualified service personnel.
MARINER MX
MX52 | MX56 | MX62 | MX66 | MX86
MX52 SST | MX62 SST
BOX CONTENTS
Sonance Mariner
®
2-Way Speaker (MX52, MX56, MX62,
MX66, MX86):
(2) Speakers
(2) Speaker Grilles
(2) FastMount Brackets
(2) Waveguide Terminal Covers
(1) Manual
Sonance Mariner Single Stereo Technology
®
Speaker
(MX52 SST, MX62 SST):
(1) Speaker
(1) Speaker Grille
(1) FastMount Bracket
(1) Waveguide Terminal Cover
(1) Manual
3
Paintable Shell (white only)
Rotation Lock
Cable Pass-Through
FastMount Bracket
Powder Coated Aluminum Grille
High Excursion Woofer
High Resolution Chambered Tweeter
Concealed Speaker Spring
Terminals
PRODUCT FEATURES
Waveguide Terminal Cover
FastMount Bracket Retention
Grille Clips
4
WALL/CEILING MOUNTING
It is important that the bracket is securely mounted onto
a structurally sound surface, capable of withstanding
the weight of the product and any vibration created
by the operation of the speaker. Four screw points
must be used at all times. A screw size of #14 to #20
PRODUCT DESCRIPTION
Thank you for purchasing Sonance Mariner
®
MX
weather-resistant speakers.When properly installed,
these speakers will give you many years of outdoor
entertainment pleasure. To get the most out of your new
speakers, please read this manual thoroughly before you
begin installation.
The directions in this manual apply to the following
models:MX52 | MX56 | MX62 | MX66 | MX86
MX52 SST | MX62 SST
WIRE GAUGE
When installing Sonance Mariner MX Outdoor Speakers,
careful consideration should be made when determining
speaker placement and what gauge wire should be used.
Please refer to the wiring chart (see Figure 1) to determine
which size wire to use over the given distance between
the amplifier/receiver and the speakers.
Wall Mount Ceiling Mount Pole Mount
Figure 2: Mounting
Figure 1: WIRE GAUGE CHART
WIRE GAUGE DISTANCE
18 Gauge Up to 100 feet (30 meters)
16 Gauge Up to 150 feet (45 meters)
14 Gauge Up to 250 feet (80 meters)
diameter x 2” length or M6 to M8 diameter x 50mm
length is recommended. When mounting onto drywall
or plasterboard, the bracket should be axed to a joist
or stud. When mounting onto brick or concrete, wall
plugs or concrete anchors should be used. Install a safety
cable from one of the 1/4-20 UNC threaded holes on the
back of the speaker to a secure location on the adjoining
mounting surface (hardware not included). Optional
compatible third party mounts: OmniMount 15.0C,
OmniMount 15.0W, and Konig & Meyer 24180-000-55.
POLE MOUNTING
To mount the speaker on a pole, two U-bolts and nuts
should be used to clamp around the pole and bolt through
the four holes on the back of the FastMount bracket.
Spring washers or blue thread lock are recommended to
ensure the nuts do not loosen through the vibration of the
speaker.
PAINTING THE SPEAKER AND GRILLE
Sonance Mariner MX Speakers feature a tough
polypropylene enclosure that can be painted. Sonance
recommends using a weather-resistant outdoor paint and
a spray gun.
1. If they have already been installed, remove the grilles
from the speakers.
2. To protect the speaker driver units during painting,
place the grilles on a piece of cardboard and trace
around their outlines. Then cut the cardboard just
inside of the trace line and fit these “paint plugs” into
the speakers’ baes. Be careful not to damage the
driver components while fitting the paint plugs.
3. Paint the speakers the desired color according to the
paint manufacturer’s instructions. Remove the paint
plugs after the paint has thoroughly dried.
SPEAKER PLACEMENT
Mariner MX Speakers are IP66 rated, weather-resistant,
and when mounted outdoors will perform exceptionally
well for years even under adverse weather conditions.
The Mariner FastMount bracket system makes it easy to
mount the speakers in a variety of positions and locations
(see Figure 2).The best performance is obtained by
placing the speakers at ear level, facing the listener.
