OWNER'S MANUAL
GAS RANGE
Read this owner's manual thoroughly before operating the appliance and keep
it handy for reference at all times.
ENGLISH
LSGU6339X
MFL71878841
Rev.00_020526
www.LGSIGNATURE.com
Copyright © 2026 LG Electronics. All Rights Reserved
Safety for a Gas Range
WARNING: If the information in these instructions is not
followed exactly, a fire or explosion may result causing property damage,
personal injury or death.
• Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electrical switch.
- Do not use any phone in your building.
- Immediately call your gas supplier from a neighbor's phone. Follow
the gas supplier's instructions.
- If you cannot reach your gas supplier, call the fire department.
• Installation and service must be performed by a qualified installer,
service agency, or the gas supplier.
WARNING:
Never Operate the Top Surface Cooking Section of this Appliance
Unattended.
• Failure to follow this warning statement could result in fire,
explosion, or burn hazard that could cause property damage,
personal injury, or death.
• If a fire should occur, keep away from the appliance and
immediately call your fire department.
DO NOT ATTEMPT TO EXTINGUISH AN O
IL/GREASE FIRE WITH
WATER.
TABLE OF CONTENTS
3
5 IMPORTANT SAFETY
INSTRUCTIONS
5 READ ALL INSTRUCTIONS BEFORE USE
5 Safety Messages
5 Anti-tip Device
6 WARNING
6 Installation
7 Operation
8 Maintenance
8 Grounding Instructions
8 Risk of Fire and Flammable Materials
9 Button Cell or Coin Batteries Symbol
10 Safety Standard for Button Cell or Coin
Batteries
11 CAUTION
11 Installation
11 Operation
11 Maintenance
12 PRODUCT OVERVIEW
12 Product Features
12 Exterior and Interior
12 Product Specifications
13 Accessories
14 INSTALLATION
14 Before Installing
14 Tools Needed
14 Parts
14 In the Commonwealth of Massachusetts
14 Unpacking and Moving the Range
15 Choosing the Proper Location
15 Ventilation
15 Flooring
15 Ambient Temperature
16 Dimensions and Clearances
17 Leveling
17 Leveling the Range
18 Connecting Gas
18 Providing Adequate Gas Supply
18 Connecting the Range to Gas
19 Adjusting Air Shutters (for LP
Conversions)
20 Connecting Electricity
20 Electrical Requirements
20 Grounding
20 Surface Burners
20 Assembling the Surface Burners
21 Checking Ignition of the Surface Burners
21 Optional Rear Filler
21 Installing the Rear Filler
21 Anti-tip Device
21 Installing the Anti-tip Device
22 Test Run
22 Test the Range Before Use
23 Removing/Assembling Oven Door Handle
23 Before Removing/Assembling the Oven
Door Handle
23 Removing Oven Door Handle
23 Assembling Oven Door Handle
24 OPERATION
24 Control Panel
24 Control Panel Features
25 Knob Features
26 Knob Lighting
26 Changing Oven Settings
26 Minimum & Maximum Default Settings
27 Wi-Fi
27 Remote Start
27 Camera & AI Gourmet
28 Control Lock
28 Display
29 Brightness
29 Clock Theme
29 Volume
29 Language
29 Date & Time
30 Temperature Unit
30 Sabbath
31 Start Screen
31 Temperature Adjustment
31 Convection Auto Conversion
31 Preheat Alarm Light
32 Smart Diagnosis
TM
4
32 Factory Reset
32 Open Source License
32 Gas Surface Burners
32 Before Using the Gas Surface Burners
34 Burner Locations
34 Using the Gas Surface Burners
34 Setting the Flame Size
35 Using the Proper Cookware
35 Using a Wok
35 Using the Wok Grate
36 Using Stove-Top Grills
36 Using the Griddle
37 In Case of Power Failure
37 Oven
37 Before Using the Oven
38 Oven Vent
38 Using Heavy Duty Oven Racks
39 Using Gliding Oven Racks
39 Meat Probe
40 Bake
41 Convection Bake and Roast
43 Recommended Baking and Roasting
Guide
44 Broil
46 Recommended Broiling Guide
47 Air Fry
49 Recommended Air Frying Guide
51 Air Sous-Vide
52 Recommended Air Sous-Vide Guide
52 Air Roast
53 Pizza
54 Frozen Meal
54 Dehydrate
55 Warm
56 Proof
56 Crispy Reheat
58 SMART FUNCTIONS
58 LG ThinQ Application
58 LG ThinQ Application Features
58 Installing LG ThinQ Application and
Connecting an LG Appliance
59 RF Module Specifications
59 FCC Statement
60 FCC RF Radiation Exposure Statement
60 Open Source Software Notice
Information
60 Smart Diagnosis
TM
Feature
60 Using LG ThinQ to Diagnose Issues
60 Using Audible Diagnosis to Diagnose
Issues
62 MAINTENANCE
62 Cleaning
62 Interior
62 Exterior
64 Gas Surface Burners
66 EasyClean
68 Self Clean
70 Removing/Assembling Lift-Off Oven
Doors
71 Removing/Assembling Drawers
72 Removing/Assembling the Vent Trim
72 Periodic Maintenance
72 Changing the Oven Light
74 TROUBLESHOOTING
74 FAQs
74 Frequently Asked Questions
76 Before Calling for Service
76 Cooking
78 Parts & Features
80 Noises
80 Wi-Fi
82 LIMITED WARRANTY
82 USA
82 TERMS AND CONDITIONS
82 THIS LIMITED WARRANTY DOES NOT
COVER:
87 PROCEDURE FOR RESOLVING DISPUTES:
5IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
Download this owner's manual at http://www.lg.com
Safety Messages
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
follow all safety messages.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury,
and tell you what may happen if the instructions are not followed.
Anti-tip Device
To reduce the risk of tipping, the appliance must be secured by a properly installed anti-tip device. To
check if the device is installed properly, verify that the anti-tip device is engaged, or grasp the top rear
edge of the range back guard and carefully attempt to tilt it forward. Refer to the installation section for
instructions.
WARNING
• A child or adult can tip the range and be killed.
• Install the anti-tip device to the structure and/or the range. Verify the anti-tip device has been properly
installed and engaged by following the guide on the anti-tip bracket template.
• Engage the range to the anti-tip device by following the guide on the anti-tip bracket template. Ensure
the anti-tip device is re-engaged when the range is moved by following the guide on the anti-tip bracket
template.
• Re-engage the anti-tip device if the range is moved. Do not operate the range without the anti-tip device
in place and engaged.
• See installation instructions for details.
• Failure to do so can result in death or serious burns to children or adults.
• Do not rest large, heavy items such as whole turkeys on the open oven door. The range could tip forward
and cause injury.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages
will follow the safety alert symbol and either the word WARNING or CAUTION.
These words mean:
WARNING
You may be killed or seriously injured if you do not follow instructions.
CAUTION
You may be injured or cause damage to the product if you do not follow instructions.
6 IMPORTANT SAFETY INSTRUCTIONS
WARNING
• Do not step or sit on the oven door. The range could be tipped and injury might result from spilled hot
liquid, food, or the range itself.
• Never remove the oven legs. The range will not be secured to the anti-tip bracket if the legs are
removed.
WARNING
WARNING
• To reduce the risk of explosion, fire, death, electric shock, injury or scalding to persons when using this
product, follow basic precautions, including the following:
Installation
• Do not attempt to open or close the door or operate the oven until the door is properly installed.
• Have the installer show you the location of the range gas shut-off valve and how to shut it off if
necessary.
• To shut off the gas supply to the range, close the range gas shut-off valve by turning it clockwise.
• Make sure your range is properly installed and grounded by a qualified installer, according to the
installation instructions. Any adjustment and service should be performed only by qualified gas range
installers or service technicians.
• Make sure your range is properly adjusted by a qualified service technician or installer for the type of gas
(natural or LP) that is to be used. Your range can be converted for use with either type of gas. See the
installation instructions.
• These adjustments must be done by a qualified service technician according to the manufacturer’s
instructions and all codes and requirements of the authority having jurisdiction. Failure to follow these
instructions could result in serious injury or property damage. The qualified agency performing these
adjustments assumes responsibility for the conversion.
• Disconnect the electrical supply before servicing the appliance.
aAnti-tip bracket
bLeveling leg
a Pressure regulator
b Lever open (use) position
c Remove the label
d Adapter (1/2"-14 NPT)
e Gas flow into range
f Range gas shut-off valve
7IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
• This product should not be installed below ventilation type hood systems that direct air in a downward
direction.
- Doing so may cause ignition and combustion problems with the gas burners resulting in personal
injury and may affect the cooking performance of the unit.
• To prevent poor air circulation, place the range out of the kitchen traffic path and out of drafty locations.
Operation
• Gas appliances can cause minor exposure to four potentially harmful substances, namely benzene,
carbon monoxide, formaldehyde and soot, caused primarily by the imperfect combustion of natural or
LP gas. Correctly adjusted burners, indicated by a bluish rather than a yellow flame, will minimize
imperfect combustion.
- Exposure to these substances can be minimized by opening windows or using a ventilation fan or
hood.
• Let the burner grates and other surfaces cool before touching them.
• Never block the vents (air holes) of the range. They provide the air inlet and outlet necessary for the
range to operate properly with correct combustion.
- Air openings are located at the rear of the cooktop, at the top and bottom of the oven door, and at the
bottom of the range.
• Never obstruct the flow of combustion and ventilation air by blocking the oven vent or air intakes. Doing
so restricts air to the burner and may result in carbon monoxide poisoning.
• Stepping, leaning or sitting on the doors or drawers of this range can result in serious injuries and also
cause damage to the range. Do not allow children to climb or play around the range. The weight of a
child on an open door may cause the range to tip, resulting in serious burns or other injury.
• Never place fingers between the door hinge and front oven frame. Hinge arms are spring mounted. If
accidentally hit, the hinge will slam shut against the oven frame and injure your fingers.
• Do not leave children alone or unattended where a range is hot or in operation. They could be seriously
burned.
• Do not let anyone climb, stand or hang on the oven door, warming drawer or cooktop. They could
damage the range or tip it over, causing severe personal injury.
• Do not stand or place excessive weight on the open oven door. This could tip the range, break the door,
or injure the user.
• To prevent fire hazard or electrical shock, do not use an adapter plug or an extension cord, or remove
the grounding prong from the electrical power cord. Doing so can result in death or serious burns to
children or adults.
• Make sure that all packaging materials are removed from the range before operating it to prevent fire or
smoke damage should the packaging material ignite.
• When opening the door of a hot oven, stand away from the range. The hot air and steam that escape can
cause burns to hands, face and eyes.
• Do not heat food in closed containers. Pressure inside the container could increase and cause the
container to burst, resulting in injury.
WARNING
NEVER cover any slots, holes or passages in the oven bottom or cover an entire rack with materials such as
aluminum foil. Doing so blocks air flow through the oven and may cause carbon monoxide poisoning.
Aluminum foil linings may also trap heat, causing a fire hazard.
WARNING
NEVER use this appliance as a space heater to heat or warm the room. Doing so may result in carbon
monoxide poisoning and overheating of the oven.
8 IMPORTANT SAFETY INSTRUCTIONS
• Do not line oven walls or bottom with aluminum foil or allow them to contact exposed heating elements
in the oven. Doing so could create a fire hazard or cause damage to the range.
• During oven operation, the upper surface of the drawer cavity becomes hot and may cause burns. Never
allow children to remain unsupervised near the oven or cooktop.
• Do not put your hand inside the drawer while the oven is operating.
• REMOTE OPERATION - This appliance is configurable to allow remote operation at any time. Do not store
any flammable materials or temperature sensitive items inside, on top or near surface units of the
appliance.
Maintenance
• Large scratches or impacts to glass doors can lead to broken or shattered glass.
• Items of interest to children should not be placed in cabinets above the range or on the backsplash of
the range.
- Children climbing on the range to reach items could be seriously injured.
• Do not attempt to repair or replace any part of your range unless it is specifically mentioned in this
manual. All other service should be referred to a qualified technician.
Grounding Instructions
• Plug your range into a 120-volt grounded outlet only. Do not remove the round grounding prong from
the plug. If in doubt about the grounding of the home electrical system, it is your personal responsibility
and obligation to have an ungrounded outlet replaced with a properly grounded, three-prong outlet in
accordance with the National Electrical Code. Do not use an extension cord with this range.
Risk of Fire and Flammable Materials
• Never wear loose fitting or hanging garments while using the appliance. Be careful when reaching for
items placed in cabinets over the range. Flammable materials could be ignited if brought in contact with
flame or hot oven surfaces and may cause severe burns.
• Do not place or use combustible materials such as gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
• Do not place flammable materials in the oven or near the cooktop.
• Do not allow cooking grease or other flammable materials in or near the range.
• Do not use water on grease fires. Never touch a flaming pan. Turn the controls off. Smother a flaming
pan on a surface burner by covering the pan completely with a well-fitting lid, cookie sheet or flat tray.
Use a multi-purpose dry chemical or foam-type fire extinguisher.
- A grease fire can be put out by covering it with baking soda or, if available, by using a multi-purpose
dry chemical or foam-type fire extinguisher.
- Flame in the oven or the drawer can be smothered completely by closing the oven door or drawer and
turning the control to off or by using a multi-purpose dry chemical or foam-type fire extinguisher.
• Leak testing of the appliance must be conducted according to the manufacturer’s instructions.
• Gas leaks may occur in the system and result in a serious hazard. Gas leaks may not be detected by smell
alone. Gas suppliers recommend you purchase and install a UL approved gas detector. Install and use in
accordance with the gas detector manufacturer’s instructions.
• When using a broiler pan, make sure to place it correctly to minimize the possibility of grease fires.
• Always remove a broiler pan from the range after you finish broiling. Grease left in the pan can catch fire
if the oven is used without removing the grease from the broiler pan.
• If you have a grease fire in a broiler pan, turn off the cooking function being used and keep the oven
door closed to contain the fire until it burns out.
9IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
• If meat is too close to the flame while broiling, the fat may ignite. Trim excess fat to prevent excessive
flare-ups.
Button Cell or Coin Batteries Symbol
INGESTION HAZARD: This product contains a button cell or coin battery.
10 IMPORTANT SAFETY INSTRUCTIONS
Safety Standard for Button Cell or Coin Batteries
• Remove and immediately recycle or dispose of used batteries
according to local regulations and keep away from children.
- Do NOT dispose of batteries in household trash or incinerate.
• Even used batteries may cause severe injury or death.
• Call a local poison control center for treatment information.
• Non-rechargeable batteries are not to be recharged.
• Do not force discharge, recharge, disassemble, heat above 140 ℉
(60 ℃) or incinerate.
- Doing so may result in injury due to venting, leakage or explosion
resulting in chemical burns.
• Product contains non-replaceable batteries.
• Battery Type : ML621-TZ1
• Nominal Voltage : 3.0 V
WARNING
• INGESTION HAZARD: This product contains
a button cell or coin battery.
• DEATH or serious injury can occur if
ingested.
• A swallowed button cell or coin battery can
cause Internal Chemical Burns in as little
as 2 hours.
• KEEP new and used batteries OUT OF
REACH of CHILDREN.
• Seek immediate medical attention if a
battery is suspected to be swallowed or
inserted inside any part of the body.
11IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
SAVE THESE INSTRUCTIONS
CAUTION
CAUTION
• To reduce the risk of minor injury to persons, malfunction, or damage to the product or property when
using this product, follow basic precautions, including the following:
Installation
• After using your range for an extended period of time high floor temperatures may result. Many floor
coverings will not withstand this kind of use. Never install the range over vinyl tile or linoleum that
cannot withstand such type of use. Never install it directly over interior kitchen carpeting.
Operation
• Do not use the oven for storing food or cookware. Items stored in the oven can catch on fire.
• To prevent damage to the oven door, do not attempt to open the door when Lock is displayed (on some
models).
• Do not use delayed baking for highly perishable foods such as dairy products, pork, poultry, or seafood.
• Keep the oven free from grease buildup.
• Insert the oven racks in the desired position while the oven is cool.
• To prevent burns when removing food, slide racks out until the stop engages, then remove food items.
This may also protect you from getting burned by touching hot surfaces of the door or oven walls.
• When placing or removing a griddle, always wear oven mitts.
• When using cooking or roasting bags in the oven, follow the manufacturer’s directions.
• Use only glass cookware that is recommended for use in gas ovens.
• For safety and better cooking performance, always bake and broil with the oven door closed. Open door
baking or broiling can cause damage to the knobs or valves. Do not leave the oven door open during
cooking or while the oven is cooling down.
Maintenance
• Do not use commercial oven cleaners on the oven finish or around any part of the oven. They will
damage the finish.
• To prevent staining or discoloration, clean the appliance after each use.
• Wear gloves when cleaning the range to avoid injury or burns.
• Clean in the self-clean cycle only parts listed in this manual. Before self-cleaning the oven, remove the
broiler pan, all oven racks, the meat probe and any utensils or food from the oven.
12 PRODUCT OVERVIEW
PRODUCT OVERVIEW
Product Features
Exterior and Interior
a
Cooktop
b
Cooktop controller
c
Oven door
d
Storage drawer
e
Temp Knob
f
Gasket
g
Broil burner
h
Convection burner
i
Model & serial number plate
Product Specifications
The appearance and specifications listed in this manual may vary due to constant product improvements.
Oven Range Models LSGU6339X
Description Gas Slide In Oven Range
Electrical requirements 0.5 kW 120 VAC
Exterior Dimensions 29 7/8" (W) x 37 1/4" (H) x 26 7/8" (D) (D with door closed)
75.8 cm (W) x 94.6 cm (H) x 68.3 cm (D) (D with door closed)
Height to cooking surface 37 1/8" (94.3 cm)
Net weight 162.3 lb (73.6 kg)
Total capacity 6.3 cu. ft.
13PRODUCT OVERVIEW
ENGLISH
Accessories
Included Accessories
Anti-tip Kit
a
Anti-tip Bracket (1 ea)
b Screws (4 ea)
c Anchors (4 ea)
d Template (1 ea)
LP Nozzle Conversion Kit
a
Cooktop Nozzles (6 ea)
b Oven Nozzles (2 ea)
c Installation Guide (1 ea)
d Choke (2 ea)
Other Accessories
a
Heavy Duty Rack (1 ea)
b Griddle (1 ea)
c Rear Filler (1 ea)
d Air Fry Tray (1 ea)
e Meat Probe (1 ea)
f Owner’s Manual (1 ea)
g Wok Grate (1 ea)
h Offset Rack (1 ea)
i Gliding Rack (1 ea)
j Grid (1 ea)
k Broiler Pan (1 ea)
l Right Front Burner Head / Cap (1 ea)
NOTE
• Contact LG Customer Service at 1-800-243-0000
(1-888-542-2623 in Canada) if any accessories
are missing.
• For your safety and for extended product life,
only use authorized components.
• The manufacturer is not responsible for product
malfunction or accidents caused by the use of
separately purchased, unauthorized
components or parts.
• The images in this guide may be different from
the actual components and accessories, which
are subject to change by the manufacturer
without prior notice for product improvement
purposes.
14 INSTALLATION
INSTALLATION
Before Installing
Tools Needed
a Phillips screwdriver
b Flat-blade screwdriver
c Pencil and ruler
d Combination or adjustable wrench
e Pipe wrench (2) (one for support)
f Level
Parts
Parts You May Need
• Gas line shut-off valve
• Pipe joint sealant that resists action of natural
and LP gases
• Flexible metal appliance connector (3/4" or 1/2"
NPT x 1/2" I.D.)
- Never use an old connector when installing a
new range.
• Flare union adapter for connection to gas supply
line (3/4" or 1/2" NPT x 1/2" I.D.)
• Flare union adapter for connection to pressure
regulator on range (1/2" NPT x 1/2" I.D.)
• Liquid leak detector or soapy water
• Lag bolt or 1/2" O.D. sleeve anchor (for concrete
floors only)
In the Commonwealth of
Massachusetts
• This product must be installed by a licensed
plumber or gas fitter.
• When using ball type gas shut-off valves, they
must be the T-handle type.
• When using a flexible gas connector, it must not
exceed 3 feet in length.
Unpacking and Moving the Range
WARNING
• You should use two or more people to move and
install the range. (Excessive Weight Hazard)
Failure to do so can result in back or other injury.
• Do not use the door handles or knobs to push or
pull the range during installation or when
moving the range out for cleaning or service.
Doing so can result in serious damage to the
range.
• Do not push or pull the range by grabbing the
open oven door or cooktop only. Doing so can
result in serious damage to the range.
• Do not lift the range using the cooktop or door
handle. Doing so can cause damage and
improper operation of the range.
• To reduce the risk of burns, do not move this
appliance while it is hot.
NOTE
• The image may differ from the actual model.
15INSTALLATION
ENGLISH
• Your range is heavy and can be installed on soft
floor coverings such as cushioned vinyl or
carpeting. Use care when moving the range on
this type of flooring. Use a belt when moving the
range to prevent damaging the floor. Or slide
the range onto cardboard or plywood to avoid
damaging the floor covering.
• Remove packing material, tape and any
temporary labels from your range before using.
Do not remove any warning-type labels, the
model and serial number label, or the Tech
Sheet that is located on the back of the range.
