REVISED BULLETIN
SERVICE PARTS LIST
BULLETIN NO.
DATE
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
CATALOG NO.
MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
PN0003524
M12™ BATTERIES
48-11-2401, 48-11-2402, 48-11-2420, 48-11-2425,
48-11-2430, 48-11-2440, 48-11-2450, 48-11-2460
Oct. 2024
M12
TM
CP
Batteries
Cat. Nos.
48-11-2401
48-11-2420
48-11-2430
M12
TM
XC
Batteries
Cat. Nos.
48-11-2402
48-11-2440
48-11-2450
(HIGH OUTPUT
TM
)
48-11-2460
M12
TM
CP HIGH
OUTPUT
TM
Battery
Cat. No.
48-11-2425
1
2
3
1
4
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 --------------- CP Service Nameplate (1)
2 10-15-0965 CP Warning Label (1)
3 10-20-8925 CP HIGH OUTPUT Warning Label (1)
(for 48-11-2425 battery only)
4 12-20-2498 XC Service Nameplate (1)
FIG. NOTES
2,3,4 A clean, dry surface is essential for proper performance for any
adhesive system. The area intended for application of any adhesive
label or nameplate must be prepared by cleaning with isopropyl
alcohol. The solvent is to be applied with a clean, lint free applicator
and the surface allowed to dry before applying the label or nameplate.
TRANSPORT NOTE:
Personal transport of Li-Ion battery packs is allowed when done in
accordance with these warnings and instructions. The proper classication,
packaging, labeling, marking, and documentation requirements for shipping
Li-Ion batteries is dependent upon whether the particular batteries are rated
greater than or less than 100 Wh. Generally, Li-Ion batteries rated 100 Wh
or less are "excepted" from certain Class 9 DG requirements. Always check
compliance of Li-Ion battery consignments against the current regulations
governing the chosen mode of transport. When in doubt, contact the carrier
or another trained Dangerous Goods professional to conrm acceptibility.
Li-Ion packs are shipped under classication UN 3480 (battery only) or UN
3481 (batteries contained in or packed with equipment).
