ZKTeco SATURN-T1000 PRO User Manual

Product Name and Model Number User Manual

User Manual

Saturn-T1000 Pro

Date: September 2026

Doc Version: 1.0

English

Saturn-T1000 Pro User Manual

Without the prior written consent of ZKTeco, no portion of this manual can be copied or forwarded in any

way or form. All parts of this manual belong to ZKTeco and its subsidiaries (hereinafter the "Company" or

"ZKTeco").

Trademark

is a registered trademark of ZKTeco. Other trademarks involved in this manual are owned by

their respective owners.

Disclaimer

This manual contains information on the operation and maintenance of the ZKTeco equipment. The

the property of ZKTeco. The contents hereof should not be used or shared by the receiver with any third

party without express written permission of ZKTeco.

The contents of this manual must be read as a whole before starting the operation and maintenance of the

supplied equipment. If any of the content(s) of the manual seems unclear or incomplete, please contact

ZKTeco before starting the operation and maintenance of the said equipment.

It is an essential pre-requisite for the satisfactory operation and maintenance that the operating and

maintenance personnel are fully familiar with the design and that the said personnel have received

thorough training in operating and maintaining the machine/unit/equipment. It is further essential for the

safe operation of the machine/unit/equipment that personnel has read, understood and followed the

safety instructions contained in the manual.

In case of any conflict between terms and conditions of this manual and the contract specifications,

drawings, instruction sheets or any other contract-related documents, the contract conditions/documents

shall prevail. The contract specific conditions/documents shall apply in priority.

ZKTeco offers no warranty, guarantee or representation regarding the completeness of any information

contained in this manual or any of the amendments made thereto. ZKTeco does not extend the warranty

of any kind, including, without limitation, any warranty of design, merchantability or fitness for a particular

purpose.

ZKTeco does not assume responsibility for any errors or omissions in the information or documents which

are referenced by or linked to this manual. The entire risk as to the results and performance obtained from

using the information is assumed by the user.

ZKTeco in no event shall be liable to the user or any third party for any incidental, consequential, indirect,

special, or exemplary damages, including, without limitation, loss of business, loss of profits, business

interruption, loss of business information or any pecuniary loss, arising out of, in connection with, or

Saturn-T1000 Pro User Manual

relating to the use of the information contained in or referenced by this manual, even if ZKTeco has been

advised of the possibility of such damages.

This manual and the information contained therein may include technical, other inaccuracies or

typographical errors. ZKTeco periodically changes the information herein which will be incorporated into

new additions/amendments to the manual. ZKTeco reserves the right to add, delete, amend or modify the

information contained in the manual from time to time in the form of circulars, letters, notes, etc. for better

operation and safety of the machine/unit/equipment. The said additions or amendments are meant for

improvement /better operations of the machine/unit/equipment and such amendments shall not give any

right to claim any compensation or damages under any circumstances.

ZKTeco shall in no way be responsible (i) in case the machine/unit/equipment malfunctions due to any

non-compliance of the instructions contained in this manual (ii) in case of operation of the

machine/unit/equipment beyond the rate limits (iii) in case of operation of the machine and equipment in

conditions different from the prescribed conditions of the manual.

The product will be updated from time to time without prior notice. The latest operation procedures and

relevant documents are available on http://www.zkteco.com

If there is any issue related to the product, please contact us.

ZKTeco Headquarters

Address ZKTeco Industrial Park, No. 32, Industrial Road,

Tangxia Town, Dongguan, China.

Phone +86 769 - 82109991

Fax +86 755 - 89602394

For business related queries, please write to us at: sales@zkteco.com.

To know more about our global branches, visit www.zkteco.com.

