1420838 ES-A25111K-1 A
Read the manual carefully and ensure you have fully understood
its contents before operating this device for the first time.
Italiano
Español
English
Français
Nederlands
Português
Deutsch
Accessories List
The following accessories are included with TV:
User Manual × 1 Screw × 4 (43"/50"/55"/65"/75"/100") Screw × 6 (85")
Base Stand × 2 AAA Battery × 2 Remote Control × 1
Power Cord × 1 Nut × 2 (for installing the wall mount bracket) (50"/55"/65")
Warranty Card × 1
NOTE
The accessories may be dierent from the list above due to dierent models, countries
/
regions. Please refer to the actual accessory bag.
Contents
Installation ..............................................................................................................................1
TV Front and Rear ..................................................................................................................5
Connection .............................................................................................................................7
Remote Control ......................................................................................................................9
Specifications ....................................................................................................................... 11
Other Information..................................................................................................................13
Figures and illustrations in this manual are provided for reference only and may dier
from actual product appearance.
Parts of the software function changes with the system upgrade.
This TV is equipped with a user manual and embedded E-Manual (Settings > Support >
E-Manual).
E-Manual support functions
Search
Try Now
QR Code
Find the help you are looking for.
Go directly to the function page and try it.
Scan to open the E-Manual on your mobile device.
Find what you want
English
A
Important Notice
Safety Instructions
The lightning flash with arrowhead
symbol, within an equilateral triangle is
intended to alert the user to the presence
of uninsulated dangerous voltage within
the product's enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
To ensure safe and correct use of this product, always comply with the following precautions
to avoid dangerous situations and damage to your unit:
Class II product : This symbol indicates that it does not require a safety connection
of protective earthing (ground).
AC voltage: This symbol indicates that the rated voltage marked with the symbol is
AC voltage.
Paragraphs beginning with the symbol indicate important instructions, tips or
conditions for the following settings.
For your own safety and the optimal performance of your TV, ensure to read
the safety instructions before performing any installation.
Compatibility with 3rd party products, software and services are not guaranteed. We cannot
be held liable for any damage or loss suffered whilst operating, using or connecting to
incompatible devices or apps.
The recording and playback of content on this or any other device may require permission
from the owner of the copyright or other such rights in that content. It is your responsibility
to ensure that your use of this or any other device complies with applicable copyright
legislation in your country. Please refer to that legislation for more information on the
relevant laws and regulations involved or contact the owner of the rights of the content you
wish to record or playback.
Read these instructions
Follow all instructions
Heed all warnings
Keep these instructions
All rights reserved.
Hereby, Hisense Visual Technology Co., Ltd. declares
that the radio equipment type is in compliance
with Directive 2014/53/EU and Radio Equipment
Regulations 2017 of UK. Please enter the model name
at the following internet address to read the full text of
the declaration of conformity: https://global.hisense.
com/support/certicate-download/.
Authorized EU Representative
Name: Gorenje gospodinjski aparati, d.o.o.
Address: Partizanska cesta 12, 3320
Velenje, Slovenija
Email: [email protected]
Please refer to the rating label for TV model name and nd Bluetooth remote control model name
on the remote control or inside the remote control cover.
B
The intended use and ambient conditions for this TV
This TV is intended for the rendering of video and audio signals, on a table-top or wall-
mounted, in a home or oce environment. It must not be used in rooms with a high level
of humidity or dust concentration. The warranty is only valid if used as intended by the
manufacturer.
WARNING
High humidity and dust concentration may lead to current leaks in the device. To
reduce the risk of re or electrical shock:
- Do not expose this unit to rain, moisture, dripping or splashing water, and do not
place objects lled with liquids, such as vases, cups, etc. on or over the unit.
- Do not touch the TV with wet hands.
- Do not expose to direct air-conditioning and keep candles or other naked ames
away from the TV at all times.
If the TV is moved from a cold environment to a hot environment, leave it switched o
for at least an hour to avoid condensation. If used outside, make sure it is protected from
moisture.
If you notice anything unusual, immediately remove the power plug.
In case of re, use preferably a
CO
2
gas or powder re extinguisher. If such extinguishers are not
accessible, try to isolate the electrical supply before using a water re extinguisher.
WARNING
Stability Hazard
A television set may fall, causing serious personal injury or death. Many injuries, particularly to
children, can be avoided by taking simple precautions such as:
- ALWAYS use cabinets or stands or mounting methods recommended by the manufacturer of
the television set.
- ALWAYS use furniture that can safely support the television set.
