Frigidaire FCWM3030AB 30 inch Microwave Combination Oven User Manual

EN User Manual | Wall Oven and Microwave Combination

Welcome to our family

Thank you for bringing Frigidaire into your home! We see your purchase as the beginning of a long relationship together.

This manual is your resource for the use and care of your product. Please read it before using your appliance. Keep it handy for quick

reference. If something doesn’t seem right, the troubleshooting section will help you with common issues.

FAQ, helpful tips and videos, cleaning products, and kitchen and home accessories are available at http://www.frigidaire.com.

We are here for you! Visit our website, chat with an agent, or call us if you need help. We may be able to help you avoid a service visit. If

you do need service, we can get that started for you.

Let’s make it official! Be sure to register your product.

CONTENTS

1. IMPORTANT SAFETY INFORMATION....................................................................................................................................... 2

2. COOKING RECOMMENDATIONS.............................................................................................................................................. 6

3. BEFORE USING THE OVEN.......................................................................................................................................................7

4. SETTING OVEN CONTROLS......................................................................................................................................................7

5. BEFORE SETTING MICROWAVE OVEN CONTROLS............................................................................................................ 11

6. SETTING MICROWAVE OVEN CONTROLS............................................................................................................................ 13

7. CARE AND CLEANING............................................................................................................................................................. 16

8. TROUBLESHOOTING............................................................................................................................................................... 18

9. LIMITED WARRANTY................................................................................................................................................................20

10. QUEBEC RIGHT TO REPAIR..................................................................................................................................................20

1. IMPORTANT SAFETY INFORMATION

1.1 Keep a record for quick reference

Model number

..........................................................

Serial number

..........................................................

Purchase date

..........................................................

Serial Number Location

Read all instructions before using this appliance.

This manual contains important safety symbols and

instructions. Please pay attention to these symbols and

follow all instructions given.

Read safety precautions in this manual before installing or

using your appliance. Safety items throughout this manual

are labeled with a WARNING or CAUTION statement based

on the risk type.

Warnings and important instructions appearing in this guide

are not meant to cover all possible conditions and situations

that may occur. Common sense, caution, and care must be

exercised with installing, maintaining, or operating your

appliance.

1.2 Installation checklist

❐ Read all the safety instructions in the front of your user manual.

❐ Remove all packaging materials from your appliance before

cooking.

❐ Confirm that the electrical power to the appliance is turned on.

❐ Wipe out the inside of the oven cavity with a damp cloth.

❐ Apply a thin layer of cooking oil to the sides of the oven racks to

keep them gliding smoothly.

❐ Set the clock. Refer to the Setting Oven Controls chapter.

❐ Test all surface elements/burners to make sure they are working

properly.

❐ Before using the appliance for the first time, set it to broil on high for

15 minutes, then switch to bake at 350°F (177°C) for an additional

45 minutes. Some noises and odors may occur during this initial

cooking cycle.

❐ Remember to complete your product registration.

1.3 Safety definitions

This is the safety alert symbol. It is used to alert of potential

personal injury hazards. Follow all safety messages that

follow this symbol to avoid possible injury or death.

WARNING!

Indicates a potentially hazardous situation which, if not avoided,

may result in death or serious injury.

CAUTION!

Indicates a potentially hazardous situation which, if not avoided,

may result in minor or moderate injury.

IMPORTANT

Indicates installation, operation, or maintenance information which

is important but not hazard-related.



NOTE

Indicates a short, informal reference – something written down to

assist the memory or for future reference.

2 ENGLISH

WARNING!

Tip over hazard

• A child or adult can tip the oven and be killed.

• Install the anti-tip device to oven and/or structure per installation

instructions.

• Ensure the anti-tip device is re-engaged when the oven is

moved.

• Do not operate the oven without the anti-tip device in place and

engaged.

• Failure to follow these instructions can result in death or serious

burns to children and adults.

Anti-tip mounting holes.

Refer to the installation instructions supplied with your appliance

for proper installation.

Check for proper installation with a visual check that the anti-tip

screws are present. Test the installation with light downward

pressure on the open oven door. The oven should not tip forward.

1.4 Precautions to avoid possible

exposure to excessive microwave

energy

For your safety, the information in this manual must be

followed to minimize the risk of fire or explosion or to prevent

property damage, personal injury or loss of life. Adhere to

the following precautions:

• Do not attempt to operate the microwave oven with the door open

since open-door operation can result in harmful exposure to

microwave energy. It is important not to defeat or tamper with the

safety interlocks.

• Do not place any object between the microwave oven front face and

the door or allow soil or cleaner residue to accumulate on sealing

surfaces.

• Do not operate the microwave oven if it is damaged. It is particularly

important that the oven door close properly and that there is no

damage to the door, hinges, latches, door seals, and sealing

surfaces.

• The microwave oven should not be adjusted or repaired by anyone

except properly qualified service personnel.

1.5 Important instructions for unpacking

and installation

IMPORTANT

Read and follow the below instructions and precautions for

unpacking, installing, and servicing your appliance.

Remove all tape and packaging before using the appliance.

Destroy the carton and plastic bags after unpacking the

appliance. Never allow children to play with packaging

material. Do not remove the wiring label and other literature

attached to the appliance. Do not remove model/serial

number plate.

Cold temperatures can damage the electronic control. When

using this appliance for the first time, or when the appliance

has not been used for an extended period of time, be sure

the appliance has been in temperatures above 32ºF (0ºC)

for at least 3 hours before turning on the power to the

appliance.

All materials used in construction of cabinets, enclosures,

and supports surrounding the product must have a

temperature rating above 194°F (90°C).

Never modify or alter the construction of the appliance by

removing the leveling legs, panels, wire covers, anti-tip

brackets/ screws, or any other part of the appliance.

Be sure to have an appropriate foam-type fire extinguisher

available, visible, and easily accessible located near the

appliance.

1.6 Grounding instructions

WARNING!

• Avoid fire hazard or electrical shock. Failure to follow this

warning may cause serious injury, fire, or death.

• Avoid fire hazard or electrical shock. Do not use an adapter

plug, use an extension cord, or remove grounding prong from

the power cord. Failure to follow this warning may cause serious

injury, fire, or death.

Proper Installation - Be sure your appliance is properly

installed and grounded by a qualified technician. In the

United States, install in accordance with the National Fuel

Gas Code ANSI Z223.1/NPFA No. 54, latest edition and

National Electrical Code NFPA No. 70 latest edition, and

local electrical code requirements. In Canada, install in

accordance with CAN/CGA B149.1 and CAN/CGA B149.2

and CSA Standard C22.1, Canadian Electrical code, Part 1-

latest editions and local electrical code requirements. Install

only per installation instructions provided in the literature

package for this appliance.

For personal safety, this appliance must be properly

grounded. For maximum safety, the power cord must be

securely connected to an electrical outlet or junction box that

is the correct voltage, is correctly polarized and properly

grounded, and protected by a circuit breaker in accordance

with local codes.

It is the personal responsibility of the consumer to have the

appropriate outlet or junction box with the correct, properly

grounded wall receptacle installed by a qualified electrician.

Contact a qualified installer to assure that the electrical

installation is adequate and is in conformance with all local

codes and ordinances.

This appliance is equipped with a four-prong grounding plug

(A) for your protection against shock hazard and should be

plugged directly into a properly grounded 240V wall

receptacle (B). Do not cut or remove the grounding prong

from this plug.

ENGLISH 3

See the installation instructions packaged with this appliance

for complete installation and grounding instructions.

1.7 Important instructions for using the

appliance

WARNING!

• Do not store flammable materials in ovens, microwaves, near

surface burners or elements, or in the storage or warming

drawer (if equipped). This includes paper, plastic, and cloth

items, such as cookbooks, plastic ware, and towels, as well as

flammable liquids. Do not store explosives, such as aerosol

cans, on or near the appliance.

• Do not leave children alone - Children should not be left alone

or unattended in the area where appliance is in use. They

should never be allowed to sit or stand on any part of the

appliance, including the storage drawer, lower broiler drawer,

warmer drawer, or lower double oven.

• Do not store items of interest to children in the cabinets above

the appliance or on the backguards of ranges. Children climbing

on or near the appliance to reach items could be seriously

injured.

• Do not allow children to climb or play around the appliance. The

weight of a child on an open oven door may cause the

appliance to tip, resulting in serious burns or other injury. An

open drawer when hot may cause burns.

• Stepping, leaning, or sitting on the door or drawers of this

appliance can result in serious injuries and also cause damage

to the appliance.

• Never cover any slots, holes, or passages in the oven bottom or

cover an entire rack with materials such as aluminum foil. Doing

so blocks airflow through the oven and may cause carbon

monoxide poisoning. Aluminum foil linings may also trap heat,

causing a fire hazard.

• Do not use oven or warmer drawer (if equipped) for storage.

• Never use your appliance as a space heater to heat or warm

the room. Doing so may result in carbon monoxide poisoning

and overheating of the appliance.

CAUTION!

• When heating fat or grease, watch it closely. Grease may catch

fire if it becomes too hot.

• Do not use water or flour on grease fires. Smother fire or flame

or use dry chemical or foam-type extinguisher. Cover the fire

with a pan lid or use baking soda.

