USER’S OPERATION MANUAL
Before operating this unit, please read this manual
thoroughly, and retain for future reference.
This is a short version of the User’s Manual. For more information,
please scan the QR code above to view the full version of the manual.
NOTE:
1. Please adjust your mobile or tablet device
to portrait mode during the browsing of
electronic manuals to achieve the best
viewing experience.
2. To ensure a smooth experience with the
download feature of the electronic manuals,
we recommend using Google Chrome,
Microsoft Edge, or the Safari browser.
1
Before using the appliance for the first time
Before connecting the appliance to the power mains, please read carefully
the instructions for use which describe the appliance and its correct and safe
use. The instructions apply to several appliance types/models; thus, settings
or equipment may be described herein which is not available in your
appliance. We recommend saving this instruction manual for future reference
and attach it to the appliance if it is sold in the future.
Check for any damage or irregularities on your appliance. If you find your
appliance is damaged, notify the retailer from which you have purchased the
appliance.
Before connecting the appliance to the power mains, let the appliance rest in
a vertical position for a minimum of 2 hours. This will reduce the possibility of
operation faults due to the effect of transport on the cooling system.
Important safety instructions
The appliance must be connected to the power mains and grounded in
compliance with the effective standards and regulations.
WARNING! Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
Before cleaning the appliance, unplug it from the power mains (unplug the
power cord from the wall outlet).
WARNING! If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
WARNING! When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING! The LED light must not be replaced by the user!
If the LED light is damaged, contact the customer helpline
for assistance.
SAFETY AND WARNING INFORMATION
WARNING
Risk of fire/flammable materials
SAFETY AND WARNING INFORMATION
2
WARNING! Do not use electrical appliances inside the
food storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
WARNING! Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING! To avoid any hazard resulting from poor
stability of the appliance, make sure it is installed as
instructed.
Freeze burn hazard
To avoid freeze burn, never put frozen food in your mouth and do not touch
frozen food.
Safety of children and vulnerable persons
The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
Remove the packaging intended to protect the appliance or particular parts
during transport and keep it outside the reach of children. It presents danger
of injury or suffocation.
When removing a used appliance, disconnect the power cord, remove the
door, and leave the shelves in the appliance. This will prevent children from
locking themselves in the appliance.
For European markets only
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance.
SAFETY AND WARNING INFORMATION
3
Cleaning and user maintenance shall not be made by children without
supervision.
Children aged from 3 to 8 years are allowed to load and unload refrigerating
appliances.
Warning regarding the refrigerant
The appliance contains a small amount of an environmentally friendly yet
flammable gas R600a. Make sure that no parts of the cooling system are
damaged. A gas leak is not hazardous to the environment, but it could cause
eye injury or fire.
In case of a gas leak, ventilate the room thoroughly, disconnect the appliance
from the power mains, and call a service technician.
Important information on the use of appliance
WARNING! This appliance is intended to be used in
household and similar applications such as:
• staff kitchen areas in shops, offices and other working
environments;
• farm houses and by clients in hotels, motels and other
residential type environments;
• bed and breakfast type environments;
• catering and similar non-retail applications.
WARNING! Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
The appliance may not be used outdoors and it may not be exposed to rain.
Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
If the appliance will be out of use for an extended period of time, switch it off
using the relevant button, and unplug it from the power mains. Empty the
appliance, defrost it, clean it, and leave the door ajar.
In case of an error or power supply failure, do not open the freezer
compartment unless the freezer has not operated for over 16 hours. After this
period, use the frozen food or provide sufficient cooling (e.g. a replacement
appliance).
Technical information on the appliance
Rating plate can be found in the appliance interior. It indicates data on
voltage, gross and net volume, type and amount of refrigerant, and
information on the climate classes.
44
SAFETY AND WARNING INFORMATION
If the language on the rating plate is not the language of your choice or the
language of your country, replace it with the one supplied.
WARNING! Do not damage the refrigerant circuit.
INSTALLING YOUR NEW APPLIANCE
• Stand your appliance in a dry and well
ventilated place. Keep the appliance out of
direct sunlight, rain or frost.
• The diagram shows the temperature range
of each climate class. The climate class of
this appliance is specified on the rating
plate. Use beyond this range may result in
poor performance.
Ambient temperature
+10°C to +32°C
+16°C to +32°C
+16°C to +38°C
+16°C to +43°C
Climate class
SN
N
ST
T
• Sufficient clear space should be available
around the appliance to facilitate
ventilation and heat dissipation.
