Refrigerator
use & care
A19894606 (January 2024)
Introduction .......................................................2
Important Safety Information ....................3
Features ............................................................6
Installation .........................................................7
Door Removal ................................................10
Door Handle Installation ............................. 12
Water Supply Connection .......................... 13
Controls and Settings ................................. 15
Automatic Ice and Water Dispenser ...... 19
Storage Features ........................................... 21
Normal Operating Sounds ........................ 22
Filter Replacement ...................................... 23
Care and Cleaning .......................................26
Troubleshooting ..........................................30
Limited Warranty ......................................... 34
2
INTRODUCTION
Doors
Handles are secure and tight
Door seals completely to cabinet on
all sides
Doors are level with each other.
Leveling
Appliance is level side-to-side and
tilted ¼" (6 mm) front-to-back
Toe grille is properly attached.
Cabinet is level on the floor.
Electrical Power
House power turned on
Appliance is plugged in
Ice Maker
House water supply connected
to appliance (Warning: Potable
water supply only.)
No water leaks present at all
connections - recheck in 24 hours
Ice maker is turned ON
Ice & water dispenser
operates correctly
Final Checks
Shipping material removed
Refrigerator and freezer tempera-
tures set to recommended setting
Crisper humidity controls set
(some models)
Registration card sent in
Installation Checklist
Lorem ipsum Lorem ipsumLorem i
psumLorem ipsumLorem ipsumLore
m ipsumLorem ipsum
Lorem ipsum Lorem ipsumLorem i
psumLorem ipsumLorem ipsumLore
m ipsumLorem ipsum
Lorem ipsum Lorem ipsumLorem
Serial Number Location
Welcome to our family
Thank you for bringing Frigidaire into
your home! We see your purchase as the
beginning of a long relationship together.
This manual is your resource for the use
and care of your product. Please read
it before using your appliance. Keep it
handy for quick reference. If something
doesn’t seem right, the troubleshooting
section will help you with common issues.
FAQs, helpful tips and videos, cleaning
products, and kitchen and home accessories
are available at Frigidaire.com.
We are here for you! Visit our website,
chat with an agent, or call us if you need
help. We may be able to help you avoid
a service visit. If you do need service, we
can get that started for you.
Let’s make it ocial! Be sure to register
your product.
Keep your product info here so it’s easy
to find.
Model Number ____________________
Serial Number ____________________
Purchase Date ____________________
3
WARNING
WARNING indicates a potentially haz-
ardous situation which, if not avoided,
could result in death or serious injury.
IMPORTANT
IMPORTANT indicates installation, oper-
ation or maintenance information which
is important but not hazard-related.
DANGER
DANGER indicates an imminently haz-
ardous situation which, if not avoided,
will result in death or serious injury.
CAUTION
CAUTION indicates a potentially haz-
ardous situation which, if not avoided,
may result in minor or moderate injury.
Safety Definitions
This is the safety alert symbol. It is
used to alert of potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible injury
or death.
WARNING
Please read all instructions before using
this appliance.
IMPORTANT SAFETY INFORMATION
DANGER
DANGER Risk of fire or explosion.
Flammable refrigerant used. Do not use
mechanical devices to defrost refrigera-
tor. Do not puncture refrigerant tubing.
DANGER Risk of fire or explosion.
Flammable refrigerant used. To be re-
paired only by trained service person-
nel. Use only manufacturer-authorized
service parts. Any repair equipment
used must be designed for flammable
refrigerants. Follow all manufacturer
repair instructions. Do not puncture
refrigerant tubing.
CAUTION
CAUTION Risk of fire or explosion.
Dispose of refrigerator properly
in accordance with the applicable
federal or local regulations. Flammable
refrigerant used.
CAUTION Risk of fire or explosion
due to puncture of refrigerant tubing.
Follow handling instructions carefully.
Flammable refrigerant used.
WARNING
CALIFORNIA RESIDENTS ONLY
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
4
IMPORTANT SAFETY INFORMATION
IMPORTANT
CFC/HCFC Disposal
Your old unit may have a cooling system
that used CFCs or HCFCs (chlorofluoro-
carbons or hydrochlorofluorocarbons).
CFCs and HCFCs are believed to harm
stratospheric ozone if released to the
atmosphere. Other refrigerants may
also cause harm to the environment if
released to the atmosphere.
If you are throwing away your old ap-
pliance, make sure the refrigerant is re-
moved for proper disposal by a qualified
technician. If you intentionally release
refrigerant, you may be subject to fines
and imprisonment under provisions of
environmental legislation.
Proper Disposal of your Appliance
Risk of child entrapment
Child entrapment and suocation are
not problems of the past. Junked or
abandoned appliances are still dangerous
– even if they will sit for “just a few days”.
If you are getting rid of your old unit,
please follow the instructions below to
help prevent accidents.
We strongly encourage responsible appli-
ance recycling/disposal methods. Check
with your utility company or visit
energystar.gov/recycle for more informa-
tion on recycling your old appliance.
Safety Instructions
• DO NOT store or use gasoline, or
other flammable liquids, or aerosols
within or in the vicinity of this or any
other appliance. Read product labels
for warnings regarding flammability
and other hazards.
• DO NOT operate the unit in the
presence of explosive fumes.
• Avoid contact with any moving parts
of automatic ice maker.
• Remove all staples from the carton.
Staples can cause severe cuts, and also
destroy finishes if they come in contact
with other appliances or furniture.
Child Safety
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
Destroy or recycle the carton, plastic
bags, and any exterior wrapping material
immediately after the appliance is
unpacked. Children should never use
these items to play. Cartons covered with
rugs, bedspreads, plastic sheets or stretch
wrap may become airtight chambers, and
can quickly cause suocation.
Before you throw away your appliance:
• Remove doors.
• Leave shelves in
place so children
may not easily
climb inside.
• Have refrigerant
removed by a
qualified service
technician.
WARNING
Do not use electrical appliances inside
the food storage compartments of the
appliance unless they are of the type
recommended by the manufacturer.
5
WARNING
These guidelines must be followed to
ensure that safety mechanisms in this
unit will operate properly.
Electrical information
• The appliance must be plugged into
its own dedicated 115 Volt, 60 Hz.,
15 Amp, AC only electrical outlet.
The power cord of the appliance
is equipped with a three-prong
grounding plug for your protection
against electrical shock hazards.
It must be plugged directly into a
properly grounded 3-prong recepta-
cle. The receptacle must be installed
in accordance with local codes and
ordinances. Consult a qualified elec-
trician. Avoid connecting the unit to a
Ground Fault Interrupter (GFI) circuit.
Do not use an extension cord or
adapter plug.
• If the power cord is damaged, it
should be replaced by an authorized
service technician to prevent any risk.
• Never unplug the appliance by pull-
ing on the power cord. Always grip
the plug firmly, and pull straight out
from the receptacle to prevent dam-
aging the power cord.
• Performance may be aected if the
voltage varies by 10% or more. Oper-
ating the appliance with insucient
power can damage the compressor.
Such damage is not covered under
your warranty.
• Do not plug the unit into an electrical
outlet controlled by a wall switch or
pull cord to prevent the unit from
being turned o accidentally.
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
IMPORTANT SAFETY INFORMATION
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break suddenly
if nicked, scratched, or exposed to sud-
den temperature change.
