Order parts online
www.follettice.com
Horizon
™
Ice Machine Installation Instructions
for Ice Storage Bin Top-mount Applications
HCD/HMD/HCF/HMF1000RBT, HCD/HMD/HCF/HMF1400RBT, HCD/HMD/HCF/HMF1650RBT,
HCD1000NBT, HMD1000NBT, HCD1400NBT, HMD1400NBT, HCD1650NBT, HMD1650NBT
(See model number con gurator on page 2 for details.)
remote condensing
00159962R08
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
2
remote condensing BIN • TOP-MOUNT
ConfigurationApplication
S RIDE™
(RIDE remote
ice delivery
equipment)
T Top-mount
400 up to
454 lbs
(206kg)
1000 up to
1036 lbs
(471kg)
1400 up to
1450 lbs
(658kg)
1650 up to
1580 lbs
(717kg)
V Vision™
H Harmony™
B Ice storage bin
J Drop-in
M Ice Manager
diverter valve
system
CondenserSeriesVoltageIcemaker
C 208-230/60/1 (icemaking head)
Self-contained only.
D 115/60/1 (icemaking head)
Self-contained and remote. If remote
unit, high side is 208-230/60/1.
E 230/50/1 (icemaking head)
Self-contained only.
F 115/60/1 (icemaking head)
Remote only. High side is
208-230/60/3.
MC Maestro™
Chewblet
®
(400 Series)
HC Horizon
Chewblet
(1000, 1400,
1650 Series)
HM Horizon
Micro Chewblet
HC 1400CSVA
A Air-cooled, self-contained
W Water-cooled, self-contained
R Air-cooled, remote condensing unit
N Air-cooled, no condensing unit for
connection to parallel rack system
Chewblet
®
Ice Machine Model Number Configurations
BIN • TOP-MOUNT remote condensing
3
Front cover
8
Internal connection
7
Ice transport tube
5
External connection
6
Louvered docking assembly
4
Bin preparation
3
Site preparation
2
Unpack
1
Read and complete the following 8 installation steps
4
remote condensing BIN • TOP-MOUNT
Carefully unpack and inspect the contents of your Follett ice machine.
1
Unpack
1/2"
1/2"
➊➋
➌➍
➎➏
Unpack ice machine
1. 1
BIN • TOP-MOUNT remote condensing
5
Prepare the installation site.
2
Site preparation
Provide drainage, water supply and electrical power to within 6 feet (2m) of ice
machine in accordance with local and national codes. Outdoor installation is
not recommended and will void warranty.
➊
NEMA
5-15
➎
3/8" ∅ (9,5mm)
➍
208264
Stock Module Identification Plate
Service No.
Module No.
Product
R
E
F
R
I
G
E
R
A
N
T
M
O
D
E
L
M
O
T
O
R
C
O
M
P
R
E
S
S
O
R
T
H
E
R
M
A
L
LY
P
R
O
T
E
C
T
E
D
E
a
s
t
o
n
P
e
n
n
s
y
l
v
a
n
i
a
F
U
L
L
L
O
A
D
A
M
P
S
M
A
X.
B
R
A
N
C
H
C
I
R
C
U
IT
F
U
S
E
S
I
Z
E
M
I
N
.
B
R
A
N
C
H
C
I
R
C
U
I
T
A
M
P
A
C
I
T
Y
D
E
S
I
G
N
P
R
E
S
S
U
R
E
H
I
G
H
S
I
D
E
AM
P
S
A
M
P
S
V
OLTS
C
O
R
P
OR
A
TI
O
N
S
E
R
I
A
L
N
O
P
H
A
S
E
S
I
N
G
L
E
C
H
A
RG
E
LO
W
S
I
D
E
P
A
RT
N
O
P
S
I
G
T
H
E
U
S
A
M
A
D
E
I
N
O
Z
R
C
R
H
Z
U
L
L
N
S
F
U
1/4"
1'
➌
➋
Electrical
➊
120/60/1-6 amps
Potable water supply
➋
• 10-70 psi (69-483kpa)
• 45-90 F (7-32 C)
• Follett recommends the use of an in-line water ltration system (item# 00130286)
Drain
➌
• The drain line from the ice machine must have at least 1/4" per foot pitch (6,4mm/.3m)
Refrigeration lines
➍
• 1000, 1400: 5/8" (15,8mm) diameter suction (insulated)
➍
• 1650: 7/8” (22,2mm) diameter suction (insulated)
➍
• 3/8" (9,5mm) liquid
➎
2.1
Installation site requirements
2.1
6
remote condensing BIN • TOP-MOUNT
Prepare the bin.
