Parts List
hoshizakiamerica.com
Refrigerated Kitchen Equipment
Steelheart A Series
Models
Undercounter
Worktop
Prep Table
Number: 71387
Issued: 10-25-2018
Revised: 6-11-2021
2
CONTENTS
Auxiliary Codes ...................................................................................................................... 3
Model Codes ........................................................................................................................11
A. Main Assembly ................................................................................................................ 12
UR27, WR27, SR27, UF27, and WF27 Undercounter, Worktop, and Prep Table ............... 12
UR36, WR36, and SR36 Undercounter, Worktop, and Prep Table .................................. 15
UR48, WR48, SR48, UF48, and WF48 Undercounter, Worktop, and Prep Table ............ 17
UR60, WR60, SR60, UF60, and WF60 Undercounter, Worktop, and Prep Table ............ 20
UR72, WR72, and SR72 Undercounter, Worktop, and Prep Table .................................. 24
B. Refrigeration Circuit ......................................................................................................... 28
UR27, WR27, and SR27 Undercounter, Worktop, and Prep Table ................................... 28
UF27 and WF27 Undercounter and Worktop .................................................................. 30
UR36, WR36, and SR36 Undercounter, Worktop, and Prep Table .................................. 32
UR48, WR48, and SR48 Undercounter, Worktop, and Prep Table .................................. 34
UF48 and WF48 Undercounter and Worktop .................................................................. 36
UR60, WR60, and SR60 Undercounter, Worktop, and Prep Table .................................. 38
UF60 and WF60 Undercounter and Worktop .................................................................. 40
UR72, WR72, and SR72 Undercounter, Worktop, Prep Table ......................................... 42
C. Door-Right Hinged ........................................................................................................... 44
D. Door-Left Hinged ............................................................................................................. 46
E. Door-Right Glass Door Hinged ........................................................................................ 48
F. Door-Left Glass Door Hinged ........................................................................................... 49
G. Drawer............................................................................................................................. 50
H. Accessories & Labels ...................................................................................................... 52
3
Auxiliary Codes
UR27A
H-5 October 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
UR27A-GLP01
H-5 May 2018
J-5 April 2019
J-6 June 2019
J-7 July 2019
K-5 February 2020
L-5 January 2021
UR27A-01
H-5 October 2018
J-5 January 2019
J-7 July 2019
K-5 January 2020
UR27A-LP
H-5 February 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
UR27A-LPC
H-5 October 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
UR27A-LPW
J-5 April 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
UR27A-D2
G-5 November 2017
H-5 October 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
WR27A
H-5 October 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
L-5 January 2021
WR27A-01
J-5 January 2019
K-5 February 2020
WR27A-D2
H-5 November 2018
J-5 January 2019
J-7 July 2019
K-5 January 2020
SR27A-8
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
SR27A-8D2
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-6 June 2019
J-7 August 2019
L-5 February 2021
SR27A-12M
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
K-5 February 2020
L-5 February 2021
SR27A-12MD2
H-5 March 2018
H-6 November 2018
J-5 September 2019
K-5 February 2020
L-5 February 2021
4
Auxiliary Codes
Continued
UF27A
G-5 July 2017
H-5 October 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
UF27A-GLP01
H-5 May 2018
J-5 January 2019
J-6 June 2019
J-7 August 2019
K-5 January 2020
L-5 March 2021
UF27A-01
J-5 February 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
UF27A-LP
G-5 December 2017
H-5 October 2018
J-5 February 2019
J-6 June 2019
J-7 July 2019
K-5 February 2020
L-5 February 2021
UF27A-D2
H-5 October 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
WF27A
G-5 July 2017
H-5 October 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
WF27A-01
H-5 October 2018
J-5 February 2019
J-6 June 2019
J-7 July 2019
L-5 March 2021
WF27A-D2
G-5 September 2017
H-5 October 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
5
Auxiliary Codes
Continued
UR36A
G-5 September 2017
H-5 November 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
UR36A-01
H-5 October 2018
J-5 March 2019
J-6 June 2019
K-5 January 2020
L-5 January 2021
WR36A
H-5 October 2018
J-5 February 2019
J-6 September 2019
L-5 January 2021
WR36A-01
J-5 February 2019
J-6 November 2019
SR36A-10
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-7 August 2019
K-5 February 2020
L-5 January 2021
SR36A-15M
H-5 January 2018
H-6 October 2018
J-5 January 2019
J-6 June 2019
J-7 August 2019
J-8 September 2019
K-5 January 2020
L-5 January 2021
6
Auxiliary Codes
Continued
UR48A
G-5 September 2017
H-5 October 2018
J-5 January 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
UR48A-GPL01
H-5 May 2018
J-5 April 2019
J-7 July 2019
UR48A-01
H-5 October 2018
J-5 February 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
UR48A-D2
H-5 November 2018
J-5 January 2019
J-7 July 2019
L-5 February 2021
UR48A-D4
G-5 November 2017
H-5 October 2018
J-5 January 2019
K-5 January 2020
L-5 January 2021
WR48A
G-5 September 2017
H-5 October 2018
J-5 January 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
WR48A-01
H-5 October 2018
J-5 March 2019
J-7 July 2019
K-5 January 2020
WR48A-D2
H-5 November 2018
J-5 March 2019
J-7 July 2019
L-5 February 2021
WR48A-D4
J-5 April 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
SR48A-8
H-5 October 2018
H-6 December 2018
J-5 January 2019
J-7 July 2019
K-5 February 2020
L-5 February 2021
SR48A-12
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-7 July 2019
K-5 February 2020
L-5 January 2021
SR48A-12D2
H-5 October 2018
H-6 November 2018
J-5 January 2019
K-5 January 2020
L-5 February 2021
