EN
DETAILED
INSTRUCTIONS FOR USE
OF REFRIGERATOR-
FREEZER
www.gorenje.comwww.gorenje.com
2
573319
We thank you for the confidence you have shown by purchasing
our appliance which is designed to simplify your life. To make the use of the
product easier, we have supplied detailed instructions for use, and installation
instructions supplied on a separate sheet. The instructions should allow you to
learn about your new appliance as quickly as possible.
We wish you find a lot of pleasure in its use.
The appliance is intended solely for household use.
The lower part is the refrigerator compartment intended for storing fresh food
at temperatures above 0°C.
The upper part is the freezer compartment intended for freezing fresh food
and long-term storage of frozen food (up to one year, depending on the type of
food). This compartment is labeled with four stars / asterisks.
Please visit our website where you can enter your appliance model number, indicated
on the rating plate or the warranty sheet, to find detailed description of your
appliance, tips on use, troubleshooting, service information, instructions for use etc.
http://www.gorenje.com
Important safety warning
General information and tips
i
Protecting the environment
!
Do not wash in the dishwasher
Link to the EU EPREL database
The QR code on the energy label supplied with the appliance provides a web
link to the registration of this appliance in the EU EPREL database. Keep
the energy label for reference together with the user manual and all other
documents provided with this appliance.
It is possible to find information related to the performance of the product
in the EU EPREL database using the link https://eprel.ec.europa.eu and the
model name and product number that you can find on the rating plate of the
appliance.
For more detailed information about the energy label, visit www.theenergylabel.eu.
3
CONTENTS
573319
INTRODUCTION
APPLIANCE
DESCRIPTION
DEFROSTING
AND CLEANING
THE APPLIANCE
4 IMPORTANT NOTES AND PRECAUTIONS
4 BEFORE USING THE APPLIANCE FOR THE FIRST TIME
5 IMPORTANT SAFETY INSTRUCTIONS
8 IMPORTANT INFORMATION ON THE USE OF APPLIANCE
9 ENVIRONMENT PROTECTION
10 ADVICE FOR SAVING POWER WITH REFRIGERATION
APPLIANCES
11 INSTALLATION AND CONNECTION
13 APPLIANCE DESCRIPTION
14 OPERATING THE APPLIANCE
19 APPLIANCE INTERIOR EQUIPMENT
23 RECOMMENDED DISTRIBUTION OF FOOD IN THE
APPLIANCE
24 STORING FOOD IN THE REFRIGERATOR
28 STORING FOOD IN THE FreshZone DRAWER
29 FREEZING AND STORING FROZEN FOOD
29 Freezing procedure
29 Important warnings on freezing
30 Storing industrially frozen food
30 Frozen food storage time
30 Defrosting frozen food
31 DEFROSTING THE APPLIANCE
32 CLEANING THE APPLIANCE
33 TROUBLESHOOTING
35 INFORMATION ABOUT APPLIANCE NOISE
MISCELLANEOUS
STORING AND
FREEZING FOOD
4
IMPORTANT NOTES AND
PRECAUTIONS
Before connecting the appliance to the power mains,
please read carefully the instructions for use which
describe the appliance and its correct and safe use.
The instructions apply to several appliance types/
models; thus, settings or equipment may be described
herein which is not available in your appliance. We
recommend saving this instruction manual for future
reference and attach it to the appliance if it is sold in
the future.
Check for any damage or irregularities on your
appliance. If you find your appliance is damaged,
notify the retailer from which you have purchased the
appliance.
Before connecting the appliance to the power mains,
let the appliance rest in a vertical position for a
minimum of 2 hours. This will reduce the possibility of
operation faults due to the effect of transport on the
cooling system.
573319
BEFORE USING THE APPLIANCE FOR
THE FIRST TIME
i
5
573319
The appliance must be connected to the power
mains and grounded in compliance with the effective
standards and regulations.
WARNING! Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the appliance.
Before cleaning the appliance, unplug it from the power
mains (unplug the power cord from the wall outlet).
WARNING! If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
WARNING! When positioning the appliance, ensure the
supply cord is not trapped or damaged.
If LED lighting does not work, call a service technician.
Do not attempt a repair of the LED lighting yourself, as
there is danger of contact with high voltage!
IMPORTANT SAFETY INSTRUCTIONS
!
WARNING! Do not use any electric devices inside
the appliance, except for those allowed by the
manufacturer
of this refrigeration appliance.
WARNING! Do not use mechanical devices or other
means to accelerate the defrosting process, other
than those recommended by the manufacturer.
WARNING! To avoid any hazard resulting from poor
stability of the appliance, make sure it is installed as
instructed.