- ALWAYS ensure the television set is not overhanging the edge of the supporting furniture.
- ALWAYS educate children about the dangers of climbing on furniture to reach the television
set or its controls.
- ALWAYS route cords and cables connected to your television so they cannot be tripped over,
pulled or grabbed.
- NEVER place a television set in an unstable location.
- NEVER place the television set on tall furniture (for example, cupboards or bookcases)
without anchoring both the furniture and television set to a suitable support.
- NEVER place the television set on cloth or other materials that may be located between the
television set and supporting furniture.
- NEVER place items that might tempt children to climb, such as toys and remote controls, on
the top of the television or furniture on which the television is placed.
If your existing television set is being retained and relocated, the same considerations as above
should be applied.
C
Moving/Transportation
Before moving this TV, disconnect all cables
and move in the vertical position only. Grasp
the device on the upper and lower edges of the
frame.
- Do not press or put stress on the front
panel of the TV. It may take two or more
people to carry larger TVs.
If you have to briey lay down the TV, place the
unit with its entire front surface lying at on soft
material.
The LED screen is made of glass and can
break if is not handled properly. Always wear
rubber gloves to carry the unit. If the LED
screen is damaged, liquid crystal might leak
out. In case of skin contact, immediately rinse
thoroughly with water.
Power Supply
Incorrect voltages can damage the TV. Only
connect this unit to a power supply with the
correct voltage and frequency noted on the
type plate, using the supplied power cable.
The power plug must be easily accessible so
that the device can be disconnected at all time.
The unit is live, even if in standby mode, as
long as the unit is connected to a power outlet.
It is recommended that this unit is placed on a
dedicated circuit.
- Do not overload the power outlets by
connect too many appliances to the same
outlet. Overloaded wall outlets, extension
cords, etc. are dangerous and can result in
electric shock and re.
- Switch o the television after use and unplug
it if it is not going to be used for.
After power o, don't turn it on again in 5 seconds.
Frequent switching power supply in a short period
of time can cause abnormal TV.
Power plug and power cable
-
Do not touch the power plug with wet hands.
- Do not place heavy objects on the power
cable. Route the cable so that it is not
kinked or laid over sharp edges, walked on
or exposed to chemicals. A power cable
with damaged insulation can cause electric
shock and re.
- Pull the power plug, NOT on the cable
when disconnecting. The cable can
become damaged and cause a short circuit
if pulled on.
- Do not place the power cable near a high
temperature object.
- Do not move the TV with the power cable
plugged into a socket.
- Do not use a damaged or loose power
cable, or a damaged socket outlet.
- Do not use any power cords other than the
one supplied with this unit.
- MAIN plug on the power cord is used as
the disconnect device, the disconnect
device and socket-outlet shall be easily
accessible.
Set-up
Check that the location is suitable to bear the
load of the TV. Place on a level, sturdy and
horizontal base. Ensure that the unit does not
hang over the edge of the base when placed in
or on furniture. If placed on a cart, use caution
when moving to avoid the unit from tipping over.
- Choose a good location for the television, in a
clean place, away from sources of heat (sun,
radiators, replaces), plants (pollen, dust,
water) and the ground (risk of knocks, dust).
- Place the unit in a normal upright horizontal
position. It must never be operated
vertically, lying at or hanging overhead
from the ceiling.
When mounting the TV on a wall, follow the
instructions supplied with the wall-mount, make
sure not to install the TV by hanging the power
and signal cables on the back of the TV.
Air ventilation and high
temperatures
Install your TV only where there is proper
ventilation, and ensure that there is at least 10
cm free space on the sides and 20 cm above
the unit for air circulation. Excessive heat and
obstruction of ventilation could lead to re or
early failure of some electric components.
- Do not place cloth, paper or other materials
over the openings on the top, sides or
bottom of the appliance.
D
- Take care not to touch the ventilation
openings since they may become hot.
- Do not insert foreign objects into the TV
through the vents.
20cm
10cm
10cm
10cm
The Stand
- Do not use any stand other than the one
supplied with this unit.
- Do not modify or use the stand if it becomes
warped of physically damaged.
- During setup, make sure that all the screws
are securely tightened.
- Ensure that the TV does not suer any impact
during the attachment of the stand.
- Ensure that children do not climb onto the
stand.
- Attach or remove the stand with at least two
people.
Prevent small items from getting into the interior
of the device through the ventilation slots. Such
objects may cause short circuits, which may
cause re.
If something should get inside the unit,
immediately unplug the power plug of the
device and contact service support.