SR48A-12D4
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-7 July 2019
K-5 January 2020
L-5 January 2021
SR48A-12M
H-6 November 2018
J-5 February 2019
J-8 November 2019
K-5 January 2020
L-5 January 2021
SR48A-18M
H-5 January 2018
H-6 November 2018
J-5 January 2019
J-7 July 2019
J-8 September 2019
K-5 January 2020
L-5 January 2021
7
Auxiliary Codes
Continued
SR48A-18MD2
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-7 July 2019
J-8 October 2019
L-5 May 2021
SR48A-18MD4
H-5 January 2018
H-6 November 2018
J-5 January 2019
J-7 July 2019
J-8 November 2019
K-5 January 2020
L-5 February 2021
UF48A
G-5 June 2017
H-5 October 2018
J-5 January 2019
J-6 June 2019
J-7 July 2019
K-5 January 2020
L-5 February 2021
UF48A-01
H-5 November 2018
J-5 March 2019
J-7 July 2019
K-5 January 2020
L-5 March 2021
UF48A-D4
G-5 September 2017
H-5 October 2018
J-5 January 2019
J-7 July 2019
K-5 February 2020
L-5 February 2021
WF48A
H-5 October 2018
J-5 January 2019
J-6 June 2019
J-7 August 2019
K-5 January 2020
L-5 February 2021
WF48A-01
H-5 October 2018
J-5 January 2019
J-7 August 2019
K-5 February 2020
L-5 March 2021
WF48A-D4
H-5 November 2018
J-5 January 2019
J-6 June 2019
J-7 August 2019
K-5 January 2020
L-5 February 2021
8
Auxiliary Codes
Continued
UR60A
G-5 August 2017
H-5 October 2018
J-5 January 2019
J-6 May 2019
J-7 June 2019
J-8 July 2019
K-5 January 2020
L-5 January 2021
UR60A-01
J-6 May 2019
J-8 December 2019
K-5 February 2020
L-5 March 2021
UR60A-D2
H-5 October 2018
J-5 January 2019
J-7 June 2019
J-8 September 2019
K-5 January 2020
L-5 January 2021
UR60A-D4
G-5 October 2017
J-5 March 2019
J-6 May 2019
J-7 June 2019
J-8 July 2019
K-5 January 2020
L-5 January 2021
WR60A
H-5 October 2018
J-5 January 2019
J-6 May 2019
J-7 June 2019
J-8 July 2019
K-5 January 2020
L-5 January 2021
WR60A-01
J-5 February 2019
J-8 July 2019
K-5 January 2020
L-5 March 2021
WR60A-D2
J-5 March 2019
J-6 May 2019
J-8 July 2019
K-5 January 2020
WR60A-D4
H-5 October 2018
J-5 March 2019
J-6 May 2019
J-7 June 2019
J-8 August 2019
K-5 January 2020
L-5 January 2021
SR60A-8
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-8 September 2019
K-5 February 2020
L-5 January 2021
SR60A-12
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-7 June 2019
J-8 September 2019
K-5 January 2020
L-5 January 2021
SR60A-12M
J-5 January 2019
J-7 June 2019
J-8 August 2019
K-5 January 2020
L-5 February 2021
SR60A-16
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-6 May 2019
J-7 June 2019
J-8 July 2019
K-5 January 2020
L-5 January 2021
SR60A-18M
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-6 May 2019
J-7 June 2019
J-8 July 2019
K-5 January 2020
L-5 January 2021
9
Auxiliary Codes
Continued
SR60A-24M
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-6 May 2019
J-7 June 2019
J-8 July 2019
J-9 September 2019
K-5 January 2020
L-5 January 2021
SR60A-24MD2
H-5 October 2018
H-6 November 2018
J-5 March 2019
J-6 May 2019
J-7 June 2019
J-8 August 2019
J-9 December 2019
SR60A-24MD4
H-5 March 2018
H-6 November 2018
J-5 January 2019
J-6 May 2019
J-7 June 2019
J-8 July 2019
J-9 September 2019
UF60A
G-5 April 2017
H-5 October 2018
J-5 January 2019
J-7 June 2019
J-8 July 2019
K-5 January 2020
UF60A-01
H-5 October 2018
J-5 July 2019
WF60A
G-5 April 2017
H-5 October 2018
J-5 January 2019
J-6 May 2019
J-7 June 2019
J-8 July 2019
K-5 January 2020
WF60A-01
H-5 November 2018
J-5 July 2019
10
Auxiliary Codes
Continued
UR72A
G-5 October 2017
H-5 November 2018
J-5 January 2019
J-6 May 2019
J-7 June 2019
J-8 July 2019
K-5 January 2020
L-5 January 2021
UR72A-01
J-5 July 2019
K-5 March 2020
L-5 January 2021
UR72A-D6
G-5 September 2017
H-5 December 2018
J-5 February 2019
J-7 June 2019
J-8 July 2019
K-5 January 2020
L-5 January 2021
WR72A
H-5 November 2018
J-5 January 2019
J-6 May 2019
J-7 June 2019
J-8 August 2019
K-5 January 2020
L-5 January 2021
WR72A-01
J-6 May 2019
K-5 February 2020
WR72A-D6
H-5 October 2018
J-5 January 2019
J-6 May 2019
J-8 July 2019
K-5 January 2020
L-5 February 2021
SR72A-12
H-5 October 2018
J-5 February 2019
J-6 May 2019
J-8 July 2019
K-5 January 2020
L-5 February 2021
SR72A-16
J-5 January 2019
J-8 July 2019
K-5 January 2020
L-5 March 2021
SR72A-18
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-6 May 2019
J-7 June 2019
J-8 July 2019
K-5 January 2020
L-5 January 2021
SR72A-18M
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-6 May 2019
J-8 July 2019
J-9 September 2019
L-5 January 2021
SR72A-24M
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-6 May 2019
J-9 September 2019
L-5 January 2021
SR72A-30M
H-5 February 2018
H-6 November 2018
J-5 January 2019
J-6 May 2019
J-7 June 2019
J-8 July 2019
J-9 September 2019
K-5 February 2020
L-5 January 2021
SR72A-30MD2
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-7 June 2019
J-9 September 2019
K-5 January 2020
L-5 March 2021
SR72A-30MD4
H-5 October 2018
H-6 November 2018
J-5 January 2019
J-7 June 2019
J-8 August 2019
J-9 September 2019
K-5 February 2020
L-5 February 2021
SR72A-30MD6
H-5 February 2018
H-6 November 2018
J-5 January 2019
J-8 August 2019
J-9 September 2019
K-5 January 2020
L-5 January 2021
11
Model Codes
The model number code breakdown is as follows:
U – Undercounter
W – Worktop
S– Prep Table
R – Refrigerator
F – Freezer
27, 36, 48, 60, 72 – width
After Dash (-) Nomenclature:
-GLP – Glass Door Low Prole
-01 – Locks
-LP – Low Prole Casters
-LPC – Low Prole Stainless Steel Shelf
-D2, -D4, -D6 – Drawers and Drawer/Door Combination
-8, -10, -12, -16, -18 – Prep Table Number of Pans
-12M, -15M, -18M, -24M, -30M – Mega Top Number of Pans
Auxiliary Code Breakdown
The auxiliary code is the rst two characters in the serial number. The rst character
indicates the year. Years progress or regress in alphabetical order. The series runs from
"A" through "V" and the letters "I" and "O" are skipped. The second character indicates
signicant part changes within a year. Base is "5" and this number advances for each
change. In cases where there is a letter in parentheses, this designates the month. This is
the last character in the serial number. The series runs from "(A)" through "(M)" and the
letter "(I)" is skipped. This designation is only included when identifying a parts change
within an auxiliary code.
Note About Ordering Parts
Most assemblies cannot be ordered as complete units; parts in the assemblies generally
must be ordered separately.
