蓝牙连接
1. 拨动开关：拨到 D 档为 HID APP 模式。
2. 首次使用（开机配对）：
a) 按 Pair 配对键开机配对，LED 快闪。
b）到系统蓝牙设备内，搜索蓝牙名为
GamepadSpace-Q37P 的设备进行配
对连接。
c）连接成功 LED 黄色常亮。
3. 再次使用（开机回 连 ）：
a）按 键开机回连，LED 慢闪。
b）回连成功 LED 黄色常亮。
4. 按Pair配对键关机
注：连接成功后，应用市场下载GamepadSpace
App 进行手柄自定义设置。
摇杆设置
摇杆校准
关机状态摇几圈摇杆后再开机，开机时请不要碰摇杆，摇杆
会自动校准。
摇杆画方圆切换：
R3 + （默认为画圆） 注： R3 键为右摇杆下压按键。
摇杆死区切换：
L3 + （默认为无死区） 注： L3 键为左摇杆下压按键。
Q37 Pro 功能示意图
方向键
X/Y/A/B 键
开机回连键
View 键
Menu 键
左摇杆/L3 键
右摇杆/R3 键
O 键
L1/L2 键
R1/R2 键
Type-C 充电口
拨动开关： 模式切换
LED 灯
Pair 开机配对键
复位孔
1
2
3
4
5
3
6
1
8
9
10
11
12
13
14
15
7
2
4 5
6
7
8
9
10
11
12
13
14
15
安卓/苹果/电脑 NS-Switch 1/2 模式
键盘鼠标多媒体
上下左右
静音
Enter
播放
鼠标左键
下一曲
音量加
上一曲
音量减
返回
切换
iOS软键盘
主页
快鼠标光标
慢鼠标光标
蓝牙连接
1. 拨动开关：拨到 K 档为 HID 键鼠模式。
2. 首次使用（开机配对）：
a) 按 Pair 配对键开机配对，LED 快闪。
b）到系统蓝牙设备内，搜索蓝牙名为
Q37 Pro for KM 的设备进行配对连接。
c）连接成功 LED 青色常亮。
3. 再次使用（开机回 连 ）：
a）按 键开机回连，LED 慢闪。
b）回连成功 LED 青色常亮。
4. 默认按键如下：
5. 按 Pair 配对键关机。
6. 键盘鼠标按键，可以通过 D 档连接的 GamepadSpace
App进行自定义。
QQ 售后群 1007622819
固件升级
安卓或苹果手机，D 档连接 GamepadSpace-Q37P 蓝牙
设备，手机应用市场下载 GamepadSpace App 进行固件
升级。
附加功能
在关机状态下，按 R1键 与 X键 不放开，再按 ，连接
安卓 ShanWan Q37 Pro 蓝牙设备，手机应用市场下
载安装 ShootingPlus App 映射玩触屏游戏。
O 键功能
X档： 无
S档： 截屏键
K档： iOS呼出软键盘
D档： 无
电性参数
工 作 电 压：
工 作 电 流：
休 眠 电 流：
规 格：
蓝牙传输距离：
电 池 容 量：
待 机 时 间：
DC3.7V
10-80 mA
< 5uA
DC5V/500mA
<= 8M
300mAh
满电放置90天
接收器连接（接收器为选配）
1. 接收器插入电脑，识别为 XBOX(即X-Input) 模式。
2. 关机状态，按住 O键 不放开，再按 连接。
3. 连接成功 LED 常亮。
4. 按 Pair 配对键关机。
手柄充电 / 休眠 / 唤醒功能
1. 手柄在充电时， LED 指示灯慢闪， 充饱后常亮。
2. 睡眠 / 唤醒功能：
配对状态： 2分钟内没有配对成功会进入休眠。
回连状态： 1分钟内没有回连成功会进入休眠。
已连接蓝牙： 15分钟内不使用会进入休眠。
按 Pair 配对键关机。 短按 键直接回连。
3. 电池电量不足时， LED 指示灯快闪提示。
陀螺仪校准
关机状态下，放平手柄，按 + A + 。
HID 与 GamepadSpace App
*注： 键可切换摇杆和按键模式
L3默认为：鼠标左键； R3默认为：鼠标右键
教程 / Tutorial
shanwan.cc/Q37Pro.html
官网 / Website
shanwan.cc
蓝牙连接
1. 拨动开关：拨到 X 档为 X-Input 模式。
2. 首次使用（开机配对）：
a) 按 Pair 配对键开机配对，LED 快闪。
b）到系统蓝牙设备内，搜索蓝牙名为
XBOX Wireless Controller 的设备
进行配对连接。
c）连接成功 LED 蓝色常亮。
3. 再次使用（开机回连）：
a）按 键开机回连，LED 蓝色慢闪。
b）回连成功 LED 蓝色常亮。
4. 按 Pair 配对键关机。
蓝牙连接
1. 拨动开关: 拨到 S 档为 Switch 模式。
2. 首次使用（开机配对）：
a) 按 Pair 配对键开机配对，LED 快闪。
b) 在 Switch 主机,选择手柄 Controllers
→ 更改握把/顺序 Change Grip/order,
进入到 Switch 主机配对界面进行配对。
c) 连接成功 LED 绿色常亮。
