Garmin 010-02616-52 Alpha 200 Handheld GPS Dog Tracker User Manual

Alpha

200 with Training

Owner’s Manual

improve its products and to make changes in the content of this manual without obligation to notify any person or organization of such changes or improvements. Go to

www.garmin.com for current updates and supplemental information concerning the use of this product.

Garmin

, the Garmin logo, Alpha

, ANT

, ANT+

, City Navigator

, and Xero

are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. BaseCamp

™

Garmin Explore

™

, Garmin Express

™

, Garmin HuntView

™

, tempe

™

, and TT

™

are trademarks of Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express

permission of Garmin.

Apple

and Mac

are trademarks of Apple Inc., registered in the U.S. and other countries. The BLUETOOTH

word mark and logos are owned by the Bluetooth SIG, Inc. and any use

of such marks by Garmin is under license. microSD

and the microSDHC logo are trademarks of SD-3C, LLC. Wi‑Fi

is a registered mark of Wi-Fi Alliance Corporation. Windows

a registered trademark of Microsoft Corporation in the United States and other countries. Other trademarks and trade names are those of their respective owners.

Table of Contents

Getting Started.................................1

Setting Up the Alpha System................. 1

Device Overviews.................................... 2

Alpha Handheld Device...................... 2

Dog Collar Device................................ 4

Installing the Battery Pack..................... 5

Charging the Handheld Device.............. 5

Charging the Dog Collar Device............. 6

Turning On the Device............................ 6

Turning Off the Device........................ 6

Selecting a Language............................. 6

Using the Touchscreen...........................6

Using the Status Page............................ 7

Acquiring Satellite Signals..................... 7

Dog Collar Device Setup................... 7

Methods to Add a Dog Collar Device to a

Handheld Device..................................... 7

Adding a Dog to the Alpha Handheld

Using Wireless Pairing........................ 8

Sharing a Dog Wirelessly.................... 8

Adding a Dog Using the Track and

Control Codes..................................... 8

VHF Radio Information....................... 9

Managing a Group.................................. 9

Editing Dog Information......................... 9

Resetting a Dog's Statistics and

Track.................................................... 9

Changing the Dog Name.................... 9

Changing the Color of the Dog's

Track.................................................... 9

Changing the Dog Type...................... 9

Changing the Dog ID......................... 10

Removing a Dog................................ 10

Fitting the Collar on Your Dog.............. 10

Communication with the Collar........... 11

Entering Sleep Mode............................ 11

Exiting Sleep Mode........................... 11

Dog Tracking..................................11

Tracking Your Dog on the Map............ 12

Dog Status Icons.................................. 12

Dog Tracking Compass........................ 13

Navigating to Your Dog........................ 13

Changing the Length of the Dog's

Track...................................................... 13

Location Alerts...................................... 13

Setting Location Alerts..................... 14

Editing Location Alerts..................... 14

Disabling Dog Data Broadcast............. 14

Dog Training.................................. 14

Selecting and Installing the Contact

Points.................................................... 15

Removing the Contact Points.......... 15

Training Methods..................................15

Linear and Traditional Stimulation.. 15

Choosing the Correct Intensity

Level...................................................15

Customizing the Training Keys............ 16

Using the Hard Keys for Training

Adjustments.......................................... 16

Default Training Settings......................16

Collar Training.......................................17

Connected Features....................... 17

Pairing a Smartphone with Your

Device.................................................... 17

Connecting to a Wireless Network...... 17

Garmin Explore..................................... 18

Contact Tracking............................18

Turning On and Off the Transmitter.... 18

Methods to Add a Contact to a

Handheld Device................................... 18

Adding a Contact Using Wireless

Pairing................................................... 18

Adding a Contact Using a Contact ID.. 19

Initiating an Emergency Alert............... 19

Sending a Message to Your

Contacts................................................ 19

Tracking a Contact............................... 19

Finding Your Contact ID....................... 19

Changing Your Contact ID.................... 19

Updating a Contact ID.......................... 20

Hunting with the Alpha System...... 20

Marking Your Truck Location...............20

Marking a Covey................................... 20

Active Hunt Metrics.............................. 20

Turning On the Collar Light.................. 20

Table of Contents i

Turning On Rescue Mode..................... 21

Pausing Dog Tracking.......................... 21

Waypoints, Routes, and Tracks.......21

Waypoints............................................. 21

Marking Your Current Location........ 21

Marking a Waypoint Using the

Map.................................................... 21

Editing a Waypoint............................ 21

Repositioning a Waypoint to Your

Current Location............................... 22

Moving a Waypoint on the Map....... 22

Increasing the Accuracy of a Waypoint

Location............................................. 22

Projecting a Waypoint...................... 22

Deleting a Waypoint.......................... 22

Routes................................................... 22

Creating a Route............................... 23

Editing the Name of a Route............ 23

Navigating a Saved Route................ 23

Editing a Route.................................. 23

Reversing a Route............................. 23

Viewing the Active Route..................23

Deleting a Route................................ 23

Recordings............................................ 23

Recording Track Logs.......................24

Viewing Details about the Track...... 24

Viewing the Elevation Plot of a

Track.................................................. 24

Navigating to the Start of a Track....24

Changing the Track Color.................24

Saving the Current Track.................. 24

Clearing the Current Track............... 24

Deleting a Track................................ 24

Navigation......................................25

Map........................................................ 25

Measuring Distance on the Map..........25

Compass............................................... 25

Calibrating the Compass.................. 25

Navigating with the Bearing

Pointer............................................... 25

Where To? Menu................................... 25

Finding a Waypoint by Name........... 25

Navigating with Sight 'N Go................. 26

Elevation Plot........................................ 26

Calibrating the Barometric

Altimeter............................................ 26

Navigating to a Point on the Plot..... 26

Changing the Plot Type.................... 26

Resetting the Elevation Plot............. 26

Trip Computer....................................... 26

Customizing the Trip Computer Data

Fields................................................. 26

Resetting the Trip Computer............ 26

Applications................................... 27

Setting a Proximity Alarm.................... 27

Calculating the Size of an Area............27

Setting an Alarm................................... 27

Using the Competition Timer............... 27

Satellite Page........................................ 27

Changing the Satellite View............. 27

Turning Off GPS................................ 27

Simulating a Location....................... 28

Downloading BirdsEye Imagery........... 28

Customizing Your Device............... 28

Customizing the Main Menu................ 28

Customizing the Data Fields................ 28

System Settings.................................... 29

Display Settings.................................... 29

Accessibility Settings....................... 29

Setting the Device Tones..................... 29

Setting Dog Alerts............................. 29

Map Settings......................................... 29

Tracked Devices Map Settings........ 30

Advanced Map Settings................... 30

Tracks Settings..................................... 30

Auto Save Settings........................... 30

Routing Settings................................... 31

Sensors Settings...................................31

Changing the Units of Measure........... 31

Position Format Settings..................... 31

Device Information......................... 31

Viewing E-label Regulatory and

Compliance Information...................... 31

Support and Updates............................ 32

Product Updates............................... 32

Device Care........................................... 32

Cleaning the Device.......................... 32

Cleaning the Touchscreen............... 32

ii Table of Contents

Specifications....................................... 33

Alpha Handheld Device

Specifications................................... 33

Dog Collar Device Specifications.....33

Mini Dog Collar Device

Specifications................................... 33

Battery Information...............................34

Long-Term Storage........................... 34

Maximizing the Battery Life............. 34

Saving Energy While Charging the

Device.................................................... 35

Data Management................................ 35

Installing a Memory Card................. 36

Connecting the Handheld Device to a

Computer........................................... 36

Connecting the Collar to a

Computer........................................... 37

Transferring Dog Tracks to

BaseCamp™.......................................37

Deleting Files..................................... 37

Disconnecting the USB Cable.......... 37

Resetting Data and Settings.............37

Appendix........................................38

Accessories and Replacement Parts.. 38

Purchasing Accessories................... 38

tempe................................................. 38

Tips for Pairing ANT+ Accessories

with Your Garmin Device.................. 38

Dog Collar Device Battery

Replacement Instructions................ 39

Replacing the Mini Dog Collar Device

Battery............................................... 41

Replacing the Collar Strap................ 41

Replacing the VHF Antenna in the Dog

Collar Device..................................... 42

Changing the Fuse in the Vehicle

Power Cable...................................... 43

Data Field Options................................ 44

Index..............................................47

Table of Contents iii

Getting Started

WARNING

See the Important Safety and Product Information guide in the product box for product warnings and other

important information.

Setting Up the Alpha System

Before you can use the Alpha system, you must set up the devices.

1 Charge the handheld device (Charging the Handheld Device, page 5).

2 Charge the dog collar device (Charging the Dog Collar Device, page 6).

3 Turn on the devices (Turning On the Device, page 6).

4 Select a language (Selecting a Language, page 6).

5 If necessary, pair the dog collar device with the handheld device (Methods to Add a Dog Collar Device to a

Handheld Device, page 7).

6 If necessary, calibrate the compass on the handheld device (Calibrating the Compass, page 25).

Getting Started 1

Device Overviews

Alpha Handheld Device

NOTICE

Avoid using a high-powered radio (greater than 5 W) in close proximity to the handheld device. It may cause

irreversible damage to the handheld device.

Satellite antenna

VHF radio antenna

Mounting spine

microSD

memory card slot (under battery)

Battery cover D-ring

Micro-USB port (under weather cap)

2 Getting Started

Alpha Device Keys

Power key

Customizable training keys

Training up

Training down

Training enter

Getting Started 3

Dog Collar Device

NOTE: Your dog collar device may look different than the device pictured.

VHF antenna

GPS antenna

Power key

Contact points

Status LED and flashing beacon LEDs

4 Getting Started

Installing the Battery Pack

1 Turn the D-ring counter-clockwise, and pull up to remove the cover.

2 Locate the metal contacts on the end of the lithium-ion battery.

3 Insert the battery into the compartment, contacts first.

4 Press the battery into place.

5 Replace the battery cover, and turn the D-ring clockwise.

Charging the Handheld Device

NOTICE

To prevent corrosion, thoroughly dry the USB port, the weather cap, and the surrounding area before charging or

connecting to a computer.

NOTE: The device does not charge when it is outside the approved temperature range (Alpha Handheld Device

Specifications, page 33).