12
A. Main Assembly
UR27, WR27, SR27, UF27, and WF27 Undercounter, Worktop, and Prep Table
G-5 to L-5
For Door, see Sections "C, D, E or F"
For Casters, see Section "H"
Model Shown: SR27A-12M
Model Shown: UF27A
For Pans, see Section "H"
Undercounter, Worktop, Prep Table
Common Parts
Prep Table
Specic Parts
For Cutting Board,
see Section "H"
5
6
30
29
19
26
25
28
24 24a
27
For Drawers,
see Section "G"
1
2 3 4
7 8
18
23
21
20
9
10
11
12
22
31 32 33
15
16
14
13
LED Light Assembly:
Glass Door Models
17
13
Title: A. Main Assembly Models: UR27, WR27, SR27, UF27, and WF27 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
Common Parts
1 Control Module UC/WT Refrigerator 4A5959G02 1
UC/WT Freezers 4A5959G04 1
Prep Tables 4A5959G03 1
2 Cabinet Temperature
Control
(Spindle)
UC/WT/
Prep Tables
4A5952-01 1
3 Dial Plate UC/WT/
Prep Tables
4A6031-01 1
4 Dial Knob UC/WT/
Prep Tables
4A5950-01 1
5 Cabinet Thermometer 461083-01 1
6 Side Pilaster All UC/WT/
Prep Tables
Except
-D(x) Models
4A5854-01 4
7 Shelf All UC/WT/
Prep Tables
Except
-D(x) Models
-LPC Models
3A2830-07 1
-LPC Models 3A2830-14 1
3A2830-20 1
8 Shelf Clip All UC/WT/
Prep Tables
Except
-D(x) Models
4A5418-01 4
9 Bumper 3A6696-01 2
10 Power Cord 4A5718-01 1
11 Rear Panel UC/WT Refrigerator
and Prep Tables
1A4961-01 1
UC/WT Freezers 1A2260-01 1
12 Pressure Relief Valve UC/WT Freezers 4A5694-01 1
13 LED Driver -GLP01 1A5501-01 1
14 LED Lamp 3A9348-01 1
15 LED Clip 4A5906-01 2
16 LED Switch 4A6067-01 1
17 Channel 4A6064-01 1
14
Title: A. Main Assembly Models: UR27, WR27, SR27, UF27, and WF27 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
Prep Table Specic Parts
18 Rail Cover
(includes items 20
through 24a)
-8, -8D2 3A9410A01 1
-12M, -12MD2 3A9411A01 1
19 Rail Hood 3A9407A01 1
20 Pivot Pin 4A6161-01 2
21 Pivot Bolt 4A6160-01 2
22 Flat Washer 7W22I0832 2
23 Tree Clip 4A0579-01 2
24 Handle 1A3416-01 1
24a Pan Head Screw 7C12I1412 2
25 Right Cutting Board
Bracket
-8, -8D2, -12M,
-12MD2
3A8971-02 1
26 Left Cutting Board
Bracket
-8, -8D2, -12M,
-12MD2
3A8971-01 1
27 Center Cutting Board
Bracket
-8, -8D2 4A5905-01 1
-12M, -12MD2 4A6794-01 2
28 Rail Divider
(front-to-back)
-8, -8D2
(HS-5187)
3A8903-01 1
-12M, -12MD2
(HS-5184)
3A8855-01 1
29 Rail Divider
(side-to-side)
-8, -8D2
(HS-5185)
3B0027-03 2
-12M, -12MD2
(HS-5185)
4
30 Catch Tray
(includes items 31
through 33)
-8, -8D 2A8668A01 1
-12M, -12MD 2A8666A01 1
31 Handle 4A4518-01 1
32 Pan Head Screw 8×32 7C12I0838 2
33 Flat Washer -8, -8D2 7W22-0400 2
-12M, -12MD2 7W22-0500 2
15
A. Main Assembly
UR36, WR36, and SR36 Undercounter, Worktop, and Prep Table
G-5 to L-5
For Door, See Sections "C, D, E or F"
Model Shown: SR36A-15M
For Pans, See Section "H"
Undercounter, Worktop, Prep Table
Common Parts
Prep Table
Specic Parts
For Cutting Board,
See Section "H"
9 10
6
7
24
15
22
21
24
20 20a
23
8
7
For Casters, See Section "H"
Model Shown: SR36A-10
26
25
2 3 4 5
14
19
16
17
12
13
-15M
27
18
1
11
For Drawers, see Section "G"
16
Title: A. Main Assembly Models: UR36, WR36, and SR36 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
J-8
(K)
J-8 (L)
to
L-5
Common Parts
1 Control Module UC/WT 4A5959G02 1 1
Prep Table 4A5959G03 1 1
2 Cabinet Temperature
Control (Spindle)
4A5952-01 1 1
3 Adapter Plate 4A5949-01 1 1
4 Dial Plate 4A5960-01 1 1
5 Dial Knob 4A5950-01 1 1
6 Cabinet Thermometer 461083-01 1 1
7 Side Pilaster 4A5719-01 4 4
8 Center Pilaster 4A5417-01 2 2
9 Shelf 3A6876-05 1 1
10 Shelf Clip 4A5418-01 6 6
11 Bumper 3A6696-01 2 2
12 Power Cord 4A5718-01 1 1
13 Rear Panel 1A2836-01 1 1
Prep Table Specic Parts
14 Rail Cover
(includes items 16
through 20a)
-10 3A9408A01 1 1
-15M 3A9409A01 1 1
15 Rail Hood 3A9406A01 1 1
16 Pivot Pin 4A6161-01 2 2
17 Pivot Bolt 4A6160-01 2 2
18 Flat Washer 7W22I0832 2 2
19 Tree Clip 4A0579-01 2 2
20 Handle 1A3416-01 1 1
20a Pan Head Screw 7C12I1412 2 2
21 Right Cutting Board
Bracket
-10, -15M 3A8971-02 1 1
22 Left Cutting Board
Bracket
-10, -15M 3A8971-01 1 1
23 Center Cutting Board
Bracket
-10 4A5905-01 1 1
-15M 4A6794-01 3 2
24 Rail Divider
(front-to-back)
-10
(HS-5187)
3A8903-01
2 2
-15M
(HS-5184)
3A8855-01
2 2
25 Rail Divider
(side-to-side outer)
-10
(HS-5185)
3B0027-03
1 1
-15M
(HS-5185)
2 2
26 Rail Divider
(side-to-side center)
-10
(HS-5186)
3B0028-03
1 1
-15M
(HS-5186)
2 2
27 Catch Tray -10 1A4219-02 1 1
-15M 1A4219-03 1 1
17
For Door, see Sections "C, D, E or F"
Model Shown: UF48A
Model Shown: SR48A-18M
For Cutting Board,
see Section "H"
For Pans, see Section "H"
Undercounter, Worktop, Prep Table
Common Parts
Prep Table
Specic Parts
A. Main Assembly
UR48, WR48, SR48, UF48, and WF48 Undercounter, Worktop, and Prep
Table
G-5 to L-5
For Drawers, see Section "G"
10
7
33
32
34
24
30
31
23
35
34
6
8 9
2
3
4 5
28
25
26
29
29a
For Casters, See
Section "H"
36
27
11
12
16
1
15
For Casters, see
Section "H"
13
14
Prep Table
and Freezer
37 38 39
-8,
-12
-12D2
-12D4
-12M
-18M
-18MD2
-18MD4
20
17
19
18
LED Light Assembly:
Glass Door Models
2221
18
Title: A. Main Assembly Models: UR48, WR48, SR48, UF48, and WF48 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
J-8
(K)
J-8
(L)
to
L-5
Common Parts