IMPORTANT
Turn o power to your appliance you
must unplug the power cord from the
electrical outlet.
6
A Fixed Door Bins
B Ice Maker
C Ice Container
D Shelves
E Damper/Air Filter Housing
F LED Lights
G Water Filter
H Dairy Compartment
I Temperature Sensor/Thermistor
J Adjustable Door Bins
K Deli Drawer (some models)
L Crisper Drawers
M Toe Grille
N Slide-Out Basket
*Features may vary according to model
L
M
N
B
C
D
E
F G
H
I
J
K
A
F
F
F
F
FEATURES
IMPORTANT
Accessories are available for your appliance and may be purchased at
Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in
Canada) or from an authorized seller.
7
INSTALLATION
NOTE
If your unit is placed with the door hinge
side against a wall, you may have to
allow additional space for the handle so
the door can be opened wider.
This Use & Care Manual provides general
operating instructions for your model. Use
the unit only as instructed in this Use &
Care Manual. Before starting the appli-
ance, follow these important first steps.
Installation
Installation clearances
• Allow the following clearances for ease
of installation, proper air circulation, and
plumbing and electrical connections:
Sides & Top ⅜"
Back 1"
Location
• Choose a place that is near a ground-
ed electrical outlet. Do Not use an
extension cord or an adapter plug.
• If possible, place the unit out of direct
sunlight and away from the range,
dishwasher or other heat sources.
• Install the appliance on a floor that is
level and strong enough to support a
fully loaded unit.
• Consider water supply availability for
models equipped with an automat-
ic ice maker. If you do not hook up
water to the appliance, remember to
turn the ice maker o.
CAUTION
Do Not install the unit where the tem-
perature will drop below 55°F (13°C) or
rise above 110°F (43°C). The compres-
sor will not be able to maintain proper
temperatures inside the appliance.
Do Not block the toe grille on the lower
front of your unit. Sucient air circula-
tion is essential for the proper opera-
tion of your appliance.
Toe Grille Installation and Removal
To install toe grille
1. Open both doors. Slide the left and
right sides of the toe grille over the
lower hinges of the appliance.
2. While pushing the toe grille firmly
against cabinet, fasten the bottom
clips of toe grille to the cabinet.
3. Fasten the top clips to the cabinet.
4. Close the doors. Fasten the right
and left side clips into the groove of
the bottom hinge.
To remove the toe grille
1. With both doors closed, unfasten
the right and left side clips of toe
grille from the bottom hinge groove.
2. Open both doors. Press firmly on the
top of the toe grille until the top of
the toe grille pops o.
3. Pull the toe grille outward toward
your body and o of the lower hinges.
1
2
3
2
3
1
4
4
Installing Toe Grille
1
2
3
2
3
1
Removing Toe Grille
WARNING
This appliance is intended for use
in residential household and similar
interior applications such as:
• a kitchen/kitchenette
• a pantry room
• a basement
• an enclosed garage
• other interior residential-type
environments
8
INSTALLATION
Door Opening
Position your unit to allow easy access to
a counter or table when removing food.
For the best use of drawers and freezer
baskets, position the appliance where
both doors can fully open.
NOTE
The doors are designed to shut by
themselves within a 20 degree opening.
Guidelines for final positioning
of your unit:
• Rest all 4 corners of the cabinet
firmly on the floor.
• Level the cabinet at the front and
rear so the front is raised ¼" (6 mm)
above the rear to ensure the door will
open/close and seal properly.
• Align the doors with each other
and level.
3. Ensure both doors are bind free
with their seals touching the cabinet
on all 4 sides.
1/4”
(6 mm)
1/4”
(6 mm)
A
B
Meet all of these conditions by
raising or lowering the adjust-
able leveling feet.
To level the cabinet using the front
leveling feet:
1. Open both doors and remove
the toe grille (see Toe Grille
Installation and Removal in the
INSTALLATION section).
2. Level the cabinet at the front and
rear so the front is raised ¼" (6 mm)
above the rear. Close the doors. Use
an adjustable wrench to loosen the
feet (A). Once you have lowered
the leveling feet slightly, use the
wrench on the nut (B) to lower
(counterclockwise) or raise (clockwise)
the front of the cabinet ensuring the
unit is sitting flat on the floor.
9
INSTALLATION
4. Reinstall the set screw, locking the
door height.
5. Replace the toe grille by fitting
it into place (see Toe Grille
Installation and Removal in the
INSTALLATION section).
2. If the freezer door is lower than
the refrigerator door (A) or the
refrigerator door is lower than the
freezer door (B), raise the door
by turning the adjustment screw
clockwise using a 10 mm wrench.
To level the doors using the adjustable
lower hinge:
1. Before leveling either door, remove
the set screw that locks the door
height into position using a
3
/
32
hex key.
10 mm
A B
Set Screw
Tornillo de
fijacion
Vis fixe
3
/
32
"
3
/
32
"
3. After leveling, verify the door stop
contacts the lower hinge and the
top of the door does not contact the
upper hinge through full movement
of the door (from fully closed to
fully open).
10 mm
Adjustment
Screw
El tornillo
de ajuste
Vis de
réglage
10
DOOR REMOVAL
To prepare for removing the doors:
1. Make sure the electrical power cord
is unplugged from the wall outlet.
2. Open both doors and remove the
toe grille (as explained in the Instal-
lation Instructions that came with
your appliance).
3. Remove any food from the door shelves.
4. Close the doors.
To remove the refrigerator door:
1. Remove the 3 screws from the cover
over the door hinge.
2. Lift hinge cover straight up and o.
3. Trace lightly around the door’s top
hinge with a pencil. This makes
reinstallation easier. Remove the 2
screws from the top hinge. Lift the
door o of the bottom hinge and set
it aside.
Rear Cover
Screw
Front Cover
Screws
Top
Hinge
Cover
Hinge
Screws
Top
Hinge
Socket
Wrench Set
Adjustable
Wrench
Top Hinge
Cover Front
Screw
Top
Hinge
Screw
Bottom
Hinge
Screw
Top Hinge
Cover Rear
Screw
Phillips™
Head
Tools Necessary:
or
or
⅜" Fixed
Wrench
Phillips™
Head
&
Flathead
Screwdriver
To reinstall the refrigerator door, reverse
the above steps.
Door
Hinge
Assembly
Closer
Pin
Hinge
Screws
Adjustable Hinge (some models)
4. Remove the 2 bottom hinge screws
and hinge if necessary.
11
DOOR REMOVAL
CAUTION
Be sure doors are set aside in a secure
position where they cannot fall and
cause personal injury.
Door
Hinge
Assembly
Screws
Water
Line
Tubing
Non-Adjusting Hinge (some models)
Closer
Pin
Hinge
Door
Water
Line
Tubing
Screws
Hinge
Assembly
Adjustable Hinge (some models)
To remove the freezer door:
1. Remove the 3 screws from the cover
over the top door hinge.
2. Lift hinge cover straight up and o.
3. Release the wires from the routing clip.
Disconnect the multi-wire cable
connector located above the top
hinge. Press the cable and lock and
separate the 2 cables.
4. Trace lightly around the hinge with a
pencil. This makes reinstallation easier.
5. Detach the water tube from the
connector located below the freezer
door. The connector releases when
you press its outer sleeve inward.
