Installation and User Manual
REMOTE BLOWER
RANGE HOODS
ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams
is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to
providing you an elevated experience in the heart of your home. With an endless selection of
features and finishes, our inspiration is your reality.
ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the
highest end luxury designs and professional features into everyone’s homes.
Because we continually strive to improve our products, we may change
specifications and designs without prior notice.
Scan the QR code to view the most up-to-date version of the Installation
Manual and User Manual.
WARNING: This product can expose you to chemicals including nickel, which is known to the
State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . .1
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
FREQUENTLY ASKED QUESTIONS . . . . . . . . . . . . . . . . . . . . .6
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
TABLE OF CONTENTS
1
General Safety
IMPORTANT SAFETY INSTRUCTIONS
WARNING
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury, or death.
• Before beginning installation, please read and follow these important instructions for
the safety of your home and the people living in it.
• The instructions in this manual are intended for qualified installers and certified
service technicians. Installation and electrical wiring must be completed by qualified
professionals and in accordance with applicable codes and standards.
• DO NOT attempt to install this appliance yourself. Injury could result from installing the
unit due to lack of appropriate electrical and technical background.
• The installer should leave these instructions with the consumer who should retain for
local inspectors’ use and for future reference.
• Due to the size and weight of this remote blower hood, two-person installation is highly
recommended.
• Use care when handling a remote blower and its associated range hood, such as
chimney covers, baffle filters, and any parts or accessories, as sharp edges may lead
to injury. Use of gloves during installation is highly recommended.
• The manufacturer will not be responsible for any damage to property or to persons
caused by incorrect installation, improper use of the appliance, or failure to heed the
warnings listed.
• The manufacturer reserves the right to make changes to its products when considered
necessary and useful, without affecting the essential safety and operating characteristics.
• This appliance is designed for general ventilating use only. DO NOT use to exhaust
hazardous or explosive materials and vapors.
• The combustion air flow needed for safe operation of fuel-burning equipment may
be affected by this unit’s operation. Follow heating equipment guidelines and safety
standards such as those published by the National Fire Protection Association (NFPA),
American Society of Heating, Refrigeration and Air Conditioning Engineers (ASHRAE),
and local code and government authorities.
• Sufficient air is needed for proper combustion and exhausting of gases through the
ducting installed with range hoods and remote blowers to prevent back drafting.
• Before servicing or cleaning the unit, fully disconnect the hood or remote blower from
power to avoid risk of electric shock and injury.
2
General Safety
IMPORTANT SAFETY INSTRUCTIONS
• Ducted range hoods and remote blowers MUST ALWAYS be vented to the outdoors or
in some instances converted to recirculate the air. All ZLINE hoods come with a transition
piece with a built-in damper.
• Some existing installations may already have an external damper at the exit point of the
home. In this case, the damper in the transition piece of your hood needs to be removed,
as these two dampers work against each other and will reduce the performance of the
hood and/or remote blower.
• Please consult an HVAC or installation professional for advice to comply with local
regulations and ensure appropriate ventilation.
• When cutting or drilling into a wall or ceiling, be careful not to damage electrical wiring
or other hidden utilities.
• All electrical wiring must be properly installed, insulated, and grounded. ZLINE range
hoods come with a grounded 3-prong plug that must be plugged into a dedicated 15-
amp circuit. Manipulating the plug or cutting the electrical cord will void your warranty.
• Remote blowers come with an additional cable to connect the hood and remote blower.
This cord is located inside the remote blower motor housing for shipping.
• Electrical installation must be in accordance with the National Electrical Code ANSI/
NPA70-latest edition and/or local codes.
• Old duct work should be cleaned or replaced, if necessary, to avoid the possibility of a
grease fire or other hazard. Check all joints on duct work to ensure proper connection; all
joints should be properly taped/secured.
• When a range hood ventilates air out of the room, the vented air must be replaced; this
is called makeup air. If a makeup air system is needed, but not used, a hood may not
function as expected due to negative air pressure.
• ZLINE does not currently provide makeup air units. Always consult applicable building
codes regarding minimum and maximum air flow rates. Certain states may require
additional items such as makeup air for larger CFM range hoods.
• Keep the remote blower motor and any associated fans, baffle channels, filters,
tunnels, grease cups, and grease-laden surfaces clean. Grease should not be allowed
to accumulate inside or on the surface of any range hood or remote blower; clean
surfaces frequently.
