This is the main product document for model 52G930B-B.

The file format is pdf, 35 pages, you can download this manual here .

background
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for future reference.
Owner's Manual
www.lg.com
Copyright 2025 LG Electronics Inc. All Rights Reserved.
52G930B
background
2
ENGLISH
TABLE OF CONTENTS
ASSEMBLING AND PREPARING .........................................................4
- Installing ............................................................................................................................5
Moving and Lifting the Monitor .........................................................................................5
Installing on a Table ...........................................................................................................6
Using the Kensington Lock .................................................................................................6
Installing on the Wall .........................................................................................................7
- Product and Button Description .........................................................................................9
How to Use the Joystick Button ........................................................................................10
Adjusting the Stand Height ..............................................................................................10
Adjusting the Angle .........................................................................................................11
- Supported Drivers and Software ......................................................................................11
USING THE MONITOR .......................................................................12
- Connecting to a PC ...........................................................................................................12
HDMI Connection .............................................................................................................12
DisplayPort Connection ....................................................................................................13
USB-C connection .............................................................................................................13
- Connecting AV Devices .....................................................................................................13
HDMI Connection .............................................................................................................13
- Connecting Peripherals ....................................................................................................14
USB Device connection ..................................................................................................... 14
Headset Connection .........................................................................................................14
USER SETTINGS ...............................................................................15
- Activating the Main Menu ................................................................................................15
Main Menu Features .........................................................................................................15
Menu Settings .................................................................................................................. 16
[Game Adjust] ..................................................................................................................16
[Picture Adjust] ................................................................................................................18
[Sound] ............................................................................................................................18
[Input]..............................................................................................................................19
[General] ..........................................................................................................................19
background
3
ENGLISH
PRODUCT SPECIFICATION ................................................................21
- Support Mode ..................................................................................................................22
HDMI ................................................................................................................................22
DisplayPort/USB-C ...........................................................................................................23
HDMI Timing (Video) ........................................................................................................24
TROUBLESHOOTING ........................................................................25
LICENSE ........................................................................................... 26
OPEN SOURCE SOFTWARE NOTICE INFORMATION .......................... 26
BEEP GUIDE .....................................................................................27
LIMITED WARRANTY (USA) ............................................................ 30
LIMITED WARRANTY (CANADA) ......................................................32
background
4
ENGLISH
ASSEMBLING AND PREPARING
CAUTION
Always use genuine LG components to ensure safety and product performance.
The product warranty will not cover damage or injury caused by the use of unauthorized components.
It is recommended that use the supplied components.
The product figures and screen displays used in this manual are examples to help consumers use the product
and may differ from the actual product.
Do not apply foreign substances (oils, lubricants, etc.) to the screw parts when assembling the product.
(Doing so may damage the product.)
Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this
way will not be covered by the product warranty.
Do not carry the monitor upside down by just holding the base. This may cause the monitor to fall off the
stand and could result in personal injury.
When lifting or moving the monitor, do not touch the monitor screen. The force applied to the monitor screen
may cause damage to it.
For wave pattern on appearance, unlike the general method of coating, it’s applied to added glittering
material in raw material. With no peeled-off appearance, it has good durability. Please use it with confidence
because there is no problem in using the product at all.
NOTE
The components may look different from those illustrated here.
Without prior notice, all product information and specifications contained in this manual are subject to
change to improve the performance of the product.
To purchase optional accessories, visit an electronics store or an online shopping site, or contact the retailer
from which you purchased the product.
The power cord provided may differ depending upon the region.
background
5
ENGLISH
Installing
Moving and Lifting the Monitor
When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or
damaged and to ensure safe transportation, regardless of its shape or size.
Place the monitor in the original box or packing material before attempting to move it.
Before moving or lifting the monitor, disconnect the power cord and all other cables.
Hold the bottom and side of the monitor frame firmly. Do not hold the panel itself.
When holding the monitor, the screen should face away from you to prevent it from being scratched.
When transporting the monitor, do not expose the monitor to shock or excessive vibration.
When moving the monitor, keep it upright and never turn the monitor on its side or tilt it sideways.
CAUTION
Avoid touching the monitor screen as much as possible.
- This may result in damage to the screen or some of the pixels used to create images.
If you use the monitor panel without the stand base, its button may cause the monitor to become unstable
and fall, resulting in damage to the monitor or human injury. In addition, this may cause the button to
malfunction.
background
6
ENGLISH
Installing on a Table
Lift the monitor and place it on the table in an upright position. Place the monitor at least 100mm
(3.9inches) away from the wall to ensure sufficient ventilation.
: 100 mm (3.9inches)
CAUTION
Unplug the power cord before moving or installing the monitor. There is risk of electric shock.
Make sure to use the power cord that is provided in the product package and connect it to a grounded power
outlet. (Depending on country)
Using the Kensington Lock
For more information on installation and usage, refer to the Kensington lock owner’s manual or visit the website
at http://www.kensington.com.
Connect the monitor to a table using the Kensington security system cable.
NOTE
The Kensington security system is optional. You can obtain optional accessories from most electronics stores.
background
7
ENGLISH
Installing on the Wall
This monitor meets the specifications for the wall mount plate or other compatible devices.
Install the monitor at least 100mm (3.9inches) away from the wall and leave about 100mm (3.9inches)
of space at each side of the monitor to ensure sufficient ventilation. Detailed installation instructions can be
obtained from your local retail store. Alternatively, please refer to the manual for how to install and set up a
tilting wall mounting bracket.
: 100 mm (3.9inches)
Installing the Wall Mount Plate
To install the monitor to a wall, attach a wall mounting bracket (optional) to the back of the monitor.
Make sure that the wall mounting bracket is securely fixed to the monitor and to the wall.
Wall Mount (mm) 100 x 100 (3.9x3.9inches)
Standard screw M4 x L10
Number of screws 4
Wall Mount Plate (Optional) LSW149
background
8
ENGLISH
NOTE
Use the screws specified by VESA standards.
The wall mount kit includes the installation guide and all necessary parts.
The wall mounting bracket is optional. You can obtain optional accessories from your local dealer.
The length of the screw may differ for each wall mounting bracket. If you use screws longer than the standard
length, it may damage the inside of the product.
For more information, please refer to the user manual for the wall mounting bracket.
Be careful not to apply too much force while mounting the wall mount plate as it may cause damage to the
screen.
Remove the stand before installing the monitor on a wall mount by performing the stand attachment in
reverse.
CAUTION
Unplug the power cord before moving or installing the monitor to avoid electric shock.
Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could
lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel.
To prevent injury, this apparatus must be securely attached to the wall in accordance with the installation
instructions.
Applying excessive force when tightening screws may cause damage to the monitor. Damage caused in this
way will not be covered by the product warranty.
Use the wall mounting bracket and screws that conform to VESA standards. Damage caused by the use or
misuse of inappropriate components will not be covered by the product warranty.
When measured from the back of the monitor, the length of each installed screw must be 8mm (0.3inches)
or less.
background
9
ENGLISH
: Wall Mount Plate
: Back of the Monitor
: Standard screw
: Max. 8mm (0.3inches)
Product and Button Description
: Joystick Button
background
10
ENGLISH
How to Use the Joystick Button
You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/
down with your finger.
Basic Functions
(Power on): Press the joystick button once with your finger to turn on the monitor.
(Power off): Press and hold the joystick button once more than 5 seconds with your finger to turn off the
monitor.
(Volume control): You can control the volume by moving the joystick button left/right.
Enters the [Accessibility] menu.
Adjusting the Stand Height
1 Place the monitor mounted on the stand base in an upright position.
2 Handle the monitor with both hands for safety.
Max 120.0mm
(4.7inches)
WARNING
When adjusting the screen height, do not place your hand on the stand body to avoid injury to your fingers.
background
11
ENGLISH
Adjusting the Angle
1 Place the monitor mounted on the stand base in an upright position.
2 Adjust the angle of the screen.
The angle of the screen can be adjusted forward or backward from -2° to 10° for a comfortable viewing
experience. And you can also adjust the angle of the screen by 10 degrees to the left or to the right.