You should fully charge the battery before you use the device for the first time. Charging a fully depleted battery

takes about 4 hours.

1 Lift the weather cap .

2 Plug the small end of the power cable into the USB port on the device.

3 Plug the other end of the power cable into an appropriate power source.

The LCD display on the handheld device shows the current battery charge level.

Getting Started 5

Charging the Dog Collar Device

NOTICE

To prevent corrosion, thoroughly dry the contacts on the collar and the surrounding area before connecting the

charging clip.

NOTE: Your dog collar device may look different than the device pictured.

You should fully charge the battery before you use the device for the first time. Charging a fully depleted battery

takes about five hours.

1 Snap the charging clip onto the device .

2 Plug the small end of the power cable into the mini-USB port on the charging clip cable.

3 Plug the power cable into a power source.

The status LED is solid red when the collar is charging.

4 After the status LED turns solid green, remove the charging clip from the collar.

Turning On the Device

• On the handheld device, press the power key.

• On the dog collar device, hold the power key until the status LED flashes and the collar beeps.

Turning Off the Device

• On the handheld device, hold the power key until the LCD screen turns off.

• On the dog collar device, hold the power key until the status LED turns red.

Selecting a Language

When you turn on your device for the first time, you will select the device language from a list of available

languages. You can change the language setting from the System settings.

1 From the main menu, select Setup > System > Language.

2 Select a language.

Using the Touchscreen

• Select to open a menu.

• Select to return to the home screen.

• Select to return to the previous page.

• If you are more than one menu away from the home screen, select and hold to return to the home

screen.

• If scroll controls are enabled, select and to scroll (Accessibility Settings, page 29).

6 Getting Started

Using the Status Page

The status page displays the time, your GPS signal strength, and the device battery life. It also allows you to

adjust settings and access shortcuts. You can open the status page from any other page by pressing the power

key.

Screen brightness: Adjusts the brightness of the screen.

Lock Screen: Locks the touchscreen to prevent inadvertent screen touches.

Lock Keys: Locks the device keys to prevent inadvertent key presses.

My ID: Displays your device ID and allows you to transmit your device information to a compatible handheld

device. You can also turn the transmitter on and off.

Alerts: Displays unread dog alerts.

Acquiring Satellite Signals

Both the collar and handheld device must acquire satellite signals before you put the collar on your dog.

Acquiring satellites can take a few minutes.

1 Go outdoors to an open area.

2 Turn on both devices (Turning On the Device, page 6).

in the status bar shows the GPS signal strength.

When the collar has acquired satellite signals, the status LED flashes a double-blink or triple-blink in green.

Dog Collar Device Setup

Methods to Add a Dog Collar Device to a Handheld Device

You can add up to 100 devices to one handheld device by using MURS/VHF, entering the track and control

codes, or by sharing wirelessly using ANT+

technology. Up to 20 devices can be active at one time.

Using MURS/VHF: Allows you to add a dog collar device after you have placed the dog collar device into pairing

mode by pressing the power key.

This method is helpful when you are adding a new accessory collar to the system prior to leaving for the

hunt (Adding a Dog to the Alpha Handheld Using Wireless Pairing, page 8).

Entering the track and control codes: Allows you to add a dog collar device that you do not own and that is not

in the area. The dog's owner must determine if you can only track the dog or can track and control the dog.

This method requires the dog's owner to find and communicate the codes to the person adding the dog

collar device.

This method is helpful when you would like to add a dog collar device during a hunt, but you are not near the

dog. For example, you are adding another member of your hunting party's dog collar device to your handheld

device, but you do not own the dog collar device (Adding a Dog Using the Track and Control Codes,

page 8).

NOTE: This feature varies based on dog collar device type and feature availability in your area. You may see

track codes only or track and control codes.

Sharing wirelessly using ANT+ wireless technology: Allows you to add a dog collar device that you do not own

and that is not in the area. The dog's owner must determine if you can only track the dog or can track and

train the dog. This method does not require the dog's owner to find and communicate the codes to the

person adding the dog collar device. This method also adds dog information, such as the dog's name,

communication settings, and initial position, from the sending handheld device to your device. The two

handheld devices must be within range 3 m (10 ft.) to share data wirelessly.

This method is helpful when you want to add a dog collar device during a hunt, but you are not near the dog.

For example, the dogs have already been let loose, and you are near the dog owner, who can share the dog

wirelessly (Sharing a Dog Wirelessly, page 8).

Dog Collar Device Setup 7

Adding a Dog to the Alpha Handheld Using Wireless Pairing

1 If the dog collar device is on, turn off the dog collar device (Turning Off the Device, page 6).

2 Hold the power key on the dog collar device until the device emits two series of beeps (about 2 seconds),

and then release the power button.

The status LED flashes rapidly in green. The dog collar device is now ready to be linked, or paired, with a

handheld device.

3 On the handheld device, select Dog List > Add Dog.

4 Select an option:

• If you are near the dog collar device, select Pair Collar, and follow the on-screen instructions.

• To pair a dog collar device by receiving the information from another handheld device, select Receive

from Handheld.

NOTE: To successfully pair the device, the other handheld device must be wirelessly sharing the dog

collar device information (Sharing a Dog Wirelessly, page 8).

5 After successfully adding the dog collar device, enter the name of the dog, and select .

Sharing a Dog Wirelessly

Before you can share data wirelessly over ANT+, you must bring your Alpha handheld device within 3 m (10 ft.)

of the other handheld device.

1 Select Dog List.

2 Select the dog to share.

3 Select > Share Wirelessly.

4 Select an option:

• To allow the other person to track your dog's location with the map and dog tracking compass, select

Track Only.

• To allow the other person to track your dog and correct your dog's behavior, select Track and Train.

To successfully share the dog collar device, the other handheld device must be receiving the device

information (Adding a Dog to the Alpha Handheld Using Wireless Pairing, page 8).

Adding a Dog Using the Track and Control Codes

NOTE: This feature varies based on dog collar device type and feature availability in your area.

Before you can add a dog using the track and control codes, the dog owner must find the track and control

codes (Finding the Dog ID and Track and Control Codes, page 8) and tell them to you.

You can use track and control codes to authorize a handheld device to interact with your dog collar device. If

you are not near the dog you want to add or you cannot put the collar into pairing mode, you can add the dog

using the track and control codes.

1 Select Dog List > Add Dog.

2 Select Enter Track or Control Code.

3 Enter the track or control code for the collar, and select .

The dog’s track code allows you to track the dog. The dog’s control code allows you to both track and train

the dog.

4 Enter the name of the dog, and select .

Finding the Dog ID and Track and Control Codes

You can share a dog’s track code so another person can track your dog. Also, you can share a dog’s control

code so another person can track and train your dog.

1 Select Dog List.

2 Select a dog.

The track code and the control code are displayed under the dog's name.

8 Dog Collar Device Setup

VHF Radio Information

This product may be used only on specific radio frequencies, which vary depending on the country of use. The

handheld device and the dog device allow the user to install a different antenna. Changing the antenna can

result in improved radio performance and higher radiated power. You must not use the device with a third party

antenna or an antenna not approved by Garmin

. Go to www.garmin.com/tracking-legal for details about the

performance and radio frequency of this product, lawful accessories, and power limits for countries.

Managing a Group

Before you can create a group, you must pair one or more dog devices to your handheld.

1 Select Dog List.

2 Select .

3 If necessary, select Create Group, and enter a group name.

4 Select a group from the list.

5 Select an option:

• To activate the group, select Activate Group.

• To deactivate the group, select Deactivate Group.

• To add a device to the group, select Manage Group > Add Device.

• To rename the group, select Rename, and enter a new name.

• To delete the group, select Delete Group.

Editing Dog Information

Resetting a Dog's Statistics and Track

You might want to clear the dog statistics and track before a new hunt.

1 Select Dog List.

2 Select a dog.

3 Select > Reset.

Changing the Dog Name

1 Select Dog List.

2 Select a dog.

3 Select the dog’s name.

4 Enter the name, and select .

Changing the Color of the Dog's Track

You can change the track color of the dog. It is helpful to have the track color match the color of the collar

strap, if possible.

1 Select Dog List.

2 Select a dog.

3 Select the colored square next to the dog’s name.

4 Select a color.

Changing the Dog Type

Before you can change the dog type, the collar must be turned on and within range of the handheld device.

1 Select Dog List.

2 Select a dog.

3 Select > Change Dog Type.

4 Select a dog type.

Dog Collar Device Setup 9

Changing the Dog ID

Before you can change the dog ID, the collar must be turned on and within range of the handheld device.

If you are experiencing interference from other collars or handheld devices in the area, you might need to

change the ID for the dog.

1 Select Dog List.

2 Select a dog.

3 Select > Change ID.

4 Select an available ID.

If another handheld device is tracking this dog, for best results, remove the dog from the device, and use the

track and control codes to add the dog again (Adding a Dog Using the Track and Control Codes, page 8).

Removing a Dog

1 Select Dog List.

2 Select a dog.

3 Select > Remove.

Fitting the Collar on Your Dog

CAUTION

To prevent irritation from the contact points, remove the collar for at least eight hours out of every 24-hour

period.

This device is not intended for human use. Do not attempt to use on any person.

Do not spray the device or collar with harsh chemicals including but not limited to flea or tick spray. Always

ensure that any flea or tick spray that is applied to the dog is completely dry before placing the collar on the

dog. Small amounts of harsh chemicals can damage the plastic components and collar laminate.

In order to effectively train the dog, the collar and device must fit the dog properly. If the collar is too loose or

positioned incorrectly, stimulation may be inconsistent. This can delay or prevent successful training.

1 Position the device at the front of the dog's neck, with the status LED facing toward the dog's chin and the

contact points against the throat.

2 Tighten the strap so that it is very snug around the dog's neck, and fasten the buckle.

NOTE: The collar should fit tightly and should not be able to rotate or slide on the dog's neck. The dog must

be able to swallow food and water normally. You should observe your dog's behavior to verify that the collar

is not too tight.

3 Wiggle the device to work the contact points through the dog's coat.

NOTE: The contact points must have contact with the dog's skin to be effective.

4 If the strap is too long, cut off the excess, leaving at least 8 cm (3 in.) to spare.

TIP: You can mark the hole used to fasten the buckle for future reference.