1 Control Module UC/WT Refrigerator 4A5959G02 1 1
UC/WT Freezers 4A5959G04 1 1
Prep Tables 4A5959G03 1 1
2 Cabinet Temperature
Control
(Spindle)
UC/WT/Prep Tables 4A5952-01 1 1
3 Adapter Plate UC/WT/Prep Tables 4A5949-01 1 1
4 Dial Plate Label UC/WT/Prep Tables 4A5960-01 1 1
5 Dial Knob UC/WT/Prep Tables 4A5950-01 1 1
6 Center Back Pilasters All UC/WT/Prep Tables
Except
-D(x) Models
4A5417-01 2 2
7 Sides and Front
Pilaster
UC/WT/Prep Tables 4A5719-01 6 6
Door/Drawer 4 4
8 Shelf UC/WT/Prep Tables 3A2830-08 2 2
Door/Drawer 1 1
9 Shelf Clip UC/WT/Prep Tables 4A5418-01 8 8
Door/Drawer 4 4
10 Cabinet Thermometer 461083-01 1 1
11 Bumpers 3A6696-01 2 2
12 Condensate Pan UC/WT Freezers/
Prep Tables
1A3373-01 1 1
13 Elbow Socket 4A5624-01 1 1
14 Hose 4A0658L01 1 1
15 Power Cord 4A5718-01 1 1
16 Rear Panel UC/WT Refrigerators 1A2261-01 1 1
UC/WT Freezers/
Prep Tables
1A5747-01 1 1
17 LED Driver -GLP01 1A5501-01 1 1
18 LED Lamp 3A9348-01 2 2
19 LED Y Harness 4A6080-01 1 1
20 LED Clip 4A5906-01 4 4
21 LED Switch 4A6067-01 1 1
22 Channel 4A6064-01 1 1
19
Title: A. Main Assembly Models: UR48, WR48, SR48, UF48, and WF48 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
J-8
(K)
J-8
(L)
to
L-5
Prep Table Specic Parts
23 Rail Cover Assembly
(includes items 25
through 29a)
-8 3A9405A01 1 1
-12, -12D2, -12D4 3A9398A01 1 1
-12M 3A9402A01 1 1
-18M, -18MD2, -18MD4 3A9399A01 1 1
24 Rail Hood -8 3A9404A01 1 1
-12M 3A9403A01 1 1
-12, -12D2, -12D4 3A9394A01 1 1
-18M, -18MD2, -18MD4 3A9395A01 1 1
25 Pivot Pin 4A6161-01 2 2
26 Pivot Bolt 4A6160-01 2 2
27 Flat Washer 7W22I0832 2 2
28 Tree Clip 4A0579-01 2 2
29 Handle 1A3416-01 1 1
29a Pan Head Screw 7C12I1412 2 2
30 Right Cutting Board
Bracket
3A8971-02 1 1
31 Left Cutting Board
Bracket
3A8971-01 1 1
32 Center Cutting Board
Bracket
-8, -12, -12D2, -12D4 4A5905-01 2 2
-12M, -18M, -18MD2,
-18MD4
4A6794-01 4 3
33 Rail Divider A
(front-to-back)
-8
(HS-5188)
3A8904-01 1 1
-12, -12D2, -12D4
(HS-5188)
2 2
-12M
(HS-5184)
3A8855-01 1 1
-18M, -18MD2, -18MD4
(HS-5184)
2 2
34 Rail Divider B
(side-to-side)
-8
(HS-5189)
3B0027-01 1 1
-12, -12D2, -12D4
(HS-5189)
2 2
-12M
(HS-5185)
3B0027-03 4 4
(outer side-to-side) -18M -18MD2, -18MD4
(HS-5185)
4 4
35 Rail Divider C
(center side-to-side)
-18M, -18MD2, -18MD4
(HS-5186)
3B0028-03 2 2
36 Catch Tray -8 1A4221-01 1 1
-12, -12D2, -12D4 1A4221-03 1 1
(includes items 37
through 39)
-12M 2A8666A01 1 1
-18M, -18MD2, -18MD4 2A8667A01 1 1
37 Handle 12M 4A4518-01 1 1
-18M, -18MD2, -18MD4 2 2
38 Pan Head Screw -12M 7C12I0838 2 2
-18M, -18MD2, -18MD4 4 4
39 Flat Washer -8, -8D2 7W22-0400 2 2
-12M, -12MD2 7W22-0500 2 2
20
Model Shown: SR60A-24M
17
24
25
27
28
For Cutting Board,
see Section "H"
For Pans, see Section "H"
26
18
23
23a
29
7
Model Shown: UF60A
Undercounter, Worktop, Prep Table
Common Parts
Prep Table
Specic Parts
A. Main Assembly
UR60, WR60, SR60, UF60, and WF60 Undercounter, Worktop, and Prep
Table
G-5 to L-5
For Drawers, see Section "G"
2 3 4
5
28
27
30
18
For Door, see Sections "C, D, E or F"
11
15
12
1
16
For Casters, See
Section "H"
8
9
10
6
13
14
Prep Table
and Freezer
19
21
20
22
30
31 32 33
-8
-12
-16
-18M
-12M
-24M
-24MD2
-24MD4
-12M
-24M
-24MD2
-24MD4
30
21
Title: A. Main Assembly Models: UR60, WR60, SR60, UF60, and WF60 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
J-9
(K)
J-9
(L)
to
L-5
Common Parts
1 Control Module UC/WT Refrigerators 4A5959G02 1 1
UC/WT Freezers 4A5959G04 1 1
Prep Tables 4A5959G03 1 1
2 Cabinet Temperature
Control (Spindle)
UC/WT/Prep Tables 4A5952-01 1 1
3 Adapter Plate 4A5949-01 1 1
4 Dial Plate UC/WT 4A5960-01 1 1
5 Dial Knob UC/WT/Prep Tables 4A5950-01 1 1
6 Cabinet Thermometer 461083-01 1 1
7 Side and Front
Pilaster
4A5719-01 6 6
Door/Drawer 4 4
8 Rear Pilaster 4A5417-01 2 2
9 Shelf 3A2830-09 2 2
Door/Drawer 1 1
10 Shelf Clip 4A5418-01 8 8
Door/Drawer 4 4
11 Bumpers 3A6696-01 2 2
12 Condensate Pan UC/WT Freezers/
Prep Tables
1A3373-01 1 1
13 Elbow Socket 4A5624-01 1 1
14 Hose 4A0658L01 1 1
15 Power Cord 4A5718-01 1 1
16 Rear Panel Refrigerators 1A2542-01 1 1
UC/WT Freezers/
Prep Tables
1A5751-01 1 1
22
Title: A. Main Assembly Models: UR60, WR60, SR60, UF60, and WF60 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
J-9
(K)
J-9
(L)
to
L-5
Prep Table Specic Parts
17 Rail Hood -8 3A9404A01 1 1
-12M 3A9403A01 1 1
-12 3A9394A01 1 1
-18M 3A9395A01 1 1
-16 3A9396A01 1 1
-24M, -24MD2, -24MD4 3A9403A01 2 2
18 Rail Cover
(includes items 19
through 23a)
-8 3A9405A01 1 1
-12 3A9398A01 1 1
-12M 3A9402A01 1 1
-16 3A9400A01 1 1
-18M 3A9399A01 1 1
-24M, -24MD2, -24MD4 3A9402A01 2 2
19 Pivot Pin -8, -12, -12M, -16,
-18M
4A6161-01 2 2
-24M, -24MD2, -24MD4 4 4
20 Pivot Bolt -8, -12, -12M, -16,
-18M
4A6160-01 2 2
-24M, -24MD2, -24MD4 4 4
21 Flat Washer -8, -12, -12M, -16,
-18M
7W22I0832 2 2
-24M, -24MD2, -24MD4 4 4
22 Tree Clip -8, -12, -12M, -16,
-18M
4A0579-01 2 2
24M, -24MD2, -24MD4 3 3
23 Handle -8, -12, -12M, -16,
-18M
1A3416-01 1 1
-24M, -24MD2, -24MD4 2 2
23a Pan Head Screw -8, -12, -12M, -16,
-18M
7C12I1412 2 2
-24M, -24MD2, -24MD4 4 4
24 Right Cutting Board
Bracket
-8, -12, -16,
-12M, -18M, -24M,
-24MD2, -24MD4
3A8971-02 1 1
25 Left Cutting Board