!
!
!
WARNING! Risk of fire/flammable materials.
6
573319
Danger of frostbite
Never put frozen food in your mouth and avoid
touching frozen food as this may cause frostnip or
frostbite.
Safety of children and vulnerable persons
The appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Cleaning and user maintenance shall not be made by
children without supervision.
Remove the packaging intended to protect the
appliance or particular parts during transport and keep
it outside the reach of children.
It presents danger of injury or suffocation.
For European markets only
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.
7
573319
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Children aged from 3 to 8 years are allowed to load
and unload refrigerating appliances.
Warning regarding the refrigerant
The appliance contains a small amount of an
environmentally friendly yet flammable gas R600a.
Make sure that no parts of the cooling system
are damaged. A gas leak is not hazardous to the
environment, but it could cause eye injury or fire.
In case of a gas leak, ventilate the room thoroughly,
disconnect the appliance from the power mains, and
call a service technician.
8
573319
The appliance may not be used outdoors and it may
not be exposed to rain.
Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
If the appliance will be out of use for an extended
period of time, switch it off using the relevant button,
and unplug it from the power mains. Empty the
appliance, defrost it, clean it, and leave the door ajar.
In case of an error or power supply failure, do not
open the freezer compartment unless the freezer has
not operated for over 16 hours. After this period, use
the frozen food or provide sufficient cooling (e.g. a
replacement appliance).
IMPORTANT INFORMATION ON THE USE
OF APPLIANCE
WARNING! Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear
of obstruction.
WARNING! This appliance is intended to be used in
household and similar applications such as:
– staff kitchen areas in shops, offices and other working
environments;
- farm houses and by clients in hotels, motels and other
residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
i
9
573319
The symbol on the product or its packaging indicates that the product
should not be treated as normal household waste. The product should be
taken to an authorized collection centre for waste electric and electronic
equipment processing. Correct disposal of the product will help prevent
any negative effects on the environment and health of people which could
occur in case of incorrect product removal. For detailed information on
removal and processing of the product, please contact the relevant municipal
body in charge of waste management, your waste disposal service, or the
store where you bought the product.
Packaging is made of environmentally friendly materials
that can be recycled, disposed of, or destroyed without
any hazard to the environment.
!
Removing an obsolete appliance
To protect the environment, take the obsolete
appliance to an authorized home appliance collection
centre.
Before doing so, do the following:
• disconnect the appliance from the power mains;
• do not allow children to play with the appliance.
ENVIRONMENT PROTECTION
WARNING! Do not damage the refrigerant circuit.
This will also prevent pollution.
i
Technical information on the appliance
Rating plate can be found in the appliance interior. It
indicates data on voltage, gross and net volume, type
and amount of refrigerant, and information on the climate
classes.
If the language on the rating plate is not the language
of your choice or the language of your country, replace
it with the one supplied.
10
ADVICE FOR SAVING POWER
WITH REFRIGERATION
APPLIANCES
i
573319
• Install the appliance as specified in the instruction manual.
• Do not open the door more often than necessary.
• Occasionally make sure air circulation underneath the appliance is
unobstructed.
• Condenser unit on the rear wall should be kept clean (see chapter Cleaning
the appliance).
• If the gasket is damaged or does not provide a perfect seal for any reason,
have it replaced as soon as possible.
• Store the food in tightly sealed containers or appropriate packaging.
• Before placing the food in the refrigerator, allow it to cool down to room
temperature.
• Defrost frozen food in the refrigerator compartment.
• To make use of the entire freezer compartment interior volume, remove
some of the drawers as described in the instruction manual.
• Defrost your conventional freezer when an approximately 3–5 millimetre
layer of frost or ice has built up on the refrigerated surfaces.
• Make sure the layout of shelves in the compartment is uniform and that
the food is placed so that the air can freely circulate in the appliance
interior (observe the recommended placement of food as described in the
instructions).
• In appliances with a fan, do not block the fan slots or vents.
• If you do not need the fan or the ionizer, switch them off to reduce power
consumption.
11
INSTALLATION AND
CONNECTION
573319
SELECTING THE ROOM
• Install the appliance in a dry and well ventilated room. The appliance will
operate correctly if the environment temperature is in the interval specifi ed in
the table. The appliance class is indicated on the rating plate / label with the
basic information on the appliance.
Description Class Ambient temperature
range °C
Relative humidity
Extended temperate SN +10 to +32
75%
Temperate N +16 to +32
Subtropical ST +16 to +38
Tropical T +16 to +43
• Do not place an appliance in a room where temperature can drop to
below 5 °C as this may cause abnormal appliance operation or failure!
i
• After the installation, the appliance mains plug should be accessible!