• Take care when cleaning a range hood or remote blower in spray form: never direct the
spray onto the electrical wiring, motor, button panel, or light bulbs.
3
General Safety
IMPORTANT SAFETY INSTRUCTIONS
• After installation, use a stainless steel cleaning product or wipe to eliminate any residues
from protective film after removal.
• When cleaning stainless steel, only use a stainless steel cleaner product with a soft
sponge, or use a cloth with a warm soap and water solution. Never use abrasive
powders or liquids.
• To reduce the risk of fire and to disperse air properly, make sure to vent air outside.
DO NOT vent exhaust into spaces between walls, crawl spaces, ceilings, attics,
basements, or garages.
• All ZLINE range hoods and remote blowers are ETL-listed, ensuring all parts were tested
for safety and meet industry standards and regulations.
• You must purchase appropriate flexible ducting and any additional items to vent the
hood and/or remote blower in accordance with government codes.
• Please verify with local and state regulations on the proper venting method for your
hood and remote blower. Many agencies have CFM rating specifications.
• Always turn the hood and blower on when cooking at high heat or when cooking
flaming foods. Use high settings on the cooking range only when necessary.
• Never leave range top surface units unattended at high settings. Boilovers can cause
smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings.
• Always use appropriate cookware and utensils. Always use cookware appropriate for
the size of the surface element on your range top.
• To reduce the risk of injury in the event of a range top grease fire, smother flames with
a close fitting lid, cookie sheet, or metal tray, then turn off the burner. Never pick up a
flaming pan — you may be severely burned.
• Keep flammable or combustible material away from flames. If flames do not go out
immediately, evacuate and call the fire department. DO NOT use water, including wet
dishcloths or towels — a violent steam explosion will result.
• Carefully inspect all items for damages upon delivery. Upon acceptance of the range
hood or remote blower, owner assumes responsibility for its safe arrival.
• Before installing your unit, test the range hood or remote blower for proper functionality
by plugging it into an appropriate outlet and testing the fan and lights. Do not install any
appliance if they have missing or broken parts. If units arrive damaged, contact ZLINE
Customer Service at 1-614-777-5004 for help.
4
Installation
INSTALLATION
If you’ve purchased a remote blower-type range hood, please use the following installation
instructions. Before beginning installation, be sure to connect the electrical cord to the hood
and plug the blower motor in to test the unit. You will find the power cord inside the remote
blower motor housing for shipping.
1. Run duct work into the area where you will install the remote blower from the range
hood installed in your kitchen.
2. Fasten ducting to the range hood using a hose clamp and foil-backed tape. Use the
least amount of elbows as possible.
3. Mount the remote blower to wooden studs to ensure stability.
4. The remote blower comes with a 26' (7924 mm) cable to connect the range hood and
remote blower. From the top of the range hood, route the cord carefully avoiding any
hazards to the connector on the remote blower. Plug in the power cord on top of the
range hood to a dedicated electrical outlet with a 15-amp circuit and test for proper
appliance operation before finalizing installation.
5. Run duct work from the blower to the outside of the house and add a back draft damper
outside to ensure proper air flow; see installation examples on the next page.
6.
7.
NOTE: The remote blower must be kept inside the
home, such as the attic or crawl space. Never try to
install a remote blower outside of the home.
5
Installation
INSTALLATION
Unit Connection Cord
Unit Connection Cord
Single and dual-motor remote blowers are designed to reduce noise by installing them in a
separate location inside the home, up to 20' (6096 mm) away from the range hood.
T85 Remote Blower — Single Motor
• This motor must be used with remote blower range hood
• Airflow: 400 (CFM)
• Noise Level: 1.2 / 2.6 / 4.2 / 6.5 (Sones)
• Dimensions: 26 1/8" W x 14 5/8" D x 13" H (667 mm x 371 mm x 330 mm)
T95 Remote Blower — Dual Motor
• This motor must be used with remote blower range hood
• Airflow: 280 / 460 / 670 / 700 (CFM)
• Noise Level: 1.2 / 2.8 / 5.0 / 7.0 (Sones)
• Dimensions: 26 1/8" W x 14 5/8" D x 13" H (667 mm x 371 mm x 330 mm)
6
Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS
NOTE: Some of these questions are specific to ZLINE range hoods and as such may not
be applicable to remote blowers.
Are ZLINE range hoods and remote blowers considered type 1 or type 2?
Type 1 — these types of range hoods are used with ranges, cook tops, and appliances that
produce grease and smoke.