• Suggested space is indicated in the figure.
In the non-built-in status
C
C
100mm Above
50-70mm Behind
100mm Each Side
A
B
C
A
B
595mm
600mm
627mm
1160mm
170mm
105°
5
INSTALLING YOUR NEW APPLIANCE
Leveling of appliance (if needed):
• The figure is for reference only.
• The appliance is fitted with adjustable feet
that can be used to level the appliance.
• To allow the doors to self-close, tilt the top
backwards by turning the adjustable feet.
Adjustable feet
Adjustable feet
• For proper installation, this refrigerator
must be placed on a level surface of
hard material that is the same height
as the rest of the flooring. This surface
should be strong enough to support a
fully loaded refrigerator.
• The rollers should be only used for
forward or backward movement.
Moving the refrigerator sideways may
damage your floor and the rollers.
WARNING
In the built-in status
C
C
5mm Above
0mm Behind
2.5mm above Each Side
A
B
C
A
B
The total space required for the refrigerator to fully
open the door in the built-in status
105
°
1145mm
765mm
6
DESCRIPTION OF THE APPLIANCE
1.
2.
3.
Electronic control
Storage shelves
Drawers
• Appliance interior equipment may change according to the appliance model.
• The diagram may slightly differ from the appliance you purchased, please get more
information in the E-manual.
CONTROL PANEL
TYPE 1: Electronic Control(located at the top of appliance)
NOTE: The control panel may differ by model, so choose according to your appliance.
Please refer to the E-manual for more information.
Power
Press and hold “Power” button for 3
seconds to turn the standby function on
or off. When the standby function is on,
the display panel will show “--”.
Eco
Press the “Eco” button to turn on the
energy saving function, the “ ” icon will
be illuminated. The temperature of the
refrigerator is -17°C under freeze mode, or
6°C under fridge mode. Press the “Temp”
button or “Eco” button to turn off the
energy saving function and the
refrigerator temperature setting will revert
back to the previous setting.
Super Cool/Freeze
This button serves two purposes:
1. Super Freeze
Press the “Super Cool/ Freeze” button
to activate Super Freeze “ ”under
Freezer mode, which auto-turns off after
52 hours or when “Super Cool/Freeze”
or “Temp” button is pressed.
2. Super Cool
Press the “Super Cool/ Freeze” button
to “ activate Super Cool ” under Fridge
mode, which auto-turns off after 6 hours
or when “Super Cool/Freeze” or “Temp”
button is pressed.
Refrigerator Compartment
Temperature
Press the “Temp” button repeatedly to
cycle from -14°C to -24°C when the
refrigerator is in the freeze state. When the
refrigerator is in the fridge state, the
temperature will cycle from 8°C to 2°C. If
there is no operation, the setting
temperature will take affect after 10
seconds.
CONTROL PANEL
7
Alarm
High temperature alarm:
If the temperature inside the appliance is
too high, an alarm will sound to alert you
and the “ ” icon will illuminated.
Switching off the alarm:
If you want to switch off the acoustic
alarm, briefly press the “Alarm” button.
The “ ” icon will remain illuminated until
the actual temperature in the appliance
drops below the alarm level.
Convert
Press and hold “Convert” button for 5
seconds to turn the Convert function on
or off.
Caution!
Before changing the compartment
setting, make sure that the stored food is
suitable for new setting mode. If not,
please empty it first. When the freezer
mode is changed to fridge mode, please
open the door about 30 minutes before
putting in the food that needs to be
refrigerated.
When the fridge mode is changed to
freezer mode, please close the door and
run about 200 minutes before putting in
the food that needs to be frozen.
When this function is activated, the “ ”
indicator will light up, the temperature in
the compartment will be set to 4°C.
Demo Mode
This mode, indicated by “OF”, stops
making cool air but appears operational.
Cancel it by pressing “Power” and “Wi-Fi”
buttons for 3 seconds and the buzzer
beeps 3 times.
Refrigerator Compartment
Temperature
Press the “Freezer” button repeatedly
to cycle from -14°C to -24°C when the
refrigerator is in the freeze state. When the
refrigerator is in the fridge state, the
temperature will cycle from 8°C to 2°C. If
there is no operation, the setting
temperature will take affect after 10
seconds.
Alarm
High temperature alarm:
If the temperature inside the appliance is
too high, an alarm will sound to alert you
and the “ ” icon will illuminated.
Switching off the alarm:
If you want to switch off the acoustic
alarm, briefly press the “Alarm” button.