• Do not place the appliance near appliances or devices radiating heat, such as
a cooker, a stove, a radiator, water heater etc., and do not expose it to direct
sunlight. The appliance should stand at least 3 cm away from an electric or gas
cooker or at least 30 cm away from an oil or solid fuel stove. If the distance
between such source of heat and the appliance is smaller, use an insulating
panel.
Note: Place the appliance in a su ciently large room. There should be at least
1 m
3
of space per 8 grams of refrigerant. Amount of refrigerant is indicated on
the rating plate in the appliance interior.
• There should be an opening or a vent of at least 200 cm
2
behind the appliance,
and the clearance between the appliance and any cabinet above it should be
at least 5 cm, to allow cooling of the condenser unit.
Note:
When installing the appliance side-by-side into kitchen cabinets, each appliance
should be integrated into a separate cabinet.
An anti-condensation service kit should be purchased, complete with a power
cord for connecting the kit to the power mains. An additional power socket is
required for connecting the anti-condensation service kit.
For safety reasons, the service kit may only be installed by an authorized
service technician!
12
The process of changing the appliance door opening and integrating the
appliance into a cabinet is described on the separate installation instructions
supplied in the bag with the instruction manual.
573319
CONNECTING THE APPLIANCE
• Connect the appliance to the power
mains using the power cord. The wall
outlet should be fi tted with a ground
contact (safety socket). Nominal
voltage and frequency are indicated
on the rating plate/label with basic
information on the appliance.
• The appliance must be connected
to the power mains and grounded
in compliance with the e ective
standards and regulations. The
appliance will withstand short-term
deviations from the nominal voltage,
but not more than +/- 6%.
CHANGING THE DOOR OPENING DIRECTION AND
INTEGRATING THE APPLIANCE INTO A CABINET
13
APPLIANCE DESCRIPTION
573319
A Refrigerator
B Freezer
1 Control unit
2 LED lighting
3 Fan with air ionizer
(+ on/off switch)*
4 Glass shelves
5 Fruit and vegetables
drawer with humidity
control
6 Fruit and vegetables
drawer
7 Low door shelves
8 Bottle shelves
1
5
6
8
7
2
3
B
A
4
Appliance interior equipment may change according to the appliance model.
This product contains a light source of energy e ciency class (F).
* Only in some models
14
A Temperature setting and on/o knob
B Lighting on/o key
Lighting will switch on automatically when you open the door, and switch o
when you close it.
Switching on: To switch on: rotate the
A dial clockwise.
Switching off: Rotate the A dial in
the counter-clockwise direction until
the arrow is aligned with the symbol
(Warning: appliance will remain
powered, i.e. there will still be electric
current in the appliance.)
SWITCHING THE APPLIANCE ON/OFF
B
A
CONTROL UNIT 1
OPERATING THE APPLIANCE
573319
15
ADJUSTING THE TEMPERATURE IN THE APPLIANCE
• To set the desired temperature, rotate
the A dial in clockwise direction.
• Recommended setting of the A dial is
on the eco position (see fi gure).
• A change in the environment
temperature will a ect the
temperature in the appliance. Adjust
the setting with the A dial accordingly.
Positions towards the mean a lower
temperature in the appliance (cooler).
Settings towards the mean a higher
temperature (warmer).
If the temperature of the room where
the appliance is installed is below 16 °C,
we recommend setting the A .
SETTING THE TEMPERATURE INSIDE THE APPLIANCE IN
CASE OF NEED FOR INTENSIVE COOLING OR FREEZING
• Activating the intensive cooling
and freezing: Rotate the »A« dial to
position shown in the fi gure.
• When the dial is set to this position,
the appliance will operate with
maximum power. During this time,
operation may be temporarily louder.
• We recommend using this setting before cleaning the appliance or 24 hours
before inserting a large amount of food. Activating this function will make sure
the food is cooled or frozen faster to retain vitamins, minerals, nutrients, and
fl avour, and to extend its freshness.
• After the end of the intensive cooling/freezing cycle, rotate the »A« dial back
to the desired setting.
573319
• After the appliance is switched on, it may take several hours for the set
temperature to be reached. Do not place any food into the refrigerator
before the temperature drops to the selected setting.
i
16
CONTROL UNIT 2
B
A
A Temperature setting and on/o knob
Use the dial to switch the appliance on or o , set the temperature, and control
the ECO and intensive freezing (freezer boost) function.
B Lighting on/o key
Lighting will switch on automatically when you open the refrigerator
compartment door, and it will switch o when you close it.
Switching on: To switch on: rotate the
A dial clockwise.
