Induction hob with integrated
ventilation system
PVQ...H2...
[en] Information for Use
en Table of contents
You can find additional information and explanations online.
Scan the QR code on the title page.
Table of contentsTable of contents
1 Safety ........................................................................ 2
2 Avoiding material damage ..................................... 4
3 Environmental protection and saving energy ...... 5
4 Suitable cookware ................................................... 6
5 Familiarising yourself with your appliance .......... 6
6 Software update ...................................................... 8
7 Operating modes ..................................................... 8
8 Before using for the first time ................................ 9
9 Basic operation ....................................................... 9
10 Ventilation control ............................................... 10
11 Favourite button .................................................. 11
12 CombiZone .......................................................... 11
13 Time-setting options ........................................... 11
14 PowerBoost ......................................................... 12
15 PanBoost .............................................................. 12
16 Keep-warm function ........................................... 13
17 PerfectFry Sensor ............................................... 13
18 Childproof lock ................................................... 14
19 Pause ................................................................... 14
20 Individual safety switch-off ................................ 14
21 Basic settings ..................................................... 14
22 Cookware test ..................................................... 16
23 HomeConnect ................................................... 16
24 Cleaning and servicing ...................................... 18
25 Troubleshooting ................................................. 20
26 Disposal ............................................................... 22
27 Customer Service ............................................... 22
28 Information regarding Free and Open Source
Software ............................................................... 22
29 Declaration of Conformity .................................. 23
30 Test dishes .......................................................... 24
Safety 1 Safety
Observe the following safety instructions.
1.1 Definition of the signal words
This is where you can find explanations for the
safety signal words used in this manual.
WARNING
This indicates that death or serious injuries
may occur as a result of non-observance of
this warning.
ATTENTION
This indicates that damage to the appliance or
other material damage may occur as a result
of non-compliance with this warning.
Note: This alerts you to important information.
1.2 General information
¡ Read this instruction manual carefully.
¡ Keep the instructions, the appliance and the
product information safe for future reference
or for the next owner.
¡ Do not connect the appliance if it has been
damaged in transit.
1.3 Intended use
Only a licensed professional may connect ap-
pliances without plugs. Damage caused by in-
correct connection is not covered under the
warranty.
The appliance can only be used safely if it is
correctly installed according to the safety in-
structions. The installer is responsible for en-
suring that the appliance works perfectly at its
installation location.
Only use this appliance:
¡ To prepare meals and drinks.
¡ Under supervision. Never leave the appli-
ance unattended when cooking for short
periods.
¡ in private households and in enclosed
spaces in a domestic environment.
¡ Up to an altitude of 2000m above sea level.
Do not use the appliance:
¡ On boats or in vehicles.
¡ With an external timer or a separate remote
control. This does not apply if operation with
2
Safety en
appliances included in EN 50615 is
switched off.
¡ To extract hazardous or explosive sub-
stances and vapours.
¡ To extract small parts and liquids.
If you wear an active implantable medical
device (e.g. a pacemaker or defibrillator),
check with your doctor that it complies with
Council Directive 90/385/EEC of 20th June
1990, EN 45502-2-1 and EN 45502-2-2, and
that it has been chosen, implanted and pro-
grammed in accordance with VDE-AR-E
2750-10. If these conditions are satisfied, and
if, in addition, non-metal cooking utensils and
cookware with non-metal handles are used, it
is safe to use this induction hob as intended.
1.4 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.5 Safe use
WARNING‒Risk of suffocation!
Children may breathe in or swallow small
parts, causing them to suffocate.
Keep small parts away from children.
Do not let children play with small parts.
Children may put packaging material over their
heads or wrap themselves up in it and suffoc-
ate.
Keep packaging material away from chil-
dren.
Do not let children play with packaging ma-
terial.
WARNING‒Risk of poisoning!
Risk of poisoning from flue gases being drawn
back in. Room-air-dependent heat-producing
appliances (e.g. gas, oil, wood or coal-oper-
ated heaters, continuous flow heaters or water
heaters) obtain combustion air from the room
in which they are installed and discharge the
exhaust gases into the open through an ex-
haust gas system (e.g. a chimney). With the
extractor hood switched on, air is extracted
from the kitchen and the adjacent rooms.
Without an adequate supply of air, the air pres-
sure falls below atmospheric pressure. Toxic
gases from the chimney or the extraction shaft
are sucked back into the living space.
Always ensure adequate fresh air in the
room if the appliance is being operated in
exhaust air mode at the same time as a
room-air-dependent heat-producing appli-
ance is being operated.
It is only possible to safely operate the appli-
ance if the pressure in the room in which the
heating appliance is installed does not fall
below 4Pa(0.04mbar). This can be
achieved whenever the air needed for com-
bustion is able to enter through openings
that cannot be sealed, for example in doors,
windows, incoming/exhaust air wall boxes or
by other technical means. An incoming/ex-
haust air wall box alone is not sufficient to
ensure compliance with the limit.
In any case, consult your responsible chim-
ney sweep. They are able to assess the
house's entire ventilation setup and will sug-
gest the suitable ventilation measures to
you.
Unrestricted operation is possible if the ap-
pliance is operated exclusively in circulating-
air mode.
WARNING‒Risk of fire!
Leaving fat or oil cooking on an unattended
hob can be dangerous and may lead to fires.
Never leave hot oil or fat unattended.
Never attempt to extinguish a fire using wa-
ter; instead, switch off the appliance and
then cover with a lid or a fire blanket.
The cooking surface becomes very hot.
Never place flammable objects on the cook-
ing surface or in its immediate vicinity.
Never place objects on the cooking surface.
The appliance will become hot.
Do not keep combustible objects or aerosol
cans in drawers directly underneath the hob.
3
en Avoiding material damage
Hob covers can cause accidents, for example
due to overheating, catching fire or materials
shattering.
Do not use hob covers.
After every use, switch off the hob using the
main switch.
Do not wait until the hob turns off automatic-
ally as there are no longer any pots and
pans on it.
Fatty deposits in the grease filters may catch
fire.
Never operate the appliance without a
grease filter.
Clean the grease filters regularly.
Never work with naked flames close to the
appliance (e.g. flambéing).
Do not install the appliance near a solid fuel
heating appliance (e.g. wood- or coal-burn-
ing) unless the heating appliance has a
sealed, non-removable cover. There must be
no flying sparks.
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use, particularly
the hob surround, if fitted.
Caution should be exercised here in order to
avoid touching heating elements.
Young children under 8 years of age must
be kept away from the appliance.
Hob guards may cause accidents.
Never use hob guards.
Metal objects on the hob quickly become very
hot.
Never place metal objects (such as knives,
forks, spoons and lids) on the hob.
The appliance becomes hot during operation.
Allow the appliance to cool down before
cleaning.
If hot liquids penetrate the appliance, only re-
move the grease filter or the overflow con-
tainer once the appliance has cooled down.
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be car-
ried out by trained specialist staff.
Only use genuine spare parts when repairing
the appliance.
If the power cord or the appliance power
cable of this appliance is damaged, it must
be replaced with a special power cord or
special appliance power cable, which is
available from the manufacturer or its Cus-
tomer Service.
If the power cord of this appliance is dam-
aged, it must be replaced by trained special-
ist staff.
If the appliance or the power cord is damaged,
this is dangerous.
Never operate a damaged appliance.
Never operate an appliance with a cracked
or fractured surface.
Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
If the appliance or the power cable is dam-
aged, immediately switch off the fuse in the
fuse box.
Call customer service.
Page22
An ingress of moisture can cause an electric
shock.
Do not use steam- or high-pressure cleaners
to clean the appliance.
The insulation on cables of electrical appli-
ances may melt if it touches hot parts of the
appliance.
Never bring electrical appliance cables into
contact with hot parts of the appliance.
WARNING‒Risk of injury!
Saucepans may suddenly jump due to liquid
between the saucepan base and the hotplate.
Always keep hotplates and saucepan bases
dry.