10 Dog Collar Device Setup

Communication with the Collar

You should keep an unobstructed line of sight between your handheld device and the dog collar device to

produce the best communication signal. To achieve the best line-of-sight conditions, you should move to the

highest elevation point in your area (for example, on the top of a hill).

Best

Good

Poor

Entering Sleep Mode

NOTE: This feature is not available with all dog collar device models.

Before you can enter sleep mode, you must track your dog's location using the compatible dog collar device.

When connected with the handheld device, the dog collar device can be put into sleep mode to conserve the

battery when you are not actively tracking your dog.

1 Select Dog List.

2 Select a dog.

3 Select > Adjust Collar Sleep Mode > Sleep.

Exiting Sleep Mode

NOTE: This feature is not available with all dog collar device models.

You can exit sleep mode on the compatible dog collar device while you are not actively tracking your dog.

1 Select Dog List.

2 Select a dog.

3 Select > Adjust Collar Sleep Mode > Wake.

Dog Tracking

The handheld device allows you to track your dog or multiple dogs, using the tracking compass or map. The

map displays your location and your dog's location and tracks. The compass pointer indicates the direction of

the dog's current location.

Dog Tracking 11

Tracking Your Dog on the Map

Before you can track a dog on the map, you must add it to the handheld device (Adding a Dog to the Alpha

Handheld Using Wireless Pairing, page 8).

You can view the dog's location on the map.

1 From the home screen, select .

2 If necessary, select and to zoom in and out of the map.

TIP: You can select to track the dog using the dog tracking compass (Dog Tracking Compass, page 13).

Dog Status Icons

Sitting

Running

On point

Treed

Unknown

The unknown status icon indicates that the collar has not acquired a satellite signal and that the handheld device cannot determine the location of the dog.

12 Dog Tracking

Dog Tracking Compass

To open the dog tracking compass, select .

You can use the dog tracking compass to view the direction and distance to your dog, your vehicle, and any

paired devices. The dog tracking compass also shows the dog's status, such as running or on point (Dog Status

Icons, page 12). The color of the pointer corresponds to the color of the track.

The dog tracking compass is most accurate when the dog, vehicle, or paired device is more than 9.1 m (30 ft.)

away. When the dog, vehicle, or paired device is less than 9.1 m (30 ft.) away, "Near" appears.

TIP: You can open an alternative view of the compass by selecting > Pro View.

Navigating to Your Dog

1 Select Dog List.

2 Select the dog.

3 Select > Go.

4 Follow the colored line to the dog.

Changing the Length of the Dog's Track

You can adjust the length of time the dog track appears on the map. Reducing the duration of the track can

reduce the clutter on the map. Changing the map does not affect the tracks stored in the handheld device.

1 Select Setup > Map > Tracked Devices > Dog Tracks on Map.

2 Select a time frame.

Location Alerts

Location alerts notify you when your dogs enter or exit a particular location. You can create a custom geofence

or use a radius around your current location.

A geofence is an invisible boundary around an area and is created using points on the map. The virtual

boundaries of a geofence are accurate up to approximately 3 m (10 ft.). Geofences perform best when sized to

cover an area encompassing an average sized backyard (approximately ¼ acre).

Dog Tracking 13

Setting Location Alerts

1 Select Location Alerts > Add Alert.

2 Select an option:

• To create a geofence alert, select Geofence, select a point for the first corner of the geofence, select Use,

and select additional points to define the geofence boundary.

You must select at least 3 points to create a geofence alert.

• To create a radius alert, select Radius, select the unit of measurement, and enter the radius distance.

Editing Location Alerts

1 Select Location Alerts.

2 Select an alert.

3 Select an option:

• Select Disable to turn off notifications for this alert.

• Select Set Alert Type to set the way the device notifies you for this alert.

• Select Set Alert Mode to set the notification to sound on exit, entrance, or both.

• Select View Map to view a geofence on the map.

NOTE: This feature is not available for the radius alert type.

• Select Delete to remove the alert.

Disabling Dog Data Broadcast

By default, the handheld device broadcasts dog data to compatible devices. You can disable data broadcasting

to keep your data from being seen on other compatible devices. See the owner's manual for your compatible

device for more information.

Select Setup > System > Broadcast Dog Data > Off.

Dog Training

NOTICE

You should research and investigate the training methods best suited for you, your dog, and your needs. This

manual provides some basic guidelines for training, but each dog has unique training needs.

When used properly, the Alpha training system is a very effective training tool to aid your dog in reaching its full

potential. The use of the training system should be part of an overall training program.

Begin training your dog on a leash, without the Alpha training system. You should train your dog how to heel, sit,

and come to you. After the dog understands these three basic commands, you can begin training with the dog

collar device and the leash. Finally, when the dog consistently obeys commands using the leash and collar, you

may be able to remove the leash to train with only the dog collar device.

14 Dog Training

Selecting and Installing the Contact Points

CAUTION

To prevent irritation from the contact points, remove the collar for at least eight hours out of every 24-hour

period.

Do not spray the device or collar with harsh chemicals including but not limited to flea or tick spray. Always

ensure that any flea or tick spray that is applied to the dog is completely dry before placing the collar on the

dog. Small amounts of harsh chemicals can damage the plastic components and collar laminate.

For best results, select the correct contact points based on your dog's coat.

1 Select the correct contact point length for your dog's coat type:

• For dogs with thicker coats, use the longer contact points.

• For dogs with shorter coats, use the shorter contact points.

2 If necessary, use the included wrench to remove the contact points.

3 Twist the contact points into the collar.

4 Tighten with the included wrench, but do not overtighten.

When you put the collar on the dog, make sure the contact points are tight against the neck.

Removing the Contact Points

When you are not training the dog using the training keys, remove the contact points.

1 Use the included wrench to remove both contact points.

2 Place the cap over the contact point holes.

Training Methods

NOTE: Training features are not available in all areas for tracking collars.

Momentary stimulation: Applies a brief stimulation when you press the training key, regardless of how long the

key is depressed.

Continuous stimulation: Applies stimulation to the dog the entire time you press the training key, for a

maximum of 8 seconds. Your stimulations should typically be much shorter than 8 seconds.

Tone: Activates an audible tone the entire time you press the training key.

Vibration: Applies vibration to the dog the entire time you press the training key, for a maximum of 8 seconds.

The effectiveness of vibration may vary based on the dog's temperament and experience.

Linear and Traditional Stimulation

You can use linear or traditional stimulation to customize your training experience. The default intensity

method is linear, which allows progressive stimulation from level 1 to level 18. Traditional stimulation allows

you to make quick changes using low, medium, and high settings within predetermined stimulation levels (1

through 6).

Choosing the Correct Intensity Level

1 Set the intensity to the lowest level (Customizing the Training Keys, page 16).

2 Select a training key.

3 Observe the dog for a reaction, such as a head shake, neck movement, or just a change in expression.

Sometimes dogs will vocalize due to the surprise of the electrical stimulation. If the dog vocalizes more than

once, the intensity level is too high for beginning training.

4 If there is no reaction, increase the intensity level by one level until the dog has a slight but recognizable

reaction to the stimulation.

The intensity level that causes a slight but recognizable reaction is your dog's baseline level for beginning collar

training. You do not need to, and should not, apply this intensity selection test again.

After you begin training, the dog’s performance guides your intensity selection. As the dog advances in training,

you may need to change the level depending upon the training situation.

Dog Training 15

Customizing the Training Keys

You can assign an application, device action, or utility to a training key. If a compatible dog collar is paired, you

can also add a dog training command to a training key. You can add multiple pages of training key settings. For

example, this is useful when training multiple dogs.

1 Select Training Setup > Training Keys.

2 Select Add Item Here below the empty key you are customizing.

3 Select a command category.

4 Select a command or, if selecting a training command, select the name of the dog to command.

5 If selecting a dog training command, select momentary (M), continuous (C), tone (T), vibration (V), or light

(L).

6 Select or to choose the intensity level.

7 If you are using traditional stimulation mode, select LOW, MED, or HI.

8 If you want to customize more than three keys, use the additional rows to add another page of training key

commands.

Using the Hard Keys for Training Adjustments

Before you can use this feature, you must customize your training keys with dog training commands

(Customizing the Training Keys, page 16).

You can access and adjust training commands using the device's hard keys.

1 From any screen, press the training up and down keys until the command page you want to adjust appears.

2 Press the training enter key to select the command page.

3 Use the training up and training down keys to highlight the training command you want to change, and press

the training enter key.

4 Select the command mode, and press the training enter key.

5 If necessary, use the training up and down keys to adjust the command setting.

6 Press the training enter key to return to the previous screen.

Default Training Settings

From the main menu, select Training Setup > Training Defaults.

Add When Paired: Automatically sets default training modes for each button when a new dog collar is paired.

Left Button: Sets the default training mode for the left training button.

Center Button: Sets the default training mode for the center training button.

Right Button: Sets the default training mode for the right training button.

16 Dog Training

Collar Training

Begin training your dog on a leash, without using the Alpha training system. After the dog shows a grasp of the

commands "heel," "sit," and "here," you can begin training with the collar and the leash.

During the initial stage of collar introduction, the dog learns that collar stimulation means the same thing as a

tug on the leash. At first, the dog may be alarmed by the electronic stimulation. The key is to be patient and

consistent and not to start off at too high of an intensity. Be fair and consistent, and use repetition and praise

when using the collar as a training tool.

If the dog does not respond to the stimulation level you have selected (Choosing the Correct Intensity Level,

page 15), increase the stimulation one level at a time until you achieve the appropriate response. After you

achieve the desired response, you can lower the stimulation level as long as the dog maintains consistency.

As the dog becomes more proficient with the commands, you can begin to introduce distractions, such as

rolling a ball in front of the dog or walking him in the presence of others.

After the dog begins to respond consistently to the command during collar training, you can remove the leash

and train with just the collar.

NOTE: You should train without a leash only when it is appropriate for your environment and your dog's

temperament. You should follow all laws and regulations for your area regarding the use of dog leashes.

Eventually in most training situations, your commands will not require stimulation to be given with the

command. You should only use stimulation when you need to repeat a command because the dog did not obey

the first one.

As the dog becomes better trained, you can decrease the use of collar training. Continue to have the dog wear

the collar until you feel certain that it is no longer needed to reinforce known commands. Abandoning the collar

too early can lead to problems in the future.

