Page 1
HALORC5 5-Button Remote Control
Model: HALORC5
Datasheet V1.
5-Button Remote Control
0
Model Description
HALORC5
A portable beacon product with a white housing, a metal middle frame, five
external buttons, and a blue LED light.(based on BLE 5.0 technology)
Page 2
HALORC5 5-Button Remote Control
The HALORC5 is an intelligent, lightweight positioning beacon utilizing Bluetooth Low Energy (BLE) 5.0
technology. Integrated with Halo's smart dog collar, it enables: canine training assistance, real-time
location tracking, and instant lost-pet alerts.
HALORC5 beacon advertises standard iBeacon and Eddystone (UID, INFO, TLM) simultaneously. The user
can configure HALORC5 beacon via configuration app BeaconSET+ as well.
Moreover, HALORC5 beacon device enables users to transmit distinct Bluetooth Low Energy (BLE)
broadcast packets via five dedicated tactile buttons, each short button press activates the integrated blue
LED for operational confirmation, alternates the BLE PHY broadcast rate between 125K (Long Range) and
1M (Standard) modes, and emits scenario-specific RSSI calibration parameters unique to each button,
where paired Halo dog collars execute corresponding commands upon receiving these broadcasts to
accommodate diverse use cases, with additional functionality available for custom implementation based
on specialized requirements.
FEATURE
- Advertise iBeacon & Eddystone simultaneously
- White colors by standard, other colors also can be customized
- Portable with key-chain hole
- Shutdown functionality is supported via the BeaconSET+ APP
- Five consecutive presses of the dot button activate fast broadcast mode for rapid device connection
- Long press the ‘dot’ button to power on the device
- Support OTA function (nRF52833 chipset)
- Easy to print customized logo
Page 3
APPLICATIO
HALORC5 5-Button Remote Control
N
It can be easily attach to daily items, such as smartphones, wallets, keys, handbags and suitcases etc.
ACTIVATE/TURN OFF HALORC5
• Pressing the ‘dot’ push button and keeping on 3 seconds;
• LED lights on 5 seconds then off, the device be activatedon;
•The HALORC5 Beacon also can be turned off by BeaconSET+ app;
CONFIGURATION TOOL
• BeaconSET+ (iOS & Android);
CERTIFICATION
• FCC Regulation (FCC Rule Parts 15C)
• CE Regulations (Included EN300328/301489/62368/62479)
• NCC Certification
• IC Certification
• CA65(Basic)-Common
• PFAS (Basic)-Common
• REACH/RoHS/UL 4200A-2023
ELECTRONIC PARAMETERS
Item Value Remarks
Battery Model 1*CR2032
Coin battery, replaceable
Operation Voltage 3V
DC
Transmission Range
Up to 500m on LOS In open field
Net Weight 17.7g
With battery
Color White
Null
Size 45*45*10.94mm Null
Page 4
BEACON PRE-CONFIGURATION
HALORC5 5-Button Remote Control
S
PACKAGING DETAILS
Details Carton
Quantity 200pcs per carton
Net Weight
3.54kgs
Gross Weight
7.9kgs
Size
32 x 23.5 x 40 cm
Page 5
HALORC5 5-Button Remote Control
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
IC warning
- English:
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada's licence-exempt RSS(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of
the device.
- French:
L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d'Innovation,
Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes :
1) L’appareil ne doit pas produire de brouillage;
2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
L'appareil a été évalué pour répondre aux exigences générales d'exposition aux RF. L'appareil peut être utilisé
sans restriction dans des conditions d'exposition portables.