Never use icy-cold cookware that has been
in the freezer.
When cooking in a bain marie, the hob and
cooking container could shatter due to over-
heating.
The cooking container in the bain marie
must not directly touch the bottom of the wa-
ter-filled pot.
Only use heat-resistant cookware.
An appliance with a cracked or broken surface
can cause cuts.
Do not use the appliance if it has a cracked
or broken surface.
Avoiding material damage2 Avoiding material damage
This is where you can find the most common causes of damage and tips on how to avoid them.
4
Environmental protection and saving energy en
Damage Cause Measure
Stains Unsupervised cooking process. Monitor the cooking process.
Stains, blisters Spilled food, especially food with a high
sugar content.
Remove immediately with a glass scraper.
Stains, blisters or frac-
tures in the glass
Defective cookware, cookware with melted
enamel or cookware with copper or alu-
minium base.
Use suitable cookware that is in a good condi-
tion.
Stains, discolouration Unsuitable cleaning methods. Only use cleaning agents that are suitable for
glass ceramic, and only clean the hob when it
is cold.
Blisters or fractures in
the glass
Knocks or falling cookware, cooking ac-
cessories or other hard or pointed objects.
When cooking, do not hit the glass or let ob-
jects fall onto the hob.
Scratches, discoloura-
tion
Rough cookware bases or moving the cook-
ware on the hob.
Check the cookware. Lift the cookware when
moving it.
Scratches Salt, sugar or sand. Do not use the hob as a work surface or stor-
age space.
Damage to the appli-
ance
Cooking with frozen cookware. Never use frozen cookware.
Damage to the cook-
ware or the appliance
Cooking without contents. Never place or heat empty cookware on a hot
cooking zone.
Glass damage Melted material on the hot cooking zone or
hot pot lid on the glass.
Do not place greaseproof paper or aluminium
foil nor plastic containers or pot lids on the
hob.
Overheating Hot cookware on the control panel or on the
frame.
Never place hot cookware on these areas.
Environmental protection and saving energy3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compatible
and can be recycled.
Sort the individual components by type and dispose
of them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use
less energy.
Select the cooking zone to match the size of your pan.
Centre the cookware on the hob.
Use cookware whose base diameter is the same dia-
meter as the hotplate.
Tip: Cookware manufacturers often give the upper dia-
meter of the saucepan. It is often larger than the base
diameter.
Unsuitable cookware or incompletely covered cook-
ing zones consume a lot of energy.
Cover saucepans with suitable lids.
Cooking without a lid consumes considerably more
energy.
Lift lids as infrequently as possible.
When you lift the lid, a lot of energy escapes.
Using a glass lid
You can see into the pan through a glass lid without
having to lift it.
Use pots and pans with flat bases.
Uneven bases increase energy consumption.
Use cookware that is suitable for the quantity of food.
Large items of cookware containing little food need
more energy to heat up.
Cook with only a little water.
The more water there is in the cookware, the more
energy that is required to heat it up.
Turn down to a lower power level early on. Use a suit-
able ongoing power level.
If you use an ongoing power level that is too high,
you will waste energy.
Adjust the fan speed to the amount of steam produced
during cooking.
The lower the fan speed, the less energy is con-
sumed.
If cooking produces large amounts of steam, select a
higher fan speed in good time.
The odours are distributed around the room less.
Switch the appliance off when you are not using it.
Ensure that there is sufficient ventilation when cooking.
The appliance works more efficiently and with fewer
operating noises.
Clean or replace the filters at regular intervals.
The effectiveness of the filter is retained.
5
en Suitable cookware
Suitable cookware4 Suitable cookware
Cookware that is suitable for induction cooking must
have a ferromagnetic base, i.e. it must be attracted by a
magnet. The base must also match the size of the cook-
ing zone. If cookware is not detected on a cooking
zone, place this on the cooking zone with the next smal-
lest diameter.
4.1 Size and characteristics of the cookware
To be able correctly detect the cookware, you must take the size and the material of the cookware into consideration.
All cookware bases must be perfectly flat and smooth.
Use Cookware test to check whether the cookware is suitable.
"Cookware test", Page16
Cookware Materials Properties
Recommended cook-
ware
Stainless steel cookware in a sandwich
design that distributes the heat well.
This cookware distributes the heat evenly,
heats up quickly, and ensures that it can be
detected easily.
Ferromagnetic cookware made of enamelled
steel, cast iron or special induction cookware
made of stainless steel.
This cookware distributes the heat evenly,
heats up quickly, and ensures that it can be
detected.
Suitable The base is not fully ferromagnetic. If the ferromagnetic area is smaller than the
base of the cookware, only the area that is fer-
romagnetic heats up. As a result, the heat is
not distributed evenly.
Cookware bases that contain aluminium. These cookware bases reduce the ferromag-
netic area, which means that less power is
emitted to the cookware. This cookware may
not be sufficiently detected or may not be de-
tected at all, and therefore does not heat suffi-
ciently.
Not suitable Cookware made from normal thin steel,
glass, clay, copper or aluminium.
Notes
Do not use adapter plates between the hob and the
cookware.
Do not heat up empty cookware and do not use
cookware with a thin base, as this may become very
hot.
Familiarising yourself with your appliance5 Familiarising yourself with your appliance
5.1 Your new appliance
Information about your new appliance
2
1
3
4
5
6
Familiarising yourself with your appliance en
No. Designation
Grease filter
Odour filter for circulating-air mode or acoustics fil-
ter for air extraction mode
1
Hob
Control panel
Overflow container
5.2 Special accessories
Depending on the appliance model, various accessories
are available and you can obtain these from specialist
retailers, from our after-sales service or from our official
website.
Air extraction set
Air recirculation set
Odour filter for recirculating air mode
Acoustics filter for air extraction mode
5.3 Control panel
Individual details, such as colour and shape, may differ from the figure.
A
D
C
B
C
Letters Designation
Main switch
Control panel
Cooking zone
Ventilation sensor
Note: Always keep the control panel clean and dry.
Tip: Do not place any cookware near the displays or
buttons. The electronics may overheat.
Touch fields
When you switch on the hob, the symbols for the con-
trols available at this time light up.
Sensor Function
Main switch
Select a cooking zone
Settings area
PowerBoost
Automatic linking/separating of cooking
zones
Sensor Function
PerfectFry Sensor
Timer functions
Childproof lock
Pause
Favourite button
Connectivity
Indicators/symbols
Display Function
Switch-off timer
PerfectFry Sensor
- Power levels
Childproof lock
Buttons in connection with Home Connect
As soon as the connection to Home Connect has been
established, the following buttons and displays are avail-
able:
1
Depending on the appliance specifications.
7
en Software update
Sensor Function
Accept settings from another appliance
If lights up, search for further information in the
HomeConnect app.
5.4 Distribution of the cooking zones
The specified power has been measured with the stand-
ard pots which are described in IEC/EN 60335-2-6. The
power may vary depending on the size of the cookware
or cookware material.
A A
AA
Area Highest setting
21 cm diameter Power level 9
PowerBoost
2500W
3700W
21 x 38 cm Power level 9 3600W
At power level 9, the hob reaches the power indicated
in the table in order to reduce the preheating times and
keeps them running for a certain time, provided the
other cooking zone on the same side is not in use.
5.5 Cooking zone
Before you start cooking, check whether the size of the
cookware fits the cooking zone that you want to use for
cooking:
Area Cooking zone type
Single-circuit cooking zone
Combi cooking zone
Page11
5.6 Residual heat indicator
The hob has a residual heat indicator for each cooking
zone. Do not touch the cooking zone if the residual heat
indicator is lit.
Display Meaning
The cooking zone is hot.
The cooking zone is warm.
5.7 Saturation indicator
The hob is equipped with a saturation indicator. When
the anti-odour filters are saturated, lights up and the fil-
ter must be replaced.
"Odour filter or acoustics filter", Page19
Software update6 Software update
If the appliance is connected to HomeConnect, some
functions may be available with a software update.
