Network Camera User Manual
i
IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.
IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
●
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
●
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
●
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE
LATTER PREVAILS.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
Network Camera User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
Network Camera User Manual
iii
Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Conguraon Process ............................................................................................................ 1
1.2 Firmware Update ................................................................................................................... 1
1.3 System Requirement .............................................................................................................. 1
Chapter 2 Device Acvaon and Accessing ................................................................................. 3
2.1 Acvate the Device via SADP ................................................................................................. 3
2.2 Acvate the Device via Browser ............................................................................................. 3
2.3 Login ...................................................................................................................................... 4
2.3.1 Plug-in
Installaon ........................................................................................................ 4
2.3.2 Admin Password Recovery ............................................................................................ 5
2.3.3 Illegal Login Lock ........................................................................................................... 6
Chapter 3 Live View .................................................................................................................... 7
3.1 Live View Parameters ............................................................................................................. 7
3.1.1 Start and Stop Live View ............................................................................................... 7
3.1.2 Aspect
Rao .................................................................................................................. 7
3.1.3 Live View Stream Type .................................................................................................. 7
3.1.4 Select the Third-Party Plug-in ....................................................................................... 7
3.1.5 Light .............................................................................................................................. 8
3.1.6 Count Pixel .................................................................................................................... 8
3.1.7 Start Digital Zoom ......................................................................................................... 8
3.1.8 Auxiliary Focus .............................................................................................................. 8
3.1.9 Lens
Inializaon .......................................................................................................... 9
3.1.10 Lens Parameters Adjustment ...................................................................................... 9
3.1.11 Conduct 3D
Posioning ............................................................................................. 11
3.2 Set Transmission Parameters ............................................................................................... 11
3.3 Set Smooth Streaming ......................................................................................................... 12
Network Camera User Manual
v
Chapter 4 Video and Audio ....................................................................................................... 14
4.1 Video Sengs ...................................................................................................................... 14
4.1.1 Stream Type ................................................................................................................ 14
4.1.2 Video Type .................................................................................................................. 14
4.1.3
Resoluon ................................................................................................................... 14
4.1.4 Bitrate Type and Max. Bitrate ..................................................................................... 15
4.1.5 Video Quality .............................................................................................................. 15
4.1.6 Frame Rate .................................................................................................................. 15
4.1.7 Video Encoding ........................................................................................................... 15
4.1.8 Smoothing ................................................................................................................... 17
4.2 Audio Sengs ...................................................................................................................... 17
4.2.1 Audio Encoding ........................................................................................................... 18
4.2.2 Audio Input ................................................................................................................. 18
4.2.3 Audio Output .............................................................................................................. 18
4.2.4 Environmental Noise Filter .......................................................................................... 18
4.3 Two-way Audio .................................................................................................................... 18
4.4 ROI ....................................................................................................................................... 19
4.4.1 Set ROI ........................................................................................................................ 19
4.5 Set Target Cropping .............................................................................................................. 20
4.6 Display Info. on Stream ........................................................................................................ 20
4.7 Display
Sengs .................................................................................................................... 20
4.7.1 Scene Mode ................................................................................................................ 21
4.7.2 Image Parameters Switch ............................................................................................ 26
4.7.3 Video Standard ........................................................................................................... 27
4.7.4 Local Video Output ..................................................................................................... 27
4.7.5 ShotN .......................................................................................................................... 27
4.8 OSD ...................................................................................................................................... 28
4.9 Set Privacy Mask .................................................................................................................. 28
Network Camera User Manual
vi
4.10 Overlay Picture ................................................................................................................... 29
Chapter 5 Video Recording and Picture Capture ........................................................................ 30
5.1 Storage
Sengs ................................................................................................................... 30
5.1.1 Memory Card .............................................................................................................. 30
5.1.2 Set FTP ........................................................................................................................ 32
5.1.3 Set NAS ....................................................................................................................... 33
5.1.4 eMMC Protecon ........................................................................................................ 34
5.1.5 Set Cloud Storage ........................................................................................................ 34
5.2 Video Recording ................................................................................................................... 35
5.2.1 Record Automacally .................................................................................................. 35
5.2.2 Record Manually ......................................................................................................... 37
5.2.3 Playback and Download Video .................................................................................... 37
5.3 Capture
Conguraon .......................................................................................................... 38
5.3.1 Capture
Automacally ................................................................................................ 38
5.3.2 Capture Manually ........................................................................................................ 38
5.3.3 View and Download Picture ........................................................................................ 39
Chapter 6 Event and Alarm ....................................................................................................... 40
6.1 Set
Moon Detecon ........................................................................................................... 40
6.1.1 Expert Mode ............................................................................................................... 40
6.1.2 Normal Mode .............................................................................................................. 41
6.2 Set Video Tampering Alarm ................................................................................................. 42
6.3 Set Alarm Input .................................................................................................................... 43
6.4 Set
Excepon Alarm ............................................................................................................. 44
6.5 Set Video Quality Diagnosis ................................................................................................. 44
6.6 Set Vibraon Detecon ........................................................................................................ 45
6.7 Set Audio
Excepon Detecon ............................................................................................ 45
6.8 Set Defocus Detecon .......................................................................................................... 46
6.9 Set Scene Change
Detecon ................................................................................................ 47
Network Camera User Manual
vii
Chapter 7 Arming Schedule and Alarm Linkage ......................................................................... 48
7.1 Set Arming Schedule ............................................................................................................ 48
7.2 Linkage Method
Sengs ...................................................................................................... 48
7.2.1 Trigger Alarm Output .................................................................................................. 49
7.2.2 FTP/NAS/Memory Card Uploading ............................................................................. 50
7.2.3 Send Email .................................................................................................................. 50
7.2.4 Nofy Surveillance Center .......................................................................................... 51
7.2.5 Trigger Recording ........................................................................................................ 51
7.2.6 Audible Warning ......................................................................................................... 51
7.2.7 Alarm Server ............................................................................................................... 52
Chapter 8 Network Sengs ...................................................................................................... 53
8.1 TCP/IP ................................................................................................................................... 53
8.2 Access to Device via Domain Name ..................................................................................... 54
8.3 Access to Device via PPPoE Dial Up Connecon .................................................................. 55
8.4 SNMP ................................................................................................................................... 55
8.5 Set IEEE 802.1X .................................................................................................................... 56
8.6 Set QoS ................................................................................................................................. 56
8.7 HTTP(S) ................................................................................................................................ 57
8.8
Mulcast .............................................................................................................................. 58
8.8.1
Mulcast Discovery ..................................................................................................... 58
8.9 RTSP ..................................................................................................................................... 58
8.10 Set SRTP ............................................................................................................................. 59
8.11 Bonjour .............................................................................................................................. 59
8.12 WebSocket(s) ..................................................................................................................... 60
8.13 Port Mapping ..................................................................................................................... 60
8.13.1 Set Auto Port Mapping .............................................................................................. 60
8.13.2 Set Manual Port Mapping ......................................................................................... 60
8.13.3 Set Port Mapping on Router ..................................................................................... 61
Network Camera User Manual
viii
8.14 RTCP ................................................................................................................................... 62
8.15 Wireless Dial ...................................................................................................................... 62
8.15.1 Set Wireless Dial ....................................................................................................... 62
8.15.2 Wireless Expert
Sengs ............................................................................................ 63
8.16 Trac Shaping .................................................................................................................... 65
8.17 Data Monitoring ................................................................................................................. 65
8.18 Set ISUP .............................................................................................................................. 65
8.19 Set OTAP ............................................................................................................................. 66
8.20 Access Camera via Hik-Connect ......................................................................................... 66
8.20.1 Enable Hik-Connect Service on Camera .................................................................... 67
8.20.2 Set Up Hik-Connect ................................................................................................... 68
8.20.3 Add Camera to Hik-Connect ...................................................................................... 69
8.21 Set Open Network Video Interface .................................................................................... 69
8.22 Set SDK Service .................................................................................................................. 70
Chapter 9 System and Security ................................................................................................. 71
9.1 System Sengs .................................................................................................................... 71
9.1.1 View Device
Informaon ............................................................................................. 71
9.1.2 Time and Date ............................................................................................................. 71
9.1.3 Set RS-232 ................................................................................................................... 72
9.1.4 Set RS-485 ................................................................................................................... 73
9.1.5 Set Live View
Connecon ............................................................................................ 73
9.1.6 Locaon Sengs ......................................................................................................... 73
9.1.7 External Device ........................................................................................................... 74
9.1.8 View Open Source
Soware License ........................................................................... 75
9.1.9 Wiegand ...................................................................................................................... 76
9.2 User and Account ................................................................................................................. 76
9.2.1 Set User Account and Permission ............................................................................... 76
9.2.2 Simultaneous Login ..................................................................................................... 77
Network Camera User Manual
ix
9.2.3 Online Users ................................................................................................................ 77
9.3 Maintenance ........................................................................................................................ 77
9.3.1 Restart ......................................................................................................................... 77
9.3.2 Upgrade ...................................................................................................................... 77
9.3.3 Restore and Default .................................................................................................... 78
9.3.4 Import and Export
Conguraon File ......................................................................... 78
9.3.5 Search and Manage Log .............................................................................................. 78
9.3.6 Search Security Audit Logs .......................................................................................... 79
9.3.7 SSH .............................................................................................................................. 79
9.3.8 Export Diagnose Informaon ...................................................................................... 79
9.4 Security ................................................................................................................................ 79
9.4.1 Set IP Address Filter .................................................................................................... 80
9.4.2 Set MAC Address Filter ............................................................................................... 80
9.4.3 Control Timeout Sengs ............................................................................................ 81
9.4.4 Cercate Management ............................................................................................. 81
9.4.5 TLS ............................................................................................................................... 84
Chapter 10 Device Management ............................................................................................... 85
10.1 Add Alarm Box ................................................................................................................... 85
Chapter 11 VCA Resource ......................................................................................................... 86
11.1 Allocate VCA Resource ....................................................................................................... 86
11.2 General
Sengs ................................................................................................................. 86
11.2.1 Set Camera Info ......................................................................................................... 87
11.2.2 Metadata .................................................................................................................. 87
11.2.3 Dynamic Mosaic Mask .............................................................................................. 88
11.2.4 AcuSearch ................................................................................................................. 88
11.3 Smart Event ........................................................................................................................ 89
11.3.1 Set Intrusion
Detecon ............................................................................................. 89
11.3.2 Set Line Crossing
Detecon ....................................................................................... 91
Network Camera User Manual
x
11.3.3 Set Region Entrance Detecon ................................................................................. 93
11.3.4 Set Region Exing Detecon ..................................................................................... 94
11.3.5 Set
Unaended Baggage Detecon .......................................................................... 96
11.3.6 Set Object Removal Detecon .................................................................................. 98
11.3.7 Set Loitering Detecon ............................................................................................. 99
11.3.8 Set People Gathering Detecon .............................................................................. 101
11.3.9 Set Fast Moving Detecon ...................................................................................... 102
11.3.10 Set Parking Detecon ............................................................................................ 103
11.3.11 Set Combined Event .............................................................................................. 105
11.4 Face Capture .................................................................................................................... 107
11.4.1 Set Face Capture ..................................................................................................... 107
11.4.2 Overlay and Capture ............................................................................................... 108
11.4.3 Face Capture Algorithms Parameters ...................................................................... 109
11.4.4 Set Shield Region .................................................................................................... 111
11.5 Mul-Target-Type Detecon ............................................................................................ 111
11.5.1 Set Mul-Target-Type Detecon Rule ..................................................................... 112
11.5.2 Set
Mul-Target-Type Counng Rule ...................................................................... 113
11.5.3 Overlay and Capture ............................................................................................... 114
11.5.4 Mul-Target-Type Detecon Advanced Parameters ............................................... 116
11.5.5 Set Shield Region .................................................................................................... 118
11.5.6 View
Mul-Target-Type Counng Stascs ............................................................ 118
11.6 Face Picture Comparison ................................................................................................. 119
11.6.1 Set Face Picture Library ........................................................................................... 119
11.6.2 Set Face Picture Comparison .................................................................................. 120
11.6.3 View Face Picture Comparison Result ..................................................................... 121
11.7 People Management ........................................................................................................ 121
11.7.1 Regional People
Counng ....................................................................................... 122
11.7.2
On/O Duty Detecon ............................................................................................ 128
Network Camera User Manual
xi
11.7.3 Queue Management ............................................................................................... 130
11.7.4 Overlay and Capture ............................................................................................... 141
11.7.5 Advanced
Sengs ................................................................................................... 141
11.8 Heat Map ......................................................................................................................... 142
11.8.1 Set Heat Map .......................................................................................................... 142
11.8.2 View Heat Map Data ............................................................................................... 144
11.9 Mul-Dimension People Counng ................................................................................... 145
11.9.1 Set Mul-Dimension People Counng Rule ............................................................ 146
11.9.2 Mul-Dimension People Counng Advanced Sengs ............................................ 148
11.9.3 Set Face Picture Library ........................................................................................... 149
11.9.4 Set Face Picture Comparison Alarm ........................................................................ 150
11.9.5 View Face Picture Comparison Result ..................................................................... 151
11.9.6 View People
Counng Stascs .............................................................................. 151
11.10 AI Open
Plaorm ........................................................................................................... 152
11.10.1 Set AI Open Plaorm ............................................................................................ 152
11.10.2 Set Rules ............................................................................................................... 155
11.11 Road
Trac .................................................................................................................... 157
11.11.1 Set Vehicle Detecon ............................................................................................ 157
11.11.2 Set Mixed-Trac Detecon Rule ........................................................................... 162
11.11.3 Overlay and Capture ............................................................................................. 165
11.11.4 Import or Export Blocklist & Allowlist ................................................................... 167
11.11.5 Advanced Parameters
Conguraon .................................................................... 168
11.11.6
Trac Flow Stascs ............................................................................................. 168
11.12 Parking Management ..................................................................................................... 169
11.12.1 Close View Mode .................................................................................................. 169
11.12.2 Distant View Mode ............................................................................................... 172
11.12.3 Overlay and Capture ............................................................................................. 175
11.12.4 Import or Export Blocklist & Allowlist ................................................................... 176
Network Camera User Manual
xii
11.12.5 Advanced Parameters Conguraon .................................................................... 177
11.13 Tunnel Event Detecon .................................................................................................. 177
11.13.1 Basic
Sengs ........................................................................................................ 177
11.13.2 Set Rules ............................................................................................................... 178
11.13.3 Trac Event Detecon .......................................................................................... 180
11.13.4 ITS Linkage and Alarm ........................................................................................... 183
11.13.5 Advanced Sengs ................................................................................................. 184
11.14 Schedule Switch Applicaon .......................................................................................... 185
11.15 Search and Export Data Aware Informaon .................................................................. 186
11.16 Search and View Power Consumpon Stascs ............................................................ 186
Chapter 12 Smart Display ....................................................................................................... 188
Chapter 13 EPTZ ..................................................................................................................... 189
13.1 Patrol ................................................................................................................................ 189
13.2 Auto-Tracking ................................................................................................................... 189
Appendix A. FAQ ..................................................................................................................... 191
Network Camera User Manual
xiii
Chapter 1 Overview
1.1 Conguraon Process
This secon briey explains the soware conguraon process of the network camera. Please set
up the device according to the actual situaon.
General Conguraon Process
Figure 1-1 General Conguraon Process
●
Acvate and access device via web browser. You should set a login password (for admin user) to
acvate the device when access the device via network. Open the web browser and enter the IP
address. The default IP address of the device is 192.168.1.64.
●
Follow the Wizard or click on the web page to quickly set the device parameters.
●
Set the basic parameters, including network, image, video and audio, alarm, etc.
●
Set event and
detecon rules. You can set basic event and detecon rules or allocate VCA
resources for deep learning funcon.
1.2 Firmware Update
For beer user experience, we recommend you to update your device to the latest rmware.
Please get the latest rmware package from the ocial website or the local technical expert. For
more
informaon, please visit the ocial website: hps://www.hikvision.com/en/support/
download/rmware/ .
For the upgrading
sengs, refer to Upgrade .
1.3 System Requirement
Your computer should meet the requirements for proper vising and operang the product.
Network Camera User Manual
1
Chapter 2 Device Acvaon and Accessing
To protect the security and privacy of the user account and data, you should set a login password
to
acvate the device when access the device via network.
Note
Refer to the user manual of the soware client for the detailed informaon about the client
soware acvaon.
2.1 Acvate the Device via SADP
Search and acvate the online devices via SADP soware.
Before You Start
Access www.hikvision.com to get SADP
soware to install.
Steps
1.
Connect the device to network using the network cable.
2.
Run SADP soware to search the online devices.
3.
Check Device Status from the device list, and select
Inacve device.
4.
Create and input the new password in the password eld, and conrm the password.
Cauon
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including upper case leers, lower case leers, numbers, and special characters) in
order to increase the security of your product. And we recommend you reset your password
regularly, especially in the high security system,
reseng the password monthly or weekly can
beer protect your product.
5.
Click OK.
Device Status changes into Acve.
6.
Oponal: Change the network parameters of the device in Modify Network Parameters.
2.2
Acvate the Device via Browser
You can access and acvate the device via the browser.
Steps
1.
Connect the device to the PC using the network cables.
2.
Change the IP address of the PC and device to the same segment.
Network Camera User Manual
3
Note
The default IP address of the device is 192.168.1.64. You can set the IP address of the PC from
192.168.1.2 to 192.168.1.253 (except 192.168.1.64). For example, you can set the IP address of
the PC to 192.168.1.100.
3.
Input 192.168.1.64 in the browser.
4.
Set device acvaon password.
Cauon
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including at least three of the following categories: upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
5.
Click OK.
6.
Input the acvaon password to log in to the device.
7.
Oponal: Go to Conguraon → Network → Network Sengs → TCP/IP to change the IP
address of the device to the same segment of your network.
2.3 Login
Log in to the device via Web browser.
2.3.1 Plug-in
Installaon
Certain operang systems and web browsers may restrict the display and operaon of the device
funcon. You should install a plug-in or complete certain sengs to ensure normal display and
operaon. For detailed restricted funcon, refer to the actual device.
Network Camera User Manual
4
Operang System Web Browser Operaon
Windows
●
Internet Explorer 10+
●
Google Chrome 57 and
earlier version
●
Mozilla Firefox 52 and earlier
version
Follow pop-up prompts to
complete plug-in installaon.
●
Google Chrome 57+
●
Mozilla Firefox 52+
●
Edge 89+
Click to download and install
plug-in.
Mac OS
●
Google Chrome 57+
●
Mozilla Firefox 52+
●
Mac Safari 16+
Plug-in installaon is not
required.
Go to Conguraon →
Network → Network Service
→ WebSocket(s) to enable
WebSocket or WebSockets for
normal view. Display and
operaon of certain funcons
are restricted. For example,
Playback and Picture are not
available. For detailed
restricted
funcon, refer to the
actual device.
Note
●
The device only supports Windows and Mac OS system, and does not support Linux system.
●
To improve the user experience on certain devices, it's recommended to use a more advanced
web browser for access. Please refer to the actual device or product specicaon.
●
Certain device models do not support Internet Explorer web browser.
2.3.2 Admin Password Recovery
If you forget the admin password, you can reset the password by clicking Forget Password on the
login page
aer compleng the account security sengs.
You can reset the password by seng the security queson or email.
Note
When you need to reset the password, make sure that the device and the PC are on the same
network segment.
Network Camera User Manual
5
Security Queson
You can set the account security during the acvaon. Or you can go to Conguraon → System →
User Management , click Account Security Sengs, select the security queson and input your
answer.
You can click Forget Password and answer the security
queson to reset the admin password when
access the device via browser.
Email
You can set the account security during the acvaon. Or you can go to Conguraon → System →
User Management , click Account Security
Sengs, input your email address to receive the
vericaon code during the recovering operaon process.
2.3.3 Illegal Login Lock
It helps to improve the security when accessing the device via Internet.
Go to Maintenance and Security → Security → Login Management , and enable Enable Illegal
Login Lock. Illegal Login
Aempts and Locking Duraon are congurable.
Illegal Login Aempts
When your login aempts with the wrong password reach the set mes, the device is locked.
Locking Duraon
The device releases the lock aer the seng duraon.
Network Camera User Manual
6
Chapter 3 Live View
It introduces the live view parameters, funcon icons and transmission parameters sengs.
3.1 Live View Parameters
The supported funcons vary depending on the model.
3.1.1 Start and Stop Live View
Click Live View. Click to start live view. Click to stop live view.
3.1.2 Aspect
Rao
Aspect Rao is the display rao of the width to height of the image.
●
refers to 4:3 window size.
●
refers to 16:9 window size.
●
refers to original window size.
●
refers to self-adapve window size.
●
refers to original rao window size.
3.1.3 Live View Stream Type
Select the live view stream type according to your needs. For the detailed informaon about the
stream type selecon, refer to Stream Type .
3.1.4 Select the Third-Party Plug-in
When the live view cannot display via certain browsers, you can change the plug-in for live view
according to the browser.
Steps
1.
Click Live View.
2.
Click
to select the plug-in.
-
When you access the device via Internet Explorer, you can select Webcomponents or
QuickTime.
-
When you access the device via the other browsers, you can select Webcomponents,
QuickTime or MJPEG.
Network Camera User Manual
7
3.1.5 Light
Click to turn on or turn o the illuminator.
Cauon
For the device with laser:
●
DO NOT stare at operang light source. May be harmful to the eyes.
●
If appropriate shielding or eye protecon is not available, turn on the light only at a safe distance
or in the area that is not directly exposed to the light.
●
When assembling, installing or maintaining the device, DO NOT turn on the light, or wear eye
protecon.
3.1.6 Count Pixel
It helps to get the height and width pixel of the selected region in the live view image.
Steps
1.
Click
to enable the funcon.
2.
Drag the mouse on the image to select a desired rectangle area.
The width pixel and height pixel are displayed on the boom of the live view image.
3.1.7 Start Digital Zoom
It helps to see a detailed informaon of any region in the image.
Steps
1.
Click to enable the digital zoom.
2.
In live view image, drag the mouse to select the desired region.
3.
Click in the live view image to back to the original image.
3.1.8 Auxiliary Focus
It is used for motorized device. It can improve the image if the device cannot focus clearly.
For the device that supports ABF, adjust the lens angle, then focus and click ABF buon on the
device. The device can focus clearly.
Click
to focus automacally.
Network Camera User Manual
8
Note
●
If the device cannot focus with auxiliary focus, you can use Lens Inializaon , then use auxiliary
focus again to make the image clear.
●
If auxiliary focus cannot help the device focus clearly, you can use manual focus.
3.1.9 Lens Inializaon
Lens inializaon is used on the device equipped with motorized lens. The funcon can reset lens
when long me zoom or focus results in blurred image. This funcon varies according to dierent
models.
Click to operate lens inializaon.
3.1.10 Lens Parameters Adjustment
PTZ is an abbreviaon for pan, lt, and zoom. It means the movement opons of the device. In live
view interface, you can click the direcon control buons to control the pan/lt movement, and
click the zoom/focus/iris buons to realize lens control.
Note
●
Supported PTZ funcons may vary according to dierent camera models.
●
For the devices which support lens movements only, the direcon buons are invalid.
Direcon Control
Click and hold the direcon buon to pan/lt the device.
Zoom
●
Click , and the lens zooms in.
●
Click , and the lens zooms out.
Focus
●
Click , then the lens focuses near and the nearby object gets clear.
●
Click
, then the lens focuses far and the distant object gets clear.
Network Camera User Manual
9
Iris
●
When the image is too dark, click to enlarge the iris.
●
When the image is too bright, click to stop down the iris.
PTZ Speed
●
Slide
to adjust the speed of the pan/lt movement.
PTZ Lock
PTZ lock means to disable the zoom, focus and PTZ rotaon funcons of the corresponding
channel, so that to reduce the target missing caused by PTZ adjustment.
Note
The funcon is only supported by certain device models.
Click to lock the PTZ operaon, or click to unlock it.
PTRZ Adjustment
PTRZ is an abbreviaon for pan, lt, rotate and zoom. It means the movement opons of the
device. In the interface, you can use the control
buons to adjust the movement of the device,
such as device panning, lng , rotang, and zooming.
Note
The funcon is only supported by certain device models.
Go to Conguraon → PTZ → PTRZ .
Control Panel
Click and hold the direconal buon to pan/lt
the device.
●
●
Click and hold the buon to adjust rotang
posion.
Auto Recovery
Click , the device will correct the rotang posion automacally to make the live view image
posive. Make sure the Self-Test Status is Inialized.
Network Camera User Manual
10
Note
●
Go to Conguraon → PTZ → PTZ to view the Self-Test Status.
●
If you want to inialize PTZ and enable PTZ self-check manually, go to Conguraon → PTZ →
PTZ and click Self-Test, then the PTZ is inialized.
Refer to Lens Parameters Adjustment for more detailed sengs of lens adjustment.
3.1.11 Conduct 3D Posioning
3D posioning is to relocate the selected area to the image center.
Steps
1.
Click to enable the funcon.
2.
Select a target area in live image.
-
Le click on a point on live image: the point is relocated to the center of the live image. With
no zooming in or out
eect.
-
Hold and drag the mouse to a lower right posion to frame an area on the live: the framed
area is zoomed in and relocated to the center of the live image.
-
Hold and drag the mouse to an upper le posion to frame an area on the live: the framed
area is zoomed out and relocated to the center of the live image.
3.
Click the
buon again to turn o the funcon.
3.2 Set Transmission Parameters
The live view image may be displayed abnormally according to the network condions. In dierent
network environments, you can adjust the transmission parameters to solve the problem.
Steps
1.
Go to Conguraon → Local → Live View Parameters .
2.
Set the transmission parameters as required.
Protocol
TCP
TCP ensures complete delivery of streaming data and
beer video quality, yet the real-me
transmission will be aected. It is suitable for the stable network environment.
UDP
UDP is suitable for the unstable network environment that does not demand high video
uency.
MULTICAST
Network Camera User Manual
11
MULTICAST is suitable for the situaon that there are mulple clients. You should set the
mulcast address for them before selecon.
Note
For detailed informaon about mulcast, refer to Mulcast .
HTTP
HTTP is suitable for the
situaon that the third-party needs to get the stream from the
device.
Playing Performance
Shortest Delay
The device takes the real-me video image as the priority over the video uency.
Balanced
The device ensures both the
real-me video image and the uency.
Fluent
The device takes the video uency as the priority over teal-me. In poor network
environment, the device cannot ensures video uency even the uency is enabled.
Custom
You can set the frame rate manually. In poor network environment, you can reduce the
frame rate to get a
uent live view. But the rule informaon may cannot display.
3.
Click Save.
3.3 Set Smooth Streaming
It is a funcon to tackle the latency and network congeson caused by unstable network condion,
and keep the live view stream on the web browser or the client soware smooth.
Before You Start
Add the device to your client
soware and select NPQ protocol in client soware before
conguring the smooth streaming funcon.
Be sure that the Bit Rate Type is selected as Constant and the SVC is selected as OFF before
enabling the
funcon. Go to Conguraon → Video/Audio → Video to set the parameters.
Note
The funcon is only supported by certain device models.
Steps
1.
Go to the
sengs page: Conguraon → Network → Network Service → Smooth Streaming .
2.
Check Enable Smooth Streaming.
3.
Select the mode for smooth streaming.
Network Camera User Manual
12
Auto The resoluon and bit rate are adjusted automacally and resoluon takes the
priority. The upper limits of these two parameters will not exceed the values
you set on Video page. Go to Conguraon → Video/Audio → Video , set the
Resoluon and Max. Bit Rate before you enable smooth streaming funcon.
In this mode, the frame rate will be adjusted to the maximum value
automacally.
Resoluon
Priority
The resoluon stays the same as the set value on Video page, and the bit rate
will be adjusted automacally. Go to Conguraon → Video/Audio → Video ,
set the Max. Bit Rate before you enable smooth streaming funcon. In this
mode, the frame rate will be adjusted to the maximum value
automacally.
Frame Rate
Priority
The image is sll smooth even under the poor network, while the image
quality may be not good.
Error
Correcon
The resoluon and bit rate stay the same as the set values on Video page. The
mode is used to correct the data error during transmission to ensure the image
quality. You can set the Error Correcon Proporon within range of 0-100.
When the
proporon is 0, the data error will be corrected by data
retransmission. When the
proporon is higher than 0, the error data will be
corrected via redundant data that is added to the stream and data
retransmission. The higher the value is, the more redundant date will be
generated, the more data error would be corrected, but the larger bandwidth
would be required. When the
proporon is 100, the redundant data will be as
large as the original data, and the bandwidth is twice required.
Note
Be sure the bandwidth is sucient in the Error Correcon mode.
4.
Click Save to save the sengs.
Network Camera User Manual
13
Chapter 4 Video and Audio
This part introduces the conguraon of video and audio related parameters.
4.1 Video Sengs
This part introduces the sengs of video parameters, such as, stream type, video encoding, and
resoluon.
Go to seng page: Conguraon → Video/Audio → Video .
4.1.1 Stream Type
For device supports more than one stream, you can specify parameters for each stream type.