Connected Features

Connected features are available for your Alpha device when you connect the device to a wireless network or a

compatible smartphone using Bluetooth

technology. Some features require you to install the Garmin Explore

™

app on your smartphone. Go to garmin.com/apps for more information.

BirdsEye imagery: Allows you to download BirdsEye Satellite Imagery directly to your device when connected to

a Wi‑Fi

network.

Garmin Explore: The Garmin Explore app syncs and shares waypoints, tracks, and routes with your device. You

can also download maps to your smartphone for offline access.

Software Updates: Allows you to receive updates for your device software when connected to a Wi‑Fi network.

Pairing a Smartphone with Your Device

1 Bring your compatible smartphone within 10 m (33 ft.) of your device.

2 From the main menu on your device, select Setup > Bluetooth.

3 On your compatible smartphone, enable Bluetooth technology, and open the Garmin Explore app.

4 From the Garmin Explore app, select Devices > Pair Device.

5 Follow the on-screen instructions in the Garmin Explore app to pair your device.

Connecting to a Wireless Network

1 Select Setup > Wi-Fi.

2 Select the toggle switch to enable Wi‑Fi technology, if necessary.

3 Select Add Network.

4 Select a wireless network from the list and enter the password, if necessary.

The device stores the network information and connects automatically when you return to this location.

Connected Features 17

Garmin Explore

The Garmin Explore website and mobile app allow you to plan trips and use cloud storage for your waypoints,

routes, and tracks. They offer advanced planning both online and offline, allowing you to share and sync data

with your compatible Garmin device. You can use the mobile app to download maps for offline access, and

then navigate anywhere without using your cellular service.

You can download the Garmin Explore app from the app store on your smartphone, or you can go to

explore.garmin.com.

Contact Tracking

You can track other hunters so you know where they are at all times. You can also send messages to your

contacts. One Alpha handheld device can track up to 20 devices, including compatible dog collar devices and

Alpha handheld devices.

Turning On and Off the Transmitter

Before you can add a contact or initiate an emergency alert, you must ensure the transmitter is enabled.

NOTE: In cold temperatures, if you transmit when the battery is low, the device may shut down.

1 Press to open the status page.

2 Select My ID > Transmitting.

Methods to Add a Contact to a Handheld Device

Using MURS/VHF: Allows you to add a handheld device contact after you have placed your handheld device

into pairing mode.

This method is helpful when you are adding a new device to the system prior to leaving for the hunt (Adding

a Contact Using Wireless Pairing, page 18).

Entering the device ID: Allows you to add a handheld device contact that is not in the area. This method

requires the contact to find and communicate their handheld device code to the person adding the device

contact.

This method is helpful when you would like to add a handheld device contact during a hunt, but you are not

near the device. For example, if you are adding another member of your hunting party to your handheld

device, but you do not own the device (Adding a Contact Using a Contact ID, page 19).

Sharing wirelessly using ANT+ wireless technology: Allows you to add a handheld device that you do not own

as a contact. This method does not require the contact to find and communicate their device code to the

person adding the device. The two handheld devices must be within a range of 3 m (10 ft.) to share data

wirelessly.

This method is helpful when you want to add a handheld device during a hunt without entering the device ID

(Adding a Contact Using Wireless Pairing, page 18).

Adding a Contact Using Wireless Pairing

Before you can add a contact wirelessly, you should be near the contact's handheld device.

1 Select Dog List > .

2 Select an option:

• On your handheld device select Add > Pair Handheld, and follow the on-screen instructions.

• To add a contact by receiving the information from the contact's handheld device, select Add > Receive

from Handheld.

3 After successfully adding the contact, enter the name of the contact, and select .

The contact is added to your handheld device.

You can repeat this procedure using another hunter's handheld device to add your contact ID to that device.

18 Contact Tracking

Adding a Contact Using a Contact ID

Before you can add a hunter using a contact ID, the hunter must find the contact ID (Finding Your Contact ID,

page 19) and send it to you.

If you are not near the hunter you want to add, you can add the hunter using a contact ID.

1 On your handheld device, select Dog List > > Add > Enter ID.

2 Select the contact ID for the contact you are adding.

3 Enter the name of the contact, and select .

The contact is added to your handheld device.

You can repeat this procedure using another hunter's handheld device to add your contact ID to that device.

Initiating an Emergency Alert

Before you can initiate an emergency alert, you must turn on the transmitter (Turning On and Off the

Transmitter, page 18).

Before someone can receive your emergency alert, someone must add you as a contact (Adding a Contact

Using Wireless Pairing, page 18).

You can use an emergency alert when you need immediate assistance and you are away from your group.

Select Dog List > > > Yes.

When your contact accepts your emergency alert request, the device displays a message indicating that

your contact has started navigating to your location.

After receiving the alert, your contacts can navigate to your location.

Sending a Message to Your Contacts

Before you can send a message to your contacts, you must turn on the transmitter (Turning On and Off the

Transmitter, page 18).

You can send and receive automated messages. There are 18 messages you can choose from, such as "Help"

and "I'm Coming."

1 Select Dog List > > Message.

2 Select a message.

The message is sent to your contacts with your name before the message. Anyone tracking your handheld

device receives the message.

Tracking a Contact

You can keep track of contacts' locations using the map.

Select .

Finding Your Contact ID

Press to open the status page.

The contact ID for your handheld device is listed under the My ID option.

Changing Your Contact ID

If you are experiencing interference from other collars or handheld devices in the area, you might need to

change the contact ID for your handheld device.

1 Press to open the status page.

2 Select My ID > ID.

3 Select a contact ID that is not yet assigned to another device in the area.

Each time a contact changes their contact ID, you must update the contact ID in your handheld device

(Updating a Contact ID, page 20).

Contact Tracking 19

Updating a Contact ID

If a contact has changed their contact ID, you can quickly update the contact ID in your handheld device.

1 Select Dog List > .

2 Select the contact.

3 Select > Update ID.

4 Select the contact ID that matches the contact's new contact ID.

Hunting with the Alpha System

You can perform various tasks that can be helpful when you are hunting with the Alpha system.

• Mark your truck's location (Marking Your Truck Location, page 20).

• Track your dogs (Tracking Your Dog on the Map, page 12).

• Track your fellow hunters (Tracking a Contact, page 19).

• Mark the location of a covey (Marking a Covey, page 20).

• View your active hunt metrics (Active Hunt Metrics, page 20).

• Send messages to your fellow hunters (Sending a Message to Your Contacts, page 19).

• Turn on the collar light (Turning On the Collar Light, page 20).

• Put the collar into rescue mode to save battery power (Turning On Rescue Mode, page 21).

• Pause tracking while you move the dogs (Pausing Dog Tracking, page 21).

Marking Your Truck Location

You can mark the location of the truck, so you can navigate back to your truck after the hunt.

1 Select Mark Waypoint > Truck.

2 Select Save.

Marking a Covey

You can mark a covey location and enter the estimated number of birds flushed and the number of birds taken.

1 Select Mark Waypoint > Covey.

2 Enter the number of birds flushed, the number of birds taken, and select OK.

3 Review and edit location information (optional).

4 Select Save.

Active Hunt Metrics

You can select Hunt from the main menu to view the active hunt metrics. The active hunt metrics page displays

the active hunt time and distance traveled for your handheld device and each paired dog collar device. It also

shows the dog status, such as on point, treed, or barking, if available. When you select End Hunt, the hunt timer

and distance traveled stop recording.

Turning On the Collar Light

You can turn on the LEDs on the collar at night to help locate a dog or to warn drivers if a dog wanders near a

road. The light is visible for up to 100 yards.

1 Select Dog List.

2 Select a dog.

3 Select Adjust Collar Light.

4 Select Continuous, Blink Slow, or Blink Fast.

TIP: Select different light setting for each dog to help you identify the dogs in the field.

20 Hunting with the Alpha System

Turning On Rescue Mode

You can turn on rescue mode to conserve battery power at the end of a long hunt or if your dog might get out of

range.

1 Select Dog List.

2 Select a dog.

3 Select > Rescue Mode.

After you have turned on rescue mode, it stays on until you turn it off.

When the collar battery power falls below 25%, the collar data updates only once every 2 minutes.

Pausing Dog Tracking

You can pause the tracking of a single dog during a hunt. This can be helpful if the dog is taking a break.

1 Select Dog List.

2 Select a dog.

3 Use the Active toggle switch to turn tracking on and off.

Waypoints, Routes, and Tracks

Waypoints

Waypoints are locations you record and store in the device. Waypoints can mark where you are, where you are

going, or where you have been. You can add details about the location, such as name, elevation, and depth.

You can add a .gpx file that contains waypoints by transferring the file to the GPX folder (Connecting the

Handheld Device to a Computer, page 36).

Marking Your Current Location

1 Select Mark Waypoint.

2 Select an option:

• Select New.

• Select a default location name, such as Truck or Camp.

3 Edit the location information (optional).

4 Select Save.

Marking a Waypoint Using the Map

1 Select .

2 Select a location on the map.

3 Select the information bar at the top of the screen.

4 Select > OK.

Editing a Waypoint

Before you can edit a waypoint, you must create a waypoint.

1 From the main menu, select Waypoint Manager.

2 Select a waypoint.

3 Select an item to edit, such as the name.

4 Enter the new information.

Waypoints, Routes, and Tracks 21

Repositioning a Waypoint to Your Current Location

You can change the position of a waypoint. For example, if you move your vehicle, you can change the location

to your current position.

1 Select Waypoint Manager.

2 Select a waypoint.

3 Select > Reposition Here.

The waypoint location changes to your current location.

Moving a Waypoint on the Map

1 Select Waypoint Manager.

2 Select a waypoint.

3 Select > Move Waypoint.

4 Select the new location on the map.

5 Select Move.

Increasing the Accuracy of a Waypoint Location

You can refine a waypoint location for more accuracy. When averaging, the device takes several readings at the

same location and uses the average value to provide more accuracy.

1 Select Waypoint Manager.

2 Select a waypoint.

3 Select > Average Location.

4 Move to the waypoint location.

5 Select Start.

6 Follow the on-screen instructions.

7 When the confidence status bar reaches 100%, select Save.

For best results, collect 4 to 8 samples for the waypoint, waiting at least 90 minutes between samples.