Saturn-T1000 Pro User Manual

About the Company

ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial, Finger-vein)

readers. Product offerings include Access Control readers and panels, Near & Far-range Facial Recognition

Cameras, Elevator/floor access controllers, Turnstiles, License Plate Recognition (LPR) gate controllers and

Consumer products including battery-operated fingerprint and face-reader Door Locks. Our security

solutions are multi-lingual and localized in over 18 different languages. At the ZKTeco state-of-the-art

700,000 square foot ISO9001-certified manufacturing facility, we control manufacturing, product design,

component assembly, and logistics/shipping, all under one roof.

The founders of ZKTeco have been determined for independent research and development of biometric

verification procedures and the productization of biometric verification SDK, which was initially widely

applied in PC security and identity authentication fields. With the continuous enhancement of the

development and plenty of market applications, the team has gradually constructed an identity

authentication ecosystem and smart security ecosystem, which are based on biometric verification

techniques. With years of experience in the industrialization of biometric verifications, ZKTeco was

officially established in 2007 and now has been one of the globally leading enterprises in the biometric

verification industry owning various patents and being selected as the National High-tech Enterprise for 6

consecutive years. Its products are protected by intellectual property rights.

About the Manual

This manual introduces the operations of Saturn-T1000 Pro Tripod Turnstile.

All figures displayed are for illustration purposes only. Figures in this manual may not be exactly consistent

with the actual products.

Features and parameters with ★ are not available in all devices.

Saturn-T1000 Pro User Manual

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to avoid danger or

property loss.

The precaution measure is divided into Dangers and Cautions:

Dangers: Neglecting any of the warnings may cause serious injury or death.

Cautions: Neglecting any of the cautions may cause injury or equipment damage.

Symbols

Convention Description

Dangers: Follow these safeguards to prevent serious injury or death.

Cautions: Follow these precautions to prevent potential injury or material damage.

Dangers:

 In the use of the product, you must be in strict compliance with the electrical safety regulations of the

nation and region.

 The equipment must be connected to an earthed mains socket-outlet.

 Shock hazard! Disconnect all power sources before maintenance.

 Do not touch the bare metal contacts of the inlets after the circuit breaker is turned off. Electricity still

exists.

 To prevent possible hearing damage, do not listen at high volume levels for long periods.

 All the electronic operation should be strictly compliance with the electrical safety regulations, fire

prevention regulations and other related regulations in your local region.

 Please use the power adapter, which is provided by normal company. The power consumption cannot

be less than the required value.

 Do not connect several devices to one power adapter as adapter overload may cause over-heat or fire

hazard.

 Please make sure that the power has been disconnected before you wire, install or dismantle the

device.

 If the top caps should be open and the device should be powered on for maintenance, make sure:

1. Power off the fan to prevent the operator from getting injured accidentally.

2. Do not touch bare high-voltage components.

3. Make sure the switch's wiring sequence is correct after maintenance.

 Please make sure that the power has been disconnected before you wire, install or dismantle the

Saturn-T1000 Pro User Manual

device.

 If smoke, odors or noise rise from the device, turn off the power at once and unplug the power cable,

and then please contact the service center.

 If the product does not work properly, please contact your dealer or the nearest service center. Never

attempt to disassemble the device yourself. (We shall not assume any responsibility for problems

caused by unauthorized repair or maintenance.)

 The Terminal PE of the switch should be connected to a ground wire.

Cautions:

 Instructions must be read before installation. Please follow these instructions carefully, incorrect

installation could affect gate operation.

 When mounting and positioning this product please ensure the power cable is unplugged.

 The motor cover will need to be removed to mount the motor to the mounting plate. Electrical-related

operation of the main unit can only be made by a licensed electrician.

 To prevent injury, this equipment must be securely attached to the floor/base of the turnstile in

accordance with the installation instructions.

 Keep straight down when moving or using the equipment.

 Never place the equipment in an unstable location. The equipment may fall, causing serious personal

injury or death.

 Cold-rolled SPCC steel may be corroded in some circumstances. You need to clean and care the device

by using the stainless steel cleaner. It is suggested to clean the device every month.