Main Stream
The stream stands for the best stream performance the device supports. It usually
oers the
best resoluon and frame rate the device can do. But high resoluon and frame rate usually
means larger storage space and higher bandwidth requirements in transmission.
Sub Stream
The stream usually
oers comparavely low resoluon opons, which consumes less bandwidth
and storage space.
Other Streams
Steams other than the main stream and sub stream may also be oered for customized usage.
4.1.2 Video Type
Select the content (video and audio) that should be contained in the stream.
Video Stream
Only video content is contained in the stream.
Video&Audio
Video content and audio content are contained in the composite stream.
4.1.3
Resoluon
Select video resoluon according to actual needs. Higher resoluon requires higher bandwidth and
storage.
Network Camera User Manual
14
4.1.4 Bitrate Type and Max. Bitrate
Constant Bitrate
It means that the stream is compressed and transmied at a comparavely xed bitrate. The
compression speed is fast, but mosaic may occur on the image.
Variable Bitrate
It means that the device
automacally adjust the bitrate under the set Max. Bitrate. The
compression speed is slower than that of the constant bitrate. But it guarantees the image
quality of complex scenes.
4.1.5 Video Quality
When Bitrate Type is set as Variable, video quality is congurable. Select a video quality according
to actual needs. Note that higher video quality requires higher bandwidth.
4.1.6 Frame Rate
The frame rate is to describe the frequency at which the video stream is updated and it is
measured by frames per second (fps).
A higher frame rate is advantageous when there is movement in the video stream, as it maintains
image quality throughout. Note that higher frame rate requires higher bandwidth and larger
storage space.
4.1.7 Video Encoding
It stands for the compression standard the device adopts for video encoding.
Note
Available compression standards vary according to device models.
H.264
H.264, also known as MPEG-4 Part 10, Advanced Video Coding, is a compression standard. Without
compressing image quality, it increases compression rao and reduces the size of video le than
MJPEG or MPEG-4 Part 2.
Network Camera User Manual
15
H.264+
H.264+ is an improved compression coding technology based on H.264. By enabling H.264+, you
can
esmate the HDD consumpon by its maximum average bitrate. Compared to H.264, H.264+
reduces storage by up to 50% with the same maximum bitrate in most scenes.
When H.264+ is enabled, Max. Average Bitrate is congurable. The device gives a recommended
max. average bitrate by default. You can adjust the parameter to a higher value if the video quality
is less
sasfactory. Max. average bitrate should not be higher than max. bitrate.
Note
When H.264+ is enabled, I Frame Interval is not congurable.
H.265
H.265, also known as High Eciency Video Coding (HEVC) and MPEG-H Part 2, is a compression
standard. In comparison to H.264, it oers beer video compression at the same resoluon, frame
rate and image quality.
H.265+
H.265+ is an improved compression coding technology based on H.265. By enabling H.265+, you
can esmate the HDD consumpon by its maximum average bitrate. Compared to H.265, H.265+
reduces storage by up to 50% with the same maximum bitrate in most scenes.
When H.265+ is enabled, Max. Average Bitrate is
congurable. The device gives a recommended
max. average bitrate by default. You can adjust the parameter to a higher value if the video quality
is less
sasfactory. Max. average bitrate should not be higher than max. bitrate.
Note
When H.265+ is enabled, I Frame Interval is not congurable.
I-Frame Interval
I-frame interval denes the number of frames between 2 I-frames.
In H.264 and H.265, an I-frame, or intra frame, is a self-contained frame that can be independently
decoded without any reference to other images. An I-frame consumes more bits than other
frames. Thus, video with more I-frames, in other words, smaller I-frame interval, generates more
steady and reliable data bits while requiring more storage space.
Network Camera User Manual
16
SVC
Scalable Video Coding (SVC) is the name for the Annex G extension of the H.264 or H.265 video
compression standard.
The
objecve of the SVC standardizaon has been to enable the encoding of a high-quality video
bitstream that contains one or more subset bitstreams that can themselves be decoded with a
complexity and
reconstrucon quality similar to that achieved using the exisng H.264 or H.265
design with the same quanty of data as in the subset bitstream. The subset bitstream is derived
by dropping packets from the larger bitstream.
SVC enables forward compability for older hardware: the same bitstream can be consumed by
basic hardware which can only decode a low-resoluon subset, while more advanced hardware
will be able decode high quality video stream.
MPEG4
MPEG4, referring to MPEG-4 Part 2, is a video compression format developed by Moving Picture
Experts Group (MPEG).
MJPEG
Moon JPEG (M-JPEG or MJPEG) is a video compression format in which intraframe coding
technology is used. Images in a MJPEG format is compressed as individual JPEG images.
Prole
This funcon means that under the same bitrate, the more complex the prole is, the higher the
quality of the image is, and the requirement for network bandwidth is also higher.
4.1.8 Smoothing
It refers to the smoothness of the stream. The higher value of the smoothing is, the beer uency
of the stream will be, though, the video quality may not be so sasfactory. The lower value of the
smoothing is, the higher quality of the stream will be, though it may appear not
uent.
4.2 Audio
Sengs
It is a funcon to set audio parameters such as audio encoding, environment noise ltering.
Go to the audio sengs page: Conguraon → Video/Audio → Audio .
Network Camera User Manual
17
Note
Only certain camera models support the funcon.
4.2.1 Audio Encoding
Select the audio encoding compression of the audio.
4.2.2 Audio Input
Note
●
Connect the audio input device as required.
●
The audio input display varies with the device models.
LineIn Set Audio Input to LineIn when the device connects to the audio
input device with the high output power, such as MP3,
synthesizer or acve pickup.
MicIn Set Audio Input to MicIn when the device connects to the audio
input device with the low output power, such as microphone or
passive pickup.
4.2.3 Audio Output
Note
Connect the audio output device as required.
It is a switch of the device audio output. When it is disabled, all the device audio cannot output.
The audio output display varies with the device modes.
4.2.4 Environmental Noise Filter
Set it as OFF or ON. When the funcon is enabled, the noise in the environment can be ltered to
some extent.
4.3 Two-way Audio
It is used to realize the two-way audio funcon between the monitoring center and the target in
the monitoring screen.
Network Camera User Manual
18
Before You Start
●
Make sure the audio input device (pick-up or microphone) and audio output device (speaker)
connected to the device is working properly. Refer to specicaons of audio input and output
devices for device
connecon.
●
If the device has built-in microphone and speaker, two-way audio
funcon can be enabled
directly.
Steps
1.
Click Live View.
2.
Click
on the toolbar to enable two-way audio funcon of the camera.
3.
Click , disable the two-way audio funcon.
4.4 ROI
ROI (Region of Interest) encoding helps to discriminate the ROI and background informaon in
video compression. The technology assigns more encoding resource to the region of interest, thus
to increase the quality of the ROI whereas the background
informaon is less focused.
4.4.1 Set ROI
ROI (Region of Interest) encoding helps to assign more encoding resource to the region of interest,
thus to increase the quality of the ROI whereas the background
informaon is less focused.
Before You Start
Please check the video coding type. ROI is supported when the video coding type is H.264 or H.
265.
Steps
1.
Go to Conguraon → Video/Audio → ROI .
2.
Check Enable.
3.
Select Stream Type.
4.
Select Region No. and click
to draw ROI region on the live view.
Note
Select the xed region that needs to be adjusted and drag the mouse to adjust its posion.
5.
Input the Area Name and ROI Level.
6.
Click Save.
Note
The higher the ROI level is, the clearer the image of the detected region is.
7.
Oponal: Select other region No. and repeat the above steps if you need to draw mulple xed
regions.
Network Camera User Manual
19
4.5 Set Target Cropping
You can crop the image, transmit and save only the images of the target area to save transmission
bandwidth and storage.
Steps
1.
Go to Conguraon → Video/Audio → Target Cropping .
2.
Check Enable and set Third Stream as the Stream Type.
Note
Aer enabling target cropping, the third stream resoluon cannot be congured.
3.
Select a Cropping Resoluon.
A red frame appears in the live view.
4.
Drag the frame to the target area.
5.
Click Save.
Note
●
Only certain models support target cropping and the funcon varies according to dierent
camera models.
●
Some funcons may be disabled aer enabling target cropping.
4.6 Display Info. on Stream
The informaon of the objects (e.g. human, vehicle, etc.) is marked in the video stream. You can
set rules on the connected rear-end device or client
soware to detect the events including line
crossing, intrusion, etc.
Before You Start
This funcon is supported in smart events. Go to VCA , select Smart Event and click Next to enable
Smart Event.
Steps
1.
Go to
Conguraon → Video/Audio → Display Info. on Stream .
2.
Check Enable Dual-VCA.
3.
Click Save.
4.7 Display
Sengs
It oers the parameter sengs to adjust image features.
Go to Conguraon → Image → Display Sengs .
Click Default to restore
sengs.
Network Camera User Manual
20
4.7.1 Scene Mode
There are several sets of image parameters predened for dierent installaon environments.
Select a scene according to the actual
installaon environment to speed up the display sengs.
Image Adjustment
By adjusng the Brightness, Saturaon, Contrast and Sharpness, the image can be best displayed.
Exposure Sengs
Exposure is controlled by the combinaon of iris, shuer, and photo sensibility. You can adjust
image eect by seng exposure parameters.
In manual mode, you need to set Exposure Time, Gain and Slow
Shuer.
Focus
It oers opons to adjust the focus mode.
Focus Mode
Auto
The device focuses
automacally as the scene changes. If you cannot get a well-focused
image under auto mode, reduce light sources in the image and avoid ashing lights.
Semi-auto
The device focuses once
aer the PTZ and lens zooming. If the image is clear, the focus does
not change when the scene changes.
Manual
You can adjust the focus manually on the live view page.
Day/Night Switch
Day/Night Switch funcon can provide color images and black/white images in day and night
mode. Switch mode is congurable.
Day
The image is always in color.
Night
The image is black/white or colorful and the supplement light will be enabled to ensure clear
live view image at night.
Network Camera User Manual
21
Note
Only certain device models support the supplement light and colorful image.
Auto
The camera switches between the day mode and the night mode according to the light
condion of environment.
Scheduled-Switch
Set the Start Time and the End Time to dene the duraon for day mode.
Triggered by alarm input
You can set Triggering Status as Day or Night. For example, if the Triggering Status is Night, the
mode turns into Night when the device receives alarm input signal.
Triggered by video
The camera switches between the day mode and the night mode according to the light
condion of environment. This mode is applicable when the device supports road trac and
vehicle
detecon.
Note
●
Day/Night Switch funcon varies according to models.
●
You can turn on the smart supplement light for beer image eect. For supplement light
sengs, refer to Supplement Light Sengs .
Supplement Light Sengs
You can set supplement light and refer to the actual device for relevant parameters.
Smart Supplement Light
Smart supplement light avoids over exposure when the supplement light is on.
Supplement Light Mode
When the device supports supplement light, you can select supplement light mode.
IR Supplement Light
IR light is enabled.
White Light
White light is enabled.
Mixed Light
Both IR light and white light are enabled.
Smart
Network Camera User Manual
22
When you select this mode aer enabling certain smart events or moon detecon, in the
night state, the default supplement light mode is IR supplement light mode. When the alarm
is triggered, the white light is enabled and the device captures the target. Aer the alarm
ends, the supplement light mode will switch to IR supplement light mode.
Only device models with IR and white light or hybrid supplement light with IR and white light
support this
funcon.
O
Supplement light is disabled.
Note
The supplement light mode may vary according to dierent device models.
Brightness Adjustment Mode
Auto
The brightness adjusts according to the actual environment automacally.
Manual
You can drag the slider or set value to adjust the brightness.
BLC
If you focus on an object against strong backlight, the object will be too dark to be seen clearly. BLC
(backlight compensaon) compensates light to the object in the front to make it clear. If BLC mode
is set as Custom, you can draw a red rectangle on the live view image as the BLC area.
WDR
The WDR (Wide Dynamic Range) funcon helps the camera provide clear images in environment
with strong
illuminaon dierences.
When there are both very bright and very dark areas simultaneously in the eld of view, you can
enable the WDR
funcon and set the level. WDR automacally balances the brightness level of the
whole image and provides clear images with more details.
Note
When WDR is enabled, some other funcons may be not supported. Refer to the actual interface
for details.
Network Camera User Manual
23
Figure 4-1 WDR
HLC
When the bright area of the image is over-exposed and the dark area is under-exposed, the HLC
(High Light Compression) funcon can be enabled to weaken the bright area and brighten the dark
area, so as to achieve the light balance of the overall picture.
White Balance
White balance is the white rendion funcon of the camera. It is used to adjust the color
temperature according to the environment.
Figure 4-2 White Balance
DNR
Digital Noise Reducon is used to reduce the image noise and improve the image quality. Normal
and Expert modes are selectable.
Normal
Set the DNR level to control the noise
reducon degree. The higher level means stronger
reducon degree.
Network Camera User Manual
24
Expert
Set the DNR level for both space DNR and me DNR to control the noise reducon degree. The
higher level means stronger
reducon degree.
Figure 4-3 DNR
Defog
You can enable the defog funcon when the environment is foggy and the image is misty. It
enhances the subtle details so that the image appears clearer.
Figure 4-4 Defog
EIS
Increase the stability of video image by using jier compensaon technology.
Network Camera User Manual
25
Gray Scale
You can choose the range of the Gray Scale as [0-255] or [16-235].
Mirror
When the live view image is the reverse of the actual scene, this funcon helps to display the
image normally.
Select the mirror mode as needed.
Note
The video recording will be shortly interrupted when the funcon is enabled.
Rotate
When this funcon is enabled, the live view will rotate 90° counterclockwise. For example, 1280 ×
720 is rotated to 720 × 1280.
Enabling this
funcon can change the eecve range of monitoring in the vercal direcon.
Note
This funcon is supported under certain sengs.
Lens Distoron Correcon
For device equipped with motorized lens, image may appear distorted to some extent. Enable this
funcon to correct the distoron.
Note
●
This funcon is only supported by certain device equipped with motorized lens.
●
The edge of image will be lost if this funcon is enabled.
4.7.2 Image Parameters Switch
The device automacally switches image parameters in set me periods.
Go to image parameters switch
seng page: Conguraon → Image → Display Sengs → Image
Parameters Switch , and set parameters as needed.
Network Camera User Manual
26
Set Scheduled-switch
Switch the image to the linked scene mode automacally in certain me periods.
Steps
1.
Check Scheduled-switch.
2.
Select and
congure the corresponding me period and linked scene mode.
Note
For Linked Scene conguraon, refer to Scene Mode .
3.
Click Save.
4.7.3 Video Standard
Video standard is an ability of a video card or video display device that denes the amount of
colors that are shown and the
resoluon. The two most common video standard used are NTSC
and PAL. In NTSC, 30 frames are transmied each second. Each frame is made up of 525 individual
scan lines. In PAL, 25 frames are
transmied each second. Each frame is made up of 625 individual
scan lines. Select video signal standard according to the video system in your country/region.
4.7.4 Local Video Output
If the device is equipped with video output interfaces, such as BNC, CVBS, HDMI, and SDI, you can
preview the live image directly by connecng the device to a monitor screen.
Select the output mode as ON/OFF to control the output.
4.7.5 ShotN
It is available when Mul-Target-Type Detecon is enabled, which can be used to opmize the
eect of captured picture.
Note
●
For certain device models, you should go to VCA and enable Mul-Target-Type Detecon rst.
●
The funcon varies according to dierent device models.
Normal Mode
The mode is used to adapvely adjust the image capture eect of face and license plate, which
can solve the overexposure of dierent types of targets captured in the same scene.
It can split the stream into 2 channels for face capture and license plate capture, and you can
set the image parameters of 2 streams separately in the expert mode.
Close
Network Camera User Manual
27
Do not split the stream.
4.8 OSD
You can customize OSD (On-screen Display) informaon such as device name, me/date, font,
color, and text overlay displayed on video stream.
Go to OSD seng page: Conguraon → Image → OSD Sengs .
Set the corresponding parameters, and click Save to take eect.
Character Set
Select character set for displayed informaon. If Korean is required to be displayed on screen,
select EUC-KR. Otherwise, select GBK.
Display
Set camera name, date, week, and their related display formats. For certain device models, you can
also set
lt angle as the displayed informaon.
Format
Sengs
Set OSD parameters, such as Display Mode, OSD Size, Font Color, and Alignment.
Text Overlay
Set customized overlay text on image.
4.9 Set Privacy Mask
The funcon blocks certain areas in the live view to protect privacy. No maer how the device
moves, the blocked scene will never be seen.
Steps
1.
Go to Conguraon → Image → Privacy Mask .
2.
Check Enable.
3.
Click
. Drag the mouse in the live view to draw a closed area.
Drag the corners of the area
Adjust the size of the area.
Drag the area Adjust the posion of the area.
Click Clear all the areas you set.
4.
Click Add to add a privacy mask and set Region Name and Mask Type.
5.
Click Save.
Network Camera User Manual
28
4.10 Overlay Picture
Overlay a customized picture on live view.
Before You Start
The picture to overlay has to be in BMP format with 24-bit, and the maximum picture size is 128 ×
128 pixel.
Steps
1.
Go to
Conguraon → Image → Picture Overlay .
2.
Check Enable.
3.
Click Upload to select a picture and open it.
The picture with a red rectangle will appear in live view
aer successfully uploading.
4.
Drag the red rectangle to adjust the picture posion.
5.
Click Save.
Network Camera User Manual
29
Chapter 5 Video Recording and Picture Capture
This part introduces the operaons of capturing video clips and snapshots, playback, and
downloading captured
les.
5.1 Storage Sengs
This part introduces the conguraon of several common storage paths.
5.1.1 Memory Card
You can view the capacity, free space, status, type, and property of the memory card. Encrypon of
memory card is supported to ensure data security.
Set New or Unencrypted Memory Card
Before You Start
Insert a new or unencrypted memory card to the device. For detailed installaon, refer to Quick
Start Guide of the device.
Steps
1.
Go to
Conguraon → Storage → Storage Management → HDD Management .
2.
Select the memory card.
Note
If an Unlock buon appears, you need to unlock the memory card rst. See Detect Memory
Card Status for details.
3.
Click Format to inialize the memory card.
When the Status of memory card turns from Uninialized to Normal, the memory card is ready
for use.
4.
Oponal: Encrypt the memory card.
1) Click Encrypted Format.
2) Set the
encrypon password.
3) Click OK.
When the
Encrypon Status turns to Encrypted, the memory card is ready for use.
Note
Keep your encrypon password properly. Encrypon password cannot be found if forgoen.
5.
Oponal: Dene the Quota of the memory card. Input the percentage for storing dierent
contents according to your needs.
Network Camera User Manual
30
6.
Click Save.
Set Encrypted Memory Card
Before You Start
●
Insert an encrypted memory card to the device. For detailed
installaon, refer to Quick Start
Guide of the device.
●
You need to know the correct encrypon password of the memory card.
Steps
1.
Go to Conguraon → Storage → Storage Management → HDD Management .
2.
Select the memory card.
Note
If an Unlock buon appears, you need to unlock the memory card rst. See Detect Memory
Card Status for details.
3.
Verify the encrypon password.
1) Click Parity.
2) Enter the
encrypon password.
3) Click OK.
When the
Encrypon Status turns to Encrypted, the memory card is ready for use.
Note
If the encrypon password is forgoen and you sll want to use this memory card, see Set New
or Unencrypted Memory Card to format and set the memory card. All exisng contents will be
removed.
4.
Oponal: Dene the Quota of the memory card. Input the percentage for storing dierent
contents according to your needs.
5.
Click Save.
Detect Memory Card Status
The device detects the status of Hikvision memory card. You receive nocaons when your
memory card is detected abnormal.
Before You Start
The
conguraon page only appears when a Hikvision memory card is installed to the device.
Steps
1.
Go to Conguraon → Storage → Storage Management → Memory Card Detecon .
2.
Click Status Detecon to check the Remaining Lifespan and Health Status of your memory card.
Remaining Lifespan
Network Camera User Manual
31
It shows the percentage of the remaining lifespan. The lifespan of a memory card may be
inuenced by factors such as its capacity and the bitrate. You need to change the memory
card if the remaining lifespan is not enough.
Health Status
It shows the condion of your memory card. You will receive a nocaon if the health status
is anything other than good when the Arming Schedule and Linkage Method are set.
Note
It is recommended that you change the memory card when the health status is not "good".
3.
Click R/W Lock to set the permission of reading and wring to the memory card.
-
Add a Lock
a. Select the Lock Switch as ON.
b. Enter the password.
c. Click Save
-
Unlock
●
If you use the memory card on the device that locks it, unlocking will be done automacally
and no unlocking procedures are required on the part of users.
●
If you use the memory card (with a lock) on a
dierent device, you can go to HDD
Management to unlock the memory card manually. Select the memory card, and click
Unlock. Enter the correct password to unlock it.
-
Remove the Lock
a. Select the Lock Switch as OFF.
b. Enter the password in Password
Sengs.
c. Click Save.
Note
●
Only admin user can set the R/W Lock.
●
The memory card can only be read and wrien when it is unlocked.
●
If the device, which adds a lock to a memory card, is restored to the factory sengs, you can
go to HDD Management to unlock the memory card.
4.
Set Arming Schedule and Linkage Method. See Set Arming Schedule and Linkage Method
Sengs for details.
5.
Click Save.
5.1.2 Set FTP
You can
congure the FTP server to save images which are captured by events or a med snapshot
task.
Before You Start
Get the FTP server address
rst.
Network Camera User Manual
32
Steps
1.
Go to Conguraon → Event → Alarm Seng → FTP .
2.
Congure FTP sengs.
FTP Protocol
FTP and SFTP are selectable. The
les uploading is encrypted by using SFTP protocol.
Server IP Address and Port No.
The FTP server address and corresponding port.
User Name and Password
The FTP user should have the permission to upload pictures.
If the FTP server supports picture uploading by anonymous users, you can check Anonymous
Login to hide your device
informaon during uploading.
Note
Anonymous login is not supported when SFTP protocol is selected.
Directory Structure
The saving path of snapshots in the FTP server.
3.
Oponal: Check Upload Picture to enable uploading snapshots to the FTP server.
Picture Filing Interval
For beer picture management, you can set the picture ling interval from 1 day to 30 days.
Pictures captured in the same
me interval will be saved in one folder named aer the
beginning date and ending date of the me interval.
Picture Name
Set the naming rule for captured pictures. You can choose Default in the drop-down list to
use the default rule, that is, IP address_channel number_capture
me_event type.jpg (e.g.,
10.11.37.189_01_20150917094425492_FACE_DETECTION.jpg). Or you can customize it by
adding a Custom
Prex to the default naming rule.
4.
Oponal: Check Enable Automac Network Replenishment.
Note
Upload to FTP/Memory Card/NAS in Linkage Method and Enable Automac Network
Replenishment should be both enabled simultaneously.
5.
Click Test to verify the FTP server.
6.
Click Save.
5.1.3 Set NAS
Take network server as network disk to store the record les, captured images, etc.
Before You Start
Get the IP address of the network disk rst.
Network Camera User Manual
33
Steps
1.
Go to NAS seng page: Conguraon → Storage → Storage Management → Net HDD .
2.
Click Add.
3.
Set
Mounng Type.
Mounng Type
Select
le system protocol according to the operaon system.
Enter user name and password of the net HDD to guarantee the security if SMB/CIFS is
selected.
4.
Set the Server Address and File Path for the disk.
Server Address
The IP address of the network disk.
File Path
The saving path of network disk
les.
5.
Click Test to check whether the network disk is available.
6.
Click OK to nish the steps to add a Net HDD.
7.
Oponal: Congure the Net HDD.
Edit Click to edit the parameter seng.
Delete Delete the Net HDD.
●
Click .
●
Select the Net HDD, click Delete.
8.
Click Save.
5.1.4 eMMC
Protecon
It is to automacally stop the use of eMMC as a storage media when its health status is poor.
Note
The eMMC protecon is only supported by certain device models with an eMMC hardware.
Go to Conguraon → System → System Sengs → System Service for the sengs.
eMMC, short for embedded mulmedia card, is an embedded non-volale memory system. It is
able to store the captured images or videos of the device.
The device monitors the eMMC health status and turns
o the eMMC when its status is poor.
Otherwise, using a worn-out eMMC may lead to device boot failure.
5.1.5 Set Cloud Storage
It helps to upload the captured pictures and data to the cloud. The plaorm requests picture
directly from the cloud for picture and analysis. The
funcon is only supported by certain models.
Network Camera User Manual
34
Steps
Cauon
If the cloud storage is enabled, the pictures are stored in the cloud video manager rstly.
1.
Go to Conguraon → Storage → Storage Management → Cloud Storage .
2.
Check Enable.
3.
Set basic parameters.
Protocol Version The protocol version of the cloud video manager.
Server IP The IP address of the cloud video manager. It supports IPv4 address.
Serve Port The port of the cloud video manager. You are recommended to use the
default port.
AccessKey The key to log in to the cloud video manager.
SecretKey The key to encrypt the data stored in the cloud video manager.
User Name and
Password
The user name and password of the cloud video manager.
Picture Storage
Pool ID
The ID of the picture storage region in the cloud video manager. Make
sure storage pool ID and the storage region ID are the same.
4.
Click Test to test the congured sengs.
5.
Click Save.
5.2 Video Recording
This part introduces the operaons of manual and scheduled recording, playback, and
downloading recorded les.
5.2.1 Record
Automacally
This funcon can record video automacally during congured me periods.
Before You Start
Select Trigger Recording in event sengs for each record type except Connuous. See Event and
Alarm for details.
Steps
1.
Go to
Conguraon → Storage → Schedule Sengs → Record Schedule .
2.
Check Enable.
3.
Select a record type.
Network Camera User Manual
35
Note
The record type is vary according to dierent models.
Connuous
The video will be recorded connuously according to the schedule.
Moon
When moon detecon is enabled and trigger recording is selected as linkage method, object
movement is recorded.
Alarm
When alarm input is enabled and trigger recording is selected as linkage method, the video is
recorded
aer receiving alarm signal from external alarm input device.
Moon | Alarm
Video is recorded when moon is detected or alarm signal is received from the external
alarm input device.
Moon & Alarm
Video is recorded only when moon is detected and alarm signal is received from the
external alarm input device.
Event
The video is recorded when congured event is detected.
4.
Set schedule for the selected record type. Refer to
Set Arming Schedule for the seng
operaon.
5.
Set the advanced recording parameters.
Overwrite
Enable Overwrite to overwrite the video records when the storage space is full. Otherwise
the camera cannot record new videos.
Pre-record
The
me period you set to record before the scheduled me.
Post-record
The me period you set to stop recording aer the scheduled me.
Stream Type
Select the stream type for recording.
Note
When you select the stream type with higher bitrate, the actual me of the pre-record and
post-record may be less than the set value.
Recording Expiraon
Network Camera User Manual
36
The recordings are deleted when they exceed the expired me. The expired me is
congurable. Note that once the recordings are deleted, they can not be recovered.
6.
Click Save.
5.2.2 Record Manually
Steps
1.
Go to Conguraon → Local .
2.
Set the Video Size and Video Saving Path for recorded video les.
3.
Click Save.
4.
Click in the live view interface to start recording. Click to stop recording.
What to do next
View the recorded video
les.
Go to Conguraon → Local and click Open behind Video Saving Path to open the saving path and
view the les.
5.2.3 Playback and Download Video
You can search, playback, clip and download the videos stored in the local storage or network
storage.
Steps
1.
Go to Playback → Video .
2.
Set search
condion and click Search.
The matched video les showed on the ming bar.
3.
Click to play the video les.
-
Click to play video les in full screen. Press ESC to exit full screen.
-
Click
to stop video playback for all channels.
4.
Oponal: Click to clip video les. Click again to stop clipping video les
Note
Go to Conguraon → Local → Clip Saving Path , view and change the saving path of clipped
video les.
5.
Oponal: Click on the playback interface to download les.
Note
Go to Conguraon → Local → Downloaded File Saving Path , view and change the saving path
of downloaded video les.
Network Camera User Manual
37
5.3 Capture Conguraon
The device can capture the pictures manually or automacally and save them in congured saving
path. You can view and download the snapshots.
5.3.1 Capture Automacally
This funcon can capture pictures automacally during congured me periods.
Before You Start
If event-triggered capture is required, you should congure related linkage methods in event
sengs. Refer to Event and Alarm for event sengs.
Steps
1.
Go to Conguraon → Storage → Schedule Sengs → Picture Capture .
2.
Set capture schedule. Refer to
Set Arming Schedule for conguring schedule me.
Figure 5-1 Set Capture Schedule
3.
Set the capture type.
Scheduled
Capture a picture at the congured me interval.
Event-Triggered
Capture a picture when an event is triggered.
4.
Set the Format,
Resoluon, Quality, Interval, and Capture Number.
Note
The resoluon of the captured picture is the same as the resoluon of the captured picture
stream. You can select Stream Type in Advanced.
5.
Click Save.
5.3.2 Capture Manually
Steps
1.
Go to
Conguraon → Local .