Projecting a Waypoint

You can create a new location by projecting the distance and bearing from a marked location to a new location.

1 Select Waypoint Manager.

2 Select a waypoint.

3 Select > Project Waypoint.

4 Enter the bearing, and select .

5 Select a unit of measure.

6 Enter the distance, and select .

7 Select Save.

Deleting a Waypoint

1 Select Waypoint Manager.

2 Select a waypoint.

3 Select > Delete > Delete.

Routes

A route is a sequence of waypoints or locations that leads you to your final destination.

22 Waypoints, Routes, and Tracks

Creating a Route

1 Select Route Planner > Create Route > Select First Point.

2 Select a category.

3 Select the first point on the route.

4 Select Use > Select Next Point.

5 Select a point.

6 Repeat steps 3 through 5 to add all the points in the route.

Editing the Name of a Route

1 Select Route Planner.

2 Select a route.

3 Select Change Name.

4 Enter the new name, and select .

Navigating a Saved Route

1 Select Route Planner.

2 Select a route.

3 Select View Map > Go.

Editing a Route

1 Select Route Planner.

2 Select a route.

3 Select Edit Route.

4 Select a point.

5 Select an option:

• To view the point on the map, select Review.

• To change the order of the points on the route, select Move Up or Move Down.

• To insert an additional point on the route, select Insert.

The additional point is inserted before the point you are editing.

• To remove the point from the route, select Remove.

Reversing a Route

1 Select Route Planner.

2 Select a route.

3 Select Reverse Route.

Viewing the Active Route

1 Select Active Route.

2 Select a point in the route to view additional details.

Deleting a Route

1 Select Route Planner.

2 Select a route.

3 Select Delete Route.

Recordings

Your device records your path as an activity. Activities contain information about points along your recorded

path, including time, location, and elevation for each point.

Waypoints, Routes, and Tracks 23

Recording Track Logs

By default, the device automatically starts recording your path as a track when it is turned on and has acquired

satellite signals. You can pause and start recording manually.

1 Select Track Manager > My Track.

2 Select an option:

• To control the current track recording, select the current track tab.

• To view data fields for the track, select the information tab.

• To view the current track on the map, select the map tab.

• To view the elevation plot for the current track, select the elevation plot tab.

Viewing Details about the Track

1 Select Track Manager.

2 Select a track.

3 Select .

The beginning and the end of the track are marked by flags.

4 Select the information bar along the top of the screen.

Information about the track is listed.

Viewing the Elevation Plot of a Track

1 Select Track Manager.

2 Select a track.

3 Select .

Navigating to the Start of a Track

You can navigate back to the beginning of a track. This can be helpful when finding your way back to camp or

the trail head.

1 Select Track Manager > My Track > .

2 Select TracBack.

Changing the Track Color

1 Select Track Manager.

2 Select a track.

3 Select > Color.

4 Select a color.

Saving the Current Track

1 From the main menu, select Track Manager.

2 Select My Track > Save.

Clearing the Current Track

Select Track Manager > My Track > Discard.

Deleting a Track

1 Select Track Manager.

2 Select a track.

3 Select > Delete.

24 Waypoints, Routes, and Tracks

Navigation

You can navigate routes and tracks to a waypoint, geocache, or any saved location in the device. You can use

the map or the compass to navigate to your destination.

Map

represents your location on the map. As you travel, the icon moves and leaves a track log. Waypoint names

and symbols appear on the map. When you are navigating to a destination, your route is marked with a line on

the map.

When the map orientation is Track Up, objects on the map appear to rotate around your position. As you travel,

the entire map reorients in the direction you are facing. You can stabilize the objects by setting the orientation

to North Up (Map Settings, page 29).

To open the map, select .

Measuring Distance on the Map

You can measure the distance between two locations.

1 From the map, select a location.

2 Select > Measure Distance > Use.

3 Move the pin to another location on the map.

Compass

The handheld device has a 3-axis, tilt-compensated compass. You can use a bearing pointer or a course pointer

to navigate to your destination.

Calibrating the Compass

NOTICE

Calibrate the electronic compass outdoors. To improve heading accuracy, do not stand near objects that

influence magnetic fields, such as vehicles, buildings, and overhead power lines.

You should calibrate the compass after moving long distances, experiencing temperature changes, or removing

the battery.

1 Select Compass > > Calibrate Compass > Start.

2 Follow the on-screen instructions.

Navigating with the Bearing Pointer

When navigating to a destination, points to your destination, regardless of the direction you are moving.

1 While navigating to a destination, select Compass.

2 Turn until points toward the top of the compass, and continue moving in that direction to the destination.

Where To? Menu

You can use the Where To? menu to find a destination to navigate to. Not all Where To? categories are

available in all areas and maps.

Finding a Waypoint by Name

1 Select Navigation > Where To? > Waypoints > > Spell Search.

2 Enter the name.

3 Select .

Navigation 25

Navigating with Sight 'N Go

You can point the device at an object in the distance, lock in the direction, and navigate to the object.

1 Select Navigation > Compass > > Sight 'N Go.

2 Point the device at an object.

3 Select Lock Direction > Set Course.

Elevation Plot

By default, the elevation plot displays the elevation for an elapsed time.

To open the elevation plot, select Track Manager > My Track > .

Calibrating the Barometric Altimeter

You can calibrate the barometric altimeter manually if you know the correct elevation or the correct barometric

pressure.

1 Go to a location where the elevation or barometric pressure is known.

2 Select Track Manager > My Track > > > Altimeter Setup > Calibrate Altimeter.

3 Follow the on-screen instructions.

Navigating to a Point on the Plot

1 Select Track Manager > My Track > .

2 Select an individual point on the plot.

3 Select > View Map.

4 Select Go.

Changing the Plot Type

You can change the elevation plot to display pressure and elevation over time or distance.

1 Select Track Manager > My Track > > > Altimeter Setup > Plot Type.

2 Select an option.

Resetting the Elevation Plot

Select Track Manager > My Track > > > Reset.

Trip Computer

The trip computer displays your current speed, average speed, maximum speed, trip odometer, and other

helpful statistics. You can customize the trip computer layout, dashboard, and data fields (Customizing the Trip

Computer Data Fields, page 26).

To open the trip computer, select Trip Computer.

Customizing the Trip Computer Data Fields

1 Select Navigation > Trip Computer.

2 Select a data field to customize.

3 Select a category or select All Categories.

4 Select the new data field.

For data field descriptions, see Data Field Options, page 44.

Resetting the Trip Computer

For more accurate trip information, reset the trip computer before beginning a trip.

Select Navigation > Trip Computer > > Reset Trip.

26 Navigation

Applications

Additional device features can be found in the applications. You can customize the main menu to display

additional applications (Customizing the Main Menu, page 28).

Setting a Proximity Alarm

Proximity alarms alert you when you or your dogs are within a specified range of a particular location. A tone

sounds when you enter the designated radius.

1 Select Proximity Alarms.

2 Select Create Alarm.

3 Select a category.

4 Select a location.

5 Select Use.

6 Enter a radius.

When you enter an area with a proximity alarm, the device sounds a tone.

Calculating the Size of an Area

1 Select Area Calculation > Start.

2 Walk around the perimeter of the area you want to calculate.

3 When finished, select Calculate.

Setting an Alarm

1 Select Alarm Clock.

2 Select and to set the time.

3 Select Turn Alarm On.

The alarm sounds at the selected time. If the device is off at the alarm time, the device turns on and sounds the

alarm.

Using the Competition Timer

1 Select Competition Timer.

2 Select an option:

• Select to start and pause the competition timer.

• Select to reset the competition timer.

• Select to set the competition timer duration and alerts.

• Select from the list to create a customized timer that counts up from zero.

Satellite Page

The satellite page shows your current location, GPS accuracy, satellite locations, and signal strength.

Changing the Satellite View

By default, the satellite view is with North at the top. You can change the view of the satellites to be oriented

with your current track toward the top of the screen.

Select Satellite > > Track Up.

Turning Off GPS

Select Satellite > > Satellite Setup > Satellite System > Demo Mode.

Applications 27

Simulating a Location

1 Select Satellite > > Satellite Setup > Satellite System > Demo Mode.

2 Select > Set Location On Map.

3 Select a location.

4 Select Use.

Downloading BirdsEye Imagery

Before you can download BirdsEye imagery directly to your device, you must connect to a wireless network

(Connecting to a Wireless Network, page 17).

1 Select BirdsEye Direct > Download Imagery.

2 Select an option:

• To download BirdsEye imagery files for a specific location or area, select Location, and select a category.

NOTE: The location defaults to your current location.

• To edit the name of the downloaded imagery files, select Name.

• To select an image quality option, select Detail.

• To define the size of the area to be shown in the downloaded imagery files, select Radius, and enter a

distance from the selected location.

An estimated file size appears for the selected image quality and radius. You should verify your device has

enough available storage space for the imagery file.

3 Select Download.

Customizing Your Device

Customizing the Main Menu

1 From the main menu, select Setup > Main Menu.

2 Select an option:

• To move a menu item, select a menu item, and select a new location.

• To delete a menu item from the list, select a menu item, and select Remove.

• To add a new menu item to the list, or to place an item on the list after you have removed it, select Add

Item Here.

• To reset the order of all items in the menu, select > Restore Defaults.

Customizing the Data Fields

You can customize the data fields and dashboards of the map, compass, elevation plot, and trip computer.

1 Open the page for which you will change the data fields.

2 Select a data field to customize.

3 Select the new data field.

For data field descriptions, see Data Field Options, page 44 .

28 Customizing Your Device

System Settings

Select Setup > System.

Satellite: Sets the satellite system options and enables or disables the use of Wide Area Augmentation

System/European Geostationary Navigation Overlay Service (WAAS/EGNOS) data.

Language: Sets the text language on the device.

NOTE: Changing the text language does not change the language of user-entered data or map data, such as

street names.

Mass Storage Mode: Sets whether your device goes into mass storage mode when it is connected to the

computer.

Broadcast Dog Data: Automatically sends dog data to compatible devices.

Units: Sets the units of measure.

Time: Sets the time zone and format.

Display Settings

Select Setup > Display.

Backlight Timeout: Adjusts the length of time before the backlight turns off.

Battery Save: Saves the battery power and prolongs the battery life by turning off the screen when the backlight

times out (Turning On the Handheld Battery Save Mode, page 35).