WARNING
To avoid injury to the fingers when adjusting the screen, do not hold the lower part of the monitor’s frame as
illustrated below.
Be careful not to touch or press the screen area when adjusting the angle of the monitor.
NOTE
The left or right side of the monitor head can be slightly rotated up or down (up to 3°). Adjust the horizontal
level of the monitor head.
Supported Drivers and Software
You can download and install the latest version from the LGE website (www.lg.com).
- Monitor Driver / LG Switch / LG Calibration Studio / Dual Controller
background
12
ENGLISH
USING THE MONITOR
Illustrations in this manual may differ from the actual product.
Press the joystick button, go to [Settings] > [Input], and then select the input option.
CAUTION
If you use generic cables not certified by LG, the screen may not display or there may be image noises.
Do not press the screen for a prolonged time. This may cause image distortion.
Do not display a still image on the screen for a prolonged time. This may cause image retention. Use a PC
screensaver if possible.
When connecting the power cord to the outlet, use a grounded (3-hole) power strip or a grounded power
outlet. (Depending on country)
The monitor may flicker when turned on in an area where the temperature is low. This is normal.
Sometimes red, green, or blue spots may appear on the screen. This is normal.
Make sure to use the supplied cable of the product. Otherwise, this may cause the device to malfunction.
If the monitor is reflecting environmental light, move the monitor or light or adjust the strength of the
environmental light.
Connecting to a PC
This monitor supports the Plug and Play* feature.
* Plug and Play: A feature that allows you to add a device to your computer without having to reconfigure
anything or install any manual drivers.
HDMI Connection
Transmits digital video and audio signals from your PC to the monitor.
NOTE
Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility issues.
Use a certified cable with the HDMI logo attached. If you do not use a certified HDMI cable, the screen may
not display or a connection error may occur.
Recommended HDMI cable types
- Ultra High Speed HDMI
®
/™ cable
- Ultra High Speed HDMI
®
/™ cable with Ethernet
background
13
ENGLISH
DisplayPort Connection
Transmits digital video and audio signals from your PC to the monitor.
NOTE
There may be no video or audio output depending on the DP (DisplayPort) version of the PC.
If you are using a Mini DisplayPort output graphics card, use a Mini DP to DP (Mini DisplayPort to DisplayPort)
cable or gender that supports DisplayPort2.1 or DisplayPort1.4. (Sold separately)
USB-C connection
Transmits digital video and audio signals from your PC to the monitor.
NOTE
PD (Power Delivery) and DP Alternate Mode (DP over USB-C) are supported via USB-C Port.
Features may not work properly depending on the connected devices specifications and the environment.
USB-C port is not for the monitor power source but for a PC power source. Connect adaptor to supply power
to the monitor.
Connecting AV Devices
HDMI Connection
HDMI transmits digital video and audio signals from your AV device to the monitor.
NOTE
Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility issues.
Use a certified cable with the HDMI logo attached. If you do not use a certified HDMI cable, the screen may
not display or a connection error may occur.
Recommended HDMI cable types
- Ultra High Speed HDMI
®
/™ cable
- Ultra High Speed HDMI
®
/™ cable with Ethernet
background
14
ENGLISH
Connecting Peripherals
USB Device connection
The USB port on the product functions as a USB hub.
Peripheral devices connected to the USB IN port can be controlled from the PC.
NOTE
It is recommended you install all Windows Updates to keep your Windows up-to-date before connecting to
the product for use.
Peripheral devices are sold separately.
A keyboard, mouse, or USB device can be connected to the USB port.
The charging speed may vary depending on the device.
To use USB Downstream port of monitor, user must connect Upstream port of monitor to Host PC using USB
C-C or USB C-A cable.
When the USB C-C cable is connected between Upstream port of monitor and Host PC, the Downstream port
of monitor support USB 2.0 device.
When the USB C-A cable is connected between Upstream port of monitor and Host PC, the Downstream port
of monitor support USB 3.0 device. However, Host PC must support USB 3.0 function.
CAUTION
Cautions when using a USB device.
- A USB device with an automatic recognition program installed, or that uses its own driver, may not be
recognized.
- Some USB devices may not be supported or may not work properly.
- It is recommended to use a USB hub or hard disk drive with power supplied. (If the power supply is not
adequate, the USB device may not be recognized properly.)
Headset Connection
Connect peripherals to the monitor via the headset port.
NOTE
Peripheral devices are sold separately.
Depending on the audio settings of the PC and external device, headset and speaker functions may be
limited.
The microphone works only when the USB port on the monitor is connected to the USB port on the PC.
USB-C
Monitor PC
Please connect the USB C-C or USB C-A cable to use a microphone function with headphones equipped with a
microphone.
background
15
ENGLISH
USER SETTINGS
NOTE
Your monitor’s OSD (On Screen Display) may differ slightly from that shown in this manual.
When [Beep Guide] is activated, pressing the joystick button will take you to [Settings] right away.
Activating the Main Menu
1 Press the joystick button on the back of the monitor.
2 Move the joystick up/down and left/right to set the options.
Joystick Button
Main Menu Features
B
C
A
E
D
Main Menu Description
: [Power Off] Turns off the monitor.
: [Input]
Sets input mode. (Default)
You can customize the left ( ) of the main menu to access your preferred
menu easily. ([Settings] > [General] > [User-defined Key 1])
: [Game Mode]
Sets the game mode for gaming. (Default)
You can customize the right ( ) of the main menu to access your
preferred menu easily. ([Settings] > [General] > [User-defined Key 2])
: [Exit] Exit the main menu.
: [Settings] Configures the screen settings.
background
16
ENGLISH
Menu Settings
1 To view the OSD menu, press the joystick button at the back of the monitor and then enter the [Settings].
2 Move the joystick up/down and left/right to set the options.
3 To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it.
4 If you want to exit the OSD menu, move the joystick to until you exit.
[Game Adjust] [Picture Adjust] [Sound] [Input] [General]
[Game Adjust]
[Settings] > [Game Adjust]
[Game Mode]: you can select picture modes for game display settings.
- [Personalized Picture]: Set up a customized picture mode tailored to your preferences. Please install the LG
Switch and proceed “Personalized Picture Wizard”.
- [Gamer 1]/[Gamer 2]: [Gamer 1] and [Gamer 2] picture modes allow you to save two sets of customized
display settings, including game-related setup options.
- [FPS]: This mode is optimized for FPS games. It is suitable for very dark FPS games.
- [RTS]: This mode is optimized for RTS games.
- [Vivid]: Optimized the screen for vivid colors.
- [Reader]: Optimizes the screen for reading documents. (for SDR only)
- [HDR Effect]: Optimizes the screen for high dynamic range. (for SDR only)
- [sRGB]: A standard RGB color space for the monitor and printer. (for SDR only)
- [DCI-P3]: Suitable for watching digital videos. (for SDR only)
- [Color Weakness]: This mode is for users who cannot distinguish between red and green. It enables users
with color weakness to easily distinguish between the two colors. (for SDR only)
- [Calibration 1]/[Calibration 2]: Adjusts to the calibrated screen. Please install LG Calibration Studio to run
calibration. (for SDR only)
background
17
ENGLISH
NOTE
The [Game Mode] can be set depends on the Input signal.
If the [Game Mode] is changed in the DP (DisplayPort) input, the screen may flicker or the resolution of your
PC screen may be affected.
HDR content may not display correctly depending on Windows OS settings, please check HDR On/Off settings
in Windows.
When the HDR function is turned on, the characters or picture quality may be poor according to Graphic card
performance.
While the HDR function is on, screen flickering or cracking may occur when changing the monitor input or
power on/off according to Graphic card performance.
For information about whether the graphics card and game support HDR, visit their manufacture's website.
