产品名称｜Product name
材质印刷与
技术要求
DWPF18S_美规UG
20260903
Lily
Alyssa
1：1
Manrope
160mm x 130mm
图纸设计禁止修改，尺寸以实际刀模图为准
尺寸｜Size
比例｜scale
设计师
｜
Designer
审核｜Audit
日期｜Date
设计版本号
Rev_V0_EN
字体｜Fonts
审核
1、 备注信息图层为非印刷区域，展示印刷物料基础信息。
2、 刀板线、备注工艺、尺寸层展示印刷工艺部分。
3、 画面信息层展示印刷展示图片与文字。
图层使用规范：
*电子文档为Adobe Illustrator制作
文件格式：model规格类目日期.AI （为可编辑原始文档）
文件格式：model规格类目日期.pdf （为文件转曲不可编辑文档）
裁切线
正折线
反折线
出血位
粘胶区域
*此页删除不做印刷
材质要求：157g铜版纸 双面覆哑膜
印刷要求：双面彩色印刷
上下风琴折页
Tip: The icon will keep flashing when pairing.
• Long press and for 3 seconds to activate/deactivate the child
lock function.
• When turned o, display will show while your fan is reseing to its
original position. You can enable/disable this feature by long
pressing and for 5 seconds.
Note:
Only DREO experts
give all the support
you need
Scan to read the full
user manual
Mon - Fri, 9:00 am-5:00 pm PST/PDT
(888) 290-1688
www.dreo.com
Reach out to us, it’s easy!
User Guide
Smart TurboPoly™ Fan
168S
When using the appliance for the first time, remove the wraps and aach the parts by following the
steps below.
LED Display
Working Modes
Connecting to the DREO App
Control Panel
Model No.: DWPF18S
Rated Power: 36W
Input: 120V~ 60Hz
正面
背面
DREO CUSTOMER CARE
12-MONTH LIMITED WARRANTY
What is Covered
DREO warrants to you that your product will be free from original defects in materials and workmanship for a period of twelve (12) months from the date of your purchase, when you use
your product for intended purposes in accordance with this User Manual.
Please retain your proof of purchase. If you do not retain your proof of purchase, your warranty will start two (2) months from the date of manufacture printed on your product label.
What is Not Covered
This limited warranty only applies to the original purchaser of your product and is non-transferable. This warranty is only valid if your product is used in the country in which you originally
purchased it. In addition, this warranty will not apply, and DREO will not be liable for any costs, damages, or repairs, in connection with any of the following:
• Accidents or use of your product with inappropriate force;
• Damage or destruction caused by wrong voltage or unstable electric current;
• Normal wear and tear;
• Careless operation or handling, misuse, abuse, neglect, and/or failure to maintain or use your product in accordance with this user manual;
• Any partially or completely altered, modified and/or dismantled products;
• Reduction in baery discharge time due to baery age or use (as applicable);
• Products with altered or removed serial numbers;
• Clearing any blockages from the product;
• Purchases from retailers and distributors not authorized by DREO to sell this product;
• Defects caused by or resulting from damages from shipping or handling by any third party not authorized by DREO to ship or handle your product; or
• Defects caused by or resulting from repairs, service, improper maintenance, or alteration to your product or any of its components by anyone other than a repair person authorized by
DREO.
Any service and customer support that DREO provides to you under this limited warranty will not extend the duration of this limited warranty.
Warranty Limitations and Exclusions
ANY IMPLIED WARRANTIES RELATING TO YOUR PRODUCT, INCLUDING BUT NOT LIMITED TO THE WARRANTY OF MERCHANTABILITY AND THE WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THE LIMITED WARRANTY SET FORTH ABOVE AND ARE OTHERWISE DISCLAIMED.
THIS LIMITED WARRANTY SHALL BE THE SOLE REMEDY OF THE PURCHASER OR USER OF THE PRODUCT, AND DREO SHALL NOT BE LIABLE FOR AN ALLEGEDLY DEFECTIVE OR DAMAGED
PRODUCT EXCEPT TO REPAIR OR REPLACE IT IN ACCORDANCE WITH THIS LIMITED WARRANTY. DREO WILL NOT BE LIABLE FOR SPECIAL, INCIDENTAL, INDIRECT, CONTINGENT, OR
CONSEQUENTIAL DAMAGES OR LOSSES OF ANY NATURE THAT YOU MAY INCUR IN CONNECTION WITH YOUR PURCHASE OR USE OF YOUR PRODUCT.
