MANUAL 10011-SB REV 0 (11/21)
$21.00
ELECTRIC COUNTER TILTING SKILLET
MANUAL SECTION CO
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #:
___________________________
Serial #:
___________________________
Date Purchased:
_____________________
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury
or death. Read the installation, operating and maintenance instructions thoroughly before installing or
servicing this equipment.
Model BECT-12
Electric Counter Tilting Skillet
BECT-12
Installation & Operation Manual
SOUTHBEND STEAM
A Middleby Company
1100 Old Honeycutt Road Fuquay-Varina, North Carolina 27526 USA
www.southbendnc.com
INSTALLATION & OPERATION MANUAL 10011-SB REV 0 (11/21)
PAGE
2
OF 12
Electric Counter Tilting Skillet
SAFETY PRECAUTIONS
Before installing and operating this equipment, be sure everyone involved in its operation is fully trained and aware of
precautions. Accidents and problems can be caused by failure to follow fundamental rules and precautions.
The following symbols, found throughout this manual, alert you to potentially dangerous conditions to the operator,
service personnel, or to the equipment.
CAUTION
WARNING
NOTICE
This symbol warns of immediate hazards that will result in severe injury or death.
This symbol refers to a potential hazard or unsafe practice that could result in injury or death.
This symbol refers to a potential hazard or unsafe practice that could result in injury, product
damage, or property damage.
This symbol refers to information that needs special attention or must be fully
understood, even though not dangerous.
DANGER
WARNING
Improper installation, operation, adjustment, alteration, service or maintenance can cause property damage, injury or death.
Read the installation, operating and maintenance instructions thoroughly before installing, operating or servicing this equipment.
NOTICE
This manual should be retained for future reference.
NOTICE
This product is intended for commercial use only. NOT FOR HOUSEHOLD USE.
Copyright © 2021 by Southbend Steam. All rights reserved. Published in the United States of America.
SPECIFICATIONS
IMPORTANT NOTES FOR INSTALLATION AND OPERATION
WARNING
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
WARNING
FOR YOUR SAFETY:
Do not store or use gasoline or other ammable vapors or liquids in the vicinity of this or any other appliance.
NOTICE
Do not attempt to operate this unit in the event of a power failure.
NOTICE
Adequate clearances MUST be maintained for servicing and proper operation.
NOTICE
Contact the factory, the factory representative or a local service company to perform maintenance and repairs
should the appliance malfunction. Refer to warranty terms.
INSTALLATION & OPERATION MANUAL 10011-SB REV 0 (11/21)
PAGE
3
OF12
Electric Counter Tilting Skillet
RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Table of Contents
Important Notes For Installation and Operation .................................................................... 2
Service Connections ............................................................................................................. 4
Installation Instructions ......................................................................................................... 6
Operating Instructions ........................................................................................................... 8
Cleaning ................................................................................................................................ 9
Maintenance ......................................................................................................................... 10
Troubleshooting .................................................................................................................... 11
Table of Contents
INSTALLATION & OPERATION MANUAL 10011-SB REV 0 (11/21)
PAGE
4
OF 12
Electric Counter Tilting Skillet
Service Connections
Service Connections
As continued product improvement is a policy of Southbend Steam, specications are subject to changge without notice.
ELECTRICAL CHARACTERISTICS AND SPECIFICATIONS
CAPACITY AND DIMENSIONS
SERVICE CONNECTIONS
– ELECTRICAL CONNECTION: To be as specied on units Data Plate.
Model Capacity A B C D E F G H J K L M N
BECT-12
12 Gallons
(45 liters)
29”
(737)
16.75”
(425)
4”
(102)
2”
(51)
24”
(610)
25.75”
(654)
5.5”
(140)
12.5”
(318)
20”
(508)
13”
(330)
10.5”
(267)
33.25”
(845)
7”
(178)
Model Phase
208V 220V 240V 380V 415V 480V
kW Amp kW Amp kW Amp kW Amp kW Amp kW Amp kW Amp
BECT-12
1 9.0 43.3 9.0 40.9 9.0 37.5 -- -- -- -- -- -- -- --
3 9.0 25.0 9.0 23.6 9.0 21.7 9.0 13.7 9.0 12.5 9.0 10.8 9.0 8.7
Model
Shipping
Weight
Minimum
Clearance
BECT-12
191 lbs.
(87 kg)
Sides
6”
(152)
Back
6”
(152)
INSTALLATION & OPERATION MANUAL 10011-SB REV 0 (11/21)
PAGE
5
OF12
Electric Counter Tilting Skillet
Unpacking
IMMEDIATELY INSPECT FOR SHIPPING DAMAGE
Immediately after unpacking, check for possible shipping damage. If the gas red tilting skillet is found to be damaged,
save the packaging material and contact the carrier within 5 days of delivery.
Before installing, verify that the type of gas supply (natural or propane) and electrical service agree with the
specications on the rating plate located on the left side console as you face the front of the appliance. If the supply and
equipment requirements do not agree, contact your dealer immediately.
Installation Instructions
WARNING
ELECTRICAL GROUNDING INSTRUCTIONS
Units equipped with a three-prong (grounding) plug for your protection against shock hazard and should be plugged directly
into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug. (120 volt units only).
Installation
Installation Instructions
1. Position appliance on counter allowing sucient rear clearance from wall to tilt freely and completely without
obstruction.