6. Remove the 2 screws from the top
hinge. Remove the hinge pulling the
multi-wire cable through it. Lift the
door o the bottom hinge.
7. Remove the 2 bottom hinge screws
and hinge if necessary.
8. Lay the door on its side to avoid
damage to the water tube extending
from the bottom hinge.
To reinstall the freezer door, reverse the
above steps.
To Disconnect
1. Press outer ring against face of
fitting
2. Pull to
remove tube
Insert tube and push until mark
touches face of fitting
To Connect
IMPORTANT
To prevent wire damage, ensure the
wires are rerouted through the routing
clip when reassembling the hinge cover.
12
DOOR HANDLE INSTALLATION
1. Remove handles from carton and
any other protective packaging.
2. Position the freezer handle end caps
over the upper and lower pre-in-
stalled shoulder bolts (A) that are
fastened into door, ensuring the
holes for the set screws are facing
toward the refrigerator door.
3. While holding the handle firmly
against door, fasten the upper and
lower Allen set screws (B) with the
supplied Allen wrench.
4. Repeat steps 2 and 3 to install refrig-
erator handle. Ensure the holes for
the set screws are facing towards the
freezer door.
Freezer
Upper
End Cap
Door
Refrigerator
Upper
End Cap
Door
Refrigerator
Lower
End Cap
Door
Freezer
Lower
End Cap
Door
Ensure Handle Set Screws are Facing Each Other with Doors Closed
CAUTION
Wear gloves and safety goggles and
use extreme CAUTION when installing
these handles. The rounded end of the
handles may be sharp (some models).
NOTE
Tighten and sub-flush all set screws (place the Allen set screw just below the sur-
face of the end cap) of the handle end cap. Draw the end caps tight to the freezer
and refrigerator doors with no gaps. To avoid scratching the metal door, keep the
door open while torquing down the set screws.
IMPORTANT
To ensure proper installation of handles,
please review these instructions and
illustrations thoroughly prior to installing
the handles.
Handles may vary according to model
13
WATER SUPPLY CONNECTION
Before Installing The Water Supply Line,
You Will Need:
• Basic Tools: adjustable wrench,
flat-blade screwdriver, and Phillips
TM
screwdriver
• Access to a household cold water
line with water pressure between 30
and 100 psi.
• A water supply line made of ¼" (6.4
mm) OD, copper or stainless steel
tubing. To determine the length of
tubing needed, measure the distance
from the ice maker inlet valve at the
back of the refrigerator to your cold
water pipe. Then add approximately
7� (2.1 m), so the refrigerator can be
moved out for cleaning.
To Connect Water Supply Line To Ice
Maker Inlet Valve
1. Disconnect the refrigerator from
electrical power source.
2. Place the end of the water supply
line into a sink or bucket. Turn ON
the water supply and flush the supply
line until the water is clear. Turn OFF
the water supply at the shuto valve.
3. Remove the plastic cap from the wa-
ter valve inlet and discard the cap.
4. If you use copper tubing - Slide the
brass compression nut, and then
the ferrule (sleeve) onto the water
supply line. Push the water supply
line into the water valve inlet as far
as it will go (¼"/6.4 mm). Slide the
ferrule (sleeve) into the valve inlet
and finger tighten the compression
nut onto the valve. Tighten another
half turn with a wrench; DO NOT
overtighten. See Figure 1.
• A shuto valve to connect the water
supply line to your household water
system. DO NOT use a self-piercing
type shuto valve.
• Do not reuse compression fitting or
use thread seal tape.
• A compression nut and ferrule
(sleeve) for connecting a copper
water supply line to the ice maker
inlet valve.
WARNING
To avoid electric shock, which can
cause death or severe personal injury,
disconnect the unit from electrical pow-
er source before connecting a water
supply line to the appliance.
CAUTION
To Avoid Property Damage:
• Use Copper or Stainless Steel braid-
ed tubing for the water supply line.
Frigidaire does not recommend wa-
ter supply tubing made of ¼" plastic.
Plastic tubing greatly increases the
potential for water leaks, and the
manufacturer will not be responsible
for any damage if plastic tubing is
used for the supply line.
• DO NOT install water supply tubing
in areas where temperatures fall
below freezing.
• Chemicals from a malfunctioning
softener can damage the ice maker.
If the ice maker is connected to soft
water, ensure that the softener is
maintained and working properly.
NOTE
Check with your local building authori-
ty for recommendations on water lines
and associated materials prior to in-
stalling your new refrigerator. Depend-
ing on your local/state building codes,
we recommend for homes with existing
valves its Smart Choice
®
water line kit
5304490728 (with a 6�Stainless Steel
Water Line) and for homes without an
existing valve, we recommend Smart
Choice
®
water line kit 5304490717 (with
a 20�copper water line with self-tap-
ping saddle valve). Please refer to
Frigidaire.com for more information.
IMPORTANT
Ensure your water supply line connections
comply with all local plumbing codes.
14
WATER SUPPLY CONNECTION
If you use braided flexible stainless
steel tubing - The nut is already
assembled on the tubing. Slide the
nut onto the valve inlet and finger
tighten the nut onto valve. Tighten
another half turn with a wrench; DO
NOT overtighten. See Figure 2.
IMPORTANT
After connecting the water supply, refer
to Priming the Water Supply System for
important information about priming an
empty water supply system.
Your refrigerator’s water supply system
includes several tubing lines, a water
filter, and a water valve. To ensure that
your water dispenser works properly,
completely fill this system with water
when you first connect your refrigerator
to the household water supply line.
5. With the steel clamp and screw,
secure the water supply line (copper
tubing only) to the rear panel of
refrigerator as shown.
6. Coil the excess water supply line
(copper tubing only), about 2½ turns,
behind refrigerator as shown and
arrange coils so they do not vibrate or
wear against any other surface.
7. Turn ON the water supply at shuto
valve and tighten any connections
that leak.
8. Reconnect the refrigerator to elec-
trical power source.
A B
C
D
E
F
G
H
I
Figure 1
A Plastic Water Tubing to
Ice Maker Fill Tube
B Steel Clamp
C Brass Compression Nut
D Ferrule (Sleeve)
E Copper Water Line
F Water Valve Bracket
G Valve Inlet
H Water Valve
I Copper Water Line from
Household Water Supply*
J Braided Flexible Stainless Steel
Water Line
K 6 ft. (1.8 m) Braided Flexible
Stainless Steel Water Line from
Household Water Supply*
*Include enough tubing in the loop to allow
moving the refrigerator out for cleaning
A B
J
F
G
H
K
Figure 2
15
CONTROLS AND SETTINGS
Sleep Mode
Sleep mode is default on. When sleep mode is on, the LEDs are not illuminated on the
display. Sleep mode can be changed to have the display on full time (Awake Mode).
While in sleep mode pressing any key will illuminate LEDs and then go back to sleep
after a short time. To turn sleep mode on/o, simultaneously press and hold Crush and
for 5 seconds. A tone will confirm.
Active Mode Display
Sleep Mode Display
Active Mode
To change from sleep mode (on) to active mode (o), simultaneously press and hold
Crush and for 5 seconds. The display will show the current temperature/ice maker
status. A tone will confirm.
NOTE
Your appliance may have some or all of the features listed below. Become familiar
with these features and their use and care.