The “ ” icon will remain illuminated until
the actual temperature in the appliance
drops below the alarm level.
Convert
Press and hold “Convert” button for 5
seconds to turn the Convert function on
or off.
Caution!
Before changing the compartment
setting, make sure that the stored food is
suitable for new setting mode. If not,
please empty it first. When the freezer
mode is changed to fridge mode, please
open the door about 30 minutes before
putting in the food that needs to be
refrigerated.
When the fridge mode is changed to
freezer mode, please close the door and
run about 200 minutes before putting in
the food that needs to be frozen.
When this function is activated, the “ ”
indicator will light up. the temperature in
the compartment will be set to 4°C.
8
CONTROL PANEL
TYPE 2: Electronic Control
(located on the door)
Power
Press and hold “Power” button for 3
seconds to turn the standby function on
or off. When the standby function is on,
the display panel will show “--”.
Eco
Press the “Mode” button to turn on the
energy saving function, the “ ” icon will
be illuminated. The temperature of the
refrigerator is -17°C under freeze mode, or
6°C under fridge mode. Press the “Temp”
button or “Eco” button to turn off the
energy saving function and the
refrigerator temperature setting will revert
back to the previous setting.
Super Cool/Freeze
1.Super Freeze
Press the “Mode” button to activate Super
Freeze ” under Freezer mode “ , which
auto-turns off after 52 hours or “Freeze”
button is pressed.
2.Super Cool
Press the “Mode” button to activate Super
Cool “ ” under Fridge mode, which
auto-turns off after 6 hours or “Freeze”
button is pressed.
NOTE:
• The distance between your appliance
and the Wi-Fi router can impact the
performance. If they are too far apart
pairing your appliance might fail or take
longer.
• The appliance supports 2.4 GHz Wi-Fi
networks only. The Wi-Fi network SSID
must be visible.
Connecting your refrigerator
After installing the Connectlife app, sign in
or create an account and follow these
steps:
1. Ensure the appliance is powered on
and the display panel is active. You’ll
know it’s ready when the panel lights up.
2. Press and hold the “Wi-Fi”(TYPE 1) or
“Mode”(TYPE 2) button for 3 seconds
until you hear a beep and see the “ ”
light flashing after it constantly on for a
few seconds.
9
Wi-Fi
ConnectLife app is a smart home app
that allows you to communicate with
your smart appliances using a
smartphone or tablet. The ConnectLife
APP is available to download free of
charge from the Apple App Store or from
the Google Play Store. Alternatively, you
can scan the following QR code with your
smart phone or tablet to find the
ConnectLife app:
3. Ensure Bluetooth is enabled on your
phone and open the ConnectLife app.
Look for the pop-up indicating that a
new appliance has been found. Tap the
button on the pop-up and follow the
instructions to proceed.
4. If a pop-up doesn’t appear, tap the
button called “Add appliance” or “+” in
the app.
5. Locate “Refrigerator” in the device list
and select it.
6. Follow the instructions in the app
connect your refrigerator. Once the
setup is complete, your refrigerator will
appear on your home screen.
3 sec
step1 step2
CONTROL PANEL
TYPE 1:
TYPE 2:
10
CLEANING AND CARE
HELPFUL HINTS AND TIPS
We recommend that you follow the tips to save energy.
• Try to avoid keeping the door open for long periods.
• Ensure the appliance is away from any sources of heat.
• Don’t set the temperature colder than necessary.
• Don’t store warm food or evaporating liquid in the appliance.
Energy saving tips
If the appliance needs to be switched off for an extended period, the following steps
should be taken prevent mould on the appliance.
1. Remove all food.
2. Remove the power plug from the mains socket.
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged open slightly to allow air to circulate.
Switching off your appliance
• For hygiene, clean the appliance (exterior and interior accessories) regularly at least
every two months.
• Ensure the appliance is completely dry before switching back on and plugging back
into the mains socket.
• Wipe the inside of the appliance with a weak solution of bicarbonate of soda, and
then rinse with warm water using a wrung-out sponge or cloth.
• Take care to keep door seals clean. Sticky food and drinks can cause seals to stick to
the cabinet. Wash the seals with a mild detergent and warm water. Rinse and dry
them thoroughly after cleaning.
• This product contains a light source of energy efficiency class G.
• For more cleaning details, please refer to the E-manual.
• Please refer to the E-manual for more information.
