USAGE INTRODUCTIONHANDBOOK
FCC Warning
This device complies with part 15 of the FCC Rules.Operation is subject to the following two condi-
tions:(1)This device may not cause harmful interference,and (2)this device must accept any interfer-
ence received,including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device,pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protec-
tion
against harmful interference in a residential installation.This equipment generates uses and can
radiate radio frequency energy and,if not installed and used in accordance with the instructions,may
cause harmful interference to radio communications.However,there is no guarantee that interference
will not
occur in a particular installation.If this equipment does cause harmful interference to radio or televi-
sion
reception,which can be determined by turning the equipment off and on,the user is encouraged to
try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
*RF warning for Portable device:
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
PREVENTCHILDREN
FROMSWALLOWING
INTRODUCTIONAND PRECAUTIONS FOR BATTERY INSTALLATION
1.Remote control car using 1 section of 3.7V(1200mAh)rechargeable lithium battery.The remote control uses 2x
1.5VAA non-rechargeable batteries.
2.Only use the same or the samebattery as the recommended battery.
3.Please pay attention to the polarity when installing or replacing the battery,and the battery should not be short-circuited.
4.Non-rechargeable batteries are not rechargeable.
5.Do not mix the old and new batteries or different types of batteries.
6.Remove the exhausted batteries from the toy.
7
8
.
.
T
R
h
e
e
c
h
p
a
o
r
wer t
geab
e
l
rm
e b
i
n
a
t
a
t
e
l
r
s
i
h
e
o
s
u
c
l
n
not
on
ly
b
e
be
s
h
c
o
h
rt
a
r
-
c
g
ir
e
c
d
u
ed
nd
e
.
r adult supervision;do not let childrencharge themselves.
Rechargeable batteries should be removed from the toy before charging.
9.Toys cannot be connected to more than the recommended number of power sources.
10.USB power cable must be regularly checked for damage to its wires,plugs,shellsand other components,if found
damaged should stop usng until the reparis complete.
11.Products can only use the recommended USB power cable;the USB power cable is not a toy.
FORWARD: BACKWARD:
A+BCONTROL LEVER UP A+BCONTROL LEVER DOWN
A-POLE UP:
TURNRIGHTFORWARD
A-POLE DOWN:
TURN RIGHT BACKWARD
LIGHTINGCONTROL PUSHSWITCH ONE-CLICK DEMO
Amphibious gameplay,allowing for both land travel and free navigation in water
Unscrew the screw
Remove the alloy steel plate
1.Installbatteries on the vehicle body,install batteries
on the remote control,and turn on the switches separately
2.If the red light on the remote control does not flash,
it indicates successful frequency pairing.
60 seconds unpaired wll enter sleep mode
(You can press any key to re-pair).
REMOTECONTROLFUNCTION
Uses 2“AA”size batteries
B-POLE UP:
TURN LEFTFORWARD
B-POLE DOWN:
TURN LEFT BACKWARD
Replace the steel plate and tighten
the screws back
Rotate the locking buckles on both
sides to remove the battery cover
210
mm
Both sides are likethis
LIGHT
4WD
12.In the power supply process,the USB power cable will appear slightly warm,a normal phenomenon.
AGES
-Consult the dealer or an experienced radio/TV technician for help.
USAGE INTRODUCTION HANDBOOK
REMOTECONTROL USAGEINSTRUCTIONS
FEREQUENCYOPERATIONSTEPS:
ON/OFF
M
renarge Batey?omuded)
THE RED LIGHT ISALWAYSON
(PAIRING iSsUCCESSFUL)
(PAIRING FAILED)
13.USB power cable can only be connected to a charger with an output voltage of 5.0V.