Switching off: Rotate the A dial in
the counter-clockwise direction until
the arrow is aligned with the symbol
(Warning: appliance will remain
powered, i.e. there will still be electric
current in the appliance.)
SWITCHING THE APPLIANCE ON/OFF
573319
17
ADJUSTING THE TEMPERATURE IN THE APPLIANCE
• To set the desired temperature,
rotate the A dial in clockwise
direction.
• Recommended setting of the A dial
is on the eco position (see fi gure).
• A change in the environment
temperature will a ect the
temperature in the appliance.
Adjust the setting with the A dial
accordingly. Positions towards the
mean a lower temperature in the
appliance (cooler). Settings towards
the mean a higher temperature
(warmer).
If the temperature of the room where
the appliance is installed is below 16 °C,
we recommend setting the A .
• After the appliance is switched on, it may take several hours for the set
temperature to be reached. Do not place any food into the refrigerator
before the temperature drops to the selected setting.
i
573319
18
INTENSIVE COOLING AND FREEZING
• We recommend using this setting before cleaning the appliance or 24 hours
before inserting a large amount of food. Activating this function will make sure
the food is cooled or frozen faster to retain vitamins, minerals, nutrients, and
fl avour, and to extend its freshness.
• Switching on the intensive cooling
and freezing: Rotate the A dial to
position
.
• When the intensive cooling/freezing
function is activated, the appliance
will operate with maximum power.
During this time, operation may be
somewhat louder.
• After the end of the intensive cooling/freezing cycle, rotate the A dial back to
the desired setting.
If the function is not deactivated manually, it will be deactivated automatically
after approximately two days. The temperature returns to the most recently set
value.
573319
19
APPLIANCE INTERIOR
EQUIPMENT
(* EQUIPMENT DEPENDS ON THE MODEL)
573319
SHELF
WIRE BOTTLE RACK*
• Some models also feature a wire
bottle holder. It is protected against
being inadvertently pulled out. It can
only be pulled out when it is empty.
To pull it out, lift it slightly at the
front and pull it towards you. Place
the bottle holder so that the length
of the bottles does not prevent
proper closing of the door.
The holder can take a maximum load of 9 0.75-litre bottles or 13 kilograms of
total weight – see label on the right side in the appliance interior.
• Cans may also be placed on the bottle rack (lengthwise or crosswise).
• Empty shelves can be distributed
as you see fi t across the guides in
the refrigerator interior without
having to remove the shelf from the
refrigerator.
To only move the shelf to a di erent
height/guide, lift it at the front, hold
it at the back, and move it higher
or lower. To take the shelf from the
refrigerator, fi rst lift it at the front
part, hold it at the back part, and pull
it out from the appliance.
Store quickly perishable food at
the back of the shelf where the
temperature is the lowest.
20
573319
FRUIT AND VEGETABLE BIN WITH
HUMIDITY CONTROL
• The bin at the bottom of the refrigerator is intended for storing fruit and
vegetables. It provides humidity and prevents the food from drying out. The
bin has integrated humidity regulator which allows setting the humidity level.
Slider position to the right: closed
vents, higher humidity in the bin
Slider position to the left: open vents,
lower humidity in the bin
If you observe droplets accumulating
below the glass shelf, open the vents
and wipe the shelf (see chapter
TROUBLESHOOTING).
• Pulling out the bin:
- Pull out the bin as far as it will go.
Then, lift the front part and pull it
out completely.
21
Interior side of the refrigerator door is
fitted with shelves intended for storing
cheese, butter, eggs, yoghurt, and
other smaller packages, tubes, cans
etc.
The height of the shelves is adjustable.
Simply lift the shelf from the groove
and place it to desired position.
Maximum load on each door shelf is
5kg.
• If the tray is used as an egg tray,
place it directly on the bottom of a
door shelf.
• If the tray is used as an ice tray, fi ll it
with water and place it in the freezer
in a horizontal position.
573319
ADJUSTABLE DOOR SHELVES
EGG/ICE TRAY
INTERIOR SIDE OF THE REFRIGERATOR DOOR
The shelves mounted on the interior side of the refrigerator door are intended
for storing cheese, butter, eggs, yoghurt and other smaller packages, tubes,
cans, etc. There is a bottle shelf at the lower end of the door.
22
573319
Switching the fan and ionizer on and off:
On = Off = 0
When the fan is switched on, a red dot will be visible on the switch.
FAN*
• The fan contributes to more even temperature distribution and faster cooling,
and reduces dew (or condensate) accumulation on the storage surfaces.