3. 再次使用（开机回连）：
a) 按 键开机回连， LED 绿色慢闪。
b) 回连成功 LED 绿色常亮。
4. 按 Pair 配对键关机。
作用：玩Steam、原生手柄游戏、XBOX串流、模拟器等。
（安卓9.0 / iOS13.0 / Win 10 及以上）
含 陀螺仪体感 功能，没有 NFC 功能
作用：1. 连接 NS-Switch 玩主机游戏
2. 电脑玩 Steam 游戏
作用： 连接 GamepadSpace App 对手柄进行设置拓
展更多玩法、OTA 固件升级等， GamepadSpace
App 直接从手机应用市场下载。
iOS 11.4.1/ 安卓 8.0 / Win10 / Mac 10 及以上
ShanWan 服务号
Q37 Pro Wireless Gaming Controller
L1/L2 Button
R1/R2 Button
Type-C Charging Port
Pair/Power Button
LED
Mode Switch
Reset Hole
D-pad Button
X/Y/B/A Button
Reconnect/Power Button
View Button
Menu Button
Left Joystick/L3 Button
Right Joystick/R3 Button
O Button
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
FCC ID: 2A3VP-Q37PA
Up,Down,
Left,Right
Mute
Enter
Play
Mouse click
Next song
Volume Up
Previous song
Volume down
iOS Soft keyboard
Fast mouse
cursor
Slow mouse
cursor
Android / iOS / Windows
NS-Switch 1/2 Mode
Bluetooth connection
1. Flip the switch: Switch to K to enter the
Keyboard and mouse mode.
2. First use (Power-on pairing):
a) Press the Pair button to start the pair,
and the LED will blink.
b) Turn on your device's Bluetooth search and
connect the Bluetooth device "Q37 Pro
for KM"
c) The LED is always cyan when reconnection is
successful.
3. Use again (Reconnection):
a) Press the button to power on and
the LED will blink slowly.
b) The LED is always cyan when reconnection is
successful.
4. The default buttons layout are as follows:
5. Press the Pair key to shut down the device.
6. Keyboard and mouse buttons can be customized
through the GamepadSpace App connected to D
mode.
Keyboard Mouse Multimedia
Back Switch HomePage
Charging / Sleep / Wake-up
When charging, the LED will blink slowly; When the battery is
full, the LED will keep bright.
Sleep / Wake-up function:
In pairing state: the controller will sleep if it’s not paired
successfully within 2 minutes.
Connect back state: The controller will sleep if it is not
connect back within 1 minutes.
Bluetooth is connected state: The controller will sleep if the
controller is not used within 15 minutes.
Wake-up function:
Press the to connect back when you need to wake-up it.