• Use dry potholders. Moist or damp potholders on hot surfaces

may result in burns from steam. Do not let potholders touch hot

cooking areas. Do not use towels or other bulky cloths.

• Do not heat unopened food containers - Build-up of pressure

may cause container to burst and result in injury.

• Wear proper apparel - Loose-fitting or hanging garments should

never be worn while using the appliance. Do not let clothing or

other flammable materials contact hot surfaces.

• Do not touch surface burners or elements, or areas near these

burners or elements, interior surfaces of the oven, or the

warmer drawer (if equipped). Surface burners and elements

may be hot even though they appear cool. Areas near surface

burners and elements may become hot enough to cause burns.

During and after use, do not touch, or let clothing or other

flammable materials touch these areas until they are cool.

These areas may include the cooktop, surfaces facing the

cooktop, oven vent areas, oven door, and oven window.

• Do not attempt to operate the appliance during a power failure.

If the power fails, always turn off the appliance. If the appliance

is not turned off and the power resumes, electric surface

elements may resume operation when power is restored. Once

the power resumes, reset the clock and the oven function.

1.8 Important instructions for using

your oven

Protective liners: Do not use aluminum foil, aftermarket oven

liners, or any other materials or devices to line oven bottom,

oven racks, or any other part of the appliance. Only use

aluminum as recommended for baking, such as lining

cookware or as a cover placed on food. Any other use of

protective liners or aluminum foil may result in a risk of

electric shock or fire or a short circuit.

Use care when opening oven door, lower oven door, or

warmer drawer (some models). Stand to the side of the

appliance when opening the door of a hot oven. Let hot air

or steam escape before you remove or replace food in the

oven.

Keep oven vent ducts unobstructed. Touching surfaces in

this area when the oven is on may cause severe burns. Do

not place plastic or heat-sensitive items on or near the oven

vent. These items can melt or ignite.

Placement of oven racks: Always place oven racks in

desired location while oven is cool. If rack must be moved

while oven is hot, do not let potholder contact hot burner or

element in oven. Use potholders and grasp the rack with

both hands to reposition. Remove all cookware and utensils

before moving the rack.

Do not use a broiler pan without its insert. Broiler pans and

inserts allow dripping fat to drain away from the high heat of

the broiler. Do not cover the broiler insert with aluminum foil;

exposed fat and grease could ignite.

Do not cook food on the oven bottom. Always cook in proper

cookware and always use the oven racks.

4 ENGLISH

1.9 Important instructions for using

microwaves ovens

WARNING!

When using electrical appliances, basic safety precautions should

be followed to reduce the risk of burns, electric shock, fire, injury to

persons, or exposure to excessive microwave energy.

Install or locate this appliance only in accordance with the

provided installation instructions.

Some products such as whole eggs and sealed containers -

for example, closed jars - are able to explode and should not

be heated in this microwave oven.

Use this appliance only for its intended use as described in

this manual. Do not use corrosive chemicals or vapors in

this appliance. This type of microwave oven is specifically

designed to heat, cook, or dry food. It is not designed for

industrial or laboratory use.

As with any appliance, close supervision is necessary when

used by children or infirm persons.

This appliance, including power cord, must be serviced only

by qualified service personnel. Contact nearest authorized

service for examination, repair, or adjustment.

Do not cover or block any vents or openings on the

microwave oven.

Do not store or use this appliance outdoors.

Do not use this product near water - for example: near a

kitchen sink, in a wet basement, near a swimming pool, or

similar locations.

Oversized foods or oversized metal utensils should not be

inserted in a microwave oven as they may create a fire or

risk of electric shock.

Do not clean with metal scouring pads. Pieces can burn off

the pad and touch electrical parts, involving a risk of electric

shock.

Do not use paper products when appliance is operated in

the convection or mix mode (some models).

Do not cover racks (if equipped) or any other part of the

microwave oven with metal foil. This will cause overheating

of the microwave oven.

Review the door cleaning instructions in the operating

instructions.

To reduce the risk of fire in the microwave oven cavity, take the

following precautions:

Do not overcook food. Carefully attend to the appliance when

paper, plastic or other combustible materials are placed inside to

facilitate cooking.

Remove wire twist-ties from paper or plastic bags before

placing bags in the microwave oven.

If materials inside the microwave oven ignite, keep oven

door closed, turn oven off , and disconnect the power cord

or shut off power at the fuse or circuit breaker panel.

Do not use microwave oven cavity for storage purposes.

Do not leave paper products, cooking utensils, or food in the

cavity when not in use.

Liquids such as water, coffee, or tea are able to be

overheated beyond the boiling point without appearing to be

boiling. Visible bubbling or boiling when the container is

removed from the microwave oven is not always present.

This could result in very hot liquids suddenly boiling over

when a spoon or other utensil is inserted into the liquid.

To reduce the risk of injury to persons from boiling liquids:

Do not overheat the liquid.

Stir the liquid both before and halfway through heating it.

Do not use straight-sided containers with narrow necks. Use

wide-mouthed containers.

After heating, allow the container to stand in the microwave

oven at least 20 seconds before removing.

Use extreme care when inserting spoons or other utensils

into the container.

If the microwave oven light fails, consult an authorized

service.

1.10 Important instructions for cleaning

the appliance

CAUTION!

Before manually cleaning any part of the appliance, be sure all

controls are turned off and the appliance is cool. Cleaning a hot

appliance can cause burns.

Clean the appliance regularly to keep all parts free of grease

that could catch fire. Do not allow grease to accumulate.

Greasy deposits in the fan could catch fire.

Always follow the manufacturer's recommended directions

for use of kitchen cleaners and aerosols. Be aware that

excess residue from cleaners and aerosols may ignite

causing damage and injury.

Clean ventilating hoods frequently - Grease should not be

allowed to accumulate on hood or filter. Follow the

manufacturer's instructions for cleaning vent hoods.

1.11 Important instructions for service

and maintenance

Do not repair or replace any part of the appliance unless

specifically recommended in the manuals. All other servicing

should be done only by a qualified technician. This reduces

the risk of personal injury and damage to the appliance.

Always contact your dealer, distributor, service agent, or

manufacturer about problems or conditions you do not

understand.

Ask your dealer to recommend a qualified technician and an

authorized repair service. Know how to disconnect the

power to the appliance at the circuit breaker or fuse box in

case of an emergency.

Remove the oven door from any unused oven if it is to be

stored or discarded.

Do not touch a hot oven light bulb with a damp cloth. Doing

so could cause the bulb to break. Handle halogen lights (if

equipped) with paper towels or soft gloves. Disconnect the

appliance or shut off the power to the appliance before

removing and replacing the bulb.

WARNING!

California Residents: for cancer and reproductive harm information,

visit www.P65Warnings.ca.gov

ENGLISH 5

2. COOKING RECOMMENDATIONS

2.1 Bakeware

The material of bakeware affects how evenly and quickly it transfers

heat from the pan to the food.

Table title

Material Attributes Recommendation

Shiny metal bakeware Shiny, aluminum, and non-coated bakeware is the best for even

heating. It is suitable for all baked goods.

Recommended cooking temperatures and times are based on shi

ny metal bakeware.

Dark metal bakeware Dark bakeware cooks hotter than shiny bakeware. Reduce the cooking temperature by 25°F / 13-14°C when you use

a dark bakeware.

Glass bakeware Glass bakeware cooks hotter than shiny bakeware.

Glass is convenient, you can use the same piece of bakeware for

cooking, serving, and storing food.

Reduce the cooking temperature by 25°F / 13-14°C when you use

a glass bakeware.

Insulated bakeware Insulated bakeware cooks cooler than shiny bakeware.

Insulated bakeware is designed for baking in gas oven.

When you use insulated bakeware, the recipe baking time may be

longer than usual.

2.2 Cooking Conditions

Conditions in your kitchen can affect the performance of your appliance

when cooking food.

Table title

Condition Attributes Recommendation

Aging cookware As pans age and become discolored, you may need to slightly

reduce a cooking time.

If food is too dark or overcooked, use the minimum cook time in the rec

ipe or packaging.

If food is too light or undercooked, use the middle to maximum cook

time recommended in the recipe or on the packaging.

High altitude Air is drier and air pressure is lower.

Water boils at a lower temperature, and liquids evaporate faster.

Foods may take longer to bake.

Doughs may rise faster.

Adjust cooking temperature, cooking time or recipes as needed.

Increase amount of liquid in baking recipes.

Increase cook time on cooktop. Cover dishes to reduce evaporation.

Increase bake time or oven temperature.

Reduce the amount of baking soda or baking powder in recipe. Reduce

rising time or punch down dough and allow it to rise twice.

2.3 Cooking Results

Small adjustments may help you achieve the best results.

Table title

Result Recommendation

Food too light Use the middle to maximum cook time recommended on packaging or recipe.

Food too dark Use the minimum cook time recommended on packaging or recipe.

2.4 Cooking Tips

Use these additional tips to get the best results from your appliance.

Table title

Situation Recommendation

Baking

Rack placement Refer to Setting Oven Controls.

Preheat Insert food immediately after the beep.

Fully preheat the oven before baking items like cookies, cakes, biscuits, and breads.