16
CONTROLS AND SETTINGS
WARNING
When using the cold drink timer, make
sure to remove drinks from freezer
compartment when alarm sounds.
Carbonated drinks may explode if left
in freezer for too long.
1
Freeze Boost (on/o)
Activates a faster rate for freezing
food in the freezer. Use this feature
when loading several items into the
freezer at one time. It automatically
deactivates after 12 hours.
2
Cold Drink Timer
Quickly chills a drink inside the freez-
er compartment. To enable, touch
Cold Drink Timer. A time value will
appear on the freezer temp display
(in minutes) and can be changed
using the +/- buttons. A tone will
sound when the time has been input.
It ranges from 20-45 minutes in 5
minute intervals. Drinks will freeze if
the temperature setting is too low or
the timer setting is too long.
3
Ice Maker
Press and hold for 3 seconds to
turn the ice maker on/o. When
the indicator is lit, the ice maker is
on. When the ice maker is o, the
ice maker o indicator is lit. When
the ice maker is o, it will stop
making ice. While o, ice dispensing
can continue as long as there is
ice in the bucket. When the ice
maker is o and ice is dispensing,
the indicator above the ice maker
button and ice maker OFF will both
blink. If the display is in sleep mode,
you will have to wake it to confirm
the ice maker is on/o.
4
The lock button can be used to lock
the display preventing it from being
used in certain situations. Press
and hold for 3 seconds to enable/
disable. While in the locked state,
no changes can be made to settings
on the display. Dispensing ice and
water will be disabled. The indicator
will flash and an audible warning
tone sounds.
5
Power Outage
In the event of a power failure, the
Power Outage alert will illuminate
once power has been restored, and
a tone will sound. Press any button
to silence the tone.
Display
1
2
3
4
5
6
7
8 9
10 11 12
13
14
15
16
17
17
CONTROLS AND SETTINGS
°F/°C
To toggle between Fahrenheit (°F)
and Celsius (°C), simultaneously
press and hold + and - for 5 seconds
on refrigerator side of display.
Chill Boost
Chill Boost is a faster rate for
chilling food in the refrigerator
compartment. Use this feature
when loading several items into the
refrigerator at one time. Deactivates
after 6 hours.
Air Filter
The display shows the current
status of the air filter (Good, Order,
or Replace). To reset the filter
status to Good, press and hold Air
Filter for 3 seconds.
Water Filter
The display shows the current
status of the water filter (Good,
Order, or Replace). To reset the
filter status to Good, press and hold
Water Filter for 3 seconds.
Toggles dispenser light On and O.
13
14
15
16
17
Power
Outage
In the event of a power out-
age, the Power Outage alert
will illuminate once power
has been restored and a tone
will sound. Press any button
to silence the tone.
Door
Open
If you leave a door open for
5 minutes or more, an alarm
will sound and the Door
Open indicator will illuminate
on the display. Turn the alarm
o by closing the door or
pressing any key. The control
panel will return to normal
operations after you close
the door.
Alarms
6
Adjusting Temp
Illuminates when temperatures are
changed on the display and will
remain illuminated until the desired
temperatures are reached inside
the refrigerator and freezer. Press
either the + or - to adjust to desired
temperature setting.
Freezer temp
Control temperatures range from
-6°F / -21°C to +4°F / -15°C.
Refrigerator temp
The Control temperature ranges
from +33°F / +1°C to +43°F / +7°C.
This unit is designed to operate at
39°F refrigerator/0°F freezer. The
unit should stabilize temperatures
within 24 hours of installation.
Door Open
Illuminates whenever the doors are
open. If a door is left open for 5
minutes or more, an alarm will sound
and the display will be illuminated
until the doors are shut. Pressing
any button will mute the alarm
temporarily. Check to make sure no
food is blocking the doorway.
Replace Water Filter
Display illuminates every 6 months
or when filter needs replacing.
Replace filter and then press and
hold Reset Water Filter for 3
seconds to deactivate warning on
display. See FILTER REPLACEMENT
for more information.
Replace Air Filter
Display illuminates every 6 months
or when filter needs replacing.
Replace filter and then press and
hold Reset Air Filter for 3 seconds
to deactivate warning on display.
See FILTER REPLACEMENT for
more information.
Water
Press Water to dispense water. An
indicator light will be illuminated
above the active feature.
Cube
Press Cube to dispense cubed ice.
An indicator light will illuminate
above the active feature.
Crush
Press Crush to dispense crushed
ice. An indicator light will illuminate
above the active feature.
7
8
9
10
11
12
18
CONTROLS AND SETTINGS
Sabbath Mode
The Sabbath mode is a feature that
disables portions of the refrigerator
and its controls in accordance with
observance of the weekly Sabbath and
religious holidays within the Orthodox
Jewish community.
Turn the Sabbath mode ON and OFF by
simultaneously pressing and holding both
the — (freezer side) and + (refrigerator
side) for 5 seconds. Other than the High
Temp alarm, no audible sounds will occur
until you exit the Sabbath mode. The dis-
play shows Sb while in Sabbath mode.
Water
Filter
The water filter needs to be
replaced when the indicator
illuminates. Change the water
filter every 6 months or after
you have dispensed 120 gal-
lons of water. To reset, press
and hold the button for 3 sec-
onds. A tone will then sound.
Air
Filter
The air filter needs to be
replaced when the indicator
illuminates. Change the air filter
every 6 months. To reset, press
and hold the button for 3 sec-
onds. A tone will then sound.
Error
Tone
An alarm will sound if you try
to make a selection that is
not available.
High
Temp
In the event of the internal
temperature of the refriger-
ator rising and staying at a
temperature above the safe
temp zone for a period of
time, HI will display on the
corresponding compartment
display (refrigerator and/or
freezer). An alarm will sound
in addition to the display
warning every 10 seconds
until acknowledged. The
refrigerator will automatically
try to cool down to improve
the condition. However, if the
temperature has not cooled
after some time, the warning
and alarm will appear again.
If the problem continues
please call 1 (800) 374-4432.
In the Sabbath mode, the High Temp
alarm is active for health reasons. For
example, if the door is left ajar the High
Temp alarm is activated. The refrigerator
will function normally once the door
is closed, without any violation of the
Sabbath/Holidays. The High Temp
alarm is permitted when the cabinet
temperature is outside the safe zone for
20 minutes. The alarm silences itself after
10 minutes while the High Temp icon
stays lit until you exit the Sabbath mode.
For further assistance, guidelines
for proper usage and a complete
list of models with the Sabbath
feature, please visit the web at
star-k.org.
Alarms (continued)
NOTE
Although you have initiated the Sab-
bath mode, the ice maker will complete
the cycle it had already started. The
ice cube compartment will remain cold
and you can make new ice cubes with
standard trays.
NOTE
While in Sabbath mode, neither the lights,
dispenser, nor the control panel will work
until Sabbath Mode is deactivated.
The refrigerator stays in Sabbath mode
after power failure recovery. You must
deactivate it with the buttons on the
control panel.
NOTE
You should exit the Sabbath mode at
your earliest convenience as the unit
runs more eciently out of the Sab-
bath mode.
19
AUTOMATIC ICE AND WATER DISPENSER
Priming the water supply system
Ice maker operation & care
After you properly install the refrigerator
and it has cooled for several hours, the ice
maker can produce ice within 24hours.