Network Camera User Manual
38
2.
Set the Image Format and saving path to for snapshots.
JPEG
The picture size of this format is comparavely small, which is beer for network
transmission.
BMP
The picture is compressed with good quality.
3.
Click Save.
4.
Click
near the live view or play back window to capture a picture manually.
5.3.3 View and Download Picture
You can search, view and download the pictures stored in the local storage or network storage.
Steps
1.
Go to Playback → Picture .
2.
Set search
condion and click Search.
The matched pictures showed in the le list.
3.
Download the pictures.
-
Select the pictures then click Download to download them.
-
Click Download This Page to download the pictures of this page.
-
Click Download All to download all the pictures.
Note
Go to Conguraon → Local → Playback Capture Saving Path , view and change the saving path
of captured pictures when playback.
Network Camera User Manual
39
Chapter 6 Event and Alarm
This part introduces the conguraon of events. The device takes certain response to triggered
alarm. Certain events may not be supported by certain device models.
6.1 Set Moon Detecon
It helps to detect the moving objects in the detecon region and trigger the linkage acons.
Steps
1.
Go to Conguraon → Event → Event and Detecon → Moon Detecon .
2.
Check Enable.
3.
Oponal: Highlight to display the moving object in the image in green.
1) Check Enable Dynamic Analysis for Moon.
2) Go to
Conguraon → Local .
3) Set Rules to Enable.
4.
Select mode in
Conguraon, and set rule region and rule parameters.
-
For the
informaon about normal mode, see Normal Mode .
-
For the
informaon about expert mode, see Expert Mode .
5.
Set the arming schedule and linkage methods. For the
informaon about arming schedule
sengs, see Set Arming Schedule . For the informaon about linkage methods, see Linkage
Method Sengs .
6.
Click Save.
6.1.1 Expert Mode
You can congure dierent moon detecon parameters for day and night according to the actual
needs.
Steps
1.
Select Expert Mode in Conguraon.
2.
Set parameters of expert mode.
Scheduled Image
Sengs
OFF
Image switch is disabled.
Auto-Switch
The system switches day/night mode automacally according to environment. It displays
colored image at day and black and white image at night.
Scheduled-Switch
Network Camera User Manual
40
The system switches day/night mode according to the schedule. It switches to day mode
during the set periods and switches to night mode during the other periods.
Sensivity
The higher the value of sensivity is, the more sensive the moon detecon is. If scheduled
image sengs is enabled, the sensivity of day and night can be set separately.
3.
Select an Area and click . Click and drag the mouse on the live image and then release the
mouse to
nish drawing one area.
Figure 6-1 Set Rules
4.
Click to clear all the areas.
5.
Click Save.
6.
Oponal: Repeat above steps to set mulple areas.
6.1.2 Normal Mode
You can set moon detecon parameters according to the device default parameters.
Steps
1.
Select Normal Mode in Conguraon.
2.
Set the Sensivity of normal mode. The higher the value of sensivity is, the more sensive the
moon detecon is. If the sensivity is set to 0, moon detecon and dynamic analysis do not
take eect.
3.
Set Detecon Target. Human and vehicle are available. If the detecon target is not selected, all
the detected targets will be reported, including the human and vehicle. This
funcon allows
alarm triggering by specied target types (human and vehicle).
Network Camera User Manual
41
Note
This funcon is only available for certain device models under certain sengs. Please refer to
the actual sengs.
4.
Click . Click and drag the mouse on the live image, and then right click the mouse to nish
drawing one area.
5.
Oponal: Click to clear all the areas.
6.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.2 Set Video Tampering Alarm
When the
congured area is covered and cannot be monitored normally, the alarm is triggered and
the device takes certain alarm response
acons.
Steps
1.
Go to Conguraon → Event → Event and Detecon → Video Tampering .
2.
Check Enable.
3.
Set the
Sensivity. The higher the value is, the easier to detect the area covering.
4.
Click and drag the mouse in the live view to draw the area.
Network Camera User Manual
42
Figure 6-2 Set Video Tampering Area
5.
Oponal: Click to delete all the drawn areas.
6.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
7.
Click Save.
6.3 Set Alarm Input
Alarm signal from the external device triggers the corresponding acons of the current device.
Before You Start
Note
This funcon is only supported by certain models.
Make sure the external alarm device is connected. See Quick Start Guide for cable connecon.
Network Camera User Manual
43
Steps
1.
Go to Conguraon → Event → Event and Detecon → Alarm Input .
2.
Select an Alarm Input NO. and click to set alarm input.
3.
Select Alarm Type from the dropdown list. Edit the Alarm Name.
4.
Check Enable Alarm Input Handling.
5.
Refer to
Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
6.
Click Copy to... to copy the sengs to other alarm input channels.
7.
Click Save.
6.4 Set Excepon Alarm
Excepon such as network disconnecon can trigger the device to take corresponding acon.
Steps
1.
Go to Conguraon → Event → Event and Detecon → Excepon .
2.
Select
Excepon Type.
HDD Full
The HDD storage is full.
HDD Error
Error occurs in HDD.
Network Disconnected
The device is oine.
IP Address Conicted
The IP address of current device is same as that of other device in the network.
Illegal Login
Incorrect user name or password is entered.
Abnormal Restart
The device restarts abnormally.
3.
Refer to
Linkage Method Sengs for seng linkage method.
4.
Click Save.
6.5 Set Video Quality Diagnosis
When the video quality of the device is abnormal and the alarm linkage is set, the alarm will be
triggered automacally.
Steps
1.
Go to Conguraon → Event → Event and Detecon → Video Quality Diagnosis .
2.
Select Diagnosis Type.
Network Camera User Manual
44
3.
Set the corresponding parameters.
Alarm Detecon Interval
The me interval to detect the excepon.
Sensivity
The higher the value is, the more easily the excepon will be detected, and the higher
possibility of misinformaon would be.
Alarm Delay Times
The device uploads the alarm when the alarm reaches the set number of
mes.
4.
Check the selected diagnosis type, and the related type will be detected.
5.
Set arming schedule. See
Set Arming Schedule .
6.
Set linkage method. See Linkage Method Sengs .
7.
Click Save.
Note
The funcon is only supported by certain models. The actual display varies with models.
6.6 Set Vibraon Detecon
It is used to detect whether the device is vibrang. The device reports an alarm and triggers linkage
acons if the funcon is enabled.
Steps
1.
Go to Conguraon → Event → Event and Detecon → Vibraon Detecon .
2.
Check Enable.
3.
Drag the slider to set the
detecon sensivity. You can also enter number to set the sensivity.
4.
Set the arming schedule. See Set Arming Schedule .
5.
Set the linkage method. See
Linkage Method Sengs .
6.
Click Save.
Note
The funcon is only supported by certain models. The actual display varies with models.
6.7 Set Audio Excepon Detecon
Audio excepon detecon funcon detects the abnormal sound in the scene, such as the sudden
increase/decrease of the sound intensity, and some certain acons can be taken as response.
Steps
1.
Go to Conguraon → Event → Event and Detecon → Audio Excepon Detecon .
2.
Select one or several audio
excepon detecon types.
Network Camera User Manual
45
Audio Loss Detecon
Detect sudden loss of audio track.
Sudden Increase of Sound Intensity Detecon
Detect sudden increase of sound intensity. Sensivity and Sound Intensity Threshold are
congurable.
Note
●
The lower the sensivity is, the more signicant the change should be to trigger the
detecon.
●
The sound intensity threshold refers to the sound intensity reference for the detecon. It is
recommended to set as the average sound intensity in the environment. The louder the
environment sound, the higher the value should be. You can adjust it according to the real
environment.
Sudden Decrease of Sound Intensity Detecon
Detect sudden decrease of sound intensity. Sensivity is congurable.
3.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage methods.
4.
Click Save.
Note
The funcon is only supported by certain models. The actual funcon varies according to
dierent models.
6.8 Set Defocus Detecon
The blurred image caused by lens defocus can be detected. If it occurs, the device can take linkage
acons.
Steps
1.
Go to
Conguraon → Event → Event and Detecon → Defocus Detecon .
2.
Check Enable.
3.
Set
Sensivity. The higher the value is, the more easily the defocus image can trigger the alarm.
You can adjust the value according to the actual environment.
4.
For the linkage method sengs, refer to Linkage Method Sengs .
5.
Click Save.
Note
The funcon is only supported by certain models. The actual display varies with models.
Network Camera User Manual
46
6.9 Set Scene Change Detecon
Scene change detecon funcon detects the change of the scene. Some certain acons can be
taken when the alarm is triggered.
Steps
1.
Go to Conguraon → Event → Event and Detecon → Scene Change Detecon .
2.
Click Enable.
3.
Set the
Sensivity. The higher the value is, the more easily the change of scene can be detected.
But the detecon accuracy is reduced.
4.
Refer to
Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
5.
Click Save.
Note
The funcon is only supported by certain models. The actual display varies with models.
Network Camera User Manual
47
Chapter 7 Arming Schedule and Alarm Linkage
Arming schedule is a customized me period in which the device performs certain tasks. Alarm
linkage is the response to the detected certain incident or target during the scheduled
me.
7.1 Set Arming Schedule
Set the valid
me of the device tasks.
Steps
1.
Oponal: Click Arming Schedule and Linkage Method in the related event interface.
2.
Click Edit behind Arming Schedule.
3.
Click Draw, and drag the
me bar to draw desired valid me.
Note
●
Each cell represents 30 minutes.
●
Move the mouse over the drawn me period to see specic me periods and ne-tune the
start me and end me.
●
Up to 8 periods can be
congured for one day.
4.
Click Erase, and drag the me bar to clear selected valid me.
5.
Click OK to save the sengs.
Figure 7-1 Set Arming Schedule
7.2 Linkage Method
Sengs
You can enable the linkage funcons when an event or alarm occurs.
Network Camera User Manual
48
7.2.1 Trigger Alarm Output
If the device has been connected to an alarm output device, and the alarm output No. has been
congured, the device sends alarm informaon to the connected alarm output device when an
alarm is triggered.
Steps
1.
Go to Conguraon → Event → Alarm Seng → Alarm Output .
2.
Set alarm output parameters.
Automac Alarm For the informaon about the conguraon, see Automac Alarm .
Manual Alarm For the informaon about the conguraon, see Manual Alarm .
Manual Alarm
You can trigger an alarm output manually.
Before You Start
Make sure the alarm output device is connected to the device.
Steps
1.
Select the Alarm Output No. according to the alarm interface connected to the external alarm
device. Click
to set alarm parameters.
Alarm Name
Custom a name for the alarm output.
2.
Click Manual Alarm to enable manual alarm output.
3.
Oponal: Click Clear Alarm to disable manual alarm output.
Automac
Alarm
Set the automac alarm parameters, then the device triggers an alarm output automacally in the
set arming schedule.
Before You Start
Make sure the alarm output device is connected to the device.
Steps
1.
Select the Alarm Output No. according to the alarm interface connected to the external alarm
device. Click
to set alarm parameters.
Alarm Name
Custom a name for the alarm output.
Delay
It refers to the me duraon that the alarm output remains aer an alarm occurs.
Network Camera User Manual
49
2.
Set the alarming schedule. For the informaon about the sengs, see Set Arming Schedule .
3.
Oponal: Click Copy to… to copy the parameters to other alarm output channels.
4.
Click Save.
7.2.2 FTP/NAS/Memory Card Uploading
If you have enabled and congured the FTP/NAS/memory card uploading, the device sends the
alarm informaon to the FTP server, network aached storage and memory card when an alarm is
triggered.
Refer to
Set FTP to set the FTP server.
Refer to Set NAS for NAS conguraon.
Refer to Set New or Unencrypted Memory Card for memory card storage conguraon.
7.2.3 Send Email
Check Send Email, and the device sends an email to the designated addresses with alarm
informaon when an alarm event is detected.
For email sengs, refer to Set Email .
Set Email
When the email is congured and Send Email is enabled as a linkage method, the device sends an
email nocaon to all designated recipients if an alarm event is detected.
Before You Start
Set the DNS server before using the Email funcon. Go to Conguraon → Network → Network
Sengs → TCP/IP for DNS sengs.
Steps
1.
Go to email
sengs page: Conguraon → Event → Alarm Seng → Email .
2.
Set email parameters.
1) Input the sender's email
informaon, including the Sender's Address, SMTP Server, and
SMTP Port.
2)
Oponal: If your email server requires authencaon, check Authencaon and input your
user name and password to log in to the server.
3) Set the E-mail Encrypon.
●
When you select TLS, and disable STARTTLS, emails are sent
aer encrypted by TLS. The
SMTP port should be set as 465.
●
When you select TLS and check Enable STARTTLS, emails are sent
aer encrypted by
STARTTLS, and the SMTP Port should be set as 25.
Network Camera User Manual
50
Note
If you want to use STARTTLS, make sure that the protocol is supported by your email server.
If you check the Enable STARTTLS while the protocol is not supported by your email sever,
your email is sent with no encr ypon.
4) Oponal: If you want to receive nocaon with alarm pictures, check Aached Picture. The
nocaon email has a certain number of aached alarm pictures about the event with
congurable image capturing interval.
Note
The number of alarm pictures may vary according to dierent device models and dierent
events.
5) Input the recipient's informaon, including the recipient's name and address.
6) Click Test to see if the
funcon is well congured.
3.
Click Save.
7.2.4
Nofy Surveillance Center
Check Nofy Surveillance Center, the alarm informaon is uploaded to the surveillance center
when an alarm event is detected.
7.2.5 Trigger Recording
Check Trigger Recording, and the device records the video about the detected alarm event.
For recording sengs, refer to Video Recording and Picture Capture .
7.2.6 Audible Warning
Aer enabling Audible Warning and seng Audible Alarm Output, the built-in speaker of the
device or connected external speaker plays warning sounds when an alarm happens.
For audible alarm output
sengs, refer to Set Audible Alarm Output .
Note
The funcon is only supported by certain camera models.
Set Audible Alarm Output
When the device detects targets in the detecon area, audible alarm can be triggered as a
warning.
Steps
1.
Go to
Conguraon → Event → Alarm Seng → Audible Alarm Output .
Network Camera User Manual
51
2.
Select Sound Type and set related parameters.
-
Select Prompt and set the alarm mes you need.
-
Select Warning and its contents. Set the alarm mes you need.
-
Select Custom Audio. You can select a custom audio
le from the drop-down list. If no le is
available, you can click Set → Add to upload an audio
le that meets the requirement. Up to
three audio
les can be uploaded.
3.
Oponal: Click Test to play the selected audio le on the device.
4.
Set arming schedule for audible alarm. See Set Arming Schedule for details.
5.
Click Save.
Note
The funcon is only supported by certain device models.
7.2.7 Alarm Server
The device can send alarms to desnaon IP address or host name through HTTP, HTTPS, or ISUP
protocol. The desnaon IP address or host name should support HTTP, HTTP, or ISUP data
transmission.
Set Alarm Server
Steps
1.
Go to
Conguraon → Event → Alarm Seng → Alarm Server .
2.
Enter Desnaon IP or Host Name, URL, and Port.
3.
Select Protocol.
Note
HTTP, HTTPS, and ISUP are selectable. It is recommended to use HTTPS, as it encrypts the data
transmission during communicaon.
4.
Click Test to check if the IP or host is available.
5.
Click Save.
Network Camera User Manual
52
Chapter 8 Network Sengs
8.1 TCP/IP
TCP/IP sengs must be properly congured before you operate the device over network. IPv4 and
IPv6 are both supported. Both versions can be congured simultaneously without conicng to
each other.
Go to Conguraon → Network → Network Sengs → TCP/IP for parameter sengs.
NIC Type
Select a NIC (Network Interface Card) type according to your network condion.
IPv4
Two IPv4 modes are available.
DHCP
The device
automacally gets the IPv4 parameters from the network if you check DHCP. The
device IP address is changed aer enabling the funcon. You can use SADP to get the device IP
address.
Note
The network that the device is connected to should support DHCP (Dynamic Host
Conguraon Protocol).
Manual
You can set the device IPv4 parameters manually. Input IPv4 Address, IPv4 Subnet Mask, and
IPv4 Default Gateway, and click Test to see if the IP address is available.
IPv6
Three IPv6 modes are available.
Route
Adversement
The IPv6 address is generated by combining the route adversement and the device Mac
address.
Note
Route adversement mode requires the support from the router that the device is connected
to.
DHCP
The IPv6 address is assigned by the server, router, or gateway.
Manual
Network Camera User Manual
53
Input IPv6 Address, IPv6 Subnet, IPv6 Default Gateway. Consult the network administrator for
required informaon.
MTU
It stands for maximum transmission unit. It is the size of the largest protocol data unit that can
be communicated in a single network layer
transacon.
The valid value range of MTU is 1280 to 1500.
DNS
It stands for domain name server. It is required if you need to visit the device with domain
name. And it is also required for some
applicaons (e.g., sending email). Set Preferred DNS
Server and Alternate DNS server properly if needed.
Domain Name Sengs
Check Enable Dynamic Domain Name and input Register Domain Name. The device is
registered under the register domain name for easier management within the local area
network.
Note
DHCP should be enabled for the dynamic domain name to take eect.
8.2 Access to Device via Domain Name
You can use the Dynamic DNS (DDNS) for network access. The dynamic IP address of the device can
be mapped to a domain name resoluon server to realize the network access via domain name.
Before You Start
Registraon on the DDNS server is required before conguring the DDNS sengs of the device.
Steps
1.
Refer to TCP/IP to set DNS parameters.
2.
Go to the DDNS
sengs page: Conguraon → Network → Network Sengs → DDNS .
3.
Check Enable and select DDNS Type.
DynDNS
Dynamic DNS server is used for domain name
resoluon.
NO-IP
NO-IP server is used for domain name resoluon.
4.
Input the domain name informaon, and click Save.
5.
Check the device ports and complete port mapping. Refer to
Port Mapping for port mapping
sengs.
6.
Access the device.
By Browsers
Enter the domain name in the browser address bar to access the device.
Network Camera User Manual
54
By Client Soware Add domain name to the client soware. Refer to the client manual for
specic adding methods.
8.3 Access to Device via PPPoE Dial Up Connecon
This device supports the PPPoE auto dial-up funcon. The device gets a public IP address by ADSL
dial-up
aer the device is connected to a modem. You need to congure the PPPoE parameters of
the device.
Steps
1.
Go to
Conguraon → Network → Network Sengs → PPPoE .
2.
Check Enable.
3.
Set the PPPoE parameters.
Dynamic IP
Aer successful dial-up, the dynamic IP address of the WAN is displayed.
User Name
User name for dial-up network access.
Password
Password for dial-up network access.
Conrm
Input your dial-up password again.
4.
Click Save.
5.
Access the device.
By Browsers
Enter the WAN dynamic IP address in the browser address bar to access
the device.
By Client Soware Add the WAN dynamic IP address to the client soware. Refer to the
client manual for details.
Note
The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes
aer reboong the camera. To solve the inconvenience of the dynamic IP, you need to get a
domain name from the DDNS provider (e.g. DynDns.com). Refer to Access to Device via Domain
Name for detail informaon.
8.4 SNMP
You can set the SNMP (Simple Network Management Protocol) to get device informaon in
network management.
Network Camera User Manual
55
Before You Start
Before seng the SNMP, you should download the SNMP soware and manage to receive the
device informaon via SNMP port.
Steps
1.
Go to
Conguraon → Network → Network Sengs → SNMP .
2.
Check Enable SNMPv1, Enable SNMP v2c or Enable SNMPv3.
Note
The SNMP version you select should be the same as that of the SNMP soware.
And you also need to use the dierent version according to the security level required. SNMP v1
is not secure and SNMP v2 requires password for access. And SNMP v3 provides encrypon and
if you use the third version, HTTPS protocol must be enabled.
3.
Congure the SNMP sengs.
4.
Click Save.
8.5 Set IEEE 802.1X
You can authencate user permission of the connected device by seng IEEE 802.1X.
Go to
Conguraon → Network → Network Sengs → 802.1X , and enable the funcon.
Select protocol and version according to router informaon. User name and password of server are
required.
Note
●
If you set the Protocol to EAP-TLS, select the Client Cercate and CA Cercate.
●
If the funcon is abnormal, check if the selected cercate is abnormal in Cercate
Management.
8.6 Set QoS
QoS (Quality of Service) can help improve the network delay and network congeson by seng
the priority of data sending.
Note
QoS needs support from network device such as router and switch.
Steps
1.
Go to
Conguraon → Network → Network Sengs → QoS .
2.
Set Video/Audio DSCP, Event/Alarm DSCP and Management DSCP.
Network Camera User Manual
56
Note
Network can idenfy the priority of data transmission. The bigger the DSCP value is, the higher
the priority is. You need to set the same value in router while conguraon.
3.
Click Save.
8.7 HTTP(S)
HTTP is an applicaon-layer protocol for transming hypermedia documents. HTTPS is a network
protocol that enables encrypted transmission and identy authencaon, which improves the
security of remote access.
Steps
1.
Go to
Conguraon → Network → Network Service → HTTP(S) .
2.
Enter HTTP Port.
Note
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.168.1.64:81 in the browser for login.
3.
Check Enable in HTTPS.
Note
You can click TLS Sengs to set the TLS version that the device supports. Refer to for details.
4.
Enter HTTPS Port.
5.
Oponal: Check HTTPS Browsing to access the device only via HTTPS protocol.
6.
Select Server Cercate.
7.
Set Web
Authencaon.
Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed
when WEB request is sent to the device. If you select digest/basic, it means the device
supports digest or basic
authencaon. If you select digest, the device only supports digest
authencaon.
Digest Algorithm
MD5, SHA256 and MD5/SHA256 encrypted algorithm in WEB authencaon. If you enable
the digest algorithm except for MD5, the third-party plaorm might not be able to log in to
the device or enable live view because of
compability. The encrypted algorithm with high
strength is recommended.
8.
Click Save.
Network Camera User Manual
57
8.8 Mulcast
Mulcast is group communicaon where data transmission is addressed to a group of desnaon
devices simultaneously.
Go to Conguraon → Network → Network Service → Mulcast for the mulcast sengs.
IP Address
It stands for the address of mulcast host.
8.8.1 Mulcast Discovery
Go to Conguraon → Network → Network Sengs → TCP/IP to enable this funcon.
Check the Enable Mulcast Discovery, and then the online network camera can be automacally
detected by client soware via private mulcast protocol in the LAN.
8.9 RTSP
RTSP (Real Time Streaming Protocol) is an applicaon-layer controlling protocol for streaming
media.
Steps
1.
Go to
Conguraon → Network → Network Service → RTSP .
2.
Enter Port.
3.
Set
Mulcast parameters.
Stream Type
The stream type as the mulcast source.
Video Port
The video port of the selected stream.
Audio Port
The audio port of the selected stream.
4.
Set RTSP
Authencaon.
Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed
when RTSP request is sent to the device. If you select digest/basic, it means the device
supports digest or basic authencaon. If you select digest, the device only supports digest
authencaon.
Digest Algorithm
MD5, SHA256 and MD5/SHA256 encrypted algorithm in RTSP authencaon. If you enable
the digest algorithm except for MD5, the third-party plaorm might not be able to log in to
Network Camera User Manual
58
the device or enable live view because of compability. The encrypted algorithm with high
strength is recommended.
5.
Click Save.
8.10 Set SRTP
The Secure Real-me Transport Protocol (SRTP) is a Real-me Transport Protocol (RTP) internet
protocol, intended to provide encrypon, message authencaon and integrity, and replay aack
protecon
to the RTP data in both unicast and mulcast applicaons.
Steps
1.
Go to Conguraon → Network → Network Service → SRTP .
2.
Enter the Port number.
3.
Set
Mulcast parameters.
Stream Type
The stream type as the mulcast source.
Video Port
The video port of the selected stream.
Audio Port
The audio port of the selected stream.
4.
Select Server Cercate.
5.
Select Encrypted Algorithm.
6.
Click Save.
Note
●
Only certain device models support this funcon.
●
If the funcon is abnormal, check if the selected cercate is abnormal in Cercate
Management .
8.11 Bonjour
It is an implementaon of zero-conguraon networking (zeroconf), a group of technologies that
includes service discovery, address assignment, and hostname resoluon. Bonjour locates devices
such as printers, other computers, and the services that those devices
oer on a local network
using mulcast Domain Name System (mDNS) service records.
Go to
Conguraon → Network → Network Service → Bonjour to enable the funcon, and click
Save.
Aer enabling the funcon, the device spread and receive service informaon in local area
network.
Network Camera User Manual
59
8.12 WebSocket(s)
WebSocket or WebSockets protocol should be enabled if you use Google Chrome 57 and its above
version or Mozilla Firefox 52 and its above version to visit the device. Otherwise, live view, image
capture, digital zoom, etc. cannot be used.
Go to
Conguraon → Network → Network Service → WebSocket(s) to set parameters, and click
Save.
WebSocket
TCP-based full-duplex communicaon protocol port for plug-in free preview via HTTP protocol.
WebSockets
TCP-based full-duplex communicaon protocol port for plug-in free preview via HTTPS protocol.
8.13 Port Mapping
By seng port mapping, you can access devices through the specied port.
Steps
1.
Go to
Conguraon → Network → Network Service → NAT .
2.
Select the port mapping mode.
Auto Port Mapping
Refer to Set Auto Port Mapping for detailed informaon.
Manual Port Mapping Refer to Set Manual Port Mapping for detailed informaon.
3.
Click Save.
8.13.1 Set Auto Port Mapping
Steps
1.
Check Enable UPnP™, and choose a friendly name for the camera, or you can use the default
name.
2.
Select the port mapping mode to Auto.
3.
Click Save.
Note
UPnP™ funcon on the router should be enabled at the same me.
8.13.2 Set Manual Port Mapping
Steps
1.
Check Enable UPnP™, and choose a friendly name for the device, or you can use the default
name.
Network Camera User Manual
60
2.
Select the port mapping mode to Manual, and set the external port to be the same as the
internal port.
3.
Click Save.
What to do next
Go to the router port mapping
sengs interface and set the port number and IP address to be the
same as those on the device. For more informaon, refer to the router user manual.
8.13.3 Set Port Mapping on Router
The following
sengs are for a certain router. The sengs vary depending on dierent models of
routers.
Steps
1.
Select the WAN
Connecon Type.
2.
Set the IP Address, Subnet Mask and other network parameters of the router.
3.
Go to Forwarding → Virtual Severs , and input the Port Number and IP Address.
4.
Click Save.
Example
When the cameras are connected to the same router, you can
congure the ports of a camera as
80, 8000, and 554 with IP address 192.168.1.23, and the ports of another camera as 81, 8001, 555,
8201 with IP 192.168.1.24.
Figure 8-1 Port Mapping on Router
Network Camera User Manual
61
Note
The port of the network camera cannot conict with other ports. For example, some web
management port of the router is 80. Change the camera port if it is the same as the management
port.
8.14 RTCP
The device relies on RTCP (Real-me Transport Control Protocol) to deliver packets sequenally to
provide a reliable delivery mechanism and to provide services for
ow control or congeson
control.
Go to Conguraon → Network → Network Service → RTCP and check Enable to enable the
funcon.
8.15 Wireless Dial
Data of audio, video and image can be transferred via 3G/4G wireless network.
Note
The funcon is only supported by certain device models.
8.15.1 Set Wireless Dial
The built-in wireless module oers dial-up access to the Internet for the device.
Before You Start
Get a SIM card, and acvate 3G/4G services. Insert the SIM card to the corresponding slot.
Steps
1.
Go to Conguraon → Network → Network Sengs → Wireless Dial .
2.
Check to enable the funcon.
3.
Go to Dial Parameters to congure and save the parameters.
4.
Click Sengs behind Dial Plan. See Set Arming Schedule for detailed informaon.
5.
View the Dial Status.
Click Refresh
Refresh the dial status.
Click Disconnect Disconnect the 3G/4G wireless network.
When the Dial Status turns to Connected, it means a successful dial.
6.
Access the device via the IP Address of the computer in the network.
-
Input the IP address in the browser to access the device.
-
Add the device in client
applicaon. Select IP/Domain, and input IP address and other
parameters to access the device.
Network Camera User Manual
62
7.
Oponal: You can view 4G SIM card informaon and network carrier informaon.
Note
For certain device models working on Performance Mode or Proacve Mode, the wireless
mode can be upgraded. If necessary, please upgrade the wireless mode under the guidance of a
professional.
8.
Oponal: Click Re-Camp to reconnect the device to wireless network manually. The device will
maintain airplane mode for 10 seconds and then connects to network automacally.
9.
Oponal: Check Enable to enable Auto Re-Camp, and then set the Re-Camp Interval. The device
will reconnect to the wireless network at set Re-Camp Interval
automacally.
Note
The funcon may vary according to dierent device models.
8.15.2 Wireless Expert Sengs
Wireless expert sengs provide more details of the 3G/4G wireless network to which the device
connects and help the professionals troubleshoot potenal network issues.
Cell Radio Frequency Parameters
Cell radio frequency parameters provides the current wireless network informaon to which the
device is connected.
Go to Conguraon → Network → Network Sengs → Wireless Dial → Expert Sengs to view
cell radio frequency parameters.