 Do not drop the device or subject it to physical shock, and do not expose it to high electromagnetism

radiation. Avoid the equipment installation on vibrations surface or places subject to shock (ignorance

can cause equipment damage).

 Do not place the device in extremely hot (refer to the specification of the device for the detailed

operating temperature), cold, dusty or damp locations, and do not expose it to high electromagnetic

radiation.

 The device cover for indoor use shall be kept from rain and moisture.

 Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is

forbidden (ignorance can cause fire danger).

 Do not aim the device at the sun or extra bright places. A blooming or smear may occur otherwise

(which is not a malfunction however), and affecting the endurance of sensor at the same time.

 Please use the provided glove when open up the device cover, avoid direct contact with the device

cover, because the acidic sweat of the fingers may erode the surface coating of the device cover.

 Please use a soft and dry cloth when clean inside and outside surfaces of the device cover, do not use

alkaline detergents.

 Please keep all wrappers after unpack them for future use. In case of any failure occurred, you need to

Saturn-T1000 Pro User Manual

return the device to the factory with the original wrapper. Transportation without the original wrapper

may result in damage on the device and lead to additional costs.

 Improper use or replacement of the battery may result in hazard of explosion. Replace with the same

or equivalent type only. Dispose of used batteries according to the instructions provided by the

battery manufacturer.

 Biometric authentication products are not 100% applicable to anti-spoofing environments. If you

require a higher security level, use multiple authentication modes.

 Do not stay in the lane when the device is rebooting.

 RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES

ACCORDING TO THE INSTRUCTIONS.

 SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY.

 The instructions shall require connection of the equipment protective earthing conductor to the

installation protective earthing conductor.

Saturn-T1000 Pro User Manual

Table of Contents

1 OVERVIEW ............................................................................................................................................ 9

Key Features ................................................................................................................................................................................................ 9

Specification ............................................................................................................................................................................................. 10

1.2.1 Appearance ................................................................................................................................................................................................... 10

1.2.2 System Components .................................................................................................................................................................................. 11

1.2.3 Technical Specifications ............................................................................................................................................................................ 11

Mechanical System ................................................................................................................................................................................. 13

Electronic Control System ................................................................................................................................................................... 13

Working Principle ................................................................................................................................................................................... 14

Power-On Self-Test ................................................................................................................................................................................. 14

Status of Traffic Indicator ..................................................................................................................................................................... 15

2 AUTHENTICATION METHODS ........................................................................................................... 16

Card Verification★ ................................................................................................................................................................................. 17

QR Code Verification★ ......................................................................................................................................................................... 17

Facial Verification★ ............................................................................................................................................................................... 18

3 CONTROL SYSTEM DESCRIPTION ..................................................................................................... 20

Wiring Diagram ........................................................................................................................................................................................ 20

Motherboard Function Description ................................................................................................................................................. 20

4 TROUBLESHOOTING.......................................................................................................................... 22

5 PRECAUTION ...................................................................................................................................... 23

6 MAINTENANCE .................................................................................................................................. 24

Chassis Maintenance ............................................................................................................................................................................. 24

Movement Maintenance ...................................................................................................................................................................... 24

Power Supply Maintenance ................................................................................................................................................................ 24

7 PACKING LIST .................................................................................................................................... 25

REVISION HISTORY ................................................................................................................................... 26

Saturn-T1000 Pro User Manual

1 Overview

The Saturn-T1000 Pro full-automatic tripod turnstile features stable product performance and outstanding

waterproofing effects, making it suitable for fully outdoor installation. The product housing is made of

electrolytic plate baking paint material, combined with an integrally molded top cover, offering a compact

and aesthetically pleasing appearance, rust resistance, and durability. The system adopts standard

electrical interfaces externally and meets fire protection channel requirements. It is suitable for

entrance/exit attendance, access control, and consumption management in enterprises and public

institutions, as well as special channel management and control. It also meets ticket-checking channel

management needs in places such as railway stations, ferry terminals, convention and exhibition centers,

and swimming pools.

