SONANCE LANDSCAPE SERIES
9” GROUND STAKE FOR
LS47SAT AND LS48SAT
INSTALLATION INSTRUCTIONS
READ THESE INSTRUCTIONS CAREFULLY
BEFORE INSTALLING THIS STAKE
This stake is intended for installation in accordance with the National
Electrical Code and local code specifications. Failure to adhere to
these codes and instructions may result in serious injury and/or
damage to the stake and will void the warranty. These instructions
cover most installation applications. For any special applications not
covered, please contact Sonance for assistance.
INSTALLATION INSTRUCTIONS
1. Drive stake into ground.
• For installation in soft soil: The stake can be installed without
excavating the soil. Place a block of wood on top of the stake
and drive it into the ground by striking the wood with a hammer.
• For installation in hard soil: Dig a hole for the stake.
Place stake in hole with top cylinder of the stake above
ground level. Hold the stake straight while backfilling and
compacting the soil.
2. Pull satellite speaker wires through top of stake and out either
side on the bottom opening.
3. Thread satellite into top of stake. Rotate satellite until it is aimed
in the desired position. Satellites are equipped with a locknut,
tighten locknut against stake.
4. Connect satellite to cable per the installation instructions for
the satellite.
33-7437 05.25.17
WIRE SLOT
9” GROUND
STAKE
BLOCK OF WOOD
SATELLITE SPEAKER
SATELLITE LOCKNUT
SPEAKER WIRE