Network Info
It displays the current cellular network
informaon. You can click Refresh to view the frequency
informaon of dierent cells.
Radio Frequency Fluctuaon
It records the uctuaon of the cellular network to which the device has connected during the
past 7 days. Click Export Report and set and conrm the encrypon password to export the
uctuaon report.
Lock Band
You can lock a set of bands that get the device faster data rates to improve the network speed.
Steps
1.
Go to Conguraon → Network → Network Sengs → Wireless Dial → Expert Sengs → Lock
Band .
2.
Check Enable.
Network Camera User Manual
63
3.
Click Add and enter the band.
Note
●
The band you enter should be B + number or N + number. For example, you can enter B1 or
N1.
●
Up to ve bands are supported.
4.
Oponal: Click to delete the selected band. You can also click Clear All to clear the list.
Capture Baseband Packet
This funcon can capture the protocol interacon packet to help the professionals to locate the
communicaon failures between 4G module and the base staon.
Steps
Note
This funcon is reserved for the professionals and technical support sta.
1.
Go to Conguraon → Network → Network Sengs → Wireless Dial → Expert Sengs .
2.
Click Conguraon behind Capture Baseband Packet to enter the seng interface.
3.
Check Enable to enable this
funcon.
4.
Set capture duraon and the saving path. The saving path depends on the actual storage
method of the device. You can click Delete Captured Packet Under This Path to delete the
captured packet.
5.
Click Save.
6.
Click Start Capturing Packet to capture the baseband packet.
7.
Oponal: Click Stop Capturing to stop the capturing process.
8.
Aer the capturing is completed, click Export Captured Packet to save the report.
Speed Test
Steps
1.
Go to Conguraon → Network → Network Sengs → Wireless Dial → Expert Sengs .
2.
Click Conguraon behind Speed Test to enter the seng interface.
3.
Select the default server or enter the server address. You can follow the steps below to get the
nearby server address.
Note
You can follow the steps below to get the nearby server address.
a. Visit this website to get the nearby server address: hps://www.speedtest.net/speedtest-
servers-stac.php .
b. Select and copy the URL of the nearby speed test
staon and paste it in Server Address.
Network Camera User Manual
64
4.
Click Speed Test to start the test.
You can view the speed details aer the test is completed. You can also click Export Speed Test
Result.
8.16 Trac Shaping
Trac shaping is used to shape and smooth video data packet before transmission.
It helps to improve latency and reduce packet loss caused by network congeson and ensure the
video quality as well. Shaping level is
congurable.
8.17 Data Monitoring
You can view and manage the SIM card data or wired network data used by the device. SIM card
data is the data service provided by network carriers; wired network data is usually provided
through a 4G router.
Steps
1.
Go to
Conguraon → Network → Network Sengs → Data Monitoring .
2.
Check Enable.
3.
Set the following parameters according to your data plan.
Plan Type
Daily, Monthly, or Annually can be selected.
Data Plan
Enter the amount of usable data and select the unit.
Pre-Alarm Threshold
When the used data reaches the set percentage of data plan, the device sends an alarm
message, and shows
nocaon on the OSD or pop-up window.
4.
Select Normal Linkage.
If Send Email or Nofy Surveillance Center is selected, the device sends an alarm message by
Email or to surveillance center when the used data reaches the threshold.
5.
Click Save.
Note
The funcon varies with dierent device models.
8.18 Set ISUP
When the device is registered on ISUP plaorm (formerly called Ehome), you can visit and manage
the device, transmit data, and forward alarm informaon over public network.
Network Camera User Manual
65
Steps
1.
Go to Conguraon → Network → Plaorm Access → ISUP .
2.
Oponal: Select an access center.
3.
Check Enable.
4.
Select a protocol version and enter related parameters.
5.
Click Save.
Register status turns to Online when the
funcon is correctly set.
8.19 Set OTAP
The device can be accessed to the maintenance
plaorm via OTAP protocol, in order to search and
acquire device informaon, upload device status and alarm informaon, reboot and update the
device.
Steps
1.
Go to
Conguraon → Network → Plaorm Access → OTAP to enable the funcon.
2.
Set related parameters.
3.
Click Test to check if the device connects to server.
4.
Click Save.
Register Status turns to Online when the
funcon is correctly set.
8.20 Access Camera via Hik-Connect
Hik-Connect is an applicaon for mobile devices. Using the App, you can view live image, receive
alarm nocaon and so on.
Before You Start
Connect the camera to network with network cables.
Steps
1.
Get and install Hik-Connect
applicaon by the following ways.
-
Visit
hps://appstore.hikvision.com to download the applicaon according to your mobile
phone system.
-
Visit the ocial site of our company. Then go to Support → Tools → Hikvision App Store .
-
Scan the QR code below to download the
applicaon.
Network Camera User Manual
66
Note
If errors like "Unknown app" occur during the installaon, solve the problem in two ways.
●
Visit hps://appstore.hikvision.com/stac/help/index.html to refer to the troubleshoong.
●
Visit hps://appstore.hikvision.com/ , and click Installaon Help at the upper right corner of
the interface to refer to the
troubleshoong.
2.
Start the applicaon and register for a Hik-Connect user account.
3.
Log in aer registraon.
4.
In the app, tap "+" on the upper-right corner and then scan the QR code of the camera to add
the camera. You can
nd the QR code on the camera or on the cover of the Quick Start Guide of
the camera in the package.
5.
Follow the prompts to set the network connecon and add the camera to your Hik-Connect
account.
For detailed
informaon, refer to the user manual of the Hik-Connect app.
8.20.1 Enable Hik-Connect Service on Camera
Hik-Connect service should be enabled on your camera before using the service.
You can enable the service through SADP soware or Web browser.
Enable Hik-Connect Service via Web Browser
Follow the following steps to enable Hik-Connect Service via Web Browser.
Before You Start
You need to acvate the camera before enabling the service.
Steps
1.
Access the camera via web browser.
2.
Enter
plaorm access conguraon interface. Conguraon → Network → Plaorm Access →
Hik-Connect .
3.
Check Enable.
4.
Click and read "Terms of Service" and "Privacy Policy" in pop-up window.
5.
Create a
vericaon code or change the old vericaon code for the camera.
Note
The vericaon code is required when you add the camera to Hik-Connect service.
6.
Save the sengs.
Network Camera User Manual
67
Enable Hik-Connect Service via SADP Soware
This part introduce how to enable Hik-Connect service via SADP soware of an acvated camera.
Steps
1.
Run SADP
soware.
2.
Select a camera and enter Modify Network Parameters page.
3.
Check Enable Hik-Connect.
4.
Create a
vericaon code or change the old vericaon code.
Note
The vericaon code is required when you add the camera to Hik-Connect service.
5.
Click and read "Terms of Service" and "Privacy Policy".
6.
Conrm the sengs.
8.20.2 Set Up Hik-Connect
Steps
1.
Get and install Hik-Connect applicaon by the following ways.
-
Visit hps://appstore.hikvision.com to download the applicaon according to your mobile
phone system.
-
Visit the
ocial site of our company. Then go to Support → Tools → Hikvision App Store .
-
Scan the QR code below to download the applicaon.
Note
If errors like "Unknown app" occur during the installaon, solve the problem in two ways.
●
Visit hps://appstore.hikvision.com/stac/help/index.html to refer to the troubleshoong.
●
Visit hps://appstore.hikvision.com/ , and click Installaon Help at the upper right corner of
the interface to refer to the
troubleshoong.
2.
Start the applicaon and register for a Hik-Connect user account.
3.
Log in
aer registraon.
Network Camera User Manual
68
8.20.3 Add Camera to Hik-Connect
Steps
1.
Connect your mobile device to a Wi-Fi.
2.
Log into the Hik-Connect app.
3.
In the home page, tap "+" on the upper-right corner to add a camera.
4.
Scan the QR code on camera body or on the Quick Start Guide cover.
Note
If the QR code is missing or too blur to be recognized, you can also add the camera by inpung
the camera's serial number.
5.
Input the vericaon code of your camera.
Note
●
The required vericaon code is the code you create or change when you enable Hik-Connect
service on the camera.
●
If you forget the vericaon code, you can check the current vericaon code on Plaorm
Access conguraon page via web browser.
6.
Tap Connect to a Network buon in the popup interface.
7.
Choose Wired Connecon or Wireless Connecon according to your camera funcon.
Wireless
Connecon
Input the Wi-Fi password that your mobile phone has connected to, and
tap Next to start the Wi-Fi connecon process. (Locate the camera within 3
meters from the router when seng up the Wi-Fi.)
Wired
Connecon
Connect the camera to the router with a network cable and tap Connected
in the result interface.
Note
The router should be the same one which your mobile phone has connected to.
8.
Tap Add in the next interface to nish adding.
For detailed informaon, refer to the user manual of the Hik-Connect app.
8.21 Set Open Network Video Interface
If you need to access the device through Open Network Video Interface protocol, you can
congure the user sengs to enhance the network security.
Steps
1.
Go to
Conguraon → Network → Plaorm Access → Open Network Video Interface .
2.
Check Enable.
3.
Select an authencaon mode.
-
If you select Digest, the device only supports digest authencaon.
Network Camera User Manual
69
-
If you select Digest&ws-username token, the device supports digest authencaon or ws-
username token authencaon.
4.
Click Add to congure the Open Network Video Interface user.
5.
Click Save.
6.
Oponal: Repeat the steps above to add more Open Network Video Interface users.
7.
Oponal: Manage the user.
-
Click
to delete the selected Open Network Video Interface user.
-
Click
to modify the selected Open Network Video Interface user.
8.22 Set SDK Service
If you want to add the device to the client
soware, you should enable SDK Service or Enhanced
SDK Service.
Steps
1.
Go to
Conguraon → Network → Plaorm Access → SDK Service .
2.
Set SDK Service parameters.
1) Check Enable to add the device to the client
soware with SDK protocol.
2) Enter the Port number.
3.
Set Enhanced SDK Service parameters.
1) Check Enable to add the device to the client
soware with SDK over TLS protocol.
2)
Oponal: Click TLS Sengs to enable the TLS version that the device supports. Refer to TLS
for details.
3) Enter the Port number.
4) Select a server
cercate to make sure the data transmission security. You can click Cercate
Management to add a cercate. Refer to Cercate Management for details.
4.
Click Save.
Network Camera User Manual
70
Chapter 9 System and Security
It introduces system maintenance, system sengs and security management, and explains how to
congure relevant parameters.
9.1 System Sengs
9.1.1 View Device Informaon
You can view device informaon, such as Device No., Model, Serial No. and Firmware Version.
Enter
Conguraon → System → System Sengs → Basic Informaon to view the device
informaon.
9.1.2 Time and Date
You can congure me and date of the device by conguring me zone, me synchronizaon and
Daylight Saving Time (DST).
Synchronize Time Manually
Steps
1.
Go to Conguraon → System → System Sengs → Time Sengs .
2.
Select Time Zone.
3.
Select Manual Time Sync..
4.
Choose one
me synchronizaon method.
-
Select Set Time, and manually input or select date and me from the pop-up calendar.
-
Click Sync. with computer
me to synchronize the me of the device with that of the local PC.
5.
Click Save.
Set NTP Server
You can use NTP server when accurate and reliable me source is required.
Before You Start
Set up a NTP server or obtain NTP server
informaon.
Steps
1.
Go to
Conguraon → System → System Sengs → Time Sengs .
2.
Select Time Zone.
Network Camera User Manual
71
3.
Click NTP.
4.
Set Server Address, NTP Port and Interval.
Note
Server Address is NTP server IP address.
5.
Click Test to test server
connecon.
6.
Click Save.
Synchronize Time by Satellite
Note
This funcon varies depending on dierent devices.
Steps
1.
Enter Conguraon → System → System Sengs → Time Sengs .
2.
Select Satellite Time Sync..
3.
Set Interval.
4.
Click Save.
Set DST
If the region where the device is located adopts Daylight Saving Time (DST), you can set this
funcon.
Steps
1.
Go to
Conguraon → System → System Sengs → Time Sengs .
2.
Check Enable.
3.
Select Start Time, End Time and DST Bias.
4.
Click Save.
9.1.3 Set RS-232
RS-232 can be used to debug device or access peripheral device. RS-232 can realize communicaon
between the device and computer or terminal when the communicaon distance is short.
Before You Start
Connect the device to computer or terminal with RS-232 cable.
Steps
1.
Go to Conguraon → System → System Sengs → RS-232 .
2.
Set RS-232 parameters to match the device with computer or terminal.
3.
Click Save.
Network Camera User Manual
72
9.1.4 Set RS-485
RS-485 is used to connect the device to external device. You can use RS-485 to transmit the data
between the device and the computer or terminal when the
communicaon distance is too long.
Before You Start
Connect the device and computer or terminal with RS-485 cable.
Steps
1.
Go to Conguraon → System → System Sengs → RS-485 .
2.
Set the RS-485 parameters.
Note
You should keep the parameters of the device and the computer or terminal all the same.
3.
Click Save.
9.1.5 Set Live View
Connecon
It controls the remote live view connecon amount.
Live view connecon controls the maximum live view that can be streamed at the same me.
Enter Conguraon → System → System Sengs → System Service to set the upper limit of the
remote connecon number.
9.1.6
Locaon Sengs
Locaon displays and uploads the current longitude and latude of the device.
Auto Uploading
Check Enable and set Locaon Upload Interval.
The device will upload its
locaon at the set interval. You can also click Refresh to upgrade the
device locaon manually.
Manual Sengs
Check Enable and set Locaon Upload Interval. Enter the longitude and latude of the device
and click Save.
The device will upload the set
locaon at the set interval.
Note
This funcon may vary according to dierent device models.
Network Camera User Manual
73
9.1.7 External Device
For the device supporng external devices, including the supplement light, wiper on the housing,
the LED light, and heater, you can control them via the Web browser when it is used with the
housing. External devices vary with models.
Operate Wiper
For the device that has a wiper, you can control the wiper via web browser.
Before You Start
●
Make sure your device supports wiper.
●
Wiper
operaon and sengs vary according to device models.
Steps
1.
Go to Conguraon → System → System Sengs → External Device.
2.
Select a wiper mode.
Cleaning Mode:
●
When Cleaning Mode is selected as Auto, the device determines whether to clean based on
abnormalies caused by the issues including dirty lenses, water droplets on the
window viewport, etc.
●
In Auto mode, the maximum number of cleaning
mes is 4 mes in 24 hours.
●
Threshold: Set the threshold value to judge the degree of dirness based on the complexity of
the image texture to determine whether to clean or not.
Note
●
For the device with water box, the cleaning mode is used to clean the sand and dust from the
lens window by spraying water and wiping in dry and rainless areas.
●
As for cleaning, the water box automacally sprays water for 2 seconds before the wipers start
working. The water spray from the water box lasts for 10 seconds and the wiper wipes 5
mes.
Normal
Mode: Only
For Wiping
You can set Manual Wiper Times, and the wiper wipes the set manual wiper
mes when you click on live view page.
Cleaning
Mode: Timed
Cleaning
The wiper works on schedule and the water box (if supported) sprays water
for cleaning at set wiping interval.
Check Enable Timed Cleaning and set Timed Cleaning Cycle (day(s)). If the
cycle is set to 7 days, the device will clean at 2:00 AM
aer 7 days, and then
clean once every 7 days.
Cleaning
Mode:
For the device with water box:
Network Camera User Manual
74
Manual
Cleaning
●
Click Clean, and the water box automacally sprays water for 2 seconds
before the wipers start working. The water spray from the water box lasts
for 10 seconds and the wiper wipes 5 mes.
●
You can also click
on live view page for manual cleaning or test.
For the device without water box:
●
Click Clean to test the wiper
funcon, and the wiper wipes.
Figure 9-1 Operate Wiper
3.
Click Save.
9.1.8 View Open Source
Soware License
On the top-right corner, click and select Open Source Soware Descripon to download the
license. You can view the license in the editor.
Network Camera User Manual
75
9.1.9 Wiegand
Note
This funcon is only supported by certain camera models.
Check Enable and select the protocol. The default protocol is SHA-1 26bit.
If enabled, the recognized license plate number will be output via the selected Wiegand protocol.
9.2 User and Account
9.2.1 Set User Account and Permission
The administrator can add, modify, or delete other accounts, and grant dierent permission to
dierent user levels.
Cauon
To increase security of using the device on the network, please change the password of your
account regularly. Changing the password every 3 months is recommended. If the device is used in
high-risk environment, it is recommended that the password should be changed every month or
week.
Steps
1.
Go to Conguraon → System → User Management → User Management .
2.
Click Add. Enter User Name, select Level, and enter Password. Assign remote permission to
users based on needs.
Administrator
The administrator has the authority to all
operaons and can add users and operators and
assign permission.
User
Users can be assigned permission of viewing live video, seng PTZ parameters, and changing
their own passwords, but no permission for other
operaons.
Operator
Operators can be assigned all permission except for operaons on the administrator and
creang accounts.
Modify
Select a user and click to change the password and permission.
Delete Select a user and click .
Network Camera User Manual
76
Note
The administrator can add up to 31 user accounts.
3.
Click OK.
9.2.2 Simultaneous Login
The administrator can set the maximum number of users logging into the system through web
browser simultaneously.
Go to
Conguraon → System → User Management → Online Users , click General, and set
Simultaneous Login.
9.2.3 Online Users
The informaon of users logging into the device is shown.
Go to Conguraon → System → User Management → Online Users to view the list of online
users.
9.3 Maintenance
9.3.1 Restart
You can restart the device via browser.
Go to Maintenance and Security → Maintenance → Restart , and click Restart.
9.3.2 Upgrade
Before You Start
You need to obtain the correct upgrade package.
Cauon
DO NOT disconnect power during the process, and the device restarts automacally aer upgrade.
Steps
1.
Go to Maintenance and Security → Maintenance → Upgrade .
2.
Choose one method to upgrade.
Firmware
Locate the exact path of the upgrade le.
Firmware Directory Locate the directory which the upgrade le belongs to.
3.
Click to select the upgrade le.
Network Camera User Manual
77
4.
Click Upgrade.
9.3.3 Restore and Default
Restore and Default helps restore the device parameters to the default sengs.
Steps
1.
Go to Maintenance and Security → Maintenance → Backup and Restore .
2.
Click Restore or Default according to your needs.
Restore Reset device parameters, except user informaon, IP parameters and video format
to the default sengs.
Default Reset all the parameters to the factory default.
Note
Be careful when using this funcon. Aer reseng to the factory default, all the
parameters are reset to the default sengs.
9.3.4 Import and Export Conguraon File
It helps speed up batch conguraon on other devices with the same parameters.
Steps
1.
Export conguraon le.
1) Go to Maintenance and Security → Maintenance → Backup and Restore → Backup .
2) Click Export and input the
encrypon password to export the current conguraon le.
3) Set the saving path to save the conguraon le in local computer.
2.
Import conguraon le.
1) Access the device that needs to be congured via web browser.
2) Go to Maintenance and Security → Maintenance → Backup and Restore → Reset .
3) Click
to select the saved conguraon le.
4) Input the encrypon password you have set when exporng the conguraon le.
5) Click Import.
9.3.5 Search and Manage Log
Log helps locate and troubleshoot problems.
Steps
1.
Go to Maintenance and Security → Maintenance → Log .
2.
Set search
condions Major Type, Minor Type, Start Time, and End Time.
3.
Click Search.
The matched log
les will be displayed on the log list.
Network Camera User Manual
78
4.
Oponal: Click Export to save the log les in your computer.
9.3.6 Search Security Audit Logs
You can search and analyze the security log les of the device so as to nd out the illegal intrusion
and troubleshoot the security events.
Steps
Note
This funcon is only supported by certain camera models.
1.
Go to Maintenance and Security → Maintenance → Security Audit Log .
2.
Select log types, Start Time, and End Time.
3.
Click Search.
The log
les that match the search condions will be displayed on the Log List.
4.
Oponal: Click Export to save the log les to your computer.
9.3.7 SSH
Secure Shell (SSH) is a cryptographic network protocol for operang network services over an
unsecured network.
Go to Maintenance and Security → Maintenance → Device Debugging , and click
Sengs of SSH.
You can edit the number of the port. Click Save.
Cauon
Use the funcon with cauon. The security risk of device internal informaon leakage exists when
the funcon is enabled.
9.3.8 Export Diagnose Informaon
Diagnose informaon includes running log, system informaon, hardware informaon.
Go to Maintenance and Security → Maintenance → Device Debugging → Diagnose Informaon .
Click Export. In the pop-up window, check desired diagnose informaon and click Export to export
corresponding diagnose informaon of the device.
9.4 Security
You can improve system security by seng security parameters.
Network Camera User Manual
79
9.4.1 Set IP Address Filter
IP address lter is a tool for access control. You can enable the IP address lter to allow or forbid
the visits from the certain IP addresses.
IP address refers to IPv4.
Steps
1.
Go to Maintenance and Security → Security → IP Address Filter .
2.
Check Enable.
3.
Select the type of IP address
lter.
Blocklist IP addresses in the list cannot access the device.
Allowlist Only IP addresses in the list can access the device.
4.
Edit the IP address lter list.
Add Add a new IP address or IP address range to the list.
Modify the selected IP address or IP address range in the list.
Delete the selected IP address or IP address range in the list.
5.
Click Save.
9.4.2 Set MAC Address Filter
MAC address lter is a tool for access control. You can enable the MAC address lter to allow or
forbid the visits from the certain MAC addresses.
Steps
1.
Go to Maintenance and Security → Security → MAC Address Filter .
2.
Check Enable.
3.
Select the type of MAC address
lter.
Blocklist
MAC addresses in the list cannot access the device.
Allowlist Only MAC addresses in the list can access the device.
4.
Edit the MAC address lter list.
Add
Add a new MAC address to the list.
Modify the selected MAC address in the list.
Delete the selected MAC address in the list.
5.
Click Save.
Network Camera User Manual
80
9.4.3 Control Timeout Sengs
If this funcon is enabled, you will be logged out when you make no operaon (not including
viewing live image) to the device via web browser within the set
meout period.
Go to Maintenance and Security → Security → Login Management → Control Timeout Sengs to
complete sengs.
9.4.4 Cercate Management
It helps to manage the server/client cercates and CA cercate, and to send an alarm if the
cercates are close to expiry date, or are expired/abnormal.
Note
The funcon is only supported by certain device models.
Server Cercate/Client Cercate
Note
The device has default self-signed server/client cercate installed. The cercate ID is default.
Create and Install Self-signed Cercate
Steps
1.
Go to Maintenance and Security → Security → Cercate Management .
2.
Click Create Self-signed Cercate.
3.
Input
cercate informaon.
Note
The input cercate ID cannot be the same as the exisng ones.
4.
Click Save to save and install the cercate.
The created cercate is displayed in the Server/Client Cercate list.
If the
cercate is used by certain funcons, the funcon name is shown in the column
Funcons.
5.
Oponal: Click Property to see the cercate details.
Network Camera User Manual
81
Install Self-signed Request Cercate
You can send the self-signed cercate to a trusted third-party for the signature, and install the
cercate to the device.
Before You Start
Create a self-signed cercate rst. See Create and Install Self-signed Cercate for instrucons.
Steps
1.
Go to Maintenance and Security → Security → Cercate Management .
2.
Select a self-signed cercate from the Server/Client Cercate list.
3.
Click Create Cercate Request.
4.
Input request
informaon.
5.
Click Save.
The
cercate request details are displayed in a pop-up window.
6.
Copy the request content and save it as a request le.
7.
Send the le to a trusted-third party for signature.
8.
Aer receiving the cercated sent back from the third-party, install it to the device.
1) Click Import.
2) Input
Cercate ID.
Note
The input cercate ID cannot be the same as the existed ones.
3) Click to select the cercate le.
4) Select Self-signed Request Cercate.
5) Click Save.
The imported
cercate is displayed in the Server/Client Cercate list.
If the
cercate is used by certain funcon, the funcon name is shown in the column
Funcons.
9.
Oponal: Click Property see the cercate details.
Install Other Authorized
Cercate
If you already has an authorized cercate (not created by the device), you can import it to the
device directly.
Steps
1.
Go to Maintenance and Security → Security →
Cercate Management .
2.
Click Import in the Server/Client Cercate list.
3.
Input
Cercate ID.
Network Camera User Manual
82
Note
The input cercate ID cannot be the same as the existed ones.
4.
Click to select the cercate le.
5.
Select Cercate and Key and select a Key Type according to your cercate.
Independent Key If your cercate has an independent key, select this opon.
Browse to select the private key and input the private-key password.
PKCS#12 If your cercate has the key in the same cercate le, select this opon
and input the password.
6.
Click Save.
The imported
cercate is displayed in the Server/Client Cercate list.
If the cercate is used by certain funcon, the funcon name is shown in the column
Funcons.
Install CA
Cercate
Before You Start
Prepare a CA cercate in advance.
Steps
1.
Go to Maintenance and Security → Security → Cercate Management .
2.
Click Import in the CA
Cercate list.
3.
Input Cercate ID.
Note
The input cercate ID cannot be the same as the exisng ones.
4.
Click to select the cercate le.
5.
Click Save.
The imported cercate is displayed in the CA Cercate list.
If the
cercate is used by certain funcons, the funcon name is shown in the Funcons
column.
Enable
Cercate Expiraon Alarm
Steps
1.
Check Enable Cercate Expiraon Alarm. If enabled, you will receive an email or the camera
links to the surveillance center that the
cercate will expire soon, or is expired or abnormal.
2.
Set the Remind Me Before Expiraon (day), Alarm Frequency (day) and Detecon Time (hour).
Network Camera User Manual
83
Note
●
If you set the reminding day before expiraon to 1, then the camera will remind you the day
before the expiraon day. 1 to 30 days are available. Seven days is the default reminding days.
●
If you set the reminding day before expiraon to 1, and the detecon me to 10:00, and the
cercate will expire in 9:00 the next day, the camera will remind you in 10:00 the rst day.
3.
Click Save.
9.4.5 TLS
The Transport Layer Security (TLS) protocol aims primarily to provide privacy and data integrity
between two or more communicang computer applicaons. TLS sengs are eecve for HTTP(S)
and enhanced SDK service.
Go to Maintenance and Security → Security → TLS , and enable the desired TLS protocol. Click
Save.
Cauon
Use the funcon with cauon. The security risk of device internal informaon leakage exists when
the funcon is enabled.
Network Camera User Manual
84
Chapter 10 Device Management
10.1 Add Alarm Box
You can add an alarm box to the device through the network protocol and view the alarm input/
output interface of the alarm box.
Steps
1.
Click Add Device to add the alarm box as needed.
2.
Set the parameters of the device, such as the IP address and the
descripon of the alarm box.
3.
Click Save.
Note
The funcon is only supported by certain device models.
Network Camera User Manual
85
Chapter 11 VCA Resource
VCA resource is a collecon of smart funcons supported by the device.
11.1 Allocate VCA Resource
VCA resource oers you opons to enable certain VCA funcons according to actual needs. It helps
allocate more resources to the desired
funcons.
Steps
1.
Click VCA on the
le tab.
2.
Enable the desired VCA funcon.
3.
Click Next to nish sengs.
Note
Certain VCA funcons are mutually exclusive.
11.2 General Sengs
Set the general parameters which are related to the smart applicaons.
Go to VCA → Set Applicaon → General Sengs to set the following parameters.
Camera Info.
For camera informaon sengs, refer to Set Camera Info .
FTP
For FTP sengs, refer to Set FTP .
Email
For Email sengs, refer to Set Email .
Alarm Output
For alarm output sengs, refer to Automac Alarm .
Audible Alarm Output
For audible alarm output sengs, refer to Set Audible Alarm Output .
Alarm Server
For alarm server sengs, refer to Alarm Server .
Network Camera User Manual
86
Metadata
For metadata sengs, refer to Metadata .
11.2.1 Set Camera Info
Customize specic informaon for the device. It may help idenfy a certain device when mulple
devices are under management.
Go to VCA → Set
Applicaon → General Sengs → Camera Info to set Device No. and Camera
Info.
11.2.2 Metadata
Metadata is the raw data that the device collects before algorithm processing. It is oen used for
the third party
integraon.
Go to VCA → Set Applicaon → General Sengs → metadata Sengs to enable metadata
uploading of the desired funcon.
Note
This funcon varies according to dierent camera models.
Smart Event
The metadata of the smart event includes the target ID, target coordinate, me, etc.
You can check Enable Stream Rule to overlay the stream rule on the live view image. Make sure
you have checked Sub-Stream and selected the sub-stream in the live view.
You can check Overlay Rule Frame and Target Frame on Background Picture to overlay the rule
and target
informaon on the sub-stream. Make sure you have checked Sub-Stream and
selected the sub-stream in the live view.
Face Capture
The metadata of face capture includes the rule
informaon, target ID, target coordinate, me
informaon, etc. The camera detects the whole image by default. If the area is congured in the
face capture
sengs, the camera detects the congured area.
Mul-Target-Type Detecon
The metadata of mul-target-type detecon includes the vehicle informaon and face capture
informaon, such as the target ID, target coordinate, me informaon, vehicle moving
direcon, etc.