• To remove any remaining tape or glue, rub the
area briskly with your thumb. Tape or glue
residue can also be easily removed by rubbing a
small amount of liquid dish soap over the
adhesive with your fingers. Wipe with warm
water and dry.
• Do not use sharp instruments, rubbing alcohol,
flammable fluids, or abrasive cleaners to remove
tape or glue. These products can damage the
surface of your range.
Choosing the Proper
Location
Ventilation
• Do not locate your range where it may be
subject to strong drafts. Any openings in the
floor or wall behind the range should be sealed.
Make sure the openings around the base of the
range that supply fresh air for combustion and
ventilation are not blocked by carpeting or
woodwork.
• This appliance must not be installed with a
ventilation system that blows air downward
toward the range. This type of ventilation system
may cause ignition and combustion problems
with the gas cooking appliance resulting in
personal injury or unintended operation.
Flooring
• Your range, like many other household units, is
heavy and can be installed on soft floor
coverings such as cushioned vinyl or carpeting.
Use care when moving the range on this type of
flooring.
• When the floor covering ends at the front of the
range, the area that the range will be installed
on should be built up with plywood to the same
level or higher than the floor covering. This will
allow the range to be moved for cleaning and
servicing, as well as provide proper air flow to
the range.
• Make sure the floor covering can resist
temperatures of at least 167 °F (75 °C). See the
Installation Safety Instructions included in this
manual.
Ambient Temperature
• Make sure the wall coverings around your range
can resist the heat generated up to 194 °F (90 °C)
by the range. See the Installation Safety
Instructions included in this manual.
16 INSTALLATION
Dimensions and Clearances
• Provide proper clearance between the range and adjacent combustible surfaces.
• These dimensions must be met for safe use of your range.
• The location of the electrical outlet and pipe opening (see "Gas Pipe and Electrical Outlet Locations"
below) may be adjusted to meet specific requirements.
• The range may be placed with 0" clearance (flush) at the back wall.
Dimensions
- Dimensions LSGU6339X
AWidth 29 7/8" (758.8 mm)
BHeight 37 1/4" (946 mm)
C Depth (Includes Door Handle) 29 3/8" (745.2 mm)
D Height (Excludes Vent Trim) 36" (913.0 mm)
E Depth (Includes only the product body that is loaded into the cabinet.
Excludes door, drawer, and handles)
24 3/4" (629.4 mm)
F Depth (Excludes Door Handle) 26 7/8" (683 mm)
G Depth when drawer is fully opened 36 1/16" (916.2 mm)
H Depth when door is fully opened 48 5/8" (1 235.9 mm)
17INSTALLATION
ENGLISH
Clearances
a Minimum
b Minimum clearance to left/right wall
c Maximum depth for cabinets above countertops
d Front edge of the range side panel forward from cabinet
e To cabinets below cooktop and at the range back
Gas Pipe and Electrical Outlet Locations
Leveling
Leveling the Range
Level the range by adjusting the leveling legs with
a wrench. Extending the legs slightly may also
make it easier to insert the rear leg into the anti-tip
bracket.
30"
(76.2 cm)
7
14
/
16
"
(20 cm)
11
13
/
16
"
(30 cm)
3
6
/
16
"
(8.5 cm)
3"
(7.6 cm)
17
15
/
16
"
(45.6 cm)
5
14
/
16
"
(15 cm)
6
11
/
16
"
(17 cm)
18 INSTALLATION
Checking Adjustments
1 Place the level diagonally on the oven rack,
and check each direction for level.
• First check direction
a. Then check
direction
b.
2 If the level doesn’t show that the rack is level,
adjust the leveling legs with a wrench.
Connecting Gas
Providing Adequate Gas Supply
• Your range is designed to operate at a pressure
of 5" of water column on natural gas or 10" of
water column on LP.
• Make sure you are supplying your range with the
type of gas for which it is configured.
• This range is convertible for use with natural or
LP gas. When using this range with LP gas,
conversion must be made by a qualified LP
installer before attempting to operate the range.
• For proper operation, the pressure of natural
gas supplied to the regulator must be between
5" and 13" of water column.
• For LP gas, the pressure supplied to the
regulator must be between 10" and 13" of water
column. When checking for correct operation of
the regulator, the inlet pressure must be at least
1" more than the operating (manifold) pressure
as given above.
•The pressure regulator located at the inlet of the
range must remain in the supply line regardless
of which type of gas is being used.
• A flexible metal appliance connector used to
connect the range to the gas supply line should
have an I.D. of 5/8" and a maximum length of 5
feet. In Canada, flexible connectors must be
single wall metal connectors less than 6 feet in
length.
Connecting the Range to Gas
WARNING
• Isolate the range from the gas supply system by
closing its individual shut-off valve during any
pressure testing of the gas supply system at test
pressures equal to or less than 1/2 psi (3.5 kPa).
• The appliance and its individual shut-off valve
must be disconnected from the gas supply
piping system during any pressure testing of
that system at test pressures in excess of 1/2 psi
(3.5 kPa).
• Shut off the range gas supply valve before
removing the old range and leave it off until the
new hook-up has been completed.
• Because hard piping restricts movement of the
range, a CSA International-certified flexible
metal appliance connector should be used
unless local codes require a hard-piped
connection.
• A manual valve must be installed in an accessible
location in the gas piping external to the
appliance for the purpose of turning on or
shutting off gas to the appliance.
• Never reuse an old connector when installing a
new range.
• To protect against gas leaks, use a qualified pipe
joint sealant on all external threads.
1 Install a male 1/2" or 3/4" flare union adapter
to the NPT internal thread of the manual shut-
off valve, taking care to back-up the shut-off
valve to keep it from turning.
2 Install a male 1/2" flare union adapter to the
1/2" NPT internal thread at the inlet of the
pressure regulator. Use a backup wrench on
the pressure regulator fitting to prevent
damage.
• Check that the gas pressure regulator valve
is in the open position.
a Lever’s open position
b Lever’s closed position
19INSTALLATION
ENGLISH
NOTE
• The gas pressure regulator valve is open when
shipped. If the range does not work properly
after installation, make sure the regulator valve
is still open.
3 Connect a flexible metal appliance connector
to the adapter on the range. Position the
range to permit connection at the shut-off
valve.
4 When all connections have been made, be
sure all range controls are in the OFF position
and the pressure regulator valve is open
before turning on the main gas supply valve.
• Gas leaks may occur in your system and
create a hazard. Gas leaks may not be
detected by smell alone.
5 Check all gas connection joints and fittings for
leaks with a non-corrosive leak detection fluid,
then wipe off.
• Gas suppliers recommend you purchase
and install a UL approved gas detector.
Install and use in accordance with the
installation instructions.
WARNING
• Do not use a flame to check for gas leaks.
NOTE
• Installation must conform with local codes or, in
the absence of local codes, with the National
Fuel Gas Code, ANSI Z223.1/NFPA 54 or, in
Canada, the Natural Gas and Propane
Installation Code, CSA B149.1.
Flexible Connector Hookup
Have the installer show you the location of the
range gas shut-off valve and how to shut it off if
necessary.
a Pressure regulator
b 1/2" adapter
c 1/2" adapter
d Gas flow into range
e Flex connector (6 ft. max.)
f Gas shut-off valve
g 1/2" adapter
h 1/2" or 3/4" gas pipe
Pressure Regulator Position
a Pressure regulator
Adjusting Air Shutters (for LP
Conversions)
The range comes from the factory with the air
shutters adjusted for proper air flow for natural
gas. If converted to LP, follow the instructions
provided in the conversion kit to properly adjust
the air shutters. LP conversion must be performed
by a qualified technician.
20 INSTALLATION
Connecting Electricity
Electrical Requirements
120 Volt, 60 Hz, properly grounded dedicated
circuit protected by a 15 or 20 Amp circuit breaker,
or slow blow fuse.
If an external electrical source is utilized, the
appliance, when installed, must be electrically
grounded in accordance with local codes or, in the
absence of local codes, with the National Electrical
Code, NFPA70 or the Canadian Electric Code, CSA
C22.1-02.
Grounding
WARNING
• For personal safety, this appliance must be
properly grounded.
• This appliance is equipped with a three-prong
groundling plug for your protection against
shock hazard and should be plugged directly
into a properly grounded receptacle.
• Do not cut or remove the groundling prong from
this plug.
• The customer should have the wall receptacle
and circuit checked by a qualified electrician to
make sure the receptacle is properly grounded.
• The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong grounding wall
receptacle to minimize the possibility of electric
shock hazard from this appliance.
• Where a standard two-prong wall receptacle is
encountered, it is the personal responsibility and
obligation of the customer to have it replaced
with a properly grounded three-prong wall
receptacle.
• Ensure proper ground
a exists before use.
• Do not use an adapter plug. Disconnecting of
the power cord places undue strain on the
adapter and leads to eventual failure of the
adapter ground terminal.
Surface Burners
Assembling the Surface Burners
CAUTION
• Do not operate the burners without all parts in
place.
1 Place the burner caps and heads on the
cooktop.
• There are one small, one medium, one
large, one oval(center), and one extra large
burner head and cap.
2 Make sure that the caps and heads are placed
in the correct locations.
3 Make sure the hole in the burner head is
positioned over the electrode.
a Oval (Center) burner head/cap assembly
b Medium burner head and cap
c Small burner head and cap
d Large burner head and cap
e Front of range
f Dual burner head and cap
g Hole
h Electrode
21INSTALLATION
ENGLISH
Checking Ignition of the Surface
Burners
Electric Ignition
Select a surface burner knob and simultaneously
push in and turn to the Lite position. You will hear
a clicking sound indicating proper operation of the
spark module.
Once the air has been purged from the supply
lines the burner should ignite within 4 seconds.
After the burner ignites, rotate the knob out of the
Lite position. Try each burner in succession until
all burners have been checked.
Quality of Flames
The combustion quality of the burner flames
needs to be confirmed visually.
Yellow flames
Call for service.
Yellow tips on outer cones
This is normal for LP gas.
Soft blue flames
This is normal for natural gas.
NOTE
• With LP gas, some yellow tipping on outer cones
is normal.
Optional Rear Filler
Installing the Rear Filler
If the counter does not bridge the opening at the
rear wall, the rear filler kit which is provided with
the slide in range will be needed.
NOTE
• If the countertop depth is greater than 25 3/8 "
there will be a gap between the filler kit and the
back wall.
• If the countertop depth is less than 24 3/4 ", the
control panel will not sit flush with the
countertop.
1 Using a screwdriver, remove the three screws
holding the rear bracket in place.
a Rear bracket
2 Attach the rear bracket and filler assembly as
shown, using the three screws removed in
step 1.
b Rear filler
Anti-tip Device
Installing the Anti-tip Device
Tip Hazard
WARNING
• A child or adult can tip the range and be killed.
22 INSTALLATION
WARNING
• Install the anti-tip device to the structure and/or
the range. Verify the anti-tip device has been
properly installed and engaged by following the
guide on the anti-tip bracket template.
• Engage the range to the anti-tip device by
following the guide on the anti-tip bracket
template. Ensure the anti-tip device is re-
engaged when the range is moved by following
the guide on the anti-tip bracket template.
• Re-engage the anti-tip device if the range is
moved. Do not operate the range without the
anti-tip device in place and engaged.
• See installation instructions for details.
• Failure to follow these instructions can result in
death or serious burns to children or adults.
• Range must be secured with an approved anti-
tip device.
• The range could be tipped by standing, sitting or
leaning on an open door if the range or anti-tip
device is not properly installed.
• The use of this device does not preclude tipping
of the range when not properly installed.
• After installing the anti-tip device, verify that it is
in place by carefully attempting to tilt the range
forward.
• This range has been designed to meet all
recognized industry tip standards for all normal
conditions.
• The installation of the anti-tip device must meet
all local codes for securing the appliance.
Using the Anti-tip Bracket Template
• The anti-tip bracket is packaged with an
installation template. The instructions include
necessary information to complete the
installation. Read and follow the range
installation instruction sheet.
•Screws
c must enter wood or concrete.
a Anti-tip Bracket
b Wall Plate
Engaging the Anti-tip Device
a Anti-tip Bracket
b Leveling Leg
1 Slide the range against the wall, making sure
the back leg slides into and engages the anti-
tip bracket.
2 Check for proper installation by grasping the
front edge of the cooktop and carefully
attempting to tilt the range forward.
Test Run
Test the Range Before Use
NOTE
• Do not try to light either the Bake or Broil
burners during a power outage. The range has
an electrical ignition system and cannot be used
without power.
Checking Operation of Bake Burners
To check ignition of the Bake burner, follow the
steps below:
1 Remove all packing materials from inside the
oven cavity.
2 Tap Manual Cook and tap Bake.
• Make sure the door is closed.
• Default Temperature is 350 ℉.
3 Tap START.
NOTE
• It may take between 30 and 90 seconds for the
burner to start heating.
23INSTALLATION
ENGLISH
Checking Operation of Broil Burners
To check ignition of the Broil burner, follow the
steps below:
1 Remove all packing materials from inside the
oven cavity.
2 Tap Manual Cook and tap Broil.
• Make sure the door is closed.
• Default Temperature setting is High.
3 Tap START.
NOTE
• It may take between 30 and 90 seconds for the
burner to start heating.
Removing/Assembling Oven
Door Handle
Before Removing/Assembling the
Oven Door Handle
• Tools Needed
- 3/32" Allen wrenches
CAUTION
• When assembling or disassembling the handles,
grasp the handle firmly to avoid dropping it.
• When assembling or disassembling the handles,
wear gloves for your safety.
• We suggest you have another person hold the
handle in place while you remove/insert the
screws.
• Do not swing the handle into nearby people or
animals.
• Make sure that the set screws are in place and
the pockets at the ends of the handles are
aligned correctly over the mounting fasteners on
the doors. The set screws should be loose
enough to allow the pockets to slide down into
place over the mounting fasteners on the door.
• Make sure that there is not a gap between the
door and handle after assembling the handle.
• After assembling the handle, pull the door open
to make sure the screws are fully assembled.
Removing Oven Door Handle
1 Loosen the set screws a located on the lower
side of the handle with a 3/32 in. Allen wrench
and remove the handle.
Assembling Oven Door Handle
1 Place the handle on the door by fitting the
handle footprints over the mounting
fasteners and tightening the set screws a
with a 3/32 in Allen wrench.
24 OPERATION
OPERATION
Control Panel
Control Panel Features
a Power On/Off button
Display Icons
Icons appear in display when activated.
a All Modes Icon
Tap to go to the All Modes screen.
Tap to go to the timer setting screen or timer editing screen.
b Control Lock Icon
Tap to activate the Control Lock function.
c Light Icon
Tap to turn on or off the interior oven lamp.
d Timer Icon
Tap to go to the timer setting screen or timer editing screen.
e Wi-Fi Icon
• Appears when oven is connected to Wi-Fi.
• Appears when oven is disconnected from Wi-Fi or is not connected in application.
25OPERATION
ENGLISH
Knob Features
After cleaning the cooktop control knobs, make sure to replace each knob in the correct position. Failure to
do so can result in improper operation of the burners.
f Remote Start Icon
• Appears when Remote Start is active.
• Appears when Remote Start is active, but Wi-Fi setting is OFF or Wi-Fi
disconnected.
g Demo Mode Icon
Appears when Demo mode is on.
h Door Lock Icon
Appears when Door Lock is on.
i Camera Icon
Appears when Camera is on.
j REC Icon
Appears when Camera is recording.
k Auto Conversion Icon
Appears when Convection Auto Conversion is turned on.
l Probe Icon
Appears when probe is connected.
m Oven Cooling Icon
Appears during or after oven operation to indicate cooling fan is running in oven.
n Settings Icon
Tap to go to the Settings Screen.
26 OPERATION
Knob Lighting
Knob lighting illuminates the edge of the knob when you turn the knob to operate the heating elements
(excluding Temp Knob).
a Knob Lighting
b Temp Knob
NOTE
• Temp Knob does not operate the Knob Lighting.
• Turning on Control Lock does not prevent the knob lighting or cooktop elements from turning on when
a cooktop knob is turned.
Changing Oven Settings
Minimum & Maximum Default
Settings
All of the features listed have a minimum and a
maximum time or temperature setting that may
be entered into the controls. An entry acceptance
beep sounds each time a control button is pressed.
An entry error tone (two short tones) sounds if the
entry of the temperature or time is below the
minimum or above the maximum setting for the
feature.
Feature
Min.
Temp.
/
Time
Max.
Temp.
/
Time
Default
Clock
12
Hr.
1:00
Hr. /
min.
12:59
Hr. /
min.
24
Hr.
0:00
Hr. /
min.
23:59
Hr. /
min.
Timer
12
Hr.
0:01
min. /
sec.
11:59
Hr. /
min.
24
Hr.
0:01
min. /
sec.
11:59
Hr. /
min.
Cook
Time
12
Hr.
0:01
Hr. /
min.
11:59
Hr. /
min.
24
Hr.
0:01
Hr. /
min.
11:59
Hr. /
min.
Conv.
Bake
300 °F /
(*275
°F)
550 °F /
285 °C
350 °F
(*325 °F) /
12 Hr.
Conv.
Roast
300 °F /
(*275
°F)
550 °F /
285 °C
350 °F
(*325 °F) /
12 Hr.
Feature
Min.
Temp.
/
Time
Max.
Temp.
/
Time
Default
27OPERATION
ENGLISH
NOTE
• * : Using auto conversion
• Default cook mode times are without setting a
cook time.
Wi-Fi
Connect the appliance to a home Wi-Fi network to
use Remote Start and other smart functions. See
the Smart Functions section for more details.
Setting Up Wi-Fi
1 Tap the Settings icon at the top right of screen
and tap Network & System.
2 Tap Wi-Fi.
3 Tap Set Up Wi-Fi.
4 Follow the instructions in the Wi-Fi Guide in
the display.
Resetting Wi-Fi
1 Tap the Settings icon at the top right of screen
and tap Network & System.
2 Tap Wi-Fi.
3 Tap Reset Wi-Fi.
4 Follow the instructions in the Wi-Fi Guide in
the display.
Remote Start
This feature can be used with the Manual Cook
modes to remotely start or stop the cooking
operation. The appliance must be connected to a
home Wi-Fi network to use Remote Start.
Setting Remote Start
1 Tap the Settings icon at the top right of screen
and tap Network & System.
2 Tap the toggle switch next to Remote Start to
select On or Off.
3 If On is selected, the Remote Start icon
appears at the top of the display.
4 Follow the instructions in the LG ThinQ app
for using the Remote Start function.
Camera & AI Gourmet
When the camera setting is turned on, you can use
camera features in the LG ThinQ app. If the Menu
Recommendation setting is also turned on, an
Auto Cook menu is recommended when you place
Broil Lo Hi
Hi /
3 Hr.
Bake
170 °F /
80 °C
550 °F /
285 °C
350 °F /
12 Hr.
Proof
0:01
Hr. /
min.
11:59
Hr. /
min.
12 Hr.
Warm 3 Hr.
Probe
80 °F /
27 °C
210 °F /
100 °C
150 °F /
65 °C
SelfClean 3 Hr. 5 Hr. 4 Hr.
EasyClean 10 min.
Frozen
Meal
300 ℉ /
150 ℃
0:01
Hr. /
min.
550 ℉ /
285 ℃
11:59
Hr. /
min.
400 °F /
205 ℃
Air Fry
300 ℉ /
150 ℃
0:01
Hr. /
min.
550 ℉ /
285 ℃
11:59
Hr. /
min.
400 °F /
205 ℃
Air Sous-
Vide
100 ℉ /
38 ℃
205 ℉ /
96 ℃
130 °F /
54 ℃
Feature
Min.
Temp.
/
Time
Max.
Temp.
/
Time
Default
Remote Start icon
28 OPERATION
food in the oven. If the AI Browning Alarm setting
is also turned on, it notifies you when the selected
browning level is reached.
Setting Camera
1 Tap the Settings icon at the top right of
screen, and tap "Network & System".
2 Tap Camera & AI Gourmet.
3 Tap the toggle switch next to Camera to
select ON or OFF.
4 If ON is selected, the Camera icon appears at
the top of the display.
When the Menu Recommendation setting is ON
and the lower oven door is closed, food
recognition proceeds immediately after entering
the start screen.
Setting Menu Recommendation
1 Make sure the Camera is ON . Menu
Recommendation can only be activated when
Camera is ON .
2 Tap the toggle switch next to Menu
Recommendation to select ON or OFF.
When the AI Browning Alarm setting is ON and an
Auto Cook menu with a browning option is
cooking, the oven will notify you with a pop-up and
sound when the browning status reaches the
selected browning level.
Setting AI Browning Alarm
1 Make sure the Camera and Wi-Fi is ON. Menu
Recommendation can only be activated when
Camera is ON .
2 Tap the toggle switch next to AI Browning
Alarm to select ON or OFF.
Control Lock
The Control Lock feature automatically prevents
most oven controls from being turned on. All
functions are disabled except the POWER button.
Control Lock does not lock the oven door.
Lock
1 Tap the Settings icon at the top right of screen
and tap Display & Sound.
2 Tap the toggle switch next to Control Lock to
select On or Off.
3 When Control Lock is activated, the lock icon
appears at the top of the display.
Unlock
1 Tap any part of the screen while Control Lock
is on.