Appearance: Sets the displayed accent colors for day and night.

Screen Capture: Allows you to save the image on the device screen.

Accessibility: Adds or changes device features to make your device more accessible (Accessibility Settings,

page 29).

Accessibility Settings

Select Setup > Display > Accessibility.

Touch Sensitivity: Sets the touchscreen sensitivity.

Review Text Size: Adjusts the size of the text.

Scroll Controls: Adds scroll arrows to the screen when a menu, list, or grid is scrollable.

Setting the Device Tones

You can customize tones for messages, keys, warnings, and alarms.

1 Select Setup > Tones & Alerts.

2 Select a tone for each audible type.

Setting Dog Alerts

You can adjust how the handheld device alerts you to certain actions of the dog.

1 Select Setup > Tones & Alerts > Dog Alerts.

2 Select an action.

3 Select the method the device uses to alert you for this action.

Map Settings

Select Setup > Map.

Configure Maps: Enables or disables the maps currently loaded on the device.

Tracked Devices: Opens the map settings options for tracked devices (Tracked Devices Map Settings,

page 30).

Show Training Bar: Displays the training bar on the map.

Show Data Fields: Displays configurable data fields on the map.

Advanced: Opens the advanced map settings (Advanced Map Settings, page 30).

Customizing Your Device 29

Tracked Devices Map Settings

Select Setup > Map > Tracked Devices.

Auto Zoom: Allows the map to zoom out automatically, so the selected devices are always displayed on the

map.

Dog Tracks on Map: Determines how much of the track log for a tracked dog collar appears on the map.

Handheld Tracks on Map: Determines how much of the track log for a tracked handheld device appears on the

map.

Dog Display: Enables and disables the dog information shown on the map.

Show Offscreen Dogs: Enables or disables the offscreen dog indicator on the map.

Advanced Map Settings

Select Setup > Map > Advanced.

Orientation: Adjusts how the map is shown on the page. North Up shows North at the top of the page. Track Up

shows your current direction of travel toward the top of the page. Automotive Mode shows an automotive

perspective with the direction of travel at the top.

Shaded Relief: Shows detail relief on the map (if available) or turns off shading.

Map Pointer: Displays the directional pointer on the map.

Text Size: Sets the text size for map items.

Tracks Settings

Select Setup > Tracks.

Record Method: Sets how the device records track data. The Smart recording option allows for longer track

recordings. The Every Second recording option provides more detailed track recordings, but may not record

entire tracks that last for longer periods of time.

Auto Save: Allows you to customize the Auto Save settings (Auto Save Settings, page 30).

Auto Start: Starts recording a track automatically when the device acquires satellites.

Auto Save Settings

When Full: Automatically saves the current recording and starts a new one when the current recording is near

20,000 track points.

Daily: Automatically saves the previous day's recording and starts a new one when you turn on the device

during a new day.

Weekly: Automatically saves the previous week's recording and starts a new one when you turn on the device

during a new week.

Auto: Automatically saves the current recording based on its length and the number of track points taken.

Never: Never saves the current recording automatically. When the current recording nears 20,000 track points,

the device filters the active track to remove redundant points while retaining the shape and history of the

recording. Unfiltered points are saved in a temporary GPX and FIT file that is saved or discarded when the

recording stops.

NOTE: When importing FIT activities or GPX tracks with more than 20,000 track points, the device filters the

line to fit in the device memory and improve map drawing performance, while retaining the shape and history

of the recording. The FIT and GPX files retain all of their original track points.

30 Customizing Your Device

Routing Settings

The available routing settings vary based on whether Direct Routing is enabled or disabled.

Select Setup > Routing.

Direct Routing: Enables or disables direct routing. Direct routing calculates the most direct route possible to

the destination.

Activity: Sets an activity while routing. The device calculates routes optimized for the type of activity you are

doing.

Calculation Method: Sets the method used to calculate your route.

Lock On Road: Locks the blue triangle, which represents your position on the map, onto the nearest road. This

is most useful when driving or navigating on roads.

Off Route Recalculation: Sets recalculation preferences when navigating away from an active route.

Avoidance Setup: Sets the types of roads, terrain, and transportation methods to avoid while navigating.

Route Transitions: Sets how the device routes from one point on the route to the next. This setting is available

only for some activities. The Distance option routes you to the next point on the route when you are within a

specified distance of your current point.

Sensors Settings

Select Setup > Sensors.

Tempe Sensor: Allows you to pair a tempe

™

sensor and turn a paired tempe sensor on and off.

Xero: Allows you to enable or disable your sharing status and make sharing public or private.

NOTE: You can share your location from a compatible Xero

device.

Changing the Units of Measure

You can customize units of measure for distance and speed, elevation, and temperature.

1 Select Setup > System > Units.

2 Select a measurement type.

3 Select a unit of measure for the setting.

Position Format Settings

NOTE: You should not change the position format or the map datum coordinate system unless you are using a

map or chart that specifies a different position format.

Select Setup > System > Units > Position Format.

Position Format: Sets the position format in which a location reading appears.

Map Datum: Sets the coordinate system on which the map is structured.

Map Spheroid: Shows the coordinate system the device is using. The default coordinate system is WGS 84.

Device Information

Viewing E-label Regulatory and Compliance Information

The label for this device is provided electronically. The e-label may provide regulatory information, such as

identification numbers provided by the FCC or regional compliance markings, as well as applicable product and

licensing information.

1 Select Setup.

2 Select About.

Device Information 31

Support and Updates

• You can update software and maps for your handheld device and compatible dog collar device using Garmin

Express

™

• Go to support.garmin.com for FAQs, videos, and more information.

Product Updates

On your computer, install Garmin Express (www.garmin.com/express).

This provides easy access to these services for Garmin devices:

• Software updates

• Map updates

• Product registration

Device Care

NOTICE

Do not store the device where prolonged exposure to extreme temperatures can occur, because it can cause

permanent damage.

Never use a hard or sharp object to operate the touchscreen, or damage may result.

Avoid chemical cleaners, solvents, and insect repellents that can damage plastic components and finishes.

Secure the weather cap tightly to prevent damage to the USB port.

Avoid extreme shock and harsh treatment, because it can degrade the life of the product.

Cleaning the Device

NOTICE

Even small amounts of sweat or moisture can cause corrosion of the electrical contacts when connected to a

charger. Corrosion can prevent charging and data transfer.

1 Wipe the device using a cloth dampened with a mild detergent solution.

2 Wipe it dry.

After cleaning, allow the device to dry completely.

Cleaning the Touchscreen

1 Use a soft, clean, lint-free cloth.

2 If necessary, lightly dampen the cloth with water.

3 If using a dampened cloth, turn off the device and disconnect the device from power.

4 Gently wipe the screen with the cloth.

32 Device Information

Specifications

Alpha Handheld Device Specifications

Battery type Rechargeable, replaceable lithium-ion

Battery life Up to 20 hr.

Operating temperature range From -20° to 60°C (from -4° to 140°F)

Charging temperature range From 0° to 45°C (from 32° to 113°F)

Long-term storage temperature range From 0° to 25°C (from 32° to 77°F)

VHF wireless range Up to 14.5 km (9 mi.)

ANT+ low power wireless range About 3 m (10 ft.)

Wireless frequencies/protocols 152-169 MHz @ 32.5 dBm maximum, 2.4 GHz @ 14.8 dBm maximum

SAR (body) 0.66 W/kg simultaneous

Water rating IEC 60529 IPX7

Dog Collar Device Specifications

Battery type Rechargeable, replaceable lithium-ion

Battery life

From 20 to 40 hr.

Battery life is determined by the handheld device in use.

Operating temperature range From -20° to 60°C (from -4° to 140°F)

Charging temperature range From 0° to 40°C (from 32° to 104°F )

ANT

wireless range Up to 10 m (32.8 ft.)

VHF radio range Up to 14.48 km (9 mi.)

Wireless frequencies/protocols 152-155 MHz @ 31.6 dBm maximum, 2.4 GHz @ 23.1 dBm maximum

Water rating 1 ATM

Mini Dog Collar Device Specifications

Battery type Rechargeable, replaceable lithium-ion

Battery life Up to 16 to 30 hr., typical use

Operating temperature range From -20° to 60°C (from -4° to 140°F)

Charging temperature range From 5° to 40°C (from 41° to 104°F)

ANT wireless range Up to 5 m (16.4 ft.)

VHF radio range Up to 6.44 km (4 mi.)

Wireless frequencies/protocols 152-155 MHz @ 31.6 dBm maximum, 2.4 GHz @ 23.1 dBm maximum

Water rating 1 ATM

Only for use with Garmin part number 361-00053-04.

The device withstands incidental exposure to water of up to 1 m for up to 30 min. For more information, go to www.garmin.com/waterrating.

The device withstands pressure equivalent to a depth of 10 m. For more information, go to www.garmin.com/waterrating.

Device Information 33

Battery Information

WARNING

This product contains a lithium-ion battery. To prevent the possibility of personal injury or product damage

caused by battery exposure to extreme heat, store the device out of direct sunlight.

Do not use a sharp object to remove batteries.

CAUTION

Contact your local waste disposal department to properly recycle the batteries.

Long-Term Storage

NOTICE

The normal long-term decrease in the charging capacity of lithium-ion batteries can be accelerated by exposure

to elevated temperatures. Storing a fully charged device in a location with a temperature outside the long-term

storage temperature range can significantly reduce its recharging capacity.

When you do not plan to use the handheld device for several months, the battery should be removed. Stored

data is not lost when the battery is removed.

When you do not plan to use the collar for several months, the battery should be charged to about 50%. The

device should be stored in a cool, dry place with temperatures around the typical household level. After storage,

the collar should be fully recharged before use.

Maximizing the Battery Life

You can do several things to extend the life of the batteries in the handheld device and collar.

• Reduce the backlight brightness (Adjusting the Backlight Brightness, page 34).

• Reduce the backlight timeout (Adjusting the Backlight Timeout, page 34).

• Turn off the transmitter (Turning On and Off the Transmitter, page 18).

• Use battery save mode (Turning On the Handheld Battery Save Mode, page 35).

• Put the dog collar device into rescue mode to conserve the collar battery (Turning On Rescue Mode,

page 21).