Road Trac
The metadata of road trac is detected vehicle informaon, including the vehicle locaon in
the scene, vehicle ID, license plate, validity, moving direcon, country/region, etc.
Network Camera User Manual
87
11.2.3 Dynamic Mosaic Mask
The funcon masks the detecon target picture in the detecon area. It is eecve for preview,
playback and recording.
Go to VCA → Set
Applicaon → General Sengs → Dynamic Mosaic Mask to set the following
parameters.
Note
●
The funcon is supported only when certain VCA funcon is enabled.
●
The funcon varies according to dierent models.
Face Mosaic Mask
When Face Mosaic Mask is enabled, the face image in the detecon area will be mosaicked.
Human Body Mosaic Mask
When Human Body Mosaic Mask is enabled, the whole body image in the detecon area will
be mosaicked.
License Plate Mosaic Mask
When License Plate Mosaic Mask is enabled, the license plate image in the detecon area will
be mosaicked.
Mosaic Level
The higher the level, the less clear the target is.
Figure 11-1 Set Dynamic Mosaic Mask
11.2.4 AcuSearch
The device transmits the POS
informaon of the target to network video recorder aer detecng
the target. It is to achieve accurate and quick search on the connected network video recorder.
Network Camera User Manual
88
Before You Start
●
Make sure the connected network video recorder (NVR) supporng AcuSearch to do with the
funcon.
●
Aer the funcon is enabled, the ongoing smart applicaon will be disabled while Smart Event
or
Mul-Target-Type Detecon will be enabled.
●
The funcon is only supported by certain models. The actual display varies with the models.
Steps
1.
Enable the funcon for the device.
2.
Set the
funcon on the connected network video recorder.
1) Enable AcuSearch funcon for the selected channel (refer to the congured camera device)
on the network video recorder.
2) Click the AcuSearch
buon on the playback page of the network video recorder.
3) Click a target on a network video recorder to search for pictures that contain the target.
4) Click a picture to play a video before and
aer that moment.
Note
Refer to the User Manual of NVR for the actual sengs on NVR.
11.3 Smart Event
Note
●
For certain device models, you need to enable the smart event funcon on VCA page rst to
show the funcon conguraon page.
●
The funcon varies according to dierent models.
11.3.1 Set Intrusion Detecon
It is used to detect objects entering and loitering in a predened virtual region. If it occurs, the
device can take linkage
acons.
Before You Start
●
Go to VCA and select the
applicaon. Select Smart Event and click Next to enable the funcon.
●
For the device supporng HEOP, go to VCA to import and enable Smart Event.
Steps
1.
Go to VCA → Set Applicaon → Smart Event → Intrusion Detecon .
2.
Check Enable.
3.
Click Add to add a rule and set a
detecon area.
1) Draw a
detecon area. Click , click on the live view to specify the vertexes and draw the
boundaries of the detecon area, and right click to complete drawing.
Network Camera User Manual
89
2) Set the minimum size and the maximum size for the target to improve detecon accuracy.
Only targets whose size are between the maximum size and the minimum size trigger the
detecon. Click and , then drag the mouse in the live view to draw the minimum and
maximum target size.
3) Oponal: Click to delete all the seng areas.
4.
Set parameters.
Detecon Target
This funcon allows alarm triggering by specied selected target types. If the detecon target
is not selected, all the detected targets will be reported.
Note
This funcon is only available for certain device models under certain sengs. Please refer to
the actual sengs.
Threshold
Threshold stands for the threshold for the me of the object loitering in the region. If the
me that one object stays exceeds the threshold, the alarm is triggered. The larger the value
of the threshold is, the longer the alarm triggering
me is.
Sensivity
Sensivity
stands for the percentage of the body part of an acceptable target that enters the
predened region. Sensivity = 100 - S1/ST × 100. S1 stands for the target body part that goes
across the predened region. ST stands for the complete target body. The higher the value of
sensivity is, the more easily the alarm can be triggered.
Target Validity
If you set a higher validity, the required target features should be more obvious, and the
alarm accuracy would be higher. The target with less obvious features would be missed.
Figure 11-2 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
Network Camera User Manual
90
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
7.
Oponal: Set Custom Alarm.
This
funcon is used to send the custom alarm messages to alarm servers. Click and set the
Custom Alarm Content to customize alarm messages in HTTP text format, up to 512 characters
in length. Alarm messages can be sent to up to 3 servers.
Note
The funcon is only supported by certain camera models.
8.
Click Save.
11.3.2 Set Line Crossing
Detecon
It is used to detect objects crossing a predened virtual line. If it occurs, the device can take linkage
acons.
Before You Start
●
Go to VCA and select the applicaon. Select Smart Event and click Next to enable the funcon.
●
For the device
supporng HEOP, go to VCA to import and enable Smart Event.
Steps
1.
Go to VCA → Set Applicaon → Smart Event → Line Crossing Detecon .
2.
Check Enable.
3.
Click Add to add a rule and set a
detecon area.
1) Draw a detecon line. Click and a line with an arrow appears in the live view. Drag the line
to the
locaon on the live view as desired.
2) Set the minimum size and the maximum size for the target to improve detecon accuracy.
Only targets whose size are between the maximum size and the minimum size trigger the
detecon. Click and , then drag the mouse in the live view to draw the minimum and
maximum target size.
3)
Oponal: Click to delete all the seng areas.
4.
Set parameters.
Detecon Target
This funcon allows alarm triggering by specied selected target types. If the detecon target
is not selected, all the detected targets will be reported.
Note
This funcon is only available for certain device models under certain sengs. Please refer to
the actual sengs.
Direcon
It stands for the direcon from which the object goes across the line.
Network Camera User Manual
91
A<->B: The object going across the line from both direcons can be detected and alarms are
triggered.
A->B: Only the object crossing the congured line from the A side to the B side can be
detected.
B->A: Only the object crossing the congured line from the B side to the A side can be
detected.
Sensivity
It stands for the percentage of the body part of an acceptable target that goes across the pre-
dened
line. Sensivity = 100 - S1/ST × 100. S1 stands for the target body part that goes
across the pre-dened line. ST stands for the complete target body. The higher the value of
sensivity is, the more easily the alarm can be triggered.
Target Validity
If you set a higher validity, the required target features should be more obvious, and the
alarm accuracy would be higher. The target with less obvious features would be missing.
Figure 11-3 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule
sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
7.
Oponal: Set Custom Alarm.
This
funcon is used to send the custom alarm messages to alarm servers. Click and set the
Custom Alarm Content to customize alarm messages in HTTP text format, up to 512 characters
in length. Alarm messages can be sent to up to 3 servers.
Note
The funcon is only supported by certain camera models.
8.
Click Save.
Network Camera User Manual
92
11.3.3 Set Region Entrance Detecon
It is used to detect objects entering a predened virtual region from the outside place. If it occurs,
the device can take linkage
acons.
Before You Start
●
Go to VCA and select the
applicaon. Select Smart Event and click Next to enable the funcon.
●
For the device
supporng HEOP, go to VCA to import and enable Smart Event.
Steps
1.
Go to VCA → Set
Applicaon → Smart Event → Region Entrance Detecon .
2.
Check Enable.
3.
Click Add to add a rule and set a
detecon area.
1) Draw a detecon area. Click , click on the live view to specify the vertexes and draw the
boundaries of the
detecon area, and right click to complete drawing.
2) Set the minimum size and the maximum size for the target to improve detecon accuracy.
Only targets whose size are between the maximum size and the minimum size trigger the
detecon. Click and , then drag the mouse in the live view to draw the minimum and
maximum target size.
3)
Oponal: Click to delete all the seng areas.
4.
Set parameters.
Detecon Target
This funcon allows alarm triggering by specied selected target types. If the detecon target
is not selected, all the detected targets will be reported.
Note
This funcon is only available for certain device models under certain sengs. Please refer to
the actual sengs.
Sensivity
It stands for the percentage of the body part of an acceptable target that goes across the
predened region. Sensivity = 100 - S1/ST × 100. S1 stands for the target body part that goes
across the
predened region. ST stands for the complete target body. The higher the value of
sensivity is, the more easily the alarm can be triggered.
Target Validity
If you set a higher validity, the required target features should be more obvious, and the
alarm accuracy would be higher. The target with less obvious features would be missing.
Network Camera User Manual
93
Figure 11-4 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
7.
Oponal: Set Custom Alarm.
This funcon is used to send the custom alarm messages to alarm servers. Click and set the
Custom Alarm Content to customize alarm messages in HTTP text format, up to 512 characters
in length. Alarm messages can be sent to up to 3 servers.
Note
The funcon is only supported by certain camera models.
8.
Click Save.
11.3.4 Set Region
Exing Detecon
It is used to detect objects exing from a predened virtual region. If it occurs, the device can take
linkage acons.
Before You Start
●
Go to VCA and select the applicaon. Select Smart Event and click Next to enable the funcon.
●
For the device supporng HEOP, go to VCA to import and enable Smart Event.
Steps
1.
Go to VCA → Set Applicaon → Smart Event → Region Exing Detecon .
2.
Check Enable.
Network Camera User Manual
94
3.
Click Add to add a rule and set a detecon area.
1) Draw a detecon area. Click , click on the live view to specify the vertexes and draw the
boundaries of the detecon area, and right click to complete drawing.
2) Set the minimum size and the maximum size for the target to improve
detecon accuracy.
Only targets whose size are between the maximum size and the minimum size trigger the
detecon. Click and , then drag the mouse in the live view to draw the minimum and
maximum target size.
3) Oponal: Click to delete all the seng areas.
4.
Set parameters.
Detecon Target
This funcon allows alarm triggering by specied selected target types. If the detecon target
is not selected, all the detected targets will be reported.
Note
This funcon is only available for certain device models under certain sengs. Please refer to
the actual sengs.
Sensivity
It stands for the percentage of the body part of an acceptable target that goes across the
predened region. Sensivity = 100 - S1/ST × 100. S1 stands for the target body part that goes
across the
predened region. ST stands for the complete target body. The higher the value of
sensivity is, the more easily the alarm can be triggered.
Target Validity
If you set a higher validity, the required target features should be more obvious, and the
alarm accuracy would be higher. The target with less obvious features would be missing.
Network Camera User Manual
95
Figure 11-5 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
7.
Oponal: Set Custom Alarm.
This funcon is used to send the custom alarm messages to alarm servers. Click and set the
Custom Alarm Content to customize alarm messages in HTTP text format, up to 512 characters
in length. Alarm messages can be sent to up to 3 servers.
Note
The funcon is only supported by certain camera models.
8.
Click Save.
11.3.5 Set
Unaended Baggage Detecon
It is used to detect the objects le over in the predened region. Linkage methods can be triggered
aer the object is le and stays in the region for a set me period.
Before You Start
●
Go to VCA and select the applicaon. Select Smart Event and click Next to enable the funcon.
●
For the device supporng HEOP, go to VCA to import and enable Smart Event.
Steps
1.
Go to VCA → Set Applicaon → Smart Event → Unaended Baggage Detecon .
2.
Check Enable.
Network Camera User Manual
96
3.
Click Add to add a rule and set a detecon area.
1) Draw a detecon area. Click , click on the live view to specify the vertexes and draw the
boundaries of the detecon area, and right click to complete drawing.
2) Set the minimum size and the maximum size for the target to improve
detecon accuracy.
Only targets whose size are between the maximum size and the minimum size trigger the
detecon. Click and , then drag the mouse in the live view to draw the minimum and
maximum target size.
3) Oponal: Click to delete all the seng areas.
4.
Set parameters.
Sensivity
Sensivity stands for the percentage of the body part of an acceptable target that enters the
predened region. Sensivity = 100 - S1/ST × 100. S1 stands for the target body part that goes
across the predened region. ST stands for the complete target body. The higher the value of
sensivity is, the more easily the alarm can be triggered.
Threshold
It stands for the me of the objects le in the region. Alarm is triggered aer the object is le
and stays in the region for the set me period.
Figure 11-6 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
7.
Click Save.
Network Camera User Manual
97
Note
The funcon is only supported by certain models. The actual display varies with the models.
11.3.6 Set Object Removal Detecon
It detects whether the objects are removed from the predened detecon region, such as the
exhibits on display. If it occurs, the device can take linkage acons and the sta can take measures
to reduce property loss.
Before You Start
●
Go to VCA and select the applicaon. Select Smart Event and click Next to enable the funcon.
●
For the device supporng HEOP, go to VCA to import and enable Smart Event.
Steps
1.
Go to VCA → Set Applicaon → Smart Event → Object Removal Detecon .
2.
Check Enable.
3.
Click Add to add a rule and set a
detecon area.
1) Draw a detecon area. Click , click on the live view to specify the vertexes and draw the
boundaries of the detecon area, and right click to complete drawing.
2) Set the minimum size and the maximum size for the target to improve
detecon accuracy.
Only targets whose size are between the maximum size and the minimum size trigger the
detecon. Click and , then drag the mouse in the live view to draw the minimum and
maximum target size.
3) Oponal: Click to delete all the seng areas.
4.
Set parameters.
Sensivity
Sensivity stands for the percentage of the body part of an acceptable target that enters the
predened region. Sensivity = 100 - S1/ST × 100. S1 stands for the target body part that goes
across the predened region. ST stands for the complete target body. The higher the value of
sensivity is, the more easily the alarm can be triggered.
Threshold
The threshold for the me of the objects removed from the region. If you set the value as 10,
alarm is triggered aer the object disappears from the region for 10s.
Network Camera User Manual
98
Figure 11-7 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, see Set Arming Schedule . For the linkage method sengs, see
Linkage Method Sengs .
7.
Click Save.
Note
The funcon is only supported by certain models. The actual display varies with the models.
11.3.7 Set Loitering Detecon
It detects whether there is any target loitering in a predened area. If the me that the target
loiters in the set region reaches the set threshold, the device can take linkage
acons.
Before You Start
●
Go to VCA and select the
applicaon. Select Smart Event and click Next to enable the funcon.
●
For the device supporng HEOP, go to VCA to import and enable Smart Event.
Steps
1.
Go to VCA → Set Applicaon → Smart Event → Loitering Detecon .
2.
Check Enable.
3.
Click Add to add a rule and set a
detecon area.
1) Draw a
detecon area. Click , click on the live view to specify the vertexes and draw the
boundaries of the detecon area, and right click to complete drawing.
Network Camera User Manual
99
2) Set the minimum size and the maximum size for the target to improve detecon accuracy.
Only targets whose size are between the maximum size and the minimum size trigger the
detecon. Click and , then drag the mouse in the live view to draw the minimum and
maximum target size.
3) Oponal: Click to delete all the seng areas.
4.
Set rules.
Threshold
Threshold stands for the threshold for the
me of the object loitering in the region. If the
me that one object stays exceeds the threshold, the alarm is triggered. The larger the value
of the threshold is, the longer the alarm triggering me is.
Sensivity
Sensivity stands for the percentage of the body part of an acceptable target that enters the
predened region. Sensivity = 100 - S1/ST × 100. S1 stands for the target body part that goes
across the predened region. ST stands for the complete target body. The higher the value of
sensivity is, the more easily the alarm can be triggered.
Figure 11-8 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
7.
Click Save.
Note
The funcon is only supported by certain models. The actual display varies with the models.
Network Camera User Manual
100
11.3.8 Set People Gathering Detecon
It detects the people density in a predened area. If the people density exceeds the set
percentage, the device can take linkage
acons.
Before You Start
●
Go to VCA and select the
applicaon. Select Smart Event and click Next to enable the funcon.
●
For the device
supporng HEOP, go to VCA to import and enable Smart Event.
Steps
1.
Go to VCA → Set
Applicaon → Smart Event → People Gathering Detecon .
2.
Check Enable.
3.
Click Add to add a rule and set a
detecon area.
1) Draw a detecon area. Click , click on the live view to specify the vertexes and draw the
boundaries of the
detecon area, and right click to complete drawing.
2) Oponal: Click to delete all the seng areas.
4.
Set rules.
Percentage
It stands for the percentage of people in the
predened area. When the people percentage in
the live view exceeds the set value, the device will trigger an alarm.
Figure 11-9 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs
7.
Click Save.
Network Camera User Manual
101
Note
The funcon is only supported by certain models. The actual display varies with the models.
11.3.9 Set Fast Moving Detecon
When there are targets moving at a high speed in a predened area, the device will take linkage
acons and trigger an alarm.
Before You Start
●
Go to VCA and select the applicaon. Select Smart Event and click Next to enable the funcon.
●
For the device
supporng HEOP, go to VCA to import and enable Smart Event.
Steps
1.
Go to VCA → Set
Applicaon → Smart Event → Fast Moving Detecon .
2.
Check Enable.
3.
Click Add to add a rule and set a detecon area.
1) Draw a
detecon area. Click , click on the live view to specify the vertexes and draw the
boundaries of the detecon area, and right click to complete drawing.
2) Set the minimum size and the maximum size for the target to improve detecon accuracy.
Only targets whose size are between the maximum size and the minimum size trigger the
detecon. Click and , then drag the mouse in the live view to draw the minimum and
maximum target size.
3)
Oponal: Click to delete all the seng areas.
4.
Set Rules.
Sensivity
Sensivity stands for the percentage of the body part of an acceptable target that enters the
pre-dened region. Sensivity = 100 - S1/ST × 100. S1 stands for the target body part that
goes across the
pre-dened region. ST stands for the complete target body. The higher the
value of sensivity is, the more easily the alarm can be triggered.
Network Camera User Manual
102
Figure 11-10 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
7.
Click Save.
Note
The funcon is only supported by certain models. The actual display varies with the models.
11.3.10 Set Parking Detecon
It detects parking violaon in a predened area. When the parking me exceeds a set threshold,
the device can take linkage
acons. It is applicable in expressway and one-way street.
Before You Start
●
Go to VCA and select the applicaon. Select Smart Event and click Next to enable the funcon.
●
For the device supporng HEOP, go to VCA to import and enable Smart Event.
Steps
1.
Go to VCA → Set Applicaon → Smart Event → Parking Detecon .
2.
Check Enable.
3.
Click Add to add a rule and set a
detecon area.
1) Draw a
detecon area. Click , click on the live view to specify the vertexes and draw the
boundaries of the detecon area, and right click to complete drawing.
Network Camera User Manual
103
2) Set the minimum size and the maximum size for the target to improve detecon accuracy.
Only targets whose size are between the maximum size and the minimum size trigger the
detecon. Click and , then drag the mouse in the live view to draw the minimum and
maximum target size.
3) Oponal: Click to delete all the seng areas.
4.
Set rules.
Threshold
Threshold stands for the threshold for the parking
me in the region. If the parking me
exceeds the threshold, an alarm is triggered. The larger the value of the threshold is, the
longer the alarm triggering me is.
Sensivity
Sensivity stands for the percentage of the part of an acceptable target that enters the pre-
dened
region. Sensivity = 100 - S1/ST × 100. S1 stands for the target part that goes across
the pre-dened region. ST stands for the complete target. The higher the value of sensivity
is, the more easily the alarm can be triggered.
Figure 11-11 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs
7.
Click Save.
Note
The funcon is only supported by certain models. The actual display varies with the models.
Network Camera User Manual
104
11.3.11 Set Combined Event
This funcon is used to combine the perimeter protecon events, including Intrusion Detecon,
Line Crossing Detecon, Region Entrance Detecon and Region Exing Detecon, and trigger the
alarm aer all the sub event alarm rules are triggered in sequence.
Before You Start
Enable at least one of the smart events rst before enabling the combined event. Individual event
alarms cannot be triggered when the combined event is enabled.
Note
The funcon is only supported by certain camera models.
Figure 11-12 Set Combined Event
Steps
1.
Go to VCA → Set Applicaon → Smart Event → Combined Event .
2.
Check Enable.
Network Camera User Manual
105
Figure 11-13 Set Rules
3.
Click Add behind Rule List to add a new rule of the combined event.
1) Click Add behind Sub Event List to add a sub event for the sub event list.
2) Select the event type.
Enable any of the perimeter
protecon events (including Intrusion Detecon, Line Crossing
Detecon, Region Entrance Detecon and Region Exing Detecon) rst so that the event
can be selected in the sub event list.
Example
●
If Intrusion
Detecon and Line Crossing Detecon are enabled and others are not, then
Intrusion Detecon and Line Crossing Detecon can be selected.
●
If Intrusion Detecon and Object Removal Detecon are enabled and others are not, then
only Intrusion
Detecon can be selected.
3) Select the rule of the sub event according to the selected event type. You can draw the
detecon area or line.
Note
The detecon rule of the current sub event is shared by all combined events. Please edit it
carefully.
4) Set the Alarm Interval. It refers to the maximum interval between alarms triggered by
dierent sub events in the same combined event.
5) Click Save.
Network Camera User Manual
106
4.
Repeat the above steps to set other rules. Up to 4 rules can be set. The detecon area should be
a convex polygon area.
5.
The arming schedule and linkage method of the combined event refers to the arming schedule
and linkage method of the alarm event.
6.
Click Save.
11.4 Face Capture
The device can capture the face that meets the rules in the congured rule area, and the captured
picture will be uploaded.
Note
●
For certain device models, you need to enable this funcon on VCA page rst.
●
The funcon is only supported by certain device models.
11.4.1 Set Face Capture
The face that appears in the congured area can be captured.
Before You Start
●
Go to VCA and select the applicaon. Select Face Capture and click Next to enable the funcon.
●
For the device supporng HEOP, go to VCA to import and enable Face Capture.
Steps
1.
Go to VCA → Set Applicaon → Face Capture → Rule .
2.
Check Enable to enable the rule sengs.
3.
Click to draw the detecon area you want the face capture to take eect. Draw area by le-
clicking end-points in the live view window, and right-clicking to nish the area drawing. It is
recommended that the drawn area occupies 1/2 to 2/3 of the live view image.
4.
Draw pupil distance.
Min. Pupil Distance
Click
to draw the minimum pupil distance. If the pupil distance of the face in the video
image is smaller than the minimum pupil distance, the face will not be detected.
Max. Pupil Distance
Click to draw the maximum pupil distance. If the pupil distance of the face in the video
image is larger than the maximum pupil distance, the face will not be detected.
You can also input the value of distance in the text
eld.
5.
Oponal: For shield region sengs, refer to Set Shield Region .
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
7.
Click Save.
Network Camera User Manual
107
8.
For overlay and capture sengs, refer to Overlay and Capture . For advanced parameters
sengs, refer to Face Capture Algorithms Parameters .
Result
You can view and download captured pictures in Playback → Picture . Refer to View and
Download Picture for details.
11.4.2 Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Note
The funcon varies according to dierent device models.
Overlay
Display VCA Info. on Stream
Display smart informaon on stream, including the target and rules informaon.
Display Target Info. on Alarm Picture
Overlay the alarm picture with target informaon.
Background Picture
Sengs
Background Picture Sengs
Comparing to target picture, background picture is the scene image which oers extra
environmental
informaon. You can set the background picture quality and resoluon.
Background Upload
If the background image need to be uploaded to surveillance center, check Background
Upload.
Face Picture
For some devices, you can also check Face Picture as needed. The device will upload the
captured face picture.
Compress Background Picture
The device uploads a compressed captured background picture. The higher the compression
level, the smaller the picture
le size.
Target Picture
Sengs
Target Picture Sengs
Custom, Head Shot, Half-Body Shot and Full-Body Shot are selectable.
Network Camera User Manual
108
Note
If you select Custom, you can customize Width, Head Height and Body Height as required.
You can check Fixed Value to set the picture height.
Face Beaucaon
Check Face Beaucaon and adjust the beaucaon level as needed.
Note
Face Beaucaon slightly adjusts the captured face pictures and reduces noise of captured
face picture.
Face Enhancement
Check Face Enhancement and the device is able to capture beer and clearer face pictures
when it is dark.
Text Overlay
Text Overlay
You can check desired items and adjust their order to display on captured pictures.
See Set Camera Info to set Device No. and Camera Info.
11.4.3 Face Capture Algorithms Parameters
It is used to set and opmize the parameters of the algorithm library for face capture funcon.
Version
It stands for the current algorithm version.
Capture Parameters
Best Shot
The best shot aer target leaves the detecon area.
Capture Threshold
It stands for the quality of face to trigger capture and alarm. Higher value means
beer
quality should be met to trigger capture and alarm.
Capture Times
It refers to the capture mes a face will be captured during its stay in the congured area.
The default value is 1.
Quick Shot
Network Camera User Manual
109
When the face picture grading value is higher than the quick shot threshold, the face picture
will be captured and uploaded. Otherwise, the picture with the highest grading value that
reaches the max. capture interval will be selected for upload.
Quick Shot Threshold
It stands for the quality of face to trigger quick shot.
Max. Capture Interval
It refers to the max. me occupaon for one quick shot.
Capture Times
It refers to the capture
mes a face will be captured during its stay in the congured area.
Remove Duplicated Faces
This funcon can help lter out repeated captures of certain face.
Similarity Threshold for Duplicates Removing
It is the similarity between the newly captured face and the picture in the duplicates removing
library. When the similarity value is higher than the value you set, the captured picture is
regarded as a duplicated face and will be dropped.
Duplicates Removing Library Grading Threshold
It is the face grading threshold that triggers duplicates checking. When the face grading is
higher than the set value, the captured face is compared with the face pictures that are
already in the duplicates removing library.
Duplicates Removing Library Update Time
The
me from when each face picture is added to the duplicates removing library unl when it
is deleted.
Face Exposure
Check the checkbox to enable the face exposure.
Reference Brightness
The reference brightness of a face in the face exposure mode. If a face is detected, the
camera adjusts the face brightness according to the value you set. The higher the value, the
brighter the face is.
Min.
Duraon
The minimum duraon of the camera exposures the face.
Note
If the face exposure is enabled, please make sure the WDR funcon is disabled, and the
manual iris is selected.
Face Filtering Time
Network Camera User Manual
110
It means the me interval between the camera detecng a face and taking a capture. If the
detected face stays in the scene for a me shorter than the set ltering me, capture will not
be triggered. For example, if the face ltering me is set as 5 seconds, the camera will
capture the detected face when the face keeps staying in the scene for 5 seconds.
Note
The face ltering me (longer than 0 s) may increase the possibility of the actual capture
mes less than the set value above.
Facial Posture Filter
Facial posture lter can lter out face of certain postures. The gure on the right of the slider
stands for the posture angle which is acceptable in the face capture
acon. Click to display
the diagram illustrang the face turning direcon when seng up this lter.
Upload Feature
Feature stands for the feature informaon the algorithm can tell from face pictures. Check the
funcon to upload the informaon.
Restore Parameters
Restore Defaults
Click Restore to restore all the
sengs in advanced conguraon to the factory default.
11.4.4 Set Shield Region
The shield region allows you to set the specic region in which the set smart funcon rule is
invalid.
Steps
1.
Select Shield Region.
2.
Click
to draw shield region. Repeat this step above to set more shield regions.
3.
Oponal: Select and click on the drawn region, then click to delete the selected drawn
region.
4.
Oponal: Click to delete all drawn regions.
5.
Click Save.
11.5
Mul-Target-Type Detecon
Mul-Target-Type Detecon is to detect, capture and upload data of targets in mulple types, such
as human face, human body, and vehicle.
Network Camera User Manual
111
Note
●
For certain device models, you need to enable Mul-Target-Type Detecon on VCA page rst.
●
The funcon is only supported by certain device models.
11.5.1 Set Mul-Target-Type Detecon Rule
Aer seng the mul-target-type detecon rules and algorithm parameters, the device captures
targets of mulple types and triggers linkage acons automacally.
Before You Start
Go to VCA and select the applicaon. Select Mul-Target-Type Detecon and click Next to enable
the
funcon.
Steps
1.
Go to VCA → Set Applicaon → Mul-Target-Type Detecon → Rule .
2.
Check Enable.
Figure 11-14 Set Rules
3.
Click to draw a detecon area. Click on the live view to specify the vertexes and draw the
boundaries of the
detecon area, and right click to complete drawing.
4.
Enter the min. pupil distance in the text eld, or click to draw min. pupil distance.
Min. Pupil Distance
The min. pupil distance refers to the minimum area between two pupils, and it is basic for the
device to recognize a face.
5.
Check to enable the Flow Overlay, and set the parameters.
6.
Click Save.
7.
Oponal: For shield region sengs, refer to Set Shield Region .
8.
Set arming schedule. See Set Arming Schedule .
9.
Set linkage method. See
Linkage Method Sengs .
Network Camera User Manual
112
10.
Oponal: For overlay and capture sengs, refer to Overlay and Capture . For advanced
parameters sengs, refer to Mul-Target-Type Detecon Advanced Parameters .
What to do next
Go to Playback → Picture to search and view the captured pictures. Refer to
View and Download
Picture for details.
Go to Applicaon Display → Display Alarm to see currently captured target pictures. Refer to
Smart Display for details.
11.5.2 Set Mul-Target-Type Counng Rule
This funcon is used to count the number of line crossing targets by type and detect the line
crossing
direcon.
Before You Start
Go to VCA and select the applicaon. Select Mul-Target-Type Detecon and click Next to enable
the
funcon.
