User Guide
Quality, Design and Innovation
home.liebherr.com/fridge-manuals
Contents
1 General safety instructions.................................. 3
2 The appliance at a glance..................................... 4
2.1 Delivered contents....................................................... 4
2.2 Overview of appliances and equipment................... 4
2.3 SmartDevice.................................................................. 5
2.4 Range of appliance use............................................... 5
2.5 Conformity..................................................................... 5
2.6 SVHC substances according to REACH regulation. 5
2.7 EPREL Database........................................................... 5
2.8 Spare parts.................................................................... 5
3 Functionality of the Touch&Swipe display......... 5
3.1 Navigation and symbol explanation......................... 5
3.2 Menus............................................................................. 6
3.3 Sleep mode................................................................... 7
4 Start-up................................................................. 7
4.1 Switching on appliance (first use)............................ 7
5 Storage.................................................................. 7
5.1 Information regarding storage................................... 7
5.2 Fridge compartment.................................................... 7
5.3 BioFresh......................................................................... 8
5.4 Storage times............................................................... 8
6 Energy saving........................................................ 9
7 Use......................................................................... 9
7.1 Controls and displays.................................................. 9
7.1.1 Status display..............................................................9
7.1.2 Display symbols.......................................................... 9
7.2 Appliance functions..................................................... 9
7.2.1 Notes on the appliance functions............................9
Switching appliance off and on.............................. 9
WiFi............................................................................ 10
Temperature.............................................................. 11
Temperature unit...................................................... 11
BioFresh B-Value ..................................................... 11
D-Value.......................................................................12
SuperCool..................................................................12
PartyMode ................................................................ 12
HolidayMode............................................................. 13
SabbathMode............................................................13
EnergySaver .............................................................14
CleaningMode...........................................................14
Display Brightness...................................................14
Door alarm.................................................................15
Input lock...................................................................15
Language...................................................................15
Appliance information.............................................16
Software.................................................................... 16
Reminder................................................................... 16
Demo mode............................................................... 17
Resetting to factory settings................................. 17
7.3 Messages...................................................................... 18
7.3.1 Overview of warnings...............................................18
7.3.2 Ending warnings....................................................... 18
7.3.3 Overview of reminders............................................. 18
7.3.4 Ending reminders......................................................18
8 Equipment............................................................. 19
8.1 Variable bottle shelf.................................................... 19
8.2 Drawers.......................................................................... 19
8.3 Lid for Fruit & Vegetable-safe.................................... 20
8.4 Butter dish.................................................................... 21
8.5 Egg rack......................................................................... 21
8.6 FlexSystem.................................................................... 21
9 Maintenance.......................................................... 22
9.1 FreshAir carbon filter................................................... 22
9.2 Disassembling / assembling pull-out systems...... 22
9.3 Removing / inserting the variable bottle shelf....... 23
9.4 Lid for Fruit & Vegetable-safe.................................... 23
9.5 Defrosting the appliance............................................ 24
9.6 Cleaning the appliance............................................... 24
10 Customer support................................................. 24
10.1 Technical specifications............................................. 24
10.2 Operating noises.......................................................... 25
10.3 Technical faults............................................................ 25
10.4 Customer Service......................................................... 26
10.5 Rating plate................................................................... 26
11 Decommissioning.................................................. 27
12 Disposal................................................................. 27
12.1 Preparing appliance for disposal.............................. 27
12.2 Disposing of the appliance in an environmentally
friendly manner............................................................ 27
The manufacturer is constantly working to improve all types
and models. Therefore, please be aware that we reserve the
right to make changes to the shape, equipment and tech‐
nology.
Symbol
Explanation
Read instructions
Please read the information in these instruc‐
tions carefully to understand all of the benefits
of your new appliance.
2 * Depending on model and options
Symbol Explanation
Additional information online
The digital manual with supplemental informa‐
tion and in additional languages can be found
online by scanning the QR code on the front
page of this manual or by entering the service
number at home.liebherr.com/fridge-
manuals.
The service number can be found on the serial
tag:
Fig.Example illustration
Check appliance
Check all parts for transport damage. If you
have any complaints, please contact your
agent or customer service.
Differences
These instructions apply to a range of models,
so there may be differences. Sections that
apply to certain models only are indicated by
an asterisk (*).
Instructions and results
Instructions are marked with a .
Results are marked with a .
Videos
Videos about the appliances are available on
the YouTube channel of Liebherr-Hausgeräte.
Open-source licenses:
The appliance includes software components that make
use of open-source licenses. You can find information on
the open-source licenses to be used here:
home.liebherr.com/open-source-licenses
These operating instructions apply to:
IRBP..i
5170
IRBPbsci 5170
1 General safety instructions
Please keep these operating instructions in a safe place so
you can refer back to them at any time.
If you pass the appliance on, please hand these operating
instructions to the new owner.
Read these operating instructions before use in order to use
the appliance safely and correctly. Follow the instructions,
safety instructions and warning messages included at all
times. They are important for ensuring you can operate and
install the appliance safely and without any problems.
Dangers for the user:
-
This appliance is suitable for use by children and persons
with reduced physical, sensory or mental capacities or
lack of experience and skills provided they are supervised
or have been instructed on the safe use of the appliance
and understand the hazards involved.
Children must not play with the appliance. Children must
not be allowed to clean or perform any user maintenance
without supervision. Children between the ages of 3-8
must not load or unload the appliance. Keep children
under the age of 3 away from the appliance if they are
not consistently supervised.
-
The socket must be easily accessible so that the appli‐
ance can be disconnected quickly from the electricity in
an emergency. It must not be located in the area behind
the appliance.
-
When disconnecting the appliance from the outlet,
always take hold of the plug. Do not pull on the cable.
-
Disconnect the power plug or switch off the power if a
fault occurs.
-
Do not damage the mains power line. Do not operate the
appliance from a defective mains power line.
-
Repairs and work on the appliance may only be carried
out by after sales service or other specifically trained
qualified personnel.
-
Only install, connect and dispose of the appliance in
accordance with the instructions.
-
Only operate the appliance after it has been installed.
Risk of fire:
-
The refrigerant contained within the appliance (specifica‐
tions on the rating plate) is environmentally friendly, but
flammable. Leaking refrigerant can ignite.
•
Do not damage the pipes of the refrigerant circuit.
•
Do not handle ignition sources inside the appliance.
•
Do not use electrical devices inside the appliance (e.g.
steam cleaners, heaters, ice cream makers, etc.).
•
If refrigerant leaks: Remove naked flames or ignition
sources located near the area of the leak. Air the room
well. Contact the customer service department.
-
Do not store explosive materials or spray cans with flam‐
mable propellants, such as e.g. butane, propane,
pentane, etc. in the appliance. You can recognize such
spray cans by the printed contents or a flame symbol.
Any leaking gasses can be ignited by electrical compo‐
nents.
-
Keep lit candles, lamps and other objects with naked
flames away from the appliance so they do not cause a
fire.
-
Alcoholic beverages or other containers holding alcohol
must always be tightly sealed for storage purposes. Any
leaking alcohol can be ignited by electrical components
Tipover hazard:
-
Do not stand or climb on the base, drawers, doors, etc.
This applies in particular to children.
Risk of food poisoning:
-
Do not consume food that has passed its best before
date.
Danger of frostbite, feelings of numbness and pain:
-
Avoid prolonged skin contact with cold surfaces or
chilled/frozen food or take protective measures, e.g.
wear gloves.
Risk of injury and damage:
-
Hot steam may lead to injuries. Do not use any electrical
heating or steam cleaning equipment, naked flames or
defrosting sprays for defrosting
-
Do not remove ice with sharp objects
Risk of crushing:
-
Do not reach into the hinge when opening and closing the
door. Fingers may get trapped.