More information on the availability of additional func-
tions can be found on the website
www.bosch-
home.com
Operating modes7 Operating modes
You can use your appliance in air extraction mode or
circulating-air mode.
7.1 Air extraction mode
The air which is drawn in is cleaned by the grease filters
and conveyed to the exterior by a pipe system.
The air must not be discharged into a flue
that is used for exhausting fumes from
appliances burning gas or other fuels (not
applicable to appliances that only dis-
charge the air back into the room).
If the exhaust air is to be conveyed into
a non-functioning smoke or exhaust
gas flue, you must obtain the consent
of the heating engineer responsible.
If the exhaust air is conveyed through
the external wall, a telescopic duct
should be used.
7.2 Air recirculation
The air which is drawn in is cleaned by the grease filters
and an odour filter, and conveyed back into the room.
To bind odours in air recirculation mode,
you must install an odour filter. The differ-
ent options for operating the appliance in
air circulation mode can be found in our
catalogue. Alternatively, ask your dealer.
The required accessories are available
from specialist retailers, from our after-
sales service or from the online shop.
Note: When cooking intensively and for a long time,
moisture is released into the air in the room. When us-
ing the appliance in air recirculation mode, we recom-
mend ventilating the kitchen adequately, e.g. by briefly
opening a window to remove excessive moisture.
8
Before using for the first time en
Before using for the first time8 Before using for the first time
Observe the following recommendations.
8.1 Initial cleaning
Remove any leftover packaging from the hob surface
and wipe the surface with a damp cloth. You can find a
list of recommended detergents on the official website
www.bosch-home.com
.
More information on care and cleaning.
Page18
8.2 Preparing the appliance
To ensure correct operation, you must arrange the com-
ponents in this order:
1.
Insert the filter.
2.
Insert the metal grease filter.
Note: Never operate the appliance without the metal
grease filter and the overflow container.
8.3 Cooking with induction
In comparison to conventional hobs, induction techno-
logy brings with it a series of changes and has a num-
ber of benefits such as time savings when cooking and
frying, energy savings as well as greater ease of clean-
ing and care. It also offers improved heat control as the
heat is generated directly in the cookware.
8.4 Cookware
You can find a list of recommended cookware on the of-
ficial website
www.bosch-home.com
.
Further information on suitable cookware.
Page6
8.5 Setting the operating mode
The appliance is supplied with a preset circulating-air
mode.
When your hob is installed with an air outlet to the out-
side, you must configure the setting to this mode.
You can find additional information about this in the sec-
tion entitled
"Basic settings", Page14
8.6 Setting Home Connect
When you first switch on the appliance, you will be
prompted to set your home network. lights up for a
few seconds on the display panel.
To begin the connection to Home Connect, touch
and proceed in accordance with the information in the
section .
To end the setting, switch off the hob.
You can also adjust the HomeConnect setting at a dif-
ferent time.
Basic operation9 Basic operation
9.1 Switching on the hob
Touch .
A signal sounds. The symbols for the cooking zones
and the currently available functions light up. lights
up in the cooking zone displays.
The hob is ready to use.
ReStart
If you switch the appliance on within four seconds of
switching it off, the hob operates with the settings that
were previously set.
9.2 Switching the hob off
Touch until the displays go out.
All cooking zones are switched off.
Note: If all of the cooking zones are switched off for
longer than 59seconds, the hob is automatically
switched off.
9.3 Setting the power level in the cooking
zones
The cooking zone has 17 power levels, which are dis-
played from to with intermediate values. Select the
best power level for the food and the planned cooking
process.
1.
Touch the required cooking zone display
and light up.
2.
Select the required power level in the settings area.
The power level has been set.
Note: If no cookware is placed on the cooking zone or
the pot is not suitable, the selected power level flashes.
After a certain period of time, the cooking zone switches
itself off.
QuickStart
If you set one or more items of cookware on any
cooking zone before switching on the appliance, the
hob detects this and automatically selects the cook-
ing zone for one of the items of cookware. Then se-
lect the power level in the next 59 seconds, or the
hob will switch off.
Changing the power level and switching off the
cooking zone
1.
Select the cooking zone.
2.
Select the required power level or set it to
The cooking zone's power level is changed or the
cooking zone is switched off.
9.4 Cooking recommendations
The table shows which power level ( ) is suitable for
which food. The cooking time ( ) may vary depend-
ing on the type, weight, thickness and quality of the
food. To preheat, set power level 8–9.
9
en Ventilation control
Melting
Butter, honey, gelatine 1-2 -
Heating and keeping warm
Boiled sausages
1
3-4 -
Defrosting and heating
Spinach, frozen 3-4 15-25
Poaching, simmering
Potato dumplings
1
4.-5. 20-30
Whisked sauces, e.g. Béarnaise
sauce, Hollandaise sauce
3-4 8-12
Boiling, steaming, braising
Rice, with double the volume of
water
2.-3. 15-30
Unpeeled potatoes 4.-5. 25-35
Pasta
1
6-7 6-10
Soups 3.-4. 15-60
Vegetables 2.-3. 10-20
Stew in a pressure cooker 4.-5. -
Braising
Pot roast 4-5 60-100
Goulash
2
3-4 50-60
Roasting/frying with a small
amount of fat
1
Escalope, plain or breaded 6-7 6-10
Steak, 3 cm thick 7-8 8-12
Poultry breast, 2cm thick 5-6 10-20
Hamburgers (2 cm thick) 6-7 10-20
Fish and fish fillet, breaded 6-7 8-20
Prawns and scampi 7-8 4-10
Sautéing fresh vegetables and
mushrooms
7-8 10-20
Frozen dishes, e.g. stir-fries 6-7 6-10
Omelette (cooked one after the
other)
3.-4. 3-10
Frying (150 to 200g per batch
in 1 to 2l oil, deep-fried in
batches)
1
Frozen products, e.g. chips,
chicken nuggets
8-9 -
Vegetables, mushrooms,
breaded, beer-battered or tem-
pura
6-7 -
Small baked items, e.g. dough-
nuts, battered fruit
4-5 -
Ventilation control10 Ventilation control
The cooking zone has an air extraction system integ-
rated in the cooking surface.
The functions for controlling the air extraction system
are described below.
You can change the factory settings at any time.
"Basic settings", Page14
Note: Use shallow cookware to improve performance.
With deep cookware, place the lid at an angle.
10.1 Automatic start for the ventilation
system
If you assign a power level to the first cooking zone, the
air extraction system will start up automatically. The
ventilation setting lights up on the ventilation sensor.
After the automatic start, you can change the ventilation
setting. Changing or deactivating the ventilation setting.
Page10
10.2 Ventilation control
The board has 9 ventilation settings.
Switching on the ventilation system
1.
Press the ventilation sensor.
The ventilation system starts at the preset power
level.
2.
Select the required power level in the settings area.
The power level for the ventilation system lights up.
Changing or switching off the ventilation
system
1.
Press the ventilation sensor.
2.
Select the required ventilation setting or change it to
.
10.3 Intensive ventilation settings
There are two intensive ventilation settings at which the
ventilation system operates for a short time at a higher
power level.
Switching on the intensive settings
1.
Press the ventilation sensor.
2.
Select the required intensive setting:
Intensive setting I: Press . lights up.
Intensive setting II: Press twice. lights up.
Note: After approx. 8minutes, the appliance automatic-
ally switches back to ventilation setting .
Changing or switching off intensive settings
1.
Press the ventilation sensor.
2.
Select the required ventilation setting or change it to
.
1
Without lid
2
Preheat to power level 8 - 8.5
10
Favourite button en
10.4 Fan run-on for the ventilation system
The ventilation system continues to run for a few
minutes after the cooking zone is switched off using the
main switch.
This assumes that the cooking zone has been switched
on for at least one minute and the ventilation system is
running.
Once the corresponding time has elapsed, the ventila-
tion system switches off automatically. This time de-
pends on the operating mode in which the appliance is
installed.