The LED screen
Despite thorough care when manufacturing
this display, it cannot be 100% guaranteed that
no sub-pixel defects will occur due to technical
reasons. These cannot be considered as a device
defect in terms of the guarantee. They will not
aect the performance and reliability of the TV.
To prevent “image burn”, avoid displaying still
images for long periods of time, there is a
possibility that a copy of the image may remain.
If the aspect ratio is set to 4:3 for a long period of
time, image burn may occur on the black areas.
Image burn is not covered by the warranty.
- Do not apply strong force or impact on the
display panel.
Avoid touching the LED screen or touching it
for long periods of time. Doing so may produce
some temporary distortion eects on the screen.
Radio waves
- Do not use the TV in any medical
institutions or locations with medical
equipment. Radio waves may interfere with
medical equipment and cause malfunction.
- Do not use the TV near any automatic
control equipment such as automatic doors
or re alarms. Radio waves may interfere
with automatic control equipment and cause
malfunction.
If you have a cardiac pacemaker, keep a
distance of at least 22 cm from the TV. Radio
waves may interfere with the operation of a
pacemaker.
Built-in wireless LAN
- Do not connect to wireless networks that
you do not have the usage rights for. Data
transmitted and received over radio waves
may be intercepted and monitored.
The built-in wireless LAN uses 2.4 GHz and
5 GHz frequency band. To avoid malfunctions
or slow response caused by radio wave
interference, keep the TV away from
devices such as other wireless LAN devices,
microwaves, mobile phones, and other devices
that use 2.4 GHz and 5 GHz signal.
Warning about o-gassing
New furniture, carpet, paint, building materials
and electronics can release chemicals into
the air through evaporation. After you set your
TV up and turn it on for the rst time, you may
notice a slight smell within a couple of hours.
This is because some components of TV are
heating up for the rst time. The materials
that we use fully meet the environmental
requirements and regulations. Your TV is
working just ne and the fumes from the o-
gassing will diminish eventually.
E
Supervision
- Do not let children play unsupervised close
to the TV. It could tip over, be pushed o
or pulled down from the stand surface and
injure someone.
- Do not allow a switched-on TV to run
unattended.
Volume
Loud music and noises can lead to irreversible
damage to your ears. Avoid extreme volume,
especially over long periods and when using
headphones.
If you hear a drumming noise in your ears, turn
down the volume or temporarily stop using
headphones.
Thunder Storms
Pull out the power plug and all connected
antenna cables from the TV during a
thunderstorm. Overvoltage caused by lightning
strikes can damage the TV via the antenna
system, as well as the wall socket.
Long periods of absence
As long as the power plug is connected to a live
socket outlet, the TV will consume power even in
standby mode. The power plug and all connected
antenna cables should be disconnected out
during long periods of absence.
Cleaning and care
CAUTION:
Unplug the power cord prior to cleaning the TV.
Clean the screen with a soft, dry cloth after
switching o and unplugging the television.
And avoid glass sprays and other household
cleaning agents. Do not use any chemicals.
-
Do not subject the surfaces to insect repellent,
solvent, thinner or other volatile substances.
This may degrade the surface quality.
- Do not spray water or other liquids directly
on the TV. Liquid inside the TV could lead
to product failure.
- The surface of the display panel is treated
and may be easily damaged. Take care not to
scratch it with ngernails or other hard objects.
- Also wipe the power plug with a dry cloth at
regular intervals.
Service/Repair
Never remove the cover/back of the TV; there
are no user serviceable parts inside. Refer all
service to qualied service personnel.
Packaging
Keep the anti-moisture materials and plastic bags
out of reach of children.
Plastic bags can cause suocation and the anti-
moisture material is harmful if swallowed. If
swallowed by mistake, force the patient to vomit
and visit the nearest hospital.
Modication
Do not attempt to modify this product in any way.
Unauthorised modication could void the warranty
of this unit, cause electric shock and res.
Remote Control batteries
- Store the remote control carefully, do not
expose it to liquids and check the condition
of the remote control batteries regularly to
prevent corrosion of the contacts.
- Incorrect installation may cause battery
leakage, corrosion and explosion.
- Replace only with the same or equivalent
type.
- Do not mix old and new batteries.
- Do not mix dierent battery types.
- Do not use rechargeable batteries.
- Do not burn or break up batteries.
- Be sure to dispose of batteries correctly.
- Do not expose batteries to excessive heat
such as sunshine, re or the like.
Outdoor Antenna Grounding
If an outdoor antenna used, be sure the
antenna system is protected against voltage
surges and built-up static charges.