Bracket
-8, -12, -16,
-12M, -18M, -24M,
-24MD2, -24MD4
3A8971-01 1 1
26 Center Cutting Board
Bracket
-8, -12, -16 4A5905-01 3 3
-12M, -18M, -24M,
-24MD2, -24MD4
4A6794-01 5 3
23
Title: A. Main Assembly Models: UR60, WR60, SR60, UF60, and WF60 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
J-9
(K)
J-9
(L)
to
L-5
27 Rail Divider
(front-to-back)
-8
(HS-5188)
3A8904-01 1 1
-12
(HS-5188)
2 2
-16
(HS-5188)
3 3
-12M
(HS-5184)
3A8855-01 1 1
-18M, -24M, -24MD2,
-24MD4
(HS-5184)
2 2
28 Rail Divider
(side-to-side)
-8
(HS-5189)
3B0027-01 2 2
(outer side-to-side) -12
(HS-5189)
2 2
-16
(HS-5189)
2 2
(side-to-side) -12M
(HS-5185)
3B0027-03 4 4
(outer side-to-side) -18M
(HS-5185)
4 4
(side-to-side) -24M, -24MD2, -24MD4
(HS-5185)
8 8
29 Rail Divider C
(center side to side)
-12
(HS-5190)
3B0028-01 1 1
-16
(HS-5190)
2 2
-18M
(HS-5186)
3B0028-03 2 2
30 Catch Tray -8 1A4221-01 1 1
-12 1A4221-03 1 1
-16 1A4221-01 2 2
(includes items 31
through 33)
-12M, -24M, -24MD2,
-24MD4
2A8666A01 2 2
-18M 2A8667A01 1 1
31 Handle 4A4518-01 2 2
32 Pan Head Screw 7C12I0838 4 4
33 Flat Washer 7W22-0500 4 4
24
A. Main Assembly
UR72, WR72, and SR72 Undercounter, Worktop, and Prep Table
G-5 to L-5
Model Shown: SR72A-30M
17
24
25
27
28
For Cutting Board,
see Section "H"
For Pans, see Section "H"
26
Undercounter, Worktop, Prep Table
Common Parts
Prep Table
Specic Parts
For Drawers, see Section "G"
23 23a
18
29
For Door, see Sections "C, D, E or F"
19
20
22
21
30
18
10
6
7
7
8 9
2 3 4 5
11
12
13
14
1
For Casters, See
Section "H"
Condensate Pan
for SR72A Series
15 16
Prep Table
and Freezer
30
31 32 33
-12
-18
-18M
-30M
-30MD2
-30MD4
-30MD6
-24M, -30M
-30MD2, -30MD4
-30MD6
-16
-18
30
25
Title: A. Main Assembly Models: UR72, WR72, and SR72 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
J-9
(K)
J-9
(L)
to
L-5
Common Parts
1 Control Module UC/WT 4A5959G02 1 1
Prep Table 4A5959G03 1 1
2 Cabinet Temperature
Control (Spindle)
UC/WT/Prep Table 4A5952-01 1 1
3 Adapter Plate UC/WT/Prep Table 4A5949-01 1 1
4 Dial Plate 4A5960-01 1 1
5 Dial Knob UC/WT/Prep Table 4A5950-01 1 1
6 Rear Pilaster 4A5417-01 4 4
-30MD2 2 2
7 Side and Front Pilaster 4A5719-01 8 8
-30MD2 6 6
-30MD4 4 4
8 Shelf 3A2830-07 3 3
-30MD2 2 2
-30MD4 3A2830-08 1 1
9 Shelf Clip 4A5418-01 12 12
-30MD2 8 8
-30MD4 4 4
10 Cabinet Thermometer 461083-01 1 1
11 Bumpers 3A6696-01 2 2
12 Power Cord 4A5718-01 1 1
13 Rear Panel UC/WT 1A2525-01 1 1
Prep Tables 1A2668-01 1 1
14 Condensate Pan UC/WT 3A9478-01 1 1
Prep Table 1A3373-01 1 1
15 Elbow Socket 4A5624-01 1 1
16 Hose 4A0658L01 1 1
26
Title: A. Main Assembly Models: UR72, WR72, and SR72 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
J-9
(K)
J-9
(L)
to
L-5
Prep Table Specic Parts
17 Rail Hood -12 3A9394A01 1 1
-18M 3A9395A01 1 1
-16 3A9396A01 1 1
-18 3A9397A01 1 1
-24M 3A9403A01 2 2
-30M, -30MD2,
-30MD4, -30MD6
(Right)
3A9403A01 1 1
-30M, -30MD2,
-30MD4, -30MD6
(Left)
3A9395A01 1 1
18 Rail Cover
(includes items 19
through 23a)
-12 3A9398A01 1 1
-16 3A9400A01 1 1
-18 3A9401A01 1 1
-18M 3A9399A01 1 1
-24M 3A9402A01 2 2
-30M, -30MD2,
-30MD4, -30MD6
(Right)
3A9402A01 1 1
-30M, -30MD2,
-30MD4, -30MD6
(Left)
3A9399A01 1 1
19 Pivot Pin -12, -16, -18, -18M 4A6161-01 2 2
-24M, -30M,
-30MD2, -30MD4,
-30MD6
4 4
20 Pivot Bolt -12, -16, -18, -18M 4A6160-01 2 2
-24M, -30M,
-30MD2, -30MD4,
-30MD6
4 4
21 Flat Washer -12, -16, -18, -18M 7W22I0832 2 2
-24M, -30M,
-30MD2, -30MD4,
-30MD6
4 4
22 Tree Clip -12, -16, -18, -18M 4A0579-01 2 2
-24M, -30M,
-30MD2, -30MD4,
-30MD6
4 4
23 Handle -12, -16, -18, -18M 1A3416-01 1 1
-24M, -30M,
-30MD2, -30MD4,
-30MD6
2 2
23a Pan Head Screws -12, -16, -18, -18M 7C12I1412 2 2
-24M, -30M,
-30MD2, -30MD4,
-30MD6
4 4
24 Right Cutting Board
Bracket
3A8971-02 1 1
25 Left Cutting Board
Bracket
3A8971-01 1 1
27
Title: A. Main Assembly Models: UR72, WR72, and SR72 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
J-9
(K)
J-9
(L)
to
L-5
26 Center Cutting Board
Bracket
-12, -16, -18 4A5905-01 3 3
-18M, -24M, -30M,
-30MD2, -30MD4,
-30MD6
4A6794-01 5 4
27 Rail Divider
(front-to-back)
-12, -18
(HS-5188)
3A8904-01 2 2
-16
(HS-5188)
3 3
-18M, -24M
(HS-5184)
3A8855-01 2 2
-30M, -30MD2,
-30MD4, -30MD6
(HS-5184)
3 3
28 Rail Divider
(side-to-side)
-12
(HS-5189)
3B0027-01 2 2
(outer side to side) -16
(HS-5189)
2 2
-18
(HS-5191)
3B0027-02 2 2
(outer side to side) -18M
(HS-5185)
3B0027-03 4 4
(side-to-side) -24M
(HS-5185)
8 8
(outer side to side) -30M, -30MD2,
-30MD4, -30MD6
(HS-5185)
8 8
29 Rail Divider C
(center side-to-side)
-12
(HS-5190)
3B0028-01 1 1
-16
(HS-5190)
2 2
-18
(HS-5192)
3B0028-02 1 1
-18M, -30M,
-30MD2, -30MD4,
-30MD6
(HS-5186)
3B0028-03 2 2
30 Catch Tray -12 1A4221-03 1 1
-16 1A4221-01 2 2
-18 1A4221-02 1 1
1A4221-03 1 1
-18M 2A8667A01 1 1
-24M 2A8666A01 2 2
-30M, -30MD2,
-30MD4, -30MD6
2A8666A01 1 1
2A8667A01 1 1
31 Handle 2A8666A01 4A4518-01 1 1
2A8667A01 2 2
32 Pan Head Screw 2A8666A01 7C12I0838 2 2
2A8667A01 4 4
33 Flat Washer 2A8666A01 7W22-0500 2 2
2A8667A01 4 4
28
B. Refrigeration Circuit
UR27, WR27, and SR27 Undercounter, Worktop, and Prep Table
G-5 to L-5
6 7
3
2
1
4
9
11
12
For compressor or condenser replacement, order item 1.