2 A popup screen appears. Tap and hold the
lock icon for 3 seconds to turn off Control
Lock.
3 The lock icon k disappears from the top of
the display.
Display
Set the length of time before the display sleeps.
There are three options you can select.
• ON : Always on
• OFF : Automatically turns off if idle for 5 minutes.
• Night Mode : Turns off from 10:00 PM to 5:00
AM.
Setting Display Option
1 Tap the Settings icon at the top right of
screen, and tap Display & Sound.
2 Tap Display.
Camera icon
Lock icon
29OPERATION
ENGLISH
3 Select the desired option.
Brightness
Adjust the brightness of the LCD display from 20 %
to 100 % in increments of 20 %.
Setting Display Brightness
1 Tap the Settings icon at the top right of
screen, and tap Display & Sound.
2 Tap Brightness.
3 Adjust the brightness by tapping the +/-
button, tapping the bar, or dragging the bar.
Clock Theme
There are five different clock themes available.
Setting Clock Theme
1 Tap the Settings icon at the top right of
screen, and tap Display & Sound.
2 Tap Clock Theme.
3 Swipe to browse through the clock themes.
And select a clock theme.
Volume
Adjust the volume of the following features: oven
start, button operation, end of cooking, preheating
complete.
Setting the Oven Volume
1 Tap the Settings icon at the top right of
screen, and tap Display & Sound.
2 Tap Volume.
3 Adjust the volume by tapping the +/- button,
tapping the bar, or dragging the bar.
NOTE
• Oven volume can be selected from 3 options:
High, Low, and Mute.
• Cooktop volume can be selected from 2 options:
High and Mute.
Language
Set the display language to English, Spanish, or
French.
Selecting a Language
1 Tap the Settings icon at the top right of
screen, and tap General.
2 Tap Language.
3 Select the desired language.
Date & Time
The date and time show in the LCD display when
the ovens are not in use.
NOTE
• When the Auto Time Sync setting is turned on,
the server's date and time is applied
automatically (Auto Time Sync requires a Wi-Fi
connection).
• When the Auto Time Sync setting is turned off,
Date & Time can be set separately.
Setting Auto Time Sync
1 Tap the Settings icon at the top right of
screen, and tap General.
2 Tap Date & Time.
3 Tap the toggle switch next to Auto Time Sync
to select On or Off.
30 OPERATION
Setting Date
1 Tap the Settings icon at the top right of
screen, and tap General.
2 Tap Date & Time.
3 Scroll to set the correct date.
Setting Current Time
1 Tap the Settings icon at the top right of
screen, and tap Time.
2 Tap Date & Time.
3 Scroll to set the correct hour and minutes. You
can also press the number pad icon and enter
the desired numbers.
Setting Time Format
1 Tap the Settings icon at the top right of
screen, and tap General.
2 Tap Date & Time.
3 Tap the toggle switch next to 24-Hour Time to
select 12 H or 24 H.
Temperature Unit
Set the oven temperature display to show either
Fahrenheit (℉) or Celsius (℃) units. The oven
defaults to Fahrenheit unless changed by the user.
Selecting Fahrenheit or Celsius
1 Tap the Settings icon at the top right of screen
and tap General.
2 Tap Temperature Unit.
3 Select the desired Temperature Unit.
Sabbath
Sabbath mode is typically used on the Jewish
Sabbath and Holidays. When the Sabbath mode is
activated, the oven does not turn off until the
Sabbath mode is deactivated. In Sabbath mode, all
oven function buttons are inactive. Sabbath and
the set temperature will appear in the display.
When Sabbath mode is enabled, the appliance can
be used without having to be powered on or
turned off.
While the oven is in Sabbath mode, the following
functions are disabled:
Temperature Adjustments, Cooking Time, Display,
Oven Light On/Off, Alarm Functions and Wi-Fi.
Setting Sabbath Mode
1 Tap the Settings icon at the top right of screen
and tap General.
2 Tap Sabbath.
3 Tap the temperature to set the desired
temperature. Adjust the temperature by
tapping the +/- button, tapping the bar, or
dragging the bar.
• You can also use the number pad icon to set
the temperature directly and then tap OK.
4 If desired, tap cook time to set the cook time.
Scroll to set the desired cook time.
• You can also use the number pad icon to set
the cook time directly and then tap OK.
5 Tap Start.
6 To stop the Sabbath mode, press the POWER
button on the control panel.
NOTE
• If a cook time is set, the oven turns off
automatically at the end of the cook time,
without chiming. The oven remains in Sabbath
mode, but is turned off.
Number pad icon
31OPERATION
ENGLISH
• If no cook time is set, the oven will not
automatically turn off.
• After a power failure, the display will turn back
on in Sabbath mode, but the oven will be off.
• Always close the oven door before engaging
Sabbath Mode.
• Probe is not available in Sabbath mode.
Start Screen
There are five different screen themes available.
Setting Start Screen
1 Tap the Settings icon at the top right of screen
and tap Customized.
2 Tap Start Screen.
3 Select the desired start screen theme.
• Main Menu
• Manual Cook
• Auto Cook
• Recent Cook
• My Recipes
Temperature Adjustment
Your new oven may cook differently than the one it
replaced. Use your new oven for a few weeks to
become more familiar with it before changing the
temperature settings. If after familiarizing yourself
with the new oven, you still think that it is too hot
or too cold, you can adjust the oven temperature
yourself.
NOTE
• To begin, either raise or lower the thermostat 15
℉ (8 ℃). Try the oven with the new setting. If the
oven still needs adjustment, raise or lower the
thermostat again, using the first adjustment as a
gauge. For example, if the adjustment was too
much, raise or lower the thermostat 10 ℉ (5 ℃).
If the adjustment was not enough, raise or lower
the thermostat 20 ℉ (11 ℃). Proceed in this way
until the oven is adjusted to your satisfaction.
Adjusting the Temperature
1 Tap the Settings icon at the top right of
screen, and tap Customized.
2 Tap Temperature Adjustment.
3 Adjust the temperature by tapping the +/-
button, tapping the bar, or dragging the bar.
Convection Auto Conversion
When Convection Bake and Convection Roast
are selected, Convection Auto Conversion
automatically converts the standard recipe
temperature entered to a convection temperature
by subtracting 25 ℉ / 14 ℃. This auto-converted
temperature shows on the display. For example,
select Convection Bake, enter 350 ℉, and 325 ℉
shows on the display after preheat.
Convection Auto Conversion is enabled by default.
To change the setting, follow these instructions.
Setting Convection Auto Conversion
1 Tap the Settings icon at the top right of
screen, and tap Customized.
2 Tap the toggle switch next to Convection
Auto Conversion to select On or Off.
3 When Convection Auto Conversion is
activated, the Auto Conversion icon appears
at the top of the display.
Preheat Alarm Light
When the oven reaches its set-temperature, the
preheat alarm light flashes 5 times or until the
oven door is opened.
You can turn the preheat alarm light on or off.
Setting the Preheat Alarm Light
1 Tap the Settings icon at the top right of
screen, and tap Customized.
2 Tap the toggle switch next to Preheat Alarm
Light to select On or Off.
32 OPERATION
Smart Diagnosis
TM
Smart Diagnosis
TM
can be run through the LG
ThinQ smartphone application or by calling for
support. Place your smartphone's mouthpiece
near the top left corner of the screen. See "Smart
Diagnosis Function" in the Smart Functions section
for detailed instructions.
1 Tap the Settings icon at the top right of
screen, and tap Maintenance & Info.
2 Tap Smart Diagnosis.
3 Tap Start to start the diagnostic tone.
Factory Reset
This function returns all settings to the factory
defaults.
CAUTION
• All stored data will be deleted.
1 Tap the Settings icon at the top right of
screen, and tap Maintenance & Info.
2 Tap Factory Reset.
3 A popup will appear in the display. If you want
to reset data to the factory defaults, then tap
Reset.
Open Source License
This screen displays a list of the open source
software contained in this product. Refer to the
indicated licenses for the terms and conditions of
their use.
1 Tap the Settings icon at the top right of screen
and tap Maintenance & Info.
2 Tap Open Source License.
3 Tap View Contents to Read Open Source
License contents.
Gas Surface Burners
Before Using the Gas Surface
Burners
Read all instructions before using.
WARNING
• Even if the top burner flame goes out, gas is still
flowing to the burner until the knob is turned to
the OFF position. If you smell gas, immediately
open a window and ventilate the area for five
minutes prior to using the burner. Do not leave
the burners on unattended.
• Use the proper pan size. Do not use pans that
are unstable or that can be easily tipped. Select
cookware with flat bottoms large enough to
cover burner grates. To avoid spillovers, make
sure the cookware is large enough to contain the
food properly. This will both save cleaning time
and prevent hazardous accumulations of food,
since heavy spattering or spillovers left on the
range can ignite. Use pans with handles that can
be easily grasped and remain cool.
CAUTION
• To avoid discoloration during use, follow the tips
in the Maintenance section.
• Do not operate the burner for an extended
period of time without cookware on the grate.
• The finish on the grate may chip without
cookware to absorb the heat.
• Touching grates before they cool down may
cause burns.
• What to do if you smell gas
- Open windows.
- Do not try to light any appliance.
- Do not touch any electrical switch.
- Do not use any phone in your building.
- Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
- If you cannot reach your gas supplier, call the
fire department.
• Be sure that all surface controls are set in the
OFF position prior to supplying gas to the range.
• Never leave the surface burners unattended at
high flame settings. Boilovers may cause smoke
and greasy spillovers that may ignite.
• Always turn the knobs to the Lite position when
igniting the top burners and make sure the
burners have ignited.
33OPERATION
ENGLISH
• Control the top burner flame size so it does not
extend beyond the edge of the cookware.
Excessive flame is hazardous.
• Only use dry pot holders- moist or damp pot
holders on hot surfaces may result in burns from
steam. Do not let pot holders come near open
flames when lifting cookware. Do not use towels
or other bulky cloth items. Use a pot holder.
• If using glass cookware, make sure the
cookware is designed for range-top cooking.
• To prevent burns from ignition of flammable
materials and spillage, turn cookware handles
toward the side or back of the range without
extending them over adjacent burners.
• Never leave any items on the cooktop. The hot
air from the vent may ignite flammable items
and will increase pressure in closed containers,
which may cause them to burst.
• Carefully watch foods being fried at a high flame
setting.
• Always heat fat slowly, and watch as it heats.
• If frying combinations of oils and fats, stir
together before heating.
• Use a deep fat thermometer if possible to
prevent overheating fat from heating beyond
the smoking point.
• Use the least possible amount of fat for effective
shallow or deep fat frying. Filling the pan with
too much fat can cause spillovers when food is
added.
• Do not cook foods directly on an open flame on
the cooktop.
• Do not use a wok on the surface burners if the
wok has a round metal ring that is placed over
the burner grate to support the wok. This ring
acts as a heat trap, which may damage the
burner grate and burner head. It may also cause
the burner to work improperly. This may cause
carbon monoxide levels which are higher than
what is allowed by current standards, resulting
in a health hazard.
• Foods for frying should be as dry as possible.
Frost or moisture on foods can cause hot fat to
bubble up and spill over the sides of the pan.
• Never try to move a pan of hot fat, especially a
deep fryer. Wait until the fat is cool.
• Do not place plastic items on the cooktop- they
may melt if left too close to the vent.
• Keep all plastics away from the surface burners.
• To prevent burns, always be sure that the
controls for all burners are in the OFF position
and all grates are cool before attempting to
remove them.
• If you smell gas, turn off the gas to the range
and call a qualified service technician. Never use
an open flame to locate a leak.
• Always turn the knobs to the OFF position before
removing cookware.
• Do not lift the cooktop. Lifting the cooktop can
cause damage and improper operation of the
range.
• If the range is located near a window, do not
hang long curtains that could blow over the
surface burners and catch on fire.
• Use care when cleaning the cooktop. The
pointed metal ends on the electrodes could
cause injury.
• Make sure that all burners are properly placed.
• Make sure that all grates are properly placed
before using the burner.
- Take care when installing or removing the
grates, as the rough edges may cause
scratches on the surface of the cooktop.
• Make sure the burners and grates are cool
before touching them, or placing a pot holder,
cleaning cloth, or other materials on them.
NOTE
• Electric spark igniters from the burners cause a
clicking noise. All the spark igniters on the
cooktop will activate when igniting just one
burner.
34 OPERATION
Burner Locations
Your gas range cooktop has four or five sealed gas
burners, depending on the model. These can be
assembled and separated. Follow the guide below.
a Medium and large burners
The medium and large burners are the primary
burners for most cooking. These general
purpose burners can be turned down from Hi
to Lo to suit a wide range of cooking needs.
b Small burner
The smallest burner is used for delicate foods
such as sauces or foods that require low heat
for a long cooking time.
c Dual burner
The dual burner is the maximum output
burner. Like the other four burners, it can be
turned down from Hi to Lo for a wide range of
cooking applications. This burner is also
designed to quickly bring large amounts of
liquid to a boil. It can be used with cookware 10
inches or larger in diameter.
d Oval burner
The center, oval burner is for use with a griddle
or oval pots.
Using the Gas Surface Burners
CAUTION
• Match the size of the cooktop burner or element
to the size of the cookware in use. Using a large
element for a small pan wastes heating energy,
and the exposed surface of the element is a burn
or fire hazard.
1 Be sure that all of the surface burners and
grates are placed in the correct positions.
2 Place cookware on the grate.
3 Push the control knob and turn to the LITE
position to light the burner.
NOTE
• The electric spark ignition system makes a
clicking noise.
4 Turn the control knob to control the flame
size.
CAUTION
• Do not attempt to disassemble or clean around
any burner while another burner is on. All the
burners spark when any burner is turned to
LITE. An electric shock may result causing you to
knock over hot cookware.
Setting the Flame Size
Watch the flame, not the knob, as you reduce heat.
Match the flame size on a gas burner to the
cookware being used for fastest heating.
CAUTION
• Never let the flames extend up the sides of the
cookware.
35OPERATION
ENGLISH
NOTE
• The flames on the surface burners may burn
yellow in the presence of high humidity, such as
a rainy day or a nearby humidifier.
• After LP gas conversion, flames can be bigger
than normal when you put a pot on the surface
burner.
Using the Proper Cookware
• Aluminum
- Medium-weight cookware is recommended
because it heats quickly and evenly. Most
foods brown evenly in an aluminum skillet.
Use saucepans with tight fitting lids when
cooking with minimum amounts of water.
• Cast-Iron
- If heated slowly, most skillets will give
satisfactory results.
• Stainless Steel
- This metal alone has poor heating properties
and is usually combined with copper,
aluminum or other metals for improved heat
distribution. Combination metal skillets work
satisfactorily if they are used with medium
heat as the manufacturer recommends.
•Enamelware
- Under some conditions, the enamel of this
cookware may melt. Follow cookware
manufacturer’s recommendations for cooking
methods.
•Glass
- There are two types of glass cookware, those
for oven use only and those for top-of-range
cooking.
• Heatproof Glass Ceramic
- Can be used for either surface or oven
cooking. It conducts heat very slowly and cools
very slowly. Check cookware manufacturer’s
directions to be sure it can be used on gas
ranges.
NOTE
• Match the size of the cookware to the amount of
food being cooked to save energy when heating.
Heating 1/2 quart of water requires more energy
in a 3-quart pot than in a 1-quart pot.
Using a Wok
If using a wok, use a 14-inch or smaller flat-
bottomed wok. Make sure that the wok bottom sits
flat on the grate.
CAUTION
• Do not use a wok support ring. Placing the ring
over the burner or grate may cause the burner
to work improperly, resulting in carbon
monoxide levels above allowable standards. This
can be hazardous to your health.
Using the Wok Grate
Use the included wok grate to support a 12" to 14"
round-bottomed wok.
CAUTION
• Turn off all burners and allow the wok grate,
burner grates, and cooktop to cool before
installing or removing the wok grate.
• The wok grate retains heat for a long time.
Always use an oven mitt when installing or
removing the wok grate. Do not store the wok
grate on the burner grate.
• Do not use flat-bottomed cookware or
incorrectly sized woks with the wok grate. The
cookware or wok could tip and cause personal
injury.
• Do not use a wok larger than 14" with the wok
grate. Doing so could cause burner flames to
spread excessively and damage the cooktop.
1 Turn off all burners and allow the grates and
cooktop to cool before installing or removing
the wok grate.
2 Remove the griddle, if necessary. Do not
remove the standard burner grates.
36 OPERATION
3 Place the wok grate on top of the left or right
front burner grate, aligning the notches on
the wok grate with the burner grate's fingers.
• Make sure the side marked FRONT is
toward the front.
a Front
NOTE
• Make sure the wok grate is stable and the wok
rests firmly on the wok grate.
• Do not use a wok that is the wrong size to fit
securely in the wok grate.
• The wok grate and griddle cannot be used at the
same time.
• For best performance, place the wok grate over
the extra large, right front burner.
• Do not use the wok grate with cookware other
than a wok.
• Clean the wok grate with hot, soapy water. Do
not use oven cleaners, steel wool, or abrasive
cleansers. Do not clean with the self-clean mode.
Using Stove-Top Grills
Do not place stove-top grills on the burner.
CAUTION
• Do not use stove top grills on the surface
burners. Using a stove top grill on the surface
burner will cause incomplete combustion and
can result in exposure to carbon monoxide
levels above allowable current standards. This
can be a health hazard.
Using the Griddle
The non-stick coated griddle provides an extra-
large cooking surface for meats, pancakes or other
food usually prepared in a frying pan or skillet.
CAUTION
• Avoid cooking extremely greasy foods as grease
spillover can occur.
• The griddle can become hot when surrounding
burners are in use.
• Do not overheat the griddle. This can damage
the non stick coating.
• Do not use metal utensils that can damage the
griddle surface. Do not use the griddle as a
cutting board.
• Do not place or store items on the griddle.
NOTE
• It is normal for the griddle to become discolored
over time.
How to Place the Griddle
The griddle can only be used with the center
burner. The griddle must be properly placed on
the center grate, as shown below.
CAUTION
• Do not remove the center grate when using the
griddle.
• Do not remove the griddle plate until the
cooktop grates, surfaces and griddle plate have
completely cooled.
• The griddle plate on the cooktop may become
very hot when using the cooktop, oven or broiler
systems. Always use oven mitts when placing or
removing the griddle plate.
a Front
Preheating Guide
Preheat the griddle according to the guide below
and adjust for the desired setting.
37OPERATION
ENGLISH
• Type of Food : Warming Tortillas
- Cook Setting: 5 (MED)
• Type of Food : Pancakes
- Preheat Conditions: HI 5 min.
- Cook Setting: HI
• Type of Food : Hamburgers
- Preheat Conditions: HI 5 min.
- Cook Setting: HI
• Type of Food : Fried Eggs
- Preheat Conditions: HI 5 min.
- Cook Setting: HI
• Type of Food : Bacon
- Preheat Conditions: HI 5 min.
- Cook Setting: HI
• Type of Food : Breakfast Sausage Links
- Preheat Conditions: HI 5 min.
- Cook Setting: HI
• Type of Food : Hot Sandwiches
- Preheat Conditions: HI 5 min.
- Cook Setting: HI
NOTE
• After cooking on the griddle for an extended
period, adjust the griddle temperature settings
as the griddle retains heat.
In Case of Power Failure
In case of a power failure, you can light the gas
surface burners on your range with a match.
Surface burners in use when an electrical power
failure occurs will continue to operate normally.
CAUTION
• Use extreme caution when lighting burners with
a match. It can cause burns and other damage.
1 Hold a lit match to the burner, then push in
the control knob.
2 Turn the control knob to the Lo position.
Oven
Before Using the Oven
Read all instructions before using.
CAUTION
• To avoid discoloration during use, follow the tips
in the Maintenance section.
• What to do if you smell gas
- Open windows.
- Do not try to light any appliance.
- Do not touch any electrical switch.
- Do not use any phone in your building.
- Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
- If you cannot reach your gas supplier, call the
fire department.
• Do not place plastic or flammable items on the
cooktop. They may melt or ignite if left too close
to the vent.
• Do not place closed containers on the cooktop.
The pressure in closed containers may increase,
which may cause them to burst.
• Metal items will become very hot if they are left
on the cooktop, and could cause burns.
• Handles of pots and pans on the cooktop may
become hot if left too close to the vent.
• Avoid opening the oven door more than
necessary during use. This helps the oven
maintain temperature, prevents unnecessary
heat loss, and saves on energy use.
• Make sure the electrical power cord and the gas
valve are properly connected.
• Confirm the correct usage of the range for the
type of food you will cook.
- Make sure you know how to use the oven
(temperature setting, time setting and recipe)
for best results.
NOTE
• If using an oven thermometer in the oven cavity,
temperatures may differ from the actual set
oven temperature with all modes.
• In case of power failure, do not use the oven.
38 OPERATION
CAUTION
• Do not attempt to operate the electric ignition
during an electrical power failure.
- The oven and broiler cannot be used during a
power outage. If the oven is in use when a
power failure occurs, the oven burner shuts off
and cannot be re-lit until power is restored.
Once power is restored, you will need to reset
the oven (or Broil function).
• Do not block, touch or place items around the
oven vent during cooking.
- Your oven is vented through ducts at the
center above the burner grate. Do not block
the oven vent when cooking to allow for
proper air flow. Do not touch vent openings or
nearby surfaces during any cooking operation.