Why is my range hood and remote blower white?
This is a protective layer that is placed on all ZLINE range hoods to prevent shipping
damage. This should be easily removable by peeling off.
Why are my range hood baffle filters blue?
This is a protective layer that is placed on ZLINE’s baffle filters to prevent shipping damage.
This should be easily removable by peeling off.
What size hood should I choose for CFM (Cubic Feet Per Minute) purposes?
1. You must determine the output of the cooktop burners of your range; this is measured in
British Thermal Units (BTUs).
2. You should provide 100 CFM of airflow per linear foot of range. To determine this,
divide the BTU rating of your range by 100. This will give you the CFM rating needed of
your range hood. For example: If your range is 35,000 BTUs, your range hood should
have a rating of 350 CFMs or greater.
3. To determine the size of the range hood for satisfactory capture of fumes and gases,
it’s recommended to go at least one size larger than the width of your range, or 3" to
6" (76 mm to 152 mm) wider. At minimum, the hood should be the same size of your
range. The range hood width also should cover 100% of the back burners and 50% of
the front burners.
4. The height of your range hood should be 30" to 36" (762 mm to 914 mm) above
your cooktop.
7
Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS
How loud is a range hood?
A sone is measure of loudness — the higher the sone rating, the louder the sound of the
hood. The sound of 1 sone is comparable to that of a quiet refrigerator. Keep in mind that
other factors such as the size of the blowers can affect the loudness of the range hood. The
higher the CFM, the louder the sone rating will be — which is why remote blowers are often
preferred to lessen noise in the kitchen.
Can my hood be ductless?
It is better to duct your range hood to the outside, but if this is not possible, ductless is an
acceptable alternative. Many ZLINE range hoods have the capability to be converted to
ductless. Ductless is when the air circulates through charcoal filters to remove odors, grease,
smoke, etc. The clean air is then re-circulated back into your home. Charcoal filters are not
reusable and need to be replaced every six months or sooner, depending on cooking style
and frequency.
What type of stainless steel are ZLINE hoods made of?
ZLINE indoor stainless steel range hoods are made with a 430 grade stainless steel. ZLINE
outdoor hoods are made of 304 grade stainless steel. The 304 grade is stronger and more
resistant to rust and corrosion.
Can I stain my unfinished wooden designer hood?
No — unfinished wood range hoods are only compatible with paint.
Do I need a chimney extension or a shortening kit when I purchase my hood?
Most ZLINE wall range hoods come with two 16" (407 mm) adjustable/telescoping
chimney covers. Designer wall hoods come with a one-piece chimney. Ensure you check
chimney dimensions before installing — short kits and longer extensions are available at
www.zlineparts.com.
8
Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS
How many amps are produced on the highest fan setting?
For dual motors, up to 3.317 amps are produced. For single motors, it is 1.678 amps.
What type of motor is in the range hoods?
ZLINE hoods are equipped with a squirrel-cage motor.
Is the width of my range hoods description, the actual size?
No — the actual width of the range hood will be slightly less than the generic description
of the range hood in order to better fit cabinet cutouts. For instance, a 30" (762 mm) range
hood will actually measure 29 1/2" (749 mm).
How do I clean my baffle filters and how often?
Your baffle filters should be washed with hot water and soap once per month or placed in a
dishwasher for cleaning. Make sure filters are completely dry before reinstalling. Re-place
the filters if they become damaged or too dirty to clean.
Can I clean my charcoal filter?
No — charcoal odor filters cannot be washed and must be discarded and replaced when
they become noticeably dirty and/or have stopped filtering the odors. They should be
replaced at least every six months.
What is the best way to duct my range hood?
For maximum performance, match your duct size to the original size of the fan’s ducting.
Use the shortest amount of ducting and keep it as straight as possible. Do not exceed 40'
(12192 mm) of ducting. For every 90° elbow, deduct 5' (1524 mm) from the total.
Do I have to exhaust the range hood to the outdoors?
Yes. If installing a range hood that has ductwork connected to it (any hoods that do NOT
recirculate the air back into the room), to properly exhaust the air, be sure to duct the air
outside. DO NOT vent exhaust air back into the spaces within the walls, ceilings, attics,
crawl spaces, or garages. A buildup of humidity and grease could cause damage and/or
a fire risk to your home.
9
Troubleshooting
TROUBLESHOOTING
• Please review this list for common troubleshooting tips before contacting customer
service, as this may save you time and money.