The ice maker will fill the ice bin from the
rear. You must dispense some ice to force
the ice forward in the bin. This will allow
the bin to fill completely.
1. Begin filling
the system
by pressing
and holding
a drinking
glass against
the water
dispenser
paddle.
2. Keep the
glass in this
position until
water comes
out of the
dispenser. It may take about
1½ minutes. Water will sputter until
you purge all air from the water lines.
3. Continue dispensing water for about
4 minutes to flush the system
and plumbing connections of any
impurities (stopping to empty the
glass as necessary).
Power Outage
Cube
ICE
WATER
Crush
Door Open
High Temp
Replace Water Filter
Replace Air Filter
Dispenser
(varies by model)
CAUTION
For proper dispenser operation, the
recommended water supply pressure
should fall between 30psi and 100psi.
Excessive pressure may cause the sys-
tem to malfunction.
Turning the ice maker on
Ice production is controlled by the ice
maker's On/O feature on the control
panel. Pressing and holding the On/O
button toggles the ice maker On/O.
NOTE
Dispensed water is not chilled. For
colder water, add ice to cup or contain-
er before dispensing water.
NOTE
The ice maker also has a built-in plastic
signal arm that automatically stops ice
production when the ice bin is full. Do
not use this signal arm to manually stop
the ice maker.
NOTE
The water dispenser has a built-in de-
vice that shuts o the water flow after
3 minutes of continuous use. To reset
this shuto device, simply release the
dispenser paddle.
IMPORTANT
Turning o the ice maker simply dis-
ables ice making. You will still be able to
dispense existing ice, and you will still be
able to dispense water.
20
Ice Maker/Dispenser Tips
• Ice cubes stored too long may
develop an odd flavor. Empty the ice
container as explained in Cleaning the
Ice Storage Bin.
• Occasionally shake the ice container
to keep ice separated.
• If your refrigerator is not connected to
a water supply or the water supply is
turned o, turn O the ice maker.
• If you need a large quantity of ice
at one time, it is best to get cubes
directly from the ice container.
• The following sounds are normal
when the ice maker is operating:
- Motor running
- Ice dropping into ice container
- Water valve opening or closing
- Ice loosening from tray
- Running water
• When dispensing ice, you will hear a
snapping or clicking sound when the
ice chute opens and closes.
• Turn O the ice maker when cleaning
the freezer and during vacations. If
you turn O the ice maker for a long
period of time, you should also turn
o the water supply valve.
Cleaning the Ice Storage Bin
Clean the ice storage bin at regular
intervals, particularly before you take a
vacation or move.
To clean the ice storage bin:
1. Turn O the ice maker.
2. Remove the ice storage bin by lifting
up and out.
3. Empty and carefully clean the ice
storage bin with mild detergent.
Rinse with clear water. Do not use
harsh or abrasive cleaners.
CAUTION
Chemicals from a malfunctioning water
softener can damage the ice maker. If
the water supply to your refrigerator is
softened, be sure the softener is main-
tained to work properly.
CAUTION
NEVER use an ice pick or similar sharp
instrument to break up the ice. This
could damage the ice storage bin and
dispenser mechanism.
4. Allow the ice storage bin to dry com-
pletely before replacing it in the freezer.
5. Remove ice chips and clean the ice
storage bin, shelf and the freezer
door chute.
6. Replace the ice storage bin. Turn On
the ice maker to resume ice production.
Remove and empty the ice storage bin if:
• An extended power failure (1 hour or
longer) causes ice cubes in the ice
storage bin to melt and freeze togeth-
er, jamming the dispenser mechanism.
• You do not use the ice dispenser
frequently. Ice cubes will freeze
together in the bin, jamming the
dispenser mechanism.
Remove the ice storage bin and shake
to loosen the cubes or clean as
explained above.
AUTOMATIC ICE AND WATER DISPENSER
Auger
IMPORTANT
When removing or replacing the ice
storage bin, avoid rotating the auger in the
ice storage bin. If the auger is accidentally
rotated, you must realign the auger by
turning it in 45 degree turns (see below)
until the ice storage bin fits into place with
the drive mechanism If the auger is not
properly aligned when replacing the ice
storage bin, the refrigerator will not dis-
pense ice. The freezer door also may not
close properly causing warm air to leak
into the freezer compartment.
21
STORAGE FEATURES
Crisper Drawer
Crispers
Crispers allow you the flexibility to store
any manner of items including fruits, veg-
etables, nuts, etc. Crispers do not feature
humidity controls.
Deli Drawer (some models)
Some models are equipped with a Deli
Drawer for storing luncheon meats,
spreads, cheeses and other deli items.
This drawer does not have a separate
temperature control.
Deli Drawer
Glass shelves
Shelves are easily adjusted to suit individ-
ual needs. Before adjusting the shelves,
remove all food. Shelves are supported by
side rails. See Glass Shelves in CARE AND
CLEANING for proper shelf removal.
Door storage
Door bins and shelves are provided for
convenient storage of jars, bottles, and
cans. You can quickly select frequently
used items.
Some models have door bins that can
accommodate gallon-sized plastic drink
containers and economy-sized jars and
containers. Some bins are adjustable for
maximum storage capacity.
The dairy compartment, which is warmer
than the general food storage section,
is intended for short term storage of
cheese, spreads, or butter.
Dairy Bin and Door Bin
22
NORMAL OPERATING SOUNDS
Understanding the Sounds you
may Hear
Your new, high-eciency unit may intro-
duce unfamiliar sounds. These sounds
normally indicate your appliance is oper-
ating correctly. Some surfaces on floors,
walls, and kitchen cabinets may make
these sounds more noticeable.
Following is a list of major components
in your unit and the sounds they can cause:
A Evaporator Refrigerant through the
evaporator may create a boiling or
gurgling sound.
B Evaporator fan You may hear air be-
ing forced through the refrigerator
by the evaporator fan.
C Defrost heater During defrost cycles,
water dripping onto the defrost
heater may cause a hissing or sizzling
sound. After defrosting, a popping
sound may occur.
D Condenser fan You may hear air be-
ing forced through the condenser.
E Water valve Makes a buzzing sound
each time it opens to fill the ice maker.
F Drain pan (not removable) You may
hear water dripping into the drain
pan during the defrost cycle.
G Condenser May create minimal
sounds from forced air.
H Motorized damper May produce in-
termittent humming during operation.
I Ice chute When dispensing ice, you
will hear a snapping or clicking sound
when the solenoid opens and closes
the ice chute.
J Ice Maker When ice has been pro-
duced, you will hear ice cubes falling
into the ice bin.
I
E
G
H
F
J
NOTE
Energy ecient foam in your refrigera-
tor is not a sound insulator.
NOTE
During automatic defrost cycle, a red
glow in the back wall vents of your
freezer compartment is normal.
Compressor
Modern, high-eciency compressors run
much faster than previous models. The
compressor may have a noticeable hum or
pulsating sound during operation.
23
FILTER REPLACEMENT
Do not use with water that is microbiologi-
cally unsafe or of unknown quality without
adequate disinfection before or after the
system. Use systems certified for cyst
reduction on disinfected waters that may
contain filterable cysts.