• If you are mounting the speakers above or below
ear level, pivot them up or down to direct the sound
toward the listener.
• You can orient the speakers either horizontally or
vertically without aecting the sound quality.
PIVOTING THE SPEAKERS
You can rotate the speaker in the bracket to direct the
sound towards the listeners.
1. Unlock the slide locks on the speaker pivots by
moving them towards the rear of the speaker.
2. Rotate the speakers to the desired position.
3. Lock the slide locks by moving them towards the front
of the speaker.
Figure 3: Rear Mounting Points
Two 1/4-20 UNC threaded
inserts spaced 2.76”
(70mm) apart.
_
+
5
1. In most cases you will be able to attach the FastMount
brackets directly to the mounting surface. Run the
speaker wiresfrom the amplifier to the speaker
locations and through the holes in the brackets (see
Figure 6).
NOTE: To increase water resistance and make installation
easier, the speaker wire terminals are located on the
Mariner speakers’ front panel behind the removable
waveguide. Be sure to leave enough wire at the speaker
location to feed though the tunnel in the speaker
enclosure and connect to the terminals on the front.
2. Attach the FastMount brackets to the mounting
surface using hardware (not included) that is
appropriate for the type of surface.If the installation
requires that the speaker be mounted in a corner,
attach the bracket with hardware through the slots in
the angled corners (see Figure 5).
4. Feed the speaker wires from the bracket into the wire
entry grommet on the back of the speaker, through
the wire tunnel and out the opening on the speaker’s
front panel (see Figure 7).
• The grommet forms a water-resistant seal around the
speaker wire.
• Make sure there is enough slack in the wire to allow
the speaker to pivot on the bracket.
_
+
Figure 4: FastMount Bracket Removal
Figure 6: Attaching Bracket
Figure 7: Wire Entry Grommet
3. If the installation requires that the speaker be
mounted on a pole you can attach the FastMount
brackets to the pole using 2.5” U-bolts (not included)
(see Figure 6).
5. Slide the speaker onto the bracket and firmly snap
into place.
NOTE: Be sure that the bracket clips snap completely
into place to prevent any blockage within the
speaker perimeter where the grille is to be inserted.
Pull enough wire through the front of the speaker to
allow connection to the terminals (see Figure 8).
IMPORTANT: Do not touch the tweeter dome as
damage will occur.
4. Paint the grille separately from the speaker using very
thin paint (5:1 ratio). Avoid plugging the grille holes
with excess paint.
INSTALLING THE SPEAKERS
WARNING: Turn the amplifer’s power o until you have
completed all of the connections and have determined
that they are correct If the amp’s AC plug is accessible
we recommend that you unplug it from the wall outlet
to avoid accidental turn-on and possible damage to the
amplifer.
Figure 5: Angled Corner Mounting
Figure 8: Connecting Wire and Attaching Speaker to Bracket
6
Figure 10: Attach the Connector Cover
FITTING AND REMOVING THE GRILLE
1. When installing the grille, align the grille skirt with the
groove in the front of the enclosure.
2. To lock the grille in place apply pressure at the
locations of the four grille retention clips. An audible
click should be heard as the grille locks into place.
NOTE: To remove the grille, we suggest starting in any
one of the four corners using a grille pulling tool (not
included). Once the grille is pulled out past the retention
clip in one corner, the remainder of the grille can be
removed by working your hand around and lightly
pulling outward, being careful not to bend the grille
skirt. If the grille skirt does become bent during removal,
it can be straightened by carefully bending it back into
its original shape.
REMOVING THE SPEAKER FROM THE
BRACKET
Remove the speakers from the mounting brackets by
pulling the tabs on the front panels outward and away
from each other while pulling the speaker cabinet toward
you, away from the bracket (see Figure 12).
Figure 11: Pushing the Grille into Place
8. Fit the removable waveguide wiring connector cover
into the recess in the speaker’s front panel. The cover
should fit tightly, but can be removed and replaced if
the speaker needs to be disconnected (see Figure 10).