Some jurisdictions do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations or
exclusions may not apply to you. This limited warranty gives you specific legal rights, and you also may have other rights which vary from jurisdiction to jurisdiction.
Limited Remedies
If your product fails because of an original defect in material and/or workmanship during the warranty period, DREO will repair or replace (in DREO’s sole discretion) your product.
To obtain warranty service on your product, contact us at [email protected] or at (888) 290-1688 (available from Monday - Friday, 9:00 AM - 5:00 PM PST/PDT) for further instructions.
IN THE EVENT OF AN ORIGINAL DEFECT IN MATERIAL AND/OR WORKMANSHIP, TO THE EXTENT PERMITTED BY LAW, THE REMEDIES SET FORTH IMMEDIATELY ABOVE ARE YOUR SOLE AND
EXCLUSIVE REMEDIES.
Power
• Turn power on/o.
• Long press for 10 seconds to reset factory seings.
Fan Speed (1-9 Levels - Turbo)
• Long press for 3 seconds to switch between
Normal/Auto Mode.
Horizontal Oscillation
• Sweep airflow horizontally (0°/30°/60°/90°/120°).
• Long press for 5 seconds to start network seings
and device pairing.
Timer
• Select to set a timer (0-8h).
Faster response.
Excellent customer support.
Hassle-free returns.
Professional product guidance.
Exceptional after-sales experience.
Turn the fan body upside down.
1
3
Push the column into the base, then
screw through the flat washer, and
into the boom of the column.
4
Raise or lower the appliance to the
desired height.
5
You can put the remote control in the
holder at the back of the fan head.
2
Install the short pedestal into the
fan body.
CAUTION
1. Do not operate the
appliance if the base has
not been installed.
2. Please exercise caution
and handle the base with
care during installation.
Horizontal
Oscillation
Timer
*To learn more, please visit www.dreo.com
Look for "Smart
TurboPoly™ Fan
168S" when
connecting your
new appliance.
Scan the QR code to
download the DREO app.
Search "DREO" on Google
Play or the App Store.
OR
Normal Mode
Fan runs at the fixed speed.
Auto Mode
Fan automatically increases speed when room temp is
higher and decreases speed when temp is lower.
Turbo Mode
Fan runs at the maximum speed.
Natural Mode (Available in the DREO app)
Fan speed goes up and down intermiently to replicate
the natural breeze.
Custom Mode (Available in the DREO app)
Fan speed changes according to temperatures or time
you desire.
Sleep Mode (Available in the DREO app)
Balance comfort and noise by automatically decreasing fan
speed as you fall asleep.
Speed decreases once every 30 minutes, two times at most
per use.
Tap + Add Device and select Smart TurboPoly™ Fan 168S.
Tip: Enable Bluetooth and plug in the appliance.
Now you can control the appliance on your app!
Tip: To restart network setup, hold again for 5 seconds.
1
3
Launch the DREO app and sign in or create an account.
Tip: Verify your email address to continue.
2
4
Hold for 5 seconds to start WiFi connection seings.
This appliance features a fused safety plug that protects against overload or short-circuit situations. If the fuse blows, please cut o power and
follow the instructions below or consult a qualified electrician.
1. Grasp plug and remove from the receptacle or other outlet device. Do not unplug by pulling on cord.
2. Open fuse cover. Slide open fuse access cover on top of aachment plug towards blades.
3. Remove fuse carefully. Push the fuse from the other side to remove the fuse.
4. Risk of fire. Replace fuse only with 5 Amp. 125 Volt fuse.
5. Close fuse cover. Slide closed the fuse access cover on top of aachment plug.
4
3
2
5
1
User Servicing Instructions (Fuse)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum
distance of 20 cm between the radiator & your body. This transmier must not be co-located or operating in conjunction with any other antenna or transmier.
FCC Statement
Risk of fire. Do not replace aachment plug. Contains a safety device (fuse) that should not be removed.
Discard product if the aachment plug is damaged.
WARNING
Adjustable:
0-5 inches
Rotate
counterclockwise
Rotate
clockwise
WiFi
Connection
Auto Mode
IMPORTANT SAFETY INSTRUCTIONS
Do not use the appliance near flammables and
combustibles.
Do not cover the air inlet and outlet while
in operation.