• Do not cover racks or oven bottom with
aluminum foil.
• You may see condensation on the oven door
glass.
- As the oven heats up, the heated air in the
oven may cause condensation to appear on
the oven door glass. These water drops are
harmless and will evaporate as the oven
continues to heat up.
Oven Vent
Areas near the vent may become hot during
operation and may cause burns. Do not block the
vent opening. Avoid placing plastics near the vent
as heat may distort or melt the plastic.
It is normal for steam to be visible when cooking
foods with high moisture content.
a Oven Vent
b Vent trim
CAUTION
• The edges of the range vent are sharp. Wear
gloves when cleaning the range to avoid injury.
• Do not block, touch or place items around the
oven vent during cooking.
- Do not block the oven vent when cooking to
allow for proper air flow. Do not touch vent
openings or nearby surfaces during any
cooking operation.
Using Heavy Duty Oven Racks
The racks have a turned-up back edge that
prevents them from being pulled out of the oven
cavity.
CAUTION
• Reposition oven racks before turning the oven
on to prevent burns.
• Do not cover the racks with aluminum foil, or
any other material, or place anything on the
bottom of the oven. Doing so will result in poor
baking and may damage the oven bottom.
• Only arrange oven racks when the oven is cool.
• Do not place objects heavier than 33 lb (15 kg)
on the racks. Do not place heavy objects on the
corners of the racks. Doing so can damage the
racks.
Removing Racks
1 Pull the rack straight out until it stops.
2 Lift up the front of the rack and pull it out.
39OPERATION
ENGLISH
Replacing Racks
1 Place the end of the rack on the support.
2 Tilt the front end up and push the rack in.
Using Gliding Oven Racks
The gliding racks slide in and out on a frame. This
keeps heavy cookware level and prevents it from
sliding forward when the rack is completely
extended.
CAUTION
• Place oven racks in the desired location before
turning on the oven to avoid burns.
• Do not cover the racks with aluminum foil, or
any other material, or place anything on the
bottom of the oven. Doing so will result in poor
baking and may damage the oven bottom.
Installing Gliding Racks
1 Start with the rack in the closed position. Hold
the rack with one hand at the center front and
the other hand at the back right corner.
2 Carefully insert the rack between the rack
guides, and slide it back until the shelf drops
into place.
a Rack guides
3 Once the rack is secured in the back, pull the
entire rack forward until the rack locks into
place.
Removing Gliding Racks
1 With the rack in the closed position, grasp the
front of the rack and frame and lift up. Slowly
push the rack towards the back wall until it is
free of the rack stop.
2 After disengaging the rack stop, lift the back
of the rack and pull the rack and frame out
between the rack guides.
Meat Probe
The meat probe accurately measures the internal
temperature of meat, poultry and casseroles. It is
available on Bake, Convection Bake, Convection
Roast, Air Roast, or some menus of Auto Cook.
Always unplug and remove the meat probe from
the oven when removing food. Before using, insert
the probe into the center of the thickest part of the
meat or into the inner thigh or breast of poultry,
away from fat or bones. Place food in the oven and
connect the meat probe to the jack. Keep the
probe as far away from heat sources as possible.
Setting the Meat Probe Function
1 Insert the meat probe into the meat.
2 Connect the meat probe to the jack.
40 OPERATION
3 The meat probe icon flashes in the display if
the meat probe is properly connected.
Method
1 Select cook mode. Probe is available on Bake,
Convection Bake, Convection Roast and Air
Roast.
2 Tap "Temp." to set the desired cooking
temperature. Then tap
! to save the
settings.
3 Tap "Probe" to set the desired probe
temperature. Then tap
! to save the
settings.
4 Press the START button.
NOTE
• The default probe temperature is 150 °F (65 °C),
but can be changed to any temperature between
80 °F (27 °C) and 210 °F (100 °C). The display
shows the changing probe temperature. When
the set probe temperature is reached, the oven
shuts off automatically.
IMPORTANT NOTE
Press the STOP button to cancel the cooking with
the probe at any time. To avoid breaking the
probe, make sure food is completely defrosted
before inserting.
CAUTION
• Always use an oven mitt to remove the
temperature probe. Do not touch the broil
element. Failure to obey this caution can result
in severe personal injury.
• To avoid damage to the meat probe, do not use
tongs to pull on the probe when removing it.
• Do not store the meat probe in the oven.
• Do not pull the wire to remove the probe. Hold
the probe head, not the wire, when inserting or
removing the probe.
Bake
Bake is used to prepare foods such as pastries,
breads and casseroles.
The oven can be programmed to bake at any
temperature from 170
8 (80 7) to 550 8 (285 7).
The default temperature is 350 8 (175 7). The
meat probe can also be used with this mode.
Setting the Bake Mode
1 Press the POWER button.
2 Tap Manual Cook and scroll to select Bake.
3 Tap 3 or drag the option card to set the cook
options.
4 Tap Temperature set the desired cook
temperature by tapping the +/- button,
tapping the bar, or dragging the bar. You can
also use the number pad icon to set the cook
temperature directly.
5 If desired, tap Cook Time or Start at to set
the cook time or cooking start time.
You can also use the number pad icon to set
the cooking temperature directly.
6 Tap When Finished to add a function after
cooking is complete.
• Keep Warm : Keeps the food warm after
cooking is complete.
• Stay On : Continues the previously selected
cooking mode after cooking is complete.
• Turn Off : Turns off automatically when
cooking is complete, without any additional
functions operating.
7 When you have selected the desired cook
settings, tap Start at the bottom right to
begin cooking.
8 A chime sounds once preheating is complete.
9 A chime sounds at the end of the set cook
time and a notification appears in the display.
41OPERATION
ENGLISH
10 Tap Done to complete cooking. If needed, you
can tap + Cook Time to continue cooking, or
tap Keep Warm to maintain the food at
serving temperature.
Changing the Cook Settings
1 Tap 3 at the middle right of the screen.
2 Tap option you want to change to make
adjustments.
3 Tap Apply at the bottom right to apply the
modified settings to your recipe.
4 Tap 4 to return to the previous screen without
making changes.
To Stop Cooking
1 Tap Stop at the button right of the screen.
2 A pop-up notification appears on the display.
Tap Stop.
Baking Pans
• When baking in Bake modes, use baking pans
with a dark metal or coated surface.
• When baking with Convection Bake, you can
also use baking pans with a bright metal surface.
• Always place cake pans in the middle of the tray
or oven rack.
• When baking with Bake, you can place two
baking pans side by side in the oven for a baking
time that is only slightly longer.
NOTE
• If no cook time is set, the oven turns off
automatically after 12 hours.
Tips for Baking
Convection Bake and Roast
The convection system uses a fan to circulate the
heat evenly within the oven. Improved heat
Results of Baking Possible Cause Solution
The cake base is too light Wrong oven rack position
Use a dark baking tin or put the
cake one rack lower down.
Cake collapses (turns lumpy,
soggy)
Oven temperature too high Set the temperature slightly lower.
Baking time too short
Set a longer baking time. The
baking time cannot be reduced by
setting a higher temperature.
Mixture contains too much liquid
Use less liquid. Follow instructions
for dough mixing times, especially
when using kitchen appliances.
Cakes are too dry
Oven temperature too low
Next time set a slightly higher
temperature.
Baking time too long Set a slightly shorter baking time.
Cakes are browned unevenly
Baking temperature too high and
baking time too short
Set a slightly lower baking
temperature and a slightly longer
baking time.
Mixture unevenly distributed
Distribute the mixture evenly over
the baking tray/tin.
Baking time too long Temperature too low
Next time set a slightly higher
temperature.
42 OPERATION
distribution allows for even cooking and excellent
results while cooking with single or multiple racks.
The Convection Roast feature is designed to give
optimum roasting performance. Convection Roast
combines cooking with the convection fan to roast
meats and poultry. The heated air circulates
around the food from all sides, sealing in juices
and flavors. Foods are crispy brown on the outside
while staying moist on the inside. Convection
roasting is especially good for large tender cuts of
meat, uncovered.
Setting the Convection Bake and Roast
Mode
1 Press the POWER button.
2 Tap Manual Cook and scroll to select
Convection Bake or Convection Roast.
3 Tap 3 or drag the option card to set the cook
options.
4 Tap Temperature to set the desired cooking
temperature by tapping the +/- button,
tapping the bar, or dragging the bar.
You can also use the number pad icon to set
the cooking temperature directly.
5 If desired, tap Cook Time or Start at to set
the cook time or cooking start time.
You can also use the number pad icon to set
the cooking time directly.
6 Tap When Finished to add a function after
cooking is complete.
• Keep Warm : Keeps the food warm after
cooking is complete.
• Stay On : Continues the previously selected
cooking mode after cooking is complete.
• Turn Off : Turns off automatically when
cooking is complete, without any additional
functions operating.
7 When you have selected the desired cook
settings, tap Start at the bottom right to
begin cooking.
8 A chime sounds once preheating is complete.
9 A chime sounds at the end of the set cook
time and a notification appears in the display.
10 Tap Done to complete cooking. If needed, you
can tap + Cook Time to continue cooking, or
tap Keep Warm to maintain the food at
serving temperature.
NOTE
• If no cook time is set, the oven turns off
automatically after 12 hours.
• The heating elements and fan turn off if the door
is opened. They turn on again after the door is
closed.
• The oven fan runs while convection baking and
convection roasting. The fan stops when the
door is opened. In some cases, the fan may shut
off during a convection bake cycle.
Changing the Cook Settings
1 Tap 3 at the middle right of the screen.
2 Tap option you want to change to make
adjustments.
3 Tap Apply at the bottom right to apply the
modified settings to your recipe.
4 Tap 4 to return to the previous screen without
making changes.
To Stop Cooking
1 Tap Stop at the bottom right the of screen.
2 A pop-up notification appears on the display.
Tap Stop.
Tips for Convection Baking
• Use Convection Bake for faster and more even
multiple-rack cooking of pastries, cookies,
muffins, biscuits, and breads of all kinds.
• Bake cookies and biscuits on pans with no sides
or very low sides to allow heated air to circulate
43OPERATION
ENGLISH
around the food. Food baked on pans with a
dark finish will cook faster.
• When using Convection Bake, place the oven
racks in positions suggested in the charts in this
manual.
• Multiple oven rack cooking may slightly increase
cook times for some foods.
Tips for Convection Roasting
The Convection Roast feature is designed to give
optimum roasting performance. Convection Roast
combines cooking with the convection fan to roast
meats and poultry. The heated air circulates
around the food from all sides, sealing in juices
and flavors. Foods are crispy brown on the outside
while staying moist on the inside. Convection
roasting is especially good for large tender cuts of
meat, uncovered.
Use a broiler pan and grid when preparing meats
for convection roasting. The broiler pan catches
grease spills and the grid helps prevent grease
splatters.
1 Place the oven rack in the recommended
position.
2 Place the grid in the broiler pan.
3 Place the broiler pan on the oven rack.
a Grid
b Broiler Pan
CAUTION
• Do not cover the roasting rack with aluminum
foil.
• Position food (fat side up) on the roasting rack.
• Pressing the POWER button during cooking
clears all settings.
Recommended Baking and
Roasting Guide
Baking results will be better if baking pans are
centered in the oven as much as possible. If
cooking on multiple racks, place the oven racks in
the positions shown.
Multiple-rack cooking saves time and energy.
Whenever possible, cook foods requiring the same
cooking temperature together in one oven.
Rack and Pan Placement
Baking Rack Guide
Multiple rack baking
Offset rack (Position 4)
Heavy duty rack
(Position 1)
Single rack baking
Heavy duty rack
Food
Rack
position
Cakes
Layer cakes
Bundt cakes
Angel food cake
2
3
3
Cookies
Sugar cookies
Chocolate chips
Brownies
3
3
3
Pizza
Fresh
Frozen
4
4
44 OPERATION
Roasting Rack Guide
Broil
The Broil function uses intense heat from the
upper heating element to cook food. Broiling
works best for tender cuts of meat, fish, and thinly
cut vegetables.
Some models may feature a hybrid broiler
consisting of an inner broiler that utilizes a carbon
heating element which provides instantaneous
heat, and a traditional outer broiling element.
During normal broiler operation, it is normal for
either element to cycle off intermittently.
CAUTION
• Do not cover the oven rack with aluminum foil.
Doing so will cause a fire.
• Should an oven fire occur, leave the oven door
closed and turn the oven off. If the fire
continues, throw baking soda on the fire or use a
fire extinguisher.
• DO NOT put water or flour on the fire. Flour may
be explosive and water can cause a grease fire to
spread and cause personal injury.
• When using your broiler, the temperature inside
the oven will be extremely high. Take care to
avoid possible burns by:
- Keeping the door closed when broiling
- Always wearing oven mitts when inserting or
removing food items
NOTE
• This appliance is designed for closed-door
broiling. Close the door to set the Broil function.
If the door is open, the Broil function cannot be
set and Close the door to start cooking
appears on the display. Close the door and reset
the Broil function. If the door is opened during
broiling, the broil burner turns off after five
seconds. The broiler turns back on automatically
once the door is closed.
Setting the Broil Mode
1 Press the POWER button.
2 Tap Manual Cook and scroll to select Broil.
3 Tap 3 or drag the option card to set the cook
options.
4 Tap Temperature and select the desired cook
temperature : Low, or High.
5 If desired, tap Cook Time or Start at to set
the cook time or cooking start time.
You can also use the number pad icon to set
the cooking time directly.
Pastry
Crust
From scratch
Refrigerated
4
4
Breads
Biscuit, canned
Biscuit, from scratch
Muffins
5
5
4
Desserts
Fruit crisps and
cobblers, from scratch
Pies, from scratch, 2-
crust fruit
3
3
Custards
Cheesecake, crème
brulée
2
Soufflés Sweet or savory 2
Casserole Frozen lasagna 5
Food
Rack
position
Beef
Rib
Rare
Medium
Well done
2
2
2
Boneless
rib, top
sirloin
Rare
Medium
Well done
2
2
2
Beef
tenderloin
Rare
Medium
2
2
Pork
Rib 2
Bone-in, sirloin 2
Ham, cooked 2
Poultry
Whole chicken 3
Chicken pieces 3
Turkey 3
Food
Rack
position
45OPERATION
ENGLISH
6 Tap When Finished to add a function after
cooking is complete.
• Keep Warm : Keeps the food warm after
cooking is complete.
• Turn Off : Turns off automatically when
cooking is complete, without any additional
functions operating.
7 When you have selected the desired cook
settings, tap Start at the bottom right to
begin cooking.
8 A chime sounds at the end of the set cook
time and a notification appears in the display.
9 Tap Done to complete cooking. If needed, you
can tap + Cook Time to continue cooking, or
tap Keep Warm to maintain the food at
serving temperature.
NOTE
• If the cook time is not set, the oven automatically
turns off after 3 hours.
• The heating elements and fan turn off if the door
is opened. They turn on again after the door is
closed.
Changing the Cook Settings
1 Tap 3 at the middle right of the screen.
2 Tap option you want to change to make
adjustments.
3 Tap Apply at the bottom right to apply the
modified settings to your recipe.
4 Tap 4 to return to the previous screen without
making changes.
To Stop Cooking
1 Tap Stop at the bottom right the of screen.
2 A pop-up notification appears on the display.
Tap Stop.
Tips for Reducing Smoke
Due to the intense heat associated with broiling, it
is normal to experience smoke during the cooking
process. This smoke is a natural byproduct of
searing and should not cause you to worry. If you
are experiencing more smoke than you are
comfortable with, use the following tips to reduce
the amount of smoke in your oven.
• Always use a broiler pan. Do not use saute pans
or regular baking sheets for safety reasons.
• The broiler pan should always be thoroughly
cleaned and at room temperature at the
beginning of cooking.
• Always run your cooktop ventilation system or
vent hood during broiling.
• Keep the interior of your oven as clean as
possible. Leftover debris from prior meals can
burn or catch fire.
• Avoid fatty marinades and sugary glazes. Both of
these will increase the amount of smoke you
experience. If you would like to use a glaze,
apply it at the very end of cooking.
• If you are experiencing significant smoke with
any food item, consider:
- Lowering the broiler to the Low setting.
- Lowering the rack position to cook the food
farther away from the broiler.
- Using the High broil setting to achieve the
level of searing you desire, and then either
switching to the Low broil setting, or switching
to the Medium broil setting.
• As a rule, fattier cuts of meat and fish will
produce more smoke than leaner items.
• Adhere to the guidelines in the Recommended
Broiling Guide section whenever possible.
46 OPERATION
Recommended Broiling Guide
The size, weight, thickness, starting temperature, and your preference of doneness will affect broiling
times.
This guide is based on meats at refrigerator temperature. For best results when broiling, use a pan
designed for broiling.
a Grid (sold separately)
b Broiler pan (sold separately)
* : This feature is for the offset rack use.
Food
Quantity and/or
Thickness
Rack
Position
First
Side
(min.)
Second
Side
(min.)
Comments
Hamburgers
9 patties
1
/
2
to
3
/
4
" thick
7* 6-7 4-5
Space evenly. Up to 9
patties may be broiled
at once.
Beef Steaks
1" thick
1 to 1
1
/
2
lbs.
Rare 6 (7*) 7 5
Steaks less than 1"
thick cook through
before browning. Pan
frying is
recommended. Slash
fat.
Medium 6 (7*) 12 5-6
Well done 6 (7*) 13 8-9
1
1
/
2
" thick
2 to 2
1
/
2
lbs.
Rare 4 (5*) 10 6-7
Medium 4 (5*) 12-15 10-12
Well done 4 (5*) 25 16-18
Toast 1 to 9 pieces 5 (6*) 1-2 1-2
Chicken
1 whole, 2 to 2
1
/
2
lbs., split
lengthwise
2 (3*) 35-40 25
Broil skin-side-down
first.
2 Breasts 2 (3*) 25-30 10-15
Lobster Tails
2–4
6 to 8 oz. each
3 (4*) 13-16
Do not
turn over
Cut through back of
shell. Spread open.
Brush with melted
butter before broiling
and after half of
broiling time.
Fish Fillets
1
/
4
to
1
/
2
" thick
5 (6*) 7-8 6
Ham Slices
(precooked)
1" thick 3 (4*) 10 5
1
/
2
" thick
4 (5*) 7 4
Pork Chops
Well done
2 (
1
/
2
" thick)
4 (5*) 10 8
2 (1" thick) about 1lb. 4 (5*) 13 8-9
47OPERATION
ENGLISH
• This guide is only for reference. Adjust cook time according to your preference.
• Do not use the gliding rack in position 7.
NOTE
• The USDA advises that consuming raw or undercooked fish, meat, or poultry can increase your risk of
food-borne illness.
• The USDA has indicated the following as safe minimum internal temperatures for consumption:
- Ground beef: 160 °F (71.1 °C)
- Poultry: 165 °F (73.9 °C)
- Beef, veal, pork, or lamb: 145 °F (62.8 °C)
- Fish / Seafood: 145 °F (62.8 °C)
Tips for Broiling
• Beef
- Steaks and chops should always be allowed to rest for five minutes before being cut into and eaten.
This allows the heat to distribute evenly through the food and creates a more tender and juicy result.
- Pieces of meat that are thicker than two inches should be removed from the refrigerator 30 minutes
prior to cooking. This will help them cook more quickly and evenly, and will produce less smoke when
broiling. Cooking times will likely be shorter than the times indicated in the Broiling Chart.
- For bone-in steaks or chops that have been frenched (all meat removed from around the bone), wrap
the exposed sections of bone in foil to reduce burning.
• Seafood
- When broiling skin-on fish, always use the Lo broil setting and always broil the skin side last.
- Seafood is best consumed immediately after cooking. Allowing seafood to rest after cooking can cause
the food to dry out.
- It is a good idea to rub a thin coating of oil on the surface of the broiling pan before cooking to reduce
sticking, especially with fish and seafood. You can also use a light coating of non-stick pan spray.
• Vegetables
- Toss your vegetables lightly in oil before cooking to improve browning.
Air Fry
The Air Fry function is specially designed for oil-
free frying.
The Air Fry mode can be programmed to cook at
any temperature from 300
8 (150 7) to 550 8
(285 7). The default temperature is 400 8 (205
7).
Temperatures can reach up to 50 8 (10 7) above
the set temperature for optimal crisping
performance.
Lamb Chops
2 (1" thick)
about 10 to 12
oz.
Medium 5 (6*) 6 4-7
Well done
5 (6*) 10 10
2 (1
1
/
2
" thick)
about 1lb.
Medium 5 (6*) 10 4-6
Well done 5 (6*) 17 12-14
Bacon 1/2 lb. (about 8 thin slices) 4 (5*) 8 3
Food
Quantity and/or
Thickness
Rack
Position
First
Side
(min.)
Second
Side
(min.)
Comments
48 OPERATION
Setting the Air Fry Mode
1 Press the POWER button.
2 Tap Manual Cook and scroll to select Air Fry.
3 Tap 3 or drag the option card to set the cook
options. Tap Temperature and set the
desired cook temperature by tapping the +/-
button, tapping the bar, or dragging the bar.
You can also use the number pad icon to set
the cooking temperature directly.
4 If desired, tap Cook Time or Start at to set
the cook time or cooking start time.
You can also use the number pad icon to set
the cooking time directly.