• We recommend switching on the fan as an extra function in the following
cases:
- when the room temperature is higher (over 30 °C);
- when humidity is higher or when dew (condensate) accumulates on the
shelves;
- when inserting a large amount of food (rapid cooling).
Note: When the fan is activated, power consumption is increased, temperature
in the refrigerator is lowered, and as a result, the temperature in the freezer
changes as well.
To maintain the same temperature in the refrigerator compartment as before
the fan was activated, we recommend rotating the A knob slightly towards the
. Adjustment of temperature in the refrigerator directly affects the freezer
temperature.
• Advanced fan system with dynamic cooling evenly distributes the ionized air
and equalizes the temperature throughout the entire refrigerator. Air enriched
with extra negative ions mimics the natural microclimate that keeps the food
fresh for longer. Moreover, the any type of food can be placed on any shelf in
the fridge as there are not temperature di erences.
• To switch the air ionizer on and o , use the switch located on the fan housing.
AIR IONIZER (IonAir)*
23
RECOMMENDED DISTRIBUTION
OF FOOD IN THE APPLIANCE
573319
Sections in the refrigerator compartment:
- Upper part: canned food, bread, wine, pastry etc.
- Middle part: dairy products, ready-made meals, desserts, soft drinks, beer,
cooked food, etc.
- Fruit and vegetable bin: fresh fruit, vegetables, salads, root vegetables,
potatoes, onions, garlic, tomatoes, sauerkraut, turnips etc.
PIZZA
Sections in the refrigerator
compartment door:
- upper/middle door bins: eggs,
butter, cheese etc.
- lower door bins: beverages, cans,
bottles etc.
Freezer sections:
- freezing, storing frozen food (see chapter Freezing and storing frozen food).
Do not store fruit (bananas,
pineapples, papaya, citruses) and
vegetables (zucchini, eggplant,
cucumbers, bell peppers,
tomatoes, and potatoes) sensitive
to low temperatures in the
refrigerator.
i
Do not store the following in the freezer: lettuce, eggs, apples, pears,
grapes, peaches, yoghurt, soured milk, sour cream, and mayonnaise.
i
24
STORING FOOD IN THE
REFRIGERATOR
573319
IMPORTANT WARNINGS REGARDING FOOD STORAGE
i
Correct use of the appliance, appropriate packaging,
maintaining the right temperature, and observing the food
hygiene standards have a decisive impact on the quality
of food storage.
Observe the expiry dates for the food, indicated on the
packaging.
Food stored in the refrigerator should be kept in closed
containers or in appropriate packaging to prevent it from
emitting or receiving odours and humidity.
Do not store inflammable, volatile, and explosive
substances in the refrigerator.
Bottles with high alcohol content should be tightly sealed
and stored in an upright position.
Some organic solutions, essential oils in lemon and orange
peel, butter acid, etc. may damage the plastic surfaces
in case of a prolonged contact, causing damage and
premature ageing of these materials.
Unpleasant odour warns of lacking cleanliness of the
appliance or perished contents (see chapter Cleaning the
Appliance).
If you are leaving home for a longer period of time,
remove perishables from the refrigerator.
AVOID CONTAMINATION OF FOOD
To avoid contamination of food, please respect the following instructions:
• Opening the door for long periods can cause a signifi cant increase of the
temperature in the compartments of the appliance.
• Regularly clean surfaces that can come in contact with food and accessible
drainage systems.
• Store raw meat and fi sh in suitable containers in the refrigerator, so that it is
not in contact with or drip onto other food.
• If the refrigerating appliance is left empty for long periods, switch o , defrost,
clean, dry, and leave the door open to prevent mould developing within the
appliance.
25
573319
STORING FOOD
TYPE OF FOOD Optimum
storage
temperature (°C)
Optimum
storage humidity
level (%)
Approximate
storage time
Pork -1 to 4 95 3 days
Beef 0 to 4 95 up to 3 weeks
Lamb 0 to 4 95 14 days
Chicken 0 to 4 95 3 days
Fish 0 to 4 95 3 to 10 days
Mollusc 0 to 4 95 2 days
Wet-aged beef 1,5 95 16 weeks
Dairy products
(yoghurt, sour
cream, butter,
soft cheese,
cheese spreads
etc.)