Steps
1.
Check Enable to enable the funcon.
Figure 11-15 Set Mul-Target-Type Counng Rule
2.
Check the desired counng target.
3.
Draw and adjust the detecon line.
-
Click to draw the detecon line. Drag the line to the locaon on the live view as desired.
-
Click
to delete the drawn lines.
4.
Oponal: Set the ow overlay parameters.
Network Camera User Manual
113
1) Check Enable to enable the ow overlay funcon.
2) Select the counng direcon.
3) Set the OSD Custom Content for the counng direcon name to be overlaid on the live view
video.
4) Set a daily reset me for Reset OSD, or you can also click Manual Reset to reset manually.
5.
Oponal: Set the data uploading parameters.
Real-Time Data Uploading
If checked, the device uploads the counng data in real-me.
Scheduled Uploading
If checked, the device uploads the counng data according to the stascal period. In this
case, Interval needs to be set.
6.
Oponal: Set email report parameters.
If you want to send the report by email, select the data type and report format as required.
When the device has
stascs on mul-target-type counng and the mailbox is set correctly, the
corresponding type of report
informaon can be sent by email.
7.
Click Save.
Note
The funcon is only supported by certain device models.
What to do next
You can view and export the
counng data in Applicaon Display. Refer to View Mul-Target-Type
Counng Stascs for details.
11.5.3 Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Note
The funcon varies according to dierent device models.
Overlay
Display VCA Info. on Stream
Display smart informaon on stream, including the target and rules informaon.
Display Target Info. on Alarm Picture
Overlay the alarm picture with target informaon.
Display Target Paern Info. on Alarm Picture
Overlay the target moving paern on the alarm picture.
Display Motor Vehicle Tracking Paern on Alarm Picture
Network Camera User Manual
114
Overlay the motor vehicle target moving paern on the alarm picture.
Target Picture Sengs
Target Picture Sengs
Custom, Head Shot, Half-Body Shot and Full-Body Shot are selectable.
Note
If you select Custom, you can customize Width, Head Height and Body Height as required.
You can check Fixed Value to set the picture height.
Face Beaucaon
Check Face Beaucaon and adjust the beaucaon level as needed.
Note
Face Beaucaon slightly adjusts the captured face pictures and reduces noise of captured
face picture.
Face Enhancement
Check Face Enhancement and the device is able to capture beer and clearer face pictures
when it is dark.
License Plate Enhancement
Check it and the device is able to capture
beer and clearer license plate pictures.
Close-up Face Picture
Sengs
Close-up Face Picture Sengs
Aspect Rao
Width × Height
Central Point Oset
The height of the center point of the face picture. The higher the value, the closer the point is
to the top of the head.
Expansion Rao
The larger the expansion rao, the smaller the close-up face in the picture.
Background Picture
Sengs
Background Picture Sengs
Comparing to target picture, background picture is the scene image which oers extra
environmental informaon. You can set the background picture quality and resoluon.
Background Upload
Network Camera User Manual
115
If the background image need to be uploaded to surveillance center, check Background
Upload.
Share Background for Face and Body
For some devices, you can check Share Background for Face and Body. Aer the funcon is
enabled, a background picture with human face and full-body image will be uploaded.
Face Picture
For some devices, you can also check Face Picture as needed. The device will upload the
captured face picture.
Compress Background Picture
The device uploads a compressed captured background picture. The higher the compression
level, the smaller the picture
le size.
Text Overlay
Text Overlay
You can check desired items and adjust their order to display on captured pictures.
See Set Camera Info to set Device No. and Camera Info.
11.5.4
Mul-Target-Type Detecon Advanced Parameters
It is used to set and opmize the parameters of the algorithm library for Mul-Target-Type
Detecon.
Note
The funcon varies according to dierent device models.
HMS Version
It refers to the current algorithm version, which cannot be edited.
Overlay Intelligent Informaon
Overlay the related intelligent informaon or POS informaon in the video.
Capture Parameters
Best Shot
Capture Threshold
It refers for the quality of face to trigger capture and alarm. Higher value means beer quality
should be met to trigger capture and alarm.
Quick Shot
Network Camera User Manual
116
When the face picture grading value is higher than the quick shot threshold, the face picture
will be captured and uploaded. Otherwise, the picture with the highest grading value that
reaches the max. capture interval will be selected for upload.
Quick Shot Threshold
It stands for the quality of face to trigger quick shot.
Max. Capture Interval
It refers to the max.
me occupaon for one quick shot.
Remove Duplicated Faces
This
funcon can help lter out repeated captures of certain face.
Similarity Threshold for Duplicates Removing
It is the similarity between the newly captured face and the picture in the duplicates removing
library. When the similarity value is higher than the value you set, the captured picture is
regarded as a duplicated face and will be dropped.
Duplicates Removing Library Grading Threshold
It is the face grading threshold that triggers duplicates checking. When the face grading is
higher than the set value, the captured face is compared with the face pictures that are
already in the duplicates removing library.
Duplicates Removing Library Update Time
The
me from when each face picture is added to the duplicates removing library unl when it
is deleted.
Face Exposure
Check the checkbox to enable the face exposure.
Reference Brightness
It refers to the reference brightness of a face in the face exposure mode. If a face in the
actual scene is brighter than the set reference brightness, the device lowers the exposure
level. If a face in the actual scene is darker than the set reference, the device increases the
exposure level.
Minimum
Duraon
The extra me the device keeps the face exposure level aer the face disappears in the
scene.
Face Filtering Time
It means the me interval between the camera detecng a face and taking a capture. If the
detected face stays in the scene for a
me shorter than the set ltering me, capture will not be
triggered. For example, if the face ltering me is set as 5 seconds, the camera will capture the
detected face when the face keeps staying in the scene for 5 seconds.
Network Camera User Manual
117
Note
The face ltering me (longer than 0 s) may increase the possibility of the actual capture mes
less than the set value above.
Simultaneous Frame Capture of Face and Human Body
The device will capture both face and human body pictures from the same frame when the
alarm is triggered, ensuring that the captured face and body pictures are associated with the
same target.
Note
The funcon is only supported by certain device models.
Data Upload
Data Upload
Check one or more desired target types for picture uploading.
Restore Parameters
Restore Defaults
Click Restore to restore all the sengs in advanced conguraon to the factory default.
11.5.5 Set Shield Region
The shield region allows you to set the specic region in which the set smart funcon rule is
invalid.
Steps
1.
Select Shield Region.
2.
Click
to draw shield region. Repeat this step above to set more shield regions.
3.
Oponal: Select and click on the drawn region, then click to delete the selected drawn
region.
4.
Oponal: Click to delete all drawn regions.
5.
Click Save.
11.5.6 View
Mul-Target-Type Counng Stascs
For the device that supports Mul-Target-Type Counng, you can view, generate a report of, and
report the counng data by its counng data stascs.
Before You Start
For mul-target-type counng sengs, refer to Set Mul-Target-Type Counng Rule for details.
Network Camera User Manual
118
Steps
1.
Go to Applicaon Display → Mul-Target-Type Counng Stascs .
2.
Set the search condion.
3.
Click Search to generate the report.
The data
informaon that matches the condions will be displayed.
4.
When the
stascs result is displayed in list, you can click Export to export the data.
11.6 Face Picture Comparison
Face picture comparison serves the purpose of face recognion by comparing the captured face
pictures with those in face picture library.
Note
●
For certain device models, you need to enable Face Picture Comparison on VCA page rst.
●
The funcon is only supported by certain device models.
11.6.1 Set Face Picture Library
Face picture library is used to store modeled human faces and informaon.
Steps
1.
Go to VCA → General
Sengs → Face Picture Library .
2.
Create a face picture library.
1) Click Add to add a face picture library.
2) Input library name, threshold and remarks.
Threshold
Face similarity higher than the set threshold triggers face picture comparison alarm
uploading.
3) Click OK.
4)
Oponal: Modify a face picture library. Select the desired library and click Modify and change
related parameters.
5)
Oponal: Delete a library. Select the desired library and click Delete.
3.
Add face pictures to the library.
Note
The picture format should be JPG or JPEG, and the size no larger than 300 KB per le.
Add one face
Click Add and upload the face picture with detailed face informaon.
Import face
pictures in batch
Click Import and select picture path. You can select and import mulple
face pictures as required.
Network Camera User Manual
119
Note
When you import face pictures in batch, the picture name is saved as the
face name. For other face informaon, you should modify one by one
manually.
4.
Oponal: Modify face informaon.
1) Select a face picture library.
2) Select the target face picture. You can use the search
funcon to locate the picture by
inpung search condions, and click Search.
3) Click Modify.
4) Edit detailed
informaon.
Note
Face picture is not allowed to change.
5) Click OK.
5.
Click Batch Modeling to create models for each face picture in library.
Note
Modeling process builds up face model for each selected face picture. Face model is required for
face picture comparison to take eect.
6.
Oponal: Repeat to create more face picture libraries.
11.6.2 Set Face Picture Comparison
The funcon compares captured pictures with face pictures in library and outputs comparison
result. Comparison result can trigger certain
acons when arming schedule and linkage method are
set.
Before You Start
●
Go to VCA and select the applicaon. Select Face Picture Comparison and click Next to enable
the
funcon.
●
You should rst set face capture funcon. See Set Face Capture .
●
You should
rst create a face picture library and add face pictures. See Set Face Picture Library .
Steps
1.
Go to VCA → Set Applicaon → Face Picture Comparison and select Comparison and Modeling.
2.
Check Enable.
3.
Select a comparison mode.
Best
Comparison
The device captures and compares the target face connuously when the
face target stays in the detecon area, and upload the best scored face
picture and related alarm informaon when the target face leaves the area.
Network Camera User Manual
120
Quick
Comparison
The device captures and compares the target face when the face grading
exceeds the set Face Grading Threshold for Capture.
Face Grading Threshold for Capture
The face grading threshold for the device to judge whether to capture and
upload the face or not.
Max. Capture Interval
The max. interval between two captures when the target is in the
detecon area. The camera takes the capture when it reaches the max.
interval even if the face grading does not reach the set threshold.
Quick Setup Mode
Select the mode according to actual using scenarios. In custom mode, you
can set Comparison Timeout and Comparison Times.
4.
Oponal: Set data uploading.
-
Select desired informaon to upload.
-
Select the desired linked comparison alarm.
5.
Select a face picture library as the reference. Refer to
Set Face Picture Library for details.
6.
Set arming schedule. See Set Arming Schedule .
7.
Set linkage method. See
Linkage Method Sengs .
8.
Click Save.
What to do next
Go to Applicaon Display → Face Picture Comparison Result to view the face picture comparison
stascs. Refer to View Face Picture Comparison Result for details.
11.6.3 View Face Picture Comparison Result
Steps
1.
Go to
Applicaon Display → Face Picture Comparison Result .
2.
Set search condion and click Search.
Result
Matched results are shown in the right area.
11.7 People Management
People management is used to detect and analyze people number and changes in a predened
region. It can be applied to the entrances and exits, supermarkets, etc.
Network Camera User Manual
121
Note
●
For certain device models, you need to enable People Management on VCA page rst.
●
The funcon is only supported by certain device models.
11.7.1 Regional People Counng
It counts people in a predened area and detects people number changes and crowded situaon.
When the people number excepon or waing me excepon occurs, the device can trigger an
alarm.
Refer to
Set People Density to set people density detecon.
Refer to Set People Excepon Detecon to set people excepon detecon.
Refer to Waing Time Excepon Detecon to set waing me excepon detecon.
Set People Density
This funcon detects the level of people density in the set rule region.
Before You Start
●
Go to VCA → Select Applicaon , select People Management and click Next to enable the
funcon.
●
For the device supporng HEOP, go to VCA to import and enable People Management.
Steps
1.
Go to VCA → Set Applicaon → People Management → Regional People Counng → Rule .
2.
Click Add to add a rule and set its name.
3.
Set a rule.
Network Camera User Manual
122
Figure 11-16 Set Rules
People Number OSD
It displays the
real-me people number in the live view window. You can drag the mouse to
adjust the OSD window
locaon.
Note
People density alarm does not support Alarm Times Per Excepon, Alarm Interval and First
Alarm Delay sengs.
4.
Click to draw a region in the live view window, le click the end-points in the live view
window to
dene the boundary of the set rule region, and right click to nish drawing.
Note
●
Up to 8 regions can be set at the same me.
●
Try not to overlap the regions.
5.
Check People Density Alarm to enable the funcon.
Network Camera User Manual
123
Figure 11-17 People Density Alarm
Scheduled Uploading
The device uploads people density informaon within the set stascs cycle.
People Quanty Change Upload
The device uploads the people quanty change informaon if there is any change in the set
rule region.
Congeson Level Upload
The device uploads the congeson informaon when there is any change of congeson level
in the set rule region.
Density Level
Number of People
The range for each level by inpung the lower limit of the number of people in the set
rule region.
Custom Name
The name of the level.
Note
●
Set the Number of People before the Custom Name.
●
Up to three levels can be congured. The density increases from level 1 to level 3.
6.
Set arming schedule. See Set Arming Schedule .
7.
Set linkage method. See
Linkage Method Sengs .
8.
Click Save.
Network Camera User Manual
124
9.
Oponal: Set overlay and capture parameters. For detailed sengs, refer to Overlay and
Capture .
10.
Oponal: View version and set ltering condion. For detailed sengs, refer to Advanced
Sengs .
Set People Excepon Detecon
This funcon detects the number of people in the set rule region and an alarm is triggered when
the situaon meets the alarm-triggering condion.
Before You Start
●
Go to VCA → Select Applicaon , select People Management and click Next to enable the
funcon.
●
For the device supporng HEOP, go to VCA to import and enable People Management.
Steps
1.
Go to VCA → Set Applicaon → People Management → Regional People Counng → Rule .
2.
Click Add to add a rule and set its name.
3.
Set a rule.
Figure 11-18 Set Rules
People Number OSD
It displays the real-me people number in the live view window. You can drag the mouse to
adjust the OSD window locaon.
Alarm Times Per Excepon
It refers to the alarm mes aer an alarm is triggered. If you do not check it and set the
mes, the device will keep sending alarms.
Alarm Interval
Network Camera User Manual
125
Within the set Alarm Interval, the same alarm will not be uploaded.
First Alarm Delay
When the rst alarm is triggered, the alarm will be uploaded aer a set me period.
4.
Click to draw a region in the live view window, le click the end-points in the live view
window to dene the boundary of the set rule region, and right click to nish drawing.
Note
●
Up to 8 regions can be set at the same me.
●
Try not to overlap the regions.
5.
Check Regional People Excepon Alarm, and set Alarm Trigger Condion and Alarm Threshold.
Note
●
Aer enabling Ignore Situaon of No People, the device will not trigger an alarm when there
is no people in the region.
●
This funcon can lter the potenal alarm condion under which the value is less than the set
Alarm Threshold and no people in the region.
Figure 11-19 Regional People Excepon Alarm
6.
Set arming schedule. See Set Arming Schedule .
7.
Set linkage method. See Linkage Method Sengs .
8.
Click Save.
9.
Oponal: Set overlay and capture parameters. For detailed sengs, refer to Overlay and
Capture .
10.
Oponal: View version and set ltering condion. For detailed sengs, refer to Advanced
Sengs .
Waing
Time Excepon Detecon
This funcon detects the waing me of the set rule region and an alarm is triggered when the
waing me meets the alarm-triggering condion.
Network Camera User Manual
126
Before You Start
●
Go to VCA → Select Applicaon , select People Management and click Next to enable the
funcon.
●
For the device
supporng HEOP, go to VCA to import and enable People Management.
Steps
1.
Go to VCA → Set Applicaon → People Management → Regional People Counng → Rule .
2.
Click Add to add a rule and set its name.
3.
Set a rule.
Figure 11-20 Set Rules
People Number OSD
It displays the real-me people number in the live view window. You can drag the mouse to
adjust the OSD window locaon.
Alarm Times Per Excepon
It refers to the alarm mes aer an alarm is triggered. If you do not check it and set the
mes, the device will keep sending alarms.
Alarm Interval
Within the set Alarm Interval, the same alarm will not be uploaded.
First Alarm Delay
When the rst alarm is triggered, the alarm will be uploaded aer a set me period.
Note
Dwell me excepon alarm supports Alarm Times Per Excepon, Alarm Interval and First Alarm
Delay sengs only on the condion that the Alarm Trigger Condion is Greater Than Threshold
A.
Network Camera User Manual
127
4.
Click to draw a region in the live view window, le click the end-points in the live view
window to dene the boundary of the set rule region, and right click to nish drawing.
Note
●
Up to 8 regions can be set at the same me.
●
Try not to overlap the regions.
5.
Check Dwell Time Excepon Alarm, and set Alarm Trigger Condion and Alarm Threshold.
Figure 11-21 Dwell Time Excepon Alarm
6.
Set arming schedule. See Set Arming Schedule .
7.
Set linkage method. See
Linkage Method Sengs .
8.
Click Save.
9.
Oponal: Set overlay and capture parameters. For detailed sengs, refer to Overlay and
Capture .
10.
Oponal: View version and set ltering condion. For detailed sengs, refer to Advanced
Sengs .
11.7.2
On/O Duty Detecon
When a target in a predened area triggers an on/o duty rule, the device can take linkage acons.
It can detect the on/o duty status and people number changes in a predened area.
Before You Start
●
Go to VCA and select the applicaon. Select People Management and click Next to enable the
funcon.
●
For the device supporng HEOP, go to VCA to import and enable People Management.
Steps
1.
Go to VCA → Set Applicaon → People Management → On/O Duty Detecon → Rule .
2.
Click Add and edit the rule name according to your need.
3.
Select a rule and set the rule parameters.
Absence
Detecon
If the people number in the set area is less than the value of Person On Duty and the lasng
me is longer than the Absence Duraon, an alarm is triggered.
Network Camera User Manual
128
On/O Duty Detecon
It includes on/o duty situaon detecon.
People Number OSD
It overlays the real-me people number on the live view. You can adjust the OSD locaon by
dragging the mouse.
Figure 11-22 Set Rules
4.
Click to draw a rule area in the live view window. Le click the end-points in the live view
window to dene the boundary of the set rule area, and right click to nish drawing.
Note
●
Up to 8 areas can be set at the same me.
●
Try not to overlap the areas.
5.
Click Save.
Note
You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
Network Camera User Manual
129
Note
Select the rule in the rule list, and click Copy to... to copy the related arming schedule and
linkage method sengs to the other rules.
7.
Oponal: Set overlay and capture parameters. For detailed sengs, refer to Overlay and
Capture .
8.
Oponal: View version and set ltering condion. For detailed sengs, refer to Advanced
Sengs .
11.7.3 Queue Management
It is used to calculate and analyze the number of people and queue status in the area, and output
results.
Refer to
Set Queue Duraon Predicon to set queue duraon predicon.
Refer to Set Regional People Queuing-Up to set regional people queuing-up detecon.
Refer to Set Waing Time Detecon to set waing me detecon.
Refer to Queue Management Stascs to set and view queue management stascs.
Note
●
Queue management is only supported by certain models.
●
Queue Duraon Predicon is mutually exclusive with some funcons, such as On/O Duty
Detecon, Regional People Queuing-Up and Waing Time Detecon. Enable this funcon may
make other
funcons unavailable, and vice versa.
Set Queue Duraon Predicon
It is used to calculate and predict the queue duraon in the predened area.
Before You Start
●
Go to VCA and select the applicaon. Select People Management and click Next to enable the
funcon.
●
For the device supporng HEOP, go to VCA to import and enable People Management.
Steps
1.
Go to VCA → Set Applicaon → People Management → Queue Management → Rule .
2.
Check Queue Duraon Predicon to enable the funcon.
Note
Queue Duraon Predicon is mutually exclusive with some funcons, such as On/O Duty
Detecon, Regional People Queuing-Up and Waing Time Detecon. Enable this funcon may
make the other funcons unavailable, and vice versa.
Network Camera User Manual
130
Figure 11-23 Set Queue Duraon Predicon
3.
Draw areas.
Note
You can click View Drawing Example for a drawing example of the actual scene.
1) Click Add and edit the rule name according to your need.
2) Select an Area color and click to draw a rule area. Le click the end-points in the live view
window to
dene the boundary of the set rule area, and right click to nish drawing. It is
recommended that the queue should be in the area.
3) Click
to draw a quadrilateral area. It is recommended that the quadrilateral area should be
drawn in the front of the queue.
Note
●
Up to 8 areas can be set at the same me.
●
Try not to overlap the areas.
Network Camera User Manual
131
Figure 11-24 Drawing Example of Queue Duraon Predicon
4.
Set rule parameters.
Queue
Duraon OSD Overlay
When enabled, the queue duraon will be displayed in the image, and you can adjust the
display posion of the OSD overlay on the live view image.
Expected Queue Duraon Upload Interval and Alarm Interval
The device uploads queue duraon informaon at each upload interval. In the set Alarm
Interval, only one
nocaon is triggered for repeated alarms.
5.
Click Save.
Note
You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
Network Camera User Manual
132
Note
Select the rule in the rule list, and click or click Copy to... to copy the related arming schedule
and linkage method sengs to the other rules.
7.
Oponal: Set overlay and capture parameters. For detailed sengs, refer to Overlay and
Capture .
8.
Oponal: View version and set ltering condion. For detailed sengs, refer to Advanced
Sengs .
What to do next
Go to
Applicaon Display → Queue Management Stascs to view detailed data analysis. For
detailed sengs, refer to Queue Management Stascs .
Set Regional People Queuing-Up
It is used to count queuing-up persons in dened areas. Alarms are triggered when the alarm
threshold condion and the alarm trigger are both met.
Before You Start
●
Go to VCA and select the applicaon. Select People Management and click Next to enable the
funcon.
●
For the device supporng HEOP, go to VCA to import and enable People Management.
Steps
1.
Go to VCA → Set Applicaon → People Management → Queue Management → Rule .
2.
Click Add and edit the rule name according to your need.
Network Camera User Manual
133
3.
Select an Area color and click to draw a rule area. Le click the end-points in the live view
window to dene the boundary of the set rule area, and right click to nish drawing.
Note
●
Up to 8 areas can be set at the same me.
●
Try not to overlap the areas.
Network Camera User Manual
134
Figure 11-25 Draw Area
4.
Set rule parameters.
Alarm Interval
During the set alarm interval, alarms of the same type only trigger one
nocaon.
People Number OSD
It displays the number of people in the live view window.
Ignore Situaon of No People
The device will not trigger an alarm when there is no people in the scene. This funcon can
lter the potenal alarm condion under which the value is less than the set alarm threshold
and no people is in the scene.
5.
Select Regional People Queuing-Up and set Alarm Trigger
Condion and Alarm Threshold.
When the people number in the set area reaches alarm threshold and triggering condion, an
alarm will be triggered.
6.
Click Save.
Note
You can set the parameters of mulple areas by repeang the above steps.
7.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
Note
Select the rule in the rule list, and click or click Copy to... to copy the related arming schedule
and linkage method sengs to the other rules.
Network Camera User Manual
135
8.
Oponal: Click Data Upload to set data uploading. Both real-me uploading and scheduled
uploading are supported. Click Save aer nishing the sengs.
Real-Time Uploading
Check Real-Time Upload and the device uploads the detected target ID, waing duraon, and
regional people number in real-me.
Scheduled Uploading
The device uploads the people number whose
waing duraon is equal to or larger than the
Min. Duraon of Stay at the integral point.
For example, if the min. duraon of stay is set as 10 sec and two areas are covered, the
device, at the integral point, will upload the people number when the
duraon of stay is
equal to or longer than 10 sec in two areas respecvely.
9.
Oponal: Set overlay and capture parameters. For detailed sengs, refer to Overlay and
Capture .
10.
Oponal: View version and set ltering condion. For detailed sengs, refer to Advanced
Sengs .
What to do next
Go to
Applicaon Display → Queue Management Stascs to view detailed data analysis. For
detailed
sengs, refer to Queue Management Stascs .
Set
Waing Time Detecon
It is used to count the waing me of each person that enters a detecon area. Alarms are
triggered when the alarm threshold condion and the alarm trigger are both met.
Before You Start
●
Go to VCA and select the applicaon. Select People Management and click Next to enable the
funcon.
●
For the device supporng HEOP, go to VCA to import and enable People Management.
Steps
1.
Go to VCA → Set Applicaon → People Management → Queue Management → Rule .
2.
Click Add and edit the rule name according to your need.
Network Camera User Manual
136
3.
Select an Area color and click to draw a rule area. Le click the end-points in the live view
window to dene the boundary of the set rule area, and right click to nish drawing.
Note
●
Up to 8 areas can be set at the same me.
●
Try not to overlap the areas.
Network Camera User Manual
137
Figure 11-26 Draw Area
4.
Set rule parameters.
Alarm Interval
During the set alarm interval, alarms of the same type only trigger one
nocaon.
People Number OSD
It displays the number of people in the live view window.
5.
Select
Waing Time Detecon and set Alarm Trigger Condion and Alarm Threshold.
When the waing me in the set area reaches alarm threshold and triggering condion, an
alarm will be triggered.
6.
Click Save.
Note
You can set the parameters of mulple areas by repeang the above steps.
7.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
Note
Select the rule in the rule list, and click or click Copy to... to copy the related arming schedule
and linkage method sengs to the other rules.
8.
Oponal: Click Data Upload to set data uploading. Both real-me uploading and scheduled
uploading are supported. Click Save aer nishing the sengs.
Real-Time Uploading
Network Camera User Manual
138
Check Real-Time Upload and the device uploads the detected target ID, waing duraon, and
regional people number in real-me.
Scheduled Uploading
The device uploads the people number whose waing duraon is equal to or larger than the
Min. Duraon of Stay at the integral point.
For example, if the min. duraon of stay is set as 10 sec and two areas are covered, the
device, at the integral point, will upload the people number when the
duraon of stay is
equal to or longer than 10 sec in two areas respecvely.
9.
Oponal: Set overlay and capture parameters. For detailed sengs, refer to Overlay and
Capture .
10.
Oponal: View version and set ltering condion. For detailed sengs, refer to Advanced
Sengs .
What to do next
Go to Applicaon Display → Queue Management Stascs to view detailed data analysis. For
detailed
sengs, refer to Queue Management Stascs .
Queue Management
Stascs
Queue management supports data analysis and report output.
Before You Start
For queue management sengs, refer to Set Regional People Queuing-Up and Set Waing Time
Detecon .
●
Select Queuing-Up Time Analysis and
Mul-Area Comparison to compare queuing-up people
number of dierent areas.
●
Select Queuing-Up Time Analysis and
Mul-Level Comparison to compare queuing-up people
number of dierent waing me levels.
●
Select Queue Status Analysis and Mul-Area Comparison to compare the me and duraon
that a queue stays at a certain length in dierent areas.
●
Select Queue Status Analysis and Mul-Level Comparison to compare the me and duraon of
the queue at
dierent queue length levels.
Steps
Note
With an on-board memory card installed, the device can save up to one mouth's data. With NO
memory card installed, the device can only save up to one week's data.
1.
Go to Applicaon Display → Queue Management Stascs .
Network Camera User Manual
139
Figure 11-27 Queue Management Stascs
2.
Select Report Type and Stascs Time.
3.
Select
Stascs Content.
Queuing-Up Time Analysis
Queuing-up me analysis calculates people number of dierent waing me levels.
Queue Status Analysis
Queue status analysis calculates the me and duraon that a queue stays a certain length.
4.
Select
Stascs Dimension.
Mul-Area Comparison
Mulple areas and one level can be selected for analysis, and an analysis chart can be drawn.
Mul-Level Comparison
Mulple levels and areas can be selected for analysis, and one analysis chart is drawn for
each area.
5.
Check one or more areas.
6.
Set
Waing Time Level. Check one desired range and enter values.
7.
Click Search to generate the report.
8.
Oponal: Click Export to export the data.
Network Camera User Manual
140
11.7.4 Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Note
The funcon varies according to dierent device models.
Go to VCA → People Management → Overlay & Capture .
Display VCA Info. on Stream
Display smart
informaon on stream, including the target and rules informaon.
Display Target Info. on Alarm Picture
Overlay the alarm picture with target informaon.
Text Overlay
You can check desired items and adjust their order to display on captured pictures.
See Set Camera Info to set Device No. and Camera Info.
11.7.5 Advanced
Sengs
Set the advanced parameters for people management funcon and click Save.
Version
It stands for the current algorithm version.
Overlay Intelligent Informaon
Overlay the related intelligent informaon or POS informaon in the video.
Algorithm Mode
Select a mode according to the installaon scene.
Filter
Target Size
It stands for the size of the target
detecon window. A target larger than this pixel can be
counted as a real target. It can remove the false alarm of a certain xed target.
Displacement
It stands for target displacement or the target width. A target will not be counted if its
displacement is less than the set percentage.
Min. Waing Duraon
Waing me shorter than the set value will be ltered.
Condence
Network Camera User Manual
141
The higher the threshold is, the more dicult a target will be detected, but the higher the
accuracy is.
