Battery Precaution
1. The 7.4V rechargeable battery pack must be charged before use by utilizing
the USB charging cable which included.
2. Do not overcharge the battery pack. Do not charge for more than 6 hours.
3. Do not charge the battery pack if it shows leakage, corrosion, or has loose or
exposed wires or other damage.
4. Do not cover the battery pack with any sort of materials while charging.
5. Do not touch the battery pack when it is hot. Wait until the battery pack cools
before installing it in the Vehicle and before recharging.
6. Do not dispose of the battery in fire.
7. Do not dismantle the battery or charger, and do not cut the battery or
charger cables.
8. The battery pack will be warm after charging, and hot after use in vehicle.
9. The supply terminals are not to be short-circuited.
10. Rechargeable batteries are to be removed from the toy before being charged.
11. Rechargeable batteries are only to charged by adult.
12. Battery replacement must be only made by adults.
13. The USB charging cable is not a toy.
14. Charge only type (1200mAh Max.) rechargeable battery packs. Other types of
batteries may burst causing injury to persons and damage. This power unit is
intended to be correctly orientated in a vertical or floor mount position. This
charger is intended to be used for charging 7.4V rechargeable battery pack
with maximum capacity of 1200mAh. It cannot be used for charging
non-rechargeable batteries. Regular examination of USB charging cable for
any damage to their cord, plug, exclosure and other parts, and that, in the
event of such damage, it must not be used with the USB charging cable or
battery pack charge until such damage has been repaired. Note that the AA
batteries are non-rechargeable and is not to be recharged. Only batteries of
the same or equivalent type as recommended are to be used. It will need
replacement when transmission is poor.
15. Exhausted batteries are to be removed from the product.
16. Do not mix old and new batteries or different type of batteries.
Charging the Rechargeable Battery Pack for the Vehicle:
1. Connect the 7.4V rechargeable battery pack to the USB charging cable.
2. When charging, the charge indicator will light up in red and then turn off when
fully charged.
3. It is recommended to connect USB charging cable (included) to computer to
charge the rechargeable battery pack. If the USB charging cable (included) is
to connect to a charger adaptor, the output limit cannot exceed 7.4V.
4. The charging time for a full charge is about 2 hours. Full charge battery
usage is 20 minutes maximum.
5. When charging is completed, unplug the USB charging cable.
6. Disconnect the rechargeable battery pack from the USB charging cable.
- RC Vehicle x 1
- RC Transmitter x 1
- Instruction Manual x 1
- 7.4V Rechargeable
Battery Pack x 1
- AA type Battery x 2
- USB Charging Cable x 1
1 x 7.4V
1200mAh Lithium Ion
Rechargeable battery
Pack For Vehicle
(Included)
7.4V
Contents
Battery Installation
RC Vehicle x 1RC Transmitter x 1
For Transmitter (Fig. 3 and Fig. 4)
1. Switch OFF the power.
2. Unscrew the screw on the battery cover.
3. Open the battery cover.
4. Install 2 AA batteries with correct polarity (+/-) as shown inside the battery
compartment.
5. Close the battery cover.
6. Tighten the screw on the battery cover.
For Vehicle (Fig. 1 and Fig. 2)
1. Switch OFF the power.
2. Turn to unlock the locking tabs and
unscrew the screw on the battery cover.
3. Open the battery cover.
4. Install 7.4V battery pack with
correct polarities (+/-) as shown
inside the battery compartment.
5. Close the battery cover.
6. Tighten the screw on the battery
cover.
Transmitter
Fig. 3
LED Battery
Indicator
ON/OFF
Accelerator
Trigger
Transmitter - Battery Installation
Fig. 4
Steering
Wheel
2 X 1.5V AA Batteries
For Transmitter
(Included)
RADIO CONTROL
PNC010003
USB Charging Cable (Included)
USB
Vehicle - Battery Installation
Fig. 1
Vehicle
Fig. 2
Battery
Compartment
ON/OFF
7.4V
This toy is only to be connected to
equipment bearing either of the following symbols:
INSTRUCTION
MANUAL
DIE-
CAST
car
shell
1:10
SPEED SWITCH
(Normal Mode /
Turbo Mode)
3. Use the Accelerator Trigger to drive the Vehicle Forward, Stop and Backward
4. Play on smooth surface to have the optimum performance.
5. Remember to switch OFF the power of the Vehicle and
Transmitter after playing.
6. The optimum control range is up to 25m/82ft outdoor.
1. Switch ON the Vehicle and Transmitter.
Turn Left Turn Right
2. Use the Steering Wheel to control the Vehicle turning left or right.
FCC label compliance statement:
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and receiver
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
- Consult the dealer or an experienced radio/TV technician for help
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
RSS-210 Compliance Statement:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired operation of the device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry
Canada,. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more
than that necessary for successful communication.
Declaration of Conformity
The product is in conformity with the requirement of EU Directive 2014/53/EU.
Performance Tips
1. Do not drive in windy or rainy weather.
2. Avoid direct impact the Vehicle with obstacles.
3. Switch OFF the power when not in use to prevent damage of Vehicle and Transmitter
due to leakage of electrolyte from batteries.
4. Remove all batteries from the Vehicle and Transmitter when not in use for long period.
5. Keep fingers, hair and loose clothing away from wheels.
6. The operating range can be affected by a variety of factors.
a) Low Voltage of batteries in Transmitter or Vehicle
b) Interference from other items that emit radio frequency signals
7. Outdoor usage is recommended in order to get optimum control range.
8. Recommend to play the vehicle on a clean and smooth surface.
9. Clean the battery compartment to make sure it is free from dust to prevent poor
contact of batteries.
10. Always get the Vehicle out of the water before the battery power fails.
How To Play
ON/OFF
Forward
Stop
Backward
Transmitter
Environmental notes:
The whole product also does not belong to household waste at the end of the product life.
You can return it at collection points for the recycling of electronic and electronical instruments
The symbol on the item, instruction manual, hangtag or packing is showing this clearly.
Materials should be recycled according to their respective markings.
Recycling of old devices or other re-use of materials contained therein represents an important contribution to environmental protection.
Please ask at your local community for the correct collection point.
Disposal of batteries
Batteries should not be disposed of in the household waste. As the consumer you are legally obliged to return batteries
containing harmful substances and all other used batteries. You can hand in your old batteries at public collection points in
your area or wherever batteries are sold.
You will find these chemical abbreviations along with a crossed-out refuse bin on batteries containing harmful substances:
Pb=Battery contains lead
Cd=Battery contains cadmium
Hg=Battery contains mercury
The packaging and instruction manual contain important information. Please keep them
for future reference.
Warning! Choking Hazard. Not suitable for children under the age of 3 years due to
small parts.
We reserve the right to improve/amend specifications and colors without notice.
Caution!
1. Do not attempt to disassemble the Vehicle or Transmitter.
2. Make sure the batteries are installed with correct polarities (+/-) as shown inside the
battery compartment.
3. Remove the package and take out all accessories before giving the Vehicle and
Transmitter to child to play.
WARNING: This toy produces flashes that may trigger epilepsy in sensitized individuals.
Frequency band:2408-2467 MHz
Maximum radio frequency power transmitted: <10 dBm
ON/OFF
Vehicle
P&C International Development Ltd.
Room 902A, 9/F, Empire Centre,
Tsim Sha Tsui, Kowloon, Hong Kong
[email protected] http:// www.pnctoys.com
Made in China
PNC/7/14-01E
