INTRODUCTION & WARRANTY
TECHNICAL DATA
INSTRUCTION MANUAL
LED BORDERLINE PANEL
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty does
not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no warran-
ty against damage to any surface due to incorrect removal and installation of the product. The products are
suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
MODEL
SKU
SHAPE
WATTS
LUMEN [USEFUL LUMEN]
BEAM ANGLE
CRI
DF
LIFE SPAN
ON/OFF CYCLE
OPERATING TEMPERATURE
INPUT VOLTAGE
IP RATING
BODY TYPE
DIMENSION
VT-6164
24168
SQUARE
64 W
6720 Lm
110°
≥80
≥0.9
30,000 Hours
>15,000 Times
-20°C to +40°C
DC: 28-42V
IP20
Aluminium+ PC
595x595x15mm
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
[email protected] FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
100
LUMENS/W
Super Bright
INSTALLATION INSTRUCTION
1. Please make sure to turn o the power before starting the installation.
2. Installation should only be done by a certified electrician.
3. The light source contained in this luminaire shall only be replaced by
the manufacturer or his service agent or a similar qualified person.
4. The servicing of the control gear in this luminaire should only be
undertaken by the manufacturer or their service agent or a similarly
skilled person.
5. The external flexible cable or cord of this luminaire cannot be replaced;
if the cord is damaged, the whole luminaire shall be replaced.
6. For Indoor use only.
WARNING
Replaceable control gear by
a professional
Replaceable (LED Only) Light
source by a professional
Note: The panel works on DC 28-42V, please connect correctly with the
conductor before connecting the conductor to the power supply main.
Luminaires not suitable for
covering with thermally
insulating material.
1. Make a hole into ceiling 2. Fix the panel into ceiling.
3. Wire the DC cable of the panel to the
driver and then wire the AC source cable
to the power supply.
4. Turn on the switch, test the
fixture light on.
DISMANTLING INSTRUCTIONS
Note
• Light source removal will void the warranty.
• The light source contained in this luminaire shall only be replaced by the
manufacturer or his service agent or a similar qualified person.
Connect to DC
power supply test
Brown +
Blue -
For Market surveillance team only
V-TAC UK LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT
[email protected] V-TAC, 5A TUNGSTEN PARK, DOWNS ROAD, WITNEY, OXFORDSHIRE, OX29 0AX
V-TAC WEST EUROPE LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
[email protected] FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC WEST EUROPE LTD. GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
Remove
Terminal
