Smart Plug (Zigbee)
VERSION A0
User Manual
1
Operating Instruction
For initial use, Smart Plug (Zigbee) enters the pairing mode
upon power on with the LED signal indicator flashing green.
The other devices should support Zigbee 3.0 protocol.
Detailed information is in accordance with the final
product.
Download DC Home app.
Power on.
The Smart Plug (Zigbee) works intelligently with Renogy
ONE to communicate with other devices.
2
Add Smart Plug (Zigbee) to Renogy ONE.
On DC Home app, tap "+ > Add Device" in the upper right
corner of the interface.
Smart Plug (Zigbee) exits the pairing mode if there is no
next operation for a long time. To re-enter the pairing
mode, you can long press the manual switch for 5s until
the LED signal indicator flashes three times.
Prior to adding Smart Plug (Zigbee) to Renogy ONE, make
sure that Renogy ONE has been bound to DC Home app.
For details, see the User Manual of Renogy ONE.
If adding Smart Plug (Zigbee) to Renogy ONE fails, move
the plug closer to Renogy ONE and redo the adding.
Renogy ONE
Add Device
Add Gateway
25%
A
Device
Device
Battery
RBT12400LFPL-...
Controller
Scene Community Me
RCC60RVRU
%
25
A
0 0
W
0
Add Devices
Found Devices
Zigbee Plug
Cancel Confirm
3
Connect multiple devices
concurrently to Renogy ONE
Power on Renogy ONE, set the sensor to pairing mode.
Choose Renogy ONE on DC Home app, tap "+ > Add
Device". Tap the sensor name to add it to Renogy ONE.
Renogy ONE
Add Device
Add Gateway
25%
A
Device
Device
Battery
RBT12400LFPL-...
Controller
Scene Community Me
RCC60RVRU
%
25
A
0 0
W
0
Add Devices
Found Devices
Door Sensor
Cancel Confirm
Motion Sensor
Zigbee Relay
LED signal indicator (green)
On/Off LED indicator (red)
Configuration button
Manual switch
Product Introduction
4
Specifications
Model
Input
S31 Lite zb
120V AC 60Hz
Output 120V AC 60Hz
Max. Load 15A / 1800W
ZigBee IEEE 802.15.4 2.4GHz
Material PC V0
Dimensions 76 x 40 x 33 mm (2.99 x 1.57 x 1.29 in)
If you need to change the network, long press the pairing
button for 5s until the LED signal indicator changes in a cycle
of two short and one long flash and release, then the device
enters quick pairing mode and you can pair it to Renogy ONE
again.
Deleting Smart Plug (Zigbee) from DC Home app restores the
plug to factory settings.
5
Features
Switch Network
Factory Reset
Smart Plug (Zigbee) is a Zigbee 3.0 smart plug that accesses
the Internet via Renogy ONE. You can remotely turn/schedule
it on or off via your smartphone.
Supported features are determined by the specific
Renogy ONE in use.
Remote Control
Smart Scene LAN Control
Timing Schedule
6
FCC Warning
Changes or modifications not expressly approved by the party
responsible for compliance could avoid the user's authority to
operate the equipment.
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interface;
(2) This device must accept any interference received,
including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance20cm
between the radiator & your body. This transmitter must not be
co-located or operating in conjunction with any other antenna
or transmitter.
FCC Radiation Exposure Statement:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or televisionreception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
Note:
Shenzhen Sonoff Technologies Co., Ltd.
1001, BLDG8, Lianhua Industrial Park, Shenzhen,
GD, China
ZIP code: 518000
MADE IN CHINA
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
7
Disclaimer
Renogy makes no warranty as to the accuracy, sufficiency,
or suitability of information in the User Manual because
continuous product improvements are going to be made.
Renogy assumes no responsibility or liability for losses or
damages, whether direct, indirect, consequential, or
incidental, which might arise out of the use of information
in the User Manual.
Renogy is not responsible or liable for the failures,
damages, or injuries resulting from repair attempted by
unqualified personnel or improper installation and
operation.
The illustrations in the User Manual are for demonstration
purposes only. Details may appear slightly different
depending on product revision and market region.
Renogy reserves the right to change the information in the
User Manual without notice.
All trademarks are property of their respective owners.