[Adaptive-Sync]/[VRR]: This function shows a clear screen without screen tearing or stuttering in the game
environment.
However, screen flickering may occur in some game environments.
- Supported Interface: DisplayPort/USB-C (Adaptive-Sync), HDMI (VRR).
- Supported Graphic Card: A graphic card that supports NVIDIA's G-SYNC or AMD’s FreeSync is necessary.
- Supported Version: Make sure to update the graphic card to the latest driver.
- For more information and requirement, refer to NVIDIA website (www.nvidia.com) and AMD website
(www.amd.com).
[Black Stabilizer]: You can control the black contrast to have better visibility in dark scenes. You can easily
distinguish objects on dark game screens.
[Response Time]: Sets a response time for displayed pictures based on the speed of the screen. For a normal
environment, it is recommended that you use [Fast]. For a fast-moving picture, it is recommended that you
use [Faster]. Once [Faster Mode] is selected, [Motion Blur]may occur depending on the content.
- [Faster]: Sets the response time to faster.
- [Fast]: Sets the response time to fast.
- [Normal]: Sets the response time to normal.
- [Off]: Does not use the response time improvement feature.
[Crosshair]: Crosshair provides a mark on the center of the screen for First Person Shooter (FPS) games.
Users can select the crosshair that fits their gaming environment among four different crosshairs.
[FPS Counter]
- [On]: The indicator is displayed on the upper left of the screen. It will reflect the actual frame rate that is
received at the input. You can also adjust the position of [FPS Counter]. (upper left/upper right/lower right/
lower left)
- [Off]: Does not use the [FPS Counter] feature.
- [FPS Counter] and [Crosshair] feature can not be used at the same time.
[Game Reset]: Returns game settings to the default settings.
background
18
ENGLISH
[Picture Adjust]
[Settings] > [Picture Adjust]
[Brightness]: Adjusts the brightness of the screen.
[Contrast]: Adjusts the contrast of the screen.
[Sharpness]: Adjusts the sharpness of the screen.
[Gamma]
- [Mode 1], [Mode 2], [Mode 3]: The higher the gamma value, the darker the image becomes. Likewise, the
lower the gamma value, the lighter the image becomes.
- [Mode 4]: If you do not need to adjust the gamma settings, select [Mode 4].
[Color Temp]: Set your own color temperature.
- [Custom]: The user can customize the red, green and blue color.
- [Warm]: Sets the screen color to a reddish tone.
- [Medium]: Sets the screen color to between a red and blue tone.
- [Cool]: Sets the screen color to a bluish tone.
- [Manual]: The user can fine-tune the color temperature.
[R/G/B]: You can customize the picture color using red, green, and blue colors.
[Six Color]: Meets the user requirements for colors by adjusting the hue and saturation of the six colors (red,
green, blue, cyan, magenta, and yellow) and then saving the settings.
- Hue: Adjusts the tone of the screen colors.
- Saturation: Adjusts the saturation of the screen colors. The lower the value, the less saturated. The higher
the value, the more saturated.
[Black Level]: Sets the offset level (for HDMI only).
Offset: as a reference for a video signal, this is the darkest color the monitor can display.
- [High]: Keeps the current contrast ratio of the screen.
- [Low]: Lowers the black levels and raises the white levels from the current contrast ratio of the screen.
[Deep Black Pro]: Provides extended contrast and gradation on a dark screen depending on game or video
content.
- [High]: Preferably for PC gaming experiences.
- [Middle]: Preferably for console gaming experiences.
- [Low]: Preferably for playing video content and internet or word-processing.
- [Off]: Disables the Deep Black Pro feature.
- When these feature is enabled, a slight halo effect may be shown on dark backgrounds. This is normal and
not a malfunction.
- When these feature is enabled, the screen flickering may occur intermittently.
- The function can only be used on HDR content.
- It is recommended to turn off when you are not using the gaming function.
[Picture Reset]: Returns picture and color to the default settings.
[Sound]
[Settings] > [Sound]
[Sound Out]: Changes the desired audio output method.
[DTS Headphone:X]: Enables the realization of three-dimensional sound with headphones or earphone.
- [Game]: This mode is optimized for Game.
- [Entertainment]: This mode is optimized for Entertainment.
- [Sports]: This mode is optimized for Sports.
- [Off]: Disables DTS Headphone:X function.
[Volume]: Adjusts the volume level.
- You can adjust [Mute] / [Unmute] by moving the joystick button to in the [Volume] menu.
background
19
ENGLISH
[Input]
[Settings] > [Input]
[Input List]: Selects the input mode.
PBP/PIP Connection
Sub Screen
HDMI 1 HDMI 2 DisplayPort USB-C
Main Screen
HDMI 1
- o o o
HDMI 2
o - o o
DisplayPort
o o - o
USB-C
o o o -
[Aspect Ratio]: Adjusts the aspect ratio of the screen. The display may look the same for [Full Wide],
[Original], and [Just Scan] options at the recommended resolution.
- [Full Wide]: Displays the video in widescreen, regardless of the video signal input.
- [Original]: Displays video according to the aspect ratio of the video signal input.
- [Just Scan]: The aspect ratio is not adjusted from the original.
[Auto Input Switch]: When [Auto Input Switch] is set to [On], display will automatically switch to new input
when connected.
[PBP / PIP]: Displays the screens of two input modes on one monitor.
[PIP Size]: Changes the size of the PIP sub-screen.
[PIP Position]: Changes the position of the PIP sub-screen.
[Screen Switch]: Switches the main screen/sub-screen in [PBP / PIP] mode.
[Sound Switch]: Switches the main screen/sub-screen sound in [PBP / PIP] mode.
NOTE
If not using the [PBP / PIP] feature, [PIP Size], [PIP Position], [Screen Switch] and [Sound Switch] are
deactivated.
Some features are not supported in [PBP / PIP] mode.
[General]
[Settings] > [General]
[Language]: Sets the menu screen to the desired language.
[USB-C Option]: Set the USB-C settings to be optimized for screen resolution or USB data rate.
[Hexagon Lighting]: Sets the lighting on the back of the monitor.
- [Static 1], [Static 2], [Static 3], [Static 4]: Sets the lighting to the desired color.
- [Cycling]: All colors appear alternately.
- [Off]: Turns off the light on the back of the monitor.
[User-defined Key 1]/[User-defined Key 2]: You can customize the main menu to access your preferred menu
easily. [User-defined Key 1] and [User-defined Key 2] appear at the left/right of the main menu.
[SMART ENERGY SAVING]: Conserve energy by using luminance compensation algorithm.
- [High]: Saves energy using the high-efficiency [SMART ENERGY SAVING] feature.
- [Low]: Saves energy using the low-efficiency [SMART ENERGY SAVING] feature.
- [Off]: Disables the feature.
- The value of energy saving data may differ depending on panel and panel suppliers.
- If you select the option of [SMART ENERGY SAVING] is [High] or [Low], monitor luminance become higher
or lower depend on source.
[Deep Sleep Mode]: When [Deep Sleep Mode] is [On], power consumption is minimized while the monitor is
in standby mode.
[Automatic Standby]: If there is no operation on the monitor for a certain period of time, the monitor will
automatically switch to standby mode.
[Input Compatibility Version]: You can set each input to match the supported version of the connected device.
- If the connected device supports 2.1 in HDMI but the screen or sound does not work properly, set this
function to 2.1(AV).
[Buzzer]: This feature lets you set the sound generated from Buzzer when your monitor powers on.
background
20
ENGLISH
[OSD Lock]: This feature disables the configuration and adjustment of menus.
All features are disabled except:
- [Brightness] / [Contrast] in [Picture Adjust]
- [Volume] in [Sound]
- [Input]
- [OSD Lock] / [Information] / [Open Source Software License] in [General]
[Screen Self-diagnosis]: Checks for any problems with the monitor image. Do not unplug the input cable.