3
Bin preparation
• Remove protective tape from
gaskets
Bin top preparation
3.1
➋
➊
➊
➌
• Apply gaskets
➊
• Install shuttle actuator
➋
through bin top
and secure with locking nut
➌
Bin top preparation
3.2
BIN • TOP-MOUNT remote condensing
7
Install the louvered docking assembly.
Louvered docking assembly
4
1" (25,4mm)
Stub Typ
3" (76mm)
1-3/4" (44,5mm)
3" (76mm)
3/8" ∅
high pressure
line
➋
➊
1000, 1400:
5/8" ∅ low pressure line
1650:
7/8" ∅ low pressure line
• Mount louvered docking assembly
➊
• “Rough-in” the refrigerant piping
➋
2.1
Louvered docking assembly
4.1
8
remote condensing BIN • TOP-MOUNT
➊
• Braze supplied expandable refrigerant
lines in place
➊
Refrigerant lines
4.2
BIN • TOP-MOUNT remote condensing
9
Ice transport tube
Install the ice transport tube.
5
➋
➊
➌
Hot Water
160 F (71 C)
5.1
• Slide insulation onto ice transport tube
• Heat end of transport tube in cup of 160 F (71 C) hot water to soften and spread with
pliers
➊
before making connection to ease assembly
• Connect ice transport tube to coupling on louvered docking station
➋
• Connect ice transport tube to shuttle actuator
➌
10
remote condensing BIN • TOP-MOUNT
Connect utilities to louvered docking assembly.
6
External connections
➋
➊
• Remove access panel if necessary.
• Install drain line
➊
.
The rigid drain line from the ice machine
must have at least 1/4" per foot pitch
(6,4mm/0,3m).
• Install ice machine potable water
supply
➋
• Replace access panel
Water and drain
6.1
BIN • TOP-MOUNT remote condensing
11
➊
• Rotate and braze refrigerant lines
➊
Refrigeration lines
7. 3
Connect louvered docking assembly to ice machine.
7
Internal connections
➊
➋
• Slide ice machine into louvered docking
assembly
➊
• Insert ice transport tube all the way into
coupling and tighten nut rmly
➋
Ice transport tube installation
7. 1
➊
➋
➊
➋
• Insert potable water line into valve
➊
• Push drain line over hose barb on
back of evaporator mount
➋
Water and drain lines
7. 2
• Remove twist tie
• Carefully pass plug thru opening and plug
into wall outlet
Power cord
7. 4
12
remote condensing BIN • TOP-MOUNT
• Position plate into opening and secure
with supplied screw
Power cord
7. 5
BIN • TOP-MOUNT remote condensing
13
14
remote condensing BIN • TOP-MOUNT
Front cover
Install front cover to ice machine.
8
• Complete installation of condensing unit
or connection to rack system.
Install condensing unit
8.1
➋
➊
• Slide ice machine cover over machine
ensuring that tabs on back of cover
slip under louvers on back of louvered
docking assembly
➊
• Insert and tighten two screws through
cover and into louvered docking assembly
➋
Install ice machine front cover
8.2
NOTICE
Ice machine MUST be sanitized prior to operation!
Consult Operation and Service Manual provided with ice machine for sanitizing instructions.
BIN • TOP-MOUNT remote condensing
15
00159962R08
3/12
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
Horizon, Maestro, Harmony, Ice Manager, SafeCLEAN, Sani-Sponge, RIDE and Vision are trademarks of Follett Corporation.
Chewblet is a registered trademark of Follett Corporation, registered in the US.