Checking food Use the window and oven light when you check the food. Opening the door may reduce baking performance.

Bake or Convection Bake Convection bake is the best function to use for baking on multiple racks. For best performance, refer to Setting Oven

Controls.

Food placement Allow at least 2 inches / 5 cm of space between bakeware for proper air circulation.

Broiling / Roasting

Broiling pan If the accessory is not included with your appliance, you can purchase it on the website www.frigidaire.com.

For best results when broiling, use a broil pan with an insert designed to drain the fat from the food, help avoid spatter,

and reduce smoke. The broiler pan catches grease spills, and insert helps prevent grease splatters.

Convection cooking

Convection attributes Convection cooking uses a fan to circulate hot air around the oven and food. It browns food more evenly and reduces

hot spots in the oven.

Convection saves time when you use multiple racks or cook several food items at once.

Convection bake Reduce cooking temperature by 25°F / 13-14°C from the recipe unless the recipe is written for convection baking.

Preheat the oven for best result.

6 ENGLISH

3. BEFORE USING THE OVEN

WARNING!

Refer to Safety chapters.

3.1 Oven Vent Location

The oven air vents are located behind the door, on it's upper

side.When the oven is on, warm air is released through the vent. This

venting is necessary for proper air circulation in the oven and good

baking results.

Steam or moisture may appear near the oven vent. This is normal.

IMPORTANT

Do not block oven vent or cover the openings with aluminium foil or

any other material.

WARNING!

Protective Liners — Do not use aluminum foil (or any other

material) or liners to line the oven bottom, walls, racks or any other

part of the range. Doing so will alter the heat distribution, produce

poor baking results, and possibly cause permanent damage to the

oven interior. Improper installation of these liners may result in risk

of electric shock or fire.

CAUTION!

Always use pot holders or oven mitts when using the oven. When

cooking, the oven interior, oven exterior and oven racks will

become very hot which can cause burns.

To prevent possible damage to the oven, do not attempt to close

the oven door until all the oven racks are fully positioned back

inside the oven cavity.

3.2 Types of Oven Rack

Flat Oven Rack

Flat oven racks may be used for most cooking needs and may be

placed in most oven rack positions.

IMPORTANT

Before using the accessories, remove and clean them according to

the instructions in the chapter: "Care and Cleaning".

4. SETTING OVEN CONTROLS

WARNING!

Refer to Safety chapters.

4.1 Oven Controls

3 521 4 6 7 8 9

101516 14 13 12 11

Bake - for delicate foods that need heat to rise and move gently in

the oven.

Conv Bake - circulates the oven heat continuously for baking.

Broil - for broiling and grilling foods under direct, high heat.

Air Fry - for preparing packaged and convenience foods with little

or no oil.

Display - shows the countdown time.

Cook Time - sets the oven to run for a period of time and then turn

off .

Steam Clean - starts a steam cleaning cycle to loosen light soils.

Delay Start - to postpone the start of the oven cooking.

Keep Warm - to keep cooked foods at serving temperature in the

oven.

Clock - to set the time of day.

Lock - deactivates the control panel to prevent accidental operation

of the appliance.

START - starts cooking functions and sets the clock.

OFF- turns off all cooking functions.

Number Keys - to set temperature and time.

Oven Light - to turn the interior light on and off. The oven light also

turns on automatically when you open the door.

Settings - to set user preferences for various control functions,

including:

• CLoC: to set clock to 12-hour or 24-hour mode.

• Hour: to switch between the 12-hour energy saving feature or

Continuous Bake.

• Audio: to set the volume of control keys or to operate in silent

mode.

• F-C: display temperatures in Fahrenheit or Celcius.

• rESEt: to reset all user preferences to original factory settings.

• uPo: to adjust the oven temperature settings.

• E-S: to turn the 12-hour energy savings feature on or off .

Minimum and maximum control settings

Feature Mode Min.Temp/Time Max.Temp/Time

Bake 170°F (77°C) 550°F (288°C)

Broil LO HI

Air Fry 170°F (77°C) 550°F (288°C)

Conv Bake 170°F (77°C) 550°F (288°C)

Keep Warm 140°F (60°C) 200°F (93°C)

Cook Time 12 h 0:01 min 11:59 h/min

24 h 0:01 min 11:59 h/min

ENGLISH 7

Feature Mode Min.Temp/Time Max.Temp/Time

Clock 12 h 1:00 h./min 11:59 Hr./Min.

24 h 0:00 min 23:59 h/min

Delay Start 0:01 min 1 h/min

Steam Clean 30 min 30 min

4.2 Setting the Clock

Set the clock to the correct time of day before using the appliance.



NOTE

When the appliance is first plugged in or if the power supply is

interrupted, the display will flash 12:00. In this case, skip to Step 4

of the instructions below.

To set the clock:

1. Press .

2. Enter the correct time using the Number Keys.

3. Press START.



NOTE

You cannot change the clock when the oven is set for cooking.

4.3 Setting 12 hr or 24 hr Display Mode ("Hour")

The clock display mode allows you to select 12 hr or 24 hr modes. The

factory pre-set clock display mode is 12 hours.

To set display mode:

1. Press until "Hour" appears on the display.

2. Press START.

3. Press to switch between 12 hr and 24 hr setting.

4. Press START to confirm the desired clock setting.

Display will return to the settings menu. After a few seconds, it will

return to the time of day.

4.4 Setting a Silent Control Panel Mode ("Audio")

When selecting a function, an audible tone is heard each time a key is

pressed. You can set the control to silent operation, if needed.

To set the controls for silent mode:

1. Press until "Audio" appears on the display.

2. Press START.

3. Press to switch between "oFF" and "on".

4. Press START to confirm the desired setting.

Display will return to the settings menu. After a few seconds, it will

return to the time of day.

4.5 Setting Temperature Display ("F-C")

The default unit in which temperature is displayed is Fahrenheit (°F).

You can change the unit to Celsius (°C). You can set the oven to

operate at any temperature from 170°F (77°C) to 550°F (287°C).

To change the temperature unit:

1. Press until “F-C” appears on the display.

2. Press START.

3. Press to switch between "F" and "C".

4. Press START to confirm the desired setting.

Display will return to the settings menu. After a few seconds, it will

return to the time of day.

4.6 Restore Factory Settings ("rESEt")

Your appliance was set with default oven control settings. You can

change the following settings while using the appliance over time:

• 12 hr or 24 hr display mode

• Continuous bake or 12-hour energy savings mode

• Silent or audible controls

• Oven temperature display (Fahrenheit or Celsius)

• Oven temperature adjustments ("UPO")

To restore oven control to factory default settings:

1. Press until “rESEt” appears on the display..

2. Press and hold START for 3 seconds. The control has been reset

with the default settings.

4.7 Operating Oven Light

The interior oven light will automatically turn on when the oven door is

opened.

Press to turn the interior oven light on and off whenever the oven

door is closed.

For best baking results, do not leave oven light on while baking.

To change the interior oven light, refer to Care and Cleaning.

4.8 Oven Lock

The appliance can be programmed to lockout: cooktop surface, oven

control keys.

To activate the lockout feature:

1. Press and hold the key for 3 seconds.

2. Once the controls are locked, will appear on the display.

To cancel the oven lockout feature:

1. Press and hold the key for 3 seconds.

2. When the lock icon no longer displays, the oven control keypad is

available for use.



NOTE

All keys will triple-beep to indicate the action cannot be performed,

except for the OFF and Lock key.

4.9 Setting Bake

Bake cooks with heat that rises from the oven bottom. The heat and air

circulate naturally in the oven. A tone will sound indicating when the set

bake temperature is reached and to place the food in the oven. The

convection fan will turn on in preheat and then cycle on and off as

needed during baking. Bake may be set for any oven temperature

between 170°F (77°C) to 550°F (288°C).

CAUTION!

Always use pot holders or oven gloves when using the oven. When

cooking the oven interior, oven racks, and cooktop will become

very hot. There is a risk of burns!

Baking tips:

• Insert the food in the oven after preheat tone beep. Fully preheat the

oven before baking items like cookies, cakes, biscuits and breads.

• Use the convection bake function for best results when baking

cookies on multiple racks.

• For best results when baking layer cakes using two oven racks,

place racks like shown on the picture below.

• When using any single rack for baking cookies, cakes, biscuits, or

muffins use rack position 3.

• Allow at least 2 inches (5 cm) of space between bakeware for

proper air circulation.

• Dark or dull bakeware absorbs more heat than shiny bakeware,

resulting in dark or overbrowned foods. It may be necessary to

8 ENGLISH

reduce oven temperature or cook time to prevent overbrowning of

some foods.

• Dark pans are recommended for pies. Shiny pans are

recommended for cakes, cookies, and muffins.

• Do not open oven door often. Opening the door will reduce the

temperature in the oven and may increase cook time.

• Do not leave oven light on while baking.

IMPORTANT

The oven will bake no longer than 12 hours. If you wish to bake for

a longer period, see “Continuous Bake Setting or 12-hour Energy

Saving Feature (E-S)” section for detailed information.

To set Bake for (default) oven temperature of 350°F:

1. Press Bake. "Bake" and 350° will appear on the display.

2. Press START.

To cancel Bake at any time, press OFF.