Key Features

Full-automatic tripod turnstile mechanism with user-friendly passage indication – light touch for

automatic passing.

Reinforced waterproof design, IPX4 rating, suitable for outdoor use in open air.

Equipped with an RS485 communication interface to support system integration.

Modular construction for easy maintenance.

Wired in accordance with international telecommunication standards; internal circuit wiring and

layout are extremely neat.

Features automatic drop-arm on power failure and automatic raise-arm on power recovery, plus

complete anti-tailgating functionality.

Integrates ZKTeco’s hybrid biometric recognition technology, combining facial recognition, QR code

scanning, card swiping and other verification methods to enhance security identification.

Can connect to control signals from any external control device, buttons, or remote controls to

achieve one-way or two-way controlled passage.

Clear passage direction indication function, equipped with a standard three-color indicator light: blue

in normal status, green during passage, red in abnormal status.

Simple installation process.

Saturn-T1000 Pro User Manual

Specification

1.2.1 Appearance

Saturn-T1000 Pro User Manual

1.2.2 System Components

1. Authentication Units 2. Traffic Indicator

3. Facial Authentication Terminal Mounting Holes 4. LiDAR (optional)

5. Arm 6. Disk Wheel

7. Cover Plate

1.2.3 Specifications

Model Saturn-T1000 Pro

Audio Indicator

Internal Buzzer

Visual Indicator

LED Indicator

Blue=Standby

Green=Access Granted

Red=Alarm/Error

LiDAR Sensor

(dToF Technology)

N/A (standard); 2 pcs (optional)

Lane Type

Single Lane

Saturn-T1000 Pro User Manual

(Support bi-directional entry/exit lane)

Lane Width

550mm

Barrier Movement Type

Rotating (Tripod)

Lid Material

Polycarbonate+2.5D tempered glass

Lid Options

Authentication Methods

RFID / Facial Authentication / QR code (Dynamic / Static)

Chassis Material

Electro-galvanized steel plate, with baked enamel finish. (T=1.0mm)

Chassis Color

Pearl White (PWH)

Tripod Rod Material

SUS304 Stainless Steel

Motherboard Function

Tripod release duration, Access mode configuration

Motherboard

Communication

Fire Alarm Port (Relay)*1, RS485 Port*1

Controller

Access controller Options: C3, InBio series or third-party controller

subject to turnstile chassis space

Credential Options

Post mount Facial Authentication Device: G4 Pro

Under mount QR code Reader: QR500

Under mount RFID Reader: ProID10

Flow Rate

Face: 15 Passengers per minute

RFID: 25 Passengers per minute

QR code: 25 Passengers per minute

Power Supply

AC 110V~220V, 50/60Hz, DC 12V

Power Rating

Operating: 40W, Standby: 10W

Fire Signal

Input for voltage-free contact

Noise Level

＜65dB

MCBF

5 Million

Weight

25kg

Dimensions (L*W*H)

1200*734*1020mm

Dimensions with Packaging

(L*W*H)

1300*305*1106mm

Operating Temperature

-20℃ to 70℃

Operating Humidity

20% to 80% RH (non-condensing)

Certifications

CE, FCC

Ingress Protection Rating

Self-laboratory test: equivalent to IPX4

Supported Software

ZKBio CVAccess/ ZKBio CVSecurity

(Compatible with software only when connected to the control

Saturn-T1000 Pro User Manual

panel)

Safety Features

Auto drop arm during power failure and emergency

Security Features

Anti-tailgating

Product Delivery

Pre-assembled

Application Environment

Indoor/Outdoor (If sheltered)

Site Preparation

Flat and level finished floor (optional base plate for unfinished floors)

Security Level

Middle

Emergency Mode

Drop arm function engages during power outage or fire alarm events

Packing Material

Carton box

Mechanical System

The mechanical system of the tripod turnstile includes the chassis and the core component. The chassis

serves as a carrier for the tri-color indicator, Reader, and Access controller. The core components primarily

include the Motor, Frame, Bearing, Arm, and other essential elements.