8
13
16
14
10
15
5
17
5
29
Title: B. Refrigeration Circuit Models: UR27, WR27, and SR27 Undercounter, Worktop, Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
H-5
H-6
to
L-5
1 Condensing Unit
(includes compressor,
condenser, and items
2 through 8; compressor
and condenser are not sold
individually)
UC/WT 3A9520-01 1 1
Prep Table 3A9316-01 1 1
2 Condenser Fan Motor 3A6798-01 1 1
3 Condenser Fan Blade 3A6799-01 1 1
4 Condensate Pan UC/WT 3A6758-01 1 1
Prep Table 3A9478-01 1 1
5 Drain Cup UC/WT 3A9702-01 1 1
Duct Bill Prep Tables SP-5345 1 -
Drain Cup 3A9702-01 1
6 Compressor External
Protector
UC/WT 3A9522-01 1 1
Prep Table 3A9475-01 1 1
7 Start Relay UC/WT 3A9523-01 1 1
Prep Table 3A9476-01 1 1
8 Start Capacitor UC/WT
145-175MFD, 250VAC
3A9524-01 1 1
Run Capacitor Prep Table
12MFD, 250VAC
3A9477-01 1 1
9 Drier 4A5576-01 1 1
10 Cabinet Thermistor UC/WT/Prep Tables 4A4864-01 1 1
11 Evaporator 2A8513-01 1 1
12 Evaporator Fan Motor 4A5343-01 1 1
13 Capillary Tube Replacement
Kit
L=2438mm SP-5437 1 1
14 Defrost Thermistor Prep Table 4A4865-01 1 1
15 Defrost Heater Prep Table 3A6443-05 1 1
16 Defrost Safety Thermostat Prep Table 4A5853-01 1 1
17 High-Pressure Switch 4A6039-01 1 1
30
B. Refrigeration Circuit
UF27 and WF27 Undercounter and Worktop
G-5 to L-5
6 7
3
2
1
4
11
12
15
For compressor or condenser replacement, order item 1.
9
8
13
17
16
14
10
5
31
Title: B. Refrigeration Circuit Models: UF27 and WF27 Undercounter and Worktop
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
1 Condensing Unit
(includes compressor,
condenser, and items
2 through 7; compressor
and condenser are not sold
individually)
3A9316-01 1
2 Condenser Fan Motor 3A6798-01 1
3 Condenser Fan Blade 3A6799-01 1
4 Condensate Pan 3A9478-01 1
5 Drain Cup 3A9702-01 1
6 Compressor External
Protector
3A9475-01 1
7 Start Relay 3A9476-01 1
8 Run Capacitor UC/WT
12MFD, 250VAC
3A9477-01
9 Drier 4A5576-01 1
10 Cabinet Thermistor 4A4864-01 1
11 Evaporator 2A8513-01 1
12 Evaporator Fan Motor 4A5343-01 1
13 Capillary Tube Replacement
Kit
L=1499mm SP-5436 1
14 Defrost Thermistor 4A4865-01 1
15 Defrost Heater 3A6443-05 1
16 Defrost Safety Thermostat 4A0954-02 1
17 High-Pressure Switch 4A6039-01 1
32
B. Refrigeration Circuit
UR36, WR36, and SR36 Undercounter, Worktop, and Prep Table
G-5 to L-5
6 7
3
2
1
4
9
11
12
8
13
15
16
10
For compressor or condenser replacement, order item 1.
17
5
14
33
Title: B. Refrigeration Circuit Models: UR36, WR36, SR36 Undercounter, Worktop, Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
1 Condensing Unit
(includes compressor,
condenser, and items
2 through 8; compressor
and condenser are not sold
individually)
UC/WT/Prep Table 3A9520-01 1
2 Condenser Fan Motor 3A6798-01 1
3 Condenser Fan Blade 3A6799-01 1
4 Condensate Pan 3A6758-01 1
5 Drain Cup 3A9702-01 1
6 Compressor External
Protector
3A9522-01 1
7 Start Relay 3A9523-01 1
8 Start Capacitor 145-175MFD,
250VAC
3A9524-01 1
9 Drier 4A5576-01 1
10 Cabinet Thermistor 4A4864-01 1
11 Evaporator 2A8513-01 1
12 Evaporator Fan Motor 4A5343-01 1
13 Capillary Tube (includes:
capillary tube, drier, cover,
insulation)
L=2438mm SP-5438 1
14 Defrost Thermistor Prep Table 4A4865-01 1
15 Defrost Heater Prep Table 3A6443-05 1
16 Defrost Safety Thermostat
(thermodisc)
Prep Table 4A5853-01 1
17 High-Pressure Switch 4A6039-01 1
34
B. Refrigeration Circuit
UR48, WR48, and SR48 Undercounter, Worktop, and Prep Table
G-5 to L-5
86 7
3
2
1
11
12
For compressor or condenser replacement, order item 1.
9
13
15
14
10
16
5
17
4
All UC/WT Refrigerator
For Prep Table
Condensate Pan,
see Section "A"
35
Title: B. Refrigeration Circuit Models: UR48, WR48, and SR48 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
1 Condensing Unit
(includes compressor,
condenser, and items
2 through 8; compressor
and condenser are not
sold individually)
UC/WT 3A9520-01 1
Prep Table 3A9316-01 1
2 Condenser Fan Motor 3A6798-01 1
3 Condenser Fan Blade 3A6799-01 1
4 Condensate Pan UC/WT 3A6758-01 1
5 Drain Cup Refrigerators 3A9702-01 1
6 Compressor External
Protector
UC/WT 3A9522-01 1
Prep Table 3A9475-01 1
7 Start Relay UC/WT 3A9523-01 1
Prep Table 3A9476-01 1
8 Start Capacitor UC/WT
145-175MFD,
250VAC
3A9524-01 1
Run Capacitor Prep Table
12MFD, 250VAC
3A9477-01 1
9 Drier 4A5576-01 1
10 Cabinet Thermistor 4A4864-01 1
11 Evaporator 2A8513-02 1
12 Evaporator Fan Motor 4A5343-01 2
13 Capillary Tube
Replacement Kit
UC/WT
L=2684mm
SP-5437 1
Prep Table
L=3584mm
SP-5438 1
14 Defrost Thermistor Prep Table 4A4865-01 1
15 Defrost Heater Prep Table 3A6443-04 1
16 Defrost Safety Thermostat Prep Table 4A5853-01 1
17 High-Pressure Switch 4A6039-01 1
36
For compressor or condenser replacement, order item 1.
B. Refrigeration Circuit
UF48 and WF48 Undercounter and Worktop
G-5 to L-5
1
2
3
9
15
7
7
6
4 5
11
14
8
12
For Freezer and Worktop
Table Condensate Pan,
see Section "A"
10
13
37
Title: B. Refrigeration Circuit Models: UF48 and WF48 Undercounter and Worktop
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
1 Condensing Unit
(includes compressor,
condenser, and items 2 through
6; compressor and condenser
are not sold individually)
3A9313-01 1
2 Condenser Fan Motor 3A6798-01 1
3 Condenser Fan Blade 3A6799-01 1
4 Compressor External Protector 3A6936-01 1
5 Start Relay 3A6937-01 1
6 Start Capacitor 378-454MFD,
115 VAC
3A6938-01 1
7 Drier 4A5576-01 1
8 Cabinet Thermistor 4A4864-01 1
9 Evaporator 2A8513-02 1
10 Evaporator Fan Motor 4A5343-01 2
11 Capillary Tube
Replacement Kit
L=1829mm SP-5435 1
12 Defrost Thermistor 4A4865-01 1
13 Defrost Heater 3A6443-04 1
14 Defrost Safety Thermostat 4A5853-01 1
15 High-Pressure Switch 4A6039-01 1
38
8
4
All UC/WT Refrigerator
ForPrep Table
Condensate Pan,
see Section"A"
17
B. Refrigeration Circuit
UR60, WR60, and SR60 Undercounter, Worktop, and Prep Table
G-5 to L-5
11
12
3
1
6 7
2
For compressor or condenser replacement, order item 1.
