Childrens video Walkie-
Talkie
Instruction Manual
1、 Appearance and functional description
2
12
1
3
10
4
9
5
6
14
15
7
13
1-
Return key 9-Intercom button/
2-
Antenna Confirm button
3-
Camera 10-Type-C interface
4-
Display Screen 11 -Charging indicator light
5-Volume up/up button 12- Lanyard hole
6-
Volume down/Down arrow 13- Horn
7-
Power switch 14- Left arrow key
8-
MIC hole 15- Right arrow key
II. Basic function operation of buttons
1) Short press the "+ " key to increase the volume. Short
press the "- " key to decrease the volume.
2) After selecting the function, please press the confirm
button (call button) to enter
3) To exit this function, please press the return button on the
right side.
4) Short press the "+ " key to increase the volume. Short
press the "- " key to decrease the volume.
5) In video mode and WeChat chat mode, long press the,
" " button to initiate voice communication. In video
intercom mode, transmission is through a one-way channel,
and only after the speaking party ends the conversation by
releasing the intercom button can the other party press and
hold the intercom button to send voice messages. When a
microphone icon appears on the screen, it indicates that the
other party is speaking.
III. Power-on and Power-off Functions
Turn the 'power switch', pull up to turn on, and pull down to
turn off.
When the power switch is turned upwards, the main interface
of the six-grid layout will appear, as shown below:
1-Video intercom
2-WeChat mode
3-Photo mode
4-Album Mode
5-Theme Mode
6- Game Mode
IV. Detailed explanation of the six major functions of the
main menu interface:
1-Video intercom
a. Short press the intercom button (confirmation button) to
make a call, and the recipient simply needs to short press the
call button to connect; b. Single press the right button to
switch the video window display; c. Single press the left
button to switch between four voice effects (original voice,
child voice, robot voice, and adult voice); d. Short press the
back button to return to the main menu.
2-WeChat
Upon entering the WeChat chat page, there are five functions
available at the bottom, arranged from left to right as follows:
Emoticons, voice chat, music, photography, and images
As shown in the figure below:
(1)
Emoji operation:
Short press the "Call/OK" button to enter the selection mode,
short press the "</M" or ">" button to select an expression,
and short press the "Call/OK" button to send
(2)
Voice intercom operation:
1)
Long press to activate voice chat, long press to speak,
release to end and send.
2)
Short press 'volume + or -' to query historical information,
and short press 'call/OK' to listen to historical voice. Press the
left or right button to exit the query information.
Note: Messages after the 8th will be automatically
overwritten and cleared. Restarting the device will
automatically clear all messages!
(3)
Music operation：
Short press the "Call/OK" button to enter the selection mode,
short press the "</M" or ">" button to select music, and
short press the "Call/OK" button to send.
(4)
Photography operation:
Short press the "Call/OK" button to enter the photo-taking
interface, take a photo, and send it directly.
(5)
Image processing:
Short press the "Call/OK" button to enter the image interface,
short press the "</M" or ">" button to select a picture, and
short press the "Call/OK" button to send.
3-
Take a photo :
Enter the photo interface and press the confirm/call button to
take a photo
4-
Photo album:
Enter the album interface, use the left and right buttons to
select pictures, briefly press the "Call/OK" button to view
photos, and press the back button to exit.
Deleting Photos: Select a photo, long press the "Call/OK"
button, use the left and right buttons to select "OK" to delete
a single photo, select "ALL?" to delete all photos, short press
the "Call/OK" button to confirm, or press the back button to
cancel the deletion.
5-
Theme mode:
Press the intercom button (confirmation button) briefly to
enter theme mode, press the left and right buttons briefly to
select the desired theme, and then press the confirmation
button
6-
Game mode:
Press the confirm button briefly to enter game mode. Both
players need to enter game mode together to automatically
start the game. Use the left and right buttons to select the
type, and press "Call/OK" briefly to confirm.
V. Charging Indication:
a.
Use the charging cable provided with this device, connect
it to the charger, and the power indicator light will turn "red".
When fully charged, the charging indicator light will
automatically turn off.
b.
Charger compatibility specification: 5V/1A.
c.
Before using this product for the first time, please fully
charge it.
VI.
Product power-on/off and automatic shutdown
functions:
This product enters working mode upon power-on; it remains
in working mode whether in use or not. When the product is
in a low battery state, it will automatically shut down. If you
stop using it, please set the toggle switch to the "OFF"
position. To restart the product, simply toggle the power
switch to "OFF" first, and then to "ON" to start it normally.
VII.
Product pairing and connection methods:
This product adopts a WIFI2.4G transmission and connection
mode; each package contains two intercoms, which have
been pre-paired. These two intercoms cannot be connected
to other devices for use. If multiple sets of products are
purchased, they can only be connected one-to-one on a set
basis, and multiple products cannot be connected and used
simultaneously.
VIII. Precautions:
a.
This product is suitable for outdoor use. Slight echo may
occur when used face-to-face at close range. This is a normal
acoustic feedback phenomenon.
b.
This device is not waterproof
C. The indoor distance of the product should be determined
based on the principle of ensuring smooth images.
IX. Product specifications
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the
following measures:
-
Reorient or relocate the receiving antenna.
-
Increase the separation between the equipment and
receiver.
-
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
-
Consult the dealer or an experienced radio/TV
technician for help.
NOTE 2: Any changes or modifications to this unit not expressly
approved by the party responsible for compliance could void
the user's authority to operate the equipment.
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure
condition without restriction.
Display
2.0 Inch lPS
CMOS pixel
30W
Batter y capacity
3.7V 400-650mAh
USB por t
Type-C
Operating temperature
-20°C~60°C
Storage temperature
-30°C~70°C
Power supply
5V/1A
Product dimensions
124mm*54mm*23mm