To change the oven temperature to 425°F when the oven is

baking:

1. Use the Number Keys to enter a new temperature of 4 2 5.

2. Press START. If you do not press the START, the temperature will

return to the previous setting.

To cancel Bake at any time, press OFF.

4.10 Setting Conv Bake

Convection Bake uses a fan to circulate the oven's heat uniformly

around the oven. This improved heat distribution allows for even

cooking and browning results. Heated air flows around the food from all

sides. The convection fan will cycle on and off as needed, during the

cooking process. Convection Bake may be set for any oven

temperature between 170°F (77°C) and 550°F (288°C).

CAUTION!

Always use pot holders or oven gloves when using the oven. When

cooking the oven interior, oven racks, and cooktop will become

very hot. There is a risk of burns!

Benefits of convection cooking include:

• Multiple rack baking.

• Foods may cook faster, saving time and energy.

Baking tips:

• Fully preheat the oven before baking items like cookies, cakes,

biscuits and breads.

• When baking cakes using two oven racks, place bakeware like

shown on the picture below.

• When using any single rack for baking cookies, cakes, biscuits or

muffins, use rack position 3.

• Unless the recipe is written for convection cooking, use Conv

Convert to reduce oven temperature from the recipe’s

recommended oven temperature.

• Dark or dull bakeware absorbs more heat than shiny bakeware,

resulting in dark or overbrowned foods. It may be necessary to

reduce oven temperature or cook time to prevent overbrowning of

some foods.

• Dark pans are recommended for pies. Shiny pans are

recommended for cakes, cookies, and muffins.

• Do not open oven door often. Opening the door will reduce the

temperature in the oven and may increase cook time.

• Do not leave oven light on while baking.

To set Convection Bake with a default oven set temperature of 325°F:

1. Press Conv Bake.

2. "Conv Bake" and 325° will appear on the display.

3. Press START. The convection fan will cycle on and off as needed,

during the cooking process.

To cancel Convection Bake at any time, press OFF.

4.11 Setting Air Fry

The Air Fry function works best for single rack baking with packaged

and convenience foods. It works well with most recipes and can be

programmed for temperatures between 170°F and 550°F. Follow the

instructions on the food packaging regarding quantity, time, and

cooking temperature.

Frigidaire offers an optional Air Fry Tray specifically designed to deliver

superior performance.

Some benefits of the optional Air Fry tray:

• Tray optimized for oven space.

• Fits in the dishwasher for easy clean-up.

• Higher yield than countertop models.

• Frees up countertop space.

• Compatible with convection ovens.

• The optional Air Fry tray may be purchased from

www.frigidaire.com.

Air Fry tips:

• Food should be arranged in single layers on the Air Fry tray or dark

cookie sheet and placed on rack position 3 for best results.

• When using the Air Fry tray, place a large cookie sheet on rack

position 1 to catch any crumbs or drippings.

• Leave oven light off when baking.

• Food may need to be removed early and should be checked at the

minimum recommended bake time. However, frozen dense foods

and items with cook times less than 15 minutes may require

additional time.

To set the Air Fry function:

1. Arrange food on tray/sheet as suggested.

2. Press Air Fry.

3. Use the Number Keys to select temperature for particular food.

4. Press START.

5. When preheat tone sounds, place the Air Fry tray or dark cookie

sheet on rack position 3. If using an Air Fry tray, place a large

cooking sheet on rack position 1.

6. Press OFF to return display to show the time of day.

Table title

Food Type

Quantity

(oz.)

Temperature

Cook Time

(min.)

Frozen Tater Tots 48 450°F (232°C) 29-33

Frozen Golden Fries 48 425°F (218°C) 25-35

Frozen Chicken Nug

gets

48 400°F (205°C) 13-15

Frozen Crispy Chicken

Strips

48 400°F (205°C) 20-22

Frozen Hot Wings

Bone-In

48 450°F (232°C) 25-28

Frozen Chicken Wings 48 375°F (190°C) 60-65

Fresh Chicken Wings 48 450°F (232°C) 30-40

4.12 Setting Broil

Broiling is direct heat cooking and will produce some smoke. If smoke

is excessive, place food further away from the element. Watch food to

prevent burning. When broiling, always remember to arrange the oven

racks while oven is still cool. Position the rack on the highest level.

This function has two settings: HI and Lo.

ENGLISH 9

WARNING!

Should an oven fire occur, leave the oven door closed and turn off

the oven. If the fire continues, use a fire extinguisher. Do not put

water or flour on the fire. Flour may be explosive and water can

cause a grease fire to spread and cause personal injury.

CAUTION!

Always use pot holders or oven gloves when using the oven. When

cooking the oven interior, oven racks, and cooktop will become

very hot. There is a risk of burns!

IMPORTANT

Broiler pans and inserts allow the grease to drain away from the

high heat of the broiler. Do not use the pan without the insert. Do

not cover the insert with foil – the exposed grease could ignite.

OPEN DOOR BROIL SHUTOFF: If the oven door is left open during

Broil for more than 3 minutes, an alarm will sound to notify the user to

close the oven door. If the door is not closed within 30 seconds from

the start of the alarm, the oven will turn off.

To set broil:

1. Move the racks in the oven while they are still cold.

2. Press Broil once for HI setting, twice for Lo setting.

3. Press START.

4. For optimum browning results, preheat oven for 2 min before

adding food.

5. Place the bakeware in the oven. Broil with oven door closed.

6. Broil on one side until food is browned; turn and broil other side

until done to your satisfaction.

7. When finished broiling, press OFF.

To cancel the function at any time, press OFF.

4.13 Notes for Broiling

• Always arrange oven racks when the oven is cool.

• Broil with oven door closed. If broiling with door open, an alarm will

sound alerting you to close the door. If left open, the Broil function

will be canceled.

• For best results, use a broil pan with broil pan insert designed to

drain the fat from the food, help avoid spatter and reduce smoking.

• When broiling, always pull the oven rack out to the stop position

before turning or removing food.

• If a broiler pan and insert are not supplied with this appliance, they

may be purchased from www.frigidaire.com.



NOTE

Broiling is direct heat cooking and will produce some smoke. If

smoke is excessive, place food further away from element. Always

watch foods carefully to prevent burning.

4.14 Delay Start

Delay Start allows you to delay the start of cooking by the desired

amount of time. It can be used with: Bake, Conv Bake. Prior to setting a

delay start, be sure the time of day is set correctly. The maximum delay

for a Delay Start is one hour.

To set Delay Start:

1. Choose the Bake function and set the temperature.

2. Press Delay Start. The display will show a time of 0:00 (0 hours

and 00 minutes).

3. Use Number Keys to enter the desired time delay.

4. Press START.

5. When the time runs out, the chosen cooking function will start.

To stop the Delay Start timer at any time, press OFF.

4.15 Setting the Sabbath Feature for the Jewish Sabbath

and Holidays (some models)

For further assistance, guidelines for proper usage, and a complete list

of models with the Sabbath feature, please visit the web at www.star-

k.org.

This appliance provides special settings for use when observing the

Jewish Sabbath/Holidays. Sabbath mode disables all audible tones or

visual display changes on the oven control. Bake is the only cooking

feature available while in the Sabbath mode. Most oven controls are

locked during Sabbath mode.

To set Sabbath Mode:

1. Select a cooking function, such as Bake, and set the temperature.

2. Set a Cook Time if desired and press START.

3. Press both Conv Bake and Air Fry at the same time.

4. When Cook Time ends oven turns off automatically. "SAb" will

appear on the display.

5. Press both Conv Bake and Air Fry at the same time to exit

Sabbath mode and show the time of day.

IMPORTANT

The Sabbath mode will override the factory preset 12 hour energy

saving mode, and the appliance will stay on until the cooking

features are canceled. If cooking is canceled when the appliance is

in the Sabbath mode, no audible or visual indicators will be

available to verify the cancellation.

If the oven interior lights are needed, be sure to activate them prior to

setting the Sabbath mode. Once the oven light is turned on and the

Sabbath mode is active, the oven light will remain on until the Sabbath

mode is turned off and the oven lights are turned off. The oven door will

not activate the interior oven lights when the oven door is opened or

closed.

It is recommended that any oven temperature modification made within

an active Sabbath mode use the number keys and press START. The

change will be accepted automatically.

WARNING!

Food poisoning hazard. Do not let food sit for more than one hour

before or after cooking. Doing so can result in food poisoning or

sickness. Foods that can easily spoil such as milk, eggs, fish, meat

or poultry, should be chilled in the refrigerator first. Even when

chilled, they should not stand in the oven for more than 1 hour

before cooking begins, and should be removed promptly when

finished cooking.

Important:

• Do not attempt to activate any other oven function except Bake

while the Sabbath feature is active. When the Sabbath feature is

active, only the number keys and OFF will function. All other keys

should not be used once the Sabbath feature is active.

• You may change the oven temperature once baking has started.

Use the number keys and START to raise or lower the oven

temperature.

• Remember that the oven control will no longer provide audible tones

or display any further changes when the Sabbath feature is active.

• The oven will shut-off automatically after completing a bake time

and therefore may only be used once during the Sabbath/Jewish

Holidays.