[Sound Self-diagnosis]: Checks for any problems with the monitor sound. If [Sound Out] is set to [H/P Out],
this feature is disabled.
[Information]: The following display information will be shown; [Total Power On Time], [Resolution].
[Open Source Software License]: If you select the [View], you can view the Open Source Software notice
information.
[Reset to Initial Settings]: Returns to the default settings.
background
21
ENGLISH
PRODUCT SPECIFICATION
Specifications are subject to change without notice.
The symbol ~ means alternating current, and the symbol means direct current.
Color Depth:
8-bit/ 10-bit color is supported.
Resolution
Max Resolution:
- 5120x2160@240Hz (HDMI / DisplayPort)
- 5120x2160@200Hz (USB-C)
Recommended Resolution:
- 5120x2160@240Hz (HDMI / DisplayPort)
- 5120x2160@200Hz (USB-C)
Environmental Conditions
Operating Conditions
- Temperature: 0°C to 40°C (32°F to 104°F)
- Humidity: Less than 80%
Storing Conditions
- Temperature: -20°C to 60°C (-4°F to 140°F)
- Humidity: Less than 85%
AC/DC Adaptor
Model: ADS-360RLB-20-1 200360E
Manufacturer: SHENZHEN HONOR ELECTRONIC CO., LTD
- Input: 100-240V~ 50/60Hz 5.5A
- Output: 20.0V 18.0A
Power Sources
Power Rating: 20.0V 18.0A
Dimensions: Monitor Size (Width x Height x Depth)
With Stand:
- 1174.6 x 713.1 x 350.0 (mm)
- 46.2x28.0x13.7 (inches)
Without Stand:
- 1174.6 x 544.3 x 247.3 (mm)
- 46.2x21.4x9.7 (inches)
Weight (Without Packaging)
With Stand: 16.8kg (36.9lbs)
Without Stand: 12.2kg (26.8lbs)
background
22
ENGLISH
Support Mode
HDMI
Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks
640 x 480 31.469 59.940 -/-
800 x 600 37.879 60.317 +/+
1024 x 768 48.363 60.004 -/-
1280 x 720 45.000 60.000 +/+
1280 x 1024 79.976 75.025 +/+
1920 x 1080 67.500 60.000 +/+
720 x 480 29.830 59.779 +/-
1280 x 720 44.444 59.979 +/-
1920 x 1080 66.587 59.934 +/-
3440 x 1440 73.681 49.987 +/- Recommended Timing ([Input Compatibility Version]: [1.4])
2560 x 2160 133.272 59.978 +/-
2560 x 2160 167.831 74.991 +/-
3440 x 1440 127.361 84.964 +/- Recommended Timing ([Input Compatibility Version]: [2.1(AV)])
2560 x 1440 182.996 119.998 +/-
5120 x 2160 133.367 60.021 +/-
5120 x 2160 226.580 100.035 +/-
5120 x 2160 333.332 144.050 +/-
5120 x 2160 459.760 200.070 +/-
5120 x 2160 536.170 240.005 +/- Recommended Timing ([Input Compatibility Version]: [2.1(PC)])
background
23
ENGLISH
DisplayPort/USB-C
Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks
640 x 480 31.469 59.940 -/-
800 x 600 37.879 60.317 +/+
1024 x 768 48.363 60.004 -/-
1280 x 720 45.000 60.000 +/+
1280 x 1024 79.976 75.025 +/+
1920 x 1080 67.500 60.000 +/+
720 x 480 29.830 59.779 +/-
1280 x 720 44.444 59.979 +/-
1920 x 1080 66.587 59.934 +/-
3440 x 1440 73.681 49.987 +/-
3440 x 1440 88.819 59.973 +/-
2560 x 2160 133.272 59.978 +/-
2560 x 2160 167.831 74.991 +/-
3440 x 1440 150.972 99.982 +/- Recommended Timing ([Input Compatibility Version]: [1.2])
5120 x 2160 133.367 60.021 +/-
5120 x 2160 226.580 100.035 +/-
5120 x 2160 333.333 144.051 +/-
5120 x 2160 459.761 200.070 +/- Recommended Timing ([Input Compatibility Version]: [1.4])
5120 x 2160 540.189 240.084 +/-
Recommended Timing ([Input Compatibility Version]: [1.4])
Recommended Timing ([Input Compatibility Version]: [2.1])
If the input timing is used outside of the supported frequency, response speed or image quality may deteriorate.
To display the preferred timing & frequency, make sure to use the graphics card that supports DSC (Display Stream Compression).
background
24
ENGLISH
HDMI Timing (Video)
Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz)
480P 31.5 60
720P 45.0 60
1080P 67.5 60
1080P 135.0 120
2160P 135.0 60
2160P 255.0 120
background
25
ENGLISH
TROUBLESHOOTING
Nothing is displayed on the screen.
Is the monitor's power cord plugged in?
- Check if the power cord is correctly plugged into the power outlet.
- If the monitor is in sleep mode (standby mode), move the mouse, or press any key on the keyboard, to
switch the display on.
- Check if the computer is turned on.
Is the monitor powered on?
- Check if the input setting is correct. ([Settings] > [Input])
Is the [The screen is not currently set to the recommended resolution.] message being displayed?
- This occurs when signals transferred from the PC (graphics card) are out of the recommended horizontal or
vertical frequency range of the monitor. Please see the PRODUCT SPECIFICATION section of this manual to
set the appropriate frequency.
Is the [No Signal] message being displayed?
- This is displayed when the signal cable between the PC and the monitor is missing or disconnected. Check
the cable and reconnect it.
Is the [Out of Range] message being displayed?
- This occurs when signals transferred from the PC (graphics card) are out of the horizontal or vertical
frequency range of the monitor. Please see the PRODUCT SPECIFICATION section of this manual to set the
appropriate frequency.
Do you see an "Unrecognized monitor, Plug and Play (VESA DDC) monitor found" message?
Have you installed the display driver?
- Be sure to install the display driver from our web site: http://www.lg.com.
- Make sure to check if the graphics card supports Plug and Play function.
Screen display is unstable and shaky. / Images displayed on the monitor leave shadow trails.
Did you select the appropriate resolution?
- If the selected resolution is HDMI 1080i 60/50 Hz (interlaced), the screen may be flickering. Change the
resolution to 1080p or the recommended resolution.
- Not setting the graphics card to the recommended (optimal) resolution may result in blurred text, a
dimmed screen, a truncated display area or misalignment of the display.
- The setting methods may be different depending on the computer or operating system, and some
resolutions may not be available depending on the performance of the graphics card. If this is the case,
contact the manufacturer of the computer or graphics card for assistance.
Are there spots on the screen?
- When using the monitor, pixilated spots (red, green, blue, white, or black) may appear on the screen. It is
not an error, nor is it related to the monitor's performance.
Some features are disabled.
Are some functions not available when you press the Menu button?
- The OSD is locked. Disable [OSD Lock] in [General].
No sound from the headset port.
Are images displayed using DisplayPort or HDMI or USB-C input without sound?
- Make sure that the headset port connections are made properly.
- Try increasing the volume with the joystick.
- Set the audio output of the PC to the monitor you are using. (The settings may differ depending on the
operating system (OS) you use.)
The recommended resolution is not displayed.
Are you using a Windows PC?
- Please use Windows 11.
- Make sure to update the graphic card to the latest driver.
- The setting methods may be different depending on the computer or operating system, and some
resolutions may not be available depending on the performance of the graphics card. If this is the case,
contact the manufacturer of the computer or graphics card for assistance.
Are you using a Mac PC?
- Some resolutions may not be supported depending on the performance of Mac PC. Contact manufacturer.
background
26
ENGLISH
LICENSE
Each model has different licenses. Visit www.lg.com for more information on the license.
The terms HDMI, HDMI High-Definition Multimedia
Interface, HDMI Trade Dress and the HDMI Logos are
trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.