Symbols on the device:
General safety instructions
* Depending on model and options 3
The symbol can be on the compressor. It
refers to the oil in the compressor and
refers to the following danger: Can be
lethal if swallowed or inhaled. This notice
only applies for recycling. There is no
danger during normal operation.
The symbol is located on the compressor
and indicates the danger of inflammable
materials. Do not remove the label.
This label or a similar one may be located
on the rear of the appliance. This label indi‐
cates that there are vacuum insulation
panels (VIP) or perlite panels in the door
and/or housing. This notice only applies for
recycling. Do not remove the label.
Observe the warning messages and other detailed infor‐
mation in the other sections:
DANGER
indicates a hazardous situation,
which if not avoided, will result in
death or serious injury.
WARNING indicates a hazardous situation,
which if not avoided, could result
in death or serious injury.
CAUTION indicates a hazardous situation,
which if not avoided, will result in
minor or moderate injury.
NOTICE indicates a hazardous situation,
which if not avoided, could result
in damage to property.
Note indicates useful advice and tips.
2 The appliance at a glance
2.1 Delivered contents
Check all parts for transport damage. If you have any
complaints, please contact the retailer or customer service.
(see 10.4 Customer Service)
Delivery contains the following parts:
-
Integrated appliance
-
Equipment (depending on your model)
-
Installation parts (depending on your model)
-
“Quick Start Guide”
-
“Installation Guide”
-
Service brochure
2.2 Overview of appliances and equip‐
ment
Fig. 1 Example illustration
Temperature range
(A)
Fridge compartment (C) Coldest zone
(B) BioFresh
Equipment
(1)
Controls (6) Lid for Fruit & Vegetable
safe
(2) Fan with FreshAir acti‐
vated charcoal filter
(7) Fruit & Vegetable safe
(3) Glass drawer (8) Drain hole
(4) Bottle holder (9) Meat & Dairy safe
(5) Variable bottle shelf (10) Type plate
Notes on loading
Fig.2
An individual drawer may
only be loaded to a
maximum of 22 kg.
The total load is a maximum
of 50 kg when you pull all
the drawers out at the
same time.
Note
► The shelves, drawers, and baskets are arranged for
optimal energy efficiency in the factory configuration.
However, changes to the arrangement within the given
insertion options – for example the arrangement of
shelves in the fridge compartment – have no effect on
energy consumption.
The appliance at a glance
4 * Depending on model and options
2.3 SmartDevice
SmartDevice is the networking solution for your refrigerator.
If your appliance is SmartDevice-enabled or compatible, you
can quickly and easily connect your appliance to your WiFi.
With the SmartDevice app, you can operate your appliance
from a mobile device. Additional functions and setting
options are available in the SmartDevice app.
SmartDevice-
enabled appliance:
Your appliance is capable of being a
SmartDevice. To be able to connect
your device to WiFi, you need to
download the SmartDevice app.
More information
about SmartDe‐
vice:
smartdevice.liebherr.com
Downloading the
SmartDevice app:
After you have installed and config‐
ured the SmartDevice app, you can
connect your appliance to your WLAN
using your SmartDevice app the
WLAN device function (seeWiFi) .
Note
The SmartDevice function is not available in the following
countries: Russia, Belarus, Kazakhstan.
2.4 Range of appliance use
Normal use
The appliance is only suitable for cooling food for residential
or other similar environments. This includes the following
types of uses
-
in staff kitchens, bed and breakfasts,
-
by guests in country homes, hotels, motels and other
types of accommodations,
-
for catering and similar wholesale services.
The appliance is not suitable for freezing food;
All other types of uses are not permitted.
Foreseeable misuse
The following uses are specifically prohibited:
-
Storage and cooling of medication, blood plasma, labora‐
tory preparations or similar substances and products in
accordance with the Medical Device Directive
2007/47/EC
-
Use in areas at risk of explosion
Incorrect appliance use can cause damage to the stored
products or cause them to spoil.
Climate ratings
The appliance is set to operate within specific ambient
temperature limits according to its climate rating The
climate rating for your appliance is printed on the rating
plate
Note
► To guarantee trouble-free operation, comply with the
indicated ambient temperatures.
Climate rating for ambient temperatures from
SN 10°C to 32°C
N 16°C to 32°C
ST 16°C to 38°C
T 16°C to 43°C
SN-ST 10°C to 38°C
SN-T 10°C to 43°C
2.5 Conformity
The refrigerant circuit has been tested for leaks. When
installed, the appliance complies with the applicable safety
regulations and with the corresponding directives.
For the EU
market:
The appliance complies with directive
2014/53/EU.
For the GB
market:
The appliance complies with the Radio
Equipment Regulations 2017 SI 2017 No.
1206.
The full text of the EU Declaration of Conformity is available
on the following website: www.Liebherr.com
The BioFresh compartment meets the requirements of a
cold storage compartment as set out in DIN EN 62552:2020.
2.6 SVHC substances according to
REACH regulation
You can check whether your appliance contains SVHC
substances according to REACH regulation at the following
link: home.liebherr.com/de/deu/de/liebherr-erleben/nach‐
haltigkeit/umwelt/scip/scip.html
2.7 EPREL Database
Details about energy labeling and ecodesign requirements
will be available on the European product database (EPREL)
from March 1, 2021. You can access the product database at
the following link: https://eprel.ec.europa.eu/ You will be
asked to enter the model ID. You can find the model ID on
the type plate.
2.8 Spare parts
Spare parts for functional and storable parts of the equip‐
ment are available for 15 years.
3 Functionality of the
Touch&Swipe display
You operate your appliance using the Touch & Swipe display.
You select appliance functions in the Touch & Swipe display
(hereafter referred to as display) by tapping them. If you do
not perform any action on the display for 10 seconds, the
display either jumps back to the higher-level menu or
directly to the status display.
3.1 Navigation and symbol explanation
In the illustrations, different symbols are used to navigate
the display. The following table describes these symbols.
Functionality of the Touch&Swipe display
* Depending on model and options 5
Symbol Description
Briefly touch the display:
Activates/deactivates function.
Confirms selection.
Opens submenu.
Touch the display for a specified time
(e.g. 3seconds):
Activates/deactivates function or
value.
Swipe left or right:
Navigate in the menu.
Briefly touch the Back symbol:
Jumps back one menu level.
Press and hold the Back symbol for
3seconds:
Jumps back to the status display.
Arrow with clock:
It takes more than 10 seconds for the
following message to appear in the
display.
Arrow with a time indication:
It takes the specified amount of time
until the following message appears in
the display.
“Open Settings menu” symbol:
Navigates to the Settings menu and
opens the settings menu.
If necessary: Navigate to the desired
function in the Settings menu.
(see 3.2.1 Opening the Settings menu)
“Open Advanced menu” symbol:
Navigates to the Advanced menu and
opens the advanced menu.
If necessary: Navigate to the desired
function in the Advanced menu.
(see 3.2.2 Opening expanded menu)
No action for
10seconds
If you do not perform any action on the
display for 10 seconds, the display
either jumps back to the higher-level
menu or directly to the status display.
Open door and
close it again.
If you open the door and immediately
close it again, the display jumps
directly back to the status display.
Note: Illustrations of the display are shown in the English
version.
3.2 Menus
The appliance functions are distributed over various menus:
Menu
Description
Main menu When you switch the appliance on, you
are automatically in the main menu.
From here you can navigate to the most
important appliance functions, to the
Settings menu and to the Advanced
menu.
Settings menu
The Settings menu contains additional
appliance functions for setting up your
appliance.
Advanced menu The advanced menu contains special
appliance functions for setting up your
appliance. Access to the Advanced menu
is protected by the numerical code 151.