Disposal
Refer to the recycling section of this manual.
1
CAUTION
Be sure to disconnect the AC power cord before installing a stand or wall mount
brackets.
The display on your TV is fragile. Make sure the TV screen is not scratched or damaged
by hard objects or from pressure.
After the installation is completed, make sure the TV is steady on a table or firmly attached
to a wall mount, before removing all protective film, if any.
Installation
Installing the stand
1. Carefully place your TV face-down (face-up for 85") on a soft, flat surface to prevent
damage to the TV or scratching to the screen.
2. Take out the 2 stands from the accessory bag and then insert the stands into the bottom
slots of the TV.
3. Secure the stands to the TV with the 4 screws (43"/50"/55"/65"/75") / 6 screws (85") in
accessory tightly.
Follow the illustrations and textual instructions below to complete the installation steps:
65"
Base Stand
Base Stand
Screws: M5×12
For 43"/50"/55"/65"/75"/85"
43"/50"/55"
Base Stand
Screws:
M4×16 (43")
M5×12 (50"/55")
Base Stand
2
Note: If your table is long enough to place the TV on top of, then insert the base stands into the
screw holes ‘A’ that are shown in the illustration. If your table is NOT long enough, then insert
the base stand into the screw holes ‘B’ that are shown in the illustration. Note that these two
installation methods types cannot be mixed.
75"/85"
Base Stand
Base Stand
A
A
Screws: M5×12
B
Base Stand
Base Stand
Screws:
M5×12
B
75"
85"
A
A
B
B
Base Stand
Base Stand
Base Stand
Base Stand
Screws: M5×16
Screws:
M5×16
3
1. One person holds the side of the TV, and the others remove the side cushions. Do not
pinch the screen when hold the TV.
2. Insert the TV base stands into the bottom slots on your TV. Use the screws provided to
secure each base stand tightly.
3. It takes three persons to transport the TV. The weight of TV with base stands is 114.4
lbs (52.0 kg), the furniture where the TV is placed should be tough enough to support.
Please make sure the width of the furniture is above 18.9 inches (480 mm).
NOTE: Three or more persons are needed to install the TV. One person holds the TV to
prevent tipping through the whole installation process.
For 100"
side cushions
Base Stand
Screws:
M5×16
Base Stand
Screws:
M5×16
4
CAUTION
When mounting the TV on a wall, follow instructions provided with the wall mount bracket. If it is
not correctly mounted, the TV may fall and cause property damage or personal injury.
NOTE
The diameter and length of the screws differ depending on the wall mount bracket model.
Wall mount bracket is optional. Your TV may not have wall mount bracket. Please refer to
the actual accessories.
Place spacers between the TV and bracket.
Standard dimensions are shown below.
We do not recommend hanging the TV on a slanted wall, and when
wall mounting make sure your television remains parallel to the wall
and does not lean forward.
TV
screen
Vertical
surface
Installing the wall mount bracket
Before you follow the third-party manufacturer instructions to attach the wall mount, be sure
to do the following things:
1.
Place the TV on a clean, safe and cushioned surface.
2.
Remove the TV stands if you have already attached them.
3. Take the nuts out of the accessory bag and tighten the nuts into the holes of the back
cover (See Fig. 1). (only for 50"/55"/65")
4.
Place spacers (not included) between the TV and the bracket (See Fig. 2).
Screw
(not included)
Bracket
(not included)
Spacer
(not included)
Fig.2
Fig. 1
Nuts: (M6×12) ×2
Wall mount hole
pattern (mm)
200 × 300 (43")
200 × 400 (50"/55")
300 × 400 (65")
400 × 300 (75")
600 × 400 (85")
800 × 400 (100")
Wall mount screw
size
M6 (43"/50"/55"/65"/75")
M8 (85"/100")
Number of wall
mount screw
4
8.0 - 10.0 mm (43"/50"/55"/65")
9.5 - 11.5 mm (75"/85")
11.0 - 13.0 mm (100")
Wall Mount Bracket
Wall Mount Screw
Wall Mount Spacer
Rear cover
of the TV
5
TV Front and Rear
Power indicator/
Power button (Standby/Source)
43"/50"/55"/65"/75"/85" 100"
Item Description
Power indicator The light is white in standby mode.
Power button
(Standby/Source)
Press the button to turn the TV on. Press it again to bring up the
control menu and move the focus between different inputs. Long
press the button to make a selection.
Built-in microphone
control button (100
"
)
Switch the built-in microphone control button to on
to use the built-
in microphone.