2 to 4 95 7 to 10 days
Beetroot 0 95 3 to 5 months
Broccoli 0 95-100 10 to 14 days
Cabbage, young 0 98-100 3 to 6 weeks
Carrots, ripe 0 98-100 4 to 5 months
Lettuce, winter 0 95-100 2 to 3 weeks
Garlic 0 65-70 6 to 7 months
Kohlrabi 0 98-100 2 to 3 months
Brussels sprouts 0 90-95 3 to 5 weeks
Cabbage,
Chinese
0 95-100 2 to 3 months
Cabbage, late
varieties
0 98-100 3 to 4 months
Carrots 0 95-100 2 weeks
Cauliflower 0 95-98 2 to 4 weeks
Celery, regular 0 98-100 2 to 3 months
Swiss chard 0 95-100 10 to 14 days
Radicchio 0 95-100 2 to 4 weeks
Corn, sweet 0 95-98 5 to 8 days
26
573319
TYPE OF FOOD Optimum
storage
temperature (°C)
Optimum
storage humidity
level (%)
Approximate
storage time
Leeks 0 95-100 2 to 3 months
Mushrooms 0 95 3 to 4 days
Parsley 0 95-100 2 to 3 days
Parsnip 0 98-100 4 to 6 months
Radish, winter 0 95-100 2 to 4 months
Horseradish 0 98-100 10 to 12 months
Cauliflower 0 to 2 90-95 2 to 4 weeks
Onions 0 to 2 65-70 6 to 7 months
Asparagus 0 to 2 95-100 2 to 3 weeks
Peas, green 0 to 2 95-98 1 to 2 weeks
Vegetables,
chopped
0 to 2 90-95 up to 5 days
Brussels sprout 0 to 2 90-95 1 to 2 weeks
Gooseberries 0 to 2 90-95 3 to 4 weeks
Cucumbers 4 to 10 95 10 to 14 days
Potatoes 7 to 10 90-95 up to 9 months
Avocado, unripe 7 to 10 85-95 up to 6 weeks
Bell peppers 7 to 10 90-95 2 to 3 weeks
Tomatoes 10 to 12 85-90 4 to 7 days
Beans, seeds < 15 40-50 6 to 10 months
Pears -3 90-95 2 to 7 months
Apricots -1 90-95 1 to 3 weeks
Strawberries 0 90-95 3 to 7 days
Raspberries 0 to 2 90-95 2 to 3 days
Currants 0 to 2 90-95 1 to 4 weeks
Blueberries 0 to 2 90-95 14 days
Cherries 0 to 2 90-95 2 to 3 weeks
Grapes 0 to 2 85 2 to 8 weeks
Kiwi, ripe 0 to 2 90-95 1 to 3 months
Peaches 0 to 2 90-95 2 to 4 weeks
27
573319
TYPE OF FOOD Optimum
storage
temperature (°C)
Optimum
storage humidity
level (%)
Approximate
storage time
Cherries 0 to 2 90-95 2 to 3 weeks
Kiwi, unripe 0 to 2 90-95 2 to 6 months
Nectarines 0 to 2 90-95 1 to 3 weeks
Oranges 0 to 2 90-95 2 to 4 weeks
Persimmon 0 to 2 90-95 2 to 3 months
Plums 0 to 2 90-95 2 to 5 weeks
Fruit, chopped 0 to 2 90-95 up to 10 days
Apples 0 to 4 90-95 1 to 12 months
Melons 4 90-95 15 days
Oranges 4 to 7 90-95 2 to 4 weeks
Tangerines 5 to 8 90-95 2 to 4 weeks
Mango 10 to 13 85-95 2 to 3 weeks
Melons 10 to 13 85-95 1 to 2 weeks
Pineapples 10 to 13 85-95 2 to 4 weeks
Lemons 11 to 13 90-95 2 to 3 weeks
Watermelon 12 to 15 85-95 1 to 3 weeks
Bananas, ripe 13 to 16 85-95 3 days
Grapefruit 13 to 16 90-95 1 to 3 weeks
28
573319
STORING FOOD IN THE
FreshZone DRAWER
In the FreshZone compartment, food stays fresh longer than in a conventional
refrigerator, retaining more flavour and nutrients.
Decay and loss of mass are slowed down; therefore, fruit and vegetables remain
fresh and natural longer. For optimum performance, the drawer should be fully
closed.
• When buying food, make sure it is fresh as this will determine the quality of
the food, as well as how long it will keep in the fridge.
• Store the food in closed containers or appropriate packaging to prevent it
from emitting or receiving odours.
• Take the food from the drawer 30 to 60 minutes before use to allow the aroma
and fl avour develop at room temperature.
• Food sensitive to low temperature and not appropriate for storage in the
FreshZone drawer includes the following: pineapples, avocado, bananas,
olives, potatoes, eggplant, cucumbers, beans, peppers (capsicum), melons,
watermelons, pumpkins, squash, zucchini etc.
• To remove the drawer:
- Pull out the drawer until it is
blocked.
- Lift it at the front and pull out
completely.