The SuperSpeed USB Trident logo is a registered trademark
of USB Implementers Forum, Inc.
Manufactured under license from DTS Licensing Limited. For
applicable DTS patents, see https://xperi.com/patents/. DTS,
the Symbol, DTS and the Symbol together, Headphone:X
and DTS Virtual:X are trademarks of DTS, Inc. and affiliates.
DTS' software, technologies, and documentation, © DTS,
Inc. and affiliates. All Rights Reserved.
VESA, VESA logo, DisplayPort compliance logo and
DisplayPort compliance logo for dual-mode source devices
are all registered trademarks of the Video Electronics
Standards Association.
USB Type-C
®
and USB-C
®
are registered trademarks of USB Implementers Forum. USB 2.0 Type-C™ is a
trademark of USB Implementers Forum.
OPEN SOURCE SOFTWARE NOTICE
INFORMATION
To obtain the source code that is contained in this product, under GPL, LGPL, MPL, and other open source
licenses that have the obligation to disclose source code, and to access all referred license terms, copyright
notices and other relevant documents, please visit https://opensource.lge.com.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing
such distribution (such as the cost of media, shipping, and handling) upon email request toopensource@lge.
com.
This offer is valid to anyone in receipt of this information for a period of three yearsafter our last shipment of
this product.
background
27
ENGLISH
BEEP GUIDE
Menu Location
Game Adjust 1
Game Adjust - Game Mode 1 1
Game Adjust - Game Mode - Personalized Picture 1 1 1
Game Adjust - Game Mode - Gamer 1 1 1 2
Game Adjust - Game Mode - Gamer 2 1 1 3
Game Adjust - Game Mode - FPS 1 1 4
Game Adjust - Game Mode - RTS 1 1 5
Game Adjust - Game Mode - Vivid 1 1 6
Game Adjust - Game Mode - Reader 1 1 7
Game Adjust - Game Mode - HDR Effect 1 1 8
Game Adjust - Game Mode - sRGB 1 1 9
Game Adjust - Game Mode - DCI-P3 1 1 10
Game Adjust - Game Mode - Color Weakness 1 1 11
Game Adjust - Game Mode - Calibration 1 1 1 12
Game Adjust - Game Mode - Calibration 2 1 1 13
Game Adjust - VRR / Adaptive-Sync 1 2
Game Adjust - VRR / Adaptive-Sync - Extended 1 2 1
Game Adjust - VRR / Adaptive-Sync - Basic 1 2 2
Game Adjust - VRR / Adaptive-Sync - Off 1 2 3
Game Adjust - Black Stabilizer 1 3
Game Adjust - Black Stabilizer 1 3 1 Slider
Game Adjust - Response Time 1 4
Game Adjust - Response Time - Faster 1 4 1
Game Adjust - Response Time - Fast 1 4 2
Game Adjust - Response Time - Normal 1 4 3
Game Adjust - Response Time - Off 1 4 4
Game Adjust - Crosshair 1 5
Menu Location
Game Adjust - Crosshair - Red Cross 1 5 1
Game Adjust - Crosshair - Green Cross 1 5 2
Game Adjust - Crosshair - Red Dot 1 5 3
Game Adjust - Crosshair - Green Dot 1 5 4
Game Adjust - Crosshair - Off 1 5 5
Game Adjust - FPS Counter 1 6
Game Adjust - FPS Counter - On 1 6 1
Game Adjust - FPS Counter - Off 1 6 2
Game Adjust - Game Reset 1 7
Game Adjust - Game Reset - No 1 7 1
Game Adjust - Game Reset - Yes 1 7 2
Picture Adjust - Brightness 2 1
Picture Adjust - Brightness 2 1 1 Slider
Picture Adjust - Contrast 2 2
Picture Adjust - Contrast 2 2 1 Slider
Picture Adjust - Sharpness 2 3
Picture Adjust - Sharpness 2 3 1 Slider
Picture Adjust - Gamma 2 4
Picture Adjust - Gamma - Mode 1 2 4 1
Picture Adjust - Gamma - Mode 2 2 4 2
Picture Adjust - Gamma - Mode 3 2 4 3
Picture Adjust - Gamma - Mode 4 2 4 4
Picture Adjust - Color Temp 2 5
Picture Adjust - Color Temp - Custom 2 5 1
Picture Adjust - Color Temp - Warm 2 5 2
Picture Adjust - Color Temp - Medium 2 5 3
Picture Adjust - Color Temp - Cool 2 5 4
Picture Adjust - Color Temp - Manual 2 5 5
Picture Adjust - Color Temp - Manual 2 5 5 1 Slider
Picture Adjust - R/G/B 2 6
Menu Location
Picture Adjust - R/G/B - Red 2 6 1
Picture Adjust - R/G/B - Red 2 6 1 1 Slider
Picture Adjust - R/G/B - Green 2 6 2
Picture Adjust - R/G/B - Green 2 6 2 1 Slider
Picture Adjust - R/G/B - Blue 2 6 3
Picture Adjust - R/G/B - Blue 2 6 3 1 Slider
Picture Adjust - Six Color 2 7
Picture Adjust - Six Color - Red Hue 2 7 1
Picture Adjust - Six Color - Red Hue 2 7 1 1 Slider
Picture Adjust - Six Color - Red Saturation 2 7 2
Picture Adjust - Six Color - Red Saturation 2 7 2 1 Slider
Picture Adjust - Six Color - Green Hue 2 7 3
Picture Adjust - Six Color - Green Hue 2 7 3 1 Slider
Picture Adjust - Six Color - Green Saturation 2 7 4
Picture Adjust - Six Color - Green Saturation 2 7 4 1 Slider
Picture Adjust - Six Color - Blue Hue 2 7 5
Picture Adjust - Six Color - Blue Hue 2 7 5 1 Slider
Picture Adjust - Six Color - Blue Saturation 2 7 6
Picture Adjust - Six Color - Blue Saturation 2 7 6 1 Slider
Picture Adjust - Six Color - Cyan Hue 2 7 7
Picture Adjust - Six Color - Cyan Hue 2 7 7 1 Slider
Picture Adjust - Six Color - Cyan Saturation 2 7 8
Picture Adjust - Six Color - Cyan Saturation 2 7 8 1 Slider
Picture Adjust - Six Color - Magenta Hue 2 7 9
Picture Adjust - Six Color - Magenta Hue 2 7 9 1 Slider
Picture Adjust - Six Color - Magenta Saturation 2 7 10
Picture Adjust - Six Color - Magenta Saturation 2 7 10 1 Slider
Picture Adjust - Six Color - Yellow Hue 2 7 11
Picture Adjust - Six Color - Yellow Hue 2 7 11 1 Slider
Picture Adjust - Six Color - Yellow Saturation 2 7 12
background
28
ENGLISH
Menu Location
Picture Adjust - Six Color - Yellow Saturation 2 7 12 1 Slider
Picture Adjust - Black Level 2 8
Picture Adjust - Black Level - High 2 8 1
Picture Adjust - Black Level - Low 2 8 2
Picture Adjust - Deep Black Pro 2 9
Picture Adjust - Deep Black Pro - High 2 9 1
Picture Adjust - Deep Black Pro - Middle 2 9 2
Picture Adjust - Deep Black Pro - Low 2 9 3
Picture Adjust - Deep Black Pro - Off 2 9 4
Picture Adjust - Picture Reset 2 10
Picture Adjust - Picture Reset - No 2 10 1
Picture Adjust - Picture Reset - Yes 2 10 2
Sound 3
Sound - Sound Out 3 1
Sound - Sound Out - H/P Out 3 1 1
Sound - Sound Out - Internal Speaker 3 1 2
Sound - DTS Headphone:X 3 2
Sound - DTS Headphone:X - Game 3 2 1
Sound - DTS Headphone:X - Entertainment 3 2 2
Sound - DTS Headphone:X - Sports 3 2 3
Sound - DTS Headphone:X - Off 3 2 4
Sound - Volume 3 3
Sound - Volume 3 3 1 Slider
Input 4
Input - Input List 4 1
Input - Input List - HDMI 1 4 1 1
Input - Input List - HDMI 2 4 1 2
Input - Input List - DisplayPort 4 1 3