Test & certification results:
• Rated Capacity - 125 gal/453 L for
PurePour and ice and water filter
• Rated service flow - .50 gal/min.
• Operating Temp.: Min. 33°F,
Max. 100°F
• Maximum Rated Pressure - 100 lbs/in.²
• Recommended Minimum Operating
Pressure: 30 lbs/in²
PurePour™
Water Filter
Keep safe, great-tasting water flowing
with a PurePour water filter. Using a Pure-
Pour water filter:
• Makes Safe Water Second Nature
PurePour water filters are certified
to reduce contaminants* and keep
great-tasting water flowing for you
and your family.
• Produces Purity You Can Trust
Know for certain your PurePour wa-
ter filter is a protector. Counterfeits
and knockos put your refrigerator
and health at risk. Frigidaire Genuine
Filters are the smarter, safer choice.
• Every Drop Gives Back
Partnered on sustainability eorts,
the use of a PurePour water filter
helps cut back on the cost and use of
plastic used to produce and package
bottled water
Ordering your replacement water filter
If you have not used your refrigerator for a
period of time (during moving for example),
change the filter before reinstalling
the refrigerator. To order your replacement
filters, please visit our online store at Frigid-
aire.com, by calling toll-free at 1-800-372-
4432, or by visiting the dealer where you
purchased your refrigerator. We recom-
mend you order extra filters when you first
install your refrigerator, and you replace
your filters at least once every 6 months.
Here are the product numbers to request
when ordering:
PurePour™ Water & Ice Refrigerator
Filter PWF-1™ FPPWFUO1
Replacing your water filter
The water filter is located at the top right
side of the refrigerator compartment. In
general, you should change the water fil-
ter every 6 months to ensure the highest
possible water quality. Water Filter Status
on the user interface prompts you to
replace the filter after a standard amount
of water (125 gal/453 L for PurePour)
has
flowed through the system.
NOTE
When you order your replacement filter,
please reorder the same filter type
currently in your refrigerator.
*Find the Performance Data Sheet
located in the Guides and Manuals
section for your specific water filter
on Frigidaire.com.
More about your advanced water filter
Certified by IAPMO R&T against NSF/ANSI
Standards 42, 53, 401, CSA B483.1 and
NSF/ANSI/CAN 372 in PurePour PWF-1
systems for reduction of the claims on the
Performance Data Sheet*.
24
FILTER REPLACEMENT
PureAir Ultra II™ Air Filter
Your appliance control display is
equipped with a REPLACE AIR FILTER
indicator to remind you to change your
filter every 6 months to ensure optimal
filtering of appliance odors. Your PureAir
Ultra II Air Filter is included in your Liter-
ature Pack in the crisper drawer. To order
replacement filters, please visit our online
store at Frigidaire.com, by calling toll-free
at 1 (800) 372-4432, or by visiting the
dealer where you purchased your unit.
Here are the product numbers to request
when ordering:
PureAir Ultra II™ Air Filter PAULTRA2
Replacing your air filter
You should change your air filter every
6 months (the filter status light on the
control panel prompts you to replace
the filter after 6 months) to optimize the
reduction of refrigerator odors. Dierent
foods will emit various levels of odor. To
install your new PureAir Ultra II air filter:
1. Pull the air filter housing straight
out.
2. Remove the old filter and discard it
(if applicable).
3. Unpack the new filter and place it
inside the housing.
4. Slide the housing back into position.
5. Activate or reset the Air Filter status
light on the control panel.
It is not necessary to turn the water
supply o to change the filter. Be ready
to wipe up any small amounts of water re-
leased during the filter replacement.
1. Turn O the ice maker.
2. Remove the filter by pushing on the
end/face of the filter.
3. Slide the old water filter cartridge
straight out of the housing and
discard it.
4. Unpackage the new filter cartridge.
Using the alignment guide, slide it
gently into the filter housing until it
stops against the snap-in connector
at the back of the housing.
5. Push firmly until the cartridge
snaps into place (you should hear a
click as the cartridge engages the
snap-in connector).
6. Press a drinking glass against the
water dispenser while checking for
any leaks at the filter housing. Any
spurts and sputters that occur as
the system purges air out of the
dispenser system are normal.
7. After filling one glass of water, con-
tinue flushing the system for about
4 minutes.
8. Turn On the ice maker.
9. Press and hold the Water Filter reset
button on the ice & water dispenser
control panel for 3 seconds. When
the display changes from red to
green, the status has been reset.
25
Damper/Air Filter Housing
In humid regions certain products stored
too close to the damper/air filter housing
may freeze. If this scenario occurs, adjust
the fresh food temperature settings and
reconfigure the top shelf storage to allow
for proper air diusion.
FILTER REPLACEMENT
PureAir Produce Keeper™
Keep fruits and vegetables fresher longer with
PureAir Produce Keeper. Our produce keeper
absorbs ethylene gas, the natural gas that
causes produce to ripen quicker. Reduce food
waste, save money and enjoy fresh-tasting
produce with a longer storage life.
Ordering your replacement filter
Order replacement filters online at
Frigidaire.com, by calling 1-800-374- 4432 or
through the dealer from which the refrigera-
tor was purchased. We recommend replacing
filters at least once every 6 months.
Here is the product number to request
when ordering:
PureAir Produce Keeper FRPAPKRF
Installing the PureAir Produce Keeper:
1. Remove the plastic wrapper. Insert the
unopened packet into the holder in the
rear of the Crisper.
2. For optimal results, replace the refill
every 6 months along with your air filter.
CAUTION
DO NOT OPEN. Contents may irritate
eyes or skin. Keep out of reach of children.
FIRST AID: Contains potassium perman-
ganate. In case of contact with eyes or
skin, rinse immediately with water.
DO NOT EAT: If swallowed, seek medical
treatment immediately.
26
CARE AND CLEANING
Protecting your investment
Keeping your appliance clean maintains
appearance and prevents odor build-up.
Wipe up any spills immediately and clean
the freezer and refrigerator compart-
ments at least twice a year. When clean-
ing, take the following precautions:
• Never use CHLORIDE or cleaners
with bleach to clean stainless steel.
• Do not wash any removable parts in
a dishwasher.
• Always unplug the electrical power cord
from the wall outlet before cleaning.
• Remove adhesive labels by hand. Do
not use razor blades or other sharp
instruments which can scratch the
appliance surface.
• Do not remove the serial plate.
Do not use abrasive cleaners such as win-
dow sprays, scouring cleansers, brushes,
flammable fluids, cleaning waxes, concen-
trated detergents, bleaches or cleansers
containing petroleum products on plastic
parts, interior doors, gaskets or cabinet
liners. Do not use paper towels, metallic
scouring pads, or other abrasive cleaning
materials or strong alkaline solutions.
CAUTION
• Pull the unit straight out to move
it. Shifting it from side to side may
damage flooring. Be careful not
to move the appliance beyond the
plumbing connections.
• Damp objects stick to cold metal
surfaces. Do not touch refrigerated
surfaces with wet or damp hands.
• Sudden temperature changes can
cause glass breakage.
NOTE
If you set your temperature controls
to turn o cooling, power to lights and
other electrical components will contin-
ue until you unplug the power cord from
the wall outlet.