After the Alexa or VIDAA Voice setup has been completed and
Hands-Free mode is turned on, you can use Hands-Free Wake-
up, just say "Alexa" or "Hey VIDAA" to call up the voice assistant.
Power indicator /
Power button
(Standby/Source)
Built-in microphone
control button
MIC
Voice indicator
NOTE
ANT2 Jack supports power supply for satellite antenna (13/18V, 420mA max).
Check the jacks for position and type before making any connections. Loose
connections can result in image or colour problems. Make sure that all connections are
tight and secure.
Not all A/V devices have the ability to connect to a TV, please refer to the user’s manual
of your A/V device for compatibility and connections procedure.
Before connecting external equipment, remove the mains plug from the wall socket.
Otherwise, it may cause electric shock.
Powering on the TV requires several seconds to load programmes. Do not rapidly turn
the TV off as it may cause the TV work abnormally.
The Picture is Only for Reference.
Before using Hands-Free Wake-up, connect your TV to the network. The Hands-Free
Wake-up and some of its features are available on limited country/region/language.
6
LAN
DIGITAL
AUDIO OUT
ANT 2
DVB-S/S2
13/18V 420mA
ANT 1
DVB-T/T2/C
HDMI 3
4K@144Hz
HDMI 2(eARC)
4K@144Hz
COMMON INTERFACE (CARD FACE FRONT)
HDMI 1 (
4K@60Hz
)
USB×2
DC 5V 0.5A(MAX)×2
AV IN
43"/50"/55"
HDMI 2 (4K@60Hz)
ANT 2
DVB-S/S2
ANT 1
DVB-T/T2/C
HDMI 4
4K@144Hz
HDMI 3(eARC)
4K@144Hz
USB 1
DC 5V 1A(MAX)
HDMI 1 (4K@60Hz)
AV IN
13/18V 420mA
65"/75"/85"
100"
AC INPUT
43"/50"/55"
65"/75"/85"
AC INPUT
100"
AC INPUT
7
Connection
Terminals
or
ANT OUT
ANT 1
DVB-T/T2/C
ANT 2
DVB-S/S2
HDMI
DVD/Blu-Ray/AV receiver/
Set-top Box
HDMI
Audio Amplier/Speaker
HDMI (eARC)
HDMI
Audio Amplier/Speaker
DIGITAL
AUDIO OUT
HEADPHONE
NOTE
Excessive sound pressure from earphones and headphones can cause hearing loss.
AV IN
NOTE
Do not repeatedly insert or remove the Common
Access Module as this may damage the interface and
cause a malfunction.
You must obtain a CI+ module and card from the
service provider of the channels you want to watch.
CI+ is not supported in some countries and regions.
White(L)
Red(R)
Yellow(Video)
Cables are not included.
VCR/DVD Player/
Recorder/Set-top box/
Satellite Receiver/
Video Camera
Video
L
A/V OUT
R
NOTE
Exceeding a total current consumption may result in damage. The USB 1.1 and USB
2.0 devices maximum current consumption are 500mA. The USB 3.0 device maximum
current consumption is 1A (only for some models).
For individual non-standard high-capacity mobile hard disk, if its impulse current is
greater than or equal 1A, it may cause TV-rebooting or self-locking. So the TV does not
support it.
USB
DC 5V 1A(MAX) DC 5V 0.5A(MAX)
USB
CAM CARD
65"/75"/85"/100"
8
Wireless router with DHCP
LAN Cable
Wireless LAN Adapter
built-in TV set
NOTES
You must use the built-in Wireless LAN Adapter to use a wireless network because the set
doesn’t support external USB network adapters.
If the wireless router supports DHCP, your TV can connect more easily to the wireless
network.
If you apply a security system other than the systems listed below, it will not work with the TV.
Security system: WPA, WEP, WPA2, WPA3.
In order to guarantee smooth network, the distance between router and TV should be less
than 10 metres.
Wireless setup
To connect your TV to your network wirelessly, you need a wireless router or modem.
See the illustration below.
·
The built-in Wireless LAN Adapter supports the IEEE 802.11a/b/g/n/ac
communication protocols. It is recommended to use IEEE 802.11ac router. Low
transfer rates for b/g may have the influence on the quality of streamed videos and
other media.
LAN (Wired setup)
Connect your TV to your network by connecting the LAN port on the back of your TV to an
external modem or router using a LAN (Ethernet/Cat 5) cable. See the illustration below.