Electronic Control System

The electronic control system of a tripod turnstile mainly consists of the Card Reader, Turnstile Control

Board, Access Controller, Alarm and Traffic Indicator.

Card Reader: The reader reads the data on the card and transmits it to the Access Controller.

Turnstile Control Board: The turnstile control board serves as the control center of the system, receiving

signals from the access controller and photoelectric switch; and it makes logical judgments and processes

these signals, then subsequently sends executive commands to the traffic indicator, motor, and alarm.

Access Controller: This component enhances convenience for authorized personnel by facilitating entry

while simultaneously restricting access for unauthorized individuals.

Traffic Indicator: Displays the current passage status of the channel and guiding pedestrians to pass

through the channel in a safe and orderly manner. (Normal status: Blue; Passage allowed: Green;

Abnormal/Error status: Red)

Alarm: This system issues an alarm alert when the system detects unauthorized entry or illegal access by

pedestrians.

Saturn-T1000 Pro User Manual

Working Principle

1. When connected to power, the tripod turnstile undergoes a Power-On Self-Test. If no issues are

detected during this process, the turnstile will operate normally.

2. When the card reader successfully reads a valid card, the peak buzzer emits a pleasant sound,

signalling to pedestrians that the card reading is successful. Simultaneously, the system processes the

information from the card, sending a signal to the turnstile control board to request passage.

3. The turnstile control board receives the signal from the card reader, processes it comprehensively,

and sends an effective control signal to the indicator and motor. The traffic indicator turns green, and

the control board activates the electromagnet to open the gate. The pedestrian pushes the boom

following the indicator light, and the boom rotates automatically to facilitate pedestrian passage.

4. If a pedestrian enters the passage without successfully verifying their identification or with an invalid

card, the system will not grant passage. Only when a valid card is successfully confirmed will the

pedestrian be allowed to pass through the passage.

Note: Make sure the ground wire of the system is securely connected to avoid personal injuries or other

accidents.

Power-On Self-Test

1. Connect the turnstile to AC 110V~220V, 50/60Hz, DC 12V power supply.

2. Turn on the power switch of the turnstile and wait 30 seconds for the self-test procedure to complete.

3. The turnstile will automatically raise the arm, as shown in the figure.

Air switch

Saturn-T1000 Pro User Manual

4. Use the two-way switch to test whether the turnstile is working properly, and simultaneously check

whether the passage indicator light is functioning correctly. If any abnormality occurs, please contact

your distributor.

Status of Traffic Indicator

The tripod turnstile is in working state after power-on self-test. The traffic indicators provide pedestrians

with the appropriate passage indications.

Passage allowed: Abnormal/Error:

Saturn-T1000 Pro User Manual

2 Authentication Methods

Users can freely choose to configure the authentication module according to actual needs. The following

options are included.

Streamlined Under Mount Options:

RFID only, RFID & QR Code.

Surface Mount Option:

Mounting Pole (Compatible with ProFace X series / SpeedFace V5L / ProFace X[CH]).

Saturn-T1000 Pro User Manual

Card Verification★

When the device is configured with a card swipe module, the Card Verification mode compares the card

number in the card induction area with all of the card number data registered in the device and sends it to

the Access Controller.

When a user presses his / her card on the card reading area, the device enters card authentication mode.

QR Code Verification★

The QR code Verification mode is to scan the QR code on the user's mobile phone through the QR code

scanner and compare the data with the registered QR code, and then sends it to the Access Controller.

When the user places the mobile phone displaying with the QR code on top of the QR code scanner, the

device enters the QR code authentication mode.

Saturn-T1000 Pro User Manual

Facial Verification★

In this verification mode, the device compares the collected facial images with all face data registered in

the device and then sends it to the Access Controller.