Note
The ltering sengs should be operated by the professionals. The lter sengs can adjust the
algorithm for detecon to change the detecon range, sensivity, etc.
Clear Storage Data
Clear all people counng data stored in the device. This funcon must be used with cauon.
11.8 Heat Map
Heat map is a graphical
representaon of data represented in colors. The heat map funcon of the
camera is used to analyze the
vising mes and dwelling me of customers in a congured area.
Note
The funcon is only supported by certain device models.
11.8.1 Set Heat Map
If you want to query stascal data of heat map, please congure the camera rst.
Before You Start
●
Go to VCA and select the applicaon. Select People Management and click Next to enable the
funcon.
●
For the device supporng HEOP, go to VCA to import and enable People Management.
●
Set the storage path rst before searching heat map data. For the storage sengs, refer to
Storage Sengs .
Steps
1.
Go to VCA → Set Applicaon → People Management → Heat Map Conguraon .
2.
Check Enable to enable the funcon.
3.
Draw a detecon area. Click , click on the live view to specify the vertexes and draw the
boundaries of the detecon area, and right click to complete drawing.
Network Camera User Manual
142
Figure 11-28 Draw Area
4.
Congure the parameters for the drawn area.
Expected Number of People
It refers to the max. number of people for heat map
counng.
ON
It refers to that the camera will compare the max. number of the people in the actual
scene with the set expected number of people and take the larger one as the max.
number of people for heat map.
OFF
It refers to that the camera will take the actual number of people as the max. value of heat
map.
Figure 11-29 Set Rules
5.
Click Save.
6.
Set arming schedule. See Set Arming Schedule .
7.
Set linkage method. See
Linkage Method Sengs .
Network Camera User Manual
143
8.
Oponal: Click Data Upload to set the data uploading informaon. Click Save to save the
sengs.
Uploading Data Type
Dwell Time
It refers to the target's dwelling me in the detecon area.
Dwell Time and Number of People
It refers to the target's dwelling me in the detecon area and the people number in the
detecon area.
What to do next
The heat map stascs will be calculated under Applicaon Display tab. Go to Applicaon Display
to check the heat map
stascs.
11.8.2 View Heat Map Data
Heat map can observe and calculate the people ow in a predened area and display the ow
stascs
in graphical form. It can be applied to scenes of large passenger ow such as malls,
supermarkets, and museums. You can nd the customers' preferences to adjust the places of
merchandise through heat map.
Before You Start
Finish heat map
conguraon. For details, refer to Set Heat Map .
Steps
1.
Go to Applicaon Display → Heat Map .
2.
Select Report Type. Daily report, weekly report, monthly report, and annual report are
selectable.
3.
Select Heat Map Type.
Spaal heat map and me heat map are selectable.
4.
Select
Stascs Type. By dwell me and by people number are selectable.
5.
Select Stascs Time.
6.
Click Search.
Daily report calculates the data on the date you selected; weekly report calculates the week data
your selected date belongs to; monthly report calculates the data for the month your selected
date belongs to; and the annual report calculates the data for the year your selected date
belongs to.
Example
Aer the calculang, you can view the data in the spaal heat map and me heat map.
Spaal Heat Map
Perform a stascal analysis on the cumulave dwelling of people in dierent areas in the
enre image.
Network Camera User Manual
144
Dierent heat values correspond to dierent colors, among which red (255, 0, 0) represents the
highest heat, and blue (0, 0, 255) represents the lowest heat. The highest heat value and lowest
heat value are divided into N levels, corresponding to dierent colors.
Time Heat Map
Perform a stascal analysis on the total dwelling me of all people in the enre image.
The me heat map is presented in a line chart, and you can click Export to export the data in an
excel
le.
11.9 Mul-Dimension People Counng
This funcon is used to calculate the number of people entering in or exing from the specied
scene.
Note
●
For certain device models, you need to enable Mul-Dimension People Counng on VCA page
rst.
●
The funcon is only supported by certain device models.
Figure 11-30 Set Mul-Dimension People Counng
Network Camera User Manual
145
11.9.1 Set Mul-Dimension People Counng Rule
Aer seng the detecon rules and algorithm parameters, the device calculates the number of
people entering or
exing in the rule area, triggers linkage acons and uploads data automacally.
Before You Start
Go to VCA → Select Applicaon , select Mul-Dimension People Counng and click Next to
enable the funcon.
Steps
1.
Go to VCA → Set Applicaon → Mul-Dimension People Counng → Rule .
Figure 11-31 Set Rules
2.
Click to draw a convex red rule frame. The rule frame should be larger than the actual
detecon area, such as door.
3.
Draw a
detecon line.
●
When the detecon area only supports one-way direcon, it is recommended to click to
draw a straight
detecon line.
●
When the detecon area supports mulple direcons, or there are walls and obstacles in the
detecon area, it is recommended to click to draw a polyline.
Note
●
The detecon line should be within and in the middle of the rule area. It is recommended to
draw the line on people chest posion in the live view.
●
The arrow of the detecon line shows entering direcon.
4.
Oponal: When the detecon area supports mulple direcons, you can enable Flow Direcon
Analysis. If the funcon is enabled, the device will change the detecon line into a polyline
automacally, divide the entrance region into sub-region B, C and D, and count the ow
direcon
of people.
5.
Oponal: Adjust the detecon area and detecon line.
Network Camera User Manual
146
Click Change the detecon line direcon if the direcon is dierent from the actual ow
direcon.
Click Clear all detecon areas and lines.
6.
Draw pupil distance.
Min. Pupil Distance
Click to draw the minimum pupil distance. If the pupil distance of the face in the video
image is smaller than the minimum pupil distance, the face will not be detected.
Max. Pupil Distance
Click
to draw the maximum pupil distance. If the pupil distance of the face in the video
image is larger than the maximum pupil distance, the face will not be detected.
7.
Set the
ow counng parameters.
Flow Overlay
Select the data to be displayed on the live view from the drop-down list.
Daily Reset Time
Select a me point through the drop-down list. Aer selecng, the ow counng data will be
automacally cleared at this me point every day. Click Manual Reset to manually trigger a
data reset.
8.
Set arming schedule. See
Set Arming Schedule .
9.
Set linkage method. See Linkage Method Sengs .
10.
Oponal: Set the people counng data uploading parameters.
Real-Time Upload Data
If it is checked, the ow counng data will be uploaded to the plaorm for update in real
me.
Upload Data Periodically
If it is checked, the ow counng data will be uploaded to the plaorm for update according
to the stascal period. In this case, Data Stascs Cycle needs to be set.
11.
Click Save.
●
When the target crosses the
detecon area along the entering direcon and passes the
detecon line, the target is counted as one entering target.
●
When the target crosses the detecon area along the leaving direcon and passes the
detecon line, the target will be counted as one exing target.
●
When the target crosses the
detecon area along the entering direcon mulple mes
within the Filtering Time Interval, and passes the detecon line, the target will be counted
as one duplicate target.
12.
Oponal: Set data opmizaon parameters. Click Save aer seng the parameters.
Special
Aribute Deduplicaon
If enabled, the device will determine whether the target is a duplicate target with the same
aribute. If it is a duplicate target, it will be counted as one entering target, and also
counted as one duplicate target.
Network Camera User Manual
147
Dynamic Deduplicaon
Persons who appear repeatedly within the Filtering Time Interval are not counted as an
eecve target. In other words, if it is a duplicate target, it will be counted as one duplicate
target and one entering target. If the Filtering Time Interval is set to 0, the funcon is not
enabled.
Face Picture Library Deduplicaon
If enabled, the device compares the target with the modeling data in the face library to
determine whether it is a duplicate target. If it is a duplicate target, it will be counted as one
entering target, and also counted as one duplicate target.
Note
For detailed sengs about face picture library, refer to Set Face Picture Library .
13.
Oponal: Set face picture comparison alarm. See Set Face Picture Comparison Alarm .
14.
Oponal: Set overlay and capture parameters.
Display VCA Info. on Stream
Display smart
informaon on stream, including the target and rules informaon.
Display Target Info. on Alarm Picture
Overlay the alarm picture with target informaon.
Text Overlay
You can check desired items and adjust their order to display on captured pictures by
sorng.
15.
Oponal: Set advanced parameters. Refer to Mul-Dimension People Counng Advanced
Sengs for details.
What to do next
Go to
Applicaon Display to view detailed people counng data analysis. For detailed sengs,
refer to View People Counng Stascs .
11.9.2
Mul-Dimension People Counng Advanced Sengs
Go to VCA → Set Applicaon → Mul-Dimension People Counng → Advanced to view and set
the advanced parameters.
Note
The funcon varies according to dierent device models.
Parameters
Mul-Dimension People Counng Version
It stands for the current algorithm version.
Overlay Intelligent Informaon
Network Camera User Manual
148
Overlay the related intelligent informaon or POS informaon in the video.
Algorithm Mode
View and select a mode according to the installaon scene.
Data Management
Clear Storage Data
This acon clears all counng data stored in the device. Pay aenon to this.
11.9.3 Set Face Picture Library
Face picture library is used to store modeled human faces and informaon.
Steps
1.
Go to VCA → General Sengs → Face Picture Library .
2.
Create a face picture library.
1) Click Add to add a face picture library.
2) Input library name, threshold and remarks.
Threshold
Face similarity higher than the set threshold triggers face picture comparison alarm
uploading.
3) Click OK.
4)
Oponal: Modify a face picture library. Select the desired library and click Modify and change
related parameters.
5)
Oponal: Delete a library. Select the desired library and click Delete.
3.
Add face pictures to the library.
Note
The picture format should be JPG or JPEG, and the size no larger than 300 KB per le.
Add one face
Click Add and upload the face picture with detailed face informaon.
Import face
pictures in batch
Click Import and select picture path. You can select and import mulple
face pictures as required.
Note
When you import face pictures in batch, the picture name is saved as the
face name. For other face informaon, you should modify one by one
manually.
4.
Oponal: Modify face informaon.
1) Select a face picture library.
Network Camera User Manual
149
2) Select the target face picture. You can use the search funcon to locate the picture by
inpung search condions, and click Search.
3) Click Modify.
4) Edit detailed
informaon.
Note
Face picture is not allowed to change.
5) Click OK.
5.
Click Batch Modeling to create models for each face picture in library.
Note
Modeling process builds up face model for each selected face picture. Face model is required for
face picture comparison to take eect.
6.
Oponal: Repeat to create more face picture libraries.
11.9.4 Set Face Picture Comparison Alarm
The funcon compares captured pictures with face pictures in library and outputs comparison
result. Comparison result can trigger certain acons when arming schedule and linkage method are
set.
Before You Start
Go to VCA → Select
Applicaon , select Mul-Dimension People Counng and click Next to
enable the funcon.
You should rst create a face picture library and add face pictures. Go to VCA → General Sengs
→ Face Picture Library to congure and manage the face pictures in library.
Steps
1.
Go to VCA → Set Applicaon → Mul-Dimension People Counng → Face Picture Comparison
Alarm .
2.
Check Background Upload if you need to
aach captured pictures to alarm informaon.
Comparing to target picture, background picture is the scene image which oers extra
environmental informaon. You can set the Background Picture Resoluon.
3.
Select a face picture library.
4.
Set arming schedule of the related face picture library.
1) Click
.
2) Click Draw, and drag the
me bar to draw desired valid me.
Note
●
Each cell represents 30 minutes.
●
Move the mouse over the drawn me period to see specic me periods and ne-tune the
start me and end me.
●
Up to 8 periods can be
congured for one day.
Network Camera User Manual
150
3) Click Erase, and drag the me bar to clear selected valid me.
4) Click OK to save the sengs.
Figure 11-32 Set Arming Schedule
5.
Set linkage method of the related face picture library. Click to set linkage method and save
the sengs. For detailed sengs, refer to Linkage Method Sengs .
6.
Click Save.
7.
Oponal: Repeat the above steps to congure the face picture comparison for the other face
picture library.
What to do next
Go to Applicaon Display to view detailed data analysis. For detailed sengs, refer to View Face
Picture Comparison Result .
11.9.5 View Face Picture Comparison Result
Steps
1.
Go to
Applicaon Display → Face Picture Comparison Result .
2.
Set search condion and click Search.
Result
Matched results are shown in the right area.
11.9.6 View People
Counng Stascs
You can view the people counng data stored in the device through the table, bar chart and line
chart.
Steps
1.
Go to
Applicaon Display → People Counng .
2.
Set Report Type, Stascs Type and Start Time.
Network Camera User Manual
151
3.
Click Search.
You can select Line Chart, Bar Chart and Table to view the data, and you can export the people
counng data through Excel.
11.10 AI Open Plaorm
AI Open Plaorm is to generate a model library based on the training material provided by the
user, then load the model library into the device and allow user to congure tasks and rules. When
a target in the scene is detected to trigger the rules, the device can take linkage
acons, which can
realize personalized smart applicaons.
Note
●
The funcon is only supported by certain device models.
●
For certain device models, you need to enable AI Open Plaorm on VCA page rst.
11.10.1 Set AI Open Plaorm
Steps
1.
Go to VCA → Set
Applicaon → AI Open Plaorm .
Note
●
Specic smart funcons are supported for conguraon via the AI Open Plaorm, such as
hard hat detecon.
●
Aer selecng a specic funcon, the device will load the model package of the
corresponding
funcon.
●
The
funcon varies according to dierent device models, please refer to the actual device.
-
For Hard Hat Detecon, it detects targets in the set detecon area who do not wear the hard
hat and triggers an alarm.
2.
Oponal: Add a model into Model Library. Select the Model Library and related Label File from
the local path, then set the Model Name. The model types are as follows.
Detecon Model
Detects a
specic target in the live view and provides the detecon result and coordinate
posion of the target.
Classicaon Model
Classies pictures or targets with aributes.
Mixed Model
Detects targets in the live view and classies them.
Network Camera User Manual
152
Note
Max. Number of Model Packages refers to the maximum number of model packages that the
device supports.
Figure 11-33 Add Model
3.
Go to engine list to bind and set if the plaorm supports mulple engines.
4.
Select a model and enable it.
Network Camera User Manual
153
Figure 11-34 Set Task
5.
Select an Analysis Mode.
Live Video Analysis
The device analyzes the live video to realize target detecon and
result uploading.
Scheduled Capture
Analysis
The device captures based on the set Auto-Switch Interval to analyze
the captured picture and upload results.
Note
If the mode is enabled and set, you can click the mode to change the current analysis mode.
6.
Set rules for the linked channel. Refer to Set Rules for details.
7.
Set the arming schedule and linkage method. For the arming schedule sengs, refer to Set
Arming Schedule . For the linkage method sengs, refer to Linkage Method Sengs .
8.
Oponal: Set advanced parameters. Enable Overlay Target Frame and Rule Overlay according to
your needs.
Overlay Target Frame
Overlay the alarm picture with target frame.
Network Camera User Manual
154
Rule Overlay Overlay the alarm picture with rule informaon.
9.
Click Save.
11.10.2 Set Rules
Set rules for the linked channel.
Before You Start
Make sure the related model in VCA → AI Open
Plaorm is selected, and the task conguraon is
nished.
Steps
1.
Click Add Rule. Select the rule and click
to rename the rule and select the rule type.
Figure 11-35 Set Rules
Region Target Excepon Status Detecon
Detects and counts the number of the target in the predened virtual rule area, and
compares it with the
seng rule. When sasfying the triggering condion, it will trigger the
alarm.
Line Crossing Target Detecon
Detects if any targets crossing the predened virtual rule line and triggers the alarm when
detects.
Network Camera User Manual
155
Full Analysis Rule
Detects and analyzes all targets in the predened virtual rule area.
Line Crossing Target Counng
Detects and counts the number of the target crossing the predened virtual rule line.
Region Target Number Counng
Detects and counts the number of the target in the predened virtual rule area.
Combined Rule
Supports Region Target
Excepon Status Detecon and Line Crossing Target Detecon in the
predened virtual rule area. You can set Combined Mode as All Sasfy or Sasfy In Order for
the detecon order.
Note
Rule types vary according to dierent model packages, please refer to the actual device.
2.
Set the detecon rule and draw rule area or line.
-
Draw a rule area: click
to draw a convex area in the live view window, le click the end-
points in the live view window to
dene the boundary of the set rule area, and right click to
nish drawing.
-
Draw a rule line: click and a line with an arrow appears in the live video. Drag the line to
the locaon in the live view window as desired.
3.
Set rule parameters.
Object
The
detecon target type of the model.
Aribute
The detecon target property of the model.
Duraon
The duraon of the status. The alarm will be triggered when the set me duraon is reached.
Alarm Interval
During the set alarm interval, alarms of the same type only trigger one nocaon.
Sensivity
The higher the value of sensivity is, the easier the alarm can be triggered. If the sensivity
value is too large, the false alarm may be produced easier. Please set it according to the
actual situaon.
Max. Alarm Times
The maximum number of mes an alarm can be triggered in the status that triggers the
alarm.
Counng Interval
The me interval for counng.
Algorithm Validity
Network Camera User Manual
156
When the condence threshold given by the algorithm is greater than or equal to the set
validity, an alarm is triggered and uploaded.
Line Crossing
The direcon from which the target goes across the line.
Quanty
Check Quanty and select the alarm rule from the drop-down box. Set Threshold or the
range (Min and Max) according to the alarm rule. When the number of the target sases
the seng alarm rule, the device will trigger the alarm.
Report Time Interval
It refers to the me interval for uploading the counng results when selecng Region Target
Number Counng.
Note
Rule parameters vary according to dierent rules, please refer to the actual device.
4.
Click Save.
11.11 Road
Trac
Vehicle Detecon and Mixed-Trac Detecon are available for the road trac monitoring. The
device captures the passing motor vehicles and non-motor vehicles and uploads the relevant
informaon together with the captured pictures.
Note
●
For certain device models, you need to select Road Trac on VCA page rst.
●
The funcon is only supported by certain device models.
11.11.1 Set Vehicle Detecon
The vehicles that enter the set lane can be detected and the picture of the vehicle and its license
plate can be captured and stored. Alarms will be triggered and captures can be uploaded.
Before You Start
●
Go to VCA and select the applicaon. Select Road Trac and click Next to enable the funcon.
●
Make sure the device is installed properly. Refer to the installaon recommendaon in ANPR
Camera FAQ for details.
●
Make sure the image parameters are properly
congured. Refer to the recommended image
parameters sengs in ANPR Camera FAQ for details.
●
Make sure the captured license plate picture is clear enough. Refer to the imaging requirements
for license plate capture in
ANPR Camera FAQ for details.
Network Camera User Manual
157
Steps
1.
Go to VCA → Set Applicaon → Road Trac → Rule , and select Vehicle Detecon as detecon
type.
2.
Check Enable.
Figure 11-36 Vehicle Detecon
3.
Select the operang mode.
Entrance/Exit
The license plate
informaon of the detected vehicle will be uploaded when the vehicle
passes the detecon area and triggers the detecon in the entrance/exit.
City Street
The license plate
informaon of the detected vehicle will be uploaded when the vehicle
passes the detecon area and triggers the detecon in the city street.
Alarm Input
It means the input alarm will trigger a license plate capture and recognion acon.
Note
●
When Alarm Input is selected, the alarm input A<-1 will automacally be assigned to trigger
vehicle detecon and its alarm type is always NO.
●
If the A<-1 alarm input is used to trigger vehicle detecon, it cannot be used for other basic
events.
●
When Alarm Input is selected and saved, previously congured linkage method for A<-1 will
be canceled.
4.
Select the total number of lanes.
5.
Click and drag the lane line to set its
posion, or click and drag the line end to adjust the length
and angle of the line.
Network Camera User Manual
158
The blue detecon line is the trigger line of the license plate, which is mainly used in the
Entrance/Exit scene to improve the capture eciency. It is recommended to put it in the lower
middle of the screen to make sure that the full-size car with the plate can pass it.
6.
Adjust the zoom
rao of the camera so that the size of the vehicle in the image is close to that of
the red frame. Only the
posion of red frame is adjustable.
Note
Only 1 license plate can be captured at one me for each lane.
7.
Select Area and Country/Region.
8.
Oponal: Check to select License Plate Category.
In certain countries/regions, the license plate number includes the license plate category and
the license plate main number. This
funcon is used to congure whether the license plate
category is included in the license plate number.
●
If the funcon is not enabled, only the license plate main number is displayed in the license
plate number.
●
When this funcon is enabled, the license plate category is included in the license plate
number.
Note
This funcon is only supported in certain countries/regions.
9.
Set the detecon mode.
Vehicle Priority
The device will detect the vehicle scale
rst, then catch the plate out to make the analysis. It
will get the beer accuracy but somemes it will lose some results in the not-sased
installaon scenario.
License Plate & Vehicle
In license plate & vehicle mode, the device detects license plate and vehicle simultaneously
and it uploads the alarm
informaon and the captured pictures.
Note
It is recommended to select Vehicle Priority mode if there are no issues on installaon and
supplement light. Aer the issues of plate recognion are carried out, you can switch the mode
to License Plate & Vehicle mode.
10.
Check Remove Duplicated License Plates and set the Time Interval. The default me interval is
4 minutes.
11.
Oponal: Set the following parameters according to the installaon scene.
Low-Installaon Mode
If the camera height is not higher than the vehicle headlight height, enable Low-Installaon
Mode to switch the algorithm to accommodate the camera installaon scenario.
Quick Li
Network Camera User Manual
159
It is used in the entrance and exit with a wide angle view and short detecon distance
scene. When you enable Quick Li, the camera can idenfy the license plate quickly, trigger
alarm output, and li the barrier gate.
Note
The funcons are only supported by certain device models in certain modes.
12.
Oponal: Check to enable Upload Motorcycle Alarm, and the device uploads the both motor
vehicle and non-motor vehicle (i.e., motorcycle) alarm
informaon, otherwise it uploads only
the motor vehicle alarm informaon.
Note
This funcon is only supported in Entrance/Exit mode.
13.
Oponal: Check to enable Upload Double-License-Plate Alarm, and the device can detect and
recognize two license plates in one vehicle and upload the alarm.
●
When Upload Double-License-Plate Alarm is enabled, Remove Duplicated License Plates
and Wiegand Linkage is only available for the primary license plate.
●
When Upload Double-License-Plate Alarm is enabled, the blocklist and allowlist is
disnguished only for the primary license plate. If the secondary license plate is recognized
but not the primary license plate, the blocklist and allowlist are not available, and the linkage
will be performed according to the
seng of Other List.
●
When two license plates in one vehicle are recognized, if the license plate number is set to
be overlaid, both license plate numbers can be overlaid, and the license plate picture can be
captured and uploaded. License plate number, license plate close-up picture of both primary
and secondary license plates can be displayed in Smart Display.
Note
This funcon is not supported in License Plate & Vehicle mode.
14.
Oponal: Check to enable Fuzzy Match License Plate. In the entrance/exit scene, to improve
the convenience, vehicles with a one-bit mismatch between the recognized license plate and
the one in the blocklist/allowlist are allowed to pass, and the alarm is uploaded.
15.
Click Save.
16.
Go to Arming Schedule and Linkage Method. You can set the arming schedule and linkage
method independently for blocklist, allowlist and other list, and you should set them one by
one.
Network Camera User Manual
160
Figure 11-37 Arming Schedule and Linkage Method
1) Click to select the blocklist, allowlist and other list.
2) Set the arming schedule. Refer to
Set Arming Schedule for details.
3) Set the linkage method. Check the checkbox of corresponding linkage method for each rule,
and click Save to save the
sengs.
Direcon
Only the vehicles moving as the selected direcon can trigger the selected linkage
methods.
All
All means that the vehicles in all moving
direcons will be considered. It is highly
recommended to choose All if there is no special use.
Forward
Forward means that the vehicle moves toward the camera.
Reverse
Reverse means that the vehicle moves away from the camera.
Wiegand Linkage
The device can send reports to the third-party
plaorm via the Wiegand protocol.
Make sure the device supports Wiegand interface and the device is connected by
Wiegand interface carefully.
Make sure the Wiegand is enabled and the protocol is properly
congured in the system
sengs. Refer to Wiegand for details.
Network Camera User Manual
161
Enable Wiegand Linkage and select the wiegand interface connected to the external
device.
The linkage will be triggered only when the detected vehicle driving direcon is the same as
the congured direcon.
17.
Go to Road Trac → Overlay & Capture to set the image parameters and text overlay of the
captured pictures. Refer to Overlay and Capture for details.
18.
Import or export the license plate blocklist and allowlist. Refer to
Import or Export Blocklist &
Allowlist for details.
19.
Oponal: Set the advanced parameters. Refer to Advanced Parameters Conguraon for
details.
20.
Oponal: Set the trac ow stascs. Refer to Trac Flow Stascs for details.
11.11.2 Set
Mixed-Trac Detecon Rule
The motor vehicles and non-motor vehicles that enter the set lane can be detected, and the
picture of targets can be captured and stored. Alarms will be triggered and captures can be
uploaded.
Before You Start
●
Go to VCA and select the
applicaon. Select Road Trac and click Next to enable the funcon.
●
Make sure the device is installed properly. Refer to the
installaon recommendaon in ANPR
Camera FAQ for details.
●
Make sure the image parameters are properly congured. Refer to the recommended image
parameters
sengs in ANPR Camera FAQ for details.
●
Make sure the captured license plate picture is clear enough. Refer to the imaging requirements
for license plate capture in
ANPR Camera FAQ for details.
Steps
1.
Go to VCA → Set Applicaon → Road Trac → Rule , and select Mixed-trac Detecon as
detecon type.
2.
Check Enable.
Network Camera User Manual
162
Figure 11-38 Mixed-Trac Detecon
3.
Select the total number of lanes.
4.
Click and drag the lane line to set its posion, or click and drag the line end to adjust the length
and angle of the line.
The blue
detecon line is the trigger line of the license plate, which is mainly used in the
Entrance/Exit scene to improve the capture
eciency. It is recommended to put it in the lower
middle of the screen to make sure that the full-size car with the plate can pass it.
5.
Adjust the zoom
rao of the camera so that the size of the vehicle in the image is close to that of
the red frame. Only the posion of red frame is adjustable.
Note
Only 1 license plate can be captured at one me for each lane.
6.
Select Area and Country/Region.
7.
Oponal: Check to select License Plate Category.
In certain countries/regions, the license plate number includes the license plate category and
the license plate main number. This funcon is used to congure whether the license plate
category is included in the license plate number.
●
If the
funcon is not enabled, only the license plate main number is displayed in the license
plate number.
●
When this
funcon is enabled, the license plate category is included in the license plate
number.
Note
This funcon is only supported in certain countries/regions.
8.
Check Remove Duplicated License Plates and set the Time Interval. The default me interval is
4 minutes.
9.
Oponal: Check to enable Upload Double-License-Plate Alarm, and the device can detect and
recognize two license plates in one vehicle and upload the alarm.
Network Camera User Manual
163
●
When Upload Double-License-Plate Alarm is enabled, Remove Duplicated License Plates and
Wiegand Linkage is only available for the primary license plate.
●
When Upload Double-License-Plate Alarm is enabled, the blocklist and allowlist is
disnguished only for the primary license plate. If the secondary license plate is recognized
but not the primary license plate, the blocklist and allowlist are not available, and the linkage
will be performed according to the seng of Other List.
●
When two license plates in one vehicle are recognized, if the license plate number is set to be
overlaid, both license plate numbers can be overlaid, and the license plate picture can be
captured and uploaded. License plate number, license plate close-up picture of both primary
and secondary license plates can be displayed in Smart Display.
10.
Click Save.
11.
Go to Arming Schedule and Linkage Method. You can set the arming schedule and linkage
method independently for blocklist, allowlist and other list, and you should set them one by
one.
Figure 11-39 Arming Schedule and Linkage Method
1) Click to select the blocklist, allowlist and other list.
2) Set the arming schedule. Refer to Set Arming Schedule for details.
3) Set the linkage method. Check the checkbox of corresponding linkage method for each rule,
and click Save to save the
sengs.
Direcon
Only the vehicles moving as the selected direcon can trigger the selected linkage
methods.
All
Network Camera User Manual
164
All means that the vehicles in all moving direcons will be considered. It is highly
recommended to choose All if there is no special use.
Forward
Forward means that the vehicle moves toward the camera.
Reverse
Reverse means that the vehicle moves away from the camera.
Wiegand Linkage
The device can send reports to the third-party
plaorm via the Wiegand protocol.
Make sure the device supports Wiegand interface and the device is connected by
Wiegand interface carefully.
Make sure the Wiegand is enabled and the protocol is properly
congured in the system
sengs. Refer to Wiegand for details.
Enable Wiegand Linkage and select the wiegand interface connected to the external
device.
The linkage will be triggered only when the detected vehicle driving
direcon is the same as
the congured direcon.
12.
Go to Road Trac → Overlay & Capture to set the image parameters and text overlay of the
captured pictures. Refer to Overlay and Capture for details.
13.
Import or export the license plate blocklist and allowlist. Refer to
Import or Export Blocklist &
Allowlist for details.
14.
Oponal: Set the advanced parameters. Refer to Advanced Parameters Conguraon for
details.
15.