When the ventilation system is switched on, the ventila-
tion setting lights up. The ventilation system can be
switched off at any time by pressing the ventilation
sensor.
Favourite button11 Favourite button
You can use the function to select two functions or
cooking settings which can then be quickly accessed
on .
11.1 Assigning Favourite button functions
Requirement: Connect the appliance to Home Connect.
You can find more information about this under Home
Connect
1.
To assign functions, open the Home Connect app
and follow the instructions.
2.
As soon as you have assigned the functions, you can
use them:
Function 1: Press briefly.
Function 2: Press and hold .
Note: If you have not assigned any functions,
switches off once the hob is switched on.
CombiZone12 CombiZone
It allows two cooking zones of the same size to be com-
bined, with the same power level being switched on in
both. This is intended in particular for cooking with long
cookware.
This function allows you to cook with one item of cook-
ware that occupies one cooking zone and that can be
moved from one zone to another for increased conveni-
ence. In this case, the two zones also retain the same
power level and the same settings.
12.1 Positioning the cookware
Use cookware that fits into the cooking zones.
12.2 Switching on CombiZone
1.
Select one of the two cooking zones and set the
power level.
2.
Press .
The function is activated.
12.3 Switching off CombiZone
Touch .
The function is switched off.
The two cooking zones once again operate independ-
ently of one another.
Time-setting options13 Time-setting options
Your hob has various functions for setting the cooking
time:
Switch-off timer
Timer
The button is assigned to the Switch-off timer function
by default. However, you can also assign one of the
above-mentioned functions to the sensor.You can
change these settings via the Home Connect app or in
the basic settings
Page14
.
13.1 Switch-off timer
Allows you to programme a cooking time for one or
more cooking zones and their automatic switch-off once
the time set has elapsed.
Switching on Switch-off timer
1.
Select the cooking zone and the required power level.
2.
Touch .
and light up.
11
en PowerBoost
3.
Within the next 10seconds, set the required cooking
time in the settings area.
You can set intermediate values between 1 minute
and 9 minutes in increments of 30 seconds. To do
this, use to select the intermediate values.
To select a time in hours, e.g. 1h 30mins, press
the numerical sequence 1 - 3 - 0 in the settings
area. If you select a time of more than 60minutes,
the time is automatically displayed in hours.
4.
Touch to confirm.
The cooking time begins to elapse. An audible signal
sounds 1minute before the selected time elapses.
You can check the status of the food and, if required,
extend the cooking time.
Once the cooking time has elapsed, the cooking
zone is switched off and a signal sounds.
Notes
If a cooking time has been programmed in a cooking
zone in which the PerfectFry Sensor is activated, the
programmed cooking time will start to count down as
soon as the selected temperature level has been
reached.
To switch the display between the operating temperat-
ure PerfectFry Sensor and the programmed cooking
time, press the selected temperature.
Changing or switching off Switch-off timer
1.
Select the cooking zone and then touch .
2.
To switch off the function, change the cooking time or
set it to .
13.2 Timer
Enables a clock to be activated. This function operates
independently of the cooking zones and other settings.
It does not automatically switch off the cooking zones.
Switching on Timer
Requirement: Assign the function to .
1.
Press .
2.
Select the required time.
The time starts to elapse.
A signal tone sounds and the displays flash once the
time has elapsed.
Changing or switching off the Timer
1.
Press .
2.
To switch off the function, change the cooking time or
set it to .
PowerBoost14 PowerBoost
The PowerBoost function enables you to heat up large
quantities of water faster than when using .
This function is available for all cooking zones, provided
the other cooking zone on the same side is not in use.
Otherwise, and flash on the display for the selected
cooking zone. is then set automatically without activat-
ing the function.
14.1 Switching on PowerBoost
1.
Select the cooking zone.
2.
Touch
The display lights up.
The function is activated.
14.2 Switching off PowerBoost
1.
Select the cooking zone.
2.
Touch .
The display goes out and the cooking zone
switches back to power level
The function is switched off.
Note: In certain circumstances, the appliance switches
this function off to protect the electronic elements inside
the hob.
PanBoost15 PanBoost
You can use this function to heat up pans more quickly
than with . Do not use the PowerBoost function with fry-
ing pans – this may damage the coating.
You can activate the function via Home Connect or Fa-
vourite button.
This function is available for all cooking zones, provided
the other cooking zone on the same side is not in use.
Otherwise, and flash on the display for the selected
cooking zone. then switches on automatically.
15.1 Recommended applications
Do not place a lid on the pan.
12
Keep-warm function en
Never leave pans unattended when they are heating
up.
Only use cold pans.
Use pans with a completely flat base. Do not use
pans with a thin base.
15.2 Switching on PanBoost
Requirement: Assign the function to . .
"Favourite button", Page11
1.
Select the cooking zone.
2.
Touch .
lights up.
The function is activated.
15.3 Switching off PanBoost
1.
Select the cooking zone.
2.
Select the power level.
goes out
The function is switched off.
Note: To avoid high temperatures, this function automat-
ically switches itself off after 30 seconds.
Keep-warm function16 Keep-warm function
You can use this function to melt chocolate or butter,
and to keep meals warm.
You can activate the function via Home Connect or Fa-
vourite button.
16.1 Switching on Keep-warm function
Requirement: Assign the function to . .
"Favourite button", Page11
1.
Select the required cooking zone.
2.
Touch .
lights up.
The function is switched on.
16.2 Switching off Keep-warm function
1.
Select the cooking zone.
2.
Set to
goes out.
The function is switched off.
PerfectFry Sensor17 PerfectFry Sensor
This function allows you to melt, prepare sauces, sauté,
deep fry or fry while keeping the temperature under con-
trol.
Instead of constantly adjusting the power level during
cooking, select the required target temperature once at
the start. The sensors under the glass ceramic measure
the temperature of the cookware and keep this constant
throughout the entire cooking process.
This function is available on all cooking zones marked
with this symbol .
Functions Temperature
Melting 70-80ºC
Preparing sauces 110 - 120 ºC
Frying 140ºC
Frying 160ºC
Frying 180-200ºC
Frying 220ºC
17.1 Recommended cookware
Special cookware has been developed for this function,
which delivers the best results.
The recommended cookware is available from customer
service, specialist retailers or our online shop
www.bosch-home.com
.
Note: You can also use other cookware. Depending on
the composition of the cookware, the achieved temper-
ature may differ from the selected temperature level.
17.2 Switching on the PerfectFry Sensor
1.
Place the empty cookware on a cooking zone.
2.
Select the cooking zone.
3.
Press .
, and the preset temperature light up on the display
for the selected cooking zone.
4.
Select the temperature by swiping your finger over
the settings area.
flashes until the set temperature is reached again.
The selected temperature and the development of the
temperature reached in the pan flash alternately until
the selected temperature has been reached.
The temperature shown on the displays is approxim-
ate and may differ from the actual temperature in the
frying pan.
Once the temperature has been reached, a signal
tone sounds and as well as the temperature symbol
stop flashing.
5.
Add the frying fat and then the food to the frying pan.
Note: If you need to cook with more than 250ml oil,
add the oil and wait a few seconds before you add the
food.
17.3 Switching off PerfectFry Sensor
Select the cooking zone and touch .
17.4 Recommendations for cooking with
PerfectFry Sensor
The enclosed documentation contains a table with re-
commendations for cooking with PerfectFry Sensor.
13
en Childproof lock
Childproof lock18 Childproof lock
The hob is equipped with a childproof lock. You can use
this to prevent children from switching on the hob.
18.1 Switching on Childproof lock
Requirement: The hob must be switched off.
Touch and hold for 4 seconds.
lights up for 10seconds.
The hob is locked
18.2 Deactivating the childproof lock
1.
To switch on the hob, touch .
2.
Touch and hold for 4 seconds.
The lock is released.