IMPORTANT
If you store or move your unit in freez-
ing temperatures, be sure to completely
drain the water supply system. Failure to
do so could result in water leaks when
you put the unit back into service. Con-
tact a service representative to perform
this operation.
27
CARE AND CLEANING
Refrigerator Glass Shelf
Refrigerator: Shelves are easily adjusted
to suit individual needs. Before adjusting
the shelves, remove all food. Shelves are
supported by side rails.
To adjust, lift up on the back of the shelf
and pull forward.
Replace the shelf by sliding it on top of
the formed rails on the side walls of the
cabinet until the rear plastic hooks of the
shelf lock into the rear of the cabinet liner.
Glass Shelves
Freezer: You can remove the glass freezer
shelf for cleaning. Remove all food from
the glass shelf. Rotate the front trim down
to remove front trim (Figure 1).
CAUTION
To avoid personal injury or property
damage, handle the freezer glass shelves
carefully. These shelves are fixed and are
not to be used as sliding shelves.
Remove both the rear trim and glass by
pulling up on the rear tab and sliding the
shelf forward (Figure 2)
Figure 1
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break sudden-
ly if nicked, scratched, or exposed to
sudden temperature change. Allow the
glass shelves to stabilize to room tem-
perature before cleaning. Do not wash
in the dishwasher.
Figure 2
CAUTION
Allow the glass shelves to stabilize to
room temperature before cleaning. Do
not wash in the dishwasher.
28
To reassemble the freezer shelf, slide the
glass and rear trim along the shelf rails
while pressing the shelf downward until
it is fully locked into place in the rear
(Figure 3).
Figure 3
Finally, rotate the front trim upward on the
front edge of the glass shelf (Figure 4).
Figure 4
CARE AND CLEANING
29
CARE AND CLEANING
Care & Cleaning Tips
Part What To Use Tips and Precautions
Interior &
Door Liners
• Soap and water
• Baking soda and water
Use 2 Tbsp of baking soda in 1 qt
of warm water. Be sure to wring
excess water out of sponge or cloth
before cleaning around controls,
light bulb or any electrical part.
Door Gaskets • Soap and water Wipe gaskets with a clean soft cloth.
Drawers & Bins • Soap and water Use a soft cloth to clean drawer
runners and tracks.
Glass Shelves • Soap and water
• Glass cleaner
• Mild liquid sprays
See Glass Shelves in CARE AND
CLEANING before cleaning. Allow
glass to warm to room temperature
before immersing in warm water.
Toe Grille • Soap and water
• Mild liquid sprays
• Vacuum attachment
Vacuum dust from front of toe grille.
Remove toe grille (see Installation
Instructions). Vacuum backside,
wipe with sudsy cloth or sponge.
Rinse and dry.
Exterior & Handles • Soap and water
• Non Abrasive Glass
Cleaner
Do not use commercial household
cleaners containing ammonia,
bleach or alcohol to clean handles.
Use a soft cloth to clean smooth
handles. DO NOT use a dry cloth to
clean smooth doors.
Exterior & Handles
(Stainless Steel
Models Only)
• Soap and water
• Stainless Steel Cleaners
Never use CHLORIDE or cleaners
with bleach to clean stainless steel.
Clean stainless steel front and
handles with non-abrasive soapy
water and a dishcloth. Rinse with
clean water and a soft cloth. Use a
non-abrasive stainless steel cleaner.
These cleaners can be purchased at
most home improvement or major
department stores. Always follow
manufacturer’s instructions. Do not
use household cleaners containing
ammonia or bleach.
NOTE: Always clean, wipe and dry
with the grain to prevent scratch-
ing. Wash the rest of the cabinet
with warm water and mild liquid
detergent. Rinse well, and wipe dry
with a clean soft cloth.
30
1-800-265-8352 (Canada)
Frigidaire.ca
1-800-374-4432 (United States)
Frigidaire.com
TROUBLESHOOTING
Let us help you troubleshoot your concern! This section will help you with common
issues. If you need us, visit our website, chat with an agent, or call us. We may be able
to help you avoid a service visit. If you do need service, we can get that started for you!
CONCERN CAUSE SOLUTION
AUTOMATIC ICE MAKER
Ice maker is not
making any ice.
• Ice maker is turned o.
• Turn on ice maker. Press and hold the
On/O button for 3 seconds until the
indicator light is on.
Ice maker is
not making
enough ice.
• Check to see if water
dispenser is dispensing
slower than normal.
• Freezer control is set
too warm.
• If it is, replace the ice and water
filter cartridge.
• Set freezer control to colder setting to
improve performance of the ice maker.
Allow 24 hours for temperature to
stabilize.
Ice cubes are
freezing together.
• Ice cubes are not being
used frequently enough.
• Ice cubes are hollow
(partially frozen cubes
with water inside).
• Freezer control is set
too warm.
• Remove ice container and discard ice
from container. Ice maker will produce
fresh supply.
• The ice and water filter cartridge may be
clogged. Replace filter cartridge.
• Set freezer control to colder setting. Al-
low 24 hours for temperature to stabilize.
DISPENSER (Ice & Water)
Dispenser will
not dispense ice.
• Dispenser lock out
is engaged.
• There is no ice in the bin
to be dispensed.
• The refrigerator
doors are not complete-
ly closed.
• Dispenser paddle has
been pressed too long
and the dispenser motor
has overheated.
• Not dispensing ice
regularly may melt and
refreeze ice causing ice
clumping. Dispensing
clumps could damage
the ice bucket.
• Press and hold control lock for
3 seconds.
• See the Ice maker is not making any ice
section above.
• Be sure to close the
refrigerator completely.
• The motor overload protector will
reset in about 3 minutes, and then ice
can be dispensed.
• Empty the ice bucket monthly or regu-
larly dispense ice. For longer periods of
time (vacation or vacant homes) see Ice
Maker/Dispenser Tips in the AUTOMAT-
IC ICE AND WATER DISPENSER section
to turn o the ice maker.
Ice dispenser is
jammed.
• Ice has melted and fro-
zen around auger due to
infrequent use, tempera-
ture fluctuations, and/or
power outages.
• Ice cubes are jammed
between ice maker and
back of ice container.
• Remove ice container, thaw, and empty
the contents. Clean container, wipe dry,
and replace in proper position. When
new ice is made, dispenser should
operate. See Cleaning the Ice Storage
Bin in the AUTOMATIC ICE AND WATER
DISPENSER section.
• Remove ice cubes that are jamming
the dispenser.
31
TROUBLESHOOTING
CONCERN CAUSE SOLUTION
DISPENSER (Ice & Water) (Continued)
Dispenser will
not dispense
water.
• Water filter not
seated properly.
• Water filter is clogged.
• Household water line
valve is not open.
• Remove and reinstall the water filter. Be
sure to push the filter firmly so that you
hear it lock solidly into position.
• Replace filter cartridge. Be sure to
remove protective caps and push the fil-
ter firmly so that you hear it lock solidly
into position.
• Open the household water line valve.
Water has an
odd taste and/
or odor.
• Water has not been
dispensed for an ex-
tended period of time.
• Unit not properly con-
nected to cold water
line.
• Draw and discard 10-12 glasses of
water to freshen the supply.
• Connect unit to cold water line that
supplies water to the kitchen faucet.
Water pressure
is extremely
low.
• Cut-o and cut-on
pressures are too low
(well systems only).