9
13
16
14
10
SR60
Prep Table
15
5
5
39
Title: B. Refrigeration Circuit Models: UR60, WR60, and SR60 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
H-5
(K)
H-5
(L)
to
L-5
1 Condensing Unit
(includes compressor,
condenser, and items
2 through 8; compressor
and condenser are not
sold individually)
UC/WT 3A9316-01 1 1
Prep Table 3A9313-01 1 1
2 Condenser Fan Motor 3A6798-01 1 1
3 Condenser Fan Blade 3A6799-01 1 1
4 Condensate Pan UC/WT 3A9478-01 1 1
5 Duct Bill UC/WT SP-5345 1 -
Drain Cup 3A9702-01 1
6 Compressor External
Protector
UC/WT 3A9475-01 1 1
Prep Table 3A6936-01 1 1
7 Start Relay UC/WT 3A9476-01 1 1
Prep Table 3A6937-01 1 1
8 Run Capacitor UC/WT
12MFD, 250VAC
3A9477-01 1 1
Start Capacitor Prep Table
378-454MFD,
115 VAC
3A6938-01 1 1
9 Drier 4A5576-01 1 1
10 Cabinet Thermistor UC/WT/Prep Table 4A4864-02 1 1
11 Evaporator 2A8513-03 1 1
12 Evaporator Fan Motor 4A5343-01 2 2
13 Capillary Tube
Replacement Kit
UC/WT/Prep Table
L=2184mm
SP-5434 1 1
14 Defrost Thermistor Prep Table 4A4865-02 1 1
15 Defrost Heater Prep Table 3A6443-06 1 1
16 Defrost Thermostat Prep Table 4A5853-01 1 1
17 High-Pressure Switch Prep Table 4A6039-01 1 1
40
B. Refrigeration Circuit
UF60 and WF60 Undercounter and Worktop
G-5 to L-5
For compressor or condenser replacement, order item 1.
1
2
3
4 5
6
7
8
9
10
11
14
12
13
15
For Freezer
Condensate Pan,
see Section "A"
41
Title: B. Refrigeration Circuit Models: UF60 and WF60 Undercounter and Worktop
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
1 Condensing Unit
(includes compressor,
condenser, and items 2 through
6; compressor and condenser
are not sold individually)
3A9313-01 1
2 Condenser Fan Motor 3A6798-01 1
3 Condenser Fan Blade 3A6799-01 1
4 Compressor External Protector 3A6936-01 1
5 Start Relay 3A6937-01 1
6 Start Capacitor 378-454MFD,
115 VAC
3A6938-01 1
7 Drier 4A5576-01 1
8 Cabinet Thermistor 4A4864-02 1
9 Evaporator 2A8513-03 1
10 Evaporator Fan Motor 4A5343-01 2
11 Defrost Heater 3A6443-06 1
12 Defrost Thermostat 4A5853-01 1
13 Capillary Tube
Replacement Kit
L=1829mm SP-5435 1
14 Defrost Thermistor 4A4865-02 1
15 High-Pressure Switch 4A6039-01 1
42
B. Refrigeration Circuit
UR72, WR72, and SR72 Undercounter, Worktop, Prep Table
G-5 to L-5
10
11
3
1
5 6
7
2
4
For compressor or condenser replacement, order item 1.
UR72 and WR72
Undercounter/Worktop
For Prep Table
Condensate Pan,
see Section "A"
16
8
13
SR72
Prep Table
15
9
12
14
43
Title: B. Refrigeration Circuit Models: UR72, WR72, and SR72 Undercounter, Worktop, and Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
1 Condensing Unit
(includes compressor,
condenser, and items 2
through 7; compressor and
condenser are not sold
individually)
UC/WT 3A9316-01 1
Prep Table 3A9313-01 1
2 Condenser Fan Motor 3A6798-01 1
3 Condenser Fan Blade 3A6799-01 1
4 Condensate Pan UC/WT 3A9478-01 1
5 Compressor External
Protector
UC/WT 3A9475-01 1
Prep Table 3A6936-01 1
6 Start Relay UC/WT 3A9476-01 1
Prep Table 3A6937-01 1
7 Run Capacitor UC/WT
12MFD, 250VAC
3A9477-01 1
Start Capacitor Prep Table
378-454MFD,
115 VAC
3A6938-01 1
8 Drier 4A5576-01 1
9 Cabinet Thermistor UC/WT/Prep Table 4A4864-02 1
10 Evaporator 2A8513-04 1
11 Evaporator Fan Motor 4A5343-01 3
12 Capillary Tube
Replacement Kit
UC/WT
L=3584mm
SP-5437 1
Prep Table
L=2184mm
SP-5434 1
13 Defrost Thermister Prep Table 4A4865-02 1
14 Defrost Heater Prep Table 3A6443-07 1
15 Defrost Safety Thermostat Prep Table 4A5853-01 1
16 High-Pressure Switch Prep Table 4A6039-01 1
44
C. Door-Right Hinged
Undercounter, Worktop, Prep Table
G-5 to L-5
3
6
7
8
9
1a1
5
2a2
11
10
4 4a
12
12
Lock is present on -01 models
13
13a
45
Title: C. Door-Right Hinged Models: Undercounter, Worktop, Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
1 Lower Hinge Bracket 3A6681G01 1
1a Hex Head Tapping Bolt 1/4-20×3/4 4A5213-01 2
2 Upper Hinge Bracket 3A6810-01 1
2a Truss Head Screw 5×12, SS 7C32-0512 2
3 Door Assembly
without Locks
(includes items 4 through
12)
_R27A and _F27A,
(All except -01,
-LPW, and -GLP)
2A7322G01 1
UR27A-LPW 2A8635G01 1
_R36A, _R60A and
_F60A
UC/WT/Prep Table
(All except -01)
2A7328G01 1
_R48A, _F48A, and
_R72A
UC/WT/Prep Table
(All except -01)
2A7324G01 1
Door Assembly
with Locks
(includes items 4through
12)
_R27A-01 and
_F27A-01
2A7323G01 1
_R36A-01,
_R60A-01, and
_F60A-01
2A8291G01 1
_R48A-01,
_F48A-01 and
_R72A-01
2A7327G01 1
4 Hinge Spring Cartridge
(includes items 5 through
9)
3A9206-01 1
4a Countersunk Screw 5×20, SS 7C42-0520 2
5 Thrust Washer 4A5234-01 1
6 Screw 4A5230-01 1
7 Lockwasher 4A5231-01 1
8 Thrust Washer 4A5233-01 2
9 Bearing 4A5232-01 1
10 Truss Head Screw
(ller screws)
5×10, SS 7C32-0510 2
11 Gasket _R27A and _F27A,
UC/WT/Prep Table
2A6996-05 1
_R36A, _R60A,
and _F60A
UC/WT/Prep Table
2A6996-09 1
_R48A, _F48A, and
_R72A
UC/WT/Prep Table
2A6996-06 1
12 End Cap 4A5432-01 2
13 Strike Plate for Doors with
Locks
-01 UC/WT 4A5493-01 1
13a T2 Screw -01 UC/WT
4×8, SS
7P32-0408 2
46
D. Door-Left Hinged
Undercounter, Worktop, Prep Table
G-5 to L-5
Lock is present on -01 models
3
5
6
7
8
9
10
13 13a
2 2a
11
1 1a
12
4 4a
12
47