18.3 Automatic childproof lock
You can also activate the childproof lock automatically
every time the hob is switched off.
You can find out how to switch the function on and off in
the "Basic settings" section
Page14
.
Pause19 Pause
You can use the function to pause and resume active
cooking processes for up to 10 minutes without chan-
ging the settings you have selected.
You can switch the function on to clean the control
panel, for example.
19.1 Activating the Pause function
Press .
lights up in the cooking zone displays.
All active cooking processes are stopped. The set-
tings are retained.
The function is activated.
19.2 Deactivating the Pause function
Touch .
The function is switched off. The cooking processes
continue.
Note: After approximately 10 minutes, the cooking zone
automatically switches off.
Individual safety switch-off20 Individual safety switch-off
Activate the safety function if one cooking zone is in op-
eration for an extended period and you do not change
any settings. The cooking zone displays and
switches itself off.
The time depends on the selected power level.
Power level Time
1.0 - 1.5 10 hours
Power level Time
2.0 - 3.5 5hours
4.0 - 5.0 4 hours
5.5 - 6.5 3 hours
7.0 - 7.5 2 hours
8.0 - 9.0 1hour
Press any button to switch on the cooking zone.
Basic settings21 Basic settings
You can configure the basic settings for your appliance
to meet your needs.
21.1 Overview of the basic settings
Display Setting Value
Childproof lock
"Childproof lock", Page14
- Manual.
1
- Automatic.
- Function switched off.
Audible signals - The confirmation signal, the fault signal and the signal
for incorrect use are deactivated.
- The fault signal is activated.
1
Factory setting
14
Basic settings en
Display Setting Value
- The confirmation signal and the signal for incorrect use
are activated.
- All signal tones are switched on
1
.
Volume of the audible signals - Quiet.
- Medium.
1
– Loud.
Assign one of the time-setting programme
functions to on the control panel.
"Time-setting options", Page11
- Switch-off timer.
1
- Timer.
Power limitation
This enables you to limit the total power of
the hob, if required, due to the circumstances
of your electrical installation. Observe the
regulations of the local electricity suppliers.
The available settings depend on the max-
imum power of the hob. You can find more
information on the rating plate. If the function
is switched on and the hob has reached the
set power limit, the required and permitted
power level flashes and you cannot select a
higher power level.
The power is increased by 500 W with each level.
– Switched off. Maximum power of the hob
1
.
- 1000 W. Lowest power setting.
. - 1500 W.
...
- 3000 W.
. - 3500 W.
- 4000 W.
. - 4500 W.
...
- Maximum power of the hob.
Demo mode
Demonstration mode for the hob: When you
switch on the hob, lights up for a few
seconds and the cooking zones do not heat
up.
- Switched off.
1
- Switched on.
Cookware test
You can use this function to test the quality of
the cookware.
"Cookware test", Page16
- Not suitable.
- Not optimal.
- Suitable.
Set circulating-air mode or air extraction
mode.
- Configure circulating-air mode.
1
- Configure air extraction mode.
Set the automatic ventilation system start.
The ventilation system starts at the preset
performance level.
- Switched off.
- Switched on.
1
Set the fan run-on for the ventilation system.
If your hob is working in air extraction mode,
the ventilation system is switched on at the
power level for approx. 6 minutes.
If your hob is working in circulating-air mode,
the ventilation system is switched on at the
power level for approx. 30 minutes.
- Switched off.
- Switched on.
1
:
Restoring factory settings - Individual settings
1
.
- Factory settings.
21.2 To go to the basic settings
Requirement: The hob must be switched off.
1.
To switch on the hob, touch .
2.
Within the next 10seconds, touch and hold for 4
seconds.
Product information Display
Customer service directory
Production number
Production number 1
Product information Display
Production number 2
The first four displays provide the product information.
Touch to view the individual displays.
3.
Touch to access the basic settings.
and light up as a presetting.
4.
Touch repeatedly until the desired setting appears.
5.
Select the required setting in the settings area.
6.
Touch and hold for 4 seconds.
This saves the settings.
1
Factory setting
15
en Cookware test
21.3 Discarding changes to the basic
settings
Touch .
All changes are discarded and not saved.
Cookware test22 Cookware test
The quality of the cookware has a major influence on
the speed and the result of the cooking process.
You can use this function to test the quality of the cook-
ware.
Before the test, ensure that the diameter of the cook-
ware base corresponds to the diameter of the cooking
zone being used.
Access is via the basic settings.
Page14
22.1 Carrying out Cookware test
1.
At room temperature, place the cookware with ap-
prox.200ml water in the centre of the cooking zone
that best fits the base of the cookware in terms of
size.
2.
Call up the basic settings and select .
3.
Touch the settings area. flashes in the cooking
zones.
The function is switched on.
After 10 seconds, the result appears in the cooking
zone displays.
22.2 Checking the result
You can see what the result means for the quality and
speed of the cooking process in the following table.
Result
The cookware is not suitable for the cooking zone
and therefore does not heat up.
The cookware is taking longer to heat up than ex-
pected and cooking is not progressing as well as it
ought to.
The cookware is heating up correctly and cooking is
progressing well.
To reactivate this function, touch the settings area.
HomeConnect 23 HomeConnect
This appliance is network-capable. Connecting your ap-
pliance to a mobile device lets you control its functions
via the HomeConnect app, adjust its basic settings and
monitor its operating status.
The HomeConnect services are not available in every
country. The availability of the HomeConnect function
depends on the availability of the HomeConnect ser-
vices in your country. You can find information about
this at:
www.home-connect.com
.
The HomeConnect app guides you through the entire
login process. Follow the instructions, noting the inform-
ation in the HomeConnect app.
Notes
Please note the safety precautions in this instruction
manual and make sure that they are also observed
when operating the appliance via the HomeConnect
app.
"Safety", Page2
Operating the appliance on the appliance itself al-
ways takes priority. During this time it is not possible
to operate the appliance using the HomeConnect
app.
In networked standby mode, the appliance requires a
maximum of2W.
23.1 Setting up HomeConnect
Requirements
The appliance is connected to the power supply and
is switched on.
You have a mobile device with a current version of
the iOS or Android operating system, e.g. a smart-
phone.
The appliance is receiving signals from the WLAN
home network (Wi-Fi) at its installation location.
The mobile device and the appliance are within range
of your home network's Wi-Fi signal.
1.
Scan the following QR code.
You can install the HomeConnect app and connect
your appliance via the QR code.
2.
Follow the instructions in the HomeConnect app.
23.2 Wi-Fi symbol
The Wi-Fi indicator on the main screen changes accord-
ing to the status and quality of the connection and the
availability of the HomeConnect server.
status Description
Lights up steadily at half
brightness.
No network connection
saved.
Flashes at full brightness. Network connection is be-
ing established.
Lights up steadily at full
brightness.
Network connection saved
and Wi-Fi active.
Flashes. Network settings are reset.
16
HomeConnect en
status Description
Switched off. Network not active.
23.3 Adding or removing a Wi-Fi home
network
The following overview shows how to add or remove a
Wi-Fi home network.
Wi-Fi home network
status
Action
No Wi-Fi home network
stored.
To add the Wi-Fi home net-
work, briefly press .
The Wi-Fi home network
has now been saved.
To pair another appliance,
press and hold .
The Wi-Fi home network
has now been saved.
To reset the Wi-Fi home
network settings, press and
hold . If flashes, press
and hold again.
23.4 Switching off the network connection
Press and hold . If flashes, press and hold
again.
The connection to the Wi-Fi network is switched off
and the network connections are disconnected.
Note: To switch the network connection back on, see .
"Adding or removing a Wi-Fi home network",
Page17
23.5 Changing settings via the
HomeConnect app
You can use the HomeConnect app to change the set-
tings for the cooking zones and send them to the hob.
Requirement: The hob is connected to the Wi-Fi and to
the HomeConnect app.
1.
Select the setting in the HomeConnect app and send
it to the hob.
Follow the instructions in the HomeConnect app.