• This list contains frequently encountered problems that are not results of faulty
workmanship or material use.
• Some of these troubleshooting items are specific to ZLINE range hoods and as such may
not be applicable to remote blowers. Your product may not have some of the features
described here.
ISSUE POSSIBLE CAUSE SOLUTION
What do I do if the
hood is working but
pulling air slower
than normal?
Check your baffle filters
for buildup and clean or
replace it if needed.
If the problem still persists, check
for obstructions in your ductwork. A
common obstruction is buildup in the
roof or wall cap, such as bird nests,
leaves, or other debris.
My range hood will
not operate.
Check that there
is power to
the range hood.
The most common issue is that the circuit
breaker is off or the fuse has blown.
Make sure the speed has been selected
at the range hood controls.
Turn off the power to the range hood
and check that all wires are properly
connected. Refer to your specific
model’s installation instructions for
proper wiring.
My hood is making
a rattling noise.
The motor is loose.
Turn off the power and remove the filter
and check that all screws are secure
and tight around the motor.
The duct work
connection is loose.
Turn off the power to the unit and
check that the ductwork connection
to the pipe is tight. Add duct tape
if necessary.
WARNING
If a problem cannot be resolved after following the instructions in the manuals,
please contact ZLINE customer service at 1-614-777-5004. Never attempt
to repair or disassemble a faulty range hood or remote blower yourself.
Always consult a professional.
10
TROUBLESHOOTING
Troubleshooting
ISSUE POSSIBLE CAUSE / SOLUTION
My range
hood does
not have power.
Check electrical connections.
Check that all connections to the circuit board are secure.
If problem still exists, please call our customer service line.
Noisy Motor
Were the fan speeds checked fan speeds prior to installation?
Is the ducting clear?
Check to make sure motor is attached to housing.
Is the backdraft damper on the transition piece functioning
properly? Does it open when the hood is engaged?
If it is stuck, it will sound like motor noise but it’s really the damper.
Was a damper installed on the roof or side vent?
Check that the damper is fully functioning by engaging the hood
and checking if it opens and closes properly.
If the motor is accessible, the motor knob can be tightened.
11
TROUBLESHOOTING
Troubleshooting
ISSUE POSSIBLE CAUSE / SOLUTION
My range hood
is not pulling.
Was the unit plugged in and was the fan checked before
installation?
What distance is the hood mounted above the cook top?
Make sure the distance is:
• Indoor: 30"–36" (762–914 mm)
• Outdoor: 36"–42" (914–1067 mm)
Is the range hood width the correct size for the cook top?
Outdoor units should be at least 1 size larger, if not 2.
Does the hood have enough BTU output in relationship to either their
gas or electric stove cook top?
Does the hood have enough BTU output in relationship to either
their gas or electric stove cook top?
Remember — BTU output per burner/100 - for gas, and wattage
output per burner/10 - for electric.
Are the baffle filters or mesh filters installed correctly? When were
they last cleaned?
Is the ducting clear?
Is the damper opening properly once the hood is turned on?
Is there air coming out of the upper chimney section?
When tissue is placed on the baffle filters under the hood, does it
hold the tissue?
How many elbows and how long is the ducting run?
Should be no more than 2–3 elbows and no more than a 40'
(12192 mm) run to exit — for every elbow subtract 5' (1524 mm).
Is the air recirculating? When were the carbon filters last changed?
The carbon filters need changed every 3-6 months based on your
cooking habits.
WARRANTY
COVERAGE
ZLINE Kitchen and Bath (“ZLINE”) range hood parts will be warrantied for three years from
the original date of product delivery for the original purchaser of the product.
ZLINE warranty periods begin from the original date of product delivery and solely cover
the original purchaser of the product, delivered new and in its original carton. ZLINE will
provide free-of-charge, non-consumable replacement parts for the components that failed
due to manufacturing defects.
Additionally, range hoods purchased on or after January 2017 carry a lifetime warranty on
the motor. It is the responsibility of the customer to install all replacement parts and motors, as
ZLINE does not perform service repairs on its range hood products.
ZLINE’s liability is limited to the original purchase price of the product. Additional injuries,
losses, damages, or other inconveniences caused by product malfunction or defects in
materials are not covered under the terms of this warranty.