9. Fit the grille onto the speaker by aligning the edges
of the grille with the groove of the speaker face
perimeter and pressing firmly until it is snugly in place
(see Figure 11).
Figure 12: Removing Speaker from Bracket
6. Connect the speaker wires to the speaker’s terminals:
• Strip about 0.5” of insulation from each conductor and
twist the strands together or tin them with solder.
• Press down on the tops of the connectors to open
them.
• Insert the wires into the connector holes (see Figure 8).
• Release the connectors.
The binding post connectors can accept wire up to 14
gauge.Double-check that you connected all of the wires
properly (amplifier ‘+’ to speaker ‘+’; amplifier ‘–’ to speaker
‘–’) at all connections.
IMPORTANT: Be sure not to let any stray ‘+’ and ‘–’ wires
touch each other. Touching wires can cause a short-circuit
that could damage your amplifer.
7. Tuck any loose wiring from the binding post wire
terminals under the wire management post just below
the terminals (see Figure 9). Option to hold the wire
under the wire management post using a zip tie and
screw (zip tie and screw not included).
Figure 9: Connect Wires to Spring Terminals
7
INCLUDED ACCESSORIES
(2) Speakers
(2) Speaker Grilles
(2) FastMount Brackets
(2) Waveguide Terminal Covers
OPTIONAL ACCESSORIES
MX5 Replacement Bracket BLK PR | 93394
MX5 Replacement Bracket WHT PR | 93391
MX5 Replacement Grille BLK EA | 93700
MX5 Replacement Grille WHT EA | 93701
MX5 Replacement Waveguide Terminal Cover EA | 93706
MX52 SPECIFICATIONS
Black Part # 93604 (PR)
White Part # 93605 (PR)
Tweeter 0.75”(19mm)ClothDome,Ferrouid-cooled,AcousticBackChamber
Woofer 5.25”(130mm)TexturedPolypropyleneCone,RubberSurround
Dispersion Technology Sinusoidal Textured Waveguide
FrequencyResponse 65Hz-20kHz+/-3dB
Impedance 8 ohms Nominal (6 ohms Minimum)
Power Handling (RMS) 5 Watts Minimum to 90 Watts Maximum
Sensitivity(2.83V/1M) 87dBSPL
Environmental Mill Spec 810 for Humidity, Salt Spray, Temperature, UV; IP66 Waterproof Rating
EnvironmentalTemp -13°to149°F(-25°Cto65°C)
Grille Perforated Aluminum
Product Dims (WxHxD) 6.36” x 10.08” x 5.68” (162mm x 256mm x 144mm)
ShippingWeight 12lbs.(5.5kg)perpair
8
INCLUDED ACCESSORIES
(2) Speakers
(2) Speaker Grilles
(2) FastMount Brackets
(2) Waveguide Terminal Covers
OPTIONAL ACCESSORIES
MX5 Replacement Bracket BLK PR | 93394
MX5 Replacement Bracket WHT PR | 93391
MX5 Replacement Grille BLK EA | 93700
MX5 Replacement Grille WHT EA | 93701
MX5 Replacement Waveguide Terminal Cover EA | 93706
MX56 SPECIFICATIONS
Black Part # 93606 (PR)
White Part # 93607 (PR)
Tweeter 0.75”(19mm)CeramicDome,Ferrouid-cooled,AcousticBackChamber
Woofer 5.25”(130mm)Kevlar/NomexCone,RubberSurround
Dispersion Technology Sinusoidal Textured Waveguide
FrequencyResponse 60Hz-20kHz+/-3dB
Impedance 8 ohms Nominal (6 ohms Minimum)
Power Handling (RMS) 5 Watts Minimum to 100 Watts Maximum
Sensitivity(2.83V/1M) 88dBSPL