• Extend the duration for the collar update rate to conserve the collar battery (Changing the Dog Collar Device

Update Rate, page 35).

Adjusting the Backlight Brightness

Extensive use of screen backlighting can significantly reduce battery life. You can adjust the backlight

brightness to maximize the battery life.

NOTE: The backlight brightness may be limited when the battery is low.

1 Select .

2 Use the slider bar to adjust the backlight brightness.

The device may feel warm when the backlight setting is high.

Adjusting the Backlight Timeout

You can decrease the backlight timeout to maximize the battery life.

1 Select Setup > Display > Backlight Timeout.

2 Select an option.

34 Device Information

Changing the Dog Collar Device Update Rate

Before you can change the collar update rate, the collar must be turned on and within range of the handheld

device.

You can select a longer duration for the update rate to conserve battery power.

1 Select Dog List.

2 Select a dog.

3 Select Update Rate.

4 Select an option.

Turning On the Handheld Battery Save Mode

You can use battery save mode to prolong the battery life.

Select Setup > Display > Battery Save > On.

When in battery save mode, the screen shuts off when the backlight times out.

Saving Energy While Charging the Device

You can turn off the device display and all other features while charging.

1 Connect your device to an external power source.

The remaining battery capacity appears.

2 Hold the power key for 4 to 5 seconds.

The display turns off, and the device goes into a low power, battery charging mode.

3 Charge the device completely.

Data Management

The device has a memory card slot for additional data storage.

NOTE: The device is compatible with Windows

7 and newer, and Mac

OS 10.4 and newer.

Device Information 35

Installing a Memory Card

WARNING

Do not use a sharp object to remove user-replaceable batteries.

You can install a microSD memory card in the handheld device for additional storage or pre-loaded maps.

1 Turn the D-ring counter-clockwise, and pull up to remove the cover.

2 Remove the battery.

3 Slide the card holder to the left and lift up.

4 Place the memory card with the gold contacts facing down.

5 Close the card holder.

6 Slide the card holder to the right to lock it.

7 Replace the battery and cover.

Connecting the Handheld Device to a Computer

NOTICE

To prevent corrosion, thoroughly dry the USB port, the weather cap, and the surrounding area before charging or

connecting to a computer.

1 Lift the weather cap .

2 Plug the small end of the USB cable into the USB connector on the device.

3 Plug the other end of the USB cable into an available USB port on the computer.

Your device appears as a removable drive in My Computer on Windows computers and as mounted

volumes on Mac computers.

36 Device Information

Connecting the Collar to a Computer

NOTICE

To prevent corrosion, you should dry the contacts on the collar and the surrounding area before connecting the

charging clip.

1 Snap the charging clip onto the collar.

2 Plug the small end of the USB cable into the USB port on the charging clip cable.

3 Plug the other end of the USB cable into a USB port on the computer.

Transferring Dog Tracks to BaseCamp

™

You can transfer the dog tracks to BaseCamp.

1 Connect the dog collar device to the computer (Connecting the Collar to a Computer, page 37).

The dog collar device turns on automatically.

2 Select on the dog collar device.

3 Open BaseCamp.

BaseCamp recognizes the device.

4 Select Device > Receive from Device.

5 Select the dog collar device from the list, and click OK.

BaseCamp creates a folder of transferred data in My Collection.

Deleting Files

NOTICE

If you do not know the purpose of a file, do not delete it. Your device memory contains important system files

that should not be deleted.

1 Open the Garmin drive or volume.

2 If necessary, open a folder or volume.

3 Select a file.

4 Press the Delete key on your keyboard.

NOTE: If you are using an Apple

computer, you must empty the Trash folder to completely remove the files.

Disconnecting the USB Cable

If your device is connected to your computer as a removable drive or volume, you must safely disconnect your

device from your computer to avoid data loss. If your device is connected to your Windows computer as a

portable device, it is not necessary to safely disconnect the device.

1 Complete an action:

• For Windows computers, select the Safely Remove Hardware icon in the system tray, and select your

device.

• For Apple computers, select the device, and select File > Eject.

2 Disconnect the cable from your computer.

Resetting Data and Settings

The device offers options for deleting your user data and resetting all settings to the factory default values.

1 Select Setup > Reset.

2 Select an option:

• To reset all settings to the default values and save all user-entered information, select Reset All Settings.

• To delete all user data and reset all settings to the factory default values, select Delete All.

Device Information 37

Appendix

Accessories and Replacement Parts

Purchasing Accessories

• Optional accessories are available at garmin.com or from your Garmin dealer.

Optional Maps

You can use additional maps with the device, such as BirdsEye satellite imagery, City Navigator

, and Garmin

HuntView

™

Plus detailed maps. Detailed maps may contain additional points of interest, such as restaurants or

marine services. For more information, go to buy.garmin.com or contact your Garmin dealer.

tempe

The tempe is an ANT+ wireless temperature sensor. You can attach the sensor to a secure strap or loop where

it is exposed to ambient air, and therefore, provides a consistent source of accurate temperature data. You

must pair the tempe with your device to display temperature data from the tempe.

Tips for Pairing ANT+ Accessories with Your Garmin Device

• Verify that the ANT+ accessory is compatible with your Garmin device.

• Before you pair the ANT+ accessory with your Garmin device, move 10 m (33 ft.) away from other ANT+

accessories.

• Bring the Garmin device within range 3 m (10 ft.) of the ANT+ accessory.

• After you pair the first time, your Garmin device automatically recognizes the ANT+ accessory each time it is

activated. This process occurs automatically when you turn on the Garmin device and only takes a few

seconds when the accessories are activated and functioning correctly.

• When paired, your Garmin device receives data from only your accessory, and you can go near other

accessories.

38 Appendix

Dog Collar Device Battery Replacement Instructions

Dog Collar Device Components

Back plate

Power key

Battery connector

Battery cover

Battery

Power connector

Removing the Old Battery

Before you replace the battery, you must remove all dirt, water, and debris from the device. You must also have

a small Phillips screwdriver.

1 Remove the six screws from the outer edges of the back plate.

NOTE: You should leave the two inner screws in place.

2 Pry off the back plate.

3 Disconnect the battery connector and power connector.

4 Remove the screws that secure the battery cover.

5 Remove the battery cover and the battery.

Remember the orientation of the battery. You must install the new battery the same way.

After you remove the old battery, contact your local waste disposal department to properly recycle the battery.

Appendix 39

Installing the New Battery

Before you replace the battery, you must remove the old battery (Removing the Old Battery, page 39). You also

must have a small Phillips screwdriver. You may need a small flat screwdriver.

1 Install the new battery using the same orientation as the old battery.

The connector should face the end nearest the power key, and the bump where the wires connect to

the battery should face toward the side with the charging clip contacts.

2 Replace the battery cover.

3 Replace the screws to secure the battery cover.

4 Connect the battery connector and power connector.

You may need to use a flat screwdriver to help secure the connectors.

5 Select the power key to test the connections.

When properly connected, a tone is emitted and the status LED blinks green.

6 Turn off the device.

7 Verify the gasket located inside the bottom cover is fully seated.

8 Replace the back plate.

9 Replace the six screws to secure the back plate.

After you install the new battery, charge the collar completely.

40 Appendix

Replacing the Mini Dog Collar Device Battery

Before you can replace the battery, you must remove all dirt, water, and debris from the device. You also need a

small Phillips screwdriver and the security screwdriver included in the battery replacement kit.

1 Remove the screws from the L-shaped cover over the VHF antenna.

2 Pry off the L-shaped cover.

3 Remove the screws from the outer edges of the back plate.

4 Pry off the back plate.

5 Grip the battery connector wires close to the connector, and pull the connector perpendicular to the circuit

board to disconnect the battery connector from the device.

6 Grip the power connector wires close to the connector, and pull the connector parallel to the circuit board to

disconnect the power connecter from the device.

7 Remove the screws from the battery plate.

8 Remove the battery plate.

9 Remove the battery.

The battery fits tightly. It may be necessary to pry the battery out of the back plate using a non-sharp, non-

metal object.

10 Install the new battery into the front enclosure with the label side of the battery facing up, and the leading

edge of the battery placed under the charging contact ledge of the device.

11 Replace the battery plate, and replace and tighten the two screws.

12 Verify the gasket is not damaged and is completely seated in the groove.

13 Connect the battery connector and the power connector to the device.

When properly installed, the connector plugs snap into the ports.

14 Replace the back plate, and replace and tighten the screws to secure the back plate.

15 Replace the L-shaped cover, and replace and tighten the screws to secure the L-shaped plate.

16 Verify the gasket is not sticking out of the device.

Replacing the Collar Strap

Before you replace the collar strap, you must remove all dirt, water, and debris from the device (Cleaning the

Device, page 32).

1 Pull the collar strap out of the GPS antenna, antenna guide, and the dog device.

You may need to push and pull the collar strap to properly remove it. You may need to loosen the screw on

the GPS antenna case, but do not remove them.

2 Thread the new collar strap through the dog device, antenna guide, and GPS antenna.

3 If necessary, tighten the screws that secure the GPS antenna case.

Appendix 41

Replacing the VHF Antenna in the Dog Collar Device

NOTICE

Do not excessively bend the band that connects the main device case with the GPS antenna.

When the L-shaped cover is removed, do not disturb the sealant opposite the VHF antenna, because this can

damage the waterproof seal of the dog collar device.

Before you replace the VHF antenna, you must remove all dirt, water, and debris from the device (Cleaning the

Device, page 32). Also, you need a small Phillips screwdriver.

1 Remove the 4 screws from the L-shaped cover over the VHF antenna.

NOTE: You should note the location of the one short screw.

2 Pry off the L-shaped cover.

3 Remove the screw securing the VHF antenna to the back plate.

4 Pull the length of the antenna from the antenna guide to remove the old antenna.

5 Loop the antenna guide around the collar strap, and thread the new VHF antenna through the guide.

This helps to point the antenna up.

6 Replace the screw securing the VHF antenna to the back plate.

7 Replace the L-shaped cover over the VHF antenna.

8 Replace the 4 screws on the L-shaped cover, replacing the short screw in the correct location.

42 Appendix

Changing the Fuse in the Vehicle Power Cable

NOTICE

When replacing the fuse, do not lose any of the small pieces and make sure they are put back in the proper

position. The vehicle power cable does not work unless it is assembled correctly.