3.2.1 Opening the Settings menu
Fig. 3 Example illustration
► Carry out action steps according to the illustration.
▷ Settings menu is open.
► If necessary: Navigate to the desired function.
3.2.2 Opening expanded menu
Fig.4
Fig. 5 Example illustration, access with numerical code 151
► Carry out action steps according to the illustration.
▷ Expanded menu is open.
► If necessary: Navigate to the desired function.
Functionality of the Touch&Swipe display
6 * Depending on model and options
3.3 Sleep mode
If you do not touch the display for 1 minute, the display
switches to sleep mode. In sleep mode, the display bright‐
ness is dimmed.
3.3.1 Ending sleep mode
► Touch the display briefly with your finger.
▷ Sleep mode is ended.
4 Start-up
4.1 Switching on appliance (first use)
Make sure that the following requirements are fulfilled:
❑
The appliance is properly installed and connected
according to the installation instructions.
❑
All adhesive strips, adhesive and protective films and
transport locks are removed from inside and on the appli‐
ance.
❑
All marketing leaflets are removed from the drawers.
❑
You are familiar with the functionality of the
Touch & Swipe display. (see 3 Functionality of the
Touch&Swipe display)
Switch on the appliance using the Touch & Swipe display.
► If the display is in sleep mode: Briefly touch the display.
► Carry out action steps according to the illustration.
Fig. 6 Example illustration
▷ Status display appears.
▷ The appliance cools to the temperature set at the factory.
▷ The appliance starts in demo mode (status display with
DEMO appears): If the appliance starts in demo mode,
you can deactivate demo mode within the next 5 minutes.
(seeDemo mode)
More information:
-
Start the SmartDevice for the first time. (see 2.3 Smart‐
Device) and (seeWiFi)
Note
The manufacturer recommends:
► Stock with food: Wait for around 6 hours until the set
temperature is reached.
► Observe the notes on storing food. (see 5.1 Information
regarding storage)
Note
Accessories can be purchased from the Liebherr-Hausg‐
eräte store at home.liebherr.com/shop/de/deu/
zubehor.html.
5 Storage
5.1 Information regarding storage
WARNING
Risk of fire from electrical appliances!
If you use electrical devices in the food area of your appli‐
ance, they may case a fire.
► Do not use electrical devices in the food area of the
appliance if they have not been recommended by the
manufacturer.
Note
Insufficient ventilation results in an increase in energy
consumption and reduction of the refrigerating performance
► Always keep the air slots unobstructed.
Observe the following specifications for storage:
-
Keep the air vents on the fan free.
-
Package or cover foods that readily take on or give off
odors or taste in closed containers.
-
Package raw meat or fish in clean, closed containers.
This will prevent meat or fish from touching or dripping
onto other food.
-
Keep liquids in closed containers.
-
Leave space between goods to ensure good air circula‐
tion.
-
Store food according to the instructions on the pack‐
aging.
-
Always observe the best-before date indicated on the
packaging.
Note
Failure to follow these guidelines can lead to foodstuffs
spoiling.
5.2 Fridge compartment
The air circulation in the appliance creates different temper‐
ature zones. You will find the different temperature zones in
the appliance and equipment overview. (see 2.2 Overview of
appliances and equipment)
5.2.1 Arranging your food properly
Note
Maximum load of a single drawer in the fridge compartment:
22 kg
Maximum load of the fridge compartment when all drawers
are pulled out at the same time: 50 kg
(see2.2 Overview of appliances and equipment)
Start-up
* Depending on model and options 7
Fig. 7 Storage examples
(1)
Butter, eggs (4) Canned food, tins
(2) Yoghurt, quark (5) Bottles, Tetra Paks
(3) Foodstuffs in small
jars or in small cans
► Load drawers according to the size of the groceries.
5.3 BioFresh
BioFresh will extend the storage time for some fresh foods
compared to traditional refrigeration.
Note
If the temperatures drop below 0 °C foods may freeze to
each other.
► Store cold-sensitive produce such as cucumbers,
eggplants, zucchinis and tropical fruit in the fridge
compartment.
5.3.1 Fruit & Vegetable safe
This safe creates a climate of close to 0 °C. The compart‐
ment lid ensures constant levels of humidity. This storage
climate is suitable for storing unpackaged food with high
intrinsic moisture (for example, lettuce, vegetables, fruit).
The humidity in the compartment depends on the moisture
content of the chilled goods placed in it, and also depends
on how often the compartment is opened. You can regulate
the humidity level.
Arranging your food properly
► Store unpackaged fruit and vegetables.
If the humidity is too high:
► Regulate the humidity.
5.3.2 Meat & Dairy safe
This safe creates a storage climate of close to 0 °C. This
storage climate is suitable for more sensitive foods (e.g.
dairy products, meat, fish, sausage).
Arranging your food properly
► Store dry or packaged food.
5.4 Storage times
The storage times given are guidelines
Food with a “use by” date must still be consumed by the
date indicated on the package
5.4.1 Fridge
The best-before date stated on the packaging applies.
5.4.2 BioFresh
Guideline storage times for the Meat & Dairy-Safe
Butter at 1°C up to 90 days
Hard cheese at 1°C up to 110 days
Milk at 1°C up to 12 days
Sausage, cold cuts at 1°C up to 8 days
Poultry at 1°C up to 6 days
Pork at 1°C up to 6 days
Beef at 1°C up to 6 days
Game at 1°C up to 6 days
Note
► Note that higher-protein foods spoil more quickly So,
shellfish and crustaceans perish faster than fish, and fish
perishes faster than meat.
Guideline storage times for the Fruit & Vegetable-Safe
Vegetables, lettuce
Artichokes at 1°C up to 14 days
Celery at 1°C up to 28 days
Cauliflower at 1°C up to 21 days
Broccoli at 1°C up to 13 days
Endives at 1°C up to 27 days
Mâche at 1°C up to 19 days
Peas at 1°C up to 14 days
Kale at 1°C up to 14 days
Carrots at 1°C up to 80 days
Garlic at 1°C up to 160 days
Cabbage turnip at 1°C up to 14 days
Iceberg lettuce at 1°C up to 13 days
Herbs at 1°C up to 13 days
Leeks at 1°C up to 29 days
Mushrooms at 1°C up to 7 days
Radishes at 1°C up to 10 days
Brussels sprouts at 1°C up to 20 days
Asparagus at 1°C up to 18 days
Spinach at 1°C up to 13 days
Savoy cabbage at 1°C up to 20 days
Fruit
Apricots at 1°C up to 13 days
Apples at 1°C up to 80 days
Storage
8 * Depending on model and options
Guideline storage times for the Fruit & Vegetable-Safe
Pears at 1°C up to 55 days
Blackberries at 1°C up to 3 days
Dates at 1°C up to 180 days
Strawberries at 1°C up to 7 days
Figs at 1°C up to 7 days
Blueberries at 1°C up to 9 days
Raspberries at 1°C up to 3 days
Red currants at 1°C up to 7 days
Cherries, sweet at 1°C up to 14 days
Kiwi at 1°C up to 80 days
Peaches at 1°C up to 13 days
Plums at 1°C up to 20 days
Cranberries at 1°C up to 60 days
Rhubarb at 1°C up to 13 days
Gooseberries at 1°C up to 13 days
Grapes at 1°C up to 29 days
6 Energy saving
-
Always ensure good ventilation. Do not obstruct ventila‐
tion openings or grilles.
-
Never block air slits in the fan.
-
Do no install the appliance in an area with direct sunlight,
next to a heating unit or similar.
-
If you install the appliance directly next to an oven, its
energy consumption may increase slightly. This depends
on the service life and how often the oven is used.