Title: D. Door-Left Hinged Models: Undercounter, Worktop, Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
1 Lower Hinge Bracket 3A6681G01 1
1a Hex Head Tapping Bolt 1/4-20×3/4 4A5213-01 2
2 Upper Hinge Bracket 3A6810-01 1
2a Truss Head Screw 5×12, SS 7C32-0512 2
3 Door Assembly
without Locks
(includes items 4 through
12)
_R48A, _F48A,
and _R72A
UC/WT/Prep Table
(All except -01)
2A7325G01 1
_R60 and _F60A
UC/WT/Prep Table
(All except -01)
2A7329G01 1
Door Assembly
with Locks
(includes items 4through
12)
_R60A-01 and
_F60A-01
2A8293G01 1
_R48A-01,
_F48A-01, and
_R72A-01
2A7326G01 1
4 Hinge Spring Cartridge
(includes items 5 through
9)
3A9206-01 1
4a Countersunk Screw 5×20, SS 7C42-0520 2
5 Thrust Washer 4A5234-01 1
6 Screw 4A5230-01 1
7 Lockwasher 4A5231-01 1
8 Thrust Washer 4A5233-01 2
9 Bearing 4A5232-01 1
10 Truss Head Screw
(ller screws)
5×10, SS 7C32-0510 2
11 Gasket _R48A, _F48A,
and _R72A
UC/WT/Prep Table
2A6996-06 1
_F60A
UC/WT/Prep Table
2A6996-09 1
12 End Cap 4A5432-01 2
13 Strike Plate for Doors with
Locks
-01 UC/WT 4A5493-01 1
13a T2 Screw -01 UC/WT
4×8, SS
7P32-0408 2
48
E. Door-Right Glass Door Hinged
Undercounter, Worktop, Prep Table
G-5 to L-5
Title: E. Door-Right Glass Door Hinged Models: Undercounter, Worktop, Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
1 Door
(includes gasket and
hinge arm)
UR27A-GLP01 2A8853-03 1
UF27A-GLP01 2A8853-04 1
UR48A-GLP01
Right Side
Hinged Door
2A8852-03 1
2 Gasket U_27A-GLP01 4A6448-01 1
UR48A-GLP01 4A6449-01 1
3 Upper Hinge 3A9346-02 1
3a Truss Head Screw 5×12, SS 7C32-0512 2
4 Hinge Pin 3A7946-04 1
5 Hinge Pin Locknut 3A7946-05 1
6 Hinge Arm 3A7946-01 1
7 Lower Hinge 3A9342-01 1
7a Hex Head Tapping Bolt 1/4-20×3/4 4A5213-01 2
8 Backer Plate 3A7946-08 1
9 Slide Pin 3A7946-11 1
10 Hinge Bushing 3A7946-09 1
11 Nylon Washer 3A7946-10 1
5
2
3a
4
1
3
9
8
10
7
7a
11
6
Model Shown: UR48A-GLP01
49
F. Door-Left Glass Door Hinged
Undercounter, Worktop, Prep Table
G-5 to L-5
Title: F. Door-Left Glass Door Hinged Models: Undercounter, Worktop, Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
1 Door
(includes gasket and
hinge arm)
UR48A-GLP01
Left Side
Hinged Door
2A8852-01 1
2 Gasket UR48A-GLP01 4A6449-01 1
3 Upper Hinge 3A9346-01 1
3a Truss Head Screw 5×12, SS 7C32-0512 2
4 Hinge Pin 3A7946-04 1
5 Hinge Pin Locknut 3A7946-05 1
6 Hinge Arm 3A7946-01 1
7 Lower Hinge 3A9342-02 1
7a Hex Head Tapping Bolt 1/4-20×3/4 4A5213-01 2
8 Backer Plate 3A7946-08 1
9 Slide Pin 3A7946-11 1
10 Hinge Bushing 3A7946-09 1
11 Nylon Washer 3A7946-10 1
5
3a
4
1
3
9
8
10
7
7a
11
6
2
Model Shown: UR48A-GLP01
50
G. Drawer
Undercounter, Worktop, Prep Table (-D)(-D2)(-D4)(-D6)
G-5 to L-5
1
6
7
3
8
2
5
4
9
51
Title: G. Drawer Models: Undercounter, Worktop, Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
J-5(B)
J-5(C)
to
L-5
1 Drawer Face _R27A-xx(M(D2)),
and _F27A-D2
UC/WT/Prep Table
2A7510G01 2 2
_R48A-xx(M(Dx)),
_F48A-D4, and
_R72A-xx(M(Dx))
UC/WT/Prep Table
2A7511G01 2 2
_R60A-xx(M(Dx))
UC/WT/Prep Table
2A7512G01 2 2
2 Upper Drawer Box _R27A-xx(M(D2)),
and _F27A-D2
UC/WT/Prep Table
3A9501G01 1 1
_R48A-xx(M(Dx)),
_F48A-D4, and
_R72A-xx(M(Dx))
UC/WT/Prep Table
3A9500G01 1 1
_R60A-xx(M(Dx))
UC/WT/Prep Table
3A9502G01 1 1
3 Lower Drawer Box _R27A-xx(M(D2)),
and _F27A-D2
UC/WT/Prep Table
3A8185G01 1 1
_R48A-xx(M(Dx)),
_F48A-D4, and
_R72A-xx(M(Dx))
UC/WT/Prep Table
3A8191G01 1 1
_R60A-xx(M(Dx))
UC/WT/Prep Table
3A8294G01 1 1
4 Upper Right Slide Roller 4A6146-02 1 1
5 Upper Left Slide Roller 4A6147-02 1 1
6 Lower Right Slide Roller 4A5663-02 1 1
7 Lower Left Slide Roller 4A5664-02 1 1
8 Gasket _R27A-xx(M(D2)),
and _F27A-D2
UC/WT/Prep Table
2A5192-15 2 2
_R48A-xx(M(Dx)),
_F48A-D4, and
_R72A-xx(M(Dx))
UC/WT/Prep Table
2A5192-17 2 2
_R60A-xx(M(Dx))
UC/WT/Prep Table
2A5192-16 2 2
9 Upper Drawer Divider _R27A-xx(M(D2)),
_F27A-D2, and
_R60A-xx(M(Dx))
UC/WT/Prep Table
3A9645-01 1
_R48A-xx(M(Dx)),
_F48A-D4, and
_R72A-xx(M(Dx))
UC/WT/Prep Table
3A9645-02 1
52
H. Accessories & Labels
Undercounter, Worktop, Prep Table
G-5 to L-5
1
1
53
Title: H. Accessories & Labels Models: Undercounter, Worktop, Prep Table
Index
No. Description
Material or
Model Number Part Number
Required Number
G-5
to
L-5
1 Penguin Label 475552L01 1
2 4" Caster Kit
(includes items 3 and 4)
HS-5035
UC
4A5434A01 1
2" Caster Kit
(includes items 3, 4, and
4a)
HS-5037
UC Low Prole
4A5436A01 1
6" Caster Kit
(includes items 3 and 4)
HS-5036
WT/Prep Table
4A5435A01 1
3 4" Non-Locking Caster UC 4A5427-01 2
2" Non-Locking Caster UC Low Prole 4A5429-01 2
6" Non-Locking Caster WT/Prep Table 4A5428-01 2
4 4" Locking Caster UC 4A5427-02 2
2" Locking Caster UC Low Prole 4A5429-02 2
6" Locking Caster WT/Prep Table 4A5428-02 2
4a Wrench UC Low Prole 4A5492-01 1
4b Caster Bracket _R48A-(xxxxx) and
_F48A-(xxxxx)
UC/WT/Prep Table
3A9099-01 2
Prep Table Specic Parts
5 1/6 Size Pan, 4" Depth -8 1000000344 8
-10 10
-16 16
-15M 15
-12, -12M, -12D(x) 12
-18, -18M, 18MD(x) 18
-24M, -24MD2 24
-30M, -30MD(x) 30
6 Cutting Board SR27A-8(Dx) and
SR27A-12(M(Dx))
3A4894-09 1
SR36A-10(-15M) 3A4894-15 1
SR48A-xx(M(Dx)) 3A4894-10 1
SR60A-xx(M(Dx)) 3A4894-13 1
SR72A-xx(M(Dx)) 3A4894-14 1