Joystick Settings
Rocker calibration
Shake the joystick several times in the off state and then turn
on the machine. Please do not touch the joystick when
turning on the machine. The joystick will be automatically
calibrated.
Joysticks draw square or circle
R3 + (default is circle).
Note: The R3 Button is press the Right Joystick.
Joystick dead zone switch
L3 + (default no dead zone).
Note: L3 is the left joystick down button.
*Note: can switch between joystick and button modes
L3 defaults to: left mouse button; R3 defaults to: right mouse button
3
6
1
8
9
10
11
12
13
14
15
7
2
4 5
Bluetooth connection
1. Flip the switch: Switch to D to enter the HID
APP mode.
2. First use (Power-on pairing):
a) Press the Pair button to start the pair, and the
LED will blink.
b) Turn on your device's Bluetooth search and
connect the Bluetooth device
"GamepadSpace-Q37P".
c) The LED is always yellow when reconnection
is successful.
3. Use again (Reconnection):
a) Press the button to power on and the LED
will blink slowly.
b) The LED is always yellow when reconnection
is successful.
4. Press the Pair button to power off the device.
Note: After the connection is successful, download
the GamepadSpace App to customize the
gamepadspace.
HID and GamepadSpace App
Bluetooth connection
1. Flip the switch: Switch to X to enter the
X-INPUT mode.
2. First use (Power-on pairing):
a) Press the Pair button to start the pair,
and the LED will blink.
b) Turn on your device's Bluetooth search
and connect the Bluetooth device
"XBOX Wireless Controller".
c) The LED is always blue when reconnetion is
successful.
3. Use again (Reconnection):
a) Press the button to power on and
the LED will blink blue slowly.
b) The LED is always blue when reconnection is
successful.
4. Press the Pair button to power off the device.
Bluetooth connection
1. Flip the switch: Switch to S to switch mode.
2. First use (Power-on pairing):
a) Press the Pair button to start the pair,
and the LED will blink.
b) On the switch console, select System
Settings Controllers and Sensors Change
Grip/Order to enter the switch console
matched page.
c) The LED is always green when reconnetion
is successful.
3. Use again (Reconnection):
Press the button to power on, and
automatically reconnect to the current
mode controller.
4. Press the Pair button to power off the device.
Notice
1. Don't store in a wet or high temperature place.
2. Don't throw it hard to avoid unnecessary damage.
3. Pay attention to garbage sorting. This product built-in
battery.
4. Stay away from a fire and high temperature when it
charging.
5. Non-professionals, please do not disassemble the controller
by yourself, otherwise you will lose warranty.
Function: Play Steam, native controller games,
XBOX streaming, simulator, etc.
(Android 9.0 / iOS13.0 / Win 10 and above)
Contains gyroscope somatosensory function, no NFC function
Use: 1. Connect to NS-Switch to play console games
2. Play Steam games on PC
iOS 11.4.1/ Android 8.0/ Win10/ Mac 10 and above
Function: Connect to GamepadSpace App to set up the
controller to expand more gameplay, OTA firmware upgrade,
etc. GamepadSpace App can be downloaded directly from the
mobile application market.
O key function
X mode： No function
S mode： Screenshot key
K mode： iOS calls out soft keyboard
D mode： No function
Firmware Upgrade
For Android or Apple phones, connect the D mode to the
Gamepadspace-Q37P Bluetooth device, and download
the GamepadSpace App for firmware upgrade
ABXY Position
In NS-Switch 1/2 mode, the ABXY
button positions correspond to the
silkscreen markings next to the
buttons;
In other modes, the ABXY button
positions correspond to the letters
on the buttons.
Electrical Parameters
Working voltage: DC3.7V
Working current: 10-80 mA
Sleep current: <5uA
Specification: DC5V/500mA
Bluetooth transmission distance: <= 8M
Battery capacity: 300mAh
Standby time: 90 days (fully charged)
Gyro Calibration
In the off state, lay the controller flat and press + A + .