If your device does not charge in your vehicle, you may need to replace the fuse located at the tip of the vehicle

adapter.

1 Rotate the end piece counter clockwise to unlock it.

TIP: You may need to use a coin to remove the end piece.

2 Remove the end piece, the silver tip , and the fuse .

3 Insert a new fast-blow fuse that has the same current, such as 1 A or 2 A.

4 Place the silver tip in the end piece.

5 Push in the end piece and rotate it clockwise to lock it back into the vehicle power cable .

Appendix 43

Data Field Options

24 hr. Max. Temperature: The maximum temperature recorded in the last 24 hours.

24 hr. Min. Temperature: The minimum temperature recorded in the last 24 hours.

Accuracy of GPS: The margin of error for your exact location. For example, your GPS location is accurate to

within +/- 12 ft. (3.65 m).

Alarm Timer: The current time of the countdown timer.

Ambient Pressure: The uncalibrated environmental pressure.

Ascent - Average: The average vertical distance of ascent since the last reset.

Ascent - Maximum: The maximum rate of ascent in feet per minute or meters per minute since the last reset.

Ascent - Total: The total elevation distance ascended since the last reset.

Automotive Turn: The direction of the next turn in the route. You must be navigating for this data to appear.

Average Lap: The average lap time for the current activity.

Barometer: The calibrated current pressure.

Battery Level: The remaining battery power.

Bearing: The direction from your current location to a destination. You must be navigating for this data to

appear.

Calories: The amount of total calories burned.

Compass Heading: The direction you are moving based on the compass.

Course: The direction from your starting location to a destination. Course can be viewed as a planned or set

route. You must be navigating for this data to appear.

Current Lap: The stopwatch time for the current lap.

Date: The current day, month, and year.

Descent - Average: The average vertical distance of descent since the last reset.

Descent - Maximum: The maximum rate of descent in feet per minute or meters per minute since the last reset.

Descent - Total: The total elevation distance descended since the last reset.

Distance to Dest.: The remaining distance to the final destination. You must be navigating for this data to

appear.

Distance to Next: The remaining distance to the next waypoint on the route. You must be navigating for this

data to appear.

Elapsed Track Time: The total time recorded. For example, if you start the timer and run for 10 minutes, then

stop the timer for 5 minutes, then start the timer and run for 20 minutes, your elapsed time is 35 minutes.

Elevation: The altitude of your current location above or below sea level.

Elevation Above Ground: The altitude of your current location above ground level (if maps contain sufficient

elevation information).

Elevation - Maximum: The highest elevation reached since the last reset.

Elevation - Minimum: The lowest elevation reached since the last reset.

ETA at Destination: The estimated time of day when you will reach the final destination (adjusted to the local

time of the destination). You must be navigating for this data to appear.

ETA at Next: The estimated time of day when you will reach the next waypoint on the route (adjusted to the

local time of the waypoint). You must be navigating for this data to appear.

Glide Ratio: The ratio of horizontal distance traveled to the change in vertical distance.

Glide Ratio to Dest.: The glide ratio required to descend from your current position to the destination elevation.

You must be navigating for this data to appear.

GPS Elevation: The altitude of your current location using GPS.

GPS Heading: The direction you are moving based on GPS.

GPS Signal Strength: The strength of the GPS satellite signal.

44 Appendix

Grade: The calculation of rise (elevation) over run (distance). For example, if for every 10 ft. (3 m) you climb you

travel 200 ft. (60 m), the grade is 5%.

Heading: The direction you are moving.

Lap Ascent: The vertical distance of ascent for the current lap.

Lap Descent: The vertical distance of descent for the current lap.

Lap Distance: The distance traveled for the current lap.

Laps: The number of laps completed for the current activity.

Lap Speed: The average speed for the current lap.

Last Lap Ascent: The vertical distance of ascent for the last completed lap.

Last Lap Descent: The vertical distance of descent for the last completed lap.

Last Lap Distance: The distance traveled for the last completed lap.

Last Lap Speed: The average speed for the last completed lap.

Last Lap Time: The stopwatch time for the last completed lap.

Location (lat/lon): The current position in latitude and longitude regardless of the selected position format

setting.

Location (selected): The current position using the selected position format setting.

Location of Dest.: The position of your final destination. You must be navigating for this data to appear.

None: This is a blank data field.

Odometer: A running tally of distance traveled for all trips. This total does not clear when resetting the trip data.

Off Course: The distance to the left or right by which you have strayed from the original path of travel. You must

be navigating for this data to appear.

Pointer: An arrow points in the direction of the next waypoint or turn. You must be navigating for this data to

appear.

Speed: The current rate of travel.

Speed Limit: The reported speed limit for the road. Not available in all maps and in all areas. Always rely on

posted road signs for actual speed limits.

Speed - Maximum: The highest speed reached since the last reset.

Speed - Moving Avg.: The average speed while moving since the last reset.

Speed - Overall Avg.: The average speed while moving and stopped since the last reset.

Stopwatch Timer: The stopwatch time for the current activity.

Sunrise: The time of sunrise based on your GPS position.

Sunset: The time of sunset based on your GPS position.

Temperature: The temperature of the air. Your body temperature affects the temperature sensor.

Time of Day: The current time of day based on your current location and time settings (format, time zone,

daylight saving time).

Time to Destination: The estimated time remaining before you reach the destination. You must be navigating

for this data to appear.

Time to Next: The estimated time remaining before you reach the next waypoint in the route. You must be

navigating for this data to appear.

To Course: The direction in which you must move to get back on the route. You must be navigating for this data

to appear.

Total Lap: The stopwatch time for all the completed laps.

Trip Odometer: A running tally of the distance traveled since the last reset.

Trip Time: A running tally of the total time spent moving and not moving since the last reset.

Trip Time - Moving: A running tally of the time spent moving since the last reset.

Trip Time - Stopped: A running tally of the time spent not moving since the last reset.

Turn: The angle of difference (in degrees) between the bearing to your destination and your current course. L

means turn left. R means turn right. You must be navigating for this data to appear.

Appendix 45

Velocity Made Good: The speed at which you are closing on a destination along a route. You must be

navigating for this data to appear.

Vertical Dist. to Dest.: The elevation distance between your current position and the final destination. You must

be navigating for this data to appear.

Vertical Dist. to Next: The elevation distance between your current position and the next waypoint in the route.

You must be navigating for this data to appear.

Vertical Speed: The rate of ascent or descent over time.

Vertical Speed to Dest.: The rate of ascent or descent to a predetermined altitude. You must be navigating for

this data to appear.

Waypoint at Dest.: The last point on the route to the destination. You must be navigating for this data to

appear.

Waypoint at Next: The next point on the route. You must be navigating for this data to appear.

46 Appendix

Index

accessories 38

activities 23

alarms

clock 27

proximity 27

tones 29

alerts 19

dog 29

location 13, 14

altimeter, calibrating 26

ANT+ sensors, pairing 38

applications 17, 18

area calculation 27

backlight 34, 35

BaseCamp 37

battery 34, 39

charging 5, 35

installing 5

life 29

maximizing 11, 21, 34, 35

replacing 39–41

storage 34

beacon 20

bearing pointer 25

Bluetooth technology 17

calibrating, altimeter 26

charging 35

collar 6

handheld 5

cleaning the device 32

cleaning the touchscreen 32

collar 11

charging 6

contact points 15

fitting 10

light 20

replacing battery 39, 40

replacing strap 41

VHF antenna 4, 42

compass 13, 25

calibrating 25

navigating 25

computer, connecting 35–37

contact 18, 19

adding 18, 19

ID 19, 20

viewing on map 19

contact points 10, 15

covey, marking 20

data

sharing 14

sharing data 14

storing 18

transferring 18

data fields 26, 28

deleting, all user data 37

device, care 32

display settings 29

dog 7, 9, 10, 18, 27

adding 7, 8

alerts 14, 29

collar 21

ID 8, 10

information 9, 10

navigating to 13

statistics 9, 20

track and control codes 8

tracking 11–14, 21

tracks 9, 13, 37

training 15, 16

training basics 14, 17

training intensity levels 15

type 9

update rate 35

elevation 24, 26

plot 26

fuse, changing 43

Garmin Express

registering the device 32

updating software 32

geofences 13, 14

GPS 27, 28

settings 29

history, sending to computer 18

hunter 18

icons 12

initial setup 6

intensity level, choosing 15

keys 2, 3

training 16

line-of-sight radio communication 11

main menu, customizing 28

maps 21, 24

BirdsEye imagery 28

measuring distances 25

navigation 25

optional 38

orientation 25, 29

settings 29, 30

updating 32

zoom 12, 30

measuring distances 25

memory card 2, 36

messages 19

microSD card. See memory card

MicroSD card. See memory card

navigation 13, 25, 26

altimeter 26

on-screen buttons 6

pairing

ANT+ sensors 38

smartphone 17

position format 31

power cables, changing the fuse 43

power key 2, 3, 6

product registration 32

proximity alarms 27

radio communication 11

radio frequencies 9

registering the device 32

replacement parts 38–42

rescue mode 21

resetting the device 37

routes 22, 23

creating 23

deleting 23

editing 23

navigating 23

settings 31

satellite signals 27, 28

acquiring 7

settings 16, 29–31

device 30, 31

recording 30

Sight 'N Go 26

sleep mode 11

smartphone 18

applications 17

pairing 17

software

updates 32

updating 32

specifications 33

storing data 18

tempe 31, 38

Tempe 31

temperature 38

tones 29

TracBack 24

tracks 13, 24

navigating 24

recording 24

settings 30

training

stimulation 15

tone 15

vibration 15

transferring, tracks 37

trip information

resetting 26

viewing 26

trip planner. See routes

troubleshooting 37

units of measure 31

updates, software 32

USB

connector 2

disconnecting 37

user data, deleting 37

VHF antenna 2, 42

waypoints 21, 25

deleting 22

editing 21, 22

projecting 22

saving 20, 21

Wi‑Fi 17

connecting 17

zooming, maps 12

Index 47

support.garmin.com

GUID-7936C255-EDC9-4713-AA2B-26476A140DA6 v1September 2021

Garmin 010-02616-52 Alpha 200 Handheld GPS Dog Tracker

Product's Documents

Owner's manual

Specifications

Garmin 010-02616-52 Questions and Answers