TERMS
ZLINE warranties apply only to the original purchaser of a ZLINE product installed for normal
residential use. This is defined as a single-family, residential dwelling in a non-commercial
setting. Any warranty claim stemming from installation, operation, or any other use within a
commercial setting is not covered under this limited warranty. Commercial settings include,
but are not limited to: schools, churches, hotels, restaurants, vacation rentals such as Airbnb,
daycare centers, private clubs, fire stations, common areas in multi-family dwellings, nursing
homes, food service locations, and institutional food service locations such as hospitals or
correctional facilities.
This warranty is non-transferable and will not under any circumstance be extended based on
the date of installation — the warranty period takes effect from the date of delivery and only
covers the original purchaser. The warranty applies only to products installed in the contiguous
United States and the District of Columbia.
WARRANTY
Out-of-pocket payments will not be reimbursed for replacement parts unless prior approval is
received from ZLINE. Unapproved out-of-pocket payments for parts will not be reimbursed.
Out-of-pockets for any type of service will not be reimbursed, as ZLINE does not perform
service repairs on its range hood products. All warranty procedures must be followed to
maintain warranty coverage.
If ZLINE is unable to replace the defective part after a reasonable number of attempts, ZLINE
reserves the right to offer to replace the product or provide the original purchaser a full refund
of the purchase price of the product (not including installation, removal, or other charges that
were not included in the original purchase price).
The original purchaser of the product must provide the original proof of purchase, including
the purchase date, when filing a claim to obtain replacement parts or refunds. Additionally,
the original purchaser of the product must provide the serial number of the product when filing
a claim to obtain replacement parts or refunds.
This warranty shall not apply to any ZLINE product in which the original factory serial
number has been removed, altered, or cannot be readily determined for any reason. Further,
ZLINE is not responsible for damage resulting from, but not limited to: shipment, delivery, or
improper installation; negligence or improper maintenance, misuse, or abuse of the product;
unauthorized alteration, modification, or tampering with the product; accident, fire, floods,
pest infestations, pandemics, natural disasters, or any other unpreventable or unexplained
acts of nature, commonly referred to as “acts of God”; flare-up fires or damages caused
by improper electric supply, electrical line current, voltage, or power surges; and service
to correct installation not in accordance with the instructions contained in ZLINE’s product
manuals and/or with local government codes.
Additionally, this range hood warranty does not apply to aesthetic damage, scratches,
or natural wear caused by normal use; second-hand, open box products, or products
purchased from an unauthorized retailer; consumable parts including, but not limited to, metal
and charcoal filters; and damages, problems, or any type of performance-related issues
stemming from alteration or tampering with the range hood, including, but not limited to,
painting stainless steel, black stainless, DuraSnow
®
, or designer- or wood-finished range
hoods, and cutting the 3-prong plug to manually hardwire the hood.
WARRANTY
Information contained within ZLINE’s installation and user manuals, in addition to product
information included on ZLINE’s website and all related digital listings, do not cover every
possible condition and situation that may occur during the installation or operation of
ZLINE products.
ZLINE reserves the right to make changes at any time to its products when considered safe,
necessary, and useful. Always check the ZLINE website for the most up-to-date version of its
product manuals: www.zlinekitchen.com/pages/manuals.
Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives
damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer
Experience at 1-614-777-5004 for help. Failure to report a damaged appliance prior to
installation or operation may void the warranty. ZLINE does not perform service repairs on its
range hood products.
ZLINE disclaims responsibility for damage or injury caused by improper installation or use of
any of its products. ZLINE is under no obligation, by law or otherwise, to provide concessions,
including repairs, prorates, rebates, discounts, or replacements, once the warranty has expired.
SERIAL NUMBER LOCATION
The rating tag shows the model and serial number of your
range hood. Please write down the model number and
serial number of your appliance. The serial number is
located behind the baffle filters near the motor. Both are
needed to obtain warranty service. Do not remove
permanently affixed labels, warnings, or plates from the
product. This will void the warranty. You may also consider
attaching your receipt or proof of purchase to this manual.
WARRANTY
CUSTOMER SERVICE AND PARTS INFORMATION
Please contact ZLINE Customer Service for questions and
troubleshooting help at 1-614-777-5004 or
visit www.zlinekitchen.com/contact to utilize our online Customer
Experience Portal.
Scan the QR code to view the most up-to-date version of ZLINE’s
range hood Installation and User Manuals.
Need to purchase a part or accessory for your ZLINE product? Visit
www.zlineparts.com, ZLINE’s official parts distribution partner.