-
Energy consumption depends on installation conditions
such as the ambient temperature (see2.4 Range of appli‐
ance use) . A warmer ambient temperature can increase
the energy consumption.
-
Avoid opening the appliance door for any longer then
necessary
-
The lower the temperature is set the higher the energy
consumption.
-
Sort your food items: home.liebherr.com/food.
-
All food stored in the appliance should be well wrapped
and covered. This prevents frost buildup.
-
Only take food out for as long as necessary so that it
does not get too warm.
-
Insertion of warm foods: first let the food cool down to
room temperature.
-
For longer periods of absence, use HolidayMode
(seeHolidayMode) .
7 Use
7.1 Controls and displays
7.1.1 Status display
Fig. 8 Status display shows the actual temperature.
(1) Fridge compartment
temperature display
(2) Temperature display
BioFresh
The status display shows the actual temperature and is the
initial display. You can navigate from there to the functions
and settings.
7.1.2 Display symbols
The display symbols provide information about the current
appliance status.
Symbol Appliance status
Standby
The appliance or temperature zone
is turned off.
Flashing number
Appliance is working. Temperature
flashes until the set temperature is
reached.
Flashing symbol
Appliance is working. Setting is
made.
7.2 Appliance functions
7.2.1 Notes on the appliance functions
The appliance functions are set at the factory so that your
appliance is fully functional.
Before you alter, activate or deactivate the appliance func‐
tions, make sure that the following requirements are met:
❑
You have read and understood the descriptions of how
the display works. (see 3 Functionality of the
Touch&Swipe display)
❑
You have familiarized yourself with the operating and
display elements of your appliance.
Switching appliance off and on
This function switches the entire appliance on and off.
Switching off the appliance
If you switch off the appliance, the settings that were made
before remain stored.
Make sure that the following requirements are fulfilled:
❑
Handling instructions (see 11 Decommissioning) have
been completed.
Fig.9
Energy saving
* Depending on model and options 9
Fig. 10
► Carry out action steps according to the illustration.
▷ Appliance is switched off.
▷ Standby symbol appears in the display.
▷ Display turns black.
Switching on the appliance
If the display is in sleep mode:
► Briefly touch the display.
Fig. 11 Example illustration
► Carry out action steps according to the illustration.
If the appliance starts in demo mode:
► Deactivate demo mode. (see Deactivating demo mode)
▷ Appliance is switched on.
▷ Previously made settings are re-established.
▷ The appliance cools to the set target temperature.
WiFi
Use this function to connect your appliance to WiFi. You can
then operate it via the SmartDevice app on a mobile device.
You can also use this function to disconnect or reset the
WiFi connection.
More information on the SmartDevice: (see 2.3 SmartDevice)
Note
The SmartDevice function is not available in the following
countries: Russia, Belarus, Kazakhstan.
Establishing the WiFi connection for the first time
Make sure that the following requirements are fulfilled:
❑
You have installed the SmartDevice app (see
apps.home.liebherr.com).
❑
Registration in the SmartDevice app is completed.
Fig.12
Fig.13
► Carry out action steps according to the illustration.
▷ Connection is established.
Disconnecting from the WiFi
Fig. 14
Fig. 15
► Carry out action steps according to the illustration.
▷ There is no connection.
Resetting the WiFi connection
Fig. 16
Fig.17
► Carry out action steps according to the illustration.
▷ WiFi connection and other WiFi settings are reset to
factory settings.
Use
10 * Depending on model and options
Showing information about the WiFi connection
Fig. 18
Fig. 19
► Carry out action steps according to the illustration.
Temperature
Use this function to set the temperature.
The temperature depends on the following factors:
-
How often the door is opened
-
How long the door is open
-
The room temperature of the installation site
-
Type, temperature and amount of food
Temperature zone
Factory-set
temperature
Recommended
setting
Fridge section
5°C 4°C
BioFresh
0°C B-Value (see
BioFresh B-Value )
Setting the temperature in the fridge section
Fig. 20 Example illustration
► Carry out action steps according to the illustration.
▷ Temperature is set.
Setting the temperature in BioFresh
You set the temperature using the BioFresh B-Value. (see
BioFresh B-Value )
Temperature unit
Use this function to set the temperature unit. You can set
the temperature unit in either degrees Celsius or
degrees Fahrenheit.
Setting the temperature unit
Fig.21
Fig. 23 Example illustration: Switching between
degrees Celsius or degrees Fahrenheit.
► Carry out action steps according to the illustration.
▷ Temperature unit is set.
BioFresh B-Value
Use this function to set the BioFresh B-Value. Use the
BioFresh B-Value to adjust BioFresh slightly warmer or
colder if a higher or lower ambient temperature makes it
necessary. Upon delivery, the BioFresh B-Value is set to the
value B5. If you adjust the B-Value, please observe the
following table:
Value
Description
B1 Lowest temperature
B1-B4 The temperature can drop below 0 °C which means
foods can easily freeze.
B5 Pre-set temperature
B9 Highest temperature
Setting the BioFresh B-Value
Fig. 24
Use
* Depending on model and options 11
Fig. 26 Example illustration: Switching from B5 to B6.
► Carry out action steps according to the illustration.
▷ The BioFresh B-Value is set.
▷ Status display shows the target temperature.
D-Value
The D-Value is preset for your appliance and must not be
changed.
SuperCool
This function activates or deactivates SuperCool. If you acti‐
vate SuperCool the appliance increases the cooling
capacity. This allows you to achieve lower cooling tempera‐
tures. You can activate SuperCool if you want to quickly cool
large volumes of food.
If the function is active, the appliance operates at a higher
output. As a result, the operating noise of the appliance may
be temporarily louder, while energy consumption increases.
Activating SuperCool
Time for activating the function:
-
If you want to store fresh food in the fridge section: Acti‐
vate the function when storing food.
Fig.27
Fig.28
► Carry out action steps according to the illustration.
-or-
► Activating with the SmartDevice app.
▷ SuperCool is activated.
▷ Temperature display turns blue.
Deactivating SuperCool
SuperCool is automatically deactivated after 18 hours.
However, you can also manually deactivate SuperCool at
any time:
Fig.29
Fig.30
► Carry out action steps according to the illustration.
-or-
► Deactivating with the SmartDevice app.
▷ SuperCool is deactivated.
▷ Appliance continues to run in normal operation.
▷ The appliance first cools to the set temperature.
PartyMode
This function activates and deactivates PartyMode. Party‐
Mode activates different functions that are useful for a
party.
PartyMode activates the following functions:
-
SuperCool (seeSuperCool)
You can set all listed functions individually and flexibly. By
deactivating PartyMode all changes are discarded.
If the function is active, the appliance operates at a higher
output. As a result, the operating noise of the appliance may
be temporarily louder, while energy consumption increases.
Activating PartyMode
Fig.31
Fig.32
► Carry out action steps according to the illustration.
▷ PartyMode and the corresponding functions are acti‐
vated.
▷ Temperature display turns blue.
▷ The current temperature flashes until the target tempera‐
ture is reached.
Deactivating PartyMode
PartyMode is automatically deactivated after 24 hours.
However, you can also manually deactivate PartyMode at
any time:
Fig.33
Use
12 * Depending on model and options
Fig.34
► Carry out action steps according to the illustration.
▷ PartyMode is deactivated.
▷ The appliance first cools to the set temperature: The
current temperature flashes until the target temperature
is reached.
HolidayMode
Use this function to activate or deactivate HolidayMode. If
you activate HolidayMode the fridge section is set to 15 °C.
This helps you save energy if you are away for a longer
period of time and avoid bad smells and mold formation.
Appliance status with active HolidayMode
Fridge section cools to 15°C.
BioFresh cools down to 15°C.
PartyMode is deactivated.