4.16 Steam Clean

The Steam Clean feature offers a chemical free and time saving

method to assist in the routine cleaning of small and light soils.

Be sure the oven is level and cool before starting Steam Clean. If the

oven temperature is above room temperature, a triple beep will be

heard, and the function will not start. Steam Clean produces best

results when started with a cool oven.

CAUTION!

Do not add bleach, ammonia, oven cleaner, or any other abrasive

household cleaners to the water used for Steam Clean.

Before cleaning any part of the oven, be sure all controls are

turned off and the oven is cool. There is a risk of burns!

To set a Steam Clean cycle:

1. Remove all racks and oven accessories.

10 ENGLISH

2. Scrape or wipe loose debris and grease from the oven bottom.

3. Pour 1 cup of tap water onto the oven bottom. Close oven door.

4. Press Steam Clean.

5. Press START. The time left for the Steam Clean cycle is shown on

the display. Do not open the door during this time. If door is open

while in Steam Clean, "d-O" will appear on the display after a few

minutes.

6. When the Steam Clean cycle is complete, an alert will sound, and

the "End" message will show on the display. Press "oFF" to return

to the clock.

7. Carefully open the door when the Steam Clean is finished. Stand to

the side of the oven, hot air will come out from inside the oven.

8. Wipe oven cavity and bottom. Do not clean oven door gasket.

Avoid leaning or resting on the oven door glass while cleaning the

cavity.

Notes:

• Opening the oven door during the Steam Clean cycle prevents the

water from reaching the temperature needed to clean.

• For best results, clean oven immediately after the cycle is complete.

Steam Clean works best for soils on the oven bottom.

• A non-abrasive scouring pad, stainless steel sponge, plastic

scraper, or eraser style cleaning pad (without cleaner) can be used

for difficult soils. Moisten pads with water before use.

• Place a paper towel or cloth in front of the oven to capture any water

that may spill while wiping out.

• Do not leave the residual water in the oven for any length of time.

• Some condensation or water vapor may appear close to the oven

vent and the oven door glass. This is normal. The oven gasket may

become damp, do not wipe them dry.

• Local water sources often contain minerals (hard water). If hard

water deposits occur, wipe cavity with a 50/50 solution of water and

vinegar or 50/50 solution of water and lemon juice.

• Steam Clean cannot be programmed with a Delay Start feature.

5. BEFORE SETTING MICROWAVE OVEN CONTROLS

WARNING!

Refer to Safety chapters.

5.1 About Your Microwave Oven

Read and keep this user manual handy for future reference on cooking

tips, techniques, and recipes.

IMPORTANT

Always use the microwave with the turntable and support in place.

Do not turn the turntable upside down.

Never turn on the microwave function without food inside.

The appliance may only be used for preparing food. Do not use it

to dry clothes or paper.

Check the food a minute or two before the minimum cooking time

specified in recipes or package directions. Add more time, if

needed.

The following cases may occur while using the device and they are

normal:

• Magnetron cycle on and off when the microwave oven operates at

power levels lower than 100%.

• The exterior of the appliance become warm during cooking or

reheating.

• Moisture condensate in the oven interior. You can reduce the

condensation by covering the food. Be sure not to block the

ventilation openings.

Radio or TV Interference:

If the microwave oven causes interference with your radio or TV,

ensure the microwave is on a different electrical circuit. You can also

move the radio or TV further away from the microwave or check

position and signal of receiving antenna.

5.2 About Microwave Cooking

• Arrange food carefully. Place thickest areas towards outside of dish.

• Watch cooking time. Cook for the shortest amount of time indicated

and add more as needed. Food severely overcooked can smoke or

ignite.

• Cover foods while cooking. It prevents spattering and helps foods to

cook evenly. Refer to your recipe or cookbook for advice on using

paper towels, wax paper, microwave-safe plastic wrap, or a lid.

• Stir foods from outside to center of dish once or twice during

cooking, if possible.

• Turn foods like chicken and hamburgers once during cooking to

speed up the process. Large items, such as roasts, should be

turned over at least once.

• Rearrange foods such as meatballs halfway through cooking both

from top to bottom and from the center of the dish to the outside.

• Allowing food to stand in or out of the oven after cooking can

improve results. Standing time after defrosting or cooking allows the

temperature to spread evenly throughout the food.

• Check for doneness. Look for signs indicating that cooking

temperatures have been reached. Doneness signs include:

– Food steams throughout, not just at edge.

– Center bottom of dish is very hot to the touch.

– Poultry thigh joints move easily.

– Meat and poultry have no pink color.

– Fish is opaque and flakes easily with a fork.

ENGLISH 11

5.3 About Foods

CAUTION!

• Some products such as whole eggs and sealed containers (e.g.

closed jars) will explode and should not be heated in the

microwave oven. There is a risk of injury!

• Do not boil eggs in a microwave oven. Pressure will build up

inside egg yolk and will cause it to burst, possibly resulting in

injury.

• Liquids may start to boil during or after removal from the

microwave. To prevent burns, let the container stand in the

microwave for 30-40 seconds after it stops. Avoid boiling liquids

in narrow-necked containers like soft drink bottles, wine flasks,

or narrow coffee cups, as steam can build up and cause them to

burst or overflow.

• Do not defrost frozen beverages in narrow-necked bottles

(especially carbonated beverages). Even if the container is

open, pressure can build up. This can cause the container to

burst, possibly resulting in injury.

• Hot foods and steam can cause burns. Be cautious when

opening containers of hot food, like popcorn bags, cooking

pouches, and boxes. To avoid injury, direct steam away from

your hands and face.

• Operating the microwave without food inside for more than a

minute can damage it, potentially start a fire, and shorten its

lifespan.

• Do not overcook potatoes. They may dehydrate and catch fire,

causing damage to your microwave oven.

• Always use pot holders or oven mitts when handling utensils

that are in contact with food. There is a risk of burns!

• When opening a food container, hold the lid by the farthest end

and pull it towards you to direct steam away from your face and

hands. Open food and popcorn bags away from your face.

IMPORTANT

• Only pop popcorn in your microwave if you use a special

microwave popcorn accessory or popcorn labeled for

microwave use.

• Pierce foods with unbroken skins, like potatoes, hot dogs,

sausages, tomatoes, apples, chicken livers, and egg yolks, to

allow steam to escape during cooking.

• Avoid heating baby food in glass jars, even with the lid off.

Ensure all infant food is thoroughly cooked, and stir it to

distribute heat evenly. Be cautious when warming formula or

breast milk, as the container may feel cooler than the milk.

Always test the milk before feeding the baby.

• Cook meat to an internal temperature of at least 160°F (71°C)

and poultry to at least 165°F (74°C), to protect against food-

borne illness.

Check foods to see that they are cooked to the United States

Department of Agriculture’s (USDA) recommended temperatures.

To check the doneness of the food, insert a meat thermometer in the

thick or dense part of the meat, away from fat or bone. Do not leave the

thermometer in the food during cooking, unless it is approved for

microwave use.

Check the cooking process frequently to avoid overcooking food.

Do not use the oven cavity to store any items (e.g. cookbooks).

Use only high quality, carefully handled food to minimize the spread of

food-borne bacteria.

Keep the waveguide cover clean. Food residue can cause arcing

and/or fires.

Make sure any utensils, accessories or your clothes do not touch the

safety door latches when removing items from the microwave oven.

5.4 Utensils and Coverings

It is not necessary to buy new cookware, as many items in your kitchen

can be used in your microwave. Make sure the utensil does not touch

the interior walls during cooking.

Table title

SAFE NOT SAFE

• glass ceramic (such as Pyroceram®,

Corningware®)

• heat-resistant glass (such as Pyrex®)

• microwave-safe plastics

• paper plates

• microwave-safe pottery, stoneware

and porcelain

• browning dish (Do not exceed recom

mended preheating time. Follow

manufacturer’s directions.)

• metal pans and bakeware

• dishes with metallic trim

• non-heat-resistant glass

• non-microwave-safe plastics (e.g.

margarine tubs)

• recycled paper products

• brown paper bags

• food storage bags

• metal twist-ties

• styrofoam

To check if the dish can be safely used in microwave, place an empty

dish inside the appliance and microwave it on HIGH setting for 30

seconds. If the dish becomes very hot, it should not be used.

Microwave safe coverings:

• Paper towels - for covering foods for reheating and absorbing fat

while cooking bacon.

• Wax paper - for cooking and reheating.

• Plastic wrap - if it is specially marked for microwave use. Do not

allow plastic wrap to touch food. Vent so steam can escape.

• Microwave safe lids - to keep heat near the food and speed up the

heating process.

• Oven cooking bags - for large meats or foods that need tenderizing.

Do not use metal twist ties. Remember to slit bag so steam can

escape.

5.5 Types of Microwave Oven Accessories

The microwave oven comes with:

• rack

• rotating tray

There are many microwave accessories available for purchase.

Choose carefully to ensure they meet your needs. A microwave-safe

thermometer can help you check the doneness and ensure you that

foods have been cooked to safe temperatures.

IMPORTANT

The manufacturer is not responsible for any damage caused by

using accessories.

5.6 About Children and the Microwave

CAUTION!

Children under 7 should use the microwave oven with close adult

supervision.