Environmental Mill Spec 810 for Humidity, Salt Spray, Temperature, UV; IP66 Waterproof Rating
EnvironmentalTemp -13°to149°F(-25°Cto65°C)
Grille Perforated Aluminum
Product Dims (WxHxD) 6.36” x 10.08” x 5.68” (162mm x 256mm x 144mm)
ShippingWeight 13lbs.(6kg)perpair
9
INCLUDED ACCESSORIES
(2) Speakers
(2) Speaker Grilles
(2) FastMount Brackets
(2) Waveguide Terminal Covers
OPTIONAL ACCESSORIES
MX6 Replacement Bracket BLK PR | 93395
MX6 Replacement Bracket WHT PR | 93392
MX6 Replacement Grille BLK EA | 93702
MX6 Replacement Grille WHT EA | 93703
MX6 Replacement Waveguide Terminal Cover EA | 93707
MX62 SPECIFICATIONS
Black Part # 93608 (PR)
White Part # 93609 (PR)
Tweeter 1”(25mm)ClothDome,Ferrouid-cooled,AcousticBackChamber
Woofer 6.5”(165mm)TexturedPolypropyleneCone,RubberSurround
Dispersion Technology Sinusoidal Textured Waveguide
FrequencyResponse 55Hz-20kHz+/-3dB
Impedance 8 ohms Nominal (6 ohms Minimum)
Power Handling (RMS) 5 Watts Minimum to 125 Watts Maximum
Sensitivity(2.83V/1M) 89dBSPL
Environmental Mill Spec 810 for Humidity, Salt Spray, Temperature, UV; IP66 Waterproof Rating
EnvironmentalTemp -13°to149°F(-25°Cto65°C)
Grille Perforated Aluminum
Product Dims (WxHxD) 7.51” x 12.14” x 6.86” (191mm x 308mm x 174mm)
ShippingWeight 14lbs.(6.4kg)perpair
10
INCLUDED ACCESSORIES
(2) Speakers
(2) Speaker Grilles
(2) FastMount Brackets
(2) Waveguide Terminal Covers
OPTIONAL ACCESSORIES
MX6 Replacement Bracket BLK PR | 93395
MX6 Replacement Bracket WHT PR | 93392
MX6 Replacement Grille BLK EA | 93702
MX6 Replacement Grille WHT EA | 93703
MX6 Replacement Waveguide Terminal Cover EA | 93707
MX66 SPECIFICATIONS
Black Part # 93610 (PR)
White Part # 93611 (PR)
Tweeter 1”(25mm)CeramicDome,Ferrouid-cooled,AcousticBackChamber
Woofer 6.5”(165mm)Kevlar/NomexCone,RubberSurround
Dispersion Technology Sinusoidal Textured Waveguide
FrequencyResponse 50Hz-20kHz+/-3dB
Impedance 8 ohms Nominal (6 ohms Minimum)
Power Handling (RMS) 5 Watts Minimum to 140 Watts Maximum
Sensitivity(2.83V/1M) 90dBSPL
Environmental Mill Spec 810 for Humidity, Salt Spray, Temperature, UV; IP66 Waterproof Rating
EnvironmentalTemp -13°to149°F(-25°Cto65°C)
Grille Perforated Aluminum
Product Dims (WxHxD) 7.51” x 12.14” x 6.86” (191mm x 308mm x 174mm)
ShippingWeight 17lbs.(7.7kg)perpair
11
INCLUDED ACCESSORIES
(2) Speakers
(2) Speaker Grilles
(2) FastMount Brackets
(2) Waveguide Terminal Covers
OPTIONAL ACCESSORIES
MX8 Replacement Bracket BLK PR | 93396
MX8 Replacement Bracket WHT PR | 93393
MX8 Replacement Grille BLK EA | 93704
MX8 Replacement Grille WHT EA | 93705
MX8 Replacement Waveguide Terminal Cover EA | 93708
MX86 SPECIFICATIONS
Black Part # 93612 (PR)
White Part # 93613 (PR)
Tweeter 1.2”(30mm)CeramicDome,Ferrouid-cooled,AcousticBackChamber
Woofer 8”(203mm)Kevlar/NomexCone,RubberSurround
Dispersion Technology Sinusoidal Textured Waveguide
FrequencyResponse 45Hz-20kHz+/-3dB
Impedance 8 ohms Nominal (6 ohms Minimum)