Try to keep the face in the centre of the screen during authentication. Please face towards the camera and

stay still during face registration.

Recommended Standing Posture and Facial Expression:

Note: Please keep your facial expression and standing posture natural while enrollment or verification.

Facial Authentication Terminal Installation:

1. Remove the top cover plate and route the unit's cables through the pre-drilled mounting holes.

2. Pass the mounting bracket through the mounting holes.

3. Place the gasket and nut and tighten the nut to secure the unit.

4. Adjust the unit to a suitable angle.

Saturn-T1000 Pro User Manual

3 Control System Description

Wiring Diagram

Motherboard Function Description

Operating Instructions

1. There are four operation buttons on the keypad: "MENU", "MODE", "ADD" and "DEC".

2. Button operation instructions:

The first button on the menu control panel is the menu button. Press and hold it to enter the menu

options.

After entering the menu, briefly press the second button to cycle through the menu function options.

The third and fourth buttons are for selecting menu function values. Use them to adjust the function

parameters up or down. After completing the adjustment, press and hold the first button to save the

parameters.

Saturn-T1000 Pro User Manual

Menu Description

Note: The codes in the following table are not listed in sequential order.

Code Menu Items Options/ Values Description

01EXXX Display Mode

0--Display current gate

position

1--Infrared input signal

2--Control input signal

3--Test mode

4--Version number

5--Hidden menu

Display description: XFX、XXX

1. Device status

2. Device status

3. Display status

4. Version number

02EXXX Device Mode

1--Controlled entry and exit

(default 1)

2--Controlled entry, free exit

3--Free entry, controlled exit

4--Free entry and exit

5--Controlled entry,

prohibited exit

6--Prohibited entry,

controlled exit

7--Free entry, prohibited exit

8--Prohibited entry, free exit

9--Prohibited entry and exit

03EXXX Opening Speed 5-32 (default 17)

Higher value = faster opening

speed

06EXXX Closing Speed 5-32 (default 17)

Higher value = faster closing

speed

07EXXX

Closing Deceleration

Stroke

0~50 (default 20)

Higher value = longer

deceleration stroke

10EXXX RS485 Address 0~254 (default 0)

11EXXX

Auto-close Time

When No One Passes

2~60 (default 5)

Unit: S, Lower value = faster

closing time

13EXXX

End Position

Adjustment

1--Closed position

adjustment

Position can only be adjusted

when in place

14EXXX Opening Memory

0--Disabled (default 0)

1--Enabled

16EXXX

Voice Volume

Adjustment

1~100 (default 70) Higher value = louder volume

17EXXX Disable Alarm Tone

0--Disable

1--Enable (default 1)

Saturn-T1000 Pro User Manual

24EXXX Factory Reset 1--Restore factory settings

Hidden Menu (To view, set "01EXXX" to "5" to display items 30-39)

40EXXX Sensor Type 0~5 (default 0)

0--Standard photoelectric

sensor

1--Laser radar

2-5--Reserved

Error Codes

ER0002 - Self-test failed, Hall sensor detection error

ER0004 - Operation timeout

ER0008 - Clutch locked

ER016 - Encoder disk detection failed

ER032 - Stall protection

4 Troubleshooting

Failure Description Solution

Passage indicator light does not respond or

indicates incorrectly

Loose or incorrect wiring of the control board

backlight.

1. Inspect the backlight wiring of the control board.

2. Ensure all connections are secure.

3. Re-connect any loose wiring if necessary.

No arm raise on power-on, no arm drop on

power-off

Check whether the solenoid valve (drop-arm

solenoid) wiring connection is secure or if the

screws are loosen. Tighten the loose screws if

necessary.

Turnstile does not open after verification

Check user permissions and wiring.

1. Check whether the user has permission to open

the turnstile.

2. Refer to the wiring diagram to check the main

board wiring.