Input - Input List - USB-C 4 1 4
Input - Aspect Ratio 4 2
Menu Location
Input - Aspect Ratio - Full Wide 4 2 1
Input - Aspect Ratio - Original 4 2 2
Input - Aspect Ratio - Just Scan 4 2 3
Input - Auto Input Switch 4 3
Input - Auto Input Switch - On 4 3 1
Input - Auto Input Switch - Off 4 3 2
Input - PBP / PIP 4 4
Input - PBP / PIP - Full Screen 4 4 1
Input - PBP / PIP - PBP(10.5:9+10.5:9) 4 4 2
Input - PBP / PIP - PIP 4 4 3
Input - PBP / PIP - PIP Size 4 5
Input - PBP / PIP - PIP Size - Small 4 5 1
Input - PBP / PIP - PIP Size - Medium 4 5 2
Input - PBP / PIP - PIP Size - Large 4 5 3
Input - PBP / PIP - PIP Position 4 6
Input - PBP / PIP - PIP Position - Bottom Right 4 6 1
Input - PBP / PIP - PIP Position - Botton Left 4 6 2
Input - PBP / PIP - PIP Position - Top Left 4 6 3
Input - PBP / PIP - PIP Position - Top Right 4 6 4
Input - PBP / PIP - Sreen Switch 4 7
Input - PBP / PIP - Screen Switch 4 7 1 Toggle (OK)
Input - PBP / PIP - Sound Switch 4 8
Input - PBP / PIP - Sound Switch 4 8 1 Toggle (OK)
General - Language 5 1
General - Language - English 5 1 1
General - Language - German 5 1 2
General - Language - French 5 1 3
General - Language - Spanish 5 1 4
General - Language - Italian 5 1 5
General - Language - Swedish 5 1 6
Menu Location
General - Language - Finnish 5 1 7
General - Language - Portuguese 5 1 8
General - Language - Portuguese (Brazil) 5 1 9
General - Language - Polish 5 1 10
General - Language - Russian 5 1 11
General - Language - Turkish 5 1 12
General - Language - Ukrainian 5 1 13
General - Language - Chinese 5 1 14
General - Language - Traditional Chinese 5 1 15
General - Language - Japanese 5 1 16
General - Language - Korean 5 1 17
General - Language - Arabic 5 1 18
General - USB-C Option 5 2
General - USB-C Option - High Resolution 5 2 1
General - USB-C Option - High Data Speed 5 2 2
General - Hexagon Lighting 5 3
General - Hexagon Lighting - Static 1 5 3 1
General - Hexagon Lighting - Static 1 5 3 1 Color Chip
General - Hexagon Lighting - Static 2 5 3 2
General - Hexagon Lighting - Static 2 5 3 2 Color Chip
General - Hexagon Lighting - Static 3 5 3 3
General - Hexagon Lighting - Static 3 5 3 3 Color Chip
General - Hexagon Lighting - Static 4 5 3 4
General - Hexagon Lighting - Static 4 5 3 4 Color Chip
General - Hexagon Lighting - Cycling 5 3 5
General - Hexagon Lighting - Off 5 3 6
General - User-defined Key 1 5 4
General - User-defined Key 1 - Input 5 4 1
General - User-defined Key 1 - Game Mode 5 4 2
General - User-defined Key 1 - Sound Out 5 4 3
background
29
ENGLISH
Menu Location
General - User-defined Key 1 - DTS Headphone:X 5 4 4
General - User-defined Key 1 - PBP / PIP 5 4 5
General - User-defined Key 1 - Crosshair 5 4 6
General - User-defined Key 1 - Black Stabilizer 5 4 7
General - User-defined Key 1 - Response Time 5 4 8
General - User-defined Key 1 - FPS Counter 5 4 9
General - User-defined Key 1 - Hexagon Lighting 5 4 10
General - User-defined Key 2 5 5
General - User-defined Key 2 - Input 5 5 1
General - User-defined Key 2 - Game Mode 5 5 2
General - User-defined Key 2 - Sound Out 5 5 3
General - User-defined Key 2 - DTS Headphone:X 5 5 4
General - User-defined Key 2 - PBP / PIP 5 5 5
General - User-defined Key 2 - Crosshair 5 5 6
General - User-defined Key 2 - Black Stabilizer 5 5 7
General - User-defined Key 2 - Response Time 5 5 8
General - User-defined Key 2 - FPS Counter 5 5 9
General - User-defined Key 2 - Hexagon Lighting 5 5 10
General - SMART ENERGY SAVING 5 6
General - SMART ENERGY SAVING - High 5 6 1
General - SMART ENERGY SAVING - Low 5 6 2
General - SMART ENERGY SAVING - Off 5 6 3
General - Deep Sleep Mode 5 7
General - Deep Sleep Mode - On 5 7 1
General - Deep Sleep Mode - Off 5 7 2
General - Automatic Standby 5 8
General - Automatic Standby - 8H 5 8 1
General - Automatic Standby - 6H 5 8 2
General - Automatic Standby - 4H 5 8 3
General - Automatic Standby - Off 5 8 4
Menu Location
General - Input Compatibility Version 5 9
General - Input Compatibility Version - 2.1(PC) / 2.1 5 9 1
General - Input Compatibility Version - 2.1(AV) / 1.4 5 9 2
General - Input Compatibility Version - 1.4 / 1.2 5 9 3
General - Buzzer 5 10
General - Buzzer - On 5 10 1
General - Buzzer - Off 5 10 2
General - OSD Lock 5 11
General - OSD Lock - On 5 11 1
General - OSD Lock - Off 5 11 2
General - Screen Self-diagnosis 5 12
General - Screen Self-diagnosis 5 12 1
General - Sound Self-diagnosis 5 13
General - Sound Self-diagnosis 5 13 1
General - Information 5 14
General - Open Source Software License 5 15
General - Open Source Software License 5 15 1
General - Reset to Initial Settings 5 16
General - Reset to Initial Settings - No 5 16 1
General - Reset to Initial Settings - Yes 5 16 2
background
30
ENGLISH
LIMITED WARRANTY (USA)
THE PRODUCT’S FULL LIMITED WARRANTY TERMS AND CONDITIONS ARE AVAILABLE AT https://www.lg.com/us AND/OR YOUR WARRANTY.
ARBITRATION NOTICE: THIS LIMITED WARRANTY CONTAINS AN ARBITRATION PROVISION THAT REQUIRES YOU AND LG ELECTRONICS (“LG”) TO RESOLVE DISPUTES BY BINDING ARBITRATION INSTEAD OF IN COURT, UNLESS YOU
CHOOSE TO OPT OUT. IN ARBITRATION, CLASS ACTIONS AND JURY TRIALS ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING DISPUTES” BELOW.
PROCEDURE FOR RESOLVING DISPUTES:
ALL DISPUTES BETWEEN YOU AND LG ARISING OUT OF OR RELATING IN ANY WAY TO THIS LIMITED WARRANTY OR THE PRODUCT SHALL BE RESOLVED EXCLUSIVELY THROUGH BINDING ARBITRATION, AND NOT IN A COURT OF GENERAL
JURISDICTION. BINDING ARBITRATION MEANS THAT YOU AND LG ARE EACH WAIVING THE RIGHT TO A JURY TRIAL AND TO BRING OR PARTICIPATE IN A CLASS ACTION.
Definitions. For the purposes of this section, references to “LG mean LG Electronics U.S.A., Inc., its parents, subsidiaries and affiliates, and each of their officers, directors, employees, agents, beneficiaries, predecessors in interest,
successors, assigns and suppliers; references to dispute or claim” shall include any dispute, claim or controversy of any kind whatsoever (whether based in contract, tort, statute, regulation, ordinance, fraud, misrepresentation or
any other legal or equitable theory) arising out of or relating in any way to the sale, condition or performance of the product or this Limited Warranty.
Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must first notify LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LG at LG Electronics, USA, Inc.
Attn: Legal Department- Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632. You and LG agree to engage in good faith discussions in an attempt to amicably resolve your claim. The notice must provide your name, address,
and telephone number; identify the product that is the subject of the claim; and describe the nature of the claim and the relief being sought. If you and LG are unable to resolve the dispute within 30 days, either party may proceed
to file a claim for arbitration.
Agreement to Binding Arbitration and Class Action Waiver. Upon failure to resolve the dispute during the 30 day period after sending written notice to LG, you and LG agree to resolve any claims between us only by binding
arbitration on an individual basis, unless you opt out as provided below. Any dispute between you and LG shall not be combined or consolidated with a dispute involving any other person’s or entitys product or claim. More
specifically, without limitation of the foregoing, any dispute between you and LG shall not under any circumstances proceed as part of a class or representative action. Instead of arbitration, either party may bring an individual
action in small claims court, but that small claims court action may not be brought on a class or representative basis.
Arbitration Rules and Procedures. To begin arbitration of a claim, either you or LG must make a written demand for arbitration. The arbitration will be administered by the American Arbitration Association (“AAA”) and will be
conducted before a single arbitrator under the AAAs Consumer Arbitration Rules that are in effect at the time the arbitration is initiated (referred to as the AAA Rules”) and under the procedures set forth in this section. The AAA
Rules are available online at www.adr.org/consumer. Send a copy of your written demand for arbitration, as well as a copy of this provision, to the AAA in the manner described in the AAA Rules. You must also send a copy of your
written demand to LG at LG Electronics, USA, Inc. Attn: Legal Department- Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632. If there is a conflict between the AAA Rules and the rules set forth in this section, the rules set
forth in this section will govern. This arbitration provision is governed by the Federal Arbitration Act. Judgment may be entered on the arbitrator’s award in any court of competent jurisdiction. All issues are for the arbitrator to
decide, except that issues relating to the scope and enforceability of the arbitration provision and to the arbitrability of the dispute are for the court to decide. The arbitrator is bound by the terms of this provision.
background
31
ENGLISH
Governing Law. The law of the state of your residence shall govern this Limited Warranty and any disputes between us except to the extent that such law is preempted by or inconsistent with applicable federal law.
Fees/Costs. You do not need to pay any fee to begin an arbitration. Upon receipt of your written demand for arbitration, LG will promptly pay all arbitration filing fees to the AAA unless you seek more than $25,000 in damages,
in which case the payment of these fees will be governed by the AAA Rules. Except as otherwise provided for herein, LG will pay all AAA filing, administration and arbitrator fees for any arbitration initiated in accordance with the
AAA Rules and this arbitration provision. If you prevail in the arbitration, LG will pay your attorneys’ fees and expenses as long as they are reasonable, by considering factors including, but not limited to, the purchase amount and
claim amount. Notwithstanding the foregoing, if applicable law allows for an award of reasonable attorneys’ fees and expenses, an arbitrator can award them to the same extent that a court would. If the arbitrator finds either the
substance of your claim or the relief sought in the demand is frivolous or brought for an improper purpose (as measured by the standards set forth in Federal Rule of Civil Procedure 11(b)), then the payment of all arbitration fees
will be governed by the AAA Rules. In such a situation, you agree to reimburse LG for all monies previously disbursed by it that are otherwise your obligation to pay under the AAA Rules. Except as otherwise provided for, LG waives
any rights it may have to seek attorneys’ fees and expenses from you if LG prevails in the arbitration.
Hearings and Location. If your claim is for $25,000 or less, you may choose to have the arbitration conducted solely on the basis of (1) documents submitted to the arbitrator, (2) through a telephonic hearing, or (3) by an
in-person hearing as established by the AAA Rules. If your claim exceeds $25,000, the right to a hearing will be determined by the AAA Rules. Any in-person arbitration hearings will be held at a location within the federal judicial
district in which you reside unless we both agree to another location or we agree to a telephonic arbitration.
Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar
days from the date of the first consumer purchaser’s purchase of the product by either: (i) sending an e-mail to [email protected], with the subject line: Arbitration Opt Out” or (ii) calling 1- 800-980-2973. You must include in the
opt out e-mail or provide by telephone: (a) your name and address; (b) the date on which the product was purchased; (c) the product model name or model number; and (d) the serial number (the serial number can be found (i)
on the product; or (ii) online by accessing https://www.lg.com/us/support and clicking on “How do I find my model number?”).
You may only opt out of the dispute resolution procedure in the manner described above (that is, by e-mail or telephone); no other form of notice will be effective to opt out of this dispute resolution procedure.
Opting out of this dispute resolution procedure will not affect the coverage of the Limited Warranty in any way, and you will continue to enjoy the full benefits of the Limited Warranty. If you keep this product and do not opt out,
then you accept all terms and conditions of the arbitration provision described above.
background
32
ENGLISH
LIMITED WARRANTY (CANADA)
THE PRODUCT’S FULL LIMITED WARRANTY TERMS AND CONDITIONS ARE AVAILABLE AT https://www.lg.com/ca_en/ AND/OR YOUR WARRANTY.
ARBITRATION NOTICE: THIS LIMITED WARRANTY CONTAINS AN ARBITRATION PROVISION THAT REQUIRES YOU AND LG TO RESOLVE DISPUTES BY BINDING ARBITRATION INSTEAD OF IN COURT, UNLESS THE LAWS OF YOUR PROVINCE
OR TERRITORY DO NOT PERMIT THAT, OR, IN OTHER JURISDICTIONS, IF YOU CHOOSE TO OPT OUT. FOR FURTHER CLARITY, THIS ARBITRATION PROVISION IS NOT APPLICABLE TO CONSUMERS RESIDING IN ONTARIO AND QUÉBEC. IN
ARBITRATION, CLASS ACTIONS AND JURY TRIALS ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING DISPUTES” BELOW.
DISCLAIMER:
IF YOU ARE A CONSUMER SUBJECT TO QUÉBEC AND ONTARIO’S CONSUMER PROTECTION ACT, THE EXCLUSION OF WARRANTIES CONTAINED IN THIS SECTION DO NOT EXCLUDE OR LIMIT THE RIGHTS AND REMEDIES THAT YOU MAY
HAVE UNDER SUCH ACT, INCLUDING THE RIGHT TO MAKE A CLAIM UNDER ANY OF THE STATUTORY WARRANTIES PROVIDED THEREUNDER.
PROCEDURE FOR RESOLVING DISPUTES:
EXCEPT WHERE PROHIBITED AT LAW (INCLUDING WITH RESPECT TO QUÉBEC AND ONTARIO CONSUMERS), ALL DISPUTES BETWEEN YOU AND LG ARISING OUT OF OR RELATING IN ANY WAY TO THIS LIMITED WARRANTY OR THE PRODUCT
SHALL BE RESOLVED EXCLUSIVELY THROUGH BINDING ARBITRATION, AND NOT IN A COURT OF GENERAL JURISDICTION. EXCEPT WHERE PROHIBITED AT LAW (INCLUDING WITH RESPECT TO QUÉBEC AND ONTARIO CONSUMERS), YOU
AND LG BOTH IRREVOCABLY AGREE TO WAIVE THE RIGHT TO A JURY TRIAL AND TO BRING OR PARTICIPATE IN A CLASS ACTION.
Definitions. For the purposes of this section, references to “LG mean LG Electronics Canada, Inc., its parents, subsidiaries and affiliates, and each of their officers, directors, employees, agents, beneficiaries, predecessors in interest,
successors, assigns and suppliers; references to dispute or claim” shall include any dispute, claim or controversy of any kind whatsoever (whether based in contract, tort, statute, regulation, ordinance, fraud, misrepresentation or
any other legal or equitable theory) arising out of or relating in any way to the sale, condition or performance of the product or this Limited Warranty.
Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must first notify LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LGECI Legal Team at 20 Norelco
Drive, North York, Ontario, Canada M9L 2X6 (the “Notice of Dispute”). You and LG agree to engage in good faith discussions in an attempt to amicably resolve your claim. The notice must provide your name, address, and telephone
number; identify the product that is the subject of the claim; and describe the nature of the claim and the relief being sought. If you and LG are unable to resolve the dispute within 30 days of LG’s receipt of the Notice of Dispute,
the dispute shall be resolved by binding arbitration in accordance with the procedure set out herein. You and LG both agree that, during the arbitration proceeding, the terms (including any amount) of any settlement offer made
by either you or LG will not be disclosed to the arbitrator until the arbitrator determines the dispute.
background
33
ENGLISH
Agreement to Binding Arbitration and Class Action Waiver. Upon failure to resolve the dispute during the 30 day period after LG’s receipt of the Notice of Dispute, you and LG agree to resolve any claims between you and LG
only by binding arbitration on an individual basis, unless you opt out as provided below, or you reside in a jurisdiction that prevents full application of this clause in the circumstances of the claims at issue (in which case if you are
a consumer, this clause will only apply if you expressly agree to the arbitration). To the extent permitted by applicable law, any dispute between you and LG shall not be combined or consolidated with a dispute involving any other
person’s or entitys product or claim. More specifically, without limitation of the foregoing, except to the extent such a prohibition is not permitted at law, any dispute between you and LG shall not under any circumstances proceed
as part of a class or representative action. Instead of arbitration, either party may bring an individual action in small claims court, but that small claims court action may not be brought on a class or representative basis except
to the extent this prohibition is not permitted at law in your province or territory of jurisdiction as it relates to the claims at issue between you and LG. This does not apply to consumers in Ontario and Québec. In accordance with
provincial legislation, the consumer and LG may agree to resolve the dispute using any procedure available, including commencing the action before the competent courts of those provinces.
Arbitration Rules and Procedures. To begin arbitration of a claim, either you or LG must make a written demand for arbitration. The arbitration will be private and confidential, and conducted on a simplified and expedited
basis before a single arbitrator chosen by the parties under the provincial or territorial commercial arbitration law and rules of the province or territory of your residence. You must also send a copy of your written demand to LG at
LG Electronics, Canada, Inc., Attn: Legal Department- Arbitration, 20 Norelco Drive, North York, Ontario M9L 2X6. This arbitration provision is governed by your applicable provincial or territorial commercial arbitration legislation.
For consumers in Ontario and Québec, the applicable arbitration legislation only applies if consumers agree to submit the dispute to arbitration. Judgment may be entered on the arbitrator’s award in any court of competent
jurisdiction. All issues are for the arbitrator to decide, except that, issues relating to the scope and enforceability of the arbitration provision and to the arbitrability of the dispute are for the court to decide. The arbitrator is bound
by the terms of this provision.
Governing Law. The law of the province or territory of your purchase shall govern this Limited Warranty and any disputes between you and LG except to the extent that such law is preempted by or inconsistent with applicable
federal or provincial/territorial law. Should arbitration not be permitted for any claim, action, dispute or controversy between you and LG, you and LG attorn to the exclusive jurisdiction of the courts of the province or territory of
your purchase for the resolution of the claim, action, dispute or controversy between you and LG.
Fees/Costs. You do not need to pay any fee to begin an arbitration. Upon receipt of your written demand for arbitration, LG will promptly pay all arbitration filing fees unless you seek more than $25,000 in damages, in which
case the payment of these fees will be governed by the applicable arbitration rules. Except as otherwise provided for herein, LG will pay all filing, administration and arbitrator fees for any arbitration initiated in accordance with
the applicable arbitration rules and this arbitration provision. If you prevail in the arbitration, LG will pay your attorneys’ fees and expenses as long as they are reasonable, by considering factors including, but not limited to, the
purchase amount and claim amount. Notwithstanding the foregoing, if applicable law allows for an award of reasonable attorneys’ fees and expenses, an arbitrator can award them to the same extent that a court would. If the
arbitrator finds either the substance of your claim or the relief sought in the demand is frivolous or brought for an improper purpose (as measured by the applicable laws), then the payment of all arbitration fees will be governed
by the applicable arbitration rules. In such a situation, you agree to reimburse LG for all monies previously disbursed by it that are otherwise your obligation to pay under the applicable arbitration rules. Except as otherwise
provided for, LG waives any rights it may have to seek attorneys fees and expenses from you if LG prevails in the arbitration.
Hearings and Location. If your claim is for $25,000 or less, you may choose to have the arbitration conducted solely (1) on the basis of documents submitted to the arbitrator, (2) through a telephonic hearing, or (3) by an
in-person hearing as established by the applicable arbitration rules. If your claim exceeds $25,000, the right to a hearing will be determined by the applicable arbitration rules. Any in-person arbitration hearings will be held at the
nearest, most mutually-convenient arbitration location available within the province or territory in which you reside unless you and LG both agree to another location or agree to a telephonic arbitration.
Severability and Waiver. If any portion of this Limited Warranty (including these arbitration procedures) is unenforceable, the remaining provisions will continue in full force and effect to the maximum extent permitted by
applicable law. Should LG fail to enforce strict performance of any provision of this Limited Warranty (including these arbitration procedures), it does not mean that LG intends to waive or has waived any provision or part of this
Limited Warranty.
background
34
ENGLISH
Opt Out. The arbitration provision requires you and LG to resolve disputes by binding arbitration instead of court, unless the laws of your province or territory do not permit that, or, in other jurisdictions, if you choose to opt out.
The arbitration provision does not apply to consumers in Ontario and Québec.
For individuals that fall within the binding arbitration provisions, you may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out,
you must send notice to LG no later than 30 calendar days from the date of the first consumer purchaser’s purchase of the product by either (i) sending an e-mail to [email protected], with the subject line: Arbitration Opt Out;” or
(ii) calling 1-800-980-2973. You must include in the opt out e-mail or provide by telephone: (a) your name and address; (b) the date on which the product was purchased; (c) the product model name or model number; and (d) the
serial number (the serial number can be found (i) on the product; or (ii) online by accessing https://www.lg.com/ca_en/findmodel_serial/ ).
In the event that you “Opt Out”, the law of the province or territory of your residence shall govern this Limited Warranty and any disputes between you and LG except to the extent that such law is preempted by or inconsistent with
applicable federal or provincial/territorial law. Should arbitration not be permitted for any claim, action, dispute or controversy between you and LG, you and LG agree to attorn to the exclusive jurisdiction
of the courts of the province or territory of your residence for the resolution of the claim, action, dispute or controversy between you and LG.
You may only opt out of the dispute resolution procedure in the manner described above (that is, by e-mail or telephone); no other form of notice will be effective to opt out of this dispute resolution procedure. Opting out of this
dispute resolution procedure will not affect the coverage of the Limited Warranty in any way, and you will continue to enjoy the full benefits of the Limited Warranty. If you keep this product and do not opt out, then you accept all
terms and conditions of the arbitration provision described above.
Conflict of Terms. In the event of a conflict or inconsistency between the terms of this Limited Warranty and the End User License Agreement (“EULA”) in regards to dispute resolution, the terms of this Limited Warranty shall
control and govern the rights and obligations of the parties and shall take precedence over the EULA.
background
The model and serial number of the product are located on the back and on one side
of the product.
Record them below in case you ever need service.
Model
Serial No.
Supplier's Declaration of Conformity
Trade Name LG
Responsible Party LG Electronics USA, Inc.
Address
111 Sylvan Avenue, North
Building, Englewood Cliffs,
NJ 07632
E-mail lg.envir[email protected]

Specifications

LG Electronics 52G930B-B Questions and Answers