Power Handling (RMS) 5 Watts Minimum to 150 Watts Maximum
Sensitivity(2.83V/1M) 91dBSPL
Environmental Mill Spec 810 for Humidity, Salt Spray, Temperature, UV; IP66 Waterproof Rating
EnvironmentalTemp -13°to149°F(-25°Cto65°C)
Grille Perforated Aluminum
Product Dims (WxHxD) 9.01” x 14.02” x 8.58” (229mm x 356mm x 218mm)
ShippingWeight 20lbs.(9kg)perpair
12
INCLUDED ACCESSORIES
(1) Speaker
(1) Speaker Grille
(1) FastMount Bracket
(1) Waveguide Terminal Cover
OPTIONAL ACCESSORIES
MX5 Replacement Bracket BLK PR | 93394
MX5 Replacement Bracket WHT PR | 93391
MX5 Replacement Grille BLK EA | 93700
MX5 Replacement Grille WHT EA | 93701
MX5 Replacement Waveguide Terminal Cover EA | 93706
MX52 SST SPECIFICATIONS
Black Part # 93614 (EA)
White Part # 93615 (EA)
Tweeter 0.75”(19mm)ClothDome,Ferrouid-Cooled,AcousticBackChamber,
Dual Voice Coil
Woofer 5.25”(130mm)TexturedPolypropyleneCone,RubberSurround,DualVoiceCoil
Dispersion Technology Sinusoidal Textured Waveguide
FrequencyResponse 65Hz-20kHz+/-3dB
Impedance 8 ohms Nominal (6 ohms Minimum)
Power Handling (RMS) 5 Watts Minimum to 90 Watts Maximum
Sensitivity(2.83V/1M) 87dBSPL
Environmental Mill Spec 810 for Humidity, Salt Spray, Temperature, UV; IP66 Waterproof Rating
EnvironmentalTemp -13°to149°F(-25°Cto65°C)
Grille Perforated Aluminum
Product Dims (WxHxD) 6.36” x 10.08” x 5.68” (162mm x 256mm x 144mm)
ShippingWeight 6lbs.(2.8kg)each
13
INCLUDED ACCESSORIES
(1) Speaker
(1) Speaker Grille
(1) FastMount Bracket
(1) Waveguide Terminal Cover
OPTIONAL ACCESSORIES
MX6 Replacement Bracket BLK PR | 93395
MX6 Replacement Bracket WHT PR | 93392
MX6 Replacement Grille BLK EA | 93702
MX6 Replacement Grille WHT EA | 93703
MX6 Replacement Waveguide Terminal Cover EA | 93707
MX62 SST SPECIFICATIONS
Black Part # 93616 (EA)
White Part # 93617 (EA)
Tweeter 1”(25mm)ClothDome,Ferrouid-Cooled,AcousticBackChamber,
Dual Voice Coil
Woofer 6.5”(165mm)TexturedPolypropyleneCone,RubberSurround,DualVoiceCoil
Dispersion Technology Sinusoidal Textured Waveguide
FrequencyResponse 55Hz-20kHz+/-3dB
Impedance 8 ohms Nominal (6 ohms Minimum)
Power Handling (RMS) 5 Watts Minimum to 125 Watts Maximum
Sensitivity(2.83V/1M) 89dBSPL
Environmental Mill Spec 810 for Humidity, Salt Spray, Temperature, UV; IP66 Waterproof Rating
EnvironmentalTemp -13°to149°F(-25°Cto65°C)
Grille Perforated Aluminum
Product Dims (WxHxD) 7.51” x 12.14” x 6.86” (191mm x 308mm x 174mm)
ShippingWeight 7lbs.(3.2kg)each
14
TECHNICAL ASSISTANCE AND
SERVICE
The Technical Assistance Department at Sonance is
available at (949) 492-7777 to answer any questions
concerning the operation and installation of your speakers
between the hours of 7:00 AM and 5:00 PM Pacific time,
Monday through Friday, except holidays.
In the event your unit should need repair or service, you
may return the unit to your authorized dealer or use the
following guidelines:
Please keep original packaging when possible.