Oponal: Set the trac ow stascs. Refer to Trac Flow Stascs for details.
11.11.3 Overlay and Capture
You can set the image parameters of the captured images in vehicle detecon and mixed-trac
detecon.
Go to VCA and select Road Trac.
Go to VCA → Set Applicaon → Road Trac → Overlay & Capture .
Note
The funcon varies according to dierent device models.
Network Camera User Manual
165
Figure 11-40 Overlay & Capture
Picture Quality
The larger the value is, the clearer the picture is, but larger storage space is also required.
Picture Size
The larger the value is, the larger the storage space is needed. And the level of network
transmission requirement is also higher.
Picture Resoluon
The captured background picture resoluon.
Picture Capture Interval
The camera supports connuously trigger the alarm and upload captured picture each interval.
Check Capture Interval and set the interval.
FTP Picture Name
Network Camera User Manual
166
You can set the naming rule for captured pictures in vehicle detecon and mixed-trac
detecon in the FTP server.
Select Default to use the default rule.
Select Custom, select informaon for the picture name, and click to adjust the order of
picture name parameters. If Capture Time is not selected in custom mode, the captured picture
triggered by the same vehicle later will replace the captured picture before due to the same
picture name.
Note
For more informaon about FTP sengs, refer to Set FTP .
Text Overlay
You can overlay camera, device or vehicle informaon on the captured image and click to
adjust the order of overlay texts.
Set the font color and background color by
selecng the color box, and click the desired color in
the pop-up palee or the drop-down box.
11.11.4 Import or Export Blocklist & Allowlist
You can import and export the blocklist and allowlist as desired, and check the list content in this
interface.
Steps
1.
Click Import to import the selected
le.
2.
Click to open the PC local directory.
3.
Find the blocklist & allowlist
le and click to select it. Click Open to conrm.
Note
●
The le to import should corresponds with the le template that is required by the camera.
You are recommended to export an empty blocklist & allowlist le from the camera as the
template and ll in the content.
●
The
le should be in the .xls, .xml or .csv format and the cell format should be Text.
4.
Click Import to import the selected le.
5.
Click Export All to export the license plate list.
Figure 11-41 Import or Export Blocklist & Allowlist
6.
Oponal: Click Add to add a license plate and set its related informaon one by one.
Network Camera User Manual
167
7.
Oponal: Click to select the ltering type. All Types, Wiegand CardID, License Plate No. and
Type are selectable. As for Type, you can select Keywords to dene the specic ltering type.
Click Search to view the results.
8.
Oponal: You can select a plate No. and click to delete a plate from the blocklist or allowlist.
9.
Oponal: You can select a plate No. and click to edit the related informaon of the license
plate from the blocklist or allowlist.
11.11.5 Advanced Parameters Conguraon
Go to VCA and select the applicaon. Enter the applicaon conguraon interface and click
Advanced to set advanced parameters. Click Save aer nishing the conguraon.
Note
The funcon varies according to dierent device models.
Version
It stands for the current algorithm version.
Overlay Intelligent Informaon
Overlay the related intelligent informaon or POS informaon in the video.
11.11.6
Trac Flow Stascs
You can set the vehicle counng parameters in vehicle detecon and mixed-trac detecon.
Go to VCA and select Road Trac.
Go to VCA → Set Applicaon → Road Trac → Trac Flow Stascs . Check Enable to enable the
funcon. Set the parameters and click Save.
Counng Type
Select the counng vehicle type as required.
Flow Overlay
Check Flow Overlay and select OSD Overlay Content. Select the overlaid vehicle ow direcon
type. None, All, and Forward/Reverse are selectable.
The counng data will be displayed on the image, and you adjust the display posion of
counng data in the live view image.
Note
OSD overlay only counts the number of vehicle on the current day. The data will be cleared
automacally when the device restarts or at the daily reset me.
Daily Reset Time
The device clears the data in 00:00 each day by default. You can set the me for the daily reset.
Network Camera User Manual
168
Manual Reset
Clear the current counng data.
Real-Time Upload
Check Real-Time Upload and the device uploads the counng data in real-me.
Go to Applicaon Display → Trac Flow Stascs to view related data stascs and export data.
11.12 Parking Management
Parking Management is applicable to the parking lots, which performs parking detecon such as
parking space status
detecon by recognizing vehicles and license plates in close view and distant
view scenes. This funcon can be used to guide vehicle parking and reasonably allocate parking
spaces according to the parking situaon.
Note
●
For certain device models, you need to select Parking Management on VCA page rst.
●
The funcon is only supported by certain device models.
11.12.1 Close View Mode
In close view mode, the device can detect at close range and can recognize the vehicle and license
plate.
Before You Start
Go to VCA and select the
applicaon. Select Parking Management and click Next to enable the
funcon.
Steps
1.
Go to VCA → Set
Applicaon → Parking Management , and select Close View Mode as the
detecon mode. Click Save or Save and Next.
2.
Go to Rule interface to set the rule.
Network Camera User Manual
169
Figure 11-42 Set Rules
3.
Check Enable to enable the funcon.
4.
Draw a detecon area. Click to draw a detecon area. Click on the live view to specify the
vertexes of the area, and right click to complete drawing. The detecon area should be a convex
polygon area.
5.
Draw the parking space area. Click
to draw a parking space area in the detecon area. Click
on the live view to specify the vertexes of the area, and right click to complete drawing. The
areas will be displayed in the parking space area list.
Note
●
The parking space area should be in the detecon area.
●
Parking space area cannot overlap.
●
You can select and click to delete a certain parking space area in the parking space area list.
●
For Close View Mode, up to 4 parking space areas can be set. The parking space area should
be a convex polygon area.
Network Camera User Manual
170
Figure 11-43 Draw Area (Close View Mode)
6.
View the parking space area parameters, including the parking space name, parking space
status, license plate No. and the parking duraon. Click Refresh to refresh the parameters.
Note
●
The license plate No. is only supported in the close view mode.
●
The supported parameters may vary according to dierent device models.
7.
Select Locality and Area/Country.
8.
Oponal: Check Enable to enable Vacant Parking Space Alarm.
Threshold of Vacant Parking Spaces
When the number of vacant parking spaces is less than the set threshold value, an alarm will
be triggered
unl the number of vacant parking spaces is greater than the set threshold
value.
9.
Set the OSD overlay. Total Parking Spaces, Available Parking Spaces and Occupied Parking
Spaces are selectable.
10.
Click Save to save the rule
sengs.
11.
Go to Arming Schedule and Linkage Method to set the arming schedule and linkage method.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method
sengs, refer to Linkage Method Sengs .
12.
Set the data uploading parameters.
Note
The funcon varies according to dierent models.
Parking Space Status
Network Camera User Manual
171
Check Scheduled Upload, and the device will upload the Parking Space Status every Upload
Interval.
Parking Timeout Alarm
When the actual parking me of the vehicle exceeds the set parking threshold, the alarm
will be triggered and the device will upload the related alarm informaon.
Parking Duraon
The set parking duraon threshold. If the actual parking duraon exceeds the set
threshold, the alarm will be triggered and the device will upload the related alarm and
vehicle informaon.
Alarm Upload Frequency and Cycle
If the alarm upload frequency is set as 5 mes and the cycle me is 3 minutes, the alarm
will be uploaded once every 3 minutes for a total of 5
mes when the actual parking
duraon exceeds the set parking threshold.
Example
If you set the parameters as shown in the following gure, it means that the alarm will be
triggered aer the vehicle parking duraon is over 10 minutes. The alarm will be uploaded
every 3 minutes for a total of 5
mes and will take a total of 15 minutes.
13.
Set the image parameters and text overlay of the captured pictures. Refer to Overlay and
Capture for details.
14.
Import or export the license plate blocklist and allowlist. Refer to
Import or Export Blocklist &
Allowlist for details.
15.
Oponal: Set the advanced parameters. Refer to Advanced Parameters Conguraon for
details.
11.12.2 Distant View Mode
In distant view mode, the device can detect at high altude from an overlook view and idenfy the
vehicles entering the detecon area.
Before You Start
Go to VCA and select the applicaon. Select Parking Management and click Next to enable the
funcon.
Network Camera User Manual
172
Steps
1.
Go to VCA → Set Applicaon → Parking Management , and select Distant View Mode as the
detecon mode. Click Save or Save and Next.
2.
Go to Rule interface to set the rule.
Figure 11-44 Set Rules
3.
Check Enable to enable the funcon.
4.
Draw a detecon area. Click to draw a detecon area. Click on the live view to specify the
vertexes of the area, and right click to complete drawing. The
detecon area should be a convex
polygon area.
5.
Draw the parking space area. Click
to draw a parking space area in the detecon area. Click
on the live view to specify the vertexes of the area, and right click to complete drawing. The
areas will be displayed in the parking space area list.
Note
●
The parking space area should be in the detecon area.
●
Parking space area cannot overlap.
●
You can select and click to delete a certain parking space area in the parking space area list.
●
For Distant View Mode, up to 40 parking space areas can be set. The parking space area
should be convex polygon area.
Network Camera User Manual
173
Figure 11-45 Draw Area (Distant View Mode)
6.
View the parking space area parameters, including the parking space name, parking space status
and the parking duraon. Click Refresh to refresh the parameters.
Note
The supported parameters may vary according to dierent device models.
7.
Oponal: Check Enable to enable Vacant Parking Space Alarm.
Threshold of Vacant Parking Spaces
When the number of vacant parking spaces is less than the set threshold value, an alarm will
be triggered
unl the number of vacant parking spaces is greater than the set threshold
value.
8.
Set the OSD overlay. Total Parking Spaces, Available Parking Spaces and Occupied Parking
Spaces are selectable.
9.
Click Save to save the rule
sengs.
10.
Go to Arming Schedule and Linkage Method to set the arming schedule and linkage method.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method
sengs, refer to Linkage Method Sengs .
11.
Set the data uploading parameters.
Note
The funcon varies according to dierent models.
Parking Space Status
Check Scheduled Upload, and the device will upload the Parking Space Status every Upload
Interval.
Parking Timeout Alarm
Network Camera User Manual
174
When the actual parking me of the vehicle exceeds the set parking threshold, the alarm
will be triggered and the device will upload the related alarm informaon.
Parking Duraon
The set parking duraon threshold. If the actual parking duraon exceeds the set
threshold, the alarm will be triggered and the device will upload the related alarm and
vehicle
informaon.
Alarm Upload Frequency and Cycle
If the alarm upload frequency is set as 5 mes and the cycle me is 3 minutes, the alarm
will be uploaded once every 3 minutes for a total of 5 mes when the actual parking
duraon exceeds the set parking threshold.
Example
If you set the parameters as shown in the following gure, it means that the alarm will be
triggered aer the vehicle parking duraon is over 10 minutes. The alarm will be uploaded
every 3 minutes for a total of 5
mes and will take a total of 15 minutes.
12.
Set the image parameters and text overlay of the captured pictures. Refer to Overlay and
Capture for details.
13.
Oponal: Set the advanced parameters. Refer to Advanced Parameters Conguraon for
details.
11.12.3 Overlay and Capture
You can set the image parameters of the captured images.
Go to VCA and select Parking Management.
Go to VCA → Set
Applicaon → Parking Management → Overlay & Capture .
Note
The funcon varies according to dierent device models.
Picture Quality
The larger the value is, the clearer the picture is, but larger storage space is also required.
Picture Size
The larger the value is, the larger the storage space is needed. And the level of network
transmission requirement is also higher.
Network Camera User Manual
175
Picture Resoluon
The captured background picture resoluon.
FTP Picture Name
You can set the naming rule for captured pictures in vehicle detecon and mixed-trac
detecon
in the FTP server.
Select Default to use the default rule.
Select Custom, select
informaon for the picture name, and click to adjust the order of
picture name parameters. If Capture Time is not selected in custom mode, the captured picture
triggered by the same vehicle later will replace the captured picture before due to the same
picture name.
Note
For more informaon about FTP sengs, refer to Set FTP .
Text Overlay
You can overlay camera, device or vehicle informaon on the captured image and click to
adjust the order of overlay texts.
Set the font color and background color by
selecng the color box, and click the desired color in
the pop-up palee or the drop-down box.
11.12.4 Import or Export Blocklist & Allowlist
You can import and export the blocklist and allowlist as desired, and check the list content in this
interface.
Steps
1.
Click Import to import the selected le.
2.
Click to open the PC local directory.
3.
Find the blocklist & allowlist le and click to select it. Click Open to conrm.
Note
●
The le to import should corresponds with the le template that is required by the camera.
You are recommended to export an empty blocklist & allowlist le from the camera as the
template and ll in the content.
●
The
le should be in the .xls, .xml or .csv format and the cell format should be Text.
4.
Click Import to import the selected le.
5.
Click Export All to export the license plate list.
Network Camera User Manual
176
Figure 11-46 Import or Export Blocklist & Allowlist
6.
Oponal: Click Add to add a license plate and set its related informaon one by one.
7.
Oponal: Click to select the ltering type. All Types, Wiegand CardID, License Plate No. and
Type are selectable. As for Type, you can select Keywords to dene the specic ltering type.
Click Search to view the results.
8.
Oponal: You can select a plate No. and click to delete a plate from the blocklist or allowlist.
9.
Oponal: You can select a plate No. and click to edit the related informaon of the license
plate from the blocklist or allowlist.
11.12.5 Advanced Parameters
Conguraon
Go to VCA and select the applicaon. Enter the applicaon conguraon interface and click
Advanced to set advanced parameters. Click Save
aer nishing the conguraon.
Note
The funcon varies according to dierent device models.
Version
It stands for the current algorithm version.
Overlay Intelligent Informaon
Overlay the related intelligent informaon or POS informaon in the video.
11.13 Tunnel Event
Detecon
Set the basic informaon for the camera, rule and arming schedule for the funcon.
Note
●
For certain device models, you need to select Tunnel Event Detecon on VCA page rst.
●
The funcon is only supported by certain device models.
11.13.1 Basic Sengs
You can set the basic informaon, listening server, and ANR.
Network Camera User Manual
177
Go to VCA → Set Applicaon → Tunnel Event Detecon → Basic Conguraon to complete the
sengs.
Basic Informaon
Applicaon Scene
Select the type of road that the device is applied to, and the detecon algorithm adapts
accordingly.
Country/Region
Select the country or region where the device is used, and the
detecon algorithm adapts
accordingly.
Listening Server
If the device uploads alarms in listening mode via our company's SDK, you should set the IP
address and port for the listening server.
ANR
When the network is disconnected, data is temporarily saved on the memory card. When the
network
connecon is resumed, the device automacally uploads the saved data to the arming
host, in which case, the arming host IP address is required.
Note
A memory card should be installed in the device. Memory card sengs should be completed.
See Memory Card for instrucons.
11.13.2 Set Rules
Set rules for the tunnel event detecon.
Before You Start
Go to VCA and select the
applicaon. Select Tunnel Event Detecon and click Next to enable the
funcon.
Steps
1.
Go to VCA → Set Applicaon → Tunnel Event Detecon → Panoramic Rule Sengs.
2.
Add lanes or polygon areas to the actual
situaon. Select the area type and click Add Area. Refer
to Set Polygon Area and Set Lane Area for details.
3.
Select and set the event. Refer to
Trac Event Detecon for details.
1) Click Add Event to add an event. You can select the event to be detected and set the rule.
2) Select arming type and check desired arming lane or arming polygon to enable arming.
4.
Click Save.
Network Camera User Manual
178
Set Polygon Area
A polygon area is where you want to set the detecon rules. Draw the area according to the actual
situaon.
Steps
1.
Go to VCA → Set Applicaon → Tunnel Event Detecon → Panoramic Rule Sengs and click
Polygon Area.
2.
Click Add Area.
3.
Click to mark the corner points of the polygon area. Right click to complete drawing.
Note
●
You can click to enlarge the live view window. Press ESC on the keyboard to exit.
●
Polygon areas cannot overlap.
●
Click on the area and you can drag the corner points to adjust the area.
4.
Select the line type of the le and right side lines according to the actual situaon.
5.
Oponal: Repeat the steps above to set mulple polygon areas.
Note
When there are mulple polygon areas, you can click on one area and click to delete it.
6.
Click Save.
Set Lane Area
A lane area is where you want to set the detecon rules. Mark the lane area according to the
actual lanes in the view.
Steps
1.
Go to VCA → Set
Applicaon → Tunnel Event Detecon → Panoramic Rule Sengs and click
Lane Area.
2.
Click Add Area.
Blue lane lines and a trigger line show on the live view.
3.
Drag the lane lines to frame the actual lane on the image.
Note
●
You can click to enlarge the live view window. Press ESC on the keyboard to exit.
●
Lane lines cannot overlap.
4.
Select the direcon of the trac and line type of the le and right lane lines according to the
actual situaon.
5.
Drag the triggering line to adjust its length and posion.
The triggering line is where the device captures the vehicle license plate pictures in some
detecons and where trac data collecon is triggered.
Network Camera User Manual
179
6.
Oponal: Repeat the steps above to set mulple lane areas.
7.
Click Save.
11.13.3 Trac Event Detecon
Trac event detecon includes detecon of incidents happens on the road, for example, thrown
objects and trac congeson. The device captures pictures and uploads alarm data.
Set Parking Detecon
The device detects parking violaons in tunnels and captures pictures.
Before You Start
Set
detecon areas. See Set Polygon Area and Set Lane Area for details.
Steps
1.
Go to VCA → Set Applicaon → Tunnel Event Detecon → Panoramic Rule Sengs .
2.
Click Add Event and select Parking
Detecon.
3.
Select Arming Polygon.
Parking detecon takes eect in the selected areas.
4.
Set the parameters.
Sensivity
With higher sensivity, the device is more sensive to detect and recognize targets.
If you enable No Alarm When
Congeson Occurs in Detecon Area, the congeson
threshold changes as the sensivity changes. The higher the sensivity, the higher the
congeson threshold and the easier it is to trigger the alarm. The lower the sensivity, the
lower the congeson threshold and the easier it is to lter the parking detecon.
No Alarm When Congeson Occurs in Detecon Area
The alarm will not be triggered if the congeson level in the detecon area reaches the set
congeson threshold.
Parking Tolerance
It stands for the threshold for the parking me in the area. If the parking me exceeds the
threshold, an alarm is triggered. The larger the value of the threshold is, the longer the alarm
triggering
me is.
5.
Click Save.
What to do next
Set the arming schedule and linkage and alarm. See Set Arming Schedule and ITS Linkage and
Alarm for details.
Network Camera User Manual
180
Set Fallen Object Detecon
The device detects fallen objects on the road and captures pictures.
Before You Start
Set detecon areas. See Set Polygon Area and Set Lane Area for details.
Steps
1.
Go to VCA → Set
Applicaon → Tunnel Event Detecon → Panoramic Rule Sengs .
2.
Click Add Event and select Fallen Object Detecon.
3.
Select Arming Lane or Arming Polygon.
Fallen object
detecon takes eect in the selected lanes or areas.
4.
Set Sensivity.
With higher
sensivity, the device is more sensive to detect and recognize targets.
5.
Click Save.
What to do next
Set the arming schedule and linkage and alarm. See
Set Arming Schedule and ITS Linkage and
Alarm for details.
Set Pedestrian
Detecon
The device detects pedestrians and non-motor vehicles in the detecon area and captures
pictures.
Before You Start
Set detecon areas. See Set Polygon Area and Set Lane Area for details.
Steps
1.
Go to VCA → Set Applicaon → Tunnel Event Detecon → Panoramic Rule Sengs .
2.
Click Add Event and select Pedestrian
Detecon.
3.
Select Arming Lane or Arming Polygon.
Pedestrian
detecon takes eect in the selected lanes or areas.
4.
Set Sensivity.
With higher
sensivity, the device is more sensive to detect and recognize targets.
5.
Set Duraon.
When the target stays in the detecon area longer than the duraon (at night, three mes the
duraon), an alarm is triggered.
6.
Set Filtering Time.
Within the set
ltering me, the same target will not trigger the alarm repeatedly.
7.
Select the target types in Detecon Target.
Only selected target types trigger linkage and alarm.
8.
Click Save.
Network Camera User Manual
181
What to do next
Set the arming schedule and linkage and alarm. See Set Arming Schedule and ITS Linkage and
Alarm for details.
Set Construcon Detecon
The device detects ongoing construcon in the detecon area and captures pictures.
Before You Start
Set detecon areas. See Set Polygon Area and Set Lane Area for details.
Steps
1.
Go to VCA → Set
Applicaon → Tunnel Event Detecon → Panoramic Rule Sengs .
2.
Click Add Event and select Construcon Detecon.
3.
Select Arming Lane or Arming Polygon.
Construcon detecon takes eect in the selected lanes or areas.
4.
Set Sensivity.
With higher
sensivity, the device is more sensive to detect and recognize targets.
5.
Set Duraon.
When the construcon in the detecon area lasts longer than the duraon, an alarm is
triggered.
6.
Set Filtering Time.
Within the set
ltering me, the construcon in the same detecon area will not trigger the
alarm repeatedly.
7.
Click Save.
What to do next
Set the arming schedule and linkage and alarm. See
Set Arming Schedule and ITS Linkage and
Alarm for details.
Set
Congeson Detecon
The device detects trac congeson in the detecon area and captures pictures.
Before You Start
Set detecon areas. See Set Polygon Area and Set Lane Area for details.
Steps
1.
Go to VCA → Set Applicaon → Tunnel Event Detecon → Panoramic Rule Sengs .
2.
Click Add Event and select Congeson Detecon.
3.
Select Arming Lane or Arming Polygon.
Congeson detecon takes eect in the selected lanes or areas.
4.
Set
Sensivity.
Network Camera User Manual
182
With higher sensivity, the device is more sensive to detect and recognize targets.
5.
Set Duraon.
When the congeson in the detecon area lasts longer than the duraon, an alarm is triggered.
6.
Set Filtering Time.
Within the set ltering me, the congeson in the same detecon area will not trigger the alarm
repeatedly.
7.
Click Save.
What to do next
Set the arming schedule and linkage and alarm. See
Set Arming Schedule and ITS Linkage and
Alarm for details.
11.13.4 ITS Linkage and Alarm
When trac events are detected, the device can perform linkage acons, for example, uploading
captured pictures and sending alarm messages.
Note
Some linkage acons may not be supported by certain device models.
Upload Pictures
Set the parameters for the device to automacally upload captured pictures to FTP server or other
plaorms.
See Upload by FTP to upload captured pictures by FTP.
See Upload by SDK or Set ISUP to upload captured pictures to plaorms.
Upload by FTP
Upload the data of vehicle detecon to an FTP server.
Before You Start
The FTP server is congured.
Steps
1.
Go to VCA → Set
Applicaon → Tunnel Event Detecon → Advanced Conguraon → FTP
Host .
2.
Check Enable.
3.
Select a Character Encoding Mode.
4.
Enter the IP Address, Port, User Name, and Password of the FTP server.
5.
Set the picture names and saving paths of
detecons.
6.
Click Save.
Network Camera User Manual
183
Upload by SDK
Upload the alarm messages by SDK in listening and arming mode.
Go to VCA → Set
Applicaon → Tunnel Event Detecon → Basic Conguraon to set Listening
Server and ANR. See Basic Sengs for details.
11.13.5 Advanced Sengs
You can set the advanced sengs according to your need to get beer vehicle arming eect.
Advanced Parameters
Go to VCA → Set Applicaon → Tunnel Event Detecon → Advanced Conguraon → Advanced
to set the following parameters.
Text Overlay on Video
Target Informaon
When target informaon is enabled, the target is highlighted with a frame in the video.
Rule Informaon
When rule informaon is enabled, the rule frames (for example, detecon areas) show in the
video.
Other Parameters
Tuning Mode
The tuning mode is for professional technicians. It is not recommended to other users as it may
aect the live view image.
Uploading Picture
Sengs
Go to VCA → Set Applicaon → Tunnel Event Detecon → Advanced Conguraon → Picture to
set the parameters of alarm pictures.
Picture Quality
Pictures with higher
resoluon and beer quality have more details and larger le size.
Enable OSD Overlay (Flow Overlay)
The device OSD is overlaid on alarm pictures.
Text Overlay on Single Alarm Picture
Check and set the text overlaid informaon on the single alarm picture.
Network Camera User Manual
184
Display Target Info. on Alarm Picture
Check to display target informaon on alarm pictures.
Display Rule Info. on Alarm Picture
Check to display rule informaon on alarm pictures.
11.14 Schedule Switch Applicaon
Set the corresponding applicaons in mulple me periods.
Before You Start
Go to VCA , select the applicaon and set the related detecon rules and parameters.
Steps
1.
Go to VCA → Select
Applicaon . For the device supporng HEOP, go to VCA for the seng.
Click Scheduled-Switch to set the schedule for switching the applicaon.
2.
Check Scheduled-Switch to enable the funcon.
3.
Click to select an applicaon to set the schedule.
4.
Click Draw, and drag the me bar to draw desired valid me.
Note
●
Each cell represents 30 minutes.
●
Move the mouse over the drawn me period to see specic me periods and ne-tune the
start me and end me.
●
Up to 8 periods can be
congured for one day.
5.
Click Erase, and drag the me bar to clear selected valid me.
6.
Click OK to save the sengs.
Figure 11-47 Set Applicaon Scheduled-Switch
Network Camera User Manual
185
Result
The device will execute the corresponding applicaon in the set me period.
11.15 Search and Export Data Aware Informaon
The data aware funcon is used to search and export the data of the restart, arming and capture
alarm
stascs.
Before You Start
Log in to the device via admin user account.
Steps
1.
Go to
Applicaon Display → Data Aware .
2.
Select the search condion.
Stascs Type Opons
Restart Records Type of restarng, start me and end me.
Arming Arming type, start me and end me.
Capture Alarm Stascs Report type, alarm target, protocol, arming IP address and start
me.
Alarm Quality Stascs Report type, alarm target and start me.
3.
Click Search.
The data informaon that match the condions will be displayed.
4.
Oponal: Click Export to save the data informaon to the local device.
11.16 Search and View Power
Consumpon Stascs
Before You Start
Log in to the device with an administrator account or an operator account with remote
conguraon permission.
Steps
1.
Go to Applicaon Display → Power Stascs .
2.
Set the search condion. Select Stascs Type, Report Type and Time.
3.
Click Search.
Result
When you select Power Consumpon as Stascs Type, the power consumpon informaon that
match the
condions will be displayed.
Network Camera User Manual
186
Figure 11-48 Power Consumpon Stascs
Network Camera User Manual
187
Chapter 12 Smart Display
This funcon displays real me pictures captured by smart funcons and analyzes the target in real
me.
Go to Applicaon Display → Display Alarm to view the real-me images. Click to go back to
Applicaon Display.
Note
●
To use this funcon, you should rst enable and congure certain smart funcons.
●
To use this funcon, your web browser version should be above IE11.0.9600.17843.
Live View Parameter
Icon Funcon
Capture a picture.
Start or stop recording.
Mute.
Adjust the volume of live view. Move the slider
to right to turn up the volume and le to turn
down the volume. Move to the le end to mute
the live view.
Download Display Pictures
Click and the device stores captured pictures to the browser cache. Hover the pointer over the
icon to see the number of pictures in the cache. Click
again to download the pictures in a
package.
Note
The browser cache has a limited size. The recommended number of pictures to download is no
more than 200.
Layout
Click and choose Layout. Check the display content you need to add it to the smart display page.
When
real-me analyze is selected, you can choose the contents you want to display.
Detect Feature
Click and choose Detect Feature. Check the corresponding checkbox to display the features of
the detecon target.
Network Camera User Manual
188
Chapter 13 EPTZ
EPTZ (Electronic PTZ) is a high-resoluon funcon that digitally zooms and pans into porons of the
image, with no physical camera movement. If you want to use the EPTZ
funcon, make sure your
device supports the Third Stream. Third stream and EPTZ should be both enabled simultaneously.
Note
The funcon is only supported by certain device models.
13.1 Patrol
Steps
1.
Go to Conguraon → EPTZ .
2.
Check Enable.
3.
The default Stream Type is Third Stream and cannot be
congured.
4.
Select Patrol in Applicaon Mode.
5.
Click Save.
What to do next
For the detailed
informaon about the patrol sengs, see the PTZ operaons on live view page.
13.2 Auto-Tracking
Steps
1.
Go to Conguraon → EPTZ .
2.
Check Enable.
3.
The default Stream Type is Third Stream and cannot be
congured.
4.
Select Auto-tracking in Applicaon Mode.
5.
Click to start drawing. Click on the live view video to specify the four vertexes of the detecon
area, and right click to complete drawing.
6.
Set rules.
Detecon Target
Human and vehicle are available. If the detecon target is not selected, all the detected
targets will be tracked, including the human and vehicle.
Note
Only certain camera models support this funcon.
Sensivity
Network Camera User Manual
189
It stands for the percentage of the body part of an acceptable target that is tracked.
Sensivity = 100 - S1/ST × 100. S1 stands for the target body part that enters the pre-dened
area. ST stands for the complete target body. The higher the value of sensivity is, the more
easily the target can be tracked.
7.
Click Save.
Network Camera User Manual
190
UD38502B