TROUBLESHOOTING
Don’t try to repair the appliance yourself. If the problem persists after you have made
the checks mentioned below, contact a qualified electrician, authorized service
engineer or the shop where you purchased the product.
WARNING
• If you experience a problem with your appliance or are concerned that the appliance
is not functioning correctly, you can carry out the following easy checks before calling
for service.
• NOTE: You can find more relevant information in the E-manual.
DANGER
Risk of child entrapment. Before you throw away your old refrigerator or freezer:
• Take off the doors.
• Leave the shelves in place so that children may not easily climb inside.
11
Problem
Possible cause & Solution
Appliance is not
working correctly
Check whether the power cord is plugged into the power outlet
properly.
The ambient temperature is too low. Try setting the chamber
temperature to a colder level to solve this problem.
A layer of frost
occurs in the
compartment
Temperature
inside is too warm
Check that the air outlets are not blocked by food and ensure
food is placed within the appliance to allow sufficient ventilation.
Ensure that the door can be fully closed.
You may have left the doors open too long or too frequently; or
the doors are kept open by some obstacle; or the appliance is
located with insufficient clearance at the sides, back and top.
The Wi-Fi password was entered incorrectly, or the network could
not be found.
For specific network configuration operations, please refer to the
electronic manual.
Unable to connect
appliance to Wi-Fi
network
DISPOSAL OF THE APPLIANCE
It is prohibited to dispose of this appliance as household waste.
Packaging materials
Packaging materials with the recycle symbol are recyclable. Dispose of the packaging
into a suitable waste collection container to recycle it.
Before disposal of the appliance
1. Pull out the mains plug from the mains socket.
2. Cut off the power cord and discard with the mains plug.
Correct Disposal of this product
This marking indicates that this product should no be
disposed with other household wastes throughout the EU.
To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the
return and collection systems or contact the retailer where
the product was purchased. They can take this product for
environmental safe recycling.
Refrigerators contain refrigerant and gases in the insulation. Refrigerant and gases
must be disposed of professionally as they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damage prior to proper disposal.
WARNING
SUGGESTION OF USING THE APPLIANCE
To avoid contamination of food, please respect the following instructions:
• Opening the door for long periods can cause a significant increase of the
temperature in the compartments of the appliance.
• Clean regularly surfaces that can come in contact with food and accessible drainage
systems.
• Clean water tanks if they have not been used for 48h; flush the water system
connected to a water supply if water has not been drawn for 5 days.(Special for
models with water tanks)
• Store raw meat and fish in suitable containers in the refrigerator, so that it is not in
contact with or drip onto other food.
• Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or
making ice-cream and making ice cubes.
• One-, two- and three-star compartments are not suitable for the freezing of fresh food.
12
SUGGESTION OF USING THE APPLIANCE
• If the refrigerating appliance is left empty for long periods, switch off, defrost, clean,
dry, and leave the door open to prevent mould developing within the appliance.
• NOTE: The information below is for reference only, as functions may vary by models.
Please get more details in the E-manual.
13
Appropriate food
Eggs, cooked food, packaged food, fruits
and vegetables, dairy products, cakes,
drinks and other foods which are not
suitable for freezing
Compartments
type
Order
Target storage
temp.[°C]
1
Fridge
+2~+8
2
Two-star
≤-12
3
4
Seafood, freshwater aquatic products
and meats
Four-star
≤-18
Three-star
≤-18
One-star
≤-6
5
Zero-star
-6~0
Fresh pork, beef, fish, chicken, some
packaged processed foods, etc. Partially
packed/wrapped up encapsulated
processed foods (non-freezable foods)
6
7
Seafood, pork, beef, chicken, freshwater
aquatic products, etc.
Chill
-3~+3
8
9
Fresh pork, beef, fish, chicken, cooked
food, etc.
Fresh Food
0~+4
Red wine, white wine, sparkling wine, etc.
Wine
+5~+20
Storage life
≤1 month
≤2 months
≤3 months
≤3 days
≤3 days
2~7 days
/
/
Declaration of conformity
The company declares that the device with the function Connectlife complies with the
essential requirements and other relevant provisions of Directive 2014/53/EU. The
detailed Declaration of Conformity can be found at the web address
https://auid.connectlife.io on the page of your device among the additional documents.
Customer support line (for UK mainland and Northern Ireland only): 0191 387 0804,
Southern Ireland customers please contact your Retailer.
UK Ltd
Ground floor Munroe Court
White Rose Office Park
Millshaw Park Lane Leeds
LS11 0EA