2. Mark four corner locations of appliance base, as shown below.
3. Remove appliance from counter and locate position of four holes as per drawing detailed below. Drill four 7/16” diameter holes.
4. Apply a continuous bead of Silastic or other equivalent sealant along the complete perimeter edge of the appliance base.
5. Use 5/16-18 Hex Cap Screws with suitable at washers to bolt down. Screw length must be 1-1/4 long plus counter
top thickness.
6. Wipe o excess sealant.
7. A Control Box with power supply equivalent to Electrical Rating of appliance should be located conveniently nearby.
8. A waterproof electrical connection for power supply to console housing must be provided.
9. Ground appliance to terminal provided inside console housing.
10. Turn power ON and check for proper operation.
INSTALLATION & OPERATION MANUAL 10011-SB REV 0 (11/21)
PAGE
6
OF 12
Electric Counter Tilting Skillet
Operating Instructions
Operating Instructions
1. Ensure that unit has been electrically connected and that circuit breakers are on.
2. Place power switch in “ON” position.
3. Set the thermostat dial to high (#10).
4. Preheat the unit and allow it to cycle thus equalizing heat across the entire surface.
5. Cooking should be done at various temperature settings on the dial as determined by the user.
6. Water will boil faster with the optional cover on.
7. Check that skillet optional level bar, on right side of control panel, moves in and out easily. This bar provides two set
positions, level and slightly tilted.
8. At end of cooking, return thermostat to “OFF” position, turn power switch “OFF”, remove food and allow to soak for
ease of cleaning.
Tilting Instructions
Your skillet has the a “Tilt Lock” feature and may not be tilted without disengaging the tilt knob located on the console at
the top right. This feature locks the kettle in the upright position. Follow these steps to tilt kettle:
1. Pull out the tilt knob at the top right of console.
2. Using tilt handle, pull skillet forward to desired angle of pour. The tilt knob can be released after the skillet has been
tilted approximately 10 degrees.
3. Upon returning the skillet to the upright position, the tilt lock will engage and locks in the upright position. The skillet
should not move in either direction once in the upright position.
Cooking Surface Positions
Your skillet is capable of cooking in two positions, at or inclined. Cooking in the inclined position allows oils or sauces to
collect at the front of the pan while providing a dry cooking surface towards the rear.
CAUTION
The Tilt Lock feature will not be engaged while cooking in the inclined position.
Operation
To cook in the inclined position:
1. Disengage the Tilt Lock and tilt the skillet forward.
2. Release the Tilt Lock knob and push the knob in on the right
side of the console to cook in the inclined position.
3. Lower the skillet down to rest in the inclined cooking position.
Thermostat Settings
Simmering 1 - 4 (200 F)
Sautéing 5 - 6 (225 - 275 F)
Searing 7 - 8 (300 - 350 F)
Pan Frying 8 - 9 (325 - 375 F)
Grilling 9 - 10 (350 - 425 F)
INSTALLATION & OPERATION MANUAL 10011-SB REV 0 (11/21)
PAGE
7
OF12
Electric Counter Tilting Skillet Cleaning
Cleaning
WARNING
Disconnect the power supply to the appliance before cleaning or servicing.
WARNING
The appliance and its parts are hot. Use care when operating, cleaning and servicing the kettle.
Cleaning Instructions
1. The Electric Counter Tilting Skillet should be cleaned after each use.
2. Soak cooking surface with water and a mild soap to remove any food stuck to surface.
3. Wash entire unit surface with mild detergent and water. Rinse entire unit and dry.
CAUTION
Do not use cleaning agents that are corrosive.
WARNING
Do not get water in electrical components.
4. Check that pour spout, strainer, cover and sides of unit are cleaned as above.
INSTALLATION & OPERATION MANUAL 10011-SB REV 0 (11/21)
PAGE
8
OF 12
Electric Counter Tilting SkilletTroubleshooting
Troubleshooting
Unit Will Not Operate
1. Power supply not “ON”.
2. Defective thermostat or elements
Pan Difficult to Tilt
1. Tilt knob not disengaged.
2. Dirt in oilite bearings causing them to bind.
NOTICE
Never grease or oil the pivot bearings as this may cause problems with tilting.
Bearings are oilite and never require lubrication.
INSTALLATION & OPERATION MANUAL 10011-SB REV 0 (11/21)
PAGE
9
OF12
Electric Counter Tilting Skillet
Notes
INSTALLATION & OPERATION MANUAL 10011-SB REV 0 (11/21)
PAGE
10
OF 12
Electric Counter Tilting Skillet
Notes
INSTALLATION & OPERATION MANUAL 10011-SB REV 0 (11/21)
PAGE
11
OF12
Electric Counter Tilting Skillet
Notes
INSTALLATION & OPERATION MANUAL 10011-SB REV 0 (11/21)
PAGE
12
OF 12
Electric Counter Tilting Skillet
BECT-12
Electric Counter Tilting Skillet
A product with the Southbend Steam name incorporates the best in durability and low maintenance. We all recognize,
however, that replacement parts and occasional professional service may be necessary to extend the useful life of this
appliance. When service is needed, contact a Southbend Steam Authorized Service Agency, or your dealer. To avoid
confusion, always refer to the model number, serial number, and type of your appliance.
SOUTHBEND STEAM
A Middleby Company
1100 Old Honeycutt Road Fuquay-Varina, North Carolina 27526 USA
www.southbendnc.com