For children aged 7 to 12, the supervising person should be in the

same room.

Teach children safety precautions for using the microwave oven: use

pot holders, remove coverings carefully, pay special attention to

packages that crisp food, as they may be very hot.

Do not let children play with the appliance, it is not a toy.

Do not let anyone lean or swing on the microawave oven door.

5.7 Preparing Food for Microwave Cooking

To avoid injury or damage to your appliance and to minimize cleaning,

prepare food for microwave cooking as shown in the table below.

Table title

Food Amount Procedure

Popcorn 1.5 - 3.5 oz

bag

Use Popcorn Mode.

Use only popcorn packaged for microwave oven use.

Do not try to pop unpopped kernels.

12 ENGLISH

Food Amount Procedure

Casserole 8-10 oz Use Reheat Mode.

Place food in a casserole dish slightly larger than the

amount of food. Cover the dish with a vented micro

wave-safe lid, plastic wrap, or wax paper. For larger

quantities or denser foods like stews use a plastic wrap

or lid.

After reheating, stir the food thoroughly if possible.

Ensure the food is hot. If not, use +30 to add more

cook time.

Entree 2-3 servings

Baked Pota

8 - 12 oz Wash and dry.

Pierce at both ends and in center.

Place on turntable.

Asparagus 1 lb

Use Fresh Veggies Mode.

Wash and place in casserole dish.

Add 2 tbsp of water.

Cover with vented microwave-safe lid or plastic wrap.

Stir after cooking.

Broccoli 2 cups

Cauliflower

(florets)

2 cups

Carrots (ba

by)

2 cups

Carrots

(sliced)

2 cups

Corn 2 cups

Food Amount Procedure

Frozen Veg

gie

2 cups Use Frozen Veggies Mode.

Add no water.

Cover with vented lid or plastic wrap.

Stir after cooking.

Rice 1 - 2 cups Place rice into a deep casserole dish and add water as

described below.

Cover with lid or plastic wrap; do not vent.

After cooking, let stand 5 minutes or until all liquid has

been absorbed.

Rice Water Size of casserole dish

1 cup 2 cups 2 quart

2 cups 4 cups 3 quart or larger

6. SETTING MICROWAVE OVEN CONTROLS

WARNING!

Refer to Safety chapters.

6.1 Microwave Control Panel

Table title

2 12

Display

2 Lock

3 Preset Modes

4 Melt / Soften

5 Power Level

6 Number Keys

START

STOP

Timer On/Off

10 Sensor Cook

Auto Cook

12 Settings

6.2 Quick Start

For quick microwave heating or cooking at full power, press any

number key from 1 to 9 to set the desired cook time in minutes. The

microwave function will start automatically after a few seconds. Once

the cooking process is completed, the tone will sound and the display

will show "FOOD READY".

6.3 Timed Heating

1. Use the number pad to enter the time in minutes and seconds. For

example, to heat for 5 min and 30 sec, enter 5 3 0.

Enter the numbers one after the other, no more than 2 seconds

apart. Otherwise, the cooking process will start automatically.

2. Press START.

Once the cooking process is completed, the tone will sound and the

display will show "FOOD READY".

6.4 Timer

This function operates as a countdown timer, it does not activate

microwave cooking.

To activate the function:

1. Press Timer On/Off.

2. Use the number pad to enter the time in minutes and seconds. For

example, to heat for 5 min and 30 sec, enter 5 3 0.

3. Press Timer On/Off.

6.5 Setting Power Level

Some types of food, such as roasts, baked goods, custards, require

slower cooking. Select from ten microwave power levels to suit your

cooking needs.

To set to cook at a lower power level:

1. Use the number pad to enter the time in minutes and seconds. For

example, to heat for 5 min and 30 sec, enter 5 3 0.

Enter the numbers one after the other, no more than 2 seconds

apart. Otherwise, the cooking process will start automatically.

2. Press the Power Level pad until the desired level displays. For

example, press once for high power (PL-HI). Press Power Level

four times to change to 70% power (PL-70). The selected power

level appears in the display.

3. Press START.

Once the cooking process is completed, three tones will sound and the

display will show "FOOD READY".

6.6 Multi-Stage Cooking

Some microwave recipes require different power levels or cooking

times for best results. Your microwave can automatically switch

between two cooking stages with different settings.

1. Use the number pads to enter the time for the first stage.

2. Press Power Level until the desired power for the first stage is

shown.

3. Use the number pads to enter the time for the second stage.

4. Press Power Level until the desired power for the second stage is

shown.

5. Press START.

ENGLISH 13

The display will show the time remaining in the first cooking stage.

Three series of beeps will sound when the second cooking stage starts,

and the display will show the time remaining for the second stage.

Once the cooking process is completed, three tones will sound and the

display will show "FOOD READY".

6.7 Add Cook Time (+30 Sec)

Pressing the START pad once starts cooking at 100% power with 30

seconds of cooking time.

Pressing the START pad during cooking adds 30 seconds (for each

press) to the cook time at the current power level.

This function is not available when using the Defrost or any of the

Preset features.

6.8 Defrost

This function provides you with the best defrosting method for frozen

foods. The cooking guide will show you which defrost sequence is

recommended for the food you are defrosting. You can choose from

three settings: MEAT, POULTRY, or FISH.

The beep during defrosting reminds you to check, turn over, separate,

or rearrange the food in order to get the best defrost results.

To set automatic defrost:

1. Press Defrost until the correct food type appears on the display.

Key Press Food

x1 Meat

x2 Poultry

x3 Fish

2. Press START.

3. Use the numeric keys to enter the weight of the food in pounds.

The setting can be from 0.1 to 6.0 lbs.

4. Press START.

Once the cooking process is completed, three tones will sound and the

display will show "FOOD READY".

6.9 Popcorn

This function lets you pop three different sizes of commercially

packaged microwave popcorn.

Do not leave the microwave oven unattended while popping corn.

To start the function:

1. Press Popcorn until the correct popcorn amount displays.

Key Press Food amount

x1 3.3 oz

x2 3.0 oz

x3 1.75 oz

2. Press START.

Once the cooking process is completed, the tone will sound and the

display will show "FOOD READY".

6.10 Potato

This function cooks 1-4 baked potatoes automatically (starting from

room temperature).

IMPORTANT

Foods with skin - such as potatoes, tomatoes, apples, and

sausages - should be pierced before microwaving to let steam

escape and prevent them from bursting.

To set the Potato feature:

1. Press Potato.

2. Press START.

Once the cooking process is completed, three tones will sound and the

display will show "FOOD READY".

6.11 Veggies

This function allows you to cook fresh and frozen vegetables.

To set Veggies function:

1. Press Veggies until the correct vegetable type displays.

Key Press Food type

x1 Fresh

x2 Frozen

2. Press START.

Once the cooking process is completed, three tones will sound and the

display will show "FOOD READY".

6.12 Beverage

This function allows to heat 1-3 cups of liquid to serving temperature.

To set Beverage function:

1. Press Beverage until the correct amount displays.

Key Press Food Amount

x1 1 cup

x2 2 cups

x3 3 cups

2. Press START.

Once the cooking process is completed, three tones will sound and the

display will show "FOOD READY".

6.13 Melt / Soften

The oven uses low power to melt and soften items.

1. Press Auto Cook until the correct food type displays.

Table title

Key

Press

Food Amount Key

x1 Butter 1 stick 1

2 sticks 2

x2 Chocolate 2 oz 2

4 oz 4

8 oz 8

x3 Ice cream 1 pint 1

1.5 quarts 2

x4 Cream cheese 3 oz 3

8 oz 8

2. Press START.

3. Press the number key corresponding to the amount of food.

4. Press START.

Once the cooking process is completed, three tones will sound and the

display will show "FOOD READY".

6.14 Auto Cook

This function sets the microwave to cook certain types of food with

minimal input.

IMPORTANT

Do not leave the microwave unattended during any Auto Cook

operation.

To set Auto Cook:

1. Press Auto Cook until the correct food type displays.

14 ENGLISH

Table title

Key

Press

Food Amount Key

x1 Bacon 1-3 slices 1-3

x2 Frozen entree 10-20 oz 1-3

x3 Rice 1-2 cups 1-3

2. Press START.

If cooking bacon, use the number keys to enter how many

pieces (1 to 3) and press START.

Once the cooking process is completed, three tones will sound and the

display will show "FOOD READY".

6.15 Sensor Cook

The Sensor Cook categories are designed to detect the increasing

humidity released by the food during the cooking process. The

microwave oven sensor will automatically adjust the cooking time to the

type and amount of food. The food categories that are controlled with

the humidity sensor are shown in the table below.

Table title

Key Press Food type

x1 Frozen breakfast (8-12) oz

x2 Ground meat

x3 Fish or seafood

x4 Chicken breast

Avoid using the same Sensor Cook setting twice in a row for the same

food. This can cause the food to overcook or burn. If the food appears

to be undercooked, use one of the Easy Set pads or cook time pads to

add more time.

Tips for Sensor Cook:

• Never start with less than 4 oz of food.

• For best cooking results, use proper containers and cover or wrap

food with plastic.

• Always use containers labeled as microwave-safe. Do not use

tightly sealed plastic containers, as they trap steam. This can

confuse the sensor and may cause the food to overcook.