5 Tap When Finished to add a function after
cooking is complete.
• Keep Warm : Keeps the food warm after
cooking is complete.
• Stay On : Continues the previously selected
cooking mode after cooking is complete.
• Turn Off : Turns off automatically when
cooking is complete, without any additional
functions operating.
6 When you have selected the desired cook
settings, tap Start at the bottom right to
begin cooking.
7 A chime sounds at the end of the set cook
time and a notification appears in the display.
8 Tap Done to complete cooking. If needed, you
can tap + Cook Time to continue cooking, or
tap Keep Warm to maintain the food at
serving temperature.
Changing the Cook Settings
1 Tap 3 at the middle right of the screen.
2 Tap option you want to change to make
adjustments.
3 Tap Apply at the bottom right to apply the
modified settings to your recipe.
4 Tap 4 to return to the previous screen without
making changes.
To Stop Cooking
1 Tap Stop at the bottom right the of screen.
2 A pop-up notification appears on the display.
Tap Stop.
NOTE
• No preheating is required when using the Air Fry
mode.
• If cooking multiple batches, the later batches
may take less time to cook.
• Wet batters and coatings will not crisp or set
when using the Air Fry mode.
Tips for Air Fry
• For best results, use the provided air fry tray.
- The mesh section of the air fry tray can be
cleaned in a dishwasher.
a Air Fry Tray
b Heavy Duty Rack
• If you don't have the air fry tray, place food on a
wire rack inside a foil-lined broiler pan.
a Broiler Pan
• For best results, cook food on a single rack
placed in the positions suggested in the chart in
this manual.
• Spread the food out evenly in a single layer.
• Use either the air fry tray or a dark baking tray
with no sides or short sides that does not cover
49OPERATION
ENGLISH
the entire rack. This allows for better air
circulation.
• If desired, spray the baking tray or air fry tray
with a pan spray. Use an oil that can be heated to
a high temperature before smoking, such as
avocado, grapeseed, peanut or sunflower oil.
• Place a foil-lined baking tray on a rack in position
1 to catch the oil falling from the food. For high-
fat foods like chicken wings, add a few sheets of
parchment paper to absorb the fat.
• Check food often and shake it or turn it over for
crisper results.
• Prepared frozen foods may cook faster with the
Air Fry mode than stated on the package.
Reduce the cooking time by about 20 percent,
check food early, and adjust cooking time as
needed.
• Use a food thermometer to make sure food has
reached a safe temperature for consumption.
Eating undercooked meats can increase your
risk of food-borne illness.
• For the crispiest results, dredge fresh chicken
wings or tenders in seasoned flour. Use 1/3 cup
flour for 2 pounds of chicken.
Recommendations When Air Frying
High-Fat Foods
Foods high in fat will smoke when using the Air Fry
mode. For best results, follow these
recommendations when air frying foods that are
high in fat, such as chicken wings, bacon, sausage,
hot dogs, turkey legs, lamb chops, ribs, pork loin,
duck breasts, or some plant-based proteins.
CAUTION
• Never cover slots, holes, or passages in the oven
bottom or cover entire racks with materials such
as aluminum foil. Doing so blocks airflow
through the oven and can result in carbon
monoxide poisoning. Aluminum foil can also
trap heat, causing a fire hazard or poor oven
performance.
• Turn on your exhaust hood at a high fan setting
before you start Air Fry and leave it on for 15
minutes after you're done.
• Open a window or sliding glass door, if possible,
to make sure the kitchen is well-ventilated.
• Keep the oven free from grease buildup. Wipe
down the interior of the oven before and after
air frying (once the oven has cooled).
• Run oven cleaning cycles (EasyClean) regularly,
depending on how often and what types of food
you Air Fry.
• Avoid opening the oven door more than
necessary to help maintain the oven
temperature, prevent heat loss, and save
energy.
• Air-frying fresh chicken pieces such as wings or
drumsticks with the skin left on can produce
smoke as the fat renders at high temperatures.
If the smoke is excessive, use the Convection
Roast mode instead of Air Fry.
Recommended Air Frying Guide
• Arrange food evenly in a single layer.
• Put a foil-lined baking pan on a rack in position 1 to catch drips. If needed, add parchment paper to
absorb oil and reduce smoking.
• Flip food over during cooking to avoid burning it.
† High-fat items may produce more smoke when cooked using Air Fry. For less smoke, cook using
Convection Roast mode.
Recommended Items
Quantity
(oz)
Temp. (°F)
Rack
Position
Time Guide
POTATOES-Frozen
Frozen French Fries
(Shoestring)
20 425 3 15-25
Frozen French Fries
(Crinkle cut, 3/8" or 10
mm)
35 425 3 15-25
50 OPERATION
Frozen Sweet Potato
Fries
25 425 3 15-30
Frozen Tater Tots 50 450 3 20-30
Frozen Hash Browns 40 450 3 25-35
POTATOES-Fresh/Homemade
Homemade French Fries
(3/8" x 3/8" or 10 x 10
mm)
25 450 3 25-35 Cut the potatoes and soak
for 30 minutes in hot tap
water. Drain and pat dry.
Brush or lightly spray with
3 tbsp. of oil. Add salt and
pepper to taste.
Homemade Potato
Wedges
60 450 3 35-45
CHICKEN-Frozen
Frozen Chicken Nuggets,
Crispy
30 400 3 15-25
Frozen Chicken Strips 35 425 3 25-35
Frozen Hot Wings, Bone-
in
50 425 3 25-35
CHICKEN-Fresh, Skin on
Fresh Chicken Wings
†
40 450 3 25-35 Brush or lightly spray with
1 tbsp. of oil. Add salt and
pepper to taste.
Fresh Chicken
Drumsticks
†
70 450 3 30-40
Thighs 40 450 3 30-35
Breasts 40 450 3 30-35
OTHER
Frozen Onion Rings,
Breaded
20 400 3 20-30
Frozen Spring Rolls (0.7
oz. each)
45 425 3 25-35
Thin Sausage
†
(2.5 oz.
each, diameter 0.8")
90 400 3 25-35
Frozen Coconut Shrimp 25 425 3 20-30 Brush or lightly spray the
surface of food with oil.
Fresh Scallops on the half
shell (35 oz.)
35 425 3 20-30 Melt 4 tbsp. of butter and
brush on scallops. Mix 1/2
cup bread crumbs, 1 tbsp.
minced garlic, 1/4 cup
grated parmesan cheese
and season to taste.
Sprinkle mixture over
scallops.
Fresh Shrimp 50 425 3 20-30
Recommended Items
Quantity
(oz)
Temp. (°F)
Rack
Position
Time Guide
51OPERATION
ENGLISH
Air Sous-Vide
This feature is only available on some models.
Air Sous-Vide cooking uses air to cook foods "low
and slow." Use it to cook meat, fish, seafood,
poultry or vegetables. Food must be vacuum
packed in pouches. It is not necessary to preheat
the oven when using Air Sous-Vide. Refer to the
cooking guide for recommended Air Sous-Vide
settings.
Benefits of Air Sous-Vide
The lower temperatures and long cooking times
used in Air Sous-Vide cooking provide many
benefits.
• Healthier
Compared to other cooking methods, sous vide
retains most of the original nutrients in food.
• Safe and Convenient
The long cooking times used in sous vide
cooking allow food to be pasteurized. Because
food is vacuum packed before cooking, the
unopened pouches can be quickly chilled then
easily stored after cooking.
• Crisp and Moist Results
The fine temperature control of sous vide
cooking is an excellent way to achieve the
perfect texture when cooking meat and poultry.
The low temperatures used retain more of the
moisture in food than conventional cooking
methods. After cooking, a final sear in a frying
pan adds the perfect crisp finish.
Setting Air Sous-Vide Mode
1 Press the POWER button.
2 Tap Manual Cook and scroll to select Air
Sous-Vide.
3 Tap 3 or drag the option card to set the cook
options. Tap Temperature and set the
desired cook temperature by tapping the +/-
button, tapping the bar, or dragging the bar.
You can also use the number pad icon to set
the cook temperature directly.
4 If desired, tap Cook Time or Start at to set
the cook time or cooking start time.
You can also use the number pad icon to set
the cooking time directly.
5 Tap When Finished to add a function after
cooking is complete.
• Stay On : Continues the previously selected
cooking mode after cooking is complete.
• Turn Off : Turns off automatically when
cooking is complete, without any additional
functions operating.
6 When you have selected the desired cook
settings, tap Start at the bottom right to
begin cooking.
7 A chime sounds at the end of the set cook
time and a notification appears in the display.
8 Tap Done to complete cooking. If needed, you
can tap + Cook Time to continue cooking.
Changing the Cook Settings
1 Tap "Temp." or "Time" to bring up the Cook
Settings screen.
2 Adjust the settings using the number pad or
scroll function.
3 Press the START button on the control panel.
Mixed Vegetables 35 425 3 20-30 Brush or lightly spray with
4 tbsp. of olive oil. Add salt
and pepper to taste.
Recommended Items
Quantity
(oz)
Temp. (°F)
Rack
Position
Time Guide
52 OPERATION
To Stop Cooking
Press the STOP button on the control panel.
Recommended Air Sous-Vide Guide
Air Roast
Air Roast is a quick and convenient way to roast
without preheating.
The Air Roast mode can be programmed to cook at
any temperature from 300
8 (150 7) to 550 8
(285
7). The default temperature is 400 8 (205
7). The meat probe can also be used with this
mode.
Setting the Air Roast Mode
1 Press the POWER button.
2 Tap Manual Cook and scroll to select Air
Roast.
3 Tap 3 or drag the option card to set the cook
options. Tap Temperature and set the
desired cook temperature by tapping the +/-
button, tapping the bar, or dragging the bar.
You can also use the number pad icon to set
the cook temperature directly.
4 If desired, tap Cook Time or Start at to set
the cook time or cooking start time.
You can also use the number pad icon to set
the cook time directly.
5 Tap When Finished to add a function after
cooking is complete.
• Keep Warm : Keeps the food warm after
cooking is complete.
• Stay On : Continues the previously selected
cooking mode after cooking is complete.
• Turn Off : Turns off automatically when
cooking is complete, without any additional
functions operating.
6 When you have selected the desired cook
settings, tap Start at the bottom right to
begin cooking.
7 A chime sounds at the end of the set cook
time and a notification appears in the display.
Food Quantity
Rack
Position
Temp.
(°F)
Time
Min. Target Max.
Beef Steaks
1” thick
14 - 17 oz.
1 135 - 2.5 hr. 3 hr.
Chicken
Breasts 4 - 6 oz. 1 150 - 2 hr. 3 hr.
Thighs
(bone-in)
6 - 8 oz. - 155 - 4 hr. 6 hr.
Salmon
1” thick
5 - 7 oz.
1 130 - 2 hr. 2.5 hr.
Vegetables
Asparagus
2.8 oz. / 6 ea
5.6 oz. / 12 ea
1 185 20 min. 30 min. 45 min.
Potatoes
1/2" diced
up to 36 oz.
1 200 - 2 hr. -
Carrots
1/2" diced
up to 18 oz.
1 200 1.5 hr. 2 hr. 3 hr.
53OPERATION
ENGLISH
8 Tap Done to complete cooking. If needed, you
can tap + Cook Time to continue cooking, or
tap Keep Warm to maintain the food at
serving temperature.
Changing the Cook Settings
1 Tap 3 at the middle right of the screen.
2 Tap option you want to change to make
adjustments.
3 Tap Apply at the bottom right to apply the
modified settings to your recipe.
4 Tap 4 to return to the previous screen without
making changes.
To Stop Cooking
1 Tap Stop at the bottom right the of screen.
2 A pop-up notification appears on the display.
Tap Stop.
Pizza
This system is designed to give the optimum
cooking performance for pizza by automatically
selecting a combination of the broil and bake
heating systems.
Setting the Pizza Mode
1 Press the POWER button.
2 Tap Manual Cook and scroll to select Pizza.
3 Tap 3 or drag the option card to set the cook
options.
4 Tap Temperature and set the desired cook
temperature by tapping the +/- button,
tapping the bar, or dragging the bar.
You can also use the number pad icon to set
the cook temperature directly.
5 If desired, tap Cook Time or Start at to set
the cook time or cooking start time.
You can also use the number pad icon to set
the cook time directly.
6 Tap When Finished to add a function after
cooking is complete.
• Keep Warm : Keeps the food warm after
cooking is complete.
• Stay On : Continues the previously selected
cooking mode after cooking is complete.
• Turn Off : Turns off automatically when
cooking is complete, without any additional
functions operating.
7 When you have selected the desired cook
settings, tap Start at the bottom right to
begin cooking.
8 A chime sounds once preheating is complete.
9 A chime sounds at the end of the set cook
time and a notification appears in the display.
10 Tap Done to complete cooking. If needed, you
can tap + Cook Time to continue cooking, or
tap Keep Warm to maintain the food at
serving temperature.
NOTE
• Preheating is necessary for better cooking
results.
• Place the food in the oven after preheating.
• Rotate frozen pizzas halfway through cooking.
Extend the cooking time as needed to meet the
desired level of doneness.
Changing the Cook Settings
1 Tap 3 at the middle right of the screen.
2 Tap option you want to change to make
adjustments.
3 Tap Apply at the bottom right to apply the
modified settings to your recipe.
54 OPERATION
4 Tap > to return to the previous screen without
making changes.
To Stop Cooking
1 Tap Stop at the bottom right the of screen.
2 A pop-up notification appears on the display.
Tap Stop.
Frozen Meal
The Frozen Meal function is specially designed for
cooking frozen prepared meals.
No preheating is required when using the Frozen
Meal mode.
Setting the Frozen Meal Mode
1 Press the POWER button.
2 Tap Manual Cook scroll to select Frozen
Meal.
3 Tap 3 or drag the option card to set the cook
options. Tap Temperature and set the
desired cook temperature by tapping the +/-
button, tapping the bar, or dragging the bar.
You can also use the number pad icon to set
the cook temperature directly.
4 If desired, tap Cook Time or Start at to set
the cook time or cooking start time.
You can also use the number pad icon to set
the cook time directly.
5 Tap When Finished to add a function after
cooking is complete.
• Keep Warm : Keeps the food warm after
cooking is complete.
• Stay On : Continues the previously selected
cooking mode after cooking is complete.
• Turn Off : Turns off automatically when
cooking is complete, without any additional
functions operating.
6 When you have selected the desired cook
settings, tap Start at the bottom right to
begin cooking.
7 A chime sounds at the end of the set cook
time and a notification appears in the display.
8 Tap Done to complete cooking. If needed, you
can tap + Cook Time to continue cooking, or
tap Keep Warm to maintain the food at
serving temperature.
Changing the Cook Settings
1 Tap 3 at the middle right of the screen.
2 Tap option you want to change to make
adjustments.
3 Tap Apply at the bottom right to apply the
modified settings to your recipe.
4 Tap 4 to apply the modified settings to your
recipe.
To Stop Cooking
1 Tap Stop at the bottom right the of screen.
2 A pop-up notification appears on the display.
Tap Stop.
Dehydrate
Use this function to dry fruit, vegetables, and beef
to create healthy and nutritious snacks without
using chemicals and preservatives. Place
parchment paper on the metal tray and spread the
food in a single layer. Dehydrate temperatures
range from 100 ℉ to 200 ℉.
Setting the Dehydrate Mode
1 Press the POWER button.
2 Tap Manual Cook scroll to select Dehydrate.
55OPERATION
ENGLISH
3 Tap <3 or drag the option card to set the cook
options. Tap Temperature and set the
desired cook temperature by tapping the +/-
button, tapping the bar, or dragging the bar.
You can also use the number pad icon to set
the cook temperature directly.
4 If desired, tap Cook Time or Start at to set
the cook time or cooking start time.
You can also use the number pad icon to set
the cook time directly.
5 Tap When Finished to add a function after
cooking is complete.
• Stay On : Continues the previously selected
cooking mode after cooking is complete.
• Turn Off : Turns off automatically when
cooking is complete, without any additional
functions operating.
6 When you have selected the desired cook
settings, tap Start at the bottom right to
begin cooking.
7 A chime sounds at the end of the set cook
time and a notification appears in the display.
8 Tap Done to complete cooking. If needed, you
can tap + Cook Time to continue cooking.
Changing the Dehydrate Settings
1 Tap 3 at the middle right of the screen.
2 Tap option you want to change to make
adjustments.
3 Tap Apply at the bottom right to apply the
modified settings to your recipe.
4 Tap 4 to return to the previous screen without
making changes.
To Stop Dehydrate
1 Tap Stop at the bottom right the of screen.
2 A pop-up notification appears on the display.
Tap Stop.
Warm
This function will maintain an oven temperature of
less than 200
8 (93 7). It will keep cooked food
warm for serving up to 3 hours after cooking has
finished.
Setting the Warm Mode
1 Press the POWER button.
2 Tap Manual Cook scroll to select Warm.
3 Select the desired temperature: Low,
Medium, or High.
4 If desired, tap Cook Time or Start at to set
the cook time or cooking start time.You can
also use the number pad icon to set the
cooking time directly.
5 Tap When Finished to add a function after
cooking is complete.
• Keep Warm : Keeps the food warm after
cooking is complete.
• Stay On : Continues the previously selected
cooking mode after cooking is complete.
6 When you have selected the desired cook
settings, tap Start at the bottom right to
begin cooking.
7 Tap Done to complete cooking. If needed, you
can tap + Cook Time to continue cooking.
Changing the Warm Settings
1 Tap 3 at the middle right of the screen.
2 Tap option you want to change to make
adjustments.
56 OPERATION
3 Tap Apply at the bottom right to apply the
modified settings to your recipe.
4 Tap 4 to return to the previous screen without
making changes.
To Stop Warming
1 Tap Stop at the bottom right the of screen.
2 A pop-up notification appears on the display.
Tap Stop.
NOTE
• The Warm function is intended to keep food
warm. Do not use it to cool food down.
Proof
This feature maintains a warm oven for rising
yeast-leavened products before baking.
Setting the Proof Mode
1 Press the POWER button.
2 Tap Manual Cook scroll to select Proof.
3 If desired, tap Cook Time or Start at to set
the cook time or cooking start time.You can
also use the number pad icon to set the
cooking time directly.
4 Tap When Finished to add a function after
cooking is complete.
• Keep Warm : Keeps the food warm after
cooking is complete.
• Stay On : Continues the previously selected
cooking mode after cooking is complete.
5 When you have selected the desired cook
settings, tap Start at the bottom right to
begin cooking.
6 Tap Done to complete cooking. If needed, you
can tap + Cook Time to continue cooking.
Changing the Proof Settings
1 Tap 3 at the middle right of the screen.
2 Tap option you want to change to make
adjustments.
3 Tap Apply at the bottom right to apply the
modified settings to your recipe.
4 Tap 4 to return to the previous screen without
making changes.
To Stop Proofing
1 Tap Stop at the bottom right the of screen.
2 A pop-up notification appears on the display.
Tap Stop.
NOTE
• To avoid lowering the oven temperature and
lengthening proofing time, do not open the oven
door unnecessarily. Check bread products early
to avoid over proofing.
• Do not use the Proofing mode for warming food
or keeping food hot. The proofing oven
temperature is not hot enough to keep foods at
safe temperatures. Use the Warm feature to
keep food warm. Proofing does not operate
when the oven is above 125 ℉. "Oven is too hot.
Try again after it cools down." shows in the
display.
• It is normal for the fan to operate during the
Proof function.
• The proof feature automatically provides the
optimum temperature for the proofing process,
and therefore does not have a temperature
adjustment.
• For best results, cover the dough with a cloth or
with plastic wrap. (The plastic may need to be
anchored underneath the container so the oven
fan does not blow it off.)
Crispy Reheat
Crispy Reheat is a new cooking function that
restores the texture of foods that have become
soggy and lost their crispiness.
57OPERATION
ENGLISH
Setting the Crispy Reheat Mode
1 Press the POWER button.
2 Tap Manual Cook and scroll to select Crispy
Reheat.
3 Tap 3 or drag the option card to set the cook
options. Tap Temperature and set the
desired cook temperature by tapping the +/-
button, tapping the bar, or dragging the bar.
You can also use the number pad icon to set
the cooking temperature directly.
4 If desired, tap Cook Time or Start at to set
the cook time or cooking start time.
You can also use the number pad icon to set
the cooking time directly.
5 Tap When Finished to add a function after
cooking is complete.
• Keep Warm : Keeps the food warm after
cooking is complete.
• Stay On : Continues the previously selected
cooking mode after cooking is complete.
• Turn Off : Turns off automatically when
cooking is complete, without any additional
functions operating.
6 When you have selected the desired cook
settings, tap Start at the bottom right to
begin cooking.
7 A chime sounds at the end of the set cook
time and a notification appears in the display.
8 Tap Done to complete cooking. If needed, you
can tap + Cook Time to continue cooking, or
tap Keep Warm to maintain the food at
serving temperature.
Changing the Cook Settings
1 Tap 3 at the middle right of the screen.
2 Tap option you want to change to make
adjustments.
3 Tap Apply at the bottom right to apply the
modified settings to your recipe.
4 Tap 4 to return to the previous screen without
making changes.
To Stop Cooking
1 Tap Stop at the bottom right the of screen.
2 A pop-up notification appears on the display.
Tap Stop.