(Only some models are fitted with this drawer)
29
FREEZING AND STORING FROZEN
FOOD
573319
i
Only use the freezer to freeze food appropriate for freezing.
Always use quality and fresh food.
Select the most suitable packaging for the food and use the
packaging correctly.
Make sure the packaging is air and water tight so that the
food does not dry out and loose its vitamins.
Indicate the type of food, amount, and date of freezing on
the packaging.
It is important that the food freezes quickly. Therefore,
smaller packages are recommended. Refrigerate the food
before freezing.
IMPORTANT WARNINGS ON FREEZING
i
Maximum amount of fresh food that may be inserted
at once is specified on the appliance rating plate. If
the amount of food to be frozen exceeds the indicated
amount, the quality of freezing will be inferior; in addition,
the quality of the food already frozen will deteriorate.
• Activate the super freeze function 24 hours before freezing fresh food:
- Control unit 1: Rotate the A dial towards the
(see chapter INTENSIVE
COOLING AND FREEZING).
- Control unit 2: Rotate the A dial to position .
Make sure the fresh food is not in contact with the food that is already frozen.
• When freezing smaller amounts of food (1-2 kilograms), activating the super freeze
function is not required.
• After the freezing process, rotate the A knob back to the desired setting.
FREEZING PROCEDURE
30
573319
FROZEN FOOD STORAGE TIME
RECOMMENDED STORAGE TIME IN THE FREEZER
Type of food Time
fruit, beef from 10 to 12 months
vegetables, veal, poultry from 8 to 10 months
Venison from 6 to 8 months
Pork from 4 to 6 months
finely chopped or ground meat 4 months
bread, pastry, cooked meals, lean fish 3 months
entrails 2 months
smoked sausage, fatty fish 1 month
DEFROSTING FROZEN FOOD
Freezing the food does not kill the microorganisms. After the food is defrosted
or thawed, bacteria are re-activated and the food spoils quickly. Use the
partially or completely defrosted food as soon as possible.
Partial thawing decreases the nutritive value of the food, particularly fruit,
vegetables, and ready-to-eat food.
STORING INDUSTRIALLY FROZEN FOOD
• When storing and using frozen food, observe the manufacturer's instructions.
Temperature and expiry date are indicated on the packaging.
• Only choose food with undamaged packaging, stored in freezers at
temperatures of –18 °C or lower.
• Do not purchase food covered in frost as this indicates it has been partly
thawed several times and that it is of inferior quality.
• Protect the food from thawing during transport. In case of an increase in
temperature, storage time will be shorter and quality will deteriorate.
31
DEFROSTING THE APPLIANCE
573319
Refrigerator does not need defrosting because the ice on the back interior wall
is thawed automatically.
Any accumulated ice will melt when the compressor unit is inactive. Drops will
flow through an opening in the refrigerator rear wall into a tray fitted above the
compressor, from where they will evaporate.
Make sure the opening in the back wall in the refrigerator interior is never
blocked by food or any other object.
If an excessive layer of ice is formed on the rear wall of refrigerator interior
(3–5 mm), switch off the appliance and defrost the appliance manually.
AUTOMATIC REFRIGERATOR DEFROSTING
DEFROSTING A CONVENTIONAL FREEZER
• Defrost the freezer when an approximately 3–5 millimetre layer of frost or ice has
built up.
• 24 hours before defrosting, activate the super freeze function to additionally
cool the food (see section Freezing procedure).
After this period, remove the food from the freezer and protect them from
defrosting.
• Switch o the appliance (see chapter Switching the appliance on/o ) and
unplug the power cord.
• Do not use a knife or any other sharp object to remove the frost, as you may
damage the cooling system.
• Do not use a knife or any other sharp object to remove the frost, because you
may damage a pipe of the cooling system.
• To speed up the defrosting process, place a pot of hot water on the glass shelf.
• Clean and dry the appliance interior (see chapter Cleaning the Appliance).
32
CLEANING THE APPLIANCE
573319
• Use a soft cloth to clean all surfaces. Cleaners that contain abrasive
substances, acids, or solvents are not suitable for cleaning as they may
damage the surface.
Clean the appliance exterior with water or a mild solution of suds.
Lacquer-coated and aluminium surfaces may be cleaned with lukewarm water
to which you have added a mild detergent. Use of cleaners with low alcohol
content is allowed (e.g. window cleaners). Do not use cleaners containing
alcohol for cleaning plastic materials.
• A gutter and an opening for
discharging the water from thawed
frost deposits are located underneath
the cooling panel that cools the
refrigerator interior. The gutter and the
opening may not be clogged. Inspect
them often and clean if necessary (e.g.
with a plastic straw).