·
It is recommended to use a modem or router that supports Dynamic Host
Configuration Protocol (DHCP). Modems and routers that support DHCP
automatically provide the IP address, subnet mask, gateway, and DNS, so you don’t
have to enter them manually. Most home networks already have DHCP.
TV JACK
Modem CableLAN CableLAN Cable
External Modem
(ADSL / VDSL / Cable TV)
IP Sharer (Router)
(with DHCP server)
9
Remote ControlRemote Control
Buttons of remote control
NOTE
The included remote control will vary depending on model, country/region. Check
information according to the actual remote control in the accessory bag.
Buttons listed here are for reference only. Actual remote control may vary depending on
model, country/region.
BUTTON DESCRIPTION
Power on/Standby
Select input sources
Number button Select a channel or input numbers
Four colour buttons Special function buttons
GUIDE
Display the Electronic Program Guide (DTV mode);
for models with
button, long press to be used
as CH.LIST
CH.LIST Display the Channel List on the screen
Playpad keys
Press to enter Menu
(˄
/
˅
/
˂
/
˃) D-pad (up/down/left/right navigation buttons)
OK Conrmation button
Under the Menu or App, return to the previous place
Display the Home screen
VOL Volume (up/down)
CH Channel (up/down)
Mute and restore sound; for models with but-
ton, long press to be used as SUBTITLE
EXIT Exit the menu or exit the application
Activate the microphone
INFO
Display the current program information; for models
with
button, long press to be used as TEXT
SUBTITLE/SUB. Activate or deactivate the subtitle mode
Custom button to launch contents quickly
TEXT
Turn on/o the teletext function; for models with
button, long press to be used as INFO
APP Quick access buttons to APP
Fast access to search
Select a channel or input numbers and special
function buttons
APP
APP
10
Installing Batteries in the Remote Control
1. Slide the back cover to open the battery compartment
of the remote control.
2. Insert two AAA size batteries. Make sure to match
the (+) and ( - ) ends of the batteries with the (+)
and ( - ) ends indicated in the battery compartment.
3. Close the battery compartment with the cover.
NOTE
Product image is only for reference, actual product may vary in appearance.
Dispose of your batteries in a designated disposal area.
Do not mix battery types or combine used batteries with new ones.
Remove depleted batteries immediately to prevent battery acid from leaking into the
battery compartment.
If you do not intend to use the remote control for a long time, remove the batteries.
Leaving a battery in an extremely high temperature surrounding environment that can
result in an explosion or the leakage of flammable liquid or gas.
Battery chemicals can cause a rash. If the batteries leak, clean the battery compartment
with a cloth. If chemicals touch your skin, wash immediately.
Risk of fire or explosion if the battery is replaced by an incorrect type.
Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a
battery, that can result in an explosion.
A battery subjected to extremely low air pressure that may result in an explosion or the
leakage of flammable liquid or gas.
Pairing the Remote Control (only for Bluetooth remote control)
Pair the remote to the TV after you power it on. Keep the remote control within 3 metres
from the TV. Press any button (except power and mic button) to pair.
NOTE
In special cases, press and hold [ ] button to pair.
If an unknown error occurred with the remote, then it could have been caused by
interference. Try to remove what's causing the interference and pair it again.
If an unknown error occurred in the remote control while the battery power is normal,
you can take out the batteries, press any key for 1~2 seconds, and insert them back.
Then the remote control will work normally.
The remote cannot be paired to the TV while the TV is in standby mode.
Remote Control Operation Range
Disposal of this unit
Product should not be damaged, dismantled or thrown in municipal waste.
It should be packed and handed over to authorised re-cycler.
1. The remote control can work at a distance of up to 8
metres in
front of the TV set.
2. The remote control angle: taking the remote sensor as
an apex, 6 metres away, its controlled horizontal angle is
within ±30°, while the vertical angle is within ±15°.
3. The operating distance may vary depending on the
brightness of the room.
6m
8m
6m
6m
8m
6m
30° 30°
15°
15°
11
Features, appearance and specifications are subject to change without notice.