SuperCool is deactivated.
Activating HolidayMode
► Empty the fridge section completely.
► Empty BioFresh completely.
Fig.35
Fig.36
► Carry out action steps according to the illustration.
▷ HolidayMode is activated.
▷ Temperature display turns blue and shows the Holiday‐
Mode symbol.
Deactivating HolidayMode
Fig.37
Fig.38
► Carry out action steps according to the illustration.
▷ HolidayMode is deactivated.
▷ The appliance first cools to the set temperature.
SabbathMode
This function activates and deactivates SabbathMode. If
you activate this function, some electronic functions are
switched off. Your appliance thereby meets the religious
requirements of Jewish holidays such as the Sabbath and
complies with STAR-K Kosher certification.
Appliance status with active SabbathMode
The status display continuously shows SabbathMode.
All functions in the display except the Deactivating
SabbathMode function are disabled.
Active functions remain active.
The display remains bright when you close the door.
The interior lighting is deactivated.
Memories are not listed. The set time interval is stopped.
Memories and warnings are not displayed.
There is no door alarm.
There is no temperature alarm.
The defrost cycle operates only for the specified time
without taking into account the appliance usage.
After a power failure, the device returns to SabbathMode.
Appliance status
Note
This appliance has certification from the “Institute for
Science and Halacha”. (www.machonhalacha.co.il)
You can find a list of STAR-K-certified appliances at
www.star-k.org/appliances.
Activating SabbathMode
WARNING
Danger of poisoning from spoiled food!
If you have SabbathMode activated and a power failure
occurs, no message appears in the status display about the
power failure. Once the power is restored, the appliance
continues to operate in SabbathMode. The power failure
may mean that food spoils and the consumption of this food
could lead to food poisoning.
After a power failure:
► Do not consume food that has been frozen and thawed.
Fig. 39
Fig.40
► Carry out action steps according to the illustration.
▷ SabbathMode is activated.
▷ Status display continuously shows SabbathMode.
Deactivating SabbathMode
SabbathMode is automatically deactivated after 80 hours.
However, you can also manually deactivate SabbathMode at
any time:
Use
* Depending on model and options 13
Fig. 41
► Carry out action steps according to the illustration.
▷ SabbathMode is deactivated.
EnergySaver
Use this function to activate or deactivate energy saving
mode. If you activate energy saving mode, energy consump‐
tion drops and the temperature in the appliance increases.
Food remains fresh, but shelf life is reduced.
Temperature zone
Recommended
setting (see Setting
the temperature in
the fridge section)
Temperature
while Ener‐
gySaver is
active
Fridge
section
4°C 7°C
Temperatures
Activating EnergySaver
Fig. 42
Fig.43
► Carry out action steps according to the illustration.
▷ Energy saving mode is activated.
Deactivating EnergySaver
Fig.44
Fig.45
► Carry out action steps according to the illustration.
▷ Energy saving mode is deactivated.
CleaningMode
This function activates and deactivates CleaningMode.
CleaningMode enables you to comfortably clean the appli‐
ance.
This setting relates to the fridge compartment.
Application:
-
Clean the fridge compartment. (see 9.6 Cleaning the
appliance)
Appliance status with active CleaningMode
The status display continuously shows CleaningMode.
The fridge section is switched off.
The interior lighting is activated.
Reminders and warnings are not displayed. No signal tone
is sounded.
Appliance status
Activating CleaningMode
Fig.46
Fig. 47
► Carry out action steps according to the illustration.
▷ CleaningMode is activated.
▷ Status display continuously shows CleaningMode.
Deactivating CleaningMode
CleaningMode is automatically deactivated after
60 minutes. However, you can also manually deactivate
CleaningMode at any time:
Fig.48
► Carry out action steps according to the illustration.
▷ CleaningMode is deactivated.
▷ The appliance first cools to the set temperature.
Display Brightness
Use this function to set the brightness of the display gradu‐
ally.
You can set the following brightness levels:
-
40%
-
60%
-
80%
-
100% (default setting)
Setting the brightness
Fig. 49
Use
14 * Depending on model and options
Fig. 50 Example illustration: Switching from 80 % to 60%.
► Carry out action steps according to the illustration.
▷ Brightness is set.
Door alarm
Use this function to activate or deactivate the door alarm.
The door alarm sounds if the door is open for too long. The
door alarm is activated upon delivery. You can set how long
to door can remain open until the door alarm sounds.
You can set the following values:
-
1 minute
-
2 minutes
-
3 minutes
-
Off
Setting the door alarm
Fig.51
Fig. 52 Example illustration: Changing the door alarm from
1 minute to 3 minutes.
► Carry out action steps according to the illustration.
▷ Door alarm is set.
Deactivating door alarm
Fig.54
Fig.55
► Carry out action steps according to the illustration.
▷ Door alarm is deactivated.
Input lock
This function activates and deactivates the input lock. The
input lock prevents the appliance from being operated acci‐
dentally, e. g. by children.
Application:
-
Prevent unintentional changes of functions.
-
Prevent switching off of the appliance.
-
Prevent unintentional temperature setting.
Activating the input lock
If you activate the input lock, you can continue to navigate
in the menus, however you cannot select or modify other
functions.
Fig.56
Fig.57
► Carry out action steps according to the illustration.
▷ Input lock is activated.
Deactivating the input lock
Fig.58
Fig. 59
► Carry out action steps according to the illustration.
▷ Input lock is deactivated.
Language
Use this function to set the display language.
Use
* Depending on model and options 15
You can set the following languages:
-
German
-
English
-
French
-
Spanish
-
Italian
-
Dutch
-
Czech
-
Polish
-
Portuguese
-
Bulgarian
-
Russian
-
Chinese
Setting the language
Fig.60
Fig. 61 Example illustration depending on the language
and temperature
► Carry out action steps according to the illustration.
▷ Language is set.
▷ Display jumps back to the status display.
Appliance information
Use this function to display the model name, index, serial
number and service number of your appliance. You will need
the appliance information when you contact customer
service. (see 10.4 Customer Service)
You also use this function to open the expanded menu.
(see3 Functionality of the Touch&Swipe display)
Display appliance information
Fig. 62
Fig.63
► Carry out action steps according to the illustration.
▷ Display shows the appliance information.
Software
Use this function to display the software version of your
appliance.
Display software version
Fig.64
Fig.65
► Carry out action steps according to the illustration.
▷ Display indicates the software version.
Reminder
Use this function to activate or deactivate reminder. This
function is activated upon delivery.
The following reminders will then appear if the function is
activated:
-
Replace the FreshAir activated charcoal filter
(see Replace FreshAir activated charcoal filter)
Activating reminder
Fig.66
Fig. 67
► Carry out action steps according to the illustration.
▷ Reminder is activated.
Deactivating reminder
Fig.68
Fig. 69
► Carry out action steps according to the illustration.
▷ Reminder is deactivated.
Use
16 * Depending on model and options
Demo mode
Demo mode is a special feature for dealers who want to
demonstrate appliance features. If you activate demo mode,
all refrigeration functions are deactivated.
If you switch on your appliance and “Demo” appears in the
status display, then demo mode is already activated.
If you activate and then deactivate demo mode, the appli‐
ance will be reset to factory defaults. (see Resetting to
factory settings)
Activating demo mode
Fig.70
Fig.71
► Carry out action steps according to the illustration.
▷ Demo mode is activated.
▷ Appliance is switched off.
► Switch on the appliance. (see 4.1 Switching on appliance
(first use))
▷ “DEMO” appears in the status display.
Deactivating demo mode
Fig.72
Fig.73
► Carry out action steps according to the illustration.
▷ Demo mode is deactivated.
▷ Appliance is switched off.