58 SMART FUNCTIONS
SMART FUNCTIONS
LG ThinQ Application
This feature is only available on models with Wi-Fi.
The LG ThinQ application allows you to
communicate with the appliance using a
smartphone.
LG ThinQ Application Features
• My Recipes
- Download new and special cooking recipes
that are not included in the standard cooking
mode on the appliance. Once My Recipes
download is completed in the appliance, the
appliance keeps the recipes. You can only
create, edit or delete the recipes in the LG
ThinQ application.
• Scan to Cook (USA Only)
- Scan the barcode on a ready-made meal using
the LG ThinQ application and send the
recommended or customized cooking
instructions straight to your oven. Remote
Start must be activated on the oven to use
Scan to Cook.
• RealTime View
- See video from inside the oven while cooking
using the LG ThinQ application. If you want,
you can take pictures. The appliance must be
connected to a home Wi-Fi network and the LG
ThinQ application to use the RealTime View
function.
• Cook record
- The camera can record the cooking process
and make a Time Lapse video. The appliance
must be connected to a home Wi-Fi network
and the LG ThinQ application to use the Cook
Record function.
• Product Upgrades
- On models with the LG UP Home Appliance
feature, experience new features by
upgrading the product through the LG ThinQ
app.
• Monitoring
- This function helps you check the current
status, remaining time, cook settings and end
time in one place.
• Product Notifications
- Turn on the Push Alerts to receive appliance
status notifications. The notifications are
triggered even if the LG ThinQ application is
not open.
• Timer
- You can set the timer from the application.
• Settings
- Allows you to set various options on the oven
and in the application.
• Smart Diagnosis
TM
- This function provides useful information for
diagnosing and solving issues with the
appliance based on the pattern of use.
• Firmware Update
- Keep the appliance updated.
NOTE
• In the following cases, you must update the
network information for each appliance in the
LG ThinQ application under Device Cards
~
Settings
~ Change Network.
- wireless router is changed
- wireless router password is changed
- Internet service provider is changed
• This information is current at the time of
publication. The application is subject to change
for product improvement purposes without
notice to users.
Installing LG ThinQ Application and
Connecting an LG Appliance
Models with QR Code
Scan the QR code attached to the product using
the camera or a QR code reader application on
your smartphone.
Models without QR Code
1 Search for and install the LG ThinQ
application from the Google Play Store or
Apple App Store on a smartphone.
59SMART FUNCTIONS
ENGLISH
2 Run the LG ThinQ application and sign in with
your existing account or create an LG account
to sign in.
3 Touch the add (~) button on the LG ThinQ
application to connect your LG appliance.
Follow the instructions in the application to
complete the process.
NOTE
• To verify the Wi-Fi connection, check that the f
icon on the control panel is lit.
• The appliance supports 2.4 GHz Wi-Fi networks
only. To check your network frequency, contact
your Internet service provider or refer to your
wireless router manual.
• LG ThinQ is not responsible for any network
connection problems or any faults, malfunctions,
or errors caused by network connection.
• The surrounding wireless environment can
make the wireless network service run slowly.
• If the distance between the appliance and the
wireless router is too far, the signal becomes
weak. It may take a long time to connect or fail
to install the application.
• If the appliance is having trouble connecting to
the Wi-Fi network, it may be too far from the
router. Purchase a Wi-Fi repeater (range
extender) to improve the Wi-Fi signal strength.
• The network connection may not work properly
depending on the Internet service provider.
• The Wi-Fi may not connect or the connection
may be interrupted because of the home
network environment.
• If the appliance cannot be connected due to
problems with the wireless signal transmission,
unplug the appliance and wait about a minute
before trying again.
• If the firewall on your wireless router is enabled,
disable the firewall or add an exception to it.
• The wireless network name (SSID) should be a
combination of English letters and numbers. (Do
not use special characters.)
• Smartphone user interface (UI) may vary
depending on the mobile operating system (OS)
and the manufacturer.
• If the security protocol of the router is set to
WEP, network setup may fail. Change the
security protocol (WPA2 is recommended), and
connect the product again.
• To disable the Wi-Fi function, press and hold the
Wi-Fi button for 3 seconds. The Wi-Fi indicator
will be turned off.
• To reconnect the appliance or add another user,
press and hold the Wi-Fi button for 3 seconds.
Run the LG ThinQ application and follow the
instructions in the application to connect the
appliance.
RF Module Specifications
† This feature is only available on some models.
FCC Statement
The following notice covers the transmitter
module contained in this product.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and the receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two
conditions:
Type
Frequency
Range
Output
Power (Max.)
Wi-Fi
2 412 - 2 472
MHz
< 12 mW/MHz
Bluetooth
†
2 402 - 2 480
MHz
< 3.6 mW
60 SMART FUNCTIONS
(1) This device may not cause harmful interference
and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
Any changes or modifications in construction of
this device which are not expressly approved by
the party responsible for compliance could void
the user’s authority to operate the equipment.
FCC RF Radiation Exposure
Statement
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This transmitter must not be co-
located or operating in conjunction with any other
antenna or transmitter.
This equipment should be installed and operated
with a minimum distance of 20 cm (7.8 inches)
between the antenna and your body. Users must
follow the specific operating instructions for
satisfying RF exposure compliance.
Open Source Software Notice
Information
To obtain the source code that is contained in this
product, under GPL, LGPL, MPL, and other open
source licenses that have the obligation to disclose
source code, and to access all referred license
terms, copyright notices and other relevant
documents, please visit https://
opensource.lge.com.
LG Electronics will also provide open source code
to you on CD-ROM for a charge covering the cost
of performing such distribution (such as the cost of
media, shipping, and handling) upon email
request to open[email protected].
This offer is valid to anyone in receipt of this
information for a period of three years after our
last shipment of this product.
Smart Diagnosis
TM
Feature
Use this feature to help you diagnose and solve
problems with your appliance.
NOTE
• For reasons not attributable to LGE’s negligence,
the service may not operate due to external
factors such as, but not limited to, Wi-Fi
unavailability, Wi-Fi disconnection, local app
store policy, or app unavailability.
• The feature may be subject to change without
prior notice and may have a different form
depending on where you are located.
Using LG ThinQ to Diagnose Issues
If you experience a problem with your Wi-Fi
equipped appliance, it can transmit
troubleshooting data to a smartphone using the
LG ThinQ application.
• Launch the LG ThinQ application and select the
Smart Diagnosis feature in the menu. Follow
the instructions provided in the LG ThinQ
application.
Using Audible Diagnosis to
Diagnose Issues
Follow the instructions below to use the audible
diagnosis method.
• Launch the LG ThinQ application and select the
Smart Diagnosis feature in the menu. Follow
the instructions for audible diagnosis provided
in the LG ThinQ application.
1 Tap the Settings icon at the top right of the
screen, tap Maintenance & Info, tap Smart
Diagnosis and tap Start to start the
diagnostic tone.
- If the display has been locked, you must
deactivate the lock and then reactivate it.
2 Place your phone's mouthpiece near the top
left corner of the screen.
3 Keep the phone in place until the tone
transmission has finished. The display will
count down the time. Once the countdown
is over and the tones have stopped, the
61SMART FUNCTIONS
ENGLISH
diagnosis will be displayed in the
application.
NOTE
• For best results, do not move the phone while
the tones are being transmitted.
62 MAINTENANCE
MAINTENANCE
Cleaning
CAUTION
• Do not clean this appliance with bleach.
• To prevent burns, wait until the cooktop has
cooled down before touching any of its parts.
• Always wear gloves when cleaning the cooktop.
Interior
Do not use oven cleaners to clean the oven cavity.
Use the product's EasyClean function regularly to
clean light soil. For stubborn soil, use the Self
Clean function (on some models) or clean
manually using the following tips.
• A plastic spatula can be used as a scraper to
scrape off any chunks or debris before and
during oven cleaning.
• Using the rough side of a non-scratch scouring
pad may help to take off burnt-on stains better
than a soft sponge or towel.
• Certain non-scratch scrubbing sponges, such as
those made of melamine foam, available at local
stores, can also help improve cleaning.
CAUTION
• Do not use oven cleaners, harsh chemical
cleaners, bleach, vinegar, steel scouring pads, or
abrasive pads or cleansers to clean the oven, as
they can permanently damage the oven surface.
• Do not clean the gasket.
Exterior
Control Panel
To prevent activating the control panel during
cleaning, disconnect power to the appliance. Clean
up splatters with a damp cloth using a glass
cleaner. Remove heavier soil with warm, soapy
water. Do not use abrasives of any kind.
Front Manifold Panel and Knobs
It is best to clean the manifold panel after each use
of the range. Clean the top surface of the manifold
panel regularly after cooking to prevent soil from
hardening. To remove stubborn soil, clean the
area with a soft brush. For cleaning, use a damp
cloth and mild soapy water or a 50/50 solution of
vinegar and water. For rinsing, use clean water
and polish dry with a soft cloth.
CAUTION
• Do not use abrasive cleansers, strong liquid
cleaners, plastic scouring pads or oven cleaners
on the manifold panel. Doing so will damage the
finish.
• Do not try to bend the knobs by pulling them up
or down, and do not hang a towel or other
objects on them. This can damage the gas valve
shaft.
• The control knobs may be removed for easy
cleaning.
• To clean the knobs, make sure that they are in
the OFF position and pull them straight off the
stems.
• To replace the knobs, make sure the knob has
the OFF position centered at the top, and slide
the knob directly onto the stem.
NOTE
• To prevent scratching, do not use abrasive
cleaners on any of these materials.
Painted and Decorative Trim
For general cleaning, use a cloth with hot soapy
water. For more difficult soils and built-up grease,
apply a liquid detergent directly onto the soil.
Leave it on for 30 to 60 minutes. Rinse with a damp
cloth and dry. Do not use abrasive cleaners.
Stainless Steel Surfaces
To avoid scratches, do not use steel wool pads.
1 Place a small amount of stainless steel
appliance cleaner or polish on a damp cloth or
paper towel.
2 Clean a small area, rubbing with the grain of
the stainless steel if applicable.
3 Dry and buff with a clean, dry paper towel or
soft cloth.
4 Repeat as necessary.
63MAINTENANCE
ENGLISH
NOTE
• To clean the stainless steel surface, use warm
sudsy water or a stainless steel cleaner or polish.
• Always wipe in the direction of the metal surface
finish.
• Stainless steel appliance cleaner or polish can be
purchased online or from most retailers of
appliances or home goods.
Oven Door
CAUTION
• Do not use harsh cleaners or harsh abrasive
cleaning materials on the outside of the oven
door. Doing so can cause damage.
• Use soapy water to thoroughly clean the oven
door. Rinse well. Do not immerse the door in
water.
• You may use a glass cleaner on the outside glass
of the oven door. Do not spray water or glass
cleaner on the door vents.
• Do not use oven cleaners, cleaning powders, or
harsh abrasive cleaning materials on the outside
of the oven door.
• Do not clean the oven door gasket. The oven
door gasket is made of a woven material that is
essential for a good seal. Care should be taken
not to rub, damage, or remove this gasket.
a Don’t hand clean oven door gasket
b Do hand clean door
Broiler Pan and Grid
• Do not store a soiled broiler pan or grid
anywhere in the range.
• Do not clean the broiler pan or grid in a self
cleaning mode.
• Remove the grid from the pan. Carefully pour
out the grease from the pan into a proper
container.
• Wash and rinse the broiler pan and grid in hot
water with a soap-filled or plastic scouring pad.
• If food has burned on, sprinkle the grid with
cleaner while hot and cover with wet paper
towels or a dishcloth. Soaking the pan will
remove burned-on foods.
• Both the broiler pan and grid may be cleaned
with a commercial oven cleaner or in the
dishwasher.
Oven Racks
Remove the oven racks before operating the Self
Clean cycle and EasyClean.
1 Clean with a mild, abrasive cleaner.
• Food spilled into the tracks could cause the
racks to become stuck.
2 Rinse with clean water and dry.
NOTE
• For models with Self Clean function:
- If the racks are cleaned using the Self Clean
cycle (not recommended), the color will turn
slightly blue and the finish will become dull.
After the Self Clean cycle is complete, and the
oven has cooled, rub the sides of the racks
with wax paper or a cloth containing a small
amount of oil. This will make the racks glide
more easily into the rack tracks.
Vent Louvers
• The appearance of the range may differ from
model to model.
64 MAINTENANCE
Use a vacuum cleaner with a brush or crevice
attachment to clean the vent louvers
a. Do not
remove the panel covering the range.
Gas Surface Burners
Removing and Replacing the Gas
Surface Burners
Position and size of burners vary by model.
Grates and burner heads/caps can be removed for
care and cleaning.
• Take care when installing or removing the
grates, as the rough edges may cause scratches
on the surface of the cooktop.
CAUTION
• Make sure burner heads and caps are reinstalled
properly. They will be stable and rest flat when
correctly installed.
• When burner cap is properly set.
• When burner cap is not properly set.
Cleaning Burner Heads/Caps
For even and unhampered flame, the slits in the
burner heads must be kept clean at all times.The
burner heads and caps (and the oval burner head
and cap assembly) can be lifted off. Do not attempt
to remove the oval burner cap.
CAUTION
• Do not hit the electrodes with anything hard.
Doing so could damage them.
• Do not use steel wool or scouring powders to
clean the burners.
• Wash the burner caps in hot soapy water and
rinse with clean water. Run water through the
oval burner from the bottom stem to flush out
debris.
• Use care when cleaning the cooktop. The
pointed metal ends on the electrodes could
cause injury. Hitting an electrode with a hard
object may damage it.
• To remove burnt-on food, soak the burner heads
in a solution of mild liquid detergent and hot
water for 20–30 minutes. For stubborn stains,
use a toothbrush or wire brush.
• The burners will not operate properly if the
burner ports or electrodes are clogged or dirty.
• Burner caps and heads should be cleaned
routinely, especially after excessive spillover.
• Burners will not light if the cap is removed.
After Cleaning the Burner Heads/Caps
Shake out any excess water and then let them dry
thoroughly. Placing the oval burner upside down
will allow the water to drain out more easily.
Replace the burner heads and caps over the
electrodes on the cooktop in the correct locations
according to their size. Make sure the hole in the
burner head is positioned over the electrode.
Burner Grates
The range consists of three separate professional-
style grates. For maximum stability, these grates
65MAINTENANCE
ENGLISH
should only be used when in their proper position.
The center grate can be interchanged from front
to back.
a Side grate
b Center grate
CAUTION
• Do not operate a burner for an extended period
of time without cookware on the grate. The
finish on the grate may chip without cookware to
absorb the heat.
Cleaning the Burner Grates
CAUTION
• Do not lift the grates out until they have cooled.
• Do not put the grate in the oven during self
cleaning mode.
• Grates should be washed regularly and after
spillovers.
• Wash the grates in hot, soapy water and rinse
with clean water.
• The grates are dishwasher safe.
• After cleaning the grates, let them dry
completely and securely position them over the
burners.
Cleaning the Cooktop Surface
The EasyClean coating makes cleaning the cooktop
easier. Even heavy grease stains can be removed
using only warm water.
CAUTION
• Before cleaning, turn all controls to OFF and
allow the cooktop to cool.
• To avoid burns, do not clean the cooktop surface
until it has cooled.
• Do not lift the cooktop surface. Lifting the
cooktop surface can lead to damage and
improper operation of the range.
• When water is spilled on the cooktop, wipe up
water immediately. If water is left on the cooktop
for a long time, discoloration may occur.
Foods with high acid or sugar content may cause a
dull spot if allowed to set. Wash and rinse soon
after the surface has cooled. For other spills such
as oil/grease spattering, wash with soap and water
when the surface has cooled, then rinse and polish
with a dry cloth.
1 Remove grates, burners and burner caps
from the cooktop.
2 Scrape off and remove any burned-on debris
with a plastic scraper or old credit card.
3 Clean the cooktop with a wet, non-scratch
scouring sponge or pad.
NOTE
• EasyClean Stainless Steel Cooktop
- To avoid scratching the cooktop surface, do
not use abrasive or metal scouring sponges or
pads.
- Rub in the direction of the grain to avoid
damaging the surface.
a Direction of the grain
- As with any cooktop, some stains may not be
removable.
- If the cooktop has hardened residue, use a
kitchen detergent for an easier cleaning.
66 MAINTENANCE
EasyClean
LG’s EasyClean enamel technology provides two
cleaning options for the inside of the range. The
EasyClean feature takes advantage of LG’s new
enamel to help lift soils without harsh chemicals,
and it runs using ONLY WATER for just 10 minutes
in low temperatures to help loosen LIGHT soils
before hand cleaning.
While EasyClean is quick and effective for small
and LIGHT soils, the Self Clean feature can be used
to remove HEAVY, built up soils. The intensity and
high heat of the Self Clean cycle may result in
smoke which will require the opening up of
windows to provide ventilation. Compared to the
more intense Self Clean process, your LG oven
gives you the option of cleaning with LESS HEAT,
LESS TIME, and virtually NO SMOKE OR FUMES.
You can reduce energy use by cleaning light oven
soils with the EasyClean feature instead of Self
Clean.
When needed, the range still provides the Self
Clean option for longer, more thorough oven
cleaning for heavier, built up soils.
• For hard to reach areas such as the back surface
of the oven, it is better to use the Self Clean
cycle.
Benefits of EasyClean
• Helps loosen light soils before hand-cleaning
• EasyClean only uses water; no chemical cleaners
• Makes for a better Self Clean experience
- Delays the need for a Self Clean cycle
- Minimizes smoke and odors
- Can allow shorter Self Clean time
NOTE
• For models without Self Clean option
- The EasyClean feature may not be effective in
removing heavy, built-up soils. Because the
range does not include a Self Clean option,
clean the oven regularly using the EasyClean
feature to prevent heavy, burnt-on soil from
building up in the oven.
When to Use EasyClean
• Example of oven soiling
Case 1
- Soil pattern: Small drops or spots
- Types of soils: Cheese or other ingredients
- Common food items that can soil your oven:
Pizza
Case 2
- Soil pattern: Light splatter
- Types of soils: Fat/grease
- Common food items that can soil your oven:
Steaks, broiled / Fish, broiled / Meat roasted at
low temperatures
EasyClean Instruction Guide
NOTE
• Allow the oven to cool to room temperature
before using the EasyClean cycle. If your oven
cavity is above 150 °F (65 °C), Hot will appear in
the display, and the EasyClean cycle will not be
activated until the oven cavity cools down.
• The range should be level to ensure that the
bottom surface of the oven cavity is entirely
covered by water at the beginning of the
EasyClean cycle.
• For best results, use distilled or filtered water.
Tap water may leave mineral deposits on the
oven bottom.
• Soil baked on through several cooking cycles will
be more difficult to remove with the EasyClean
cycle.
• Do not open the oven door during the EasyClean
cycle. Water will not get hot enough if the door is
opened during the cycle.
1 Remove oven racks and accessories from the
oven.
2 Scrape off and remove any burnt-on debris
with a plastic scraper.
67MAINTENANCE
ENGLISH
• Suggested plastic scrapers:
- Hard plastic spatula
- Plastic pan scraper
- Plastic paint scraper
- Old credit card
3 Fill a spray bottle (10 oz or 300 ml) with water
and use the spray bottle to thoroughly spray
the inside surfaces of the oven.
4 Use at least 1/5 (2 oz or 60 ml) of the water in
the bottle to completely saturate the soil on
both the walls and in the corners of the oven.
5 Spray or pour the remaining water (8 oz or
240 ml) onto the bottom center of the oven
cavity. The indentation on the oven bottom
should be fully covered to submerge all soils.
Add water if necessary.
NOTE
• If cleaning multiple ovens, use an entire bottle of
water to clean each oven. Do not spray water
directly on the door. Doing so will result in water
dripping to the floor.
6 Close the oven door. Scroll and tap Cleaning.
Tap EasyClean. Tap Start at the bottom right
to begin cleaning.
CAUTION
• Some surfaces may be hot after the EasyClean
cycle. Wear rubber gloves while cleaning to
prevent burns.
• During the EasyClean cycle, the oven becomes
hot enough to cause burns. Wait until the cycle is
over before wiping the inside surface of the
oven. Failure to do so may result in burns.
• Avoid leaning or resting on the oven door glass
while cleaning the oven cavity.
7 A tone will sound at the end of the 10 minute
cycle. Tap Done to complete cooking.
8 After the cleaning cycle and during hand-
cleaning, enough water should remain on the
oven bottom to completely submerge all soils.
Add water if necessary. Place a towel on the
floor in front of the oven to capture any water
that may spill out during hand-cleaning.
9 Clean the oven cavity immediately after the
EasyClean cycle by scrubbing with a wet, non-
scratch scouring sponge or pad. (The scouring
side will not scratch the finish.) Some water
may spill into the bottom vents while
cleaning, but it will be captured in a pan under
the oven cavity and will not hurt the burner.
NOTE
• Do not use any steel scouring pads, abrasive
pads or cleaners as these materials can
permanently damage the oven surface.
10 Once the oven cavity is cleaned, wipe any
excess water with a clean dry towel. Replace
racks and any other accessories.
68 MAINTENANCE
11 If some light soils remain, repeat the above
steps, making sure to thoroughly soak the
soiled areas.
• For models with Self Clean function
- If stubborn soils remain after multiple
EasyClean cycles, run the Self Clean cycle.