Settings that you send from the HomeConnect app to
the hob must be confirmed on the hob.
As soon as cooking settings are transmitted to a
cooking zone, the display starts to flash, depending
on the setting.
2.
Press to confirm the setting.
3.
To discard the setting, press any other touch field on
the hob.
23.6 Activating Bluetooth® detection
This wireless technology enables automatic presence
detection. Provided you are near the hob, you no longer
need to confirm settings from your mobile device on the
hob. If you send settings to a cooking zone, you can
confirm these directly from your mobile device.
Requirements
The hob is connected to the Wi-Fi and to the
HomeConnect app.
The Bluetooth® system is connected to the mobile
device.
The user is near the hob.
1.
Open the HomeConnect app.
2.
In order to set Bluetooth® detection, follow the in-
structions in the HomeConnect app.
Note: The Bluetooth® connection is deactivated if the
hob is disconnected and switches to energy-saving
mode. The Bluetooth® connection can also be deactiv-
ated via the Home Connect app.
23.7 Software update
Your appliance's software can be updated using the
software update function, e.g. for the purposes of optim-
isation, troubleshooting or security updates.
To do this, you must be a registered HomeCon-
nectuser, have installed the app on your mobile device
and be connected to the HomeConnectserver.
As soon as a software update is available, you will be
informed via the HomeConnectapp and will be able to
start the software update via the app. Once the update
has been successfully downloaded, you can start in-
stalling it via the HomeConnectapp if you are in your
home network (Wi-Fi). The HomeConnectapp informs
you once installation is successful.
The current software version can be found in the
HomeConnect app under the appliance information for
the relevant home appliance.
Notes
The software update consists of two steps.
– The first step is the download.
– The second step is the installation on your appli-
ance.
You can continue to use your appliance as normal
while updates are downloading. Depending on your
personal settings in the app, software updates can
also be set to download automatically.
Installation takes a few minutes. You cannot use your
appliance during installation.
We recommend that you install security updates as
soon as possible.
23.8 Remote diagnostics
Customer Service can use Remote Diagnostics to ac-
cess your appliance if you contact them, have your ap-
pliance connected to the HomeConnect server and if
Remote Diagnostics is available in the country in which
you are using the appliance.
Tip: For further information and details about the avail-
ability of Remote Diagnostics in your country, please
visit the service/support section of your local website:
www.home-connect.com
.
23.9 Data protection
Please see the information on data protection.
The first time your appliance is registered on a home
network connected to the Internet, your appliance will
transmit the following types of data to the HomeCon-
nect server (initial registration):
Unique appliance identification (consisting of appli-
ance codes as well as the MAC address of the in-
stalled Wi-Fi communication module).
Security certificate of the Wi-Fi communication mod-
ule (to ensure a secure data connection).
17
en Cleaning and servicing
The current software and hardware version of your
appliance.
Status of any previous resetting to factory settings.
This initial registration prepares the HomeConnect func-
tions for use and is only required when you want to use
the HomeConnect functions for the first time.
Note: Please note that the HomeConnect functions can
only be utilised with the HomeConnect app. Information
on data protection can be retrieved in the HomeCon-
nect app.
Cleaning and servicing24 Cleaning and servicing
24.1 Hob surface
Preventing damage to the surface
Before you use the appliance for the first time, clean the
surface with a soft cloth and a commercially available
glass ceramic cleaner.
Do not use the hob as a work surface or storage
space.
Prevent food from coming into contact with the hot-
plate since this may lead to permanent discolouration
of the surface.
Carefully remove any food residue, sugar, plastic, alu-
minium foil and spilled food immediately with a glass
scraper.
Immediately remove the coarse dirt, salt and sugar
from the cooking surface.
Do not use cookware with a rough base.
Lift the cookware when moving it.
Do not use a scraper that is in poor condition.
24.2 Cleaning products
You can obtain suitable cleaning products and glass
scrapers from customer service, the online shop or a re-
tailer.
ATTENTION
Unsuitable cleaning products may damage the surfaces
of the appliance.
Never use unsuitable cleaning products.
Do not use cleaning products while the hob is still
hot. This may cause marks on the surface.
Unsuitable cleaning products
Undiluted detergent
Detergent intended for dishwashers
Abrasive cleaning products
Aggressive cleaning products such as oven spray or
stain remover
Abrasive sponges
High-pressure or steam jet cleaners
Basic products such as degreasing agents
24.3 Cleaning the hob
Clean the hob after every use to prevent cooking
residues from getting burnt on.
Requirement: The hob must be cold. Do not allow the
hob to cool down if it has sugar stains, rice starch,
plastic or aluminium foil on it.
1.
Remove heavy soiling using a glass scraper.
2.
Spray the entire surface with soapy water or commer-
cially available detergent. Only use cleaning agents
for glass ceramic cooktops if there is stubborn dirt.
Apply the cleaning agent evenly and gently.
Follow the cleaning instructions on the packaging
of the cleaning product.
You can achieve good cleaning results using a
special sponge for glass ceramic.
3.
Wipe it with a damp cloth and dry it with a cloth.
Tip: If you keep the base of the cookware clean, the
hob surface remains in a good condition.
24.4 Cleaning profiles
Clean the profiles if they are dirty or stained after use.
Note: Do not use a glass scraper.
1.
Clean using warm soapy water and a soft cloth.
Wash new sponge cloths thoroughly before use.
2.
Dry with a soft cloth.
24.5 Grease filter
The grease filter filters the grease out of the kitchen
steam. The filter comprises a container and two remov-
able grease filters. How frequently you clean the module
depends on the quantity and type of grease used when
cooking. To keep them in good working order, you must
clean the grease filters if there are visible grease depos-
its or at least once a month.
WARNING‒Risk of fire!
Fatty deposits in the grease filters may catch fire.
Never operate the appliance without a grease filter.
Clean the grease filters regularly.
Never work with naked flames close to the appliance
(e.g.flambéing).
ATTENTION
Falling grease filters may damage the hob below.
Grip below the grease filter with one hand.
18
Cleaning and servicing en
1.
Remove the grease filter.
Grease may accumulate in the bottom of the con-
tainer. Keep the grease filter level to prevent
grease from dripping out.
2.
Remove the components of the grease filter.
3.
Clean the grease filter in the dishwasher or by hand.
"Cleaning the grease filters manually", Page19
"Cleaning the grease filter in the dishwasher",
Page19
4.
If required, remove the odour filters or acoustics fil-
ters and clean the appliance from the inside.
5.
If any objects get into the appliance, remove these
objects and ensure that the supply to the overflow
container is not blocked.
6.
Wipe out the inside of the appliance with soapy water
and a dish cloth.
7.
After cleaning, reinsert the dried grease filter.
Cleaning the grease filters manually
1.
Remove the components of the grease filter.
2.
Soak the grease filter in hot soapy water.
Use a brush to clean the grease filter. Do not use
aggressive, acidic or alkaline cleaning products.
Use special grease solvent for stubborn dirt. You
can purchase the grease solvent from Customer
Service, through our online shop or in a specialist
shop.
3.
Rinse the grease filters thoroughly.
4.
Leave the grease filter to drain.
5.
Fit the components of the grease filter.
6.
After drying, insert the grease filter into the appliance.
Cleaning the grease filter in the dishwasher
1.
Remove the grease filter.
2.
Remove the components of the grease filter.
3.
Place the components of the grease filter loosely in
the dishwasher and do not jam them in.
Do not clean heavily soiled grease filters with table-
ware. Do not use aggressive, acidic or alkaline clean-
ing products.
4.
Start the dishwasher. Select a maximum temperature
setting of 70°C.
5.
Leave the grease filter to drain.
6.
After drying, insert the grease filter into the appliance.
24.6 Odour filter or acoustics filter
You can obtain odour filters or acoustics filters from
specialist retailers, customer service or in the online
shop.
Notes
Replace the odour filters when the warning is dis-
played on the appliance.