► Switch on the appliance. (see 4.1 Switching on appliance
(first use))
▷ Appliance is reset to factory settings.
Resetting to factory settings
Use this function to reset all settings to factory settings. All
settings you have made so far are reset to their original
settings.
Performing a reset
Fig. 74
Fig.75
► Carry out action steps according to the illustration.
▷ Appliance is reset.
▷ Appliance is switched off.
► Restart the appliance. (see 4.1 Switching on appliance
(first use))
Use
* Depending on model and options 17
7.3 Messages
There are two categories of messages:
Category Meaning
Warning Warnings are displayed if there is a door alarm
or a malfunction.
You can easily end warnings yourself. For any
major malfunction, you must contact Customer
Service. (see 10.4 Customer Service)
Reminder Reminders remind you of general processes.
You can perform these processes and end the
message doing so.
7.3.1 Overview of warnings
The appliance’s behavior in the event of a warning:
-
Warning appears in the display in red.
-
Alarm sounds in increasing volume.
-
For some warnings the interior lighting pulses.
Message
Cause Ending the
message
Door alarm
The message appears if
the door is open for too
long.
Carry out
action steps
(see Door
alarm) .
Error
This message appears if
there is an appliance error.
An appliance module indi‐
cates an error.
Carry out
action steps
(see Error) .
WLAN error
This message appears if
the appliance could not be
connected to WLAN.
(see Establishing the WiFi
connection for the first
time) This message only
appears the first time the
appliance is set up.
Carry out
action steps
(see WLAN
error) .
7.3.2 Ending warnings
Door alarm
Fig. 76 Example illustration
► Carry out action steps according to the illustration.
-or-
► Close the door.
▷ Display skips to status display.
You can set how long to door may remain open until the
door alarm sounds. (see Setting the door alarm)
Error
Fig. 77 Example illustration
► Briefly touch the display.
▷ Error code is displayed.
► Make a note of the error code.
► Briefly touch the display.
▷ Display skips to status display.
► Contact Customer Service. (see 10.4 Customer Service)
WLAN error
► Check the WLAN connection.
► Connect the appliance to the WLAN again. (seeWiFi)
7.3.3 Overview of reminders
The appliance’s behavior in the event of a reminders:
-
Reminder appears in the display in yellow.
-
Alarm tone sounds.
-
For some reminders the interior lighting pulses.
You can deactivate the following reminders (see Deacti‐
vating reminder) :
-
Replace FreshAir activated charcoal filter
Message
Cause Ending the
message
Replace FreshAir
activated charcoal
filter
This message
appears if you
have to replace
the FreshAir acti‐
vated charcoal
filter.
Carry out action
steps
(see Replace
FreshAir acti‐
vated charcoal
filter) .
7.3.4 Ending reminders
Replace FreshAir activated charcoal filter
Liebherr recommends: Replace the FreshAir activated char‐
coal filter every 6 months.
Note
FreshAir activated charcoal filters can be purchased from
the Liebherr-Hausgeräte store at home.liebherr.com/
shop/de/deu/zubehor.html.
Fig. 78 Example illustration
► Briefly touch the display.
Use
18 * Depending on model and options
▷ Display shows information about the reminder.
► Briefly touch the display.
► Replace activated charcoal filter. (see 9.1 FreshAir carbon
filter)
▷ The activated charcoal filter ensures optimum air quality
in the refrigerator.
▷ Reminder appears again after 6 months.
If you no longer want to keep this reminder, you can deacti‐
vate the reminder. (see Deactivating reminder)
8 Equipment
8.1 Variable bottle shelf
You can use either the glass shelf or the variable bottle
shelf on the floor of the fridge section. The glass shelf is
inserted upon delivery.
Fig. 79 Example illustration
(1)
Variable bottle rack
8.1.1 Using the variable bottle shelf
Fig.80
► Lift the glass shelf Fig. 80 (1) in the front at the recess
and pull it out.
► Store the glass shelf Fig. 80 (1) somewhere safe outside
of the appliance.
Fig.81
► Insert the bottles facing backwards towards the rear
wall. (see Fig.81)
Note
If the bottles protrude towards the front over the variable
bottle shelf:
► Set the lower door rack one position higher.
8.1.2 Using the glass shelf
Make sure that the following requirements are fulfilled:
❑
Bottles are removed.
❑
The variable bottle shelf has been cleaned.
(see 9.3 Removing / inserting the variable bottle shelf)
(see 9.6.3 Cleaning the equipment)
Fig.82
► Place the glass shelf Fig. 82 (1) at an angle, tilted back
and down.
► Lower the glass shelf Fig.82(1) at the front.
8.2 Drawers
You can remove the drawers for cleaning.
The way to remove/insert the drawers varies depending on
the pull-out system. Your appliance can contain a variety of
pull-out systems.
Note
Insufficient ventilation results in an increase in energy
consumption and reduction of the refrigerating perform‐
ance.
► Never obstruct the vents on the interior rear wall!
8.2.1 Drawer on telescopic rails
The drawer runs on full-extension rails (telescopic rails).
There are full-extension telescopic rails and telescopic rails
with partial pull-out. Drawers which are full extension can
be pulled out fully from the appliance. Drawers with partial
pull-out cannot be pulled out fully from the appliance. The
system in your appliance depends on the type of appliance.
Full extension*
If you have full-extension rails, there is a clamp located at
the back on the left and right of the rail.
Removing drawer
Fig.83
► Pull out drawer as far as it will go.
► Lift left clamp and simultaneously pull drawer forwards
on the left. Fig.83(1)
► Lift right clamp and simultaneously pull drawer forwards
on the right. Fig.83(2)
Equipment
* Depending on model and options 19
► Remove drawer to the front. Fig.83(3)
► Slide rails in.
Inserting drawer
Fig.84
► Slide rails in.
► Place drawer on rails.
► Slide in drawer to the back.
▷ Drawer latches in audibly at the back.
Full-extension glass drawer*
Removing drawer
Fig.85
► Pull out drawer as far as it will go.
► Lift up drawer at the front. Fig.85(1)
► Remove drawer to the front. Fig.85(2)
► Slide rails in.
Inserting drawer
Fig.86
► Slide rails in.
► Place drawer on rails.
► Slide in drawer to the back.
▷ Drawer latches in.
8.3 Lid for Fruit & Vegetable-safe
The lid ensures constant levels of humidity.
The lid is located directly on the drawer and can be covered
by shelves or additional drawers.
Fig. 87 Example illustration of the lid for Fruit & Vegetable-
safe
(1) Fruit & Vegetable-safe
(2) Lid for Fruit & Vege‐
table-safe
(3) Variable bottle rack
8.3.1 Reducing humidity in the drawer
Fig.88
► Pull out the drawer Fig.88(1).
► Grip the handle recess Fig. 88 (2) on the lid while pulling
the lid forward at the same time.
▷ When the drawer is closed, there is a small gap between
the lid and the drawer.
8.3.2 Increasing humidity in the drawer
Fig.89
► Pull out the drawer Fig.89(1).
► Grip the handle recess Fig. 89 (2) on the lid while pulling
the lid backward at the same time.
▷ When the drawer is closed, the lid closes tightly with the
drawer.
8.3.3 Using Fruit & Vegetable-safe as a
Meat & Dairy-safe
You can use the Fruit & Vegetable-safe as a Meat & Dairy-
safe. To do so, you must reduce the moisture in the drawer.
(see 8.3.1 Reducing humidity in the drawer)
Equipment
20 * Depending on model and options
8.4 Butter dish
8.4.1 Opening/closing the butter dish
Fig.90
8.4.2 Dismantling the butter dish
You can disassemble the butter dish for cleaning.
Fig. 91
► Disassemble the butter dish.