• Be sure the outside of the cooking containers and the cavity of the

microwave oven are dry before placing food inside. Excessive

moisture turning into steam that does not result from the food

cooking can confuse the sensor.

To set Sensor Cook:

1. Press Sensor Cook until the correct food type displays.

2. Press START.

Once the cooking process is completed, three tones will sound and the

display will show "FOOD READY".

6.16 Reheat

This function is designed to detect the increasing humidity released by

the food during the cooking process. The microwave oven sensor will

automatically adjust the cooking time to the type and amount of food.

Table title

Key Press Food Type Amount Key

x1 Dinner plate 1-2 plates Default

x2 Soup/sauce 1-2 cups Default

x3 Casserole 1-4 servings Default

Tips for reheat:

• For casseroles, add 2-3 tablespoons of liquid, cover with lid or

vented plastic wrap. Stir when instructed from display.

• For canned foods, empty contents of can into a casserole dish or

serving bowl. Cover dish with lid or vented plastic wrap. Let stand a

few minutes before serving.

• For plates of food, arrange food on plate and add butter or gravies,

etc. Cover with loose-fitting lid or vented plastic wrap. After

reheating, let stand a few minutes before serving.

To set Reheat:

1. Press Reheat until the correct food type displays.

2. Press START.

3. For soup/sauce, use the number keys to enter the quantity (skip for

Default) and press START again.

Once the cooking process is completed, three tones will sound and the

display will show "FOOD READY".

6.17 Keypad Lock

The microwave control panel can be locked to prevent the unintentional

use of the appliance, such as by children.

To lock the panel:

1. Touch and hold for 3 seconds.

The icon will light up.

2. The display will show "LOCKED" if you attempt to set any controls.

To unlock the controls touch and hold for 3 seconds. The lock icon

will go out.

6.18 Setting Clock

1. Press pad once.

"ENTER TIME" flashes on the display.

2. Enter the time using the numeric keys.

3. Press START.

This is a 12 hour clock. If you attempt to enter an incorrect clock time,

the appliance will beep three times. Touch the STOP pad to clear the

display and start again.

6.19 Sound Volume

You can change the volume of the microwave’s audible signals.

1. Press pad twice.

“VOLUME” appears on the display. “LOW”, “MED”, and “HIGH” will

show in a cycle.

2. Press START when the desired volume is shown on the display.

6.20 Pounds / Kilograms

You can set the microwave to measure food weight in either pounds or

kilograms.

1. Press pad 3 times.

"Lb / KG" appears on the display.

2. Press STARTto change the setting.

"Lb" or " KG" will be shortly displayed to show the new setting.

6.21 Microwave suitable cookware and materials

For the microwave, use only suitable cookware and materials. Use the

table below as a reference.

Table title

Cookware / Material Defrost

Reheat

Liquid

Convec

tion

Top Grill

Ovenproof glass and porcelain with no metal

components, e.g. heat-proof glass.

Non-ovenproof glass and porcelain without

any silver, gold, platinum or other metal dec

orations.

Glass and glass ceramic made of oven

proof / frost-proof material.

Ceramic and earthenware without any

quartz or metal components and glazes

which contain metal.

Ceramic, porcelain and earthenware with

unglazed bottom or with small holes, e.g. on

handles.

Heat-resistant plastic up to 392 °F (200 °C).

Always check the plastic container specifica

tion before use.

Cardboard, paper

ENGLISH 15

Cookware / Material Defrost

Reheat

Liquid

Convec

tion

Top Grill

Clingfilm

Roasting film with microwave safe closure

(always check the film specification before

use).

Roasting dishes made of metal, e.g. enam

el, cast iron.

Baking tins, black lacquer or silicon- coated

(always check the baking tins specification

before use).

Cookware / Material Defrost

Reheat

Liquid

Convec

tion

Top Grill

Baking tray

Wire shelf

Cookware for microwave use, e.g. crisp pan.

7. CARE AND CLEANING

WARNING!

Refer to Safety chapters.

7.1 General Information

Remove spills and any heavy soiling as soon as possible. Regular

cleaning reduces the difficulty of major cleaning later.

CAUTION!

Before cleaning any part of the appliance, make sure all controls

are turned off and the appliance is cool.

If you use ammonia or appliance cleaners, remove them and

thoroughly rinse the appliance before operating. Follow

manufacturer's instructions and provide adequate ventilation.

WARNING!

Do not use bleach to clean the appliance.

CAUTION!

Use scouring pads, oven cleaners, abrasive cleaners and

ammonia with special caution while cleaning the appliance.

Table title

Surface or Area Cleaning Recommendation

Aluminum and vinyl Use a soft cloth and clean with mild dish detergent and water. Rinse with clean water, dry and polish with a

soft, clean cloth.

Painted body parts

Painted decorative trims

Use a soft cloth and clean with mild dish detergent and water or a 50/50 solution of vinegar and water.

Rinse with clean water, dry and polish with a soft, clean cloth. Do not apply glass cleaners directly to the

surface, spray onto cloth and wipe.

Touch display Use a soft cloth and clean with mild dish detergent and water or a 50/50 solution of vinegar and water. Do

not spray liquids directly on the display area. Do not use large amounts of water on the display, excess wa

ter may cause damage to the appliance. Do not use other liquid cleaners, abrasive cleaners, scouring pads

or paper towels, they may damage the finish.

Control panel Use a soft cloth and clean with mild dish detergent and water or a 50/50 solution of vinegar and water.

Do not spray liquids directly on the oven control and display area.

Do not use large amounts of water on the control panel. Excess water on the control area may cause dam

age to the appliance.

Do not use other liquid cleaners, abrasive cleaners, scouring pads, or paper towels, they damage the finish.

Stainless Steel Use a soft cloth and clean with mild dish detergent and water or a 50/50 solution of vinegar and water.

Rinse with clean water, and dry with a soft clean cloth.

Do not use abrasive cleaners such as chlorides, chlorines, or ammonia.

Coated Stainless Steel Use a soft cloth and clean with mild dish detergent and water or a 50/50 solution of vinegar and water.

Rinse with clean water, and dry with a soft clean cloth.

Do not use appliance cleaner, stainless steel cleaner or cleaners containing abrasives, chlorides, chlorine,

or ammonia. They may damage the finish.

Porcelain-enameled broiler pan and insert

Porcelain door liner

Porcelain body parts

Rinse with clean water and a damp cloth. Scrub gently with a soapy non-abrasive scouring pad to remove

most spots. Rinse with a 50/50 solution of clean water and ammonia. If necessary, cover difficult spots with

an ammonia soaked paper towel for 30 to 40 minutes. Rinse and wipe dry with a clean cloth. Remove all

cleaners to avoid damage to the porcelain caused by heating.

Do not allow food spills with a high sugar or acid content such as milk, tomatoes, sauerkraut, fruit juices, or

pie filling to remain on porcelain surfaces. They may cause a dull spot even after cleaning.

Manual clean oven interior The interior of the oven is porcelain coated and safe to clean with oven cleaner. Always follow manufactur

er's instructions for cleaners. After cleaning, remove all cleaners to avoid damage to the porcelain caused

by heating.

Do not spray oven cleaner on any electrical controls or switches.

Do not spray cleaner on oven door trim, door gasket, plastic drawer glides, handles or any exterior surfaces

of the appliance.

16 ENGLISH

Surface or Area Cleaning Recommendation

Oven door Use mild dish detergent and water or a 50/50 solution of vinegar and water to clean the top, sides, and front

of the oven door and rinse well. You can use a glass cleaner on the outside glass of the door. You can use

ceramic smoothtop cleaner or polish on the interior door glass.

Do not immerse the door in water. Do not spray or allow water or cleaners to enter the door vents.

Do not use oven cleaners, cleaning powders, or any harsh abrasive cleaning materials on the outside of the

oven door.

Do not clean the oven door gasket. The oven door gasket is made of a woven material which is essential

for a good seal.

Do not rub, damage, or remove oven door gasket.

7.2 General Cleaning

Refer to the table at the beginning of this chapter for more information

about cleaning specific parts of the oven.

Follow these cleaning precautions:

• Allow the oven to cool before cleaning.

• Wear rubber gloves when cleaning the appliance manually.

Remove soils using hot, soapy water. Do not allow food spills with a

high sugar or acid content (such as milk, tomatoes, sauerkraut, fruit

juices or pie filling) to remain on the surface as they may cause a dull

spot even after cleaning. Remove spillovers and heavy soiling as soon

as possible. Regular cleaning will reduce the effort required for major

cleaning later.

CAUTION!

Before manually cleaning any part of the oven, be sure all controls

are turned off and the oven is cool. The oven may be hot and can

cause burns. Remove all racks and accessories from the oven

before cleaning. Ammonia must be rinsed before operating the

oven. Provide adequate ventilation.

Cleaning Porcelain Enamel Oven

The oven interior is porcelain on steel.

To clean the interior use oven cleaners.

To remove heavy soil:

1. Place the dish of ammonia in the oven.

Let it sit overnight or for several hours with the oven door closed.

Clean softened dirt spots using hot, soapy water.

Rinse thoroughly with water and a clean cloth.