"Resetting the saturation indicator", Page20
Change the acoustics filters if they are dirty.
Requirement: To keep them in good working order,
only use genuine replacement filters.
1.
Remove the grease filter.
2.
Remove the four odour filters or acoustics filters, and
dispose of them properly.
19
en Troubleshooting
3.
Insert two new odour filters or acoustics filters into the
left and right of the appliance and slide them for-
wards.
4.
Insert the other odour filters or acoustics filters into
the left and right of the appliance.
5.
Insert the grease filter into the appliance.
Resetting the saturation indicator
After the appliance is switched off, lights up.
1.
Replace the odour filters.
"Odour filter or acoustics filter", Page19
2.
Press and hold the ventilation sensor until a signal
tone sounds.
stops lighting up. The odour filter display is reset.
24.7 Cleaning the overflow container
The overflow container collects liquids or objects that
come into the appliance from above.
Requirement: The appliance has cooled and the resid-
ual heat indicator has gone out.
1.
Hold the overflow container with one hand and un-
screw it with the other hand.
Hold the overflow container level to prevent liquid
from leaking out.
2.
Empty the overflow container and rinse it out.
3.
If required, unscrew the screw and clean the overflow
container without the screw in the dishwasher.
4.
Clean the overflow container before screwing it back
into place.
5.
Ensure that the supply to the overflow container is not
blocked.
Remove any objects that have entered the appliance
once it has cooled down. To do this, remove the
grease filter.
Troubleshooting25 Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after-
sales service. This will avoid unnecessary costs.
Tip: Permanently connect your appliance to the Home Connect app to automatically receive software updates. This
allows errors to be eliminated, performance to be improved and new functions to be made available.
WARNING‒Risk of injury!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
If the appliance is defective, call Customer Service.
"Customer Service", Page22
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
Only use genuine spare parts when repairing the appliance.
If the power cord or the appliance power cable of this appliance is damaged, it must be replaced with a special
power cord or special appliance power cable, which is available from the manufacturer or its Customer Service.
If the power cord of this appliance is damaged, it must be replaced by trained specialist staff.
20
Troubleshooting en
25.1 Warnings
Notes
If or appears in the displays, press and hold the
sensor for the respective cooking zone and read the
fault code.
If the fault code is not listed in the following table, dis-
connect the hob from the power supply and wait
30seconds before reconnecting it. If this display ap-
pears again, contact Customer Service and specify
the exact fault code.
If an error occurs, the appliance does not switch to
low power mode.
In order to protect the appliance's electronic parts
from overheating or surge currents, the hob may tem-
porarily reduce the power level.
25.2 Information on the display panel
Fault Cause and troubleshooting
No displays light up. The power supply has been disconnected.
Use other electrical appliances to check whether there has been a power fail-
ure.
The appliance has not been connected as shown in the circuit diagram.
Connect the appliance in accordance with the circuit diagram.
Electronics fault
If you are unable to rectify the fault, inform the technical after-sales service.
The displays flash. The control panel is wet or an object is covering it.
Dry the control panel or remove the object.
Ventilation system not working The appliance has not been connected as shown in the circuit diagram.
Connect the appliance in accordance with the circuit diagram.
The odour filter is saturated or the saturation indicator lights up even though the
filter has been replaced.
Change the filter and reset the filter saturation indicator. You can find additional
information about this in the section entitled .
"Cleaning and servicing", Page18
, , , , The electronics have overheated and one or all of the cooking zones have been
switched off.
Wait until the electronics have cooled down sufficiently. Then touch any button
on the control panel.
+ power level and audible sig-
nal
There is hot cookware in the vicinity of the control panel. This may cause the
electronics to overheat.
Remove the cookware. The fault display goes out shortly afterwards. You can
continue to cook.
and signal tone There is hot cookware in the vicinity of the control panel. The cooking zone has
been switched off to protect the electronics.
Remove the cookware. Wait a few seconds. Touch any button. When the fault
display goes out, you can continue cooking.
/ The cooking zone has overheated and has been switched off to protect the work
surface.
Wait until the electronics have cooled down sufficiently before switching the
cooking zone back on.
The cooking zone has been operating continuously for an extended period.
Individual safety switch-off is switched on. Touch any button to switch off the
display so that you can set the cooking zone.
/ The operating voltage is incorrect and outside of the normal operating range.
Contact your energy supplier.
/ The hob is not connected correctly.
Disconnect the hob from the mains. Connect the hob in accordance with the
circuit diagram.
Demo mode is activated.
Switch off demo mode in the basic settings.
HomeConnect is not working
properly.
Different causes are possible.
Go to
www.home-connect.com
.
Animations on the displays In certain circumstances, the hob can perform self-maintenance tasks, e.g. a firm-
ware update, optimisation or troubleshooting.
Wait until the process is complete and only then switch the hob on.
21
en Disposal
25.3 Normal noises from your appliance
An induction hob may sometimes cause noises or vibra-
tions, such as buzzing, crackling, hissing noises, fan
noises or rhythmic noises.
Disposal26 Disposal
26.1 Disposing of old appliance
Valuable raw materials can be reused by recycling.
1.
Unplug the appliance from the mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are avail-
able from your specialist dealer or local authority.
This appliance is labelled in accordance
with European Directive 2012/19/EU
concerning used electrical and elec-
tronic appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the framework
for the return and recycling of used ap-
pliances as applicable throughout the
EU.
Customer Service27 Customer Service
Function-relevant genuine spare parts according to the
corresponding Ecodesign Directive can be obtained
from Customer Service for a period of at least 10years
from the date on which your appliance was placed on
the market within the European Economic Area.
Furthermore, our Customer Service will continue to
provide you with other function-relevant and storable
genuine spare parts for up to 15years from the date on
which your appliance was placed on the market.
For more information, please contact our Customer Ser-
vice team.
Note: Under the terms of the manufacturer's warranty
the use of Customer Service is free of charge.
Detailed information about the warranty period and the
warranty conditions in your country is available via the
QR code on the enclosed document on service con-
tacts and warranty conditions, from our customer ser-
vice or on our website.
You can find the contact details for our customer ser-
vice via the QR code on the enclosed document on ser-
vice contacts and warranty conditions or on our website.
You can find the information required as per Regula-
tions (EU) 65/2014, (EU) 66/2014 and (EU) 2023/826
online at
www.bosch-home.com
on the product and ser-
vice pages for your appliance, in the area of user manu-
als and additional documents.
27.1 Product number (E-Nr.), production
number (FD) and consecutive numbering (Z-
Nr.)
If you contact Customer Service, you will require the
product number (E-Nr.), the production number (FD)
and the consecutive numbering (Z-Nr.), which you can
find on the appliance's rating plate.
The rating plate can be found:
On the appliance certificate.
On the underside of the hob, towards the front.
The product number (E no.) can also be found on the
glass ceramic. You can also display the customer ser-
vice index (KI) and the production number (FD) in the
basic settings.
Page14
Make a note of your appliance's details and the Cus-
tomer Service telephone number to find them again
quickly.
Information regarding Free and Open Source Software28 Information regarding Free and Open Source Software
This product includes software components that are li-
censed by the copyright holders as free software or
open source software.
The applicable licence information is stored on your
home appliance. You can also access the applicable li-
cence information via your HomeConnect app: "Profile
22
Declaration of Conformity en
-> Legal information -> Licence Information".
1
You can
also download the licence information on the brand
product website. (Please search on the product website
for your appliance model and additional documents). Al-
ternatively, you can request the relevant information
from [email protected] or BSH Hausgeräte GmbH,
Carl-Wery-Str. 34, 81739 Munich, Germany.
The relevant source code will be made available on re-
quest.
Please send your request to [email protected] or
BSH Hausgeräte GmbH, Carl-Wery-Str.34, 81739 Mu-
nich, Germany.
Subject: „OSSREQUEST“
The cost of performing your request will be charged to
you. This offer is valid for three years from the date of
purchase or at least as long as we offer support and
spare parts for the relevant appliance.