Be sure that the oven cavity is empty of
oven racks and other accessories, and
that the oven cavity surface is dry before
running the Self Clean cycle. Consult the
Self Clean section of your owner’s manual
for further details. If a Self Clean option is
not available, scrape off and remove
stubborn soil using a scraper.
NOTE
• If you forget to saturate the inside of the oven
with water before starting EasyClean, turn the
oven mode knob to the OFF position to end the
cycle. Wait for the range to cool to room
temperature and then spray or pour water into
the oven and start another EasyClean cycle.
• The cavity gasket may be wet when the
EasyClean cycle finishes. This is normal. Do not
clean the gasket.
• If mineral deposits remain on the oven bottom
after cleaning, use a cloth or sponge soaked in
vinegar to remove them.
• It is normal for the fan to operate during the
EasyClean cycle.
• Using commercial oven cleaners or bleach to
clean the oven is not recommended. Instead,
use a mild liquid cleanser with a pH value below
12.7 to avoid discoloring the enamel.
Self Clean
The Self Clean cycle uses extremely hot
temperatures to clean the oven cavity. While
running the Self Clean cycle, you may notice
smoking or an odor. This is normal, especially if
the oven is heavily soiled. During Self Clean, the
kitchen should be well ventilated to minimize the
odors from cleaning.
Before Starting Self Clean
• Clean only parts listed in manual. Remove the
oven racks, broiler pan, broiler grid, all
cookware, aluminum foil or any other material
from the oven.
- If oven racks are left in the oven cavity during
the Self Clean cycle, they will discolor and
become difficult to slide in and out.
• The kitchen should be well ventilated to
minimize the odors from cleaning. Open a
window or turn on a ventilation fan or hood
before self-cleaning.
• Wipe any heavy spillovers on the bottom of the
oven.
• Make sure that the oven light cover is in place
and the oven light is off.
• Clean the frame of the oven and door with hot
soapy water. Rinse well.
WARNING
• If the oven is heavily soiled with oil, self-clean the
oven before using the oven again. The oil could
cause a fire.
• If there is a fire in the oven during self-clean,
turn the oven off and wait for the fire to go out.
Do not force the door open. Introduction of
fresh air at self-clean temperatures may lead to
a burst of flame from the oven. Failure to follow
this instruction may result in severe burns.
CAUTION
• Do not use oven cleaners. Commercial oven
cleaner or oven liner protective coating of any
kind should not be used in or around any part of
the oven.
• The oven displays an F error code and sounds
three long beeps during the self-cleaning
process if it malfunctions in the self-clean mode.
Switch off the electrical power to the main fuse
or breaker and have the oven serviced by a
qualified technician.
• If the self cleaning mode malfunctions, turn the
range off and disconnect the power supply. Have
it serviced by a qualified technician.
• It is normal for parts of the oven to become hot
during a Self Clean cycle. Avoid touching the
cooktop, door, window or oven vent area during
a Self Clean cycle.
• Do not leave small children unattended near the
appliance. During the Self Clean cycle, the
outside of the range can become very hot to the
touch.
• If you have pet birds, move them to another
well-ventilated room. The health of some birds is
extremely sensitive to the fumes given off during
the Self Clean cycle of any range.
• Do not line the oven walls, racks, bottom or any
other part of the range with aluminum foil or
any other material. Doing so will destroy heat
distribution, produce poor baking results and
cause permanent damage to the oven interior
69MAINTENANCE
ENGLISH
(aluminum foil will melt to the interior surface of
the oven).
NOTE
• The oven light cannot be turned on during a Self
Clean cycle. The oven light cannot be turned on
until the oven temperature has cooled below
500 ˚F (260 ˚C) after a Self Clean cycle is
complete.
• During the Self Clean cycle, the cooktop
elements and warming drawer cannot be used.
• Clean the frame of the oven and door with hot
soapy water. Rinse well.
• Do not clean the gasket. The fiberglass material
of the oven door gasket cannot withstand
abrasion. It is essential for the gasket to remain
intact. If you notice it becoming worn or frayed,
replace it.
• It is normal for the fan to operate during the Self
Clean cycle.
• As the oven heats, you may hear sounds of metal
parts expanding and contracting. This is normal
and will not damage the oven.
• You may notice some white ash in the oven.
Wipe it off with a damp cloth or a soap-filled
steel wool pad after the oven cools. If the oven is
not clean after one Self Clean cycle, repeat the
cycle.
• If oven racks were left in the oven and do not
slide smoothly after a Self Clean cycle, wipe racks
and rack supports with a small amount of
vegetable oil to make them glide more easily.
• After a Self Clean cycle, fine lines may appear in
the porcelain because it went through heating
and cooling. This is normal and will not affect
performance.
• The Self Clean cycle cannot be started if the
Control Lock / Lockout feature is active.
• If the clock is set for a 12-hour display (default)
the Delayed Self Clean can never be set to start
more than 12 hours in advance.
• After the oven is turned off, the convection fan
keeps operating until the oven has cooled down.
When to Use Self Clean
• Example of oven soiling
Case 1
• Soil pattern: Medium to heavy splatter
• Types of soils: Fat/grease
• Common food items that can soil your oven:
Meat roasted at high temperatures
Case 2
• Soil pattern: Drops or spots
• Types of soils: Filling or sugar based soils
• Common food items that can soil your oven: Pies
Case 3
• Soil pattern: Drops or spots
• Types of soils: Cream or tomato sauce
• Common food items that can soil your oven:
Casseroles
NOTE
• The Self Clean cycle can be used for soil that has
been built up over time.
Setting Self Clean
The Self Clean function has cycle times of 3, 4, or 5
hours.
Self Clean Setting Guide
1 Remove all racks and accessories from the
oven.
Oven Cavity
Soil Level
Number
Button
Cycle
Time
Lightly Soiled 1 3 hr.
Moderately
Soiled
24 hr.
Heavily Soiled 3 5 hr.
70 MAINTENANCE
2 Close the oven door. Scroll and tap Cleaning.
Tap Self Clean. The oven defaults to the
recommended four-hour Self Clean for a
moderately soiled oven.
If desired, tap Cleaning Time to set the
cleaning time. Select one of the three: 3 hr, 4
hr, 5 hr.
If desired, tap Starts at to set the cleaning
start time.
3 Tap Start at the bottom right to begin
cleaning.
4 Once the Self Clean cycle is set, the oven door
locks automatically and the lock icon k
displays. You will not be able to open the oven
door until the oven has cooled. The lock
releases automatically when the oven has
cooled.
CAUTION
• Do not force the oven door open when the lock
icon is displayed. The oven door remains locked
until the oven temperature has cooled. Forcing
the door open will damage the door.
• Use care when opening the oven door after the
Self Clean cycle. Stand to the side of the oven
when opening the door to allow hot air or steam
to escape. The oven may still be VERY HOT.
NOTE
• It may become necessary to cancel or interrupt a
Self Clean cycle due to excessive smoke or fire in
the oven. To cancel the Self Clean function, Tap
Stop at the bottom right.
Removing/Assembling Lift-Off
Oven Doors
NOTE
• Parts may be changed due to product
improvement and may look different than
shown in images.
Door Care Instructions
Most oven doors contain glass that can break.
CAUTION
• Do not close the oven door until all the oven
racks are fully in place.
• Do not hit the glass with pots, pans, or any other
object.
• Scratching, hitting, jarring, or stressing the glass
may weaken its structure causing an increased
risk of breakage at a later time.
Removing Doors
1 Fully open the door.
2 Lift up the hinge lock b and flip it towards the
hinge arm d completely. Repeat on other
side.
a Slot
b Hinge Lock
c Oven Frame
d Hinge Arm
3 Firmly grasp both sides of the door at the top.
4 Partially close the door to approximately 5
degrees
a. If the position is correct, the hinge
arms will move freely.
a about 5°
Locked Position Unlocked Position
71MAINTENANCE
ENGLISH
5 Lift and pull the door towards you until the
hinge latches are completely loosened.
Assembling Doors
1 Firmly grasp both sides of the door at the top.
2 Fully insert the hinge arms a into the slots b
until the indentations c on the hinge arms
rest on the bottom edges of the slots.
a Hinge Arm
b Bottom Edge of Slot
c Indentation
3 Slowly open the door fully. Make sure that the
hinge arms are properly engaged in the slots.
4 Lift up the hinge lock b and flip it towards the
oven
c until it clicks into position. Repeat on
other side.
a Slot
b Hinge Lock
c Oven Frame
d Hinge Arm
5 Close the oven door.
Removing/Assembling Drawers
Removing Drawers
CAUTION
• Disconnect the electrical power to the range at
the main fuse or circuit breaker panel. Failure to
do so can result in severe personal injury, death,
or electrical shock.
Most cleaning can be done with the drawer in
place; however, the drawer may be removed if
further cleaning is needed. Use warm water to
thoroughly clean.
1 Fully open the drawer.
2 Unscrew the screw a on the side at the back
of the drawer.
3 Locate the glide lever on each side of the
drawer. Push down on the left glide lever and
pull up on the right glide lever.
a Lever
b Push down with finger
c Pull up with finger
4 Pull the drawer away from the range.
Unlocked Position Locked Position
72 MAINTENANCE
Assembling Drawers
1 Pull the bearing glides to the front of the
chassis glide.
2 Align the glide on each side of the drawer with
the glide slots on the range.
3 Push the drawer into the range until levers
click (approximately 2 inches).
4 Insert and tighten the screws on the side at
the back of the drawer.
5 Pull the drawer open again to seat the
bearing glides into position.
Removing/Assembling the Vent
Trim
Removing the Vent Trim
1 Using a screwdriver, remove the 3 screws
holding the vent trim in place.
2 Lift the vent trim.
Assembling the Vent Trim
Assemble the vent trim in the reverse sequence of
its removal.
Periodic Maintenance
Changing the Oven Light
The oven light is a standard 40-watt appliance
halogen lamp. It turns on when the oven door is
open. When the oven door is closed, press Light to
turn it on or off.
WARNING
• Make sure that the oven and lamp are cool.
• Disconnect the electrical power to the range at
the main fuse or circuit breaker panel. Failure to
do so can result in severe personal injury, death,
or electrical shock.
1 Unplug the range or disconnect power.
2 Turn the glass lamp cover in the back of the
oven counterclockwise to remove.
3 Remove the halogen lamp from the socket.
4 Insert the new halogen lamp.
5 Insert the glass lamp cover and turn it
clockwise.
73MAINTENANCE
ENGLISH
6 Plug in the range or reconnect the power.
74 TROUBLESHOOTING
TROUBLESHOOTING
FAQs
Frequently Asked Questions
CAUTION
• Foil may be used to wrap food in the oven or warming drawer, but do not allow the foil to come into
contact with the exposed heating/broiling elements in the oven. The foil could melt or ignite, causing
smoke, fire, or injury.
Q: What types of cookware are recommended for use with the cooktop?
A:
• The pans must have a flat bottom and straight sides.
• Only use heavy-gauge pans.
• The pan size must match the amount of food to be prepared and the size of the surface
element.
• Use tight fitting lids.
• Only use flat-bottom woks.
Q: My new oven doesn’t cook like my old one. Is there something wrong with the temperature
settings?
A: No. Your oven has been factory tested and calibrated. For the first few uses, follow your recipe times
and temperatures carefully. If you still think your new oven is too hot or too cold, you can adjust the
oven temperature yourself to meet your specific cooking needs. Refer to the "Changing Oven
Settings" section in this manual for easy instructions on how to adjust your thermostat.
Q: Is it normal to hear a clicking noise coming from the back of my oven when I am using it?
A: Your new range is designed to maintain a tighter control over your oven’s temperature. You may hear
your oven’s heating elements click on and off more frequently on your new oven. This is NORMAL.
Q: Why is the time flashing?
A: This means that the product has just been plugged in, or that it has experienced a power
interruption. To clear the flashing time, touch any button and reset the clock if needed.
Q: During convection cooking the fan stops when I open the door. Is that normal?
A: Yes, this is normal. When the door is opened, the convection fan will stop until the door is closed.
Q: Can I use aluminum foil to catch drippings in my oven cavity?
A: Never use aluminum foil to line the bottom or sides of the oven or the warming drawer (on some
models). The foil will melt and stick to the bottom surface of the oven and will not be removable. Use
a foil-lined sheet pan placed on a lower oven rack to catch drippings instead. (If foil has already
melted onto the bottom of the oven, it will not interfere with the oven’s performance.)
Q: Can I use aluminum foil on the racks?
A: Do not cover racks with aluminum foil. Covering entire racks with foil restricts air flow, leading to
poor cooking results. Use a sheet pan lined with foil under fruit pies or other acidic or sugary foods to
prevent spillovers from damaging the oven finish.
Q: Can I leave my racks in the oven when running a Self Clean cycle? (On some models)
A: No. Although it will not damage the racks, it will discolor them and may make them hard to slide in
and out during use. Remove all items from the oven before starting a Self Clean cycle.
75TROUBLESHOOTING
ENGLISH
Q: What should I do if my racks are sticky and have become hard to slide in and out?
A: Over time, the racks may become hard to slide in and out. Apply a small amount of olive oil to the
sides of the racks. This will work as a lubricant for easier gliding.
Q: What should I do for hard to remove stains on my cooktop?
A: The cooktop should be cleaned after every use to prevent permanent staining. When cooking foods
with high sugar content, such as tomato sauce, clean the stain off with a scraper while the cooktop is
still warm. Use an oven mitt when scraping to prevent burns. Refer to the "MAINTENANCE" section of
this owner's manual for further instruction.
Q: Why aren't the function buttons working?
A:
Make sure that the range is not in Control Lock / Lockout mode. The lock
k will show in the display if
Control Lock / Lockout is activated. To deactivate Control Lock / Lockout, refer to the "Control Lock /
Lockout" section. The unlock melody sounds and Loc appears in the display until the controls are
unlocked.
Q: My range is still dirty after running the EasyClean cycle. What else should I do?
A: The EasyClean cycle only helps to loosen light soils in your oven range to assist in hand-cleaning of
your oven. It does not automatically remove all soils after the cycle. Some scrubbing of your oven
range is required after running the EasyClean cycle.
Q: I tried scrubbing my oven after running. EasyClean, but some soils still remain. What can I do?
A: The EasyClean feature works best when the soils are fully soaked and submerged in water before
running the cycle and during hand-cleaning. If soils are not sufficiently soaked in water, it can
negatively affect the cleaning performance. Repeat the EasyClean process using sufficient water.
• For models with Self Clean function:
Sugar-based and certain greasy soils are especially hard to clean. If some stubborn soils
remain, use the Self Clean feature to thoroughly clean your oven.
Q: Soils on my oven walls are not coming off. How can I get the oven walls clean?
A: Soils on the side and rear walls of your oven range may be more difficult to fully soak with water. Try
repeating the EasyClean process with more than the ¼ cup (2 oz or 60 ml) of spray recommended.
Q: Will EasyClean get all of the soils and stains out completely?
A: It depends on the soil type. Sugar-based and certain grease stains are especially hard to clean. Also, if
stains are not sufficiently soaked in water, this can negatively affect cleaning performance.
• For models with Self Clean function:
If stubborn or built-up stains remain, use the Self Clean feature. Refer to the Self Clean section
of your owner's manual.
Q: Are there any tricks to getting some of the stubborn soils out?
A: Scraping the soils with a plastic scraper before and during hand-cleaning is recommended. Fully
saturating soils with water is also recommended.
• For models with Self Clean function:
However, certain types of soils are harder to clean than others. For these stubborn soils, the
Self Clean cycle is recommended. Consult the Self Clean section of your owner's manual for
details.
Q: Is it safe for my convection fan or heater element to get wet during EasyClean?
A: Yes. The convection fan or heater element may get a little wet during cleaning. However, direct spray
onto the broil burner and heater elements is not necessary because these are self-cleaning during
regular use.
Q: Do I need to use all 1 ¼ cups (10 oz or 300 ml) of water for EasyClean?
76 TROUBLESHOOTING
Before Calling for Service
Review this section before calling for service; doing so will save you both time and money.
For detailed information or videos, visit www.lg.com
for the troubleshooting page.
Cooking
A: Yes. It is highly recommended that 1 cup (8 oz or 240 ml) of water be sprayed or poured on the
bottom and an additional ¼ cup (2 oz or 60 ml) of water be sprayed on walls and other soiled areas to
fully saturate the soils for better cleaning performance.
Q: I see smoke coming out of my oven range’s cooktop vents during EasyClean. Is this normal?
A: This is normal. This is not smoke. It is actually water vapor (steam) from the water in the oven cavity.
As the oven heats briefly during EasyClean, the water in the cavity evaporates and escapes through
the oven vents.
Q: How often should I use EasyClean?
A: EasyClean can be performed as often as you wish. EasyClean works best when your oven is LIGHTLY
soiled from such things as LIGHT grease splatter and small drops of cheese. Please refer to the
EasyClean section in your owner's manual for more information.
Q: What is required for EasyClean?
A: A spray bottle filled with 1¼ cups (10 oz or 300 ml) of water, a plastic scraper, a non-scratch scrubbing
pad and a towel. You should not use abrasive scrubbers such as heavy-duty scouring pads or steel
wool.
Q: How can I help keep children safe around the range?
A: Children should be supervised around the range whenever it is in use, and after use until surfaces
have cooled. You can also use the Control Lock / Lockout feature to help prevent children from
accidentally turning on the cooktop or oven. The Control Lock / Lockout feature disables most control
panel buttons and the cooktop control knobs. On some models, it also locks the oven door. Consult
the "Control Lock / Lockout" section of your owner’s manual for details. (In models without a Self
Clean option, the Control Lock / Lockout feature locks the controls but does not lock the oven door.)
Q: The third knob from the right doesn't light up. Is that normal? (On some models)
A: This is normal. Your range is designed to light up only 5 burner knobs.
Q: Why isn't the Instaview working? (On some models)
A: Level the range by adjusting the leveling legs with a wrench.
Problem Possible Cause & Solution
Top burners do not
light or do not burn
evenly.
The electrical plug is not inserted properly.
• Make sure that the electrical plug is inserted into a live, properly grounded outlet.
Electrode area is not clean.
• Remove the burners and clean them. Check the electrode area for burnt on food or grease.
See "Cleaning Burner Heads/Caps" in the MAINTENANCE chapter.
Burner parts are not installed properly.
• Make sure that the burner parts are installed correctly. See "Removing and Replacing the
Gas Surface Burners" in the MAINTENANCE chapter.
77TROUBLESHOOTING
ENGLISH
Burners are not
lighting properly
after cleaning the
cooktop surface.
Burner heads and caps are not completely dry or properly positioned.
• Make sure that the burner heads and caps are completely dry and properly positioned.
Burner flames are
very large or yellow.
It may be due to improper installation or setting.
• If the range is connected to LP gas, contact the technician who installed your range or
made the conversion.
Surface burners light
but the oven does
not.
Shut-off valve is not fully open.
• Make sure that the oven gas shut-off valve, located behind the range, is fully open.
Food does not bake
or roast properly
Oven controls improperly set.
• See the "Oven" section in the Operation chapter.
Rack position is incorrect or the rack is not level.
• See the "Oven" section in the Operation chapter.
Incorrect cookware or cookware of improper size being used.
• See the "Oven" section in the Operation chapter.
Oven thermostat needs to be adjusted.
• See the "Calibrating the Oven Temperature" section in the Operation chapter.
The Clock is not set correctly.
• See "Changing Oven Settings" in the OPERATION chapter.
Aluminum foil used improperly in the oven.
• See "Using Oven Racks" in Oven section.
Food does not broil
properly
Oven controls improperly set.
• Make sure you select the Broil mode properly.
Improper rack position being used.
• See the Broiling Guide.
Cookware not suited for broiling.
• Use broiling pan and grid.
The oven door is not closed.
• See "Broil" in the OPERATION chapter.
Aluminum foil used on the broiling pan and grid has not been fitted properly and slit as
recommended.
• See the "Oven" section in the Operation chapter.
Oven temperature
too hot or too cold
Oven sensor needs to be adjusted.
• See the "Calibrating the Oven Temperature" section in the Operation chapter.
Excessive smoking
during a Self Clean
cycle (On some
models)
Excessive soil.
• Turn off the Self Clean function. Open the windows to rid the room of smoke. Wait until the
Self Clean mode is cancelled. Wipe up the excess soil and reset the clean.
Burning or oily odor
emitting from the
vent
This is normal in a new oven.
• This will disappear in time. To speed the process, set a Self Clean cycle for a minimum of 3
hours. See the Self Clean section. (On some models)
Oven will not work Plug on range is not completely inserted in the electrical outlet.
• Make sure electrical plug is plugged into a live, properly grounded outlet.
Problem Possible Cause & Solution
78 TROUBLESHOOTING
Parts & Features
Oven will not work A fuse in your home may be blown or the circuit breaker tripped.
• Replace the fuse or reset the circuit breaker.
Oven controls improperly set.
• See the "Oven" section in the Operation chapter.
Oven too hot.
• Allow the oven to cool to below locking temperature.
Steam is exhausted
through the oven
vent.
Cooking foods with high moisture produces steam.
• This is normal.
Appliance does not
operate.
Cord is not plugged in correctly.
• Make sure cord is plugged correctly into outlet. Check circuit breakers.