8.5 Egg rack
You can pull out and turn the egg rack. You can use both
sides of the egg rack so you can label specifics like the
purchase date.
8.5.1 Using the egg rack
Fig.92
► Top section: store hen eggs.
► Bottom section: store quail eggs.
8.6 FlexSystem
8.6.1 Using the FlexSystem
The FlexSystem helps you store and arrange food clearly
and in the way you want. It lets you clearly divide your food
into fruit, vegetables or by use-by dates, for example.
Fig. 93
► Move the inside tray.
8.6.2 Removing the FlexSystem
Fig. 94
► Lift the FlexSystem at the back.
► Pull up and out.
Equipment
* Depending on model and options 21
8.6.3 Inserting the FlexSystem
Fig.95
► Insert front of the FlexSystem first.
► Lower the back part.
8.6.4 Disassembling the FlexSystem
The FlexSystem can be dismantled for cleaning.
Fig.96
► Dismantling the FlexSystem.
9 Maintenance
9.1 FreshAir carbon filter
The FreshAir carbon filter is located in the compartment
above the fan.
It guarantees the best air quality.
❑
Change the carbon filter every 6 months.
When the reminder is set, a message on the display
prompts you to change it.
❑
You can dispose of the carbon filter with the regular
household waste.
Note
FreshAir activated charcoal filters can be purchased from
the Liebherr-Hausgeräte store at home.liebherr.com/
shop/de/deu/zubehor.html.
9.1.1 Removing the FreshAir carbon filter
Fig.97
► Pull out the compartment Fig.97(1).
► Remove the carbon filter Fig.97(2).
9.1.2 Inserting the FreshAir carbon filter
Fig.98
► Insert the carbon filter as shown in the diagram
Fig.98(1).
▷ The carbon filter clicks into place.
If the carbon filter is pointing downwards:
► Push the compartment in Fig.98(2).
▷ The carbon filter is now ready for use.
9.2 Disassembling / assembling pull-
out systems
9.2.1 Notes on disassembly
You can disassemble some of the pull-out systems for
cleaning. Your appliance can contain a variety of pull-out
systems.
The following pull-out systems can be disassembled or
cannot be disassembled:
Pull-out system
can be disassembled/
cannot be disassembled
Full extension* cannot be disassembled*
Full-extension glass
drawer*
can be disassembled (see Full-
extension glass drawer*) *
9.2.2 Drawer on telescopic rails
Full-extension glass drawer*
Disassembling pull-out system
Make sure that the following requirements are fulfilled:
❑
Drawer has been removed. (see Full-extension glass
drawer*)
❑
Glass shelf has been removed.
Fig. 99 Glass shelf with rails
► Remove rail from glass shelf sideways.
Maintenance
22 * Depending on model and options
Installing pull-out system
Fig. 100Damping mechanism
The damping mechanism is attached to the left rail. (see
Fig. 100) There is no damping mechanism attached to the
right rail.
Fig. 101 Glass shelf with rails
Install rail with damping mechanism:
► Push rail as far as it will go onto the left side of the glass
shelf.
Install rail without damping mechanism:
► Push rail as far as it will go onto the right side of the
glass shelf.
9.3 Removing / inserting the variable
bottle shelf
You can remove the variable bottle shelf for cleaning.
9.3.1 Removing the variable bottle shelf
Make sure that the following requirements are fulfilled:
❑
Bottles are removed.
❑
Glass shelf is removed. (see 8.1.1 Using the variable
bottle shelf)
Fig. 102
► Lift the variable bottle shelf from the front and pull it out.
▷ The compartment lid is visible.
Note
Liebherr recommends:
Do not store any product on the compartment lid below it.
9.3.2 Inserting the variable bottle shelf
Fig. 103
► Push in the variable bottle shelf as far as it goes and
press it down.
▷ The back plugs on the variable bottle shelf are connected
automatically.
▷ LED light ups.
► Insert the glass shelf. (see8.1.2Using the glass shelf)
-or-
► Use the variable bottle shelf for bottles.
9.4 Lid for Fruit & Vegetable-safe
You can remove the lid for cleaning.
9.4.1 Removing the lid
Make sure that the following requirements are fulfilled:
❑
The glass plate directly above the variable bottle rack
has been removed.
❑
The variable bottle rack has been removed.
❑
The drawer directly below the lid has been removed.
(see8.2 Drawers)
Fig. 104
► Push the lid backward.
► Lift up the lid forward.
► Remove the front lid by lifting it up at an angle.
Maintenance
* Depending on model and options 23
9.4.2 Inserting the lid
Fig. 105
If the lettering THIS SIDE UP is on top:
► Insert the rear bracket retainers in the corresponding rear
openings.
► Push the lid backward.
► Lower the lid at the front and latch the front bracket
retainers in the openings.
► Bring the lid to the desired position.
9.5 Defrosting the appliance
WARNING
Appliance incorrectly defrosted!
Injuries and damage.
► Do not use mechanical devices or other means to accel‐
erate the defrosting process, other than those recom‐
mended by the manufacturer.
► Do not use any electrical heating or steam cleaning
equipment, naked flames or defrosting sprays.
► Do not remove ice with sharp objects.
Defrosting is performed automatically. The water from the
thawing process runs out via the drain opening and is
evaporated.
► Clean the drain hole regularly. (see 9.6Cleaning the appli‐
ance)
9.6 Cleaning the appliance
9.6.1 Preparation
WARNING
Danger of electric shock.
► Unplug refrigerator or disconnect power.
WARNING
Danger of fire
► Do not damage the refrigerant circuit.
► Empty appliance.
► Pull out the power plug.
-or-
► Activate CleaningMode. (seeCleaningMode)
9.6.2 Cleaning the interior
NOTICE
Improper cleaning!
Damage to the appliance.
► Only use soft cleaning cloths and ph-neutral all-purpose
cleaners.
► Do not use steel wool or sponges that scour or scratch.
► Do not use caustic or abrasive cleaning materials or
those containing sand, chloride, or acids.
► Plastic surfaces: clean by hand with a soft clean cloth,
lukewarm water and a little detergent.
► Metal surfaces: clean by hand with a soft clean cloth,
lukewarm water and a little detergent.
► Drain hole: remove any deposits with a thin item such as
a cotton bud.
9.6.3 Cleaning the equipment
NOTICE
Improper cleaning!
Damage to the appliance.
► Only use soft cleaning cloths and ph-neutral all-purpose
cleaners.
► Do not use steel wool or sponges that scour or scratch.
► Do not use caustic or abrasive cleaning materials or
those containing sand, chloride, or acids.
Clean with a soft, clean cloth, lukewarm water and a little
washing up liquid:
- Lid for Fruit & Vegetable-safe
- Drawer
- Variable bottle shelf
- FlexSystem
Clean with a damp cloth:
- Retracting rails
Please note: the grease in the tracks is there for lubrica‐
tion purposes and must not be removed!
Clean in the dishwasher up to 60°C:
- Egg rack
- Butter dish
► Disassemble the equipment: see the relevant section.
► Clean the equipment.
9.6.4 After cleaning
► Wipe dry the appliance and items of equipment
► Connect and switch on the appliance.
When the temperature is sufficiently cold
► Place the food inside.
► Repeat cleaning regularly.
10 Customer support
10.1 Technical specifications
Temperature zone
Cool: 3°C to 9°C
BioFresh 0°C to 3°C
Customer support
24 * Depending on model and options
Max. equipment capacity
Equipment Appliance
width
550 mm
(see instal‐
lation
instruc‐
tions,
appliance
dimen‐
sions)
Appliance
width
600 mm
(see
installa‐
tion
instruc‐
tions,
appliance
dimen‐
sions)
Appliance
width
700 mm
(see instal‐
lation
instruc‐
tions, appli‐
ance
dimen‐
sions)
Glass drawer,
height 59mm
15 kg -- --
Glass drawer,
height 100mm
15 kg -- --
Glass drawer,
height 150mm
20 kg -- --
Lighting
Energy efficiency class
1
Light source
This product contains one or more energy
efficiency class G light sources.