When using electrical appliances, basic precautions should always
be followed to reduce the risk of fire, electric shock, and injury to
persons, including the following:
General Safety
1. Read all instructions before using this appliance.
2. Children should be supervised to ensure that they do not play with the appliance. Cleaning and maintenance shall not be performed by children
without supervision.
3. Use the appliance as described in the user manual only. Any other use not recommended in the user manual may cause fire, electrical shock, or
personal injury.
4. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Operation Safety
1. Place the appliance on a flat, dry surface before use.
2. Do not immerse in water or any other liquids.
3. Do not use the appliance until the base is installed.
4. Do not insert your fingers, pencils, or any other objects into the grilles while in operation.
5. Do not aempt to repair or modify any electrical or mechanical functions on the appliance. All servicing should be performed by qualified
personnel only.
Cleaning Instructions
1. Always turn o and unplug the appliance before cleaning.
2. Gently wipe o the dust with a soft, dry cloth.
3. Use a soft, dry cloth or a coon-tipped swab to remove any dust from the air inlet.
4. DO NOT use cleaning agents.
5. DO NOT use abrasive scrubbers.
6. Fire or electrical shock hazard. DO NOT immerse the main unit in water. Never allow water to get inside the appliance.
7. Except for cleaning, any servicing should be performed by an authorized service representative.
8. Store in a cool, dry area and keep the cable out of high-traic areas to avoid tripping hazards.
Electricity Safety
1. Make sure that the voltage of your electricity supply is the same as that indicated on the appliance.
2. Always unplug before cleaning or leaving the appliance unused for a long period of time. Keep your hands dry when plugging/unplugging.
3. Do not operate any fan with a damaged cord or plug. Discard the fan or return to an authorized service facility for examination and/or repair.
4. Do not run the cord under carpeting. Do not cover the cord with throw rugs, runners, or similar coverings. Do not route the cord under furniture or
appliances. Arrange the cord away from traic areas and where it will not be tripped over.
5.
WARNING: To reduce the risk of fire, electric shock, or injury to persons, do not use replacement parts that have not been recommended
by the manufacturer (e.g. parts made at home using a 3D printer).
6.
WARNING: To reduce the risk of fire or electric shock, do not use this fan with any solid-state speed control device.
7.
WARNING: If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to
avoid a hazard.
8. The appliance shall not be modified by users, such as by adding supplemental filters to the appliance.
9. Exclusive for models that include a power adapter in their package contents: The appliance is only to be used with the power adapter provided
with the appliance. Turn o the appliance before plugging in.
10. Exclusive for models that don't include a power adapter in their package contents: This product employs overload protection (fuse). A blown
fuse indicates an overload or short-circuit situation. If the fuse blows, unplug the product from the outlet. Replace the fuse as per the user
servicing instructions and check the product. If the replacement fuse blows, a short-circuit may be present and the product should be discarded
or returned to an authorized service facility for examination and/or repair.
11. Exclusive for models that don't include a power adapter in their package contents: This appliance has a polarized plug (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not aempt to defeat this safety feature.
Baery Replacement
1. Remove the baery cover in the direction indicated by the arrow.
2. Replace with two new AAA 1.5V baeries. Make sure that the positive (+) and negative (-) terminals are positioned correctly.
3. Push the baery cover back into place.
WARNING
- Replace with new baeries of the same type when replacement is required.
- Remove the baeries when the remote control is unused for a long period of time.
- Do not aempt to destroy or dismantle the baeries.
- Do not dispose of the baeries in a fire as baeries may explode or leak.
- Chemical burn hazard. Keep baeries away from children.
- Do not mix old and new baeries. Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, nimh, etc.) baeries.
- Always purchase the correct size and grade of baery most suitable for the intended use.
- Replace all baeries of a set at the same time.
- Clean the baery contacts and also those of the device prior to baery installation.
- Remove used baeries promptly.
- Non-rechargeable baeries are not to be recharged.
CHOKING HAZARD - Small parts. Not for children under 3 years.
The remote control has
no RF circuit.
1
3
2
FOR HOUSEHOLD USE ONLY
READ AND SAVE THESE INSTRUCTIONS
Reach out to us, it's easy!
www.dreo.com
HESUNG INNOVATION CORP 377 Valley Rd, Unit #2686, Clifton, NJ 07013 USA
Rev_EN_RTL_1.0
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
130MM
160MM
折痕线，不印刷