Service wiring is not complete.
• Contact your electrician for assistance.
Power outage.
• Check house lights to be sure. Call your local electric company for service.
Oven smokes
excessively during
broiling.
Control not set properly.
• Follow instructions under Setting Oven Controls.
Meat too close to the element.
• Reposition the rack to provide proper clearance between the meat and the element.
Preheat broil element for searing.
Meat not properly prepared.
• Remove excess fat from meat. Cut remaining fatty edges to prevent curling.
Insert on broiler pan wrong side up and grease not draining.
• Always place the grid on the broiler pan with ribs up and slots down to allow grease to drip
into the pan.
Grease has built up on oven surfaces. Old grease or food spatters cause excessive
smoking.
• Regular cleaning is necessary when broiling frequently.
Moisture collects on
oven window or
steam comes from
oven vent
This happens when cooking foods high in moisture.
• This is normal.
Excessive moisture was used when cleaning the window.
• Do not use excessive moisture when cleaning the window.
Problem Possible Cause & Solution
Clock and timer does
not work.
The electrical plug is not inserted properly.
• Make sure the electrical plug is inserted into a live, properly grounded outlet. Replace the
fuse or reset the circuit breaker.
Improper oven control settings
• See "Changing Oven Settings" in the OPERATION chapter.
Oven light does not
work.
It is time to replace the lamp or the lamp is loose.
• Replace or tighten lamp. See "Changing the Oven Light" section in this Owner’s Manual.
Problem Possible Cause & Solution
79TROUBLESHOOTING
ENGLISH
Oven light does not
work.
The plug on the range is not completely inserted in the electrical outlet.
• Make sure the electrical plug is inserted into a live, properly grounded outlet.
Oven will not Self
Clean. (On some
models)
The oven temperature is too high to set a Self Clean operation.
• Allow the range to cool and reset the controls.
Oven controls improperly set.
• See the Self Clean section.
A Self Clean cycle cannot be started if the oven Control Lock / Lockout feature is active.
• See the "Control Lock / Lockout" in "Changing Oven Settings" section.
Oven door does not
open after a Self
Clean cycle (On some
models)
Oven is too hot.
• Allow the oven to cool below locking temperature.
The control and door may be locked.
• Allow about one hour for the oven to cool after the completion of a Self Clean cycle. The
door can be opened when the lock
k is no longer displayed.
The oven is not clean
after a Self Clean
cycle (On some
models)
Oven controls not properly set.
• See the Self Clean section.
Oven was heavily soiled.
• Clean up heavy spillovers before starting the clean cycle. Heavily soiled ovens may need to
Self Clean again or for a longer period of time.
CLEAN and door
flash in the display
(On some models)
The Self Clean cycle has been selected, but the door is not closed.
• Close the oven door.
"Loc" is on in the
display when you
want to cook (On
some models)
The oven is locked because of the Control Lock / Lockout feature.
• Deactivate the Control Lock / Lockout feature.
Oven control beeps
and displays any F
code error.
Electronic control has detected a fault condition.
• Remove the power from the range for five minutes and then reconnect the power. If the
function error code repeats, call for service.
- [Case 1]
Code: F-3
Cause: Key short error
- [Case 2]
Code: F-9
Cause: Oven not heating
• Check the main gas shut-off valve or the oven gas shut-off valve and call for service.
Oven control
displays Sb/5b/S6/56
error code.
This code is not an error code. It indicates that the product's Sabbath mode
sb is
activated.
• See the "Using the Sabbath Mode" section in the Operation chapter.
The oven racks were
cleaned in a Self
Clean cycle. (On
some models)
The shiny, silver-colored racks were cleaned in a Self Clean cycle.
• Apply a small amount of vegetable oil to a paper towel and wipe the edges of the oven
racks with the paper towel. Do not use lubricant sprays.
Problem Possible Cause & Solution
80 TROUBLESHOOTING
Noises
Wi-Fi
Displayed colon in
the clock is flashing
This means that the product has just been plugged in, or that it has experienced a
power interruption.
• This is normal. Reset the clock and any cooking function.
Light can be seen
through the oven air
vents.
While the Broil function is running, it is normal to see a light between the oven air
vents.
• This is normal.
Range is not level. Poor installation.
• Place oven rack in center of oven. Place a level on the oven rack. Adjust leveling legs at
base of range until the oven rack is level.
• Be sure floor is level and strong and stable enough to adequately support range.
• If floor is sagging or sloping, contact a carpenter to correct the situation.
Kitchen cabinet alignment may make range appear unlevel.
• Be sure cabinets are square and have sufficient room for range clearance.
Cannot move
appliance easily.
Appliance must be
accessible for
service.
Cabinets not square or are built in too tightly.
• Contact builder or installer to make appliance accessible.
Carpet interferes with range.
• Provide sufficient space so range can be lifted over carpet.
Anti-tip device engaged.
• Uninstall the anti-tip device to move the range. Reengage the anti-tip device after pulling
the range out for cleaning, service, or any other reason.
Convection fan
stops. (During
Conv.Bake mode)
Convection fan stops during a convection bake cycle. It is done to allow for more even
heating during the cycle.
• This is not a failure of the range and should be considered normal operation.
Fan operation
(During Bake Mode)
This is to ensure even baking results.
• It is normal for the fan to operate periodically throughout a normal bake cycle in the oven.
Problem Possible Cause & Solution
“Crackling” or
“popping” sound
This is the sound of the metal heating and cooling during both the cooking and Self
Clean functions.
• This is normal.
Fan noise A convection fan may automatically turn on and off.
• This is normal.
When lighting just
one burner, clicking
noise is heard from
all the burners.
Electric spark igniters from the burners cause the clicking noise. All the spark igniters
on the cooktop will activate when igniting just one burner.
• This is normal.
Problem Possible Cause & Solution
Trouble connecting
appliance and
smartphone to Wi-Fi
network
The password for the Wi-Fi network was entered incorrectly.
• Delete your home Wi-Fi network and begin the connection process again.
Problem Possible Cause & Solution
81TROUBLESHOOTING
ENGLISH
Trouble connecting
appliance and
smartphone to Wi-Fi
network
Mobile data for your smartphone is turned on.
• Turn off the Mobile data on your smartphone before connecting the appliance.
The wireless network name (SSID) is set incorrectly.
• The wireless network name (SSID) should be a combination of English letters and
numbers. (Do not use special characters.)
The router frequency is not 2.4 GHz.
• Only a 2.4 GHz router frequency is supported. Set the wireless router to 2.4 GHz and
connect the appliance to the wireless router. To check the router frequency, check with
your Internet service provider or the router manufacturer.
The appliance and the router are too far apart.
• If the appliance is too far from the router, the signal may be weak and the connection may
not be configured correctly. Move the router closer to the appliance or purchase and
install a Wi-Fi repeater.
During Wi-Fi setup, the app is requesting a password to connect to the product (on
certain phones).
• Locate the network name which starts with "LG" under Settings > Networks. Note the last
part of the network name.
- If the network name looks like LGE_Appliance_XX-XX-XX, enter lge12345.
- If the network name looks like LGE_Appliance_XXXX, enter XXXX twice as your password.
For example, if the network name appears as LGE_Appliance_8b92, then you would
enter 8b928b92 as your password. In this instance, the password is case sensitive and
the last 4 characters are unique to your appliance.
Problem Possible Cause & Solution
82 LIMITED WARRANTY
LIMITED WARRANTY
USA
TERMS AND CONDITIONS
ARBITRATION NOTICE: THIS LIMITED WARRANTY CONTAINS AN ARBITRATION PROVISION THAT
REQUIRES YOU AND LG ELECTRONICS (“LG”) TO RESOLVE DISPUTES BY BINDING ARBITRATION
INSTEAD OF IN COURT, UNLESS YOU CHOOSE TO OPT OUT. IN ARBITRATION, CLASS ACTIONS AND
JURY TRIALS ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING
DISPUTES” BELOW.
Should your LG Gas Range ("Product") fail due to a defect in materials or workmanship under normal and
proper use, during the warranty period set forth below, LG will, at its option, repair or replace the Product.
This limited warranty is valid only to the original retail purchaser of the Product (“You”) and applies only
when purchased lawfully and used within the United States including U.S. Territories.
• Replacement Products and parts are warranted for the remaining portion of the original warranty period
or ninety (90) days, whichever is greater.
• Replacement Products and parts may be new, reconditioned, refurbished, or otherwise factory
remanufactured.
• Replaced Product or part(s) will be the property of LG.
• Proof of original retail purchase specifying the Product model and date of purchase is required to obtain
warranty service under this limited warranty.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THE PRODUCT IS LIMITED IN
DURATION TO THE DURATION OF THE ABOVE LIMITED WARRANTY. UNDER NO CIRCUMSTANCES
SHALL LG OR ITS U.S. DISTRIBUTORS/DEALERS BE LIABLE FOR ANY INDIRECT, INCIDENTAL,
CONSEQUENTIAL, SPECIAL, OR PUNITIVE DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST
GOODWILL, LOST REVENUES OR PROFITS, WORK STOPPAGE, IMPAIRMENT OF OTHER GOODS, COST OF
REMOVAL AND REINSTALLATION OF THE PRODUCT, LOSS OF USE, OR ANY OTHER DAMAGES WHETHER
BASED IN CONTRACT, TORT, OR OTHERWISE. LG’S TOTAL LIABILITY, IF ANY, SHALL NOT EXCEED THE
PURCHASE PRICE PAID BY YOU FOR THE PRODUCT.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES OR LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU. THIS LIMITED WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
THIS LIMITED WARRANTY DOES NOT COVER:
• Service trips to deliver, pick up, or install, educate how to operate, correct wiring, or correct
unauthorized repairs.
• Damage or failure of the Product to perform during power failures and interrupted or inadequate
electrical service.
• Damage or failure of the Product caused by leaky or broken water pipes, frozen water pipes, restricted
drain lines, inadequate or interrupted water supply or inadequate supply of air.
• Damage or failure of the Product resulting from operating the Product in a corrosive atmosphere or
contrary to the Product owner’s manual.
Warranty Period Scope of Warranty HOW SERVICE IS HANDLED
Two (2) years from the
date of original retail
purchase, or from the
date of delivery as per
applicable law
Parts and Labor (internal
/ functional parts only)
LG will provide, free of charge, all labor and in-home
service to replace defective part(s).
83LIMITED WARRANTY
ENGLISH
• Damage or failure of the Product caused by accidents, pests and vermin, lightning, wind, fire, floods, acts
of nature, or any other causes beyond the control of LG.
• Damage or failure of the Product caused by unauthorized modification or alteration, or if the Product is
used for other than the intended purpose, or any water leakage where the Product was not properly
installed.
• Damage or failure of the Product caused by incorrect electrical current, voltage, or plumbing codes.
• Damage or failure of the Product caused by transportation, storage, and/or handling, including
scratches, dents, chips, and/or other damage to the finish of the Product, unless such damage is
reported within one (1) week of delivery.
• Damage or failure of the Product resulting from misuse, abuse, improper installation, repair, or
maintenance. Improper repair includes the use of parts not authorized by LG. Improper installation or
maintenance includes installation or maintenance contrary to the Product owner’s manual.
• Damage or failure of the Product caused by the use of parts, components, accessories, consumable
cleaning products, or any other products or services that were not authorized by LG.
• Damage or missing items to any display or open box Product.
• Refurbished Product or any Product sold “As Is”, “Where Is”, “With all Faults”, or similar disclaimer.
• Products with original serial numbers that have been removed, altered, or cannot be readily determined.
• Increases in utility costs and additional utility expenses.
• Any noises associated with normal operation.
• Products used for other than normal and proper household use (e.g., commercial, business, or industrial
settings, including any retail or food service establishments, or any commercial lodging/transient rental
setting), or any use contrary to the Product owner's manual.
• Costs associated with removal and reinstallation of the Product for repairs, or the removal and
reinstallation of the Product if it is installed in an inaccessible location or not installed in accordance with
the Product Owner's manual.
• Accessories, removable components, or consumable parts (e.g. Shelves, door bins, drawers, water/air
filters, racks, light bulbs, batteries, etc., as applicable), except for internal/functional parts covered under
this limited warranty.
• Cost of conversion of the Product from natural gas to LP gas or vice versa.
Not Covered by this Limited Warranty
Problem Possible Cause & Prevention
Burners do not
light.
Clogged or dirty burner ports or electrodes will not allow the burner to operate
properly.
a OK
b Not working (must be cleaned)
• Check and clean the gas electrode.
84 LIMITED WARRANTY
Uneven flame Improper burner cap installation
a Burner cap is properly seated.
b Burner cap is NOT properly seated.
• Check installation of burner head and cap.
Burner ports clogged by food residue
c Ports blocked by dirt
d Flames uneven
• Hardened residue should be removed using a toothbrush.
Burner cap color
change and lost
shine
Scratching
• Do not use steel wool or abrasive cleansers to clean.
Use of detergent or abrasive cleansers
• To remove burnt-on food, soak the burner heads in hot water for 20–30 minutes.
(Do not use detergent)
a Shine is lost.
Knobs melt Improper usage
• Do not leave door at stop position during Broil/Bake mode or right after cooking.
Oven or racks are
stained after
using aluminum
foil
Aluminum foil has melted in the oven
• Never cover the oven bottom or cover an entire rack with materials such as
aluminum foil.
• If the foil has already melted onto the oven, it will not affect the performance of
the oven.
Problem Possible Cause & Prevention
85LIMITED WARRANTY
ENGLISH
Flame or power is
weak
Gas pressure may be weak
• Check with gas supplier first.
Surface is not level
Oven is tipping
Range not leveled
• Check with installer first.
• Use carpenter’s level a to check level.
Anti-tip device not installed correctly
a Approximately 0.65" (16.5 mm)
b Level both sides of range
c Screw must enter wood or concrete
d Anti-tip bracket
e Wall plate
• Check with installer first.
Oven shows error
code (F9, F19) but
cooktop burners
are working.
The gas pressure regulator valve is closed.
a Lever’s closed position
• Check that the regulator valve is in the open position.
• If the regulator valve is closed, rotate the lever to open the valve.
b Lever’s closed position
c Lever’s open position
Problem Possible Cause & Prevention
86 LIMITED WARRANTY
The cost of repair or replacement under these excluded circumstances shall be borne by You.
Flames too big on
converted cooktop
(NP
~LP)
The installer missed part of the conversion. (Check 3 parts: regulator, cooktop
valve, broil/bake valve.)
a Regulator
b Cooktop valve
c Broil/Bake valve
• Check with installer first.
• Refer to installation manual.
Flame is too small
or too large
1. Variable gas pressure
2. Installer did not check
• Check with installer first.
Gas smell Improper connection
Flexible Connector Hookup
a Pressure regulator
b 1/2" Adapter
c Gas Flow into Range
d Flex connector (6 ft. max.)
e Gas shut-off valve
f 1/2" or 3/4" Gas pipe
• Check with installer first.
Problem Possible Cause & Prevention
87LIMITED WARRANTY
ENGLISH
TO OBTAIN WARRANTY SERVICE AND ADDITIONAL INFORMATION
Call 1-800-243-0000
and select the appropriate option from the menu.
Or visit our website at http://www.lg.com
Or by mail: LG Electronics Customer Service P.O. Box 240007 Huntsville, AL 35813 ATTN: CIC
PROCEDURE FOR RESOLVING DISPUTES:
ALL DISPUTES BETWEEN YOU AND LG ARISING OUT OF OR RELATING IN ANY WAY TO THIS LIMITED
WARRANTY OR THE PRODUCT SHALL BE RESOLVED EXCLUSIVELY THROUGH BINDING ARBITRATION, AND
NOT IN A COURT OF GENERAL JURISDICTION. BINDING ARBITRATION MEANS THAT YOU AND LG ARE EACH
WAIVING THE RIGHT TO A JURY TRIAL AND TO BRING OR PARTICIPATE IN A CLASS ACTION.
Definitions. For the purposes of this section, references to “LG” mean LG Electronics U.S.A., Inc., its
parents, subsidiaries and affiliates, and each of their officers, directors, employees, agents, beneficiaries,
predecessors in interest, successors, assigns and suppliers; references to “dispute” or “claim” shall include
any dispute, claim or controversy of any kind whatsoever (whether based in contract, tort, statute,
regulation, ordinance, fraud, misrepresentation or any other legal or equitable theory) arising out of or
relating in any way to the sale, condition or performance of the product or this Limited Warranty.
Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must first notify
LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LG at LG
Electronics, USA, Inc. Attn: Legal Department- Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632.
You and LG agree to engage in good faith discussions in an attempt to amicably resolve your claim. The
notice must provide your name, address, and telephone number; identify the product that is the subject of
the claim; and describe the nature of the claim and the relief being sought. If you and LG are unable to
resolve the dispute within 30 days, either party may proceed to file a claim for arbitration.
Agreement to Binding Arbitration and Class Action Waiver. Upon failure to resolve the dispute during
the 30 day period after sending written notice to LG, you and LG agree to resolve any claims between us
only by binding arbitration on an individual basis, unless you opt out as provided below. Any dispute
between you and LG shall not be combined or consolidated with a dispute involving any other person’s or
entity’s product or claim. More specifically, without limitation of the foregoing, any dispute between you
and LG shall not under any circumstances proceed as part of a class or representative action. Instead of
arbitration, either party may bring an individual action in small claims court, but that small claims court
action may not be brought on a class or representative basis.
Arbitration Rules and Procedures. To begin arbitration of a claim, either you or LG must make a written
demand for arbitration. The arbitration will be administered by the American Arbitration Association
(“AAA”) and will be conducted before a single arbitrator under the AAA’s Consumer Arbitration Rules that
are in effect at the time the arbitration is initiated (referred to as the “AAA Rules”) and under the
procedures set forth in this section. The AAA Rules are available online at www.adr.org/consumer
. Send a
copy of your written demand for arbitration, as well as a copy of this provision, to the AAA in the manner
described in the AAA Rules. You must also send a copy of your written demand to LG at LG Electronics,
USA, Inc. Attn: Legal Department- Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632. If there is a
conflict between the AAA Rules and the rules set forth in this section, the rules set forth in this section will
govern. This arbitration provision is governed by the Federal Arbitration Act. Judgment may be entered on
the arbitrator’s award in any court of competent jurisdiction. All issues are for the arbitrator to decide,
except that issues relating to the scope and enforceability of the arbitration provision and to the
arbitrability of the dispute are for the court to decide. The arbitrator is bound by the terms of this
provision.
Governing Law. The law of the state of your residence shall govern this Limited Warranty and any
disputes between us except to the extent that such law is preempted by or inconsistent with applicable
federal law.
Fees/Costs. You do not need to pay any fee to begin an arbitration. Upon receipt of your written demand
for arbitration, LG will promptly pay all arbitration filing fees to the AAA unless you seek more than $25,000
in damages, in which case the payment of these fees will be governed by the AAA Rules. Except as
otherwise provided for herein, LG will pay all AAA filing, administration and arbitrator fees for any
arbitration initiated in accordance with the AAA Rules and this arbitration provision. If you prevail in the
arbitration, LG will pay your attorneys’ fees and expenses as long as they are reasonable, by considering
88 LIMITED WARRANTY
factors including, but not limited to, the purchase amount and claim amount. Notwithstanding the
foregoing, if applicable law allows for an award of reasonable attorneys’ fees and expenses, an arbitrator
can award them to the same extent that a court would. If the arbitrator finds either the substance of your
claim or the relief sought in the demand is frivolous or brought for an improper purpose (as measured by
the standards set forth in Federal Rule of Civil Procedure 11(b)), then the payment of all arbitration fees will
be governed by the AAA Rules. In such a situation, you agree to reimburse LG for all monies previously
disbursed by it that are otherwise your obligation to pay under the AAA Rules. Except as otherwise
provided for, LG waives any rights it may have to seek attorneys’ fees and expenses from you if LG prevails
in the arbitration.
Hearings and Location. If your claim is for $25,000 or less, you may choose to have the arbitration
conducted solely on the basis of (1) documents submitted to the arbitrator, (2) through a telephonic
hearing, or (3) by an in-person hearing as established by the AAA Rules. If your claim exceeds $25,000, the
right to a hearing will be determined by the AAA Rules. Any in-person arbitration hearings will be held at a
location within the federal judicial district in which you reside unless we both agree to another location or
we agree to a telephonic arbitration.
Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can
require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no
later than 30 calendar days from the date of the first consumer purchaser’s purchase of the product by
either: (i) sending an e-mail to [email protected]
, with the subject line: “Arbitration Opt Out” or (ii) calling 1-
800-980-2973. You must include in the opt out e-mail or provide by telephone: (a) your name and address;
(b) the date on which the product was purchased; (c) the product model name or model number; and (d)
the serial number (the serial number can be found (i) on the product; or (ii) online by accessing https://
www.lg.com/us/support and clicking on “How do I find my model number?”).
You may only opt out of the dispute resolution procedure in the manner described above (that is, by e-mail
or telephone); no other form of notice will be effective to opt out of this dispute resolution procedure.
Opting out of this dispute resolution procedure will not affect the coverage of the Limited Warranty in any
way, and you will continue to enjoy the full benefits of the Limited Warranty. If you keep this product and
do not opt out, then you accept all terms and conditions of the arbitration provision described above.
Memo
Memo
Memo