Specications
Item
43" 50"
Dimension
(W × H × D)
Without Stand
37.9
× 22.0 ×2.9 inches
(963 × 560× 74 mm)
44.1 × 25.7 × 3.1 inches
(1119 × 654 × 80 mm)
With Stand
37.9 × 24.1 × 8.8 inches
(963 × 611 × 223 mm)
44.1 × 27.6 × 10.8 inches
(1119 × 702 × 274 mm)
Weight
Without Stand 16.3 lbs (7.4 kg) 20.7 lbs (9.4 kg)
With Stand 17.2 lbs (7.8 kg) 20.9 lbs (9.5 kg)
Active Screen Size (Diagonal) 108 cm 126 cm
Audio power 10W × 2 10W × 2
Operating mode power density 0.022 Watts/cm² 0.018 Watts/cm²
Item
55" 65"
Dimension
(W × H × D)
Without Stand
48.6 × 28.2 × 3.1 inches
(1234 × 717 × 80 mm)
57.2 × 33.1 × 3.0 inches
(1453 × 840 × 76 mm)
With Stand
48.6 × 30.2 × 10.8 inches
(1234 × 768 × 274 mm)
57.2 × 35.3 × 11.8 inches
(1453 × 897 × 300 mm)
Weight
Without Stand 24.5 lbs (11.1 kg) 33.1 lbs (15.0 kg)
With Stand 24.9 lbs (11.3 kg) 33.5 lbs (15.2 kg)
Active Screen Size (Diagonal) 139 cm 164 cm
Audio power 10W × 2 10W × 2
Operating mode power density 0.016 Watts/cm² 0.018 Watts/cm²
Item
75" 85"
Dimension
(W × H × D)
Without Stand
66.0 × 38.0 × 3.4 inches
(1676 × 965 × 87 mm)
74.5 × 43.0 × 4.0 inches
(1892 × 1091 × 101 mm)
With Stand
66.0 × 41.1 × 14.6 inches
(1676 × 1044 × 370 mm)
74.5 × 46.8 × 17.7 inches
(1892 × 1189 × 450 mm)
Weight
Without Stand 50.3 lbs (22.8 kg) 77.6 lbs (35.2 kg)
With Stand 50.9 lbs (23.1 kg) 78.9 lbs (35.8 kg)
Active Screen Size (Diagonal) 189 cm 215 cm
Audio power 15W × 2 15W × 2
Operating mode power density 0.013 Watts/cm² 0.017 Watts/cm²
12
Item
100"
Dimension
(W × H × D)
Without Stand
87.8 × 50.6 × 3.7 inches
(2229 × 1284 × 95 mm)
With Stand
87.8 × 51.9 × 18.9 inches
(2229 × 1317 × 480 mm)
Weight
Without Stand 111.1 lbs (50.5 kg)
With Stand 114.4 lbs (52.0 kg)
Active Screen Size (Diagonal) 253 cm
Audio power 15W × 2 + 20W
Operating mode power density 0.017 Watts/cm²
Network standby power consumption
≤ 2.0 W
Power consumption in standby mode
0.5 W
Screen resolution 3840 × 2160
Power consumption Please refer to the rating label.
Power supply Please refer to the rating label.
Receiving
systems
Analog PAL-D/K, B/G, I, SECAM-D/K, B/G
Digital DVB-T/T2, DVB-C, DVB-S/S2
Wireless
LAN Module
specifications
Frequency Range
2.4-2.4835GHz
5.15-5.85GHz
Output Power
(Max.)
2.4-2.4835GHz 17dBm
5.15-5.25GHz 14dBm
5.25-5.35GHz(DFS Band) 14dBm
5.49-5.71GHz(DFS/TPC Band) 14dBm
5.725-5.85GHz(for Non EU) 14dBm
Bluetooth
Module
specifications
Frequency Range
2.4-2.4835GHz
Output Power
(Max.)
2.4-2.4835GHz, Class1, 6dBm
Environmental conditions
Temperature: 41°F - 95°F (5°C - 35°C)
Humidity: 20% - 80% RH
Atmospheric pressure: 86 kPa - 106 kPa
HDMI Input
RGB / 60Hz (640×480, 800×600, 1024×768)
YUV / 60Hz (480i, 480p, 720p, 1080i, 1080p)
YUV / 50Hz (576i, 576p, 720p, 1080i, 1080p)
3840×2160 / 24Hz, 3840×2160 / 25Hz,
3840×2160 / 30Hz, 3840×2160 / 50Hz,
3840×2160 / 60Hz
For HDMI 2, 3 (43"/50"/55") or HDMI 3, 4 (65"/75"/85"/100"):
3840×2160 / 120Hz, 2560×1440 / 120Hz,
1920×1080 / 120Hz, 3840×2160 / 144Hz,
2560×1440 / 144Hz, 1920×1080 / 144Hz
13
Recycling/Licenses
WEEE (Waste Electronic Electric Equipment)
European Directive 2012/19/EU
This symbol on the product or on its packaging indicates that this
product must not be disposed of with your household waste. Instead, it
is your responsibility to dispose of your waste equipment by handing it
over to a designated collection point for the recycling of waste electrical
and electronic equipment. The separate collection and recycling of your
waste equipment at the time of disposal will help to conserve natural
resources and ensure that it is recycled in a manner that protects
human health and the environment. For more information about where
you can drop o your waste equipment for recycling, please contact
your local city oce, your household waste disposal service or the shop
where you purchased the product.