• Reverse osmosis system
is in regenerative phase.
• Have someone turn up the cut-o
and cut-on pressure on the water
pump system (well systems only).
• It is normal for a reverse osmosis
system to be below 20 psi during
the regenerative phase.
• See the WATER SUPPLY CONNEC-
TION section.
Water not cold
enough.
• As warmer tap water
goes through the filter
and enters the water
tank the chilled water
is pushed through to
the dispenser. Once the
chilled water is used up
it will take several hours
to bring the freshly
replaced water to a
cooler temperature.
• Some models are de-
signed without a wa-
ter tank, these water
dispensing systems
are not designed to
chill water.
• Add ice to cup or container before
dispensing water.
• Add ice to cup or container before
dispensing water
OPENING/CLOSING OF DOORS/DRAWERS
Door(s) will not
close.
• Door was closed too
hard, causing other
door to open slightly.
• Refrigerator is not lev-
el. It rocks on the floor
when moved slightly.
• Refrigerator is touch-
ing a wall or cabinet.
• Close both doors gently.
• Ensure floor is level and solid, and
can adequately support the refriger-
ator. Contact a carpenter to correct
a sagging or sloping floor.
• Ensure floor is level and solid, and
can adequately support the refriger-
ator. Contact a carpenter to correct
a sagging or sloping floor.
32
CONCERN CAUSE SOLUTION
OPENING/CLOSING OF DOORS/DRAWERS (Continued)
Drawers are
dicult to move.
• Food is touching shelf
on top of drawer.
• Track that drawers slide
on is dirty.
• Remove top layer of items in drawer.
• Ensure drawer is properly installed
on track.
• Clean drawer, rollers, and track. See
CARE AND CLEANING.
RUNNING OF REFRIGERATOR
Compressor
does not run.
• Freezer control is set to
OF or 0.
• Refrigerator is in
defrost cycle.
• Plug at electrical outlet
is disconnected.
• House fuse blown or
tripped circuit breaker.
• Power outage.
• Set freezer control.
• This is normal for a fully automatic de-
frost refrigerator. The defrost cycle occurs
periodically, lasting about 30 minutes.
• Ensure plug is tightly pushed into outlet.
• Check/replace fuse with a 15 amp
time-delay fuse. Reset circuit breaker.
• Check house lights. Call local
electric company.
Refrigerator
runs too much
or too long.
• Room or outside
weather is hot.
• Doors are opened too
frequently or too long.
• Refrigerator/freezer
door may be
slightly open.
• Freezer control is set
too cold.
• Refrigerator/freezer
gasket is dirty, worn,
cracked, or poorly fitted.
• Condenser is dirty.
• It’s normal for the refrigerator to work
longer under these conditions.
• Warm air entering the refrigerator causes
it to run more. Open doors less often.
• Ensure refrigerator is level. Keep food
and contains from blocking door. See
PROBLEM column OPENING/CLOSING
OF DOORS/DRAWERS.
• Set Refrigerator control to warmer
setting until refrigerator temperature is
satisfactory. Allow 24 hours for tempera-
ture to stabilize.
• Clean or change gasket. Leaks in door
seal will cause refrigerator to run longer in
order to maintain desired temperatures.
• Clean condenser. See CARE
AND CLEANING.
Appliance seems
to run
continuously.
• Today's refrigerators are
designed with a variable
speed compressor to be
more energy ecient
than previous models.
This means your com-
pressor reacts quickly
to temperature fluctua-
tions and circulates cold
air based o your use
and room temperature.
• This is normal for a variable speed com-
pressor refrigerator; however, if you have
concerns, call 1-800-374-4432 (United
States) Frigidaire.com or 1-800-265-8352
(Canada) Frigidaire.ca.
DIGITAL TEMPERATURE DISPLAY
Digital tempera-
ture displays
are flashing.
• Electronic control
system has detected a
performance problem.
• Call your Frigidaire service representative,
who can interpret any messages or num-
ber codes flashing on the digital displays.
TROUBLESHOOTING
33
TROUBLESHOOTING
CONCERN CAUSE SOLUTION
WATER/MOISTURE/FROST INSIDE REFRIGERATOR
Moisture collects
on inside of
refrigerator walls.
• Weather is hot
and humid.
• Door is slightly open.
• The rate of frost buildup and internal
sweating increases.
• See PROBLEM column OPENING/CLOS-
ING OF DOORS/DRAWERS.
Water collects
on bottom side
of drawer cover.
• Vegetables contain and
give o moisture.
• It is not unusual to have moisture on the
bottom side of the cover.
• Move humidity control (some models) to
lower setting.
Water collects
in bottom
of drawer.
• Washed vegetables
and fruit drain while in
the drawer.
• Dry items before putting them in the
drawer. Water collecting in bottom of
drawer is normal.
Stored prod-
ucts on top
shelf freeze
• Fresh food temperature
setting too cold.
• Certain products stored
too close to damper /
air filter housing.
• Adjust fresh food temperature settings.
• Reconfigure top shelf storage to
allow proper diusion of air. See
Damper/Air Filter Housing in the
FILTER REPLACEMENT section.
WATER/MOISTURE/FROST OUTSIDE REFRIGERATOR
Moisture
collects on
outside of
refrigerator or
between doors.
• Weather is humid.
• Door is slightly open,
causing cold air from in-
side refrigerator to meet
warm air from outside.
• This is normal in humid weather.
When humidity is lower, the moisture
should disappear.
• See PROBLEM column OPENING/CLOS-
ING OF DOORS/DRAWERS.
LED LIGHTING
LED is
not working.
• LED is burned out. • To replace LEDs, contact a qualified
service technician.
34
LIMITED WARRANTY
Your appliance is covered by a one year limited warranty. For one year from your date of
delivery, Electrolux will pay all costs for repairing or replacing any parts of this appliance that
prove to be defective in materials or workmanship when such appliance is installed, used and
maintained in accordance with the provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be
readily determined.
2. Product that has been transferred from its original owner to another party or removed
outside the USA or Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship,
or for appliances not in ordinary household use or used other than in accordance with
the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use
your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim,
cupboards, shelves, etc., which are not a part of the appliance when it is shipped from
the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other
consumables, or knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service
calls, tolls, ferry trip charges, or mileage expense for service calls to remote areas,
including the state of Alaska.
12. Damages to the finish of appliance or home incurred during installation, including but
not limited to floors, cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of
parts other than genuine Electrolux parts or parts obtained from persons other than
authorized service companies; or external causes such as abuse, misuse, inadequate
power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL
BE PRODUCT REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON
IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD
ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. ELECTROLUX SHALL NOT BE LIABLE
FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND
INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED
WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR
LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the
warranty period should service be required. If service is performed, it is in your best interest
to obtain and keep all receipts. Service under this warranty must be obtained by contacting
Electrolux at the addresses or phone numbers below.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted
by Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In
Canada, your appliance is warranted by Electrolux Canada Corp. Electrolux authorizes no person
to change or add to any obligations under this warranty. Obligations for service and parts under
this warranty must be performed by Electrolux or an authorized service company. Product
features or specifications as described or illustrated are subject to change without notice.
USA
1-800-374-4432
Frigidaire
10200 David Taylor Drive
Charlotte, NC 28262
Canada
1.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