Declaration of Conformity29 Declaration of Conformity
BSH Hausgeräte GmbH hereby declares that the appliance with Home Connect functionality conforms to the essen-
tial requirements and other relevant provisions of Directive 2014/53/EU.
A detailed RED Declaration of Conformity can be found online at
www.bosch-home.com
among the additional docu-
ments on the product page for your appliance.
Hereby, BSH Hausgeräte GmbH declares that the appliance with HomeConnect functionality is in compliance with
relevant statutory requirements.
2
A detailed Declaration of Conformity can be found online at
www.bosch-home.co.uk
among the additional documents
on the product page for your appliance.
2
2.4 GHz band (2400–2483.5MHz): Max. 100mW
5-GHz band (5150–5350MHz + 5470–5725MHz): max. 130mW
BE BG CZ DK DE EE IE EL ES
FR HR IT CY LI LV LT LU HU
MT NL AT PL PT RO SI SK FI
SE NO CH TR IS UK (NI)
5GHz WLAN (Wi-Fi): For indoor use only.
AL BA MD ME MK RS UK UA
5GHz WLAN (Wi-Fi): For indoor use only.
29.1 Statement of Compliance for Great
Britain
Product type
This statement of compliance covers the products de-
scribed in this information for use whose model identi-
fier group is seen on the title page. The full model identi-
fier is made up of the characters before the slash in the
product number (E no.) which can be found on the rat-
ing plate. Alternatively, you can also find the model iden-
tifier in the first line of the UK Energy Label.
Name and address of manufacturer
BSH Hausgeräte GmbH, Carl-Wery-Strasse 34, 81739
München, Germany
This statement of compliance is prepared by the manu-
facturer.
The manufacturer, BSH Hausgeräte GmbH deems that it
has complied with
provision 5.1-1 of ETSI EN 303 645 v2.1.1 and,
where relevant, provision 5.1-2 of ETSI EN 303 645
v2.1.1;
provision 5.2-1 of ETSI EN 303 645 v2.1.1;
provision 5.3-13 of ETSI EN 303 645 v2.1.1.
Support period
BSH Hausgeräte GmbH will provide security updates
that are necessary to maintain the main functions free of
charge until at least 28/02/2034.
1
Depending on the appliance specifications
2
Only applies to Great Britain
23
en Test dishes
Test dishes30 Test dishes
These recommended settings are intended for test insti-
tutes to facilitate the testing of our appliances. The tests
were carried out using our cookware sets for induction
hobs. If required, these accessory sets can be pur-
chased at a later point from specialist retailers, or
through our technical after-sales service or our online
shop.
30.1 Melting the chocolate coating
Ingredients: 150 g dark chocolate (55% cocoa).
16 cm saucepan without lid
– Boiling: Power level 1.
30.2 Heating and keeping lentil stew warm
Recipe in accordance with DIN 44550
Initial temperature 20°C
Heating up without stirring
16 cm saucepan with lid, amount: 450g
– Heating up: Duration 1 min. 30 sec., power level 9
– Simmering: Power level 1.
20 cm saucepan with lid, amount: 800g
– Heating up: Duration 2 min. 30 sec., power level 9
– Simmering: Power level 1.
30.3 Heating and keeping lentil stew warm
E.g.: Lentil diameter 5–7 mm. Initial temperature 20 °C
Stir after heating for 1 minute
16 cm saucepan with lid, amount: 500g
– Heating up: Duration approx. 1 min. 30 sec., power
level 9
– Simmering: Power level 1.
20 cm saucepan with lid, amount: 1kg
– Heating up: Duration approx. 2 min. 30 sec., power
level 9
– Simmering: Power level 1.
30.4 Béchamel sauce
Milk temperature: 7 °C
16 cm saucepan without lid, ingredients: 40 g butter,
40 g flour, 0.5 l milk with 3.5% fat content and a
pinch of salt
Preparing Béchamel sauce
1.
Melt the butter, stir in the flour and salt, and heat up
the mixture.
Heating up: Duration 6 min., power level 2
2.
Add the milk to the roux and bring to the boil, stirring
continuously.
Heating up: Duration 6 min. 30 sec., power level 7
3.
Once the Béchamel sauce comes to the boil, leave it
on the cooking zone for a further two minutes.
Simmering: Power level 2
30.5 Cooking rice pudding with the lid on
Milk temperature: 7 °C
1. Heat the milk until it starts to rise up. Heat up without
a lid. Stir after heating for 10 min.
2. Set the recommended power level and add rice,
sugar and salt to the milk.
The cooking time, including heating up, is approx. 45
minutes.
16 cm saucepan, ingredients: 190g short-grain rice,
90g sugar, 750ml milk with 3.5% fat content and 1 g
salt
– Heating up: Duration approx. 5 min. 30 sec., power
level 8.
– Simmering: Power level 3
20 cm saucepan, ingredients: 250g short-grain rice,
120g sugar, 1l milk with 3.5% fat content and 1.5 g
salt
– Heating up: Duration approx. 5 min. 30 sec., power
level 8.
– Simmering: Power level 3, stir after 10 minutes
30.6 Cooking rice pudding without a lid
Milk temperature: 7 °C
1. Add the ingredients to the milk and heat the mixture
up while stirring continuously.
2. Once the milk has reached approx. 90°C, select the
recommended power level and leave it to simmer on a
low heat for approx. 50minutes.
16 cm saucepan without lid, ingredients: 190g short-
grain rice, 90g sugar, 750ml milk with 3.5% fat con-
tent and 1 g salt
– Heating up: Duration approx. 5 min. 30 sec., power
level 8.
– Simmering: Power level 3
20 cm saucepan without lid, ingredients: 250g short-
grain rice, 120g sugar, 1l milk with 3.5% fat content
and 1.5 g salt
– Heating up: Duration approx. 5 min. 30 sec., power
level 8.
– Simmering: Power level 2.
30.7 Cooking rice
Recipe in accordance with DIN 44550
Water temperature: 20°C
16 cm saucepan with lid, ingredients: 125g long-
grain rice, 300 g water and a pinch of salt
– Heating up: Duration approx. 2 min. 30 sec., power
level 9
– Simmering: Power level 2
20 cm saucepan with lid, ingredients: 250g long-grain
rice, 600 g water and a pinch of salt
– Heating up: Duration approx. 2 min. 30 sec., power
level 9
– Simmering: Power level 2.
24
Test dishes en
30.8 Roasting a pork loin
Initial temperature of the loin: 7°C
24cm pan without lid, ingredients: 3 pork loins, total
weight approx. 300g, 1cm thick, and 15g sunflower
oil
– Heating up: Duration approx. 1 min. 30 sec., power
level 9
– Simmering: Power level 7
30.9 Preparing crêpes
Recipe in accordance with DIN EN 60350-2
24 cm pan without lid, ingredients: 55 ml batter per
crêpe
– Heating up: Duration 1 min. 30 sec., power level 9
– Simmering: Power level 7
30.10 Deep-fat frying frozen chips
Pot dia. 20 cm without lid: ingredients: 2 l sunflower
oil. For each frying time: 200 g frozen chips, 1 cm
thick.
– Heating up: Power level 9, until the oil temperature
reaches 180 °C.
– Simmering: Power level 9
25
Bosch Home Connect App
Connect your home appliance today and enjoy the following
benefits:
• Is the hob switched off? Check your appliance from anywhere via
the app.
• Choose from a great range of recipes. If frying sensor available,
you can send the settings to your hob.
• Never forget to maintain your filters. When it’s time, you will get an
app notification.
Need some help?
You can find it here.
Expert advice on your Bosch home appliances, help with problems or repairs by
professionals from Bosch.
Discover all the different ways Bosch can assist you:
www.bosch-home.com/service
The contact details of all countries are listed in the attached service directory.
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
www.bosch-home.com
A Bosch Company
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
*9002025859*
9002025859 (060114) REG25
en