LED
1
The appliance may contain light sources with different
energy efficiency classes. The lowest energy efficiency class
is indicated.
For appliances with a WiFi connection:
Frequency specification
Frequency band 2.4GHz
Maximum radiated
power
< 100 mW
Purpose of the
wireless equipment
Integration in the local WiFi network
for data communication
10.2 Operating noises
The appliance makes noises while in operation.
-
At less cooling output the appliance saves energy but
takes longer to cool items. The volume is lower.
-
At a higher cooling output the food cools more quickly.
The volume is higher.
Examples:
•
Activated functions (see 7.2Appliance functions)
•
Running fan
•
Freshly sorted food
•
High ambient temperature
•
Door opened for long periods
Noise
Possible cause Type of noise
Bubbling and
splashing
Coolant is flowing
into the cooling
circuit.
Normal noise
Spitting and
hissing
Coolant is spraying
into the cooling
circuit.
Normal noise
Humming The appliance
cools. The volume
depends on the
cooling output.
Normal noise
Sipping noises The self-closing
door is being
opened and
closed.
Normal noise
Whirring and
murmuring
The fan is running. Normal operating
noise
Clicking Components are
being switched on
and off.
Normal switching
noise
Rattling or
humming
Valves are active. Normal switching
noise
Noise Possible
cause
Type of noise How to
resolve
Vibration Unsuitable
installation
Error noise Check instal‐
lation.
Set up the
appliance.
Clattering Equipment,
Objects
inside the
appliance
Error noise Secure
equipment
parts.
Leave a gap
between
items.
10.3 Technical faults
Your appliance is designed and manufactured for reliable
operation and a long service life. If a malfunction nonethe‐
less occurs during operation, please check whether the
malfunction is due to an operating error. In this case, you
will have to be charged for the costs incurred, even during
the warranty period.
You may be able to rectify the following faults yourself.
10.3.1 Appliance function
Defect
Cause Remedy
The appliance does
not work.
→ The appliance is not switched on. ► Switch on the appliance.
→ The power plug is not properly
inserted in the wall socket.
► Check the power plug.
→ The powerfuse in the wall socket is
not OK.
► Check the fuse.
→ Power failure. ► Keep the appliance closed.
Customer support
* Depending on model and options 25
Defect Cause Remedy
→ The IEC socket is not correctly
plugged into the appliance.
► Check the IEC socket.
The temperature is
not cold enough
→ This means that the door of the
appliance is not closed properly
► Close the appliance door
→ Insufficient ventilation ► Clear and clean the ventilation grille.
→ The ambient temperature is too
high
► Problem solution: (see2.4 Range of appliance use)
→ The appliance was opened too
frequently or for too long
► Wait to see if the required temperature corrects itself. If
not, contact Customer Service. (see 10.4 Customer
Service)
→ The temperature is incorrectly set ► Set to a colder temperature and check after 24 hours.
→ The appliance is too near to a heat
source (stove, heater etc).
► Change location of appliance or the heat source.
→ The appliance was not properly
installed in the recess.
► Make sure the appliance was installed correctly and the
door closes properly.
The door seal is
defective or should
be replaced for
other reasons.
→ The door seal is interchangeable.
You can replace it without the use
of any special tools.
► Contact Customer Service. (see 10.4 Customer Service)
The appliance is
iced up or conden‐
sation is building.
→ The door seal may have slipped out
of its groove.
► Check the door seal is well placed in the groove.
10.3.2 Equipment
Defect Cause Remedy
The interior light
does not turn on.
→ The appliance is not switched on. ► Switch on the appliance.
→ The door was open for more than
15 minutes.
► If the door is open, the interior lighting switches off
automatically after about 15 minutes.
→ The LED interior light is faulty or
the lid is damaged.
► Contact Customer Service. (see 10.4 Customer Service)
10.4 Customer Service
First check whether you can rectify the fault yourself
(see 10 Customer support) . If you cannot rectify the
problem, contact Customer Service.
You can find the address in the enclosed brochure “Liebherr-
Service” or at home.liebherr.com/service.
WARNING
Unprofessional repair!
Injuries.
► Repairs and work on the appliance and the power supply
cable not described in the Manual (see 9 Maintenance)
should only be carried out by a qualified service provider.
► A damaged power cable may only be replaced by the
manufacturer, the manufacturer’s Customer Service or a
similarly qualified person.
► For appliances with an IEC connector, the change can be
made by the customer.
10.4.1 Contacting Customer Service
Make sure that the following appliance information is avail‐
able:
❑
Appliance name (model and index)
❑
Service no. (service)
❑
Serial no. (S no.)
► Call up the appliance information via the display. (see
Appliance information)
-or-
► Refer to the type plate for appliance information.
(see 10.5 Rating plate)
► Take note of the appliance information.
► Notify customer service: Report errors and the appliance
information.
▷ This will help us give you fast and accurate support.
► Follow further instructions from Customer Service.
10.5 Rating plate
The nameplate is located behind the drawers on the inside
of the appliance.
Customer support
26 * Depending on model and options
Fig. 106
(1) Appliance name (3) Serial no.
(2) Service no.
► Information from the nameplate.
11 Decommissioning
► Empty appliance.
► Switch off appliance. (see Switching appliance off and
on)
► Pull the power plug from the outlet.
► If necessary, remove the IEC socket: Pull the IEC socket
out of the appliance plug while turning it to the left and
right at the same time.
► Clean appliance. (see 9.6Cleaning the appliance)
► Leave the door open to prevent unpleasant odors.
12 Disposal
12.1 Preparing appliance for disposal
Liebherr uses batteries in some of its appli‐
ances. In the EU, for environmental reasons,
legislation obliges the end user to remove
these batteries before disposing of the old
appliances. If your appliance contains
batteries, a corresponding notice is attached to
the appliance.
Lamps If you can remove the lamps yourself without
destroying them, also remove these before
disposal.
► Take the appliance out of operation.
► If possible: Remove lamps without destroying them.
12.2 Disposing of the appliance in an
environmentally friendly manner
The appliance still contains
valuable materials and must be
collected separately from
unsorted municipal waste so it
can be recycled.
Dispose of batteries separately
from the old appliance. You can
do this by returning the
batteries free of charge to
retailers or taking them to recy‐
cling centers and collection
centers for recyclable materials.
Lamps Dispose of removed lamps via
the respective collection
systems.
For Germany: You can dispose of the appli‐
ance free of charge via the class
1 collection containers at the
local recycling and recyclable
material collection centers.
When purchasing a new fridge/
freezer, if the sales area > 400
m
2
, retailers will also take back
the old appliance free of charge.
WARNING
Leaking refrigerant and oil!
Fire. The refrigerant contained within the appliance is envi‐
ronmentally friendly, but flammable. The oil contained
within the appliance is flammable. Escaping refrigerant and
oil can ignite if they are of high enough concentration and
are exposed to an external heat source.
► Do not damage the pipelines of the coolant circuit and
the compressor.
►
Observe the notes on appliance transport.
► Transport the appliance away without damaging it.
► Dispose of batteries, lamps, and the appliance according
to the above specifications.
Decommissioning
* Depending on model and options 27
home.liebherr.com/fridge-manuals
Built-in refrigerator with BioFresh
Issue date:20250908
Part number index:7088425-00
Liebherr-Hausgeräte GmbH
Memminger Straße 77-79
88416Ochsenhausen
Deutschland
