USER MANUAL
Sound System
English
INTRODUCTION
Product model: RK SH100
BT distance: ≥10m
Horn power: 40W
Batterycapacity: 4000mAh
Working hours: ≈3.5Hour(100% Volume)
Charging time: ≈5 Hour
Charging mode: Type-C 5V 2.1A
Product size: 250（L）x135（W）x135（H）mm
TOP BUTTON
①
Play mode
Conversion key
②
Volume-
Previous song
③
Play/
pause button
④
Volume +
Next song
⑤
TWS
⑥
Clock
⑦
Light /
wake up
①Short press, Mode switching
②Long press, volume-; Short press, Previous song
③BT / TF / U disc / AUX In play Short press, Pause play;
AUX In play Short press, Mute playback;
④Long press, volume+; Short press, Next song
⑤Short press, TWS to pair, Short press again TWS to disconnect
⑥Short press to flash, repress "V+-/Next" is adjust the time;Hold down the clock
button timing
⑦Short press to switch lighting modes; when the audio system is in sleep mode,
short press the lighting button to wake up the audio system; long press for 10
seconds to reset and restart the audio system.
BACK INTERFACE
①Pullleft,Power on; Pull right,Power Off
③3.5mm Audio input jack
⑤Maximum support 128G
②Type-c Power interface
④Maximum support U Disc128G
①
ON/OFF
②
Type-c
⑤
TF Card
③
AUX
④
USB
BT CONNECTION
①Pull left, Power on
②Turn on BT, Search for RK SH100 Speaker pairing
③Open the music app on your phone to enjoy music
RK SH100
TWS SERIES CONNECTION
DISPLAY DEFINITION
Supports only the function without microphone
Short press,one of them"TWS" key, When you hear the "dong" tone, the series is
successful.Instantly enjoy left and right channel 360°surround shock sound.
1. Boot, the display display mode, without any operation 30 seconds to change back
to the time display.
2.BT, TF card, U disk, AUX playthe correspondingfunctions ofthedisplayscreen
slowlyflash, pause the display long light.
FCC WARNING
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment .
This transmitter must not be co‐located or operating in conjunction with any other
antenna or transmitter.
This equipment should be installed and operated with minimum distance 20cm
between the radiator& your body.
ISED STATEMENT
This device contains licence‐exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada's licence‐exempt RSS(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Cet appareil contient des é metteurs/ré cepteurs sans licence qui sont conformes
aux RSS sans licence d'Innovation, Sciences et Dé veloppement é conomique
Canada. L'exploitation est soumise aux deux conditions suivantes:
(1) Cet appareil ne doit pas causer d'interfé rences.
(2) Cet appareil doit accepter toute interfé rence, y compris les interfé rences qui
pourraient causer un fonctionnement indé sirable de l'appareil.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Tous les changements ou modifications non expressément approuvée par le
responsible de la conformité pourrait vider l’utilisateur est habilité à exploiter
l’équipemen.
ISEDC Radiation
Exposure Statement:
This equipment complies with ISEDC RF radiation exposure limits set forth for an
uncontrolled environment.
This transmitter must not be co‐located or operating in conjunction with any
other antenna or transmitter.
This equipment should be installed and operated with minimum distance 20cm
betweenthe radiator& your body.
Cet appareil est Conforme aux limitesd’exposition de rayonnement RF ISEDC é
tabliespour un environnement non contrôlé .
Ceté metteur ne doit pas ê tre co‐implanté oufonctionner en onjunction avec
toute autreantenne ou transmetteur.
Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm
entre le radiateur et votre corps.
BATTERIES
A warning that batteries (battery pack or batteries installed) shall not be exposed
to excessive heat such as sunshine, fire or the light.
1) Replacement of a battery with an incorrect type that can defeat a safeguard;
2) Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting
of a battery, that can result in an explosion;
3) Leaving a battery in an extremely high temperature surrounding environment
that can result in an explosion or the leakage of flammable liquid or gas;
4)A battery subjected to extremely low air pressure that may result in an explosion
or the leakage of flammable liquid or gas.
制造商：京恒腾伟（惠州）电子科技有限公司
地址：广东省惠州博罗县园洲镇民营一路8号
Manufacturer: JingHeng TengWei (HuiZhou)Electronic Technology Co., Ltd.
Address: No.8, Minying 1st road, Yuanzhou Town,Boluo County, Huizhou City, Guangdong Province.
Feel free to contact us with any product issues or questions.
We will reply as quickly as possible to ensure all your needs are handled.
166-500203-001
