Intelligent proximity alert system
• Model no. : PAS-K01-12
• Ultra Wideband based intelligent proximity alert system
• CAN bus interface with 12/24V external power
• Easy use without a setup
• Detecting functions are unaffected by wind, falling rain or snow, fog,
humidity, air temperature, or light
• Tag operates in warehouses, factories, ports, and construction/mining sites
as a safety device
• IP65 enclosure withstands harsh environments
● Technical Data
Weight
Standard Deviation of
Detecting Distance
Max. Detectable
Distance
Interface
Communication
Method
2.9cm (500ms, 20m)20mCAN Bus 2.0BUWB
General Specifications
Data Rate
Conducted Tx Power
Density
Conducted Rx SensitivityMethod
6.8Mbps
Max
-41.3dBm/MHz
-93dBm
/500MHz (6.8Mbps, PER
1%)
UWB compliant
IEEE802.15.4-2011 STD
Ultra Wideband RF Parameter
Power ConsumptionOperating VoltagePower (Adaptor)
Below 4WDC 12V or 24V
INPUT : 100 – 230VAC 50-60Hz 1.2A
OUTPUT : 12VDC 2.5A
Electrical Characteristic
Connector
Ingress Protection
Rating
Storage Temperature
Operating
Temperature
I.P Connector PLUG 6P
(M10xP0.5)
IP65-40~85℃-30~85℃
Operating Specifications
Intelligent proximity alert system
● Overview
IPAS - Silent tag creates a mute environment within a certain zone.
Once the silence tag detects a pedestrian tag within the preconfigured range, any pedestrian tag will
not be acted by surrounding devices and eventually become silent. Then, the pedestrian tag will re-alert
once leaving the zone. The safety zone feature is widely used in small ones inside the warehouse and
employees’ lounges.
Figure 1. IPAS Silent Tag
• Configuration : By IPAS Update Tool S/W
Figure 2. IPAS Silent Tag Detecting Distances
Safety Area
Maximum
Distance
Minimum
Distance
AreaTag
20m2m
ASilent Tag
Configuration
The distance can be calibrated by using IPAS update toolkit software.
Figure 3. IPAS Silent Tag setting
8/20/2026
3
Intelligent proximity alert system
● Specifications
Figure 4. IPAS Silent Tag Detecting Dimension
Wire Description
FunctionPin No.
ColorSize
Red
AWG #26
+12VP01
YellowCAN_LP02
BlueCAN_HP03
WhiteRS232_TXP04
GreenRS232_RXP05
BlackGNDP06
Dimension
Connector Specifications
● Products Assembly
Standard
Silent Tag
Cigar Jack AC Adapter
Extension Cable
8/20/2026
4
Intelligent proximity alert system
● Accessory
IPAS Extension Cable(6M)
IPAS Cable / Cigar Jack Adapter
(250V 5A Fuse Included)
Products
IPAS Universal AC Adapter
● Certifications
FCC: ZE8-PAS-K01-12-B
R-R-KWO-PAS-K01-12-B
Note:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
"This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.“
The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter, except in accordance with FCC multi-transmitter product procedures.
A minimum separation distance of 20cm must be maintained between the antenna and the person for this
appliance to satisfy the RF exposure requirements.
Operation on board an aircraft or a satellite is prohibited. Devices operating under this section may not be
employed for the operation of toys. Except for operation onboard a ship or a terrestrial transportation
vehicle, the use of a fixed outdoor infrastructure is prohibited.
8/20/2026
5
Intelligent proximity alert system
CAUTION : Make No Modification to this Product
Any modifications to this product not expressly approved by Kyungwoo Systech could void
the user’s authority to operate the product. Contact Kyungwoo Systech for more information.
Kyungwoo Systech, Inc. Limited Warranty
Kyungwoo Systech, Inc. warrants its products to be free from defects in material and workmanship for
one year following the date of shipment. Kyungwoo Systech, Inc. will repair or replace, free of charge,
any replace, any product of its manufacture which, at the time it is returned to the factory, is found to
have been defective during the warranty period. This warranty does not cover damage or liability for
misuse, abuse, or the improper application or installation of KIGIS product.
THIS LIMITED WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES WHETHER
EXPRESS OR IMPLIED (INCLUDING, WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE), AND WHETHER ARISING UNDER
COURSE OF PERFORMANCE, COURSE OF DEALING OR TRADE USAGE.
This Warranty is exclusive and limited to repair or, at the discretion of Kyungwoo Systech, Inc.,
replacement. IN NO EVENT KYUNGWOO SYSTECH INC. BE LIABLE TO BUYER OR ANY OTHER
PERSON OR ENTITY FOR ANY EXTRA COSTS, EXPENSES, LOSSES, LOSS OF PROFITS, OR ANY
INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES RESULTING FROM ANY PRODUCT DEFECT
OR FROM THE USE OR INABILITY TO USE THE PRODUCT, WHETHER ARISING IN CONTRACT OR
WARRANTY, STATUTE, TORT, STRICT LIABILITY, NEGLIGENCE, OR OTHERWISE.
Kyungwoo Systech, Inc. reserves the right to change, modify or improve the design of the product
without assuming any obligations or liabilities relating to any product previously manufactured by
Kyungwoo Systech, Inc. Any misuse, abuse, or improper application or installation of this product or
use of the product for personal protection applications when the product is identified as not intended
for such purposes will void the product warranty. Any modifications to this product without prior
express approval by Kyungwoo Systech, Inc. will void the product warranties. All specifications
published in this document are subject to change; Kyungwoo Systech, reserves the right to modify
product specifications or update documentation at any time. For the most recent version of any
documentation, refer to: www.kyungwoo.com, www.kigistec.com.
항공기, 선박, 위성, 모형비행기에의 적용을 금지함.
These devices may not be employed for the operation of toys. Operation onboard an aircraft, a ship or a
satellite is prohibited.
적합성평가를 받은 자의 상호 : ㈜경우시스테크
기자재 명칭 : Intelligent Proximity Alert System
기자재의 제조시기 : 별도표기
기자재의 제조자 및 제조국가 : (주)경우시스테크/대한민국