Batteries
In accordance with the Battery Directive, used batteries should not
be disposed of in the domestic waste. Dispose your batteries in the
collection containers specic for this purpose in retail stores.
ROHS (Restriction of Hazardous Substance)
European Directive 2011/65/EU
This European directive limits the use of dangerous and hazardous
substances which are dicult to recycle.
This allows recycling easily the EEE and contributes to the
safeguard of the environment.
Substances included in this product match to the RoHS directive.
The terms HDMI, HDMI High-Denition Multimedia Interface, HDMI
Trade dress and the HDMI Logos are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc.
Dolby, Dolby Vision, Dolby Atmos, and the double-D symbol are
registered trademarks of Dolby Laboratories Licensing Corporation.
Dolby Vision IQ is a trademark of Dolby Laboratories Licensing
Corporation. Manufactured under license from Dolby Laboratories.
Confidential unpublished works. Copyright © 2012-2024 Dolby
Laboratories. All rights reserved.
FOR DTS PATENTS, SEE HTTP://XPERI.COM/DTS-PATENTS/.
MANUFACTURED UNDER LICENSE FROM DTS, INC. AND ITS
AFFILIATES. DTS, DTS:X, AND THE DTS:X LOGO ARE REG-
ISTERED TRADEMARKS OR TRADEMARKS OF DTS, INC.
AND ITS AFFILIATES IN THE UNITED STATES AND/OR OTHER
COUNTRIES. © DTS, INC. AND ITS AFFILIATES. ALL RIGHTS
RESERVED.
Other Information
EPREL Registration Information
43E7Q PRO (2335472)
43E77Q PRO (2335480)
43E78Q PRO (2335482)
43E79Q PRO (2335484)
43E71Q PRO (2335487)
43E7QTUK PRO (2335489)
43E77QTUK PRO (2335491)
43E78QTUK PRO (2335492)
43E79QTUK PRO (2335493)
50E7Q PRO (2335660)
50E77Q PRO (2335674)
50E78Q PRO (2335675)
50E79Q PRO (2335676)
50E71Q PRO (2335679)
50E7QTUK PRO (2335680)
50E77QTUK PRO (2335681)
50E78QTUK PRO (2335684)
50E79QTUK PRO (2335685)
55E7Q PRO (2186208)
55E77Q PRO (2186446)
55E78Q PRO (2186452)
55E79Q PRO (2186454)
55E71Q PRO (2186455)
55E7QTUK PRO (2186456)
55E77QTUK PRO (2186458)
55E78QTUK PRO (2186460)
55E79QTUK PRO (2186462)
65E7Q PRO (2171187)
65E77Q PRO (2171225)
65E78Q PRO (2171226)
65E79Q PRO (2171229)
65E71Q PRO (2171230)
EPREL-Registrierungsdaten Informação de Registo EPREL
Información del registro EPREL Informations sur l'enregistrement EPREL
Informazioni di registrazione EPREL EPREL-registratiegegevens
65E7QTUK PRO (2171233)
65E77QTUK PRO (2171234)
65E78QTUK PRO (2171236)
65E79QTUK PRO (2171237)
75E7Q PRO (2194199)
75E77Q PRO (2194215)
75E78Q PRO (2194225)
75E79Q PRO (2194230)
75E71Q PRO (2194232)
75E7QTUK PRO (2194233)
75E77QTUK PRO (2194236)
75E78QTUK PRO (2194239)
75E79QTUK PRO (2194240)
85E7Q PRO (2218309)
85E77Q PRO (2218339)
85E78Q PRO (2218340)
85E79Q PRO (2218343)
85E71Q PRO (2218346)
85E7QTUK PRO (2218349)
85E77QTUK PRO (2218351)
85E78QTUK PRO (2218360)
85E79QTUK PRO (2218362)
100E7Q PRO (2248973)
100E77Q PRO (2248978)
100E78Q PRO (2248980)
100E79Q PRO (2248982)
100E71Q PRO (2248984)
100E7QTUK PRO (2248986)
100E77QTUK PRO (2248987)
100E78QTUK PRO (2248988)
100E79QTUK PRO (2248989)