• Frost or ice build-up, 3–5 mm thick,
will increase power consumption.
Therefore, it should be regularly
removed. Do not use any sharp
objects, solvents, or sprays.
• The condenser unit mounted on the
(exterior) back wall should always be
kept clean, free of dust or deposits
resulting from kitchen smoke or
fumes. Occasionally clean the dust
using a soft non-metal brush or a
vacuum cleaner.
• After cleaning, switch the appliance
back on and insert the food.
Appliance interior can be cleaned with lukewarm water to which you can
add some vinegar.
Before cleaning, unplug the appliance from the power mains – switch off
the appliance (see chapter Switching the Appliance On/Off) and unplug
the power cord from the wall outlet.
!
• Do not wash the parts of appliance interior equipment in a dishwasher as
they may be damaged.
33
TROUBLESHOOTING
Problem: Cause or remedy
Appliance is connected
to the power mains but
it does not work.
• Make sure there is voltage in the power outlet and
that the appliance is switched on.
Cooling system
operates continuously
for a long period of
time:
A
• Too high environment temperature.
• Door opened too frequently or too long.
• Door not closed correctly (possible impurities on
the seal, misaligned door, damaged seal etc.).
• Too much fresh food inserted at once.
• Sensor in the refrigerator (A) blocked by fresh
food. Make sure the air can circulate around the
sensor (only with some models).
• Insufficient compressor and condenser unit
cooling. Check for sufficient air circulation behind
the appliance and clean the condenser unit.
Excessive build-up of
ice on the back wall
of refrigerator interior
can be a result of the
following:
• Door opened too frequently or too long.
• Warm food placed in the refrigerator.
• Food or containers in contact with the back
interior wall of the refrigerator.
• Poor door sealing.
• If the seal is dirty or damaged, clean or replace it.
Build-up of ice or frost
in the freezer interior
may be a result of the
following:
• Door opened too frequently or too long.
• Door not properly closed.
• Poor door sealing.
• If the seal is dirty or damaged, clean or replace it.
Condensate (dew) on
the shelf above the
drawers:
• This is transient phenomenon which cannot be
entirely avoided in periods of high environment
temperature and humidity. It subsides when
temperature and humidity are normalized. We
recommend cleaning the drawers more frequently
and wiping the droplets occasionally.
• Open the humidity control slider.
• Place the food in to bags or other airtight
packaging.
573319
34
Problem: Cause or remedy
Water is dripping/
leaking from the
refrigerator:
• Clogged water discharge opening or water
dripping past the water gutter.
• Clean the blocked opening, e.g. using a plastic
straw.
• If a thick layer of ice builds up, defrost the
appliance manually (see Defrosting the Appliance).
Door is difficult to open: • If you are trying to open the freezer door after
just having closed it, this could be difficult to do.
As you open the door, some cool air escapes from
the appliance and it is replaced by warm air from
the environment. When this air is cooled, negative
pressure is generated which results in problems as
you try to open the door. After a few minutes, the
condition is normalized and the door can be easily
opened again.
LED lighting does not
work:
• If LED lighting does not work, call a service
technician.
• Do not attempt a repair of the LED lighting
yourself, as there is danger of contact with high
voltage!
If the above tips do not resolve your problem, call the nearest authorized service
centre and state the type, model, and serial number indicated on the appliance
rating plate or label located in the appliance interior.
573319
35
INFORMATION ABOUT
APPLIANCE NOISE
573319
Cooling in refrigerator freezers is made possible by a cooling system that also
includes a compressor (and a fan with some appliances), which generates some
noise. The level of noise depends on installation, proper use, and age of the
appliance.
• After connecting the appliance to the power mains, compressor operation,
or the sound of fl owing liquid, may be somewhat louder. This is not a sign
of malfunction and it will not a ect the useful life of the appliance. In time,
appliance operation and this noise will become quieter.
• Sometimes, unusual or loud noises may appear during appliance operation;
these are mostly the result of improper installation:
- The appliance must stand level and stable on a solid base.
- The appliance may not be in contact with a wall or adjacent furniture.
- Make sure the interior equipment sits firmly in its place and that the noise is
not caused by rattling cans, bottles or other containers placed next to each
other.
• Due to the higher workload on the cooling system when the door is opened
more frequently or for a longer time, when a large amount of fresh food is
introduced or when intensive freezing or cooling functions are activated, the
appliance can temporarily generate more noise.
WE RESERVE THE RIGHT TO CHANGES THAT DO NOT AFFECT THE
APPLIANCE FUNCTIONALITY.
COOLER 4* BI540 ESS en (11-21)
