Setup Video
Scan QR code or visit
https://www.tp-link.com/support/
setup-video/#smart-sensors
Meet Your Temperature and Humidity Sensor
Measure the temperature and humidity of the environment and send you instant notications
when the environment changes. It is suitable for green houses, bedrooms, nursery, incubators,
and wine cellars.
Quick Start Guide
Smart Temperature and
Humidity Sensor
©2024 TP-Link 7106511249 REV1.3.0
*Images may dier from actual products.
Open the Tapo app and tap the button.
Select Sensors and then your model. Follow
the app instructions to complete setup.
2. Set Up Your SensorBefore You Start
A Tapo Hub is required. Make sure your Tapo
Hub is successfully added via the Tapo app.
OR
2
Remove the battery insulation tab to power up
your sensor. The LED should blink.
Note: If the LED is not blinking, use a pin to press the Reset
button for 5 seconds to reset your sensor and enter pairing
mode.
1. Power Up Your Sensor1
Take your sensor to the preferred location.
Option 1
Single press the Reset button. Your hub should
make a voice prompt.
3. Test Your Sensor3
Option 2
Blow on the sensor detector. The temperature
and humidity displayed on the Tapo app should
change.
Reset
Sensor
Detector
LED
Battery Pinhole
Use a pin to press and
remove the cover
Reset Button
Single press: Eective range test
Press for 5s: Reset and enter
pairing mode
+
CR2450
4. Place Your Sensor4
Option 1: Hang with the Lanyard
(The installation height should not be higher than 2
meters/6.56 feet.)
4. Place Your Sensor4
4. How to replace the battery?
b. Magnetically attach the sensor to metallic
surfaces.
b. Stick the sensor to your preferred location.a. Stick the included 3M adhesives to the
back panel.
Option 3: Use 3M Adhesives
3M
3M
3M
3M
3M
3M
x2
Metallic Surface
1. Use a pin to press and remove the cover.
2. Replace the battery with a fresh cell
(battery model: CR2450).
3. Put the cover back.
+
CR2450
(The installation height should not be higher than 2 meters/6.56 feet.)
• INGESTION HAZARD: This product contains a button cell or coin
battery.
• DEATH or serious injury can occur if ingested.
• A swallowed button cell or coin battery can cause Internal
Chemical Burns in as little as 2 hours.
• KEEP new and used batteries OUT OF REACH of CHILDREN
• Seek immediate medical attention if a battery is suspected to be
swallowed or inserted inside any part of the body.
• If the battery compartment does not close securely, stop using the
product and keep it away from children.
Risk of explosion if the battery is replaced by an incorrect type.
CAUTION!
Avoid replacement of a battery with an incorrect type that can defeat a
safeguard.
Avoid disposal of a battery into re or a hot oven, or mechanically crushing
or cutting of a battery, that can result in an explosion.
Do not leave a battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of ammable
liquid or gas; Do not leave a battery subjected to extremely low air pressure
that may result in an explosion or the leakage of ammable liquid or gas.
CAUTION!
a) Remove and immediately recycle or dispose of used batteries according
to local regulations and keep away from children. Do NOT dispose of
batteries in household trash or incinerate.
b) Even used batteries may cause severe injury or death.
c) Call a local poison control center for treatment information.
d) This product includes button/coin cell batteries of type CR2450.
e) The nominal voltage of the button/coin cell batteries is +3V.
f) Non-rechargeable batteries are not to be recharged.
g) Do not force discharge, recharge, disassemble, heat above 60°C/140°F
or incinerate. Doing so may result in injury due to venting, leakage or
explosion resulting in chemical burns.
Ensure the batteries are installed correctly according to polarity (+ and -).
Do not mix old and new batteries, dierent brands or types of batteries,
such as alkaline, carbon-zinc, or rechargeable batteries.
Remove and immediately recycle or dispose of batteries from equipment
not used for an extended period of time according to local regulations.
Always completely secure the battery compartment. If the battery
compartment does not close securely, stop using the product, remove the
batteries, and keep them away from children.
Operating Temperature: -20°C (-4°F) ~ 60°C (140°F)
Warning! This product contains a button cell or coin battery. Avoid ingestion
hazard. Death or serious injury can occur if ingested.
Explanation of the symbol on the product
Support
For technical support, user guides, warranty and more,
please visit https://www.tapo.com/support/
a. Stick the included adhesive magnets to
the back panel.
Option 2: Use Adhesive Magnets
x2
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need
service, please contact us.
Do not use the device where wireless devices are not allowed.
Please read and follow the above safety information when operating the
device. We cannot guarantee that no accidents or damage will occur due
to improper use of the device. Please use this product with care and
operate at your own risk.
TP-Link hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of directives
2014/53/EU, 2011/65/EU and (EU) 2015/863.
The original EU declaration of conformity may be found at
https://www.tapo.com/en/support/ce/
TP-Link hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of the Radio
Equipment Regulations 2017.
The original UK declaration of conformity may be found at
https://www.tapo.com/support/ukca/
For EU/UK Region:
Operating Frequency / Nominal Operating Frequency / Max Output
Power:
863~865MHz / 863.35MHz / 25mW (e.r.p)
863~865MHz / 864.35MHz / 25mW (e.r.p)
868~868.6MHz / 868.35MHz / 25mW (e.r.p)