Saturn-T1000 Pro User Manual

5 Precaution

1. It is recommended to purchase optional accessories to use in outdoor environment.

a) Install optional cooling fans if the working temperature frequently exceeds 50°C.

b) Proper installation makes it equivalent to IPX4 waterproof, but it cannot withstand regions

prone to typhoons.

c) For temperatures below -30°C, consider installing a heating plate. Allow time for automatic self-

checking during power-on in extreme cold conditions.

d) Note that using the equipment in coastal areas or regions with acid rain may reduce its service

life.

2. When power and signal cables are correctly connected, the equipment can be submerged up to a

depth of 250 mm in water. Do not power on the equipment when submerged in water to prevent

operational issues.

3. It is highly recommended to set up a card swiping warning line to prompt passers-by to swipe cards

properly. Establish a reasonable passage width to prevent illegal squeezing by passers-by.

4. It is recommended to place a warning sign at a conspicuous position. The sign should prompt:

"Please swipe your card outside the warning line and pass in order. Thank you!”

The maximum tolerance of the tripod turnstile's arms

Note that the maximum stress tolerance at the center of the arm is 80kg, while at the ends of the arm, it is

40kg. In the event of an impact force reaching the designed limit on the tripod turnstile, the arms are

engineered to detach first as a safety mechanism. This is a safety feature to prevent damage to the entire

equipment and ensure the safety of passers-by.

In case of emergencies

The equipment is designed to automatically drop the arms during a power failure, enabling open passage

for safe egress. Furthermore, the turnstile control board offers an interface to connect an emergency

switch (Drop Arm), maintaining the tripod turnstile in an open position during emergencies. Note: After

power is restored, wait at least 6 seconds before manually lifting the arms.

Saturn-T1000 Pro User Manual

6 Maintenance

Chassis Maintenance

The chassis is made of SPCC steel (GB700) with powder coating. If it has been used for a long time, the

surface may develop rust stains. It is recommended to clean the surface regularly with a clean cloth.

Movement Maintenance

Before performing maintenance, ensure the power is turned off. Open the door, wipe away surface dust,

and apply lubricant for smooth movement.

Power Supply Maintenance

Switch off the power supply before conducting maintenance.

Check the power plug connection; if loose, securely fix it..

Do not change any connection position randomly.

Periodically check the insulation of the external power supply.

Conduct regular checks for any potential leakage.

Check if the technical parameters of interface are normal.

Check the service life of the electronic components and replace accordingly.

Caution: All maintenance procedures for the tripod turnstile mentioned above should be carried out by a

professional technician, especially when handling movement and electric control components. To

guarantee operational safety, it is crucial to switch off the power supply when the barrier is not in use.

Saturn-T1000 Pro User Manual

7 Packing List

The package consists of the following items:

Saturn-T1000 Pro 1

Cover Plate 2

Arm Assembly 1

Power Adapter 1

Expansion Screw 4

Washer 4

Expansion Screw Washers 4

Hex Wrench 1

Hex Socket Cap Screw

M10×60

(Used to fix the arm assembly)

Stainless Steel Maintenance Wipes 1

Saturn-T1000 Pro User Manual

Revision History

Revision Date Author Reviewer Description

V1.0 09/01/2026 Mia Liang Original Document

ZKTeco Industrial Park, No. 32, Industrial Road,

Tangxia Town, Dongguan, China.

Phone : +86 769 - 82109991

Fax : +86 755 - 89602394

ZKTeco SATURN-T1000 PRO

Product's Documents

PDF ZK Saturn-T1000 Pro User Manual 20260917 User Manual 3.69MB 2026-09-20

Specifications

ZKTeco SATURN-T1000 PRO Questions and Answers

Related Products

ZKTeco BS-852E22T-S3-MI-SE

ZKTeco BS-852E23C-S3-MI-SE

ZKTeco BS-852E23C-S3-SE

ZKTeco BS-852E23T-S3-MI-SE

ZKTeco DL-852E28B-S3-SE

ZKTeco DL-852E28B-S3-SE-F