1. Be prepared to state the model number and/or serial
number, date of purchase, and dealer’s name and
address when calling.
2. Contact Sonance directly at (949) 492-7777 or at
www.sonance.com
YOU MUST HAVE PRIOR AUTHORIZATION TO RETURN
YOUR UNIT.
3. If you are returning the product directly to Sonance,
call us to obtain a return authorization number before
shipping.
4. Ship the product via United Parcel Service, Federal
Express, or other package delivery service. Please do
not use the U.S. Postal Service.
Write the Return Authorization Number on the shipping
label. Do not write it on the outside of the box.
Ship to:
Attn: Quality Assurance Department
Sonance
11016 Mulberry Ave
Fontana, CA 92337
15
LIMITED FIVE (5) YEAR WARRANTY
Sonance warrants to the first end-user purchaser that this Sonance-brand product (“Product”), when purchased from
an authorized Sonance Dealer/Distributor, will be free from defective workmanship and materials for the period stated
below. Sonance will at its option and expense during the warranty period, either repair the defect or replace the Product
with a new or re-manufactured Product or a reasonable equivalent.
EXCLUSIONS
TO THE EXTENT PERMITTED BY LAW, THE WARRANTY SET FORTH ABOVE IS IN LIEU OF, AND EXCLUSIVE OF,
ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND IS THE SOLE AND EXCLUSIVE WARRANTY PROVIDED
BY SONANCE. ALL OTHER EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF
MERCHANTABILITY, IMPLIED WARRANTY OF FITNESS FOR USE, AND IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE ARE SPECIFICALLY EXCLUDED.
No one is authorized to make or modify any warranties on behalf of Sonance. The warranty stated above is the sole and
exclusive remedy, and Sonance’s performance shall constitute full and final satisfaction of all obligations, liabilities, and
claims with respect to the Product.
IN ANY EVENT, SONANCE SHALL NOT BE LIABLE FOR CONSEQUENTIAL, INCIDENTAL, ECONOMIC, PROPERTY,
BODILY INJURY, OR PERSONAL INJURY DAMAGES ARISING FROM THE PRODUCT, ANY BREACH OF THIS WARRANTY,
OR OTHERWISE.
This warranty statement gives you specific legal rights, and you may have other rights which vary from state to state.
Some states do not allow the exclusion of implied warranties or limitations of remedies, so the above exclusions and
limitations may not apply. If your state does not allow disclaimer of implied warranties, the duration of such implied
warranties is limited to period of Sonance’s express warranty. Your Product Model and Description: Mariner
®
MX Outdoor
Speakers. Warranty Period for this Product: Five (5) years from the date on the original sales receipt or invoice or
other satisfactory proof of purchase. Additional Limitations and Exclusions from Warranty Coverage: The warranty
described above is nontransferable, applies only to the initial installation of the Product, does not include installation
of any repaired or replaced Product, does not include damage to allied or associated equipment which may result for
any reason from use with this Product, and does not include labor or parts caused by accident, disaster, negligence,
improper installation, misuse (e.g. overdriving the amplifier or speaker, excessive heat, cold or humidity, mishandling,
etc.), or from service or repair which has not been authorized by Sonance. Obtaining Authorized Service: To qualify for
the warranty, you must contact your authorized Sonance Dealer/Installer or call Sonance Customer Service at (949)
492-7777 within the warranty period, must obtain a return merchandise number (RMA), and must deliver the Product
to Sonance shipping prepaid during the warranty period, together with the original sales receipt, or invoice or other
satisfactory proof of purchase.
©2024 Sonance. All rights reserved. Sonance is a registered trademarks of Dana Innovations. Due to continuous product improvement, all features and
specifications are subject to change without notice. For the latest Sonance product specification information visit our website: www.sonance.com
SONANCE • 991 Calle Amanecer • San Clemente, CA 92673 USA • PHONE: (949) 492-7777 • FAX: (949) 361-5151 • Technical Support: (949) 492-7777 •
www.sonance.com 06.18.2024
