A3 正反面
INSTRUCTION MANUAL
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these
instructions carefully before starting the installation and keep this manual handy for future refer-
ence. If you have any another query, please contact our dealer or local vendor from whom you
have purchased the product. They are trained and ready to serve you at the best. The warranty is
valid for 2 years from the date of purchase. The warranty does not apply to damage caused by
incorrect installation or abnormal wear and tear. The company gives no warranty against damage
to any surface due to incorrect removal and installation of the product. The products are suitable
for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
MODEL
SKU
INPUT VOLTAGE
WATT
IP RATING
DIMENSION
VT-10191
24319
AC:220-240V, 50Hz
24W
IP54
69x69x800mm
TECHNICAL DATA
LED BOLLARD LIGHT
A3 正反面
WARNING
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. The light source of this luminaire is not replaceable; when the light source
reaches its end of life the whole luminaire shall be replaced.
4. Proper grounding should be ensured throughout the installation.
5. For Indoor Use only
INSTALLATION DIAGRAM
INSTALLATION INSTRUCTIONS
1. Turn o the power before starting the installation.
2. Drill two holes on the wall and insert two plastic expansion bolts in it.
3. Fix the plastic plate on the plastic expansion piece with self-tapping screws.
4. Connect the supply leads with terminal.
5. Open the lamp and install the bulb in the lamp
6. Fix the lamp body on the plate and tighten the screws.
7. Switch on and test.
V-TAC EUROPE Ltd,Rozhen bul. 41,Sofia 1271, BULGARIA