2. If soil remains, use a nonabrasive scouring pad or nonabrasive

cleaner.

If necessary, apply an oven cleaner following the manufacturer's

instructions.

Do not mix ammonia with other cleaners.

3. Clean any soil from the oven frame, the door liner outside the oven

door gasket, and the small area at the front center of the oven

bottom.

Use hot, soapy water for cleaning.

Rinse well with clean water and a cloth.

Aluminum Foil, Aluminum Utensils, and Oven Liners

WARNING!

Never cover any slots, holes, or passages in the oven bottom or

cover an entire oven rack with materials such as aluminum foil.

Doing so blocks airflow through the oven and may cause carbon

monoxide poisoning. Aluminum foil linings may trap heat, causing

a fire hazard.

• Protective liners- Do not use aluminum foil to line the oven bottom.

High heat can melt it, damaging the oven and reducing air

circulation, leading to poor baking results. Only use aluminum foil as

recommended in the manual to avoid electric shock or fire risks

• Aluminum utensils- Aluminum utensils have a lower melting point

than other metals. Use aluminum pots and pans with care.

• Oven racks- Do not cover oven racks with aluminum foil. It restricts

heat and airflow, affecting cooking results.

7.3 Replacing the Oven Light

CAUTION!

Be sure the oven is unplugged and all parts are cool before

replacing the oven light.

The interior oven light is located at the rear of the oven cavity and is

covered by a glass shield. The glass shield must be in place whenever

the oven is in use.



NOTE

Wear a cotton glove or use a paper towel when installing a new

bulb. Do not touch the new bulb with your fingers when replacing.

This will shorten the life of the bulb.

To replace the oven interior light bulb:

1. Turn electrical power off at the main source or unplug the

appliance.

2. Remove interior oven light shield by turning a quarter turn counter-

clockwise.

3. Replace bulb with a new T-4 type Halogen 25 watt appliance bulb.

4. Replace glass oven light shield by rotating clockwise.

5. Turn power back on again at the main source (or plug the

appliance back in).

Be sure to reset the time of day on the clock.

7.4 Removing and Replacing the Oven Door

CAUTION!

The door is heavy. For safe, temporary storage, lay the door flat

with the inside of the door facing down.

IMPORTANT

Most oven doors contain glass that can break. Do not hit the glass

with pots, pans, or any other object. Scratching, hitting, jarring, or

stressing the glass may weaken its structure, causing an increased

risk of breakage at a later time. Do not close the oven door until all

of the oven racks are fully in place.

To remove the oven door

1. Open oven door completely, horizontal with floor.

ENGLISH 17

Figure A

2. Pull up the lock located on each hinge support toward front of the

oven until the lock stops. You may have to apply a little upward

pressure on the lock to pull it up.

Figure B

3. Grasp the door by the sides, and close the door until the door

frame makes contact with the unlocked hinges.

Figure C

4. Pull the bottom of the door toward you while rotating the top of the

door toward the appliance to completely disengage the hinge

levers.

Figure D

To replace the oven door

1. Firmly grasp both sides of oven door along the door sides. Do not

use the oven door handle (Figure D).

2. Hold the oven door at the same angle as the removal position

(Figure C). Carefully insert the hinge levers into the oven frame

until you feel the hinge levers are seated into the hinge notches.

The hinge arms must be fully seated into the hinge notches before

the oven door can be fully opened.

3. Fully open the oven door, horizontal with floor (Figure A).

4. Push the door hinge locks up toward and into the oven frame on

both left and right oven door hinges to the locked position (Figure

B).

5. Close the oven door.

7.5 Cleaning the Microwave

• Keep the oven clean inside and out for best performance and

safety.

• Wipe spills immediately, especially after cooking greasy foods.

• Clean the surfaces with soft cloth and mild detergent. Avoid

abrasive cleaners or scouring pads.

• To loosen stubborn residue, heat 2 cups of water (optionally with

lemon juice) in a microwave-safe container for 5 minutes. Let it sit

for 1–2 minutes before cleaning.

• Remove and wash the glass turntable separately with care. Do not

put it in water immediately after cooking.

• Clean the outside surface with mild soap and a soft cloth. Do not let

water enter vents or openings.

• Clean the oven door with soft cloth and mild detergent to avoid

scratching.

• The steam can accumulate during operation of the microwave oven.

Wipe it away with a soft cloth.

• Never operate empty microwave oven. This may damage internal

components.

8. TROUBLESHOOTING

WARNING!

Refer to Safety chapters.

8.1 Oven Baking

For best cooking results, preheat the oven before baking cookies,

breads, cakes, pies, pastries, etc.

There is no need to preheat the oven for roasting meat or baking

casseroles.

The cooking time and temperature need to bake a product may vary

from the previously owned appliance.

Table title

Baking Problems Possible Cause Solution

Cookies and biscuits burn on the bottom. Cookies and biscuits put into oven before oven is

preheated.

Allow oven to preheat to desired temperature before placing food in oven.

Choose pan size that permits at least 2'' of air space.

18 ENGLISH

Baking Problems Possible Cause Solution

Cakes too dark on top or bottom. Cakes put in oven before oven is preheated.

Rack position too high or too low.

Oven too hot.

Allow oven to preheat to selected temperature before placing food in the oven.

Use proper rack position for baking needs.

Set oven temperature 25°F / 13°C lower than recommended.

Cakes not done in center. Oven too hot.

Incorrect pan size.

Pan not centered in oven.

Glass cookware slow heat conductor.

Set oven temperature 25°F / 13°C lower than recommended.

Use pan size suggested in recipe.

Use proper rack position and place pan with the space on all sides of pan at

least 2'' / 5.1 cm.

Reduce temperature and increase cook time or use shiny bakeware.

Cakes not level. Oven not level.

Pan too close to oven wall or rack overcrowded.

Pan warped.

Oven light left on while baking.

Place a marked glass measuring cup filled with water on the center of the

oven rack. If the level is uneven, refer to installation instructions for leveling

the oven.

Use proper rack position and place pan with the space on all sides of pan at

least 2'' / 5.1 cm.

Do not use dented or warped pans.

Do not leave the oven light on while baking.

Foods not done when cooking time is over. Oven too cool.

Oven overcrowded.

Oven door opened too frequently.

Set oven temperature 25°F / 13°C higher than suggested and bake for the

recommended time.

Make sure to remove all pans from the oven except the ones that you use for

baking.

Open oven door only after the shortest recommended baking time.

8.2 Before you Call (Solutions to Common Problems)

Table title

Let us help you troubleshoot your concern! This section will help you with common issues. If you need us, visit our website, chat with an agent, or call us.

We may be able to help you avoid a service visit. If you do need service, we can get that started for you!

Frigidaire.com (United States)

1-800-374-4432

Frigidaire.ca (Canada)

1-800-265-8352

Table title

Occurrence Possible cause Solution

Entire appliance does not operate. Appliance not connected. Make sure power cord is plugged properly into outlet. Check your fuse box or breaker box

to make sure the circuit is active.

Electrical power outage. Check the house light to be sure. Call your local electric company for service outage infor

mation.

Oven Problems

Occurrence Possible cause Solution

Poor baking results. Many factors affect baking results. Use proper oven rack position. Center food in the oven and space pans to allow air to cir

culate. Preheat the oven to the set temperature before placing food in the oven. Adjust the

temperature and baking time recommended in the recipe.

Flames inside oven or smoking from

oven vent.

Excessive spills in oven.

Grease of food spilled onto the oven bot

tom or oven cavity.

Wipe up excessive spills before turning on the oven.

If flames or excessive smoke are present when using broil, refer to Setting Oven Controls.

Oven smokes excessively when boil

ing.

Incorrect setting. Refer to Setting Oven Controls.

Meat to close to the broil element or burn

er.

Reposition the broil pan to provide proper clearance between the meat and broil element

or burner. Remove excess fat from meat. Cut remaining fatty edges to prevent curling, do

not cut into lean.

Grease build up on oven surfaces. Regular cleaning is necessary when you broil frequently. Grease or food splatters cause

excessive smoking.

Convection fan does not rotate. Oven door is open. The convection fan turns off if the oven door is open when convection is active. Close the

oven door.

On gas models, the convection fan begins to rotate about 6 minutes into the preheating

process.

Frigidaire FCWM3030AB 30 inch Microwave Combination Oven with 6.9 cu. ft. Capacity, Air Fry, 30-Minute Steam Clean, Convection Bake and Sensor Cook Black

Product's Documents

Use and Care Manual.

Specifications

Frigidaire FCWM3030AB Questions and Answers

Related Products

Frigidaire PCWM3085AF Professional 30 inch Microwave Combination Wall Oven with 7 cu. ft. Total Capacity, Stone-Baked Pizza Mode, Total Convection, Convection Microwave and Temperature Probe in Stainless Steel

Frigidaire GLEB27M9FSB 27 Inch Microwave Combination Oven

Frigidaire GCWM3070AF Combination Electric Wall Oven and Microwave

Frigidaire FCWM2727AB 27" Electric Wall Oven/Microwave Combination

Frigidaire FCWM2727AS 27" Electric Wall Oven/Microwave Combination

Frigidaire FGMC2766UD - 27'' Electric Wall Oven/Microwave Combination
