Tryst
Models: KBF462C
KBF462MB
KBF462SS
1
INSTALLATION GUIDE
Karran USA Tel: 866.452.7726 www.karran.com [email protected]
COMPONENT LIST QTY
1 - Faucet Body 1
2 - O-Ring 1
3 - Rubber Washer 1
4 - Metal Washer 1
5 - Mounng Hardware 1
6 - Screw 2
3
2
7-1/8”
4-3/8”
9-7/8”
2-1/8”
11-1/4”
5-7/8”
5
4
7
6
1 - Screw Cover
2 - Screw
3 - Handle
4 - Cover Ring
5 - Nut
6 - Cartridge
7 - Faucet Body
8 - Aerator
9 - Aerator Cover
10 - Base Ring
11 - Base
12 - O-Ring
13 - Rubber Washer
14 - Metal Washer
15 - Mounng Hardware
16 - Screws
17 & 18 - Water Lines
